CLOSING THE BUSINESS-APPLICATION GAP IN SOA

Challenges and Solution Directions

Boris Shishkov

Department of Computer Science, University of Twente, Enschede, The Netherlands

Jan L.G. Dietz

Department of Software Technology, Delft university of Technology, Delft, The Netherlands

Marten van Sinderen

Department of Computer Science, University of Twente, Enschede, The Netherlands

Keywords: Business-software alignment; Software services; Service-Oriented Architecture - SOA.

Abstract: Adequately resolving the business-software gap in the context of SOA (Service-Oriented Architecture)

appears to be

a non-trivial task, mainly because of the dual essence of the service concept: (i) services are

inevitably business-restricted because they operate in real-life environments; (ii) services are also

technology-restricted because the software components realizing them have to obey the restrictions of their

complex technology-driven environments. Hence, the existence of these two restriction directions makes the

(SOA-driven) business-software alignment challenging – here current business-software mapping

mechanisms can only play a limited role. With regard to this, the contribution of the current paper is two-

fold: 1. it analyzes SOA and its actual challenges, from a business-software-alignment perspective, deriving

essential SOA application desirable properties; 2. it proposes software services specification directions,

particularly concerning the (SOA-driven) business-software mapping. This contribution is expected to be

useful in current software development.

1 INTRODUCTION

Closing the semantic gap between business logic and

application logic, is claimed to be of crucial

importance for an adequate software development

(Shishkov et al., 2006a). We argue that this

endeavor fundamentally concerns the underlying

technology used and especially the restrictions it

imposes on the application. Hence, we focus on a

particular technology in this paper, namely the Web

Service Technology that can be seen as an

implementation of the

ervice-Oriented Architecture

– SOA (Pasley, 2005). SOA provides a structure for

composing software applications based on the use of

‘services’ as building blocks that can perform

distinct functions through well defined interfaces

(Alonso et al., 2004). These services are self-

describing and platform-independent, and as such

they are actually considered as fundamental

computational elements in the composition of

business processes; this makes them advantageously

usable in developing software solutions (that

concern the business system to be supported), as

concluded in previous work (Shishkov et al., 2006b).

We can consider SOA as a conceptual business

arch

itecture wh

ere business/application functionality

is made available to users, as shared, re-usable

services (modules of business/application

functionality) on a network (Marks & Bell 2006),

invokeable by messages through exposed interfaces.

Hence, the ability of finding, selecting and

com

posing services without prior agreement results

in a ‘loose coupling’, which, together with the

availability of service standards, bring potential

benefits of increased software re-use, easier

application integration and higher business agility

(Caceres et al., 2004).

333

Shishkov B., L.G. Dietz J. and van Sinderen M. (2007).

CLOSING THE BUSINESS-APPLICATION GAP IN SOA - Challenges and Solution Directions.

In Proceedings of the Second International Conference on Software and Data Technologies - SE, pages 333-336

DOI: 10.5220/0001326803330336

 SciTePress

To fully benefit from this potential, it is

necessary that the specification of software services

(in the SOA context) is properly integrated in a

software design approach where the business-

software mapping is systematically elaborated. This

points to the above mentioned semantic gap which

(obviously) needs to find resolution in the SOA

context. Nevertheless, this appears to be a non-trivial

task, mainly because of the dual essence of the

service concept: (i) services are inevitably business-

-restricted because they operate in real-life

environments; (ii) services are also technology-

restricted because the software components realizing

them have to obey the restrictions of their complex

technology-driven environments. Hence, the

existence of these two restriction directions makes

the (SOA-driven) business-software alignment

challenging; as a comparison, introducing some

software systems can enforce changes in

corresponding business-level processes.

Therefore, current business-software mapping

mechanisms can only play a limited role in the

specification of software services, which appears to

be an actual and widely recognized problem.

With respect to this, the contribution of the

current paper is two-fold:

- it analyzes SOA and its actual challenges, from

a business-software-alignment perspective, deriving

essential SOA application desirable properties;

- it proposes software services specification

directions, particularly concerning the (SOA-driven)

business

-software mapping.

The paper is thus organized as follows: Section 2

– analysis; Section 3 – proposal; Section 4 -

conclusions.

2 SOFTWARE COMPONENTS

AND SOA

The emergence of Service Oriented Computing - SOC

is considered as a move towards combining real-life

business concerns and technological concerns,

envisioning a service (of a component/entity) as

defining the goal, capabilities and/or behavior (of

the component/entity) as observed by and relevant to

the users (of the component/entity) (Pasley, 2005).

A web service (WS, for short) is considered as a

self-contained, Internet-enabled service component

capable not only of performing business activities on

its own but also possessing the ability to engage

other WS in order to form higher-order business

transactions (World Wide Web Consortium, 2005).

We distinguish between composite and

constituent WS – a composite WS consists of (is

provided by an orchestration of) multiple constituent

WS, and a constituent WS is an ‘elementary’ WS,

i.e. a WS which can be used on its own or in a

composite WS (Newcomer, 2002; Papazoglou &

Kratz, 2006).

In order to be usable on a large scale, WS (which

are based on specific sets of standards) should be

somehow reflectable in certain abstractions, as an

instrument for their application in any platform

through which the Internet user accesses them.

Moreover, WS usually should not require design

‘from scratch’ because this would make them

expensive. They should instead be re-usable, using

one WS as a basis for developing another, by

making use of its core functionality (Bosworth,

2001; Papazoglou & Kratz, 2006).

We thus consider it innovative that multiple

users are able to access WS, personalize them and

finally use them. Our first conclusion is that this

usage of WS implies advanced infrastructures

and application platforms that utilize and

coordinate such (globally) re-usable services.

Furthermore, employing such generic WS for work

in domain-specific business environments means

that the service use has to be driven by appropriate

underlying business models.

Prior to their use, WS should have been

discovered (by matching requirements to advertised

names) and subjected to negotiation (since the user

must of course accept using a particular WS).

All these considerations have contributed to the

emergence of the

Service-Oriented Architecture –

SOA which goes beyond the sole consideration of

WS (Alonso et al., 2004), being a useful paradigm

that can support engineers in their designing,

building and using distributed software systems.

SOA facilitates the establishment of ICT support for

business processes, which is readily available,

flexible and easily maintainable across multiple

organizations and platforms. The concept of

service/WS adopted by SOA, has evolved from

modular object/component middleware approaches,

such as CORBA, DCOM and J2EE (Newcomer,

2002). However, WS has become the technology of

choice for implementing service-oriented software

systems, primarily because they are based on

ubiquitous Internet standards, such as HTTP and

XML, and because they support ‘loose coupling’.

Whereas the uptake of WS based SOA is impressive,

there are still important fundamental challenges not

addressed by this technology, as recognized by

ACT4SOC (ACT4SOC, 2007).

ICSOFT 2007 - International Conference on Software and Data Technologies

334

Firstly, the ‘plug and play’ interoperability of

WS to enable ad hoc cooperation of new partners is

limited (Wang & Zhang, 2006). For on-demand

composition of services in an open service-oriented

world, interoperability has to be ensured at different

levels (syntactic and semantic) and in different

dimensions (information and behavior). Current

research in this direction is using, for example,

Semantic Web and ontology technologies (World

Wide Web Consortium, 2005).

Secondly, the property of ‘loose coupling’ is not

appropriate for many applications that involve

stateful components. Hence, the benefits of Web

services and SOA would be limited for developers

of such applications if they themselves have to solve

the issues of stateful interaction, notification of state

changes, support for sharing and coordination

(Shishkov et al., 2006b). It should thus be aimed that

these concerns are placed at the service

infrastructure level or that another solution is

enforced. Thus, our second conclusion is that

enhancement needs to be achieved in the way

applications which are by nature not loosely

coupled, are supported by SOA-related

technology.

Finally, WS alone are insufficiently capable of

guaranteeing an appropriate ‘alignment’ between

business requirements and software functionality, as

mentioned already. What is needed is a structured

approach for developing service-oriented software

solutions, in which consistency with business

requirements, (de-)composition of application

services, and mapping onto (alternative) technology

platforms can be systematically and separately

addressed (Alonso et al., 2004, Shishkov et al.,

2006b). Hence, our third conclusion is that a

business-software alignment is needed

particularly in the SOA context.

Taking into account the 3 business-software-

alignment-related conclusions made in the current

section, we formulate the following 3

(corresponding) desirable properties concerning the

SOA-driven application development:

1. Application architecture must allow usage

of SOA infrastructure;

2. ‘Loose coupling’ should be enforced;

3. Application architecture must fit within the

business context.

We will consider in the following section,

several solution directions that are driven by these

properties and especially by the third one.

3 SOLUTION DIRECTIONS

In presenting solution directions in this section, we

will consider fundamentally an Alignment

perspective and a Loose-coupling perspective.

The

Alignment perspective basically concerns

desirable properties 3 and 1, as defined in Section 2.

The existence of their related restriction directions

has already been mentioned in the Introduction. We

claim that in order to adequately address them, it is

necessary that they are distinguished clearly.

As for business-level restrictions, they obviously

concern the enterprise that is going to be supported

by the services-to-be-developed. Thus, the enterprise

under consideration needs to be sufficiently

explored, which can be appropriately accomplished

through a conceptual enterprise model, as studied by

Dietz (2006). This model nevertheless would need to

be coherent (the distinguished aspect models

constitute a logical and truly integral whole),

comprehensive (all relevant issues are covered),

consistent (the aspect models are free from

contradictions or irregularities), concise (no

superfluous matters are considered) as well as

essential – revealing only the essence of the

enterprise, its deep structure. Considering this last

property as crucially important, we argue that

meeting the business-level restrictions, as above

formulated, should include a (SOA) application

specification that is realized as a REFINEMENT OF

A CORRESPONDING ESSENTIAL ENTERPRISE

MODEL. Such a model could be properly developed

using LAP-driven generic business process patterns,

as studied in (Shishkov et al., 2006a).

As for technology-level restrictions, they could

in no way concern essential issues as formulated

above. Instead, they concern realization and/or

implementation issues which are to stay consistent

with corresponding essential issues (Dietz, 2006).

Nonetheless, after mapping technology-level

restrictions on the essential enterprise model, it

might appear that a model re-design seems sensible

– this is an example of an indirect impact of

technology-level restrictions on the enterprise

model. Apart from this, technology-level restrictions

concern the application’s integration with respect to

the service infrastructure – the APPLICATION IS

TO ALWAYS FUNCTION CONSISTENTLY

WITH THE (SERVICE) INFRASTRUCTURE

THAT PROVIDES TO IT GENERIC (RE-

USABLE) SERVICES. Such a consistency can be

enforced through a network-infrastructure-

application-layered software development, as

studied in AWARENESS (2007).

CLOSING THE BUSINESS-APPLICATION GAP IN SOA - Challenges and Solution Directions

335

The

Loose-coupling perspective concerns

desirable property 2, as defined in Section 2. If

straightforwardly reflecting an enterprise model in a

SOA-driven application model, the services (which

would be identified) would inevitably be tightly

coupled because (normally) there is a dependency of

the services provided by one entity on services

provided by other entities. As concluded in

(Shishkov et al., 2006b), this could be resolved, by

introducing ‘in between’ an ADDITIONAL

APPLICATION COMPONENT (labelled

‘Orchestrator’) THAT HAS THE TASK OF

COORDINATION. The Orchestrator is application-

specific (as the coordination is application-specific).

The (subordinate) services, however, which are

coordinated by the Orchestrator, may be useful for

many different types of applications. Their

description may hence be published through a public

(or corporate) registry, such that they can be

discovered, and selected for invocation by an

orchestration component. Related to its coordination

tasks, the Orchestrator could sometimes supply to

one service the result of another service, if this is

necessary for the service to perform its task(s).

4 CONCLUSIONS

This paper proposes improvements to the business-

application alignment, particularly in the context of

SOA. Reporting work-in-progress, the paper has

only identified (relevant) application desirable

properties and corresponding solution directions.

According to the first solution direction, the SOA

application model must be developed as a

refinement of a corresponding essential enterprise

model. According to the second solution direction,

the application functionality must be specified

consistent with the (service) infrastructure. These

two solution directions are relevant (in combination)

to the objective of overcoming (especially in the

context of SOA) the semantic gap between business

logic and application logic. As for the third solution

direction, it mainly concerns the usage of generic

services, which characterizes SOA. In particular, it

is suggested that an additional application

component is introduced to handle the (application-

specific) coordination activities with respect to

(subordinate) services, in delivering application’s

functionality.

We expect that this paper and the discussion it

opens would be useful to the on-going SOA

developments aiming at putting SOC on a more

solid (theoretical) background.

ACKNOWLEDGEMENTS

This work is part of the Freeband A-MUSE project

(http://a-muse.freeband.nl). Freeband is sponsored

by the Dutch government under contract BSIK

03025.

REFERENCES

ACT4SOC 2007: Proc. of the First Int. Workshop on

Architectures, Concepts and Technologies for Service

Oriented Computing – ACT4SOC, INSTICC Press.

AWARENESS 2007: Dutch project context AWARE

mobile NEtworks and ServiceS, Gvrnm. supported.

Alonso, G., F. Casati, H. Kuno, V. Machiraju, 2004. Web

services, concepts, architectures and applications,

Springer-Verlag. Berlin Heidelberg.

Bosworth, A., 2001. Developing Web Services. In Proc:

International Conference on Data Engineering.

Caceres, P., Marcos, E., De Castro, V., 2004. Integrating

agile and model-driven practices in a methodological

framework for the Web information systems

development. In ICEIS’04, 6th Int. Conference on

Enterprise Information Systems. INSTICC Press.

Dietz, J.L.G., 2006. Enterprise ontology, Springer-Verlag

Berlin Heidelberg.

Marks, E.A., Bell, M., 2006. Service-Oriented

Architecture, A Planning and Implementation Guide

for Businesses and Technology, John Wiley & Sons

Inc., Hoboken, New Jersey.

Newcomer, E., 2002. Understanding Web services, XML,

WSDL, SOAP and UDDI, Addison-Wesley. Boston.

Papazoglou, M.P., Kratz, B., 2006. A Business-Aware

Web Services Transaction Model. In ICSOC’06,

International Conference on Service-Oriented

Computing. Springer Berlin/Heidelberg.

Pasley, J., 2005. How BPEL and SOA are changing Web

Services development. IEEE Internet Computing,

Vol.9, Iss.3 (2005). IEEE Press.

Shishkov, B., Dietz, J.L.G., Liu, K., 2006. Bridging the

Language-Action Perspective and Organizational

Semiotics in SDBC. In ICEIS’06, 8th Int. Conference

on Enterprise Information Systems. INSTICC Press.

Shishkov, B., Van Sinderen, M.J., Quartel, D., 2006.

SOA-driven business-software alignment. In

ICEBE’06, IEEE International Conference on e-

Business Engineering. IEEE Press.

Wang, H., Zhang, H., 2006. Enabling enterprise resources

reusability and interoperability through Web services.

In ICEBE’06, IEEE International Conference on e-

Business Engineering. IEEE Press.

World Wide Web Consortium, 2005. Web Services

Description Language 1.1, W3C Note,

http://www.w3.org/TR/wsdl.

ICSOFT 2007 - International Conference on Software and Data Technologies

336
