AN APPROXIMATION-AWARE ALGEBRA FOR XML FULL-TEXT

QUERIES

∗

Giacomo Buratti

Department of Mathematics and Informatics, University of Camerino, Via Madonna delle Carceri 9, Camerino, Italy

Danilo Montesi

Department of Computer Science, University of Bologna, Mura Anteo Zamboni 7, Bologna, Italy

Keywords:

XML, Algebra, Full-Text, Approximate Query.

Abstract:

XQuery Full-Text is the proposed standard language for querying XML documents using either standard or

full-text conditions; while full-text conditions can have a boolean or a ranked semantics, standard conditions

must be satisﬁed for an element to be returned. This paper proposes a more general formal model that considers

structural, value-based and full-text conditions as desiderata rather than mandatory constraints. The goal is

achieved deﬁning a set of relaxation operators that, given a path expression or a selection condition, return

a set of relaxed path expressions or selection conditions. Algebraic approximated operators are deﬁned for

representing typical queries and returns either elements that perfectly respect the conditions and elements that

answer to a relaxed version of the original query. A score reﬂecting the level of satisfaction of the original

query is assigned to each result of the relaxed query.

1 INTRODUCTION

The study of semi-structured data and XML have re-

ceived in the last years a further boost from a new

trend: the integration of structured, semi-structured

and unstructured data into a more general framework

(INEX, 2006). A convergence between these diverg-

ing models is made necessary by the consideration

that many today’s applications have to cope with data

covering the entire spectrum. This requirement led

to the deﬁnition of many query languages for XML

with full-text capabilities; lastly, W3C has published

a Working Draft for XQuery Full-Text (W3C, 2006),

a extension of XQuery with full-text operators.

Our contribution to this convergence effort has

been the deﬁnition of AFTX (Buratti, 2007), an al-

gebra for semi-structured and full-text queries over

XML repositories. Our algebra includes either ba-

sic or full-text operators. Basic operators are used to

restructure and ﬁlter the input trees. Full-text opera-

tors perform full-text searches, either using a boolean

model or a ranked retrieval. In the ﬁrst case a binary

judgement (relevant / not relevant) is assigned to each

∗

This work has been supported by CIPE 4/2004

input tree; in the second case a score value, reﬂecting

how relevant the tree is with respect to the user query,

is calculated.

1.1 The Need for Approximation

One of the main differences between structured and

semi-structured paradigm is the ﬂexibility of the

schema. In fact the schema speciﬁcations for an XML

document can deﬁne some elements as optional, or

the cardinality of an element can differ from doc-

uments to documents; moreover, it is perfectly le-

gal for an XML document not to have an associated

schema at all. This ﬂexibility poses interesting ques-

tions for what concerns answering to a query that im-

poses some constraints on the structure of XML frag-

ments to retrieve; it could be the case that such con-

straints are satisﬁed by a very small part of input doc-

uments. Nevertheless, there could be documents that

are relevant to users, even if they do not closely re-

spect some structure constraints.

XQuery Full-Text treats basic conditions (i.e. nav-

igational expressions and constraints on value of ele-

ments or attributes) and full-text conditions in a non-

uniform way. In fact, when writing full-text con-

Buratti G. and Montesi D. (2007).

AN APPROXIMATION-AWARE ALGEBRA FOR XML FULL-TEXT QUERIES.

In Proceedings of the Second International Conference on Software and Data Technologies - Volume ISDM/WsEHST/DC, pages 62-69

DOI: 10.5220/0001327700620069

 SciTePress

ditions, it is possible to specify whether to use a

boolean semantics or to perform a ranked retrieval.

On the contrary, basic conditions are always treated

as mandatory: in order to be retrieved, an element

must be reachable by exactly following the speciﬁed

path expression, and all the conditions on values must

be satisﬁed.

In the effort of providing a uniform treatment of

basic and full-text conditions, the key idea is to con-

sider the searched path expression and the speciﬁed

conditions on values as desirable properties to enjoy

for an element to be returned, instead that consider-

ing them as mandatory constraints. Therefore, an el-

ement should be returned even if it does not perfectly

respect basic conditions, and a score value should in-

dicate how well such conditions are satisﬁed.

1.2 A Motivating Example

Consider the XML document shown graphically in

Figure 1. Suppose a user writes an XQuery ex-

pression containing the for clause for $a in doc(

“bib.xml”)/bib/book/author. The user need is

probably to ﬁnd all book authors, including those who

just co-authored a book. The for clause, however,

will ﬁnd only those authors that are the single authors

of at least one book. If the for clause has an approx-

imated behavior, it could also return a subtree reach-

able by following an relaxed version of the original

path expression, for example /bib/book//author,

therefore including co-authors in the result.

This relaxed query would ﬁnd all the book au-

thors, but not the paper authors. It could be the

case that such authors are also of interest for the

user. The user need could be satiﬁsﬁed by fur-

ther relaxing the query, i.e. the path expression

/bib/book//author could be transformed into the

path expression /bib//author.

Suppose now the user writes an expres-

sion containing the clause for $a in doc(

“bib.xml”)/bib/book/title. Such a query ﬁnds

all the book titles, but ignores paper titles, which

could also be interesting for the user. In fact some

semantic relationship exists between the words

book and paper: using some lexical database (e.g.

(Princeton University, 2007)) we can ﬁnd that both

these words are hyponyms of the word publication.

Considering such a relationship, a different kind of

relaxation could treat the path /bib/paper/title

as a approximated version of /bib/book/title and

therefore include in the result also the paper titles.

Let us now consider a for clause including a ﬁlter

predicate based on the full-text operator ftcontains,

like the following:

for $a in doc("bib.xml")//paper

[//section/title ftcontains "INEX"]

We are looking for papers that include in a section

title the word INEX. The paper shown in Figure 1 is

not returned, because the titles of the various sections

do not include the searched word. However, the word

is included in the content of the ﬁrst section of the

paper, therefore the paper is probably of interest for

the user. A possible relaxation could transform the

previous query by removing the last step in the path

expression, thus obtaining:

for $a in doc("bib.xml")//paper

[//section ftcontains "INEX"]

As a ﬁnal example, consider the partial query

for $b in doc("bib.xml")/bib/book

where $b /price < 39

The user wants to ﬁnd books with a price lower than

39. However, it could be the case that very few books

satisfy such a constraint (in the document of Fig-

ure 1, no book satisﬁes the constraint); consequently,

the user could also be interested in books having a

price of 39, or even in books having a price not much

greater than 39. A relaxed version of the where clause

could return such books, by substituting the condi-

tion $b/price < 39 with an approximated version

of it, obtained by changing the comparison operator

($b/price ≤ 39) or even increasing the threshold

price ($b/price < 45).

1.3 Our Contribution

The purpose of this paper is to formally deﬁne the

notion of query relaxation that has been informally

presented. Section 2 represents the core of the pa-

per; here we introduce the various relaxation opera-

tors, that perform one of the following tasks: 1) given

a path expression, deﬁne a set of relaxed path expres-

sions; 2) given a predicate on a element value, deﬁne

a set of relaxed predicates.

With respect to (Amer-Yahia et al., 2004), the pa-

per that mainly inﬂuenced us, our work has the advan-

tage of considering a wider spectrum of relaxations.

Moreover, we incorporate the notion of approxima-

tion into a general algebraic framework suitable for

representing queries over XML.

The relaxation operators are then used in Section

3 to deﬁne a set of approximated algebraic operators.

These operators are a variant of some of those pre-

viously deﬁned for AFTX; AFTX, which is brieﬂy

reviewed in the same section, is an algebra working

on forests of trees, i.e. ordered lists of trees. For a

deeper treatment of AFTX data model, algebraic op-

AN APPROXIMATION-AWARE ALGEBRA FOR XML FULL-TEXT QUERIES

bib

book

title author

Year = “1994”

publisher price

“TCP-IP

Illustrated”

last first

“Stevens” “W.”

“Addison-

Wesley”

65.95

book

title

author

Year = “2000”

publisher

price

“Data on

the Web”

last first

“Abiteboul” “Serge”

“Morgan Kaufmann

Publishers”

39.95

author

last first

“Buneman” “Peter”

author

last first

“Suciu” “Dan”

authors

paper

title

author

Year = “2000”

abstract

sections

“FleXPath: Flexible

Structure

and Full-Text

Querying for XML.”

last first

“Amer-Yahia” “S.”

“Querying XML data is a

well-explored topic…”

“...Consider querying

documents in the IEEE INEX…”

author

last first

“Lakshmanan” “L.V.S.”

authors

section

“Introduction”

title content

section

...

Figure 1: Graphical representation of an XML document.

erators, XQuery Full-Text translation, and algebraic

optimization see (Buratti, 2007).

Approximated algebraic operators are based on

the concept of score: a relaxed answer (i.e. an an-

swer to a relaxed query) has a score which reﬂects

how exact is the query that returns such an answer.

In a certain way exact and relaxed queries play the

same role of boolean and ranked retrieval in classi-

cal Information Retrieval (and in XQuery Full-Text):

while exact queries classify each document fragment

as either relevant (i.e. fulﬁlling constraints imposed

on document structure and elements / attributes value)

or not relevant, relaxed queries establish how relevant

a fragment is. The deﬁnition of an approximation-

aware algebra for XML standard and full-text search

can serve as the theoretical foundation for the deﬁ-

nition of an approximation-aware version of XQuery

Full-Text.

The main contribution of the presented work is the

formal deﬁnition of the concept of approximation in

terms of approximation operators. Therefore it should

be regarded to as a valuable starting point for future

research in the area; in Section 4, besides drawing

some conclusions, we outline some possible future re-

search directions.

2 RELAXATION OPERATORS

In this section we formally deﬁne a set of relaxation

operators. We propose two kinds of relaxation: path

relaxations and comparison relaxations.

2.1 Path Relaxations

We deﬁne four path relaxation functions: axis relax-

ation, internal step deletion, ﬁnal step deletion, and

name relaxation. Their goal is to obtain a set of re-

laxed path expressions, starting from an input path

expression.

Axis Relaxation P

approximates a path expres-

sion λ

/λ

by substituting a child axes with a de-

scendant axes, thus obtaining the relaxed expres-

sion λ

//λ

. Its goal has already been depicted

in an example in Section 1, where the path ex-

pression /bib/book/author were transformed into

/bib/book//author.

It is clear that multiple relaxed expression can

be obtained from the original expression, possi-

bly recursively applying the relaxation function; in

this example, other possible relaxed expressions

are /bib//book/author, /bib//book//author,

//bib/book//author etc. Formally, the set of ob-

tainable relaxed expressions has cardinality

∑

i=1





Internal Step Deletion P

approximates a path

expression λ

αβ//λ

(where α is an axes and

β is an element name) by eliminating the inter-

nal step αβ, thus obtaining the relaxed expression

//λ

. As an example, consider the XML doc-

ument in Figure 1 and suppose to start with the

path expression /bib/book/authors/author. Us-

ing P

we could transform it into the relaxed version

/bib/book/authors//author, but this transforma-

tion is not yet sufﬁcient to capture authors of a book

having just one author; now we can apply P

, obtain-

ing /bib/book//author, which captures either au-

ICSOFT 2007 - International Conference on Software and Data Technologies

thors and co-authors.

Final Step Deletion P

removes from the original

path expression λαβ the ﬁnal step αβ, thus obtaining

the relaxed expression λ; for example, using P

can transform the expression /bib/book/content

into the expression /bib/book. The behaviour of the

ﬁnal step deletion function is radically different to that

of P

and P

; while an application of P

or P

results

in a relaxed path expression that reaches all the ele-

ments that can be reached using the original path ex-

pression (plus some extra elements), an application

of P

results in a set of path expressions that reach

a completely different set of elements. As one could

expect, its usage is therefore different from that of the

two previous relaxations, as we will see in Section 3.

Name Relaxation P

substitutes an element

name β in a path expression λ

αβλ

with an-

other name β

, thus obtaining the relaxed expression

αβ

. For example, using P

we could trans-

form the expression//book/author into the expres-

sion //publication/author.

In the spirit of data integration, this operation

should be intended as a way to manage heterogenous

data sources disregarding possible name conﬂicts due

to the usage, for example, of synonyms in the schema

deﬁnition. Generally speaking, the Name Relaxation

function should be thought of as a way to substitute

a name with another one that has a certain degree of

similarity with it; such a similarity could be calcu-

lated, for example, using an ontology.

2.2 Comparison Relaxations

Typical operations on XML documents also involve

checking the satisfaction of a comparison predicate.

For example, having selected a set of book elements,

we could ﬁlter those element on the basis of the book

price, using the predicate /price < 50. There are

two possible relaxations we can perform on a pred-

icate like this: operator relaxation and value relax-

ation.

Operator Relaxation C

substitutes an operator

θ in a comparison expression xθy with another opera-

tor θ

, thus obtaining xθ

y. For example, using C

could transform /price < 50 into the relaxed com-

parison /price ≤ 50.

Clearly, such a transformation makes sense only if

the new operator guarantees a larger (or at least equal)

number of successful comparison than the original

one. A partial ordering relation  can be deﬁned be-

tween available operators, stating that θ  θ

if, for

each pair of operands (x,y), xθy implies xθ

y. An

example of ordering relationships between operands

on numeric values is shown in Figure 2, where an ar-

row from operand θ to operand θ

means that θ  θ

;

similarly, an ordering relationship should be deﬁned

between operators on strings, dates, etc.

< = >

<= between >=

Figure 2: Ordering between numeric operators.

Value Relaxation C

substitutes an operand y in

a comparison expression xθy with another operand y

thus obtaining xθy

. For example, using C

we could

transform /price < 50 into the relaxed comparison

/price < 55.

This relaxation, along with C

, permits to include

in the list of satisfactory elements also those whose

value slightly differs from the user request. As usual,

its goal is therefore to expand the space of possible

results. The choice of the new value y

should depend

on the comparison operator. For example, given the

comparison x < y, y

should be a value such that y

3 APPROXIMATED ALGEBRAIC

OPERATORS

In this section we deﬁne a set of approximated alge-

braic operators. For each of them, we brieﬂy recall the

semantics of the basic AFTX operator and deﬁne the

new operator on the basis of the relaxation operators

that can be used.

3.1 Approximated Projection

AFTX projection π is a unary operator that takes is

a forest and operates a vertical decomposition on it:

every input tree contributes, with the subtrees of in-

terest, to the projection output. The subtrees of inter-

est are speciﬁed in the projection predicate through a

path expression λ, a concept almost identical to that

used in XPath, except for the fact that it can not con-

tain selection conditions. For example, the AFTX ex-

pression π

/bib/book

(“bib.xml”), where bib.xml is the

XML document shown in Figure 1, returns a forest

containing two trees, that correspond to the two sub-

trees rooted at book that can be found in the input

tree.

The approximated projection π

operator has the

following behavior:

AN APPROXIMATION-AWARE ALGEBRA FOR XML FULL-TEXT QUERIES

• calculate all possible relaxation of the path ex-

pression λ in the predicate, using Axis Relaxation

, Internal Step Deletion P

, Name Relaxation

;

• for each relaxed path expression, execute the pro-

jection using that path expression;

• calculate the union of the projection results (in-

cluding the result of the projection that uses the

original path expression), eliminating duplicate

trees (i.e. subtrees reachable by following two dif-

ferent relaxed path expressions).

As one could expect, the Final Step Deletion

relaxation function P

is not used here. In fact,

such a relaxation would lead to results completely

unrelated to those expected. For example, sup-

pose we want to do a projection using the predicate

/bib/book/author; by eliminating the ﬁnal step we

would obtain the predicate /bib/book; trees result-

ing from such a projection would represent books, a

completely different concept to that of authors.

Example 1 Consider the XML document in Figure

1 and suppose to write the algebraic expression

∗

/bib/book/author

(“bib.xml”)). Using the basic AFTX

projection this expression would return only the au-

thor W. Stevens. However, by applying P

to the

projection path expression we can obtain the relaxed

path expression /bib/book//author, thus including

in the result also Serge Abiteboul, Peter Buneman,

and Dan Suciu. Moreover, by applying P

we can

substitute book with paper, thus obtaining the path

expression /bib/paper//author and adding to the

result also S. Amer-Yahia and L.V.S. Lakshmanan.

3.2 Approximated Selection

AFTX selection σ is a unary operator that takes is a

forest and operates a horizontal decomposition on it:

only the trees of interest contribute, with their entire

content, to the selection output. The selection predi-

cate is composed by a path expression λ and a selec-

tion condition γ. The path expression is used to op-

erate a temporary projection on the input tree. Each

subtree T

belonging to the temporary projection re-

sult is then checked: if at least one of them satisﬁes

the selection condition, the original input tree is added

to the selection output.

The selection condition is a conjunction of base

selection conditions. The evaluation of each base con-

dition γ

depends on its form:

• if γ

is the form λ

, it is satisﬁed if exists at least

one subtree T

that can be reached from root(T

)

by following λ

;

• if γ

is the form λ

≡ λ

, it is satisﬁed if exists at

least a pair of subtrees (T

) that can be reached

from root(T

) by following, respectively, λ

and

, and such that T

is strictly equal to T

(infor-

mally, strict equality between trees means that the

two trees are two copies of the same tree);

• if γ

is the form λ

pθx, where x is a constant and p

is an element property (for example its value, the

value of one of its attributes, etc.), it is satisﬁed if

exists at least one subtree T

that can be reached

from root(T

) by following λ

such that root(T

is in relation θ with x;

• if γ

is the form λ

θλ

, it is satisﬁed if exists at

least a pair of subtrees (T

) that can be reached

from root(T

) by following, respectively, λ

and

, and such that root(T

is in relation θ with

root(T

For example, the AFTX expression

/book[/author AND /price.v<40]

(π

/bib/book

(“bib.xml”))

returns a forest containing the subtrees rooted at book

that have at least one author sub-element and such

that the value of the price sub-element is less than

40.

The approximated selection σ

operator does the

following:

• calculate all possible relaxation of the path ex-

pression λ in the predicate, using Axis Relaxation

, Internal Step Deletion P

, Name Relaxation

;

• calculate all possible relaxations of the selection

condition γ, applying some relaxation function to

each base selection condition depending on the

kind of the base selection condition;

• for each relaxed path expression and selection

condition, calculate the result of the selection;

• calculate the union of the selection results (includ-

ing the result of the selection that uses the original

selection predicate), eliminating duplicate trees.

If a base condition γ

is the form λ

, we can re-

lax λ

as usual. For example, the selection predi-

cate /book[/authors/author] can be relaxed into

/book[//author]. Moreover, P

can also be ap-

plied. For example /book[/authors/author] can

be relaxed into /book[/authors], or even into

/book[]; in practice, we relax (or even eliminate) the

constraint on the presence of a subtree.

If γ

is the form λ

≡ λ

, we can apply to λ

and

, P

and P

. For example the selection predicate

/books[/csbook/authors

/author ≡ /mathbook/authors/author] can

be relaxed into /books[/csbook//author ≡

/mathbook//author].

ICSOFT 2007 - International Conference on Software and Data Technologies

If γ

is the form λ

pθx, we can apply P

, P

and P

on λ

; for example /book[/authors/author.count

> 1] (“ﬁnd all the books with more than one author”)

can be relaxed into /book[//author.count > 1].

Moreover, we can apply C

and C

on pθx; for ex-

ample the predicate book[/price.v < 50] can be

relaxed into book[/price.v ≤ 55].

Finally, if γ

is the form λ

θλ

, we can use all

the relaxations seen for the previous case; moreover

can also be relaxed using P

, P

and P

. For ex-

ample, the predicate /books[/csbook/totalprice

< /mathbook

/totalprice] could be relaxed into /books[

/csbook/price ≤ /mathbook/price] using: 1)

Name Relaxation on /csbook/totalprice, 2) Name

Relaxation on /mathbook/totalprice, and 3) Oper-

ator Relaxation on <.

Example 2 Consider the XML document in Figure 1

and suppose to write the following algebraic expres-

sion:

∗

/book[/author/last.v=“Amer−Yahia” OR /price.v<60]

(

∗

/bib/book

(“bib.xml”)) .

Using non-approximated operators, projection re-

turns a forest containing the two books, and the sub-

sequent selection retains the book Data on the Web.

The paper is not returned, even if, having Amer-Yahia

among its authors, it is probably of interest for the

user. However, using the approximated selection and

projection operators:

• projection returns also the paper, because using

the path expression /bib/book can be trans-

formed into /bib/paper;

• selection retains the paper in the result; us-

ing P

and P

the selection predicate is

relaxed into /paper[//author/last.v =

‘‘Amer-Yahia’’ OR /price.v < 60];

• selection retains the book TCP-IP Illustrated also;

in fact the selection base condition /price.v <

60 can be transformed into /price.v < 70.

3.3 Approximated Full-text Selection

AFTX full-text selection ς behaves in a way simi-

lar to that of basic selection operator: it performs

a horizontal decomposition of the input forest, re-

taining only those trees having at least one sub-

tree satisfying the full-text selection predicate. The

full-text selection predicate allows to search one or

more words or phrases (speciﬁed by the parame-

ter γ, which is a list of word or phrases connected

with boolean operators) into the full-text value of

an element (i.e. the value of the element concate-

nated with the value of its sub-elements) or into

the value of an attribute a. Moreover, it sup-

ports proximity search. For example, the expression

/∗/title[“XML” OR “Web”]

(π

/bib/∗

(“bib.xml”))

returns all the books or papers that contain the word

XML or the word Web in the title (note that * is a wild-

card that means “any name”).

The approximated full-text selection operator

, as usual, transforms the predicate using some re-

laxation operator and returns the union of the results

of the relaxed full-text selections.

First of all, the path expression λ can

be subject to P

, P

and P

; for example,

/book/chapter/section["XML"] can be re-

laxed into /publication//section["XML"], thus

obtaining as result also those publications (like

papers) which are not divided into chapters.

Another relaxation function that is worthwhile

applying is P

, thus broadening the search scope.

For example, relaxing /book/title["XML" AND

"Algebra"] into /book["XML" AND "algebra"]

we obtain as result all the books that contain the

searched words everywhere, instead that just in the

title: we have broadened the search scope from

the full-text value of /book/title to the full-text

value of /book (that includes the full-text value of

/book/title).

Example 3 Consider the XML document in Figure 1.

Suppose we look for papers that include, in their title,

the words XML and INEX. Then we write the follow-

ing algebraic expression:

/paper/title[“XML” AND “INEX”]

(π

/bib/paper

(“bib.xml”)).

This expression would return an empty answer; in

fact the paper title contains the word XML, while

the word INEX is included only in the content of the

ﬁrst section. However, using P

we can remove the

title step in the path expression of the full-text se-

lection predicate, thus obtaining the relaxed predicate

/paper[“XML” AND “INEX”]. Therefore the paper will

be returned, because both searched words are found

in its full-text value.

3.4 Generalized Top-K and Threshold

Selection

The three approximated operators have the goal to

broaden the result space, by adding some trees that

would have been discarded by applying the corre-

sponding exact operator. Their usage is therefore

valuable, because a strict interpretation of conditions

imposed by the user query could discard trees which

could be of interest for the user, even if they do not

perfectly respect some conditions.

However, the usage of such relaxations could lead

to the opposite problem: the user who poses the query

AN APPROXIMATION-AWARE ALGEBRA FOR XML FULL-TEXT QUERIES

could be overwhelmed by a huge amount of answers.

What is needed is therefore a way to ﬁlter such results,

retaining only those that best match the user needs.

A similar problem has already been tackled in ba-

sic AFTX regarding the full-text score assignment op-

erator ξ. This operator does not perform a selection:

each input tree is returned, without ﬁltering. What it

does is to assign to each tree a score value that repre-

sents the relevance of that tree to the full-text search

condition; this value is stored in the score property

of the root element. The full-text condition is spec-

iﬁed in the score assignment predicate, in the same

way as in the full-text selection predicate. However, a

weight can be assigned to each word or phrase (within

the parameter γ) in order to specify which words (or

phrases) should highly inﬂuence score calculation.

Moreover, an extra parameter f , which can be thought

of as a function pointer, speciﬁes the way the score is

calculated.

After using full-text score assignment, a user typ-

ically wants to receive results in score order, disre-

garding those with a lower score. The solution has

been found in the introduction of two derived oper-

ators: top-K full-text selection > and threshold full-

text selection ω. They assign a score to each input

tree and return, respectively, the k trees with highest

scores and those trees whose score is higher than a

deﬁned threshold τ; in both cases trees are returned in

descending score order.

Having introduced relaxed operators into our al-

gebra, now such a process of ﬁltering and ordering

could be based on two kinds of score:

• the full-text score, which represents the level of

satisfaction of full-text conditions; such a score is

calculated by full-text score assignment;

• a new structural score, which represents the level

of satisfaction of non-full-text conditions.

Informally, the structural score should be the an-

swer to the question “how much have you relaxed

my query in order to include this tree in the result?”.

The best way to calculate such a score is not trivial to

ﬁnd; similarly, the way to combine the structural score

with the full-text score is a quite interesting problem.

Both these issues are beyond the scope of this paper

and are candidate targets for future research ((Amer-

Yahia et al., 2005) and (Marian et al., 2005) both deal

with this issue). However, supposing to have a set

of structural score calculation functions and a set of

combined score calculation functions, we can deﬁne

a generalized version of top-K >

∗

, f

(F) and thresh-

old ω

∗

, f

,τ

(F) operators, which operates as follows:

• calculate the structural score using the function

;

• combine the structural score just calculated and

the full-text score (previously calculated by some

score operator) using the function f

;

• retain in the output, respectively, the k trees with

highest score or the trees with a score higher than

τ.

Example 4 Consider the XML document shown in

Figure 1 and suppose to write the following algebraic

expression:

∗

, f

(ξ

/∗/title[0.2 “We b” OR 0.8 “XML”]f

(

∗

/bib/book

(“bib.xml”))) .

The projection ﬁnd all books, then the score as-

signment calculates a score, using the scoring func-

tion f and considering the word XML more impor-

tant than Web; ﬁnally the generalized top-K returns

the book with the highest combined score.

By applying P

to the path expression, the relaxed

projection returns a forest containing three trees, cor-

responding to the two books and to the paper. Sup-

pose the full-text scoring function f calculates a sim-

ple sum of the weights of the found words; then the

full-text score of the two books are, respectively, 0 and

0.2, while the paper has a full-text score of 0.8.

Suppose now the structural score function f

when P

has been used, assigns a structural score

corresponding to the degree of similarity between the

original word and the substitute, and suppose that the

similarity between book and paper is 0.7. Therefore,

the two books has a structural score of 1 (because no

relaxation has been done for them), while the paper

has a structural score of 0.7.

Finally, suppose the combined score calculation

function f

returns a weighted sum of the structural

score (with weight 0.2) and the full-text score (with

weight 0.8). Then: the book TCP-IP Illustrated has

a combined score of 1 ∗ 0.2 + 0 = 0.2; the book Data

on the Web has a combined score of 1 ∗ 0.2 + 0.2 ∗

0.8 = 0.36; the paper has a combined score of 0.7 ∗

0.2 + 0.8 ∗ 0.8 = 0.78. Therefore, the generalized top-

k operator returns the paper, which is the publication

with the highest combined score.

4 CONCLUSION AND FUTURE

WORK

In this paper we have presented an approximation-

aware theoretical framework for full-text search over

XML repositories. Some relaxation operators have

been presented and used for deﬁning approximated al-

gebraic operators. The algebra is intended as a formal

basis for the deﬁnition of an approximated query lan-

ICSOFT 2007 - International Conference on Software and Data Technologies

guage for XML, which should be an extension of the

actual W3C candidate standard, XQuery Full-Text.

As already mentioned, a ﬁrst future research di-

rection is the development of valid scoring methods

for calculating the structural score of a tree, i.e. a

score reﬂecting how precisely a tree satisﬁes the struc-

tural conditions imposed by a user query. Moreover,

a set of combined score calculation functions should

be developed; their goal is to combine the structural

score and the full-text score, returning a global score

reﬂecting how precisely a tree satisﬁes structural and

full-text conditions. The combined score calculation

function should enjoy some properties, e.g. the value

of the result should be a continuous function of the

weights assigned to structural and full-text score (Fa-

gin and Wimmers, 2000).

Considering structural constraints of a query as a

desiderata instead that a requirement also poses inter-

esting performance issues. In fact, dealing with relax-

ation means transforming a query into a set of similar

queries, each of which must be executed in order to

calculate the ﬁnal result. It is therefore needed a way

to efﬁciently compute such answers. This problem is

closely related to that of score calculation; again, the

usage of scoring functions enjoying some properties

(like monotonicity) should allow the deﬁnition of im-

pacting optimization strategies, for example allowing

to prune some part of the tree of the possible relaxed

queries, which means avoiding to execute part of the

relaxed queries.

REFERENCES

Amer-Yahia, S., Koudas, N., Marian, A., Srivastava, D.,

and Toman, D. (2005). Structure and Content Scor-

ing for XML. In Proceedings of the 31st International

Conference on Very Large Data Bases (VLDB 2005),

pages 361–372, Trondheim, Norway.

Amer-Yahia, S., Lakshmanan, L. V. S., and Pandit, S.

(2004). FleXPath: Flexible Structure and Full-Text

Querying for XML. In Proceedings of the ACM SIG-

MOD International Conference on Management of

Data, pages 83–94, Paris, France.

Buratti, G. (2007). A Model and an Algebra for

Semi-Structured and Full-Text Queries (Ph.D. The-

sis). Technical Report UBLCS-2007-03, University

of Bologna.

Fagin, R. and Wimmers, E. L. (2000). A Formula for In-

corporating Weights into Scoring Rules. Theoretical

Computer Science, 239(2):309–338.

INEX (2006). INitiative for the Evaluation of XML

Retrieval. http://inex.is.informatik.

uni-duisburg.de/2006/.

Marian, A., Amer-Yahia, S., Koudas, N., and Srivastava,

D. (2005). Adaptive Processing of Top-K Queries

in XML. In Proceedings of the 21st International

Conference on Data Engineering (ICDE 2005), pages

162–173, Tokyo, Japan.

Princeton University, C. S. L. (2007). Wordnet.

http://wordnet.princeton.edu/.

W3C (2006). XQuery 1.0 and XPath 2.0 Full-Text,

W3C Working Draft. http://www.w3.org/TR/

xquery-full-text/.

AN APPROXIMATION-AWARE ALGEBRA FOR XML FULL-TEXT QUERIES
