TEST COVERAGE ANALYSIS

FOR OBJECT ORIENTED PROGRAMS

Structural Testing through Aspect Oriented Instrumentation

Fabrizio Baldini, Giacomo Bucci, Leonardo Grassi and Enrico Vicario

Dept. Sistemi e Informatica, Universit

a degli Studi di Firenze

Via S. Marta 3, 50139 Firenze, Italy

Keywords:

Data Flow Analysis, Object Oriented Testing, Abstract Syntax Tree, Aspect Oriented Programming.

Abstract:

The introduction of Object Oriented Technologies in test centered processes has emphasized the importance

of ﬁnding new methods for software veriﬁcation. Testing metrics and practices, developed for structured

programs, have to be adapted in order to address the prerogatives of object oriented programming. In this

work, we introduce a new approach to structural coverage evaluation in the testing of OO software. Data ﬂow

paradigm is adopted and reinterpreted through the deﬁnition of a new type of structure, used to record def/use

information for test critical class member variables. In the ﬁnal part of this paper, we present a testing tool

that employs this structure for code based coverage analysis of Java and C

programs.

1 INTRODUCTION

Testing is the process of verifying the correctness of

a system through the exercise of its components and

functionalities (Beizer, 1990). As a part of this pro-

cess, coverage analysis is the activity of evaluating

the degree of coverage attained by performed tests

with respect to some abstraction of the system. This

provides a measure of the quality of tests, and, indi-

rectly, of the conﬁdence about the absence of residual

undetected faults. In structural approaches, these ab-

stractions are derived from the implementation of the

system according to different paradigms which may

address control ﬂow (Ntafos, 1988), data ﬂow (Rapps

and Weyuker, 1985), ﬁnite state behavior (Fujiwara

et al., 1991) (Yannakakis and Lee, 1995).

In control ﬂow analysis, coverage is evaluated

with reference to the ﬂow of control, measuring

the number of covered statements, basic blocks,

branches, conditions or paths. Data ﬂow testing ex-

tends the approach by focusing the analysis on paths

between deﬁnitions and uses of program variables

(Rapps and Weyuker, 1985). This follows a basic

rational for which “paths formed by deﬁnitions and

uses of variables are a good place to look for errors

in software” (Binder, 1994). In fact, if there’s a fault

in the program we have a good chance of detecting

it by covering the statements where the faulty-written

memory location is read. Data ﬂow theory prescribes

different coverage criteria. The most relevant is All

uses which requires that the test suite exercises at least

one def-use path between each variable deﬁnition and

every subsequent use of the same variable.

While data ﬂow theory has been developed and

successfully practiced mainly on structured program-

ming, its capabilities effectively answer to some of

the speciﬁc complexities posed by OO programming.

In fact, OO programming basically reduces the sig-

niﬁcance of control ﬂow and, at the same time, aug-

ments coupling based on concurrent def/usage of at-

tributes: control ﬂow does not follow a regular hierar-

chical pattern as in structured programming and rather

evolves in a graph-like often tangled manner; mem-

ber variables have global visibility within the class

so that class methods are coupled through the inner

state of the object; the object state is maintained even

when the ﬂow of control is not located in the object

methods; objects have global visibility within the pro-

gram, and can be concurrently invoked by a variety of

clients, thus extending coupling to the interclass level.

Several abstractions have been proposed to ad-

dress these complexities in the testing process.

Baudry, in (Baudry and Traon, 2005), proposes a

structure called Class Dependency Graph (CDG),

Baldini F., Bucci G., Grassi L. and Vicario E. (2007).

TEST COVERAGE ANALYSIS FOR OBJECT ORIENTED PROGRAMS - Structural Testing through Aspect Oriented Instrumentation.

In Proceedings of the Second International Conference on Software and Data Technologies - PL/DPS/KE/WsMUSE, pages 55-60

DOI: 10.5220/0001329200550060

 SciTePress

which is used to support design through a measure

of testability and through the identiﬁcation of some

speciﬁc anti-patterns which are supposed to be most

error-prone. The CDG is derived from a detailed

UML class diagram, which should, at the same time,

capture implementation details and designer’s intent;

the graph represents the dependency among classes

deriving from inheritance/implementation/override

and from delegation relations with no reference to

def/use coupling on class attributes. (Hong et al.,

1995) and (Gallagher et al., 2006) propose a special

type of control ﬂow graph, called Class/Component

Flow Graph, which describes the interaction among

methods of one or more classes, using the formalism

of state transition systems. The approach emphasizes

state behavior more than data ﬂow dependency on

variables accesses and requires that program behav-

ior be modeled as an FSM in a so-called Class State

Machine. However, this cannot be automatically de-

rived from code inspection and does not effectively

encompass programs with dynamic object creation.

In (Harrold and Rothermel, 1994), the structure of a

program is modeled as a Class Control Flow Graph

which extends the concept of inter-procedural con-

trol ﬂow graph (Pande and Landi, 1991) to the OO

context by capturing intra-method, inter-method and

intra-class control ﬂow deriving from decision struc-

tures and function calls. The graph is proposed as a

basis to select test cases in data ﬂow style for the lim-

ited scope of each single class.

In this paper, we address the application of data

ﬂow criteria to test coverage analysis of object ori-

ented programs. We propose a technique and a tool

performing static analysis of C

or Java code to iden-

tify def/use dependencies in the access to selected

salient attributes which occur among methods in the

intra-class and inter-class scope; these are reported

in so-called Def/Use Tables, replacing conventional

control ﬂow graphs in the representation of cases

that should be covered for reliable testing. We then

describe how Aspect Oriented Programming (AOP)

can be used to efﬁciently instrument the code to log

method invocations and to provide a basis for the of-

ﬂine evaluation of the coverage attained with respect

to def/use tables, in the reference of various data ﬂow

criteria.

The rest of the paper is organized in ﬁve sections.

In Sect. 2 and 3 we introduce Def/Use Tables as

a way of representing data ﬂow information and we

present the set of syntactic rules used for their au-

tomated retrieval through code inspection. Sect. 4

formally deﬁnes the coverage criteria developed on

Def/Use tables and describes how these criteria are

evaluated though the ofﬂine analysis of an execution

log produced by the aspect oriented (Kiczales et al.,

1997) instrumentation of the program. In Sect. 5,

we provide a description of two practical tools devel-

oped to automate coverage analysis in the testing of

Java and C

programs. Finally, a validation of these

tools, with respect to design patterns, is presented.

2 OBJECT ORIENTED DATA

FLOW

Data ﬂow testing employs an annotated version of

control ﬂow graph, called deﬁnition-use graph (Rapps

and Weyuker, 1985), to record the structural informa-

tion of the program under test. Basic blocks repre-

sent the building unit of the graph. Each node of the

deﬁnition-use graph is labeled with the set of variable

deﬁnitions (def) and uses (c-use or p-use) performed

in the corresponding basic block.

In our approach, we identify basic blocks with

method invocations without unfolding the control

ﬂow graph within each method, this facilitates code

instrumentation for coverage evaluation and simpli-

ﬁes the analysis so as to allow to scale to the inter-

class level; at the same time, in code developed ac-

cording to a good programming practice, this simpli-

ﬁcation does not hide relevant information due to the

high cohesion between statements contained within

the body of each single method.

Moreover, we do not distinguish between p-uses

and c-uses. This is not restrictive for All Uses cover-

age and avoid the needs to parse the statements that

encompass the expressions in which an attribute is re-

ferred to.

2.1 Def/Use Tables

The deﬁnition-use graph provides a global represen-

tation of data accesses in the program. In our work,

the graph structure has been replaced by an annotated

structure, called Def/Use table, expressing data ﬂow

information with respect to single variables.

We deﬁne a Def/Use table as follows: let x be the

member variable under observation. Let T

use

(x) be

the set of methods (functions) performing at least a

use on x and let T

de f

(x) be the set of methods (func-

tions) performing at least a deﬁnition on x. Let n and

m be the size of T

use

(x) and T

de f

(x), respectively. A

Def/Use table for variable x is a n-row, m-column

table where rows are labeled with the elements of

use

(x) and columns are labeled with the elements of

de f

(x). Note that, if x is read and written within the

body of one method m, then m will be an element of

both T

use

(x) and T

de f

(x) and will appear in both a row

ICSOFT 2007 - International Conference on Software and Data Technologies

and a column of the x table. A Def/Use table represen-

tation for attribute

age

of the following class

Person

is reported in Table 1.

class Person {

public:

Person() {age = 0;}

˜Person(){}

void birthday() {age = age +1;}

int getYears() {return age;}

bool isAdult() {return age>=18;}

private:

int age;

};

Table 1: Def/Use table for the attribute age of class Person.

class:

Person

DEF

var:

age

Person() birthday()

isAdult()

USE getYears()

birthday()

Each cell of a Def/Use table can be regarded as a path

between a def node and a use node of the deﬁnition-

use graph. The set formed by such deﬁnition clear

paths is thus given by the Cartesian product between

the columns and the rows of the table. The number of

the resulting (DEF

method, USE method) sequences

is anyway to be considered as a theoretical upper

bound of the number of feasible paths. The identi-

ﬁcation of infeasible paths is a complex data ﬂow is-

sue (Holley and Rosen, 1981) and has not been part

of this research. Indeed, during coverage evaluation,

we accepted the structural or semantical infeasibility

of some speciﬁc def-use pairs formed by methods not

sequentially executable by the program.

2.2 Table Levels

Def/Use tables context of analysis can be extended

to include those methods which indirectly cause an

access to the variable under observation by invoking

another method that deﬁnes or uses the variable.

Let x be the variable under observation. Let

T (x, i) be the set of functions contained in table of

level i for variable x. Let T

de f

(x, i) and T

use

(x, i)

be the subsets of T (x, i) identifying the functions

that perform a deﬁnition or a use on x. As a re-

sult, T (x, i) = T

de f

(x, i) ∪ T

use

(x, i) and, generally,

de f

(x, i) ∩ T

use

(x, i) 6= 0. Table of level i+ 1 can be

built from table of level i as follows:

• T

de f

(x, i+ 1) is formed by all methods (functions)

that directly invoke at least one method (function)

contained in T

de f

(x, i)

• T

use

(x, i+ 1) is formed by all methods (functions)

that directly invoke at least one method (function)

contained in T

use

(x, i)

As an example, consider the implementation of class

Parent

class Parent: public Person{

public:

Parent(){...};

void childBirthday(){

if(child.isAdult()){

...

}

celebrate(child);

}

protected:

int celebrate(Person& p){

p.birthday();

return p.getYears();

}

private:

Person child;

};

Parent::celebrate(Person&)

invokes directly

Person::birthday()

and

Person::getYears()

which are in the table of level 0 for the attribute

age

;

according to this,

Parent::celebrate(Person&)

will be recorded in level 1 table. The ﬁnal form of

level 1 table for

Person::age

will then be:

Table 2: Def/Use table of Level 1 for variable age.

class:

Person

DEF

var:

age

level: 1 celebrate(Person&)

USE celebrate(Person&)

childBirthday()

Higher order tables provide an essential means for the

completeness of the representation of the deﬁnition-

use graph since they enable the evaluation of method

interactions at both the inter-method and inter-class

level (Harrold and Rothermel, 1994).

3 SOURCE CODE MODEL

The set of deﬁnitions and uses reported in a Def/Use

table is given by the union of methods performing

a direct or indirect access on the member variable

under observation. Direct accesses are given by ex-

plicit references to the attribute in inﬁx, preﬁx, postﬁx

and assignment expressions contained in the method

body. An indirect access happens when the examined

method invokes another method by passing the vari-

able under test as one of its parameter and/or when

TEST COVERAGE ANALYSIS FOR OBJECT ORIENTED PROGRAMS - Structural Testing through Aspect Oriented

Instrumentation

the current method changes the state of the attribute

by invoking a method on it (i.e. the variable is of an

abstract data type).

In order to identify each expression contained in

a method deﬁnition and addressing the variable the

table refers to, we require an analyzable abstraction

of the program under test. This model is provided by

the Abstract Syntax Tree (AST) (Kuhn and Thomann,

2006). Code parsing is performed by exloring the

nodes of the AST of each method, according to the

following rules: let x be the table attribute.

1. Every assignment, preﬁx or postﬁx expression,

that contains x, is examined as a node in the

method AST to detect a possible direct def or use

on x.

2. Every method invocation node of the AST is vis-

ited to detect a possible indirect def or use on x.

3. If a use and a def for that method have already

been registered, the analysis for that method stops.

While the retrieving of direct accesses is a relatively

simple task to accomplish, the activity of identifying

indirect accesses strongly depends on the semantic of

the adopted programming language. The only general

rule that can be derived consists in the migration of

the scope of analysis from the calling method to the

called one.

As an example of indirect attribute access, we will

refer to class

Parent

. Method

childBirthday()

invokes

isAdult()

on the attribute

child

. This

method has no side effects for the invoking object so

only a use is registered for

childBirthday()

. More-

over,

childBirthday()

passes a reference to

child

as a parameter to

Parent::celebrate(Person&

. The status of

is changed through the invocation

p.birthday()

, consequently,

childBirthday()

is considered to perform a deﬁnition on

child

. The

resulting Def/Use table for

child

is presented in Ta-

ble 3.

Table 3: Def/Use table for attribute child.

class:

Parent

DEF

var:

child

level: 0 childBirthday()

USE childBirthday()

The state of an object is a predicate on the values of its

member variables.

4 COVERAGE ANALYSIS

4.1 Logging Aspect

Aspect Oriented Programming (AOP) was used to in-

strument the code of the program under test and to

produce a log ﬁle containing the trace of tested be-

haviors.

An AOP language is a language containing ex-

pressions for the encapsulation of crosscutting con-

cerns into single units called aspects. An aspect is a

modular unit of crosscutting implementation that can

alter the behavior of multiple classes belonging to the

non-aspect part of the program.

Logging is a type of crosscutting concern that

AOP languages are able to address; several works

(Chen et al., 2004), (Rajan and Sullivan, 2005), have

employed this technique for structural and functional

analysis of object oriented programs.

Our AOP model is created according to the pro-

gram structure and to the scope of analysis deter-

mined by the tester. An aspect module is the result of

an aspect generator that, on the basis of the Def/Use

tables, automatically states which method calls must

be instrumented. The resulting aspect is formed by a

pointcut whose joinpoints are the elements of the ta-

bles. Two different advices are deﬁned on the pointcut

to detect when the ﬂow of execution enters the body

of a method and when the execution leaves it. The log

ﬁle records these advices in XML format indicating,

for each entry, the ID

of the class instance the logged

method refers to, the identity of the process that gen-

erated the method execution and a message ﬁeld used

by the program to trace the execution sequence.

4.2 Coverage Criteria

Def/Use tables serve as a tracking utility to record

couples of methods sequentially executed. Every

cell of a table corresponds to a def-use pair between

methods and functions of the same level, and can be

marked with the deﬁnition clear path effectively ex-

ercised by test cases. To retrieve the paths covered

during test execution, three rules have been deﬁned to

individually evaluate each method of the logged se-

quence:

• Def method: the method is labeled as the last one

that performed an assignment to the variable.

• Use method: if there is a method labeled as last

def then a deﬁnition clear path has been covered;

In Java, the value of the ID ﬁeld is given by an hashcode

representation of the object. In C

, the ID is given by the

object’s memory location.

ICSOFT 2007 - International Conference on Software and Data Technologies

the information is registered in the Def/Use table

and the last def label is removed.

• Def-use method: the method performs both a

reading and a writing on the variable. Conven-

tionally, the use access is notiﬁed before the def

access. Before reassigning the last def label, a

check is performed to detect a possible def-use

chain.

Classical data ﬂow metrics have been adapted to the

object oriented context, deriving three different cov-

erage criteria.

• All nodes: this criterion represents the weakest

of the three. Full coverage for this criterion is

reached when test execution exercises every ele-

ment contained in the Def/Use table.

• All defs: full coverage for this criterion requires

the test set to exercise at least one use element for

every def element contained in the table.

• All uses: full coverage for this criterion requires

the test set to exercise every use element for every

def element contained in the table. This criterion

implies that every ordered couple of methods, be-

longing to the cartesian product between the rows

and the column of the Def/Use table, is executed

during the testing phase.

In our approach, if coverage analysis is performed on

a set of member variables, the total coverage mea-

sure is derived from the partial measures, individually

evaluated on each Def/Use table.

Instance control is a required means to guaran-

tee that each def-use pair, reported in a table, is ac-

tually related to the same variable. Every time a nom-

inal deﬁnition clear path is encountered, a check is

performed to verify the correspondence between the

identities of the object that invoked the last deﬁning

method and the object invoking the use method.

5 TOOL SUPPORT

To support the proposed technique we implemented

two testing tools named CppTest and JavaTest. Both

programs have been developed as plug-ins for the

Eclipse platform, and use the CDT and JDT tools

for structural analysis of source code. AspectC

and

AspectJ were also used to perform code instrumen-

tation for the purposes of test logging. CppTest and

JavaTest perform structural analysis of source code,

create Def/Use tables for the user-deﬁned variables,

instrument the code and evaluate the coverage results

of a test set execution.

To validate both the technique and the tools we

performed experiments on a workbench comprised of

a set of design patterns (Gamma et al., 1995) exhibit-

ing a variety of interactions and structural dependen-

cies which are common in the good practice of OO

programming.

As an example, Table 4 represents the Def/Use ta-

ble extracted from the implementation of an Observer

pattern (Gamma et al., 1995). In the pattern, the at-

tribute

observers

, represents the list of references to

the observers previously attached to the subject. The

table indicates which are the possible def/use depen-

dencies among methods, and it marks with a token

which of them have been actually exercised in a test-

ing suite including the following testing sequence:

1 7021720 - Subject::Subject()

2 7019640 - Subject::Subject()

3 7019640 - void Subject::attach(Observer*)

4 7021720 - void Subject::attach(Observer*)

5 7021720 - void Subject::detach(Observer*)

6 7021720 - Subject::˜Subject()

7 7021720 - void Subject::detach(Observer*)

8 7019640 - void Subject::notify()

The path

attach()-detach()

, i.e. the registra-

tion and removal of one observer, is provided by lines

4 and 5. The destruction of one Subject instance is

given by lines 6 and 7 which cover the def-use pair

detach()-

∼

Subject()

. Lines 3 and 8 cover the

attach()-notify()

path by updating the status of

a registered observer.

6 CONCLUSIONS

We adapted signiﬁcant concepts of data ﬂow theory to

the context of OO programming, and we proposed a

technique of coverage analysis supported by tools for

and Java programs.

Def/Use relations appear to catch semantics

relevant for class interaction, thus establishing a

correspondence between the completeness of a

requirement-based test case selection activity and the

measure of structural data-ﬂow coverage achieved by

those tests. Besides, the adoption of Def/Use tables

in place of a labeled graph provides a compact rep-

resentation of method interactions focused on critical

attributes that capture the intent of the composition of

classes. This enables abstraction which is essential to

scale up the scope of analysis in the integration test-

ing.

The proposed technique and tools can be effec-

tively cast into a methodology that spans over devel-

opment and veriﬁcation activities of an UP-like soft-

ware lifecycle. In the development process, designers

TEST COVERAGE ANALYSIS FOR OBJECT ORIENTED PROGRAMS - Structural Testing through Aspect Oriented

Instrumentation

Table 4: Def/Use table for the Observer pattern. Bullet items indicate test covered def-use pairs.

class:

Subject

DEF

var:

observers

level: 0 attach(Observer*) detach(Observer*) Subject()

∼Subject() •

USE attach(Observer*) •

detach(Observer*) •

notify() •

are supposed to document the relevant attributes of

salient classes which are most critical for inter-class

interaction (Cockburn, 1996). This can be done as

an annotation of UML class diagrams comprising the

speciﬁcation or the implementation model (Fowler,

2003). In the testing stage, Def/Use tables are au-

tomatically derived through source code analysis, and

code is automatically instrumented using Aspect Ori-

ented Programming. The application is then tested

on a suite of cases selected according to any speciﬁc

approach (e.g. derived from use cases (Heumann,

2001)), and their execution is logged to a ﬁle con-

taining the trace of the methods effectively exercised.

Coverage analysis is ﬁnally performed through ofﬂine

check of the def-use paths reported in the log ﬁle and

contained in the tables.

REFERENCES

Baudry, B. and Traon, Y. L. (2005). Measuring design testa-

bility of a uml class diagram. Information and Soft-

ware Technology, 1(47).

Beizer, B. (1990). Software testing techniques (2nd ed.).

Van Nostrand Reinhold Co., New York, NY, USA.

Binder, R. V. (1994). Design for testability in object-

oriented systems. Commun. ACM, 37(9):87–101.

Chen, Y., Qiu, W., Zhou, B., and Peng, C. (2004). An

automatic test coverage analysis for systemc descrip-

tion using aspect-oriented programming. In Computer

Supported Cooperative Work in Design. Proceedings.

The 8th International Conference on, Vol. 2, pages 632

– 636.

Cockburn, A. (1996). The interaction of social issues and

software architecture. Commun. ACM, 39(10):40–46.

Fowler, M. (2003). UML Distilled: A Brief Guide to

the Standard Object Modeling Language. Addison-

Wesley Longman Publishing Co., Inc., Boston, MA,

USA.

Fujiwara, S., von Bochmann, G., Khendek, F., Amalou, M.,

and Ghedamsi, A. (1991). Test selection based on ﬁ-

nite state models. IEEE Trans. Softw. Eng., 17(6):591–

603.

Gallagher, L., Offutt, J., and Cincotta, A. (2006). Integra-

tion testing of object-oriented components using ﬁnite

state machines: Research articles. Softw. Test. Verif.

Reliab., 16(4):215–266.

Gamma, E., Helm, R., Johnson, R., and Vlissides, J. (1995).

Design patterns: elements of reusable object-oriented

software. Addison-Wesley Longman Publishing Co.,

Inc., Boston, MA, USA.

Harrold, M. J. and Rothermel, G. (1994). Performing data

ﬂow testing on classes. In SIGSOFT ’94: Proceedings

of the 2nd ACM SIGSOFT symposium on Foundations

of software engineering, pages 154–163. ACM Press.

Heumann, J. (2001). Generating test cases from use cases.

The Rational Edge. Retrieved January 20, 2007, from

www.therationaledge.com.

Holley, L. H. and Rosen, B. K. (1981). Qualiﬁed data ﬂow

problems. IEEE Trans. Softw. Eng., 7(1):60–78.

Hong, H. S., Kwon, Y. R., and Cha, S. D. (1995). Test-

ing of object-oriented programs based on ﬁnite state

machines. In APSEC ’95: Proceedings of the Second

Asia Paciﬁc Software Engineering Conference, page

234. IEEE Computer Society.

Kiczales, G., Lamping, J., Mendhekar, A., Maeda, C.,

Lopes, C. V., Loingtier, J.-M., and Irwin, J. (1997).

Aspect-oriented programming. In Proceedings of the

11th European Conference on Object-Oriented Pro-

gramming, pages 220–242.

Kuhn, T. and Thomann, O. (2006). Abstract syntax tree.

Eclipse Corner Articles. Retrieved October 23, 2006,

from http://www.eclipse.org/articles/index.php.

Ntafos, S. C. (1988). A comparison of some structural test-

ing strategies. IEEE Trans. Softw. Eng., 14(6):868–

874.

Pande, H. D. and Landi, W. (1991). Interprocedural def-use

associations in c programs. In TAV4: Proceedings of

the symposium on Testing, analysis, and veriﬁcation,

pages 139–153, New York, NY, USA. ACM Press.

Rajan, H. and Sullivan, K. (2005). Aspect language fea-

tures for concern coverage proﬁling. In AOSD ’05:

Proceedings of the 4th international conference on

Aspect-oriented software development, pages 181–

191. ACM Press.

Rapps, S. and Weyuker, E. J. (1985). Selecting software test

data using data ﬂow information. IEEE Trans. Softw.

Eng., 11(4):367–375.

Yannakakis, M. and Lee, D. (1995). Testing ﬁnite state

machines: fault detection. In Selected papers of the

23rd annual ACM symposium on Theory of comput-

ing, pages 209–227. Academic Press, Inc.

ICSOFT 2007 - International Conference on Software and Data Technologies
