TOWARDS A GENERAL ONTOLOGYOF COMPUTER

PROGRAMS

Pascal Lando, Anne Lapujade, Gilles Kassel and Frédéric Fürst

LaRIA, Jules Verne University of Picardy, 33 rue Saint Leu, F-80039 Amiens, France

Keywords: Knowledge engineering, ontological engineering, foundational ontologies, core ontologies, program

ontologies.

Abstract: Over the past decade, ontology research has inves

tigated the field of computer programs. This work has

aimed at defining conceptual descriptions of the programs so as to master their design and use.

Unfortunately, these efforts have only been partially successful. In this paper, we present the basis of a Core

Ontology of Programs and Software (COPS) which integrates the field’s main concepts. But, above all, we

emphasize the method used to build the ontology. In fact, COPS specializes not only the DOLCE

foundational ontology (“Descriptive Ontology for Linguistic and Cognitive Engineering”, Masolo et al.,

2003) but also core ontologies of domains (e.g. artefacts, documents) situated on a higher abstraction level.

This approach enables us to take into account the “dual nature” of computer programs, which can be

considered as both syntactic entities (well-formed expressions in a programming language) and artefacts

whose function is to enable computers to process information.

1 INTRODUCTION

Over the last ten years or so, the field of computing

programs has witnessed an increasing number of

ontological investigations in several disciplines with

different targets: in the philosophy of computer

science, the goal is to attain better knowledge of the

nature (Eden & Turner, 2006) and semantics of

computer programs (Turner & Eden, in press); in

software engineering, formal descriptions aim at

facilitating program maintenance (Welty, 1995,

Oberle et al., 2006). Such descriptions can also be

used to orchestrate and automate the discovery of

web services (Roman et al., 2005).

The work presented here is in line with these efforts.

It aim

s, in a first step, at building a general or “core”

ontology (Gangemi & Borgo, 2004) of the domain

of programs and software, encompassing main

concepts and relations for this domain. This core

ontology, named COPS (for: Core Ontology of

Programs and Software), will be used in a second

step to conceptualize a sub-domain of computer

programs, namely that of image processing tools.

This step takes place within the project NeuroLOG

(

http://neurolog.polytech.unice.fr

) which aims at

developing a distributed software platform to help

members of the neuroimaging community to share

images and image processing programs. This

platform relies on an ontology integrating COPS as a

component (Temal et al., 2006). In this paper, we

present on the current content of COPS in particular

but our overall focus is on the methodological

process that we used to build the ontology and the

resulting structural features. The COPS ontology

indeed specializes more abstract modules which

highly determine its structure, including the DOLCE

foundational ontology (“Descriptive Ontology for

Linguistic and Cognitive Engineering”, Masolo et

al., 2003) and the I&DA core ontology

(“Information and Discourse Acts”, Fortier &

Kassel, 2004). This type of design process is aimed

at mastering two sorts of complexity: i) conceptual

complexity, providing the ability to model complex

objects (such as programs) at different abstraction

levels and ii) modeling complexity, providing the re-

use of previously used and approved modules and,

equally, the ability to design new modules by

working in a distributed manner.

COPS has two syntactic expressions, corresponding

the specifications of the ontology using the semi-

formal language from the OntoSpec method (Kassel,

2005) and using the RDF Schema language. Within

the NeuroLOG project, this latter expression is

implemented into software under development that

includes a semantic research tool called CORESE

(designed as part of the ACACIA project at the

163

Lando P., Lapujade A., Kassel G. and Fürst F. (2007).

TOWARDS A GENERAL ONTOLOGYOF COMPUTER PROGRAMS.

In Proceedings of the Second International Conference on Software and Data Technologies - PL/DPS/KE/WsMUSE, pages 163-170

DOI: 10.5220/0001340901630170

 SciTePress

INRIA institute, http://www.inria.fr/acacia/corese).

However, due to space restrictions, we shall

disregard these syntactic aspects in this paper and

focus on the ontology’s content.

The remainder of this article is structured in the

following way. In section 2, we present the overall

ontological framework of reference used (and the

DOLCE and I&DA ontologies in particular). Section

3 details the COPS ontology’s content and our

design choices. In section 4, our work is compared

with other efforts to design ontologies in the domain

of computer programs.

2 OUR ONTOLOGICAL

FRAMEWORK

As shown in Figure 1, the COPS ontology is

integrated into a larger ontology composed of sub-

ontologies which are situated at different levels of

abstraction: a descending link between two sub-

ontologies O

and O

means that the conceptual

entities (concepts and relations) of O

are defined by

specialization of the conceptual entities of O

. The

DOLCE foundational ontology and the different

core ontologies make up the resource used by the

OntoSpec methodology (http://www.laria.u-

picardie.fr/IC/site/) for helping to structure

application ontologies (which include all the

concepts necessary for a particular application), such

as that developed within the NeuroLOG project.

As a consequence of this overall structure, COPS’s

conceptualization depends on modeling choices

made upstream, i.e. in components situated at a

higher level of abstraction. In this section, we

present these key modeling choices by successively

introducing the DOLCE ontology (2.1), the

modeling of (participant) roles & artefacts (2.2) and

the I&DA ontology (2.3).

Foundational

ontology

Core

ontologies

Domain

ontologies

DOLCE

I&DA

OntoKADS

COPS

Particular

Documents

Artefacts

Participant roles

Reasonin

Programs &

Software

Medical ima

es Images processing tools

Figure 1: Structure of the application ontology in the

NeuroLOG project.

2.1 DOLCE (Particulars)

DOLCE is a “foundational” ontology, which means

that it comprises abstract concepts aimed at

generalizing the set of concepts that we may

encounter in the different domains of knowledge. In

accordance with philosophically-grounded

principles, DOLCE’s domain – that of Particulars –

is partitioned into four sub domains (cf. Fig. 2):

– Endurants are entities “enduring in time” (e.g.

the present article). Within Endurants, Physical

Objects are distinguished from Non-Physical

Objects, since only the former possess direct

spatial Qualities. The domain of Non-Physical

Objects covers social entities (e.g. the French

community of researchers in knowledge

engineering) and cognitive entities (e.g. your

notion of knowledge engineering). To take plural

entities into account (a community of persons or

the proceedings of a conference), the notion of

Collection was recently introduced under Non-

Physical Objects (Bottazzi et al., 2006).

– Perdurants are entities which “happen in time”

(e.g. your reading of this article) and in which

Endurants participate. Among Perdurants, one

defines Actions that are intentionally

accomplished (Accomplishments), i.e. controlled

by an Agent (further defined in 2.2).

– Endurants and Perdurants have inherent

properties (Qualities) that we perceive and/or

measure (e.g. the weight of the paper copy of the

article you may be holding or how long it takes

you to read this paper).

– These Qualities take a value (Quale) within

regions of values which are Abstracts (e.g. 20

grams, 15 minutes).

These concepts are defined in DOLCE by means of

rich axiomatization, which space restrictions prevent

us from presenting. In particular, Endurants and

Perdurants can be differentiated in terms of the

dissimilar temporal behaviors of their parts. The

interested reader is invited to refer to (Masolo et al.,

2003).

Particular

Endurant

Perdurant Quality Abstract

Physical

Object

Non-physical

Object

Mental

Object

Agentive

Social

Object

Event

Stative

Achievement

Accomplishment

State Process

Collection

Action

Figure 2: An excerpt from DOLCE’s hierarchy of

concepts.

Comment: in the following sections, names of

conceptual entities will be noted in italics, with first

Capital Letters for concepts and in a

javaLikeNotation for relations.

ICSOFT 2007 - International Conference on Software and Data Technologies

164

Endurant

Person Determinant Patient

Agent Substrate

Autho

#PascalLando

Endurant

Non-Physical

Object

Artefact

Cognitive Artefact

Tool

Artefact of

Communication

Artefact of

Computation

Scientific Publication

(

Lando et al., 2007

)

isa

2.2 Roles and Functions

In this section, we introduce two important notions

linking Endurants to Perdurants (namely roles and

functions) and we provide a brief reminder of the

underlying modeling choices (Bruaux et al., 2005).

A role (or more exactly a “participant role” or

“thematic role”) accounts for the way an Endurant

participates (as meant by DOLCE) in a Perdurant.

By way of an example, during the writing of an

article, several entities participate in this Action: a

person as an Agent, a pencil or a pen as an

Instrument and the article itself as a Result. The term

“role” designates here a category of concepts (e.g.

Agent, Instrument, Result) which constitute a sub-

ontology of Endurants, as the signature of the

participation relation constraints participants to be

Endurants (cf. Fig. 3a).

Figure 3: Modeling of roles (a) and functions-artefacts (b).

2.3 I&DA (Documents)

I&DA is a core ontology in the domain of semiotics,

and was initially built to classify documents by their

contents. As shown in Figure 4, I&DA extends

DOLCE by introducing three main concepts:

– Inscriptions are knowledge forms materialized

by a substance and inscribed on a physical

medium (e.g. a written text materialized by some

ink on a sheet of paper). Furthermore, these

forms are intentional objects, holding for other

entities: Inscriptions realize Expressions.

A function can be defined as the ability – assigned

by agents to Endurants – to facilitate the

performance of an Action, i.e. the ability of playing

the role of Instrument in a Perdurant; in turn, this

notion enables definition of the concept of an

Artefact - an Endurant to which a function is

assigned. According to the type of Action (the sub-

ontology of Actions on which COPS relies is

discussed in 3.2), different types of Artefacts can be

distinguished (cf. Fig. 3b): Tools are distinguished

from Cognitive Artefacts according to whether the

Action they can perform corresponds to modification

of the physical world or the non-physical world. Of

the latter, Artefacts of Communication enable

communication of information to agents, whereas

Artefacts of Computation allow computers to

perform Actions as Agents.

– Expressions are non-physical knowledge forms

orderedBy a Language. In their turn,

Expressions hold for other entities, namely

contents that agents attribute to them:

Expressions express Conceptualizations.

– Lastly, Conceptualizations are means by which

agents can reason about a world. Within

Conceptualizations, a functional distinction is

made between Propositions (which are

descriptions of situations) and Concepts (which

serve to classify entities in a world).

The reader will note that, in order to account for

documents, I&DA chooses to consider three distinct

entities rather than three different views of the same

entity. We shall see in the next section that this

modeling choice has important repercussions on the

structure of COPS.

In Figure 3, one can note that the concepts of Author

and Scientific Publication encapsulate the type of

entity and, respectively, the role and function

assigned to the entity. This modeling choice, which

is consistent with the most common paradigm for

role modeling (Steimann, 2000), leads to a tangled

taxonomy.

sical

ndurant

Support

Physical Object

Non

sical Ob

ect

Cognitive Artefact

Artefact of

Comm

nicat

Inscription Ex

ression Conce

tualization

Collect

Language

Linguistic

ressio

Formal

ression

Conce

Pro

osition

Figure 4: The top level of I&DA’s hierarchy of concepts.

TOWARDS A GENERAL ONTOLOGY OF COMPUTER PROGRAMS

165

3 COPS: A CORE ONTOLOGY OF

PROGRAMS AND SOFTWARE

The COPS ontology indeed classifies a program as a

document whose main characteristic is to allow a

computer to perform information processing. In

section 3.1, we first show how the ontological

framework presented so far contributes to the

definition of these particular documents. In sections

3.2 to 3.5, we then present several sub-ontologies

dedicated to the different aspects of the notion of

“program”.

3.1 The Dual Nature of Programs

Firstly, the distinction made in DOLCE between

Endurants and Perdurants allows us to distinguish

between the program as an Endurant and its

executions, which are Perdurants. Secondly, when

focusing on the program as an Endurant, the

distinctions in I&DA between Inscriptions,

Expressions and Conceptualizations prompt us to

consider three categories of entities commonly

referred to as “programs” (cf. Fig. 5):

– Files, which are Inscriptions written on an

electronic support (e.g. CDs, computer memory,

magnetic tape, etc.). Furthermore, these files

constitute only one type of program Inscription;

a paper listing or an on-screen display of a

program are also program Inscriptions.

– Computer Language Expressions, which are

well-formed formulas (isAWellFormedFormula

Of is a sub-relation of isOrderedBy) in a

Computer Language. These expressions include

Programs.

– DataTypes and Algorithms, which are

Conceptualizations that represent the semantics

of Programs. DataTypes are Concepts on which

rely programming languages (e.g. variable, class,

structure) and which are reflect to diversity of

programming languages (Turner & Eden, in

press). Algorithms describe calculus steps in

terms of these DataTypes (e.g. affecting a

constant to the value of a variable, then adding

another value, etc.).

This approach boils down to considering programs

as Expressions, which is a consensual point of view

in both computer science and philosophy. However,

we consider that this purely syntactical description

of a program is not enough to fully capture the

nature of programs.

Indeed, programs have also a functional dimension,

in that they allow computers to perform Actions

(Computations). This functional dimension is

present in expressions such as “sort program”,

“program for calculating the greatest common

divisor of two numbers” or “image processing

program”. Programs are therefore also Artefacts of

Computation (cf. Fig. 5). As commonly proposed in

philosophy for the characterization of artefacts

(Kroes & Meijers, 2002), we therefore end at a dual

characterization of programs, considered to be both

Computer Language Expressions and Artefacts of

Computation.

In order to account for these dimensions of programs

(and refine them), COPS proposes a sub-ontology of

Actions (cf. 3.2) and a sub-ontology of Languages

(cf. 3.3). We shall see in 3.4 that COPS’s concept of

Program integrates complementary constraints with

regard to this first characterization.

Inscription

File

Directory

Formal Expression

Computer Language

Expression

Artefact of Computation

Program

Concept

Data Type

Proposition

Action model

Algorithm

Conceptualization

Figure 5: The general structure of COPS.

3.2 A Sub-ontology of Actions

In order to refine the functional dimension of

Programs (and Computer Language Expressions in

general) and specify what these latter allow a person

or a computer to perform, COPS is endowed with an

ontology of Actions (cf. Fig. 6).

On one level, Actions are distinguished according to

(i) the world in which the transformation-Action

occurs (physical (Doing) or non-physical (Non-

physical Action)) and (ii) the Agent performing the

Action (a human (Human Action) or a computer

(Computational Action)).

The first semantic axis relies on a strong hypothesis

dealing with the identity criteria of Actions, namely

that Actions performed in separate worlds of entities

are themselves distinct Actions. The worlds of

entities considered in COPS converge with the

common hierarchy of computer description levels, to

which we add the “knowledge level” postulated by

Newell (1982). This hypothesis prompts

specialization of Non-physical Actions into Symbolic

Actions (which, at the symbolic level, consist in

transforming Expressions - e.g. Executing a

Program, Compiling a Program) and Conceptual

Actions (which, at the knowledge level, consist in

transforming Conceptualizations). Of the latter,

Actions involving knowledge models and which are

taken into account by the CommonKADS

methodology (Bruaux et al., 2005) (e.g. Diagnosing

a car’s failure, Monitoring a patient) are

distinguished from Actions performed on Data and

ICSOFT 2007 - International Conference on Software and Data Technologies

166

Data Types constituting the paradigms generated by

the different programming languages (e.g.

Incrementing a Variable, Creating an Object). The

reader should note (cf. Fig. 6) that Discourse Acts

are Non-physical Actions. The latter (considered as

Actions which lead to a change in the state of

knowledge of the addressee of the discourse) are

used in COPS to account for Actions such as

Requests (e.g. querying databases) or Orders for

executing Programs.

Action

Doing

Non-physical

action

Human

action

Computational

action

Discourse act

Symbolic

action

Symbolic

computation

Executing

a program

Compiling

a program

Computation

Conceptual

action

Creating

an object

Incrementing

a variable

Monitoring

a patient

Diagnosing a

car's failure

Figure 6: The sub-ontology of Actions in COPS

3.3 A Sub-ontology of Computer

Languages

In order to refine the syntactical dimension of

Expressions, COPS includes an ontology of

languages. Classically, one distinguishes between

natural languages and formal languages. The formal

languages of interest here are Computer Languages,

i.e. those designed for interpretation by a computer

(microprocessor) or a program. Our

conceptualization of Computer Languages (cf. Fig.

7) is based on the functions (the artefactual

dimension) of the Expressions that they can order.

The first category of computer languages is that of

General Purpose Computer Languages (GPCLs),

i.e. Turing-complete languages dedicated to the

writing of all kinds of programs. The second

category is that of Domain-Specific Computer

Languages (DSCLs), i.e. non-Turing-complete

languages limited to the writing of particular types

of expressions (database queries, operating system

commands, etc.). Programming languages are all

GPCLs that are understandable by humans. GPCLs

that are only understandable by computers or

programs are Low-level Computer Languages (or

low-level programming languages): Machine

Languages (understandable by a processor) and

Byte-code Languages (understandable by a virtual

machine).

Language

Natural language

Formal language

Computer lan

Logical language

General purpose

computer language

Domain specific

computer lan

Query

language

Command

language

Low-level computer

language

Programming

language

Bytecode

language

Machine

language

Figure 7: The sub-ontology of computer languages in

COPS.

3.4 A Sub-ontology of Computer

Language Expressions and

Programs

The sub-ontology of Expressions (all of which are

considered here to be well-formed Expressions)

mirrors the sub-ontology of Languages that order

these Expressions. The structure of these two

taxonomies is similar (cf. Fig. 8) and is based on the

functional dimension. An Expression in a GPCL

(General Purpose Computer Language Expression)

allows a computer to perform an arbitrary

Computation (e.g. declaring a variable, calculating

the greatest common divisor of two numbers). By

contrast, an Expression in a Query Language (Query

Expression) or an Expression in a Command

Language (Command Expression) are functionally

different: they do not allow computers to performing

a Computation but allow (human) users to Ordering

(which is a kind of Discourse Act) the performance

of particular Computations, such as, for example,

querying or modifying a set of data. These

Expressions are therefore Artefacts of

Communication and this functional distinction has

repercussions for the definition of COPS’s concept

of Program.

On one side, we consider that a Program

syntactically corresponds only to a particular type of

Expressions orderedBy a Programming Language.

Indeed, the peculiarity of Expressions qualified as

Programs is that they can be either directly executed

by a computer (after a compilation) or taken in

charge by an interpreter. As an example, a program

in the language C is composed of one or more

functions, one of these functions being necessarily

called “main”. By contrast, Expressions such as a

TOWARDS A GENERAL ONTOLOGY OF COMPUTER PROGRAMS

167

function or an instruction do not possess this entry

point rendering the Expression executable or

interpretable.

On another side, we consider that there exist

executable or interpretable Expressions which are

not Programs. Indeed, in the same lines as Eden and

Turner (Eden & Turner, 2006), we only speak of

Programs in case of Expressions being ordered by

Turing-complete languages (or General Purpose

Programming Languages). Therefore, a SQL query

or a shell command, which are yet interpretable or

executable, are not considered in COPS to be

Programs. To sum up, we define a Program as an

Expression in a Turing-complete language which

can be interpreted or compiled and executed by an

Operating System (Executable Program) or a Virtual

Machine (Byte-code Program).

In addition, crosscutting relations link the different

types of Programs: a Source Code

hasForExecutable (or “can be compiled into

several”) Executable programs, and conversely an

Executable Program or a Byte-code Program

hasForSourceCode a Source Code.

Formal Expression

Artefact of

Computation

Computer Language Expression

Program

Domain Specific Computer

Language Expression

Query

Expression

Command

Expression

General Purpose Computer

Language Expression

Loop

Fonction

Source Code

Programming

Language Expression

Low-level Computer

Language Expression

Executable

Program

Byte-code

Program

Figure 8: A sub-ontology of Programs in COPS.

Note that Operating Systems or Virtual Machines do

not appear in COPS’s sub-ontology of Programs.

The reason is that they are not Programs, but they

are rather made up of a set of Programs. They are

therefore related to software, which are defined in

COPS as collections of Programs, as presented in

the next section.

3.5 A Sub-ontology of Software and

Platforms

This sub-ontology of COPS models entities that are

collections of Programs rather than single

Programs. The concept Library of Programs (cf.

Fig. 9) designates a Collection of Programs and,

potentially, other documents (such as manuals).

By analogy with Program, Software is defined as

both a Library of Programs and an Artefact of

Computation. Since it must be executable, Software

includes at least one Executable (or Interpretable)

Program. Software includes Compilers (whose

function is to allow a computer to translate a Source

Code into an Executable program), Interpreters

(whose function is to allow a computer to execute a

Source Code) and Operating Systems (whose

function is to allow a computer to execute

Executable Programs). This function defines

another class of Artefacts - the Platforms.

A Platform can be a purely material entity

(Hardware Platform) or an entity that is partially

made up of Software (Software Platform). Software

Platforms include Operating Systems and Computers

on which Operating Systems run.

Crosscutting relations link Programs and particular

types of Software: a Source Code isCompilableBy

particular Compilers and/or isInterpretableBy

particular Interpreters; an Executable Program

runsOn a particular Operating System; a Byte-code

Program runsOn a particular Virtual Machine.

Collection

Artefact of

Computation

Technical

Artefact

Physical

Object

Library of Programs

Software

Operating

System

Platform

Software

Platform

Hardware

Platfo

Computer Cluster

Computer Running

Under an OS

Compiler

Interpreter

Virtual

Machine

Figure 9: The sub-ontology of Software and Platforms in

COPS.

4 DISCUSSION

In this section, we compare COPS with other

attempts to elaborate ontologies of programs.

In the philosophy of computer science, Eden &

Turner (2006) recently began creating an ontology

of programs in order to answer questions like: how

can we display differences between hardware and

software entities, and how can we distinguish a

program from a program specification? Even though

the ontological tools used in the present work are

different from Eden & Turner's, it is interesting to

compare the respective conceptualizations. For

example, Eden & Turner (2006) define a program as

a “well-formed expression in a Turing-complete

programming language” - emphasizing the

syntactical dimension of programs but setting aside

their functional dimension (which exists in the

ICSOFT 2007 - International Conference on Software and Data Technologies

168

COPS concept of Program). The fact that these two

notions differ suggests that it would be useful to

extend the COPS core ontology to other concepts.

The “web services” community has generated a

variety of initiatives – METEOR-S, OWL-S,

WSMO (Roman et al., 2005) – which seek to

formally describe the discovery, evocation and

orchestration (at different levels of automation) of

such services. These efforts are currently far

removed from COPS’ aims because (i) the work

emphasizes the operational nature of the descriptions

and (ii) these descriptions concerning the function

(the Action in COPS) realized by the service (e.g.

booking a travel ticket) are situated on a meta level,

which allows defining the prerequisites for operation

of the service (e.g. information about the travel has

to be given) and the effects resulting from its

execution (e.g. the ticket price is debited from a

bank account). Within the framework of the

NeuroLOG project, the functionalities targeted in

terms of the evocation and orchestration of software

tools are similar, which is why we plan to extend

COPS to consider this level of description.

In the software engineering domain, Welty (2005)

has suggested developing Comprehensive Software

Information Systems (for software maintenance) by

using an ontology which enables a detailed,

conceptual description of software. This ontology

could be considered as an extension of the COPS

Expression sub-ontology, as it enables description at

the code level and consideration of all the syntactical

constructions available in programming languages.

On the other hand, it supposes (strangely) that the

entities playing data and result roles are real world

entities (e.g. persons) and not conceptualizations

modeling the real world. In COPS, we chose to

follow (Turner & Eden’s, in press) idea whereby

program semantics are based on data and data types

which model real world entities - for example (in the

object paradigm), an instance which models an

individual person or a class which models a set of

persons.

Other work in the software engineering domain

(Oberle et al., 2005) has led to publication of CSO

(the Core Software Ontology) in order to better

develop, administer and maintain complex software

systems. The ontology-building approach is similar

to ours, with re-use of the DOLCE high level

ontology and core ontologies such as DnS

(“Descriptions & Situations”, Gangemi & Mika,

2003). COPS and CSO also share some modeling

choices, such as the distinction between three

entities (called Inscriptions, Expressions and

Conceptualizations in COPS). However, we can

note some different modeling choices. For example,

in CSO (and assuming that every program can be a

data item for another program), the Data concept

subsumes the Software concept. In contrast, COPS

assimilates the Data concept to a participant role (cf.

2.2) which can be played by arbitrary entities -

Programs, for example. In fact, whereas CSO

considers only one type of Action (namely

“computational activities” whose participants are

necessarily Inscriptions (in the sense of COPS)

inscribed on some sort of hardware), COPS

distinguishes several categories of Actions according

to the nature of the participant entities (cf. 3.2).

COPS’ richer framework allows it to define a

Program Compilation as an Action in which at least

two Programs participate. Lastly, we can note that

the functional dimension of programs is absent in

CSO.

Those comparisons show that some core ontology

proposals for the software domain do exist but that

the various efforts are not yet coordinated and that

the existing ontologies display some important

differences in terms of both range and structure.

5 CONCLUSION

In this paper, we have presented the foundations of a

core ontology of programs and software (COPS)

derived by specializing the DOLCE foundational

ontology and whose goal is to help structure more

specific programming domains. In this connection,

the next application of COPS within the NeuroLOG

project, to help conceptualizing the domain of image

processing tools, will provide an opportunity for

evaluating the modeling choices made for the

building of the ontology.

COPS’ current conceptualization reveals a domain

populated by entities having various nature. Indeed,

there are temporal entities (program executions),

physical entities (program inscriptions), plural

entities (program collections), functional entities

(program execution platforms) and, lastly, dual-

nature (syntactic and functional) entities - the

programs themselves. COPS’ model-building

feedback confirms the fact that ontological resource

re-use (enabling modeling choices at several

abstraction levels) is necessary for controlling the

complexity of such domains.

In its current version, COPS only covers a part of

this domain. Work in process is extending the

ontology in several directions. A first goal is to

extend the programs semantics: links with

processing (functions) only give an account of the

“what”, so it lacks the “how” - requiring us to take

into account algorithms and data types which have

only been positioned (cf. Fig. 5) and not precisely

analyzed. A second goal is to enlarge COPS to

program specifications: we plan to re-use the

TOWARDS A GENERAL ONTOLOGY OF COMPUTER PROGRAMS

169

“problem resolution model” notion in OntoKADS

(Bruaux et al., 2005) to extend COPS to the more

general class of action models performed by

computers using programs.

ACKNOWLEDGEMENTS

This work was partially financed by the NeuroLOG

project (ANR-06-TLOG-024) under the French

National Research Agency’s Software Technologies

program (http://neurolog.polytech.unice.fr).

REFERENCES

Bottazzi E., Catenacci C., Gangemi A. & Lehmann J. ,

2006. From Collective Intentionality to Intentional

Collectives: an Ontological Perspective. In Cognitive

Systems Research, Special Issue on Cognition, Joint

Action and Collective Intentionality, Elsevier, 7(2-3),

p. 192-208.

Bruaux S., Kassel G. & Morel G., 2005. An ontological

approach to the construction of problem-solving

models. In P. Clark and G. Schreiber (eds), In the 3

International Conference on Knowledge Capture (K-

CAP 2005), ACM, p. 181-182. A longer version is

published as LaRIA’s Research Report 2005-03.

Available at: http://hal.ccsd.cnrs.fr/ccsd-00005019 .

Eden A. H. & Turner R., 2006. Problems in the Ontology

of Computer Programs. Technical Report CSM-461,

ISSN 1744-8050, Department of Computer Science,

University of Essex. From

www.eden-

study.org/articles/2006/problems-

ontology_programs_csm461.pdf.

Fortier J.-Y. & Kassel G., 2004. Managing Knowledge at

the Information Level: an Ontological Approach. In

Proceedings of the ECAI'2004 Workshop on

Knowledge Management and Organizational

Memories, Valencia (Spain), p. 39-45.

Gangemi A. & Borgos S. (eds), 2004. Proceedings of the

EKAW’04 Workshop on Core Ontologies in Ontology

Engineering, Northamptonshire (UK). From

http://ceur-ws.org (Vol-118).

Gangemi A. & Mika P., 2003. Understanding the

Semantic Web through Descriptions and Situations. In

R. Meersman et al. (eds), Proceedings of the

International Conference on Ontologies, Databases

and Applications of Semantics (ODBASE 2003),

Catania (Italy), 2003.

Kroes P. & Meijers A., 2002. The Dual Nature of

Thechnical Artifacts – presentation of a new research

programme. In Techné, 6(2) Winter 2002, p. 4-8.

Masolo C., Borgo S., Gangemi A., Guarino N., Oltramari

A. & Schneider L., 2003. The WonderWeb Library of

Foundational Ontologies and the DOLCE ontology.

WonderWeb Deliverable D18, final report (vr. 1.0, 31-

12-2003).

Newell A., 1982. The Knowledge Level. In Artificial

Intelligence 18, p. 87-127.

Niles I., Pease A., 2001. Towards a standard upper

ontology. In Proceedings of the International

Conference on Formal Ontology in Information

Systems (FOIS’2001). ACM Press., p 2-9.

Oberle D., Lamparter S., Grimm S., Vrandecic D., Staab

S. & Gangemi A., 2006. Towards Ontologies for

Formalizing Modularization and Communication in

Large Software Systems. In Applied Ontology, 1(2), p.

163-202.

Roman D., Keller U., Lausen H., de Bruijn J., Lara R.,

Stollberg M., Polleres A., Feier C., Bussler C. &

Fensel D., 2005. Web Service Modeling Ontology. In

Applied Ontology 1, p. 77-106.

Steimann F., 2000. On the representation of roles in

object-oriented and conceptual modelling. In Data and

Knowledge Engineering, 35, p. 83-106.

Temal L., Lando P., Gibaud B., Dojat M., Kassel G. &

Lapujade A

., 2006. OntoNeuroBase: a multi-layered

application ontology in neuroimaging. In Proceedings

of the 2

Workshop: Formal Ontologies Meet

Industry: FOMI 2006, Trento (Italy).

Turner R. & Eden A.H. (in press). Towards a

Programming Language Ontology. In G. Dodig-

Crnkovic and S. Stuart (eds.), Computing, Philosophy,

and Cognitive Science, Cambridge, UK: Cambridge

Scholars Press.

Welty C., 1995. An Integrated Representation for

Software Development and Discovery. Ph.D. Thesis,

RPI Computer Science Dept. July, 1995. From

http://www.cs.vassar.edu/faculty/welty/papers/phd/

ICSOFT 2007 - International Conference on Software and Data Technologies

170
