TOWARDS A HOLISTIC INTEGRATION OF SOFTWARE

LIFECYCLE PROCESSES USING THE SEMANTIC WEB

Roy Oberhauser and Rainer Schmidt

Department of Computer Science, Aalen University, Beethovenstr. 1, 73430 Aalen, Germany

Keywords: Software Lifecycle Proce

sses, Software Engineering, Semantic Web.

Abstract: For comprehensive software lifecycle processes, a trichotomy continues to subsist between the software

development processes, enterprise IT processes, and the software runtime environment. Currently,

integrating software lifecycle processes requires substantial effort, and the information needed for the

execution of (semi-)automated software lifecycle workflows is not readily accessible and is typically

scattered across semantically heterogeneous sources. Consequently, an interrupted flow of information

ensues between the development/maintenance phases and operational phases in the software lifecycle,

resulting in ignorance, inefficiencies, and suboptimal product quality and support levels. Furthermore,

today’s abstract IT (e.g., ITIL) and software processes are often derived into concrete processes and

workflows manually, causing errors, extensive effort, and limiting widespread adoption of best practices.

This paper describes an approach for improving information flow throughout the software lifecycle via the

(semi-)automated realization of abstract software lifecycle processes and workflows in combination with

Semantic Web technologies.

1 INTRODUCTION

For a long time, software development and operation

were regarded as separate disciplines. However,

there is an increasing interest in a holistic view on

the entire software lifecycle. For enterprises,

software lifecycle processes such as the ITIL

(ITSMF, 2004) application management process

provide an abstract view that includes phases of the

software lifecycle as shown in Figure 1. Software

lifecycle processes tend to have a broader view than

most software development processes, which

typically include only the phases from requirements

analysis to roll-out, but often ignore the operation

and the retirement phases of software. Application

development entails the requirements, design, and

build phases. Service management consists of the

deploy, operate, optimize, and retirement phases.

For instance, it is theoretically possible to use

information gathered during one phase to help

optimize another. Operational information could be

used for optimizing the software design.

To realize advantages of software lifecycle

processes ec

onomically and efficiently, it is

necessary to have information flows of semantically-

annotated information with appropriate information

retrievable in a diverse operational infrastructure

across organization boundaries.

Today, however, various barriers impede the

necessary effi

cient information flow capability.

Therefore, this paper will analyze barriers for

realizing the advantages of comprehensive software

lifecycle processes and provide an initial approach to

towards overcoming some of these impediments.

Application Management

Requirements

Optimise

Operate

Deploy

Design

Build

Service Management

Application Development

Retirement

Figure 1: ITIL application management.

137

Oberhauser R. and Schmidt R. (2007).

TOWARDS A HOLISTIC INTEGRATION OF SOFTWARE LIFECYCLE PROCESSES USING THE SEMANTIC WEB.

In Proceedings of the Second International Conference on Software and Data Technologies - Volume ISDM/WsEHST/DC, pages 137-144

DOI: 10.5220/0001343101370144

 SciTePress

2 PROBLEM

While comprehensive software lifecycle processes

offer a number of advantages, in practice these are

rarely fully exploited. Two reasons are plausible:

realizing integrated software lifecycle processes

requires significant effort, and the information

needed for the execution of (semi-)automated

software lifecycle workflows is not readily

accessible and is typically distributed across

semantically heterogeneous sources.

2.1 High Implementation Effort for

Software Lifecycle Processes

The prodigious implementation effort for software

lifecycle processes is due to a large extent because

of the semantic gap between the abstract process

descriptions and the executable process, as shown in

Figure 2. Furthermore, there is no appropriate

representation of best practices. Workflows which

already have been proven as beneficial cannot be

easily reused, because they are not easily accessible

and a common representation is missing. Thus, the

derivation of executable processes from the abstract

process description has to be done manually.

However, the manual derivation causes a number of

subsequent problems: it is an error-prone task.

Second, the degree of reuse is low; the executable

software lifecycle processes reuse only few

elements, leading to a higher error rate because

tested workflows are rarely reused. Third, there is

only a low degree of standardization. This is of

particular consequence when the software lifecycle

process spans multiple interacting organizations.

Figure 2: Semantic gap.

2.2 Breaks in Information Flows

An encumbering problem for the efficient

implementation of software lifecycle processes are

breaks in the information flows between software

operation and software development as shown in

Figure 3.

After transferring the software to the run-time

environment, only few or no information is passed

back to the software developer. This information can

be divided into two sets.

First, there is run-time information which is

machine-observable. That means, this information

can be gathered automatically. Such machine

observable run-time information is, for example, the

application log, the server log, and the system log.

Furthermore, data in the application database may be

important for debugging, etc.

Software Developer

Administrator

Software Development Operation

Software

Run-time

environment

(

)

User

Help Desk

Incident

Management

Problem

Management

(

)

Application

Log

Application

Database

System Log

Server Log

CMDB Incident DB

Figure 3: Breaks in information flows.

Second, there is run-time information which

cannot be directly gathered by a machine, e.g.,

functional defects in the software: the software

continues its operations but delivers invalid results

or exhibits incorrect behavior. This information is

gathered indirectly by a user or administrator and

usually communicated to a single point of contact,

called a help or service desk. All information

gathered by the help desk is processed by incident

and problem management processes (as defined in

ITIL) and stored in an incident database. The

incident and problem analysis is supported by the

configuration management database which contains

information about the configuration of the run-time

environment, e.g., details such as software versions

used on which systems, hardware, networking, etc.

In practice, an important problem is deciding

which information can be used to diagnose which

type of problem. Figure 4 shows three hypothetical

examples. For performance problems, the server log

and the application database could be analyzed.

Reliability problems can be analyzed using the

server, system and application log in conjunction

with the configuration management database

ICSOFT 2007 - International Conference on Software and Data Technologies

138

(CMDB). Finally problems in the application logic

(e.g., incorrect behavior) can be analyzed using the

application database and incident database where

observations of incorrect behavior of the application

are stored.

Figure 4: Best practices for problem diagnosis.

It is evident that the selection of the appropriate

information sources non-trivial. But in practice,

there is no means to appropriately store the

information about which kind of problem requires

which information sources. This knowledge is not

theory-based, but comes from observation and

experience and can be seen as a collection of best

practices.

Figure 5: Scattered Information Island Landscape.

While both machine-readable and human-

readable run-time information could provide a

significant benefit to the software developer -

however, differences in syntax and semantics

impede the usage of such information. Furthermore,

important information is not discoverable because of

the dispersion across different sources using

incompatible syntaxes and semantics. Consequently

a landscape of isolated tools, systems, and databases

emerges as shown in Figure 5.

3 SOLUTION APPROACH

Any feasible and concomitantly practical approach

towards a holistic solution needs to address the

previously mentioned problems of section 2 within

realistic constraints. E.g., to further adoption, it

should be platform-independent, vendor-neutral,

utilize standards, and support a high degree of

flexibility and loose-coupling. A possible approach

that this paper presents is SWLIFE: Semantic Web-

based Lifecycle Integration Framework for

Enterprises. Before describing the framework

elements, the underlying principles of the

framework’s architecture will be elucidated.

3.1 Solution Principles

This section describes the key principles of the

solution approach.

I) Holistic need-based integration of human and

machine processes, services, and ontologically

structured data for the operational lifecycle.

The lack of integration between software

engineering processes and customer (e.g.,

enterprise or IT) software operational processes

(e.g., ITIL) causes extensive inefficiencies,

especially in the maintenance phase of a

software product - both in the processes and

access to necessary data. Yet this is typically

the longest, most expensive, and least

predictable phase.

II) Round-trip Process Engineering: prescriptive

while concurrently descriptive abstract

processes. Too often abstract processes are not

transformed or mapped to concrete processes

correctly, thereby losing its prescriptive nature.

Abstract processes hereby are mapped (semi-

)automatically to concrete processes, and

customized current concrete processes are

abstracted to determine if they still conform to

the abstract processes. If not, either they or the

abstract processes are adjusted so that the

abstract processes are also descriptive.

III) Semantic Web accessibility and utilization of

meaningful data. Instead of hidden, obscure

(operational) data in applications and tools

such as log files, this data is discoverable,

accessible, and its meaning described via

Semantic Web Services.

TOWARDS A HOLISTIC INTEGRATION OF SOFTWARE LIFECYCLE PROCESSES USING THE SEMANTIC WEB

139

IV) (Semi-)Automated exchangeability and reuse of

machine-readable best practices in the form of

workflows. Rather than just textual exchange

via documents, which are difficult and arduous

to automate, both abstract and concrete

processes and workflows are described in

standardized Markup Languages, e.g.,

including XMI (e.g., from UML Activity

Diagrams), BPEL4WS, various Grid Workflow

languages, etc. These are stored and exchanged

in enterprise-wide and trusted internet

repositories. Apposite choices or standards for

such Markup Languages are outside the scope

of this paper.

V) Service-Oriented Architecture (SOA). In order

to achieve the level of integration necessary,

SOA principles including loose-coupling,

encapsulation, reusability, composability,

discoverability, etc. are applied, generally in

conjunction with Web Services standards.

VI) Feasible and reasonable automation. Common

operational or maintenance routines are

automated to the degree reasonable and

economical for workflows and the (semi)-

automated composition of services.

VII) Web-based human process documentation and

integrated infrastructure binding. Web-based

process documentation of software engineering

processes (e.g., VM-XT, RUP) and IT

processes (e.g., ITIL) are tailored to the context

and bound to the actual human and machine

workflows used, with the services hyperlinked

within the documentation. Thus a human can

determine the status of a workflow, start an

(automated) workflow, etc., all in the context

of the organization’s processes.

3.2 Solution Description

This section describes the solution approach of

SWLIFE as depicted in the illustration of Figure 6.

The layers used are for grouping purposes and are

not intended to show strict abstraction or

dependency relations. The white rectangles show

examples of possible current processes and tools.

The black rectangles show new areas that SWLIFE

provides or enables. It is not intended to be

exhaustive but rather illustrative of the approach,

additional layers and items are conceivable.

The vertical column Vendor Development

Operations (see Fig. 6) includes the processes and

infrastructure of a product developer, while the

vertical column Enterprise IT Operations includes

those of the product customer who operates the

software product. Black hashed ellipses between

these columns show a new permeation between

these two usually distinct organizational entities at a

given layer.

The Process Layer (see Fig. 6) can include

processes defined at an organizational level, and

depicts abstract process models (e.g., RUP or ITIL)

that are tailored via a Process Mapping Framework

to concrete processes. These processes typically

include workflows performed at various points by

various human roles defined by theses processes,

and can include machine-based workflows to

automate certain recurring tasks. The Process

Mapping Framework includes techniques and

tooling to support the tailoring of abstract processes

and workflows to concrete processes, and for

analyzing concrete processes and workflows,

abstracting them, and comparing them to intended or

previous abstract processes. The Process and

Workflow Repository provides a retrieval, update,

and exchange mechanism for processes and

workflows, such as software engineering-related,

domain-specific (e.g., ecommerce, banks),

enterprise-specific, platform-specific, and vendor-

and application- specific areas. Such a mechanism

could improve quality and reduce investment costs

by enhancing the distribution and interchange of best

practices in these areas. The Integrated Process and

Workflow Transformation and Execution Subsystem

ensures that integrated human and machine

processes and workflows are transformed, including

(semi-)automatic composition, as necessary at run-

time, and ensures and monitors their execution.

The transformations and mappings in the Process

Layer can utilize, where available, a Knowledge

Layer, where Knowledge Management repositories

of the applicable organizations may contain

knowledge in the form of rules for defining process

and workflow transformation.

The Semantic Integration Layer (see Fig. 6)

includes the Semantic Web interfaces for tools and

services, including adapters when not provided, and

any necessary infrastructure. This includes existing

subsystems on the vendor and enterprise side for

ontology loading and reasoning, as well as an

integrated capability for SWLIFE scenarios.

The Infrastructure and Technology Layer in Fig.

6 includes the tools, applications, and technology

utilized in the various organizations.

Governance Management includes the aspects

necessary to govern the integration between

organizations, including the integration of policy

management.

ICSOFT 2007 - International Conference on Software and Data Technologies

140

SWLIFE

Semantic Web-based Lifecycle Integration Framework for Enterprises

Infrastructure and

Technology Layer

Process Layer

Abstract IT Processes

(e.g., ITIL)

Concrete IT Processes

Application

Lifecycle

Management

Tools (ALM)

Abstract Software Engineering

(SE) Processes

(e.g, VM-XT, RUP)

Concrete SE Processes

Specific Human and Machine

SE Workflows

Specific Human and Machine

IT Operational Workflows

Configuration

Management

Database

(CMDB)

Process Mapping

Framework

Process and

Workflow

Repository

(Shared and Local)

Incident

Database

Network and

Systems

Management

Defect

Database

SE Tools

Configuration

Management

Integrated Process

and Workflow

Transformation and

Execution

Governance Management

Enterprise Policy

Management

Vendor Policy

Management

Integrated Policy

Management

Knowledge Layer

IT Knowledge

Management

SE Knowledge

Management

Integrated Knowledge

Management

Semantic Integration Layer

Semantic Web

Infrastructure

SE and Application

Ontology

Subsystem

IT and Domain

Ontology

Subsystem

Enterprise IT OperationsVendor Development Operations

Figure 6: SWLIFE.

An example of the interaction of the layers is

shown in Figure 7. The Semantic Integration Layer

encapsulates Semantic Web Services (SWS)

interfaces of information sources such as CMDB,

Incident DB, and Application Logs. In the Semantic

Integration Layer, ontologies both from the vendor

and enterprise are used to classify the SWS and to

clarify their relationships. Aggregation and filtering

is done via a Reasoner to support the workflow

transformation process. Rules provided in the

Knowledge Management Layer assist the Workflow

Transformation Service in order to transform

integrated workflows from the vendor and enterprise

into concrete executable workflows which are

provided and executed as SWS.

Figure 7: Layer interaction.

4 SOLUTION REALIZATION

The implementation of the SWLIFE approach has

focused on the problem of the transformation of

abstract processes to and from concrete processes.

To support an efficient, correct, and reliable

transformation, the support non-trivial workflows

and their (semi-)automatic composition should be

supported on tooling suitable in engineering and IT

settings. Although there is much research in the

automatic composition of OWL-S based services,

various HTN planners mentioned in research were

considered unsuitable, e.g., due to the lack of access,

instability, or lack of usable results in practice. E.g.,

OWLS-XPlan was considered, but lacked branching

capabilities, sufficient documentation, and an

execution engine for its PDDXML workflow format.

E.g., Mindswap Composer also lacked branching

and loop capabilities.

With the current lack of usable planners for

workflow composition, a separate and practical

solution for the Workflow Transformation Service

was developed that combines an Ontology

Subsystem with a Rule Engine, as shown in Figure

8. For the Ontology Subsystem, the Protégé OWL

API 3.2 Beta, was used to read in the ontologies, and

the integrated Protégé Reasoner was used (external

reasoners are an option) to select a set of possible

service matches. For the Rule Engine, JBoss Rules

3.0.5 was chosen. As the abstract workflow is read

in and parsed, any abstract concepts are detected and

the Reasoner returns a set of service instances that

are a possible match. Because the choices may be

highly dependent on a number of factors, this set is

passed to the rule engine as a fact model and

inserted into its working memory. The rule engine

then selects the appropriate service based on the set

of rules in the Rule Base. The use of a rule engine

allows a greater degree of flexibility and change for

enterprises without the encumbrances inherent in

lower-level programming languages, although script

languages are an alternative. If no matching service

was found, an error is issued. If more than one

service matched, then the first one was used,

replacing the abstract concept in the workflow with

a concrete service.

Figure 8: Abstract to Concrete Workflow Transformation.

TOWARDS A HOLISTIC INTEGRATION OF SOFTWARE LIFECYCLE PROCESSES USING THE SEMANTIC WEB

141

Various workflow languages would be suitable

for SWLIFE, however, the domain-specific language

Service Language Layer (SLL) (Kossmann et al,

2005)(Dinger et al, 2006 SLL), was chosen for the

implementation due to its simplicity as a workflow

language at the programming language level and

because of its service-centric nature. SLL can also

be viewed in its XML form and be transformed into

BPEL4WS or another workflow language.

For feasibility test purposes for such a workflow

scenario, Web Service adapters and OWL-S

descriptions for typically non-SOA software

lifecycle applications (e.g., Subversion version

control system, compiler, etc.) were created, along

with an abstract workflow specified in SLL that

specified various abstract tools to automatically

generate a report for an engineer. This abstract SLL

workflow was passed to the Workflow

Transformation Service which then converted it into

a concrete SLL workflow referencing concrete tool

service instances, and the workflow was then

deployed and executed as a service on the OpenXL

platform.

For performance measurements, a Windows XP

SP2 PC with an AMD 2600+ CPU, 1GB RAM, a

1Mb/s Internet connection, Java 5, Apache Tomcat

Version 5.5.20, Apache Axis 1.4, and OpenXL 1.0

was used.

In applying a SWLIFE scenario, it was

determined that a major contributing factor to the

performance of the workflow transformation was the

ontology loading time. Because of the difficulty of

creating local copies, adapting import URLs, and

maintaining these against new version, Internet

retrieval of OWL-S related ontologies is a highly

likely use case. The average across 100 attempts for

inserting an OWL-S based service ontology to the

knowledge base was 5.66 seconds. This would

indicate that it is best to load and initialize the

Workflow Transformation Service once as a long-

running service even in an enterprise setting.

Table 1: Average workflow transformation time.

Number of

possible Services

4 Abstract

concepts (ms)

100 Abstract

concepts (ms)

5 86 111

10 92 120

25 106 123

The actual abstract to concrete workflow

transformation time given a simple rule file was

measured, averaged across 500 attempts as shown in

Table 1, based on the number of available services,

and utilizing 4 or 100 abstract concepts. This shows

that the performance of workflow transformation

from abstract to concrete workflows utilizing a rule

engine is practicable.

5 RELATED WORK

Approaches for a holistic access and integration of

information include collaboration software, ALM

(Application Lifecycle Management) and ECM

(Enterprise Content Management) which allows the

management of an organization’s unstructured

information, wherever it exists as the AIIM

(Association for Information and Image

Management) intends. Yet most of the current

applications in these areas have only partial

solutions, non-standard interfaces, and little to no

integration in the operational IT processes of

customers. Grid technologies, platforms (e.g., the

Globus Toolkit), and related research (e.g., the

Adaptive Services Grid) could well provide an

infrastructural basis for some aspects of SWLIFE, so

while this approach does not preclude it, it does not

require the Grid since the primary focus of SWLIFE

is not the sharing computational resources or

services. The concept of virtual organizations as

used in the Grid could be leveraged for the ad-hoc

integration and access by a vendor to the provided

customer software and/or data.

The SWLIFE approach can leverage and

integrate work on software engineering ontologies,

e.g., (Calero, 2006) includes work on SWEBOK,

software maintenance, software measurement, and

other related ontologies. Work on generic IT and

domain-specific ontologies could be used in

SWLIFE, an example is the Health Information

Technology Ontology Project (HITOP).

The approach presented here also has

relationships to the semantic-based composition of

web services as described in (Sivashanmugam et al.,

2004), (Medjahed et. al., 2003) and (McIllraith et al.,

2000). These approaches show how Web Services

can be integrated using semantic web technologies.

This also applies to the ontology-based description

of business processes as defined in (Koschmider et

al., 2005) and in (Rosemann et al., 2002) and

(Rosemann et al., 2004). Work utilizing the

Semantic Web for automated software engineering

purposes includes (Dinger, 2006 SWS-ASE). A

tighter relationship exists with approaches for the

ontology-based representation of service processes

such as the incident and problem management

processes as defined in (Schmidt et al., 2007). The

semantic alignment of business processes using

ICSOFT 2007 - International Conference on Software and Data Technologies

142

ontologies is described in (Brockmanns et al., 2006).

Ontologies can also be used for supporting the

composition of web services as described in

(Agarwal et al., 2005). A mixed-initiative

framework for Semantic Web service discovery and

composition is presented in (Rao et al., 2006). It

interleaves human decision making and automated

functionality. Thus it can also be applied even if

annotations are incomplete and inconsistent. This

scenario is rather similar to the scenario of SWLIFE,

and therefore this approach will be further

investigated.

6 CONCLUSION

The lack of integration of between the stages in

comprehensive lifecycle processes between product

vendors and enterprise customers continues to

plague the software industry. This manifests itself

perplexed administrators, in extensive, expensive

and difficult defect remediation, long defect duration

times, long service response and patch turn-around

times, etc. As software continues to increase in its

complexity and degree of integration, this situation

will deteriorate without attention.

To address this situation, the SWLIFE approach

bridges these process and information flow breaks

by supporting integrated lifecycle processes, shared

human and machine (semi-)automated workflows,

and enabling better quality and more efficient

semantic integration of infrastructure elements and

artifacts. SWLIFE is influenced by background

trends such as a high degree of networked systems,

increasing integration via Service-Oriented

Architecture (SOA) and Web Services, Semantic

Web, outsourcing, and cross-organizational value

creation, and service providing in the IT area.

Economically, an advantage of the SWLIFE

approach is that each vendor of a product invests in

the Semantic Web interface to its product once, and

all customers can benefit from faster and higher

quality maintenance response, providing an

incentive to customers. Customers can utilize the

Semantic Web interfaces to automate workflows,

integrate workflows into higher-level processes, and

more efficiently gather and analyze quality metrics.

Via a standardized exchange format and repositories

for processes and workflows, the investments can be

incremental and shared. The implementation work

showed that a feasible and practical solution for the

(semi-)automatic composition of workflows using

Semantic Web Service interfaces for the tools and

services involved in SWLIFE scenarios exists.

A future market for packaged processes and

workflows (analogous to the IBM Rational Unified

Process) which are trusted, supported, and

maintained, is thinkable. In addition, Semantic Web

Service adapters can be provided to integrate legacy

or non-conforming products.

Even a partial application of the SWLIFE

approach can yield advantages via increased and

systematic application of best practices in the form

of human and machine-readable processes and

workflows, the holistic needs-based integration of

vendor and customer infrastructure, and the

utilization of machine-processable semantic

infrastructure. This a viable approach to addressing

the skyrocketing complexity and maintenance costs

associated with the use of software products.

Some challenges for the SWLIFE approach

include: the need for highly-trained personnel for

semantic, ontology, process, and workflow creation

and usage; for cross-organizational access trust,

security, authorization, and policy issues need to be

addressed; the lack of (standardized) ontologies in

the various SE and IT areas; and the adoption and

usage of abstract processes and their description in

machine-processable form.

Further work will include exploring additional

application scenarios, for instance, enhanced

response workflows for security intrusions, where

rapid response and high quality incident data play

important roles.

ACKNOWLEDGEMENTS

The authors would like to thank and acknowledge

Thomas Ilzhöfer for his thesis work.

REFERENCES

Agarwal, V.; Koustuv, D.; Karnik, N.; Kumar, A.; Kundu,

A.; Mittal, S,; Srivastava, B.; 2005: A service creation

environment based on end to end composition of Web

services. Proceedings of the 14th International

Conference on World Wide Web, Chiba, Japan p 128

– 137, 2005.

Brockmans, S.; Ehrig, M.; Koschmider, K.; Oberweis, A.;

Studer, R., 2006.: Semantic Alignment of Business

Processes. In: Proceedings of the Eighth International

Conference on Enterprise Information Systems (ICEIS

2006), pp. 191-196. INSTICC Press, Cyprus, 2006.

Calero, C., Ruiz, F., Piattini, M., 2006. Ontologies for

Software Engineering and Software Technology.

Springer-Verlag.

TOWARDS A HOLISTIC INTEGRATION OF SOFTWARE LIFECYCLE PROCESSES USING THE SEMANTIC WEB

143

Dinger, U., Oberhauser, R., Reichel, C., 2006. SWS-ASE:

Leveraging Web Service-based Software Engineering.

In Proceedings of the International Conference on

Software Engineering Applications, 2006.

Dinger, U., Reichel, C., 2006. Service Language Layer

(SLL) Specification Version 1.1.3, Working Draft.

http://www.dbis.ethz.ch/people/reichech/sll_service_la

nguage_layer_specification_version_1.1.3.pdf

ITSMF, Service Management Forum, 2004.: IT Service

Management – An Introduction. Van Haren

Publishing, Amsterdam, 2004.

Koschmider, A.; Oberweis, A., 2005.: Ontology based

Business Process Description. In: Proceedings of the

CAiSE´05 WORKSHOPS, no. 2, pp. 321-333,

Portugal, 2005.

Kossmann, D., Reichel, C., 2005. SLL: Running My Web

Services on Your WS Platforms. Proceedings of ICWS

2005

McIlraith, S.A. Son, T.C. Honglei Zeng, 2000.

Semantic Web sServices 2000. IEEE Intelligent

Systems and Their Applications Volume: 16, Issue: 2,

pages 46- 53

Medjahed, B.; Bouguettaya, A.; and Elmagarmid, A. K.

2003.: Composing Web services on the Semantic

Web. The VLDB Journal The International Journal on

Very Large Data Bases, Volume 12.,

Rao, J.,; Dimitrov, D.;, Hofmann, P.;, Sadeh, N., 2006. ;

"A Mixed Initiative Approach to Semantic Web

Service Discovery and Composition: SAP’s Guided

Procedures Framework," icws , pp. 401-410, 2006.

Rosemann, M.; Green, P., 2002.: Developing a meta

model for the Bunge-Wand-Weber ontological

constructs. In: Information Systems (27), pp. 75-91,

2002.

Rosemann, M.; Indulska, M.; Green, P., 2004.: A

Reference Methodology for Conducting Ontological

Analyses. In: Proceedings of the 23rd International

Conference on Conceptual Modelling (ER 2004). pp.

110-121, Shanghai, 2004.

Schmidt, R.; Bartsch C.:, 2007. Ontology-based Modelling

of Service Processes and Services. In: Proceedings of

the IADIS International Conference, Applied

Computing 2007, pp. 67-74, Salamanca, Spain, 2007.

Sivashanmugam, K.; Miller, J. A.; Sheth, A. P.; Verma K.

2004:. Framework for Semantic Web Process

Composition International Journal of Electronic

Commerce Volume 9, Number 2 / Winter 2004-5,

pages 71 - 106

ICSOFT 2007 - International Conference on Software and Data Technologies

144
