A CONTEXT-BASED APPROACH FOR LINGUISTIC MATCHING

Youssef Bououlid Idrissi and Julie Vachon

DIRO, University of Montreal

Montreal, Quebec, H3C 3J7, Canada

Keywords:

Context analysis, semantic alignment, linguistic matching, data source integration.

Abstract:

As currently implemented by most data mapping systems, linguistic matching often boils down to string

comparison or to a synonym look-up in a dictionary. But these solutions have proved to be inefﬁcient for

dealing with highly heterogeneous data sources. To cope with data source heterogeneity more efﬁciently, we

introduce INDIGO, a system which computes semantic matching by taking into account data sources’ context.

The distinctive feature of INDIGO consists in enriching data sources with semantic information extracted

from their individual development artifacts before mapping them. As explained in this article, experiments

conducted on two case studies proved the relevance of this approach.

1 INTRODUCTION

Considering their omnipresence in matching solutions

(Noy and Musen, 2001; Hu et al., 2006; J. Madhavan

and Rahm, 2001; Euzenat and et. al, 2004), linguistic

matching strategies deserve to be further developed

and improved. Current strategies commonly resort

to two main evaluation techniques: (1) string com-

parison metrics and (2) lexical similarity functions.

String metrics compare concept names according to

their string characteristics (e.g. number of shared

characters, similar string lengths, etc.). As for lexi-

cal functions, they assess similarity between concept

names rather by comparing their respective meanings.

Hence, each concept name is looked up in some exter-

nal dictionary (e.g. WordNet) in order to extract the

set of words that are semantically related to it (e.g. by

synonymy, hyponymy, etc.). But in practice, unfortu-

nately, neither string metrics nor lexical-based func-

tions prove to be robust matching techniques when

data sources to be aligned are very heterogeneous. In

particular, lexical-based functions rarely perform well

since general dictionaries on which they rely do not

consider domain speciﬁcities and can even muddle up

matching with irrelevant synonyms or homonyms. A

reference to the context is often mandatory to clear

up ambiguities. Hence, this article introduces IN-

DIGO

, a system which implements an innovative so-

lution based on the exploration of the data sources’

informational context. The informational context of

a data source is composed of all the available textual

and formal artifacts documenting, specifying, imple-

menting this data source. It therefore conceals pre-

cious supplementary information which can provide

useful insights about the semantics of data sources’

concepts.

INDIGO distinguishes two main sets of documents

in the informational context (cf. (Bououlid and Va-

chon, 2005)). The ﬁrst set, called the descriptive con-

text, gathers all the available data source speciﬁcation

and documentation ﬁles produced during the different

development stages. The second set is called the op-

erational context. It is composed of formal artifacts

such as programs, forms or XML ﬁles. To get con-

textual semantic information, INDIGO focuses on the

ﬁrst set of documents i.e. the descriptive context

Given their descriptive nature, these documents are

more likely to reveal concept names semantically re-

lated to the ones found in the data sources. INDIGO

explores the descriptive context to extract the words

INteroperability and Data InteGratiOn

The operational context is explored for other purposes,

such as for elaborating complex matching (Bououlid and

Vachon, 2007).

197

Bououlid Idrissi Y. and Vachon J. (2007).

A CONTEXT-BASED APPROACH FOR LINGUISTIC MATCHING.

In Proceedings of the Second International Conference on Software and Data Technologies - Volume ISDM/WsEHST/DC, pages 197-202

DOI: 10.5220/0001345601970202

 SciTePress

found in the vicinity of some data source concept

name found within a phrase in a document. These

neighboring words will be useful to evaluate similar-

ity between concepts. Extracted words are integrated

and related to their corresponding concept in the data

source. In INDIGO, this enhancement of a data source

with information gathered from its context is called

data source enrichment.

To show the beneﬁts of data source enrichment,

INDIGO was compared to two well-known matching

approaches, that is Similarity Flooding (Melnik et al.,

2002) and V-Doc (Y. Qu and Cheng, 2006). The ex-

periment consisted in applying each matching sys-

tem over the two following case studies: (1) Match-

ing of two database schemas taken from two open-

source e-commerce applications: Java Pet Store (Mi-

crosystems, 2005) and eStore (McUmber, 2003) and

(2) Matching of two real data sources describing

courses taught at Cornell University and at the Uni-

versity of Washington.

The rest of the paper is organized as follows. Sec-

tion 2 surveys recent work on linguistic matching.

Section 3 describes the current implementation of IN-

DIGO’s Context Analyzer and Mapper modules. Ex-

perimental results of our two case studies are pre-

sented and commented in Section 4. Concluding re-

marks and comments on future work are given in Sec-

tion 5.

2 RELATED WORK

As pointed out in section 1, there are essentially

two categories of techniques for linguistic matching:

string comparison metrics and lexical-based match-

ing methods. Concerning string metrics, the most

popular are certainly the following (Euzenat and et.

al, 2004): Levenstein, Needleman-Wunsch, Smith-

Waterman, Jaro-Winkler and Q-Gram. As for lexical-

based metrics, they were mostly developed within

the framework of speciﬁc mapping systems such as

ASCO (B.T. Le and Gandon, 2004) and HCONE-

merge (K. Kotis and Stergiou, 2004) to serve their

own application objectives. Both of these systems

resort to WordNet to collect additional semantic in-

formation (sets of words) about the concept to be

matched. For instance, ASCO searches for synonyms

while HCONE-merge looks for hyponyms.

Among the numerous linguistic matching solu-

tions mentioned in the literature, we had a closer

look at two systems frequently cited by researchers

for their performances and which were available on

the net: Similarity Flooding (SF)(Melnik et al., 2002)

and V-Doc (Y. Qu and Cheng, 2006). We selected

those two applications to experimentally compare

them with our own system INDIGO.

Similarity Flooding (SF) is a generic algorithm

used to match different kinds of data structures

called models. Models can be composed of data

schemas, data instances or a combination of both.

The SF algorithm converts both source and tar-

get models into some proprietary labeled directed

graph representation (G

and G

). It then applies

an iterative ﬁxed point based procedure over these

two graphs to discover matches between their re-

spective nodes.

V-Doc is the linguistic matching module of Falcon-

AO (Hu et al., 2006), a matching system for on-

tologies. V-Doc constructs for each entity in the

ontologies to be aligned, a virtual document con-

sisting in a set of words extracted from the name,

label and comment ﬁelds of the entity and of its

neighbors within the ontology. It then compares

virtual documents using the well-known TF/IDF

technique.

INDIGO aims at the same objectives as the above

systems. From a conceptual standpoint, it belongs to

the category of systems relying on multiple strategic

matchers (A. Doan and Halevy, 2003; Do and Rahm,

2002). It distinguishes itself by taking into account

the informational context of data sources in its align-

ment process.

3 INDIGO’S ARCHITECTURE

To handle both context analysis and semantic match-

ing, INDIGO presents an architecture composed of

two main modules: a Context Analyzer and a Map-

per module. The Context Analyzer module takes the

data sources to be matched along with related context

documents and proceeds to their enrichment before

delivering them to the Mapper module for their effec-

tive matching.

3.1 Context Analyzer

The role of the Context analyzer consists in parsing

the artifacts related to a data source with the aim to

extract pertinent semantic information and to enrich

this data source with it. Our implementation targets

two types of enrichment: (1) enhancement of a data

source with complex concepts

and (2) enhancement

Term frequency/Inverted Document frequency.

This kind of enhancement will not be discussed in this

article because it is not directly involved in linguistic match-

ing (c.f. (Bououlid and Vachon, 2007) for details).

ICSOFT 2007 - International Conference on Software and Data Technologies

198

of a data source with related concept names. To be

more speciﬁc about the semantics of a given concept,

the descriptive context is searched for entities which

may relate to this concept. The following heuristics

is proposed to identify these relations: ”Two concepts

that are often brought up one near the other are likely

to be closely related.”

Name

Product

PetStore

Supplier

Order

Figure 1: Graph of dependencies between concepts of the

Pet Store application.

In the Pet Store application (our ﬁrst case study),

the database model reveals that name is an attribute

of the product entity. In other respects, documen-

tation ﬁles clearly show that order and supplier are

concepts frequently appearing in the vicinity of the

product concept. For each concept referenced by path

s in the XML data source, a graph is constructed to

trace presumed dependencies between concepts. We

call such a graph a concept dependency graph (CDG).

Let s be the XML path of a concept in the data source

and let Concepts(s) be the set of concepts composing

s. A CDG for s is a graph that

1. links each c ∈ Concepts(s) to its successor c

′

in s

(with c

′

∈ Concepts(s)). The position of a concept

in the list thus obtained is called its level.

2. links each c ∈ Concepts(s) to a list elist(c)

of enrichment concepts extracted from the data

source’s context. The position of a concept in

elist(c) is called its rank.

Figure 1 shows a CDG stressing the connection

of the product concept with its name attribute and the

Pet Store database to which it belongs. These con-

cepts are vertically ordered on the ﬁgure. The CDG

also shows the relation of product with two enriching

concepts, order and supplier, which were often found

close by in the data source’s context. These concepts

appear horizontally ordered.

The design of INDIGO’s Context Analyzer (Fig-

ure 2) comprises two main modules, each being spe-

cialized in a speciﬁc type of information extraction.

To be speciﬁc, it is composed of a Concept Name Col-

lector and a Complex Concept Extractor, providing

the necessary support for the two kinds of enhance-

ment mentioned previously.

enhancer

Concept name

Context

generatorpreprocessor

Context

Complex concept

collector

Concept name

analyzer

Meta−

extractor

Figure 2: Architecture of the Context Analyzer.

As illustrated on Figure 2, these two analyzer

modules are headed by a meta-analyzer which coor-

dinates their respective tasks. At the lowest level, the

architecture provides utility modules to pre-process,

generate and enrich data sources with context infor-

mation.

3.1.1 Meta-analyzer

This module explores the set of documents constitut-

ing the informational context of the data source. It

classiﬁes each of them into either the formal or infor-

mal category. Then it addresses formal documents to

the Complex Concept Extractor and informal ones to

the Concept Name Collector.

3.1.2 Concept Name Collector

Given a concept name of a data source, the Collec-

tor gathers from the descriptive context all names fre-

quently surrounding it. The Collector chooses then

the closest ones to enrich the concept name with them.

Actually, the Collector executes the data source en-

richment process in two main stages: a context pre-

processing step followed by a data source enhance-

ment procedure.

Context preprocessing. The Collector relies on

two internal modules respectively named Context

Preprocessor and Context Generator to generate what

we called the contextualized concept ﬁle of a data

source (abbreviated CC-ﬁle). This ﬁle is written in

XML. For each concept name in the data source, it

gathers a set of nouns surrounding the concept in the

data source’s context documents. These nouns are

saved by the CC-ﬁle in some normalized form which

prevents that a single concept appearing in different

guises (e.g. inventory and inventories) be considered

as two distinct nouns. Let us consider the Pet Store

application for example, whose database contains a

table named SKU (i.e. Stock Keeping Unit). The

Context Preprocessor will thus parse the set of doc-

uments it was addressed and will gather all sentences

A CONTEXT-BASED APPROACH FOR LINGUISTIC MATCHING

199

containing the concept name SKU. Sentences are then

ﬁltered by the Context Generator to keep noun-type

words in their normalized form. The order in which a

word ﬁrst appears in a sentence is of course preserved.

SKU inventory item...

...store instance SKU inventory...

...item SKU.

K=2

PetStore

SKU

Inventory

Item

Figure 3: Enhancement of the SKU concept (generation of

the corresponding part of the CDG).

Data source enhancement. The CC-ﬁle elaborated

during the previous step is used by a third internal

module of the Collector, called Concept Name En-

hancer, to generate a CDG for each data source con-

cept. Let us consider the enhancement of the SKU

concept. Over each sentence of the CC-ﬁle relating

to SKU, the Concept Name Enhancer applies a po-

sition marker which tags each name surrounding the

SKU word with a distance value. This value indicates

how many names separate the tagged name from the

word SKU, be it on the left or on the right. The left

part of Figure 3 shows the tagging process. From

there on, each tagged name is collected together with

its distance tag and its frequency rate. Tagged names

are sorted in descending order of frequency rates and

proximity to SKU. Best candidates are retained to en-

rich the SKU concept. A threshold value is used to

limit the number of enriching concepts to be kept.

In the previous example, given a threshold K=2, the

names item and inventory are retained to enrich the

SKU concept and are thus added to SKU’s CDG.

3.2 Mapper Module

After the enhancement of data sources with the newly

extracted information, the Mapper module proceeds

to the matching phase. Allowing for multiple match-

ing strategies, its architecture is organized as a hier-

archy of modules where internal nodes are called co-

ordinators and where leaves represent aligners. Each

aligner implements a speciﬁc matching strategy based

on a particular similarity measure. For instance, a

name-based aligner can be used to compute matches

between concepts according to the similarity of their

names. As for coordinators, they combine predic-

tions of their respective children to elaborate their

own matching proposal.

3.3 Context-based Alignment

Context-based alignment is executed as follows. First,

a mapping is computed between two given data

sources without considering their context. Then,

for each pair of concepts a context similarity factor

(CSF) is assessed by comparing their respective CDG

(cf. Section 3.1). The CSF is a normalized value be-

tween 0 and 1 which is used to rate the augmentation

of concepts’ similarity by taking into account the sim-

ilarity of their respective context.

To show how a CSF is calculated, let us consider

the respective CDG of a source and of a target con-

cept, SN and TN, as illustratred on Figure 4. SN

(resp. TN

) denotes the concept occupying level i

and enrichment rank j in the CDG of the source con-

cept (resp. target concept). Each row of a CDG

denotes a context level, while each column denotes

a concept ranking regarding relevance to the context

(recall that rank 1 denotes the most relevant concept).

The evaluation of the CSF between SN and TN is as

follows.

First, we split up equally each list of enrichment

concepts into some predeﬁned number of subsets.

Figure 5 depicts the splitting, into w boxes, of the en-

richment concepts in a CDG. On a same level, boxes

should contain almost the same number of enrichment

concepts. Considering there are p

concepts on level i

and that p

= w∗k

, the ﬁrst r

boxes will therefore

contain k

+ 1 =

⌈

⌉

concepts while the follow-

ing w− r

others will have k

of these. Let SB

, with

i ∈ {1, ...,w}, denote the i

box in a source concept’s

CDG. SB

i, j

thus corresponds to the set of enrichment

concepts of level j in box SB

. Note that the CDG

of the target concept, illustrated on Figure 4, has been

splitted up exactly the same way as the CDG of the

source concept. Then, similarity between boxes SB

and TB

, where i

∈ {1,..., w}, is given by the fol-

lowing formula:

BoxSim(SB

,TB

) =

∑

min(n,m)

l=1

Inter(SB

,n−l+1

,TB

,m−l+1

)

∑

min(n,m)

l=1

Inter(SB

,n−l+1

,TB

,m−l+1

) is a function return-

ing 0 if SB

,n−l+1

∩TB

,m−l+1

is empty, and returning

1 otherwise. λ is a positive constant, superior to one,

which is empirically settled.

Finally, the context similarity factor (CSF) evalu-

ated between the respective CDG of a source and of

a target concept is given by the following formula:

CSF =

∑

i=1

w−|i−n(i)|

BoxSim(SB

,TB

n(i)

)

wα

where n(i) is the nearest target box index to i such as

BoxSim(SB

,TB

n(i)

) 6= 0.

ICSOFT 2007 - International Conference on Software and Data Technologies

200

...

n 1

n−1 1

1 1

n 2

n−1 p

n p

n−1

1 p

n−1 2

1 2

...

m 1

m−1 1

1 1

m 2

m−1 2

1 2

m q

m−1 q

m−1

1 q

Figure 4: CDG of a source and of a target name.

n−1 1

n 1 n 2

n−1 2

n−1

n−1 2*k

n−1 (w−1)*k+2

n (w−1)*k+2

n p

n−1 k

n k

n−1 k +1

n−1

n k +1

n k +2

n−1 k +2

n−1

n 2*k

n−1

n−1 p

n−1

n−1 (w−1)*k+1

n (w−1)*k+1

n−1

...

SN SN

1 1

1 2

1 k+1

1 (w−1)*k+2

1 p

1 (w−1)*k+1

1 k

1 1

1 k +2

1 2*k

1 1

...

Figure 5: Splitting of a concept name’s CDG.

4 TESTS AND EVALUATION

Two types of tests have been targeted: (1) the impact

of contextualization on linguistic matching and (2) the

comparison of INDIGO with the state of the art.

4.1 Impact of Contextualization

For this experiment, the Mapper was conﬁgured with

ﬁve name-based aligners, that is one for each of the

ﬁve well-known string metrics (i.e. Jaro-Winkler,

Smith-Waterman, Levenshtein, Needleman- Wunch

and Q-Gram) mentioned in section 2. Each aligner

was individually tested on the ﬁrst case study, i.e. the

mapping of the PetStore’s data source over eStore’s,

with and without contextualization being taken into

account. Table 1 describes the results obtained when

ﬁxing the enrichment threshold to K = 30 and the

context splitting parameter to w = 5. The two con-

stants λ and α were respectively set to 4 and 2. Re-

sults show that data sources contextualizing has a pos-

itive impact on the performance of name-based align-

ers. In the case of the QGram distance, the f-measure

of the alignment process increased by 127%.

4.2 Comparison with Other Semantic

Matching Systems

INDIGO was confronted with both the Similarity

Flooding algorithm and the V-Doc System. For this

experiment, the Mapper module was conﬁgured with

a single matching strategy, namely a sole aligner

based on the JaroWinkler metric. Each system was

executed over the two case studies thus computing:

(1) the mapping of the PetStore’s data source over eS-

tore’s and (2) the mapping of course data source of

Cornell university over the one of Washington uni-

versity. To be precise, two versions of the second

case study were experimented on: a version over re-

duced course data sources and the original one. Cor-

responding test results are summarized in Table 2. In

particular, the two last rows present the results ob-

tained with INDIGO for both (1) non context-based

and (2) context-based alignments.

In all alignment tests, INDIGO succeeded in im-

proving its performance thanks to contextual data

source enrichment. It did not globally surpass all the

other systems but managed to get very close to the

best one (i.e. SF) thanks to data source contextualiza-

tion. Indeed, INDIGO’s global performance was in-

creased by 14% with contextualization, what brought

it close to SF’s results by less than 1.8%. Finally, it

is worth noting that INDIGO did surpass all the other

systems in the PetStore/eStore case study thanks to

data source contextualization. This proves that IN-

DIGO’s context-based approach is particularly use-

ful for matching data sources that are very heteroge-

neous.

A CONTEXT-BASED APPROACH FOR LINGUISTIC MATCHING

201

Table 1: Performance variations due to data source contextualization observed in the mapping of PetStore’s data source over

eStore’s using INDIGO.

Non context-based Context-based Variation

prec. rec. f-m. prec. rec. f-m. prec. rec. f-m.

Jaro-Winkler 44.44 13.79 21.04 31.11 20.9 25 −30% +51% +19%

Smith-Waterman 34.78 18.39 24.05 39.62 24.14 30.00 +14% +31% +25%

Levenshtein 48.15 14.94 22.80 53.85 16.09 24.77 +16% +7% +10%

Needleman-Wunch 43.75 8.05 13.59 23.91 12.64 16.53 −45% +57% +22%

Q-Gram 66.67 9.20 16.17 60.53 26.44 36.80 −9% +187% +127%

Table 2: Comparison of INDIGO’s performance with Similarity Flooding and the V-Doc matching results.

PetStore/eStore mini-cornell/mini-washington cornell/washington average

prec. rec. f-m. prec. rec. f-m. prec. rec. f-m. prec. rec. f-m.

SF 41.66 14.92 21.97 1.0 79.41 88.52 60.0 72.22 65.54 34.22 55.51 58.67

V-Doc 66.66 2.98 5.71 65.62 61.76 63.63 17.36 46.29 25.25 49.88 37.01 31.53

Indigo(1) 44.44 13.79 21.04 83.87 78.79 81.85 34.51 73.58 46.99 54.27 55.38 49.96

Indigo(2) 31.11 20.9 25 84.38 81.82 83.08 58.06 67.92 62.61 57.85 56.88 56.9

5 CONCLUSIONS

This paper presents INDIGO, an innovative solution

to linguistic matching. INDIGO relies on an architec-

ture composed of two main modules: a Context An-

alyzer and a Mapper module. The Context Analyzer

enriches data sources with semantic information ex-

tracted from artifacts belonging to their respective en-

vironments before delivering them to the Mapper for

their effective alignment. Tests conducted over two

case studies proved that data source contextualizing

can improve the alignment process performance. In

particular, INDIGO was compared to two renowned

matching systems in the domain and outperformed

them in the case of data source candidates presenting

higher heterogeneity.

REFERENCES

A. Doan, P. D. andHalevy, A. (2003). Learning to match the

schemas of data sources : a multistrategy approach.

Journal of Machine Learning, 50(3):279–301.

Bououlid, I. and Vachon, J. (2005). Context analysis

for semantic mapping of data sources using a multi-

strategy machine learning approach. In Proc. of the In-

ternational Conf. on Enterprise Information Systems

(ICEIS05), pages 445–448, Miami.

Bououlid, I. and Vachon, J. (2007). A context-based ap-

proach for for complex semantic matching. In Proc.

of CAiSE-Forum, Trondheim, Norway.

B.T. Le, R. D.-K. and Gandon, F. (2004). On ontology

matching problems - for building a corporate seman-

tic web in a multi-communities organization. In Proc.

of the Int. Conf. on Enterprise Information Systems

(ICEIS), volume 4, pages 236–243.

Do, H. and Rahm, E. (2002). Coma: a system for ﬂexible

combination of schema matching approaches. In Pro-

ceedings of the 28th Conf. on Very Large Databases.

Euzenat, J. and et. al (2004). State of the art on ontology

alignment. part of a research project funded by the

ist program of the commission of the european com-

munities. Technical Report project number IST-2004-

507482, Knowledge Web Consortium.

Hu, W., Cheng, G., Zheng, D., Zhong, X., and Qu, Y.

(2006). The results of falcon-ao in the oaei 2006 cam-

paign. In International Workshop on Ontology Match-

ing.

J. Madhavan, P. B. and Rahm, E. (2001). Generic schema

matching using cupid. In In Proceedings of the 27th

VLDB Conference, pages 48–58, Roma, Italy.

K. Kotis, G. V. and Stergiou, K. (2004). Capturing seman-

tics towards automatic coordination of domain ontolo-

gies. In Artiﬁcial Intelligence: Methodology, Systems,

and Applications, volume 3192 of LNCS, pages 22–

32.

McUmber, R. (2003). Developing pet store using rup and

xde. Web Site.

Melnik, S., Garcia-Molina, H., and Rahm, H. (2002). Sim-

ilarity ﬂooding: a versatile graph matching algorithm

and its application to schema matching. In Proc. Inter-

national Conference on Data Engineering (ICDE’02),

pages 117–128.

Microsystems, S. (2005). Java petstore. Web Site.

Noy, N. and Musen, M. (2001). Anchor-prompt: Using

non-local context for semantic matching. In In Proc.

IJCAI 2001 workshop on ontology and information

sharing, pages 63–70, Seattle (WA US).

Y. Qu, W. H. and Cheng, G. (2006). Constructing virtual

documents for ontology matching. In Proceedings of

the 15th International World Wide Web Conference.

ICSOFT 2007 - International Conference on Software and Data Technologies

202
