BACKGROUND SUBTRACTION FOR REALTIME TRACKING OF A

TENNIS BALL

Jinzi Mao, David Mould and Sriram Subramanian

Department of Computer Science, University of Saskatchewan, Saskatoon, Canada

Keywords:

Motion tracking, background subtraction, real-time vision, tennis ball detection, tennis ball tracking.

Abstract:

In this paper we investigate real-time tracking of a tennis-ball using various image differencing techniques.

First, we considered a simple background subtraction method with subsequent ball veriﬁcation (BS). We then

implemented two variants of our initial background subtraction method. The ﬁrst is an image differencing

technique that considers the difference in ball position between the current and previous frames along with

a background model that uses a single Gaussian distribution for each pixel. The second is uses a mixture of

Gaussians to accurately model the background image. Each of these three techniques constitutes a complete

solution to the tennis ball tracking problem. In a detailed evaluation of the techniques in different lighting

conditions we found that the mixture of Gaussians model produces the best quality tracking. Our contribution

in this paper is the observation that simple background subtraction can outperform more sophisticated tech-

niques on difﬁcult problems, and we provide a detailed evaluation and comparison of the performance of our

techniques, including a breakdown of the sources of error.

1 INTRODUCTION

While ball tracking systems have been successful in

soccer (football) and baseball, ball tracking in ten-

nis matches is less well explored. Applications in-

cluding computer-assisted refereeing and computer-

assisted coaching could beneﬁt from real-time track-

ing of the tennis ball. However, ball tracking in a

tennis match poses particular challenges owing to the

ball’s small size, high speed, and large variation in tra-

jectories. Soccer balls are relatively large and move

relatively slowly, while baseballs are slightly larger

and (in a baseball pitch) have a much more highly

constrained trajectory.

Neither object-based techniques nor non-object-

based techniques are suitable for this application.

Such techniques have limited processing speed and

sometimes lack the ability to track objects which

move signiﬁcant distances between frames. In this

paper, we present an investigation of image process-

ing algorithms aimed at tennis ball tracking. We use

background subtraction as the ﬁrst step in the tracking

process; background subtraction generates a number

of regions representing changes in the image, all of

which are possible ball locations, or ball candidates.

We determine which ball candidates to report as ten-

nis balls based on size and shape analysis of the can-

didate regions. First, we present a basic algorithm

which uses an extremely simple, static background

model; the results from this were encouraging, so we

created two variant methods with different augmenta-

tions to the background model. The variants outper-

formed both the initial method and two existing al-

ternative methods, even in a context where the back-

ground varied considerably and background subtrac-

tion might be thought unsuitable.

Tennis ball tracking systems were reported by

Sudhir et al. (Sudhir et al., 1998) and by Pingali et

al. (Pingali et al., 2000); neither group of authors

made a systematic analysis of their systems’ perfor-

mance in a real-world environment. Also, they did

not address ball occlusion or player-ball interaction.

Our paper describes the results of our real-world de-

ployment and gives detailed data on error rates and

sources of error.

We present a framework for tennis ball tracking

427

Mao J., Mould D. and Subramanian S. (2007).

BACKGROUND SUBTRACTION FOR REALTIME TRACKING OF A TENNIS BALL.

In Proceedings of the Second International Conference on Computer Vision Theory and Applications - IU/MTSV, pages 427-434

 SciTePress

intended to satisfy two main requirements: speed and

robustness. First, the system needs to execute quickly,

in real time or close to it. Second, the system needs to

be robust to changes in the environment, to deal with

other moving objects, to track a fast-moving and er-

ratically moving object, to deal with occlusion, and to

track an object whose screen-space size varies signif-

icantly during a single test, owing to changes in dis-

tance to the camera (the ball ranged in apparent size

from 5 pixels to 60 pixels during our tests). As we

will see, we met some of these criteria, but not all;

nonetheless, the techniques we developed have con-

siderably better performance than existing techniques

that we compared against.

The paper is organized as follows. Section 2

discusses previous work, including existing methods

which we incorporate into our algorithm. Section 3

describes our algorithms. Section 4 describes our ex-

periments, analysis of the data, and evaluation of the

technique. Finally, we close in Section 5 with con-

cluding remarks and suggestions for future work.

2 PREVIOUS WORK

A number of object detection and tracking techniques

have been developed in the last two decades for track-

ing humans (Rano et al., 2004) and cars (Stauffer

and Grimson, 1999). More recently, researchers have

examined computer vision techniques for tracking

sporting events (Han et al., 2002; Assfalg et al., 2002;

Sudhir et al., 1998). Here we review the related liter-

ature on computer vision based object detection and

tracking techniques.

Viola et al. (Viola and Jones, 2001) introduced

classiﬁer cascades for object recognition. They

trained a set of weak classiﬁers on a set of very sim-

ple features, one classiﬁer per feature; the classiﬁers

are used in sequence to detect the presence of the tar-

get object, and since the weak classiﬁers are able to

reject most non-target objects quickly, the majority

of the computational effort is spent on difﬁcult cases.

Lienhart and Maydt (Lienhart and Maydt, 2002) ex-

tended this work by proposing a richer set of features

(Haar-like features, including edge, line, and center-

surround features) and showing a lower false positive

rate than was achieved by the simple feature set of

Viola et al (Viola and Jones, 2001).

Stauffer and Grimson (Stauffer and Grimson,

1999) proposed a background model in which each

pixel is a mixture of Gaussian distributions; pixels

which ﬁt into some existing distribution are consid-

ered background, while pixels which lie outside all

distributions are considered foreground. The method

allows the distributions to adapt to new samples, so

that only parts of the image which change faster than

a set learning rate are still considered foreground, and

portions which change more slowly are incorporated

into the background.

Ren et al. (Ren et al., 2004) devised K-ZONE,

a system for tracking baseball pitches. They used

a mixture of Gaussians for background discrimina-

tion; their method uses trajectory information to re-

ject some ball candidates. They report good results

for their context, but the trajectory of the baseballs

is considerably constrained compared to the variation

we can expect in a tennis match.

D’Orazi et al. (D’Orazio et al., 2002) propose

a system for tracking soccer balls using a modiﬁed

Hough transform. They use the parametric represen-

tation of a circle to transform the image and deter-

mine points which are on the soccer ball. They show

that the circular Hough transform is effective in de-

tecting the soccer ball. However, their algorithm re-

quires considerable processing to be viable as a real-

time ball tracking technique.

In (Sudhir et al., 1998) the authors perform an au-

tomatic analysis of tennis video to facilitate content-

based retrieval. They generate an image model for

the tennis court-lines based on the knowledge of the

dimensions and connectivity of a tennis court and typ-

ical geometry used when capturing a tennis video.

They use this model to track the tennis players over

a sequence of images.

In (Pingali et al., 2000) the authors use multiple

cameras to track the 3D trajectory of the ball using

stereo matching algorithms. A multi-thread approach

is taken to track the ball using motion, intensity and

shape. However, they do not give enough details of

their implementation to compare their approach with

ours.

Throughout this paper we use various image pro-

cessing techniques, including median ﬁltering and

shape feature extraction (Shapiro and Stockman,

2001). The median ﬁlter is used to reduce noise in

the image while shape features, including aspect ra-

tio, compactness, and roughness, are used to check if

a region’s properties resemble a ball or not.

3 ALGORITHMS AND INITIAL

RESULTS

Complex algorithms, such as boosted classiﬁers based

on Haar-like features, and circular Hough transforms

have been brought to bear on the problem of tennis

ball tracking. Many problems arise when they are ap-

plied to the tennis tracking system.

• The computation costs are too high. The pro-

cessing speed for these referred techniques can-

not guarantee high processing speed especially

when high-resolution, high frame-rate cameras

are used.

• The size of the tennis ball is quite small and the

feature space in such a small region is limited, so

can often be insufﬁcient to describe the target ob-

ject.

We believe a good strategy for the current prob-

lem would be to start with a simple algorithm and

enhance it by combining the beneﬁts of the tech-

niques described above. A simple algorithm based

on background modeling has several beneﬁts, includ-

ing high processing speed and low dependence on

training dataset. We were interested in seeing how

well a naive algorithm based on background model-

ing would perform.

3.1 Initial Approach

Our initial, naive algorithm works as follows. We

compute a simple background model by averaging

frames from a short video sequence of the vacant ten-

nis court. Then, the algorithm determines ball candi-

dates by ﬁnding regions whose intensity in the cur-

rent frame is larger than in the background frame.

Next, ball candidates in the vicinity of the player are

discarded. Shape and dynamics characteristics for

remaining candidates are computed, and those with

shape too far from the ball or which did not move like

the ball in previous frames are also discarded. Any re-

maining candidates are reported as being tennis balls.

We addressed the problem of ball-player interac-

tion by explicitly identifying the largest foreground

blob with the player. A player almost never appears

as a single foreground blob because of the dynam-

ics of the tennis game. Just before making a tennis

shot players often move their forearms, upper bod-

ies and feet, but rarely displace their hips. Thus a

player often appears as 2 or 3 adjacent blobs (upper-

body, legs, and forearm). We explicitly search for

blobs that are comparable in size and in the vicinity

of each other to identify them with the player (see

Figure 1). We then extend our search to identify the

player’s racquet if it is visible. The main features used

to connect the different blobs are blob size and adja-

cency. Once the player, the racquet, and the ball can-

didates in the vicinity of the player are discarded, the

remaining candidates are checked based on size (5 to

60 pixels) shape (compactness and roughness close to

0.9) and dynamics characteristics (candidates whose

distances to the predicted location exceeds a prede-

ﬁned threshold are removed) to discard false detec-

tions. Any remaining candidates are reported as be-

ing tennis balls. Note that this method allows us to

correctly report when multiple actual tennis balls are

present in the scene, as was sometimes the case (for

example, a ball from an earlier rally had not been re-

trieved and was lying on the court while the players

continued with a new ball).

Figure 1: Algorithmic player removal. First, the largest re-

gion plus nearby large regions are detected (top). Second,

the player region is expanded to include the racquet (bot-

tom).

We compared our method against two existing

methods: the technique of boosted classiﬁers (BC),

trained with Haar-like features; and the Hough trans-

form (HT) used to detect the tennis ball’s circular

shape.

The performance of our system is measured by

three ﬁgures: the true positive rate; the false posi-

tive rate; and the processing rate. True positive rate

is deﬁned as the ratio of the number of correctly rec-

ognized features to the number of appearances of the

feature. The false positive rate is the ratio of the

number of incorrect recognitions to the number of in-

stances where no feature was present. We measure

processing rate by frame rate, that is, the number of

images that can be processed in a second. A success-

ful system has a true positive rate as high as possible,

a false positive rate as low as possible, and a process-

ing rate as high as possible.

We recorded raw data consisting of thirty brief

videos of tennis games, each about 1 minute in length,

in an indoor setting. We captured images using a

monochrome camera at a resolution of 782 ×582 pix-

els at 25 fps. A sample frame is shown in Figure 2.

Figure 2: A sample frame from video taken on an indoor

tennis court.

For each frame of each video, we manually

marked the position of the tennis ball. This gave us

a ground truth against which we could compare the

output of the three algorithms. Then, we ran each

video through each of the BS, BC, and HT algorithms.

We computed true positive and false positive rates for

each algorithm on the entire corpus of data; a sum-

mary of the results appears in Table 1.

Table 1: Summary of comparison between naive back-

ground subtraction and existing methods.

BS BC HT

True positives 87.4% 30.1% 11.8%

False positives 1.35% 62.2% 73.4%

Processing rate 21.4 6.2 8.2

The data show that even with our naive approach

we were able to do better than standard algorithms

at the task of tracking the tennis ball. Our naive al-

gorithm has a higher recognition rate, a lower error

rate, and a faster frame rate than either of the com-

parison techniques. Also, it avoids a time-consuming

training period; it took upwards of a week to train the

boosted classiﬁers for the tennis context. The Hough

transform, while not requiring much setup, performed

extremely badly. The assumption that the tennis ball

has a circular shape is not satisﬁed in frames of the

video, owing to two main reasons. First, illumina-

tion can cause the tennis ball to have an apparently

crescent shape rather than a round shape. Second,

blurring because of rapid motion can cause the ball

to appear elongated in the direction of motion. Other

factors (such as noise, and deformation of the ball on

impact) can also play a role.

We were pleased with our results in the indoor

case, but wondered whether the good results were

primarily due to the largely static background in the

indoor environment. It might be that our naive ap-

proach would perform dramatically worse in cases of

more dynamic backgrounds, while the performance

of BC and HT would not suffer as much. Real tennis

matches have somewhat dynamic backgrounds, since

the crowd, the weather, and sometimes the advertise-

ments change during the match.

To determine whether this was the case, we

recorded another thirty videos in an outdoor environ-

ment. The weather on the day we did the recording

was extremely active, with trees in the background

swaying vigorously and clouds moving rapidly. The

cloud movement caused issues for two reasons: ﬁrst,

the clouds were sometimes visible as moving objects

in the scene; second, the clouds sometimes moved in

front of the sun or out from in front of it, causing rapid

changes in illumination. This highly dynamic back-

ground provides a good test case for automatic tennis

ball tracking, since real tennis match videos are un-

likely to have worse conditions. A sample frame from

the outdoor setting is shown in Figure 3.

Figure 3: A frame from the outdoor tennis court. Notice the

trees and clouds visible in the background.

Once the videos were recorded, we again per-

formed manual ball detection to arrive at a ground

truth and used each of the BS, BC, and HT algorithms

to perform ball detection. The results are summarized

in Table 2.

Table 2: Summary of comparison between naive back-

ground subtraction and existing methods in outdoor envi-

ronment.

BS BC HT

True positives 23.5% 27.2% 3.7%

False positives 56.4% 52.6% 77.5%

Processing rate 20.0 6.3 8.1

Not unexpectedly, the simple background subtrac-

tion algorithm did not cope well with the dynamic

background; its true positive rate dropped signiﬁ-

cantly, and its false positive rate rose enormously. The

method of boosted classiﬁers saw a slight reduction in

true positive rate but now performs better than simple

background subtraction. The Hough transform again

performed poorly.

3.2 Improved Background Model

Having conﬁrmed that background subtraction is a

good technique when we can reliably determine the

background, we decided to improve our background

model. The naive approach uses a static background

model obtained by averaging images of an empty ten-

nis court. We decided to use a Gaussian model for

each image pixel, inspired by the work of Stauffer and

Grimson.

We devised two variants of the naive method – im-

age differencing (ID) and mixture of Gaussians model

(MG). We discuss both below.

3.2.1 Image Differencing

Image differencing (ID) is a technique inspired by the

tennis ball tracking system of Pingali et al., who use

the difference between the current and previous frame

to determine ball candidates. The reasoning here is

that the tennis ball is usually fast-moving, and will

occupy an entirely different set of pixels in consec-

utive frames, while slower-moving objects will have

signiﬁcant overlap. However, Pingali et al.’s method

uses a complex mechanism for estimating ball inten-

sity levels, in order to cope with lighting, shadow, and

distance variations. We wanted to see whether we

could obtain good results combining image differenc-

ing with background subtraction.

In our ID technique, we model each background

pixel with a single Gaussian. That is, we compute

a mean µ and standard deviation σ for each pixel, us-

ing an initial set of background images; outliers (more

than two standard deviations from the mean) will be

considered foreground pixels.

The difference between the foreground of the pre-

vious frame and the foreground of the current frame

is used to obtain one set of ball candidates, say A. The

set of foreground pixels gives another set, say B. We

obtain a ﬁnal set of candidates C by taking the logical

AND of A and B. The candidates in C are subjected to

characteristics tests (compactness, aspect ratio, size)

and those that pass are reported as being tennis balls.

We report results of testing our ID technique in Sec-

tion 3.2.3.

For pixels not considered part of the ball, pa-

rameters of the Gaussian distribution are updated as

follows:

= (1− ρ)µ

t−1

+ ρX

(1)

= (1− ρ)σ

t−1

+ ρ(X

− µ

)

, (2)

where ρ is the learning rate for the parameters, and X

is the measured value for that pixel. This allows the

technique to adapt to changes in the background.

3.2.2 Mixture of Gaussian Models

In the mixture of Gaussians technique (MG), each

background pixel is modeled by a mixture of Gaus-

sians; pixels that cannot be explained by any of the

distributions are considered foreground objects (ball

candidates). Each Gaussian is characterized by a

weight w, a mean µ, and a standard deviation σ.

When creating the background model each pixel

is veriﬁed against the corresponding gaussian distri-

butions until a match is found or all distributions are

checked. A match is found when the pixel value is

within 2.5 standard deviation of the distribution.

If no match is found, a new Gaussian distribution

is added or the least probable distribution is updated

with the new pixel value as the mean, a high std., and

a low weight. If a match is found, the weights of the

existing distribution at time t are updated as follows:

k,t

= (1− α) ∗ w

k,t−1

+ α∗ M

k,t

(3)

where α is the learning rate for the weights, and M

k,t

is 1 for the distribution that matches and 0 otherwise.

Following this reassignment the weights are normal-

ized. The learning rate determines how fast the model

responds to changes in the environment; a higher

learning rate means changes to the environment will

be adapted to the existing background model more

quickly, while a low learning rate means that the ini-

tial background model will be slow to change.

The MG technique also updates the values for its

parameters, using the process described in equations 1

and 2. Once the parameters have been updated, the

Gaussians are ordered by the value of w/σ. The dis-

tribution with the higher weight w and smaller σ is

the more probable representation of the current back-

ground in that pixel location.

3.2.3 Comparison of Techniques

Both variants use the player-removal system we de-

signed for the naive algorithm.

We tested both the ID and MG approaches with

the videos we had already obtained. We will make

a comparison directly with the naive BS algorithm.

Table 3 shows a summary of the results for the indoor

case, and Table 4 summarizes the outdoor case.

Table 3: Summary of indoor results for our three methods.

BS ID MG

True positives 87.4% 89.6% 90.7%

False positives 1.35% 1.07% 1.02%

Processing rate 21.4 19.0 14.7

We see only a slight improvement in quality of re-

sults in the indoor case; this is not surprising, since

Table 4: Summary of outdoor results for our three methods.

BS ID MG

True positives 23.5% 35.6% 39.5%

False positives 56.4% 49.8% 26.5%

Processing rate 20.0 19.5 13.8

the nature of the indoor scene was such that the as-

sumption of static background held up well. Nonethe-

less, some improvement is observed: both ID and MG

have higher true positive rates than BS, and both have

a lower false positive rate. Both algorithms are doing

more sophisticated processing, and they have frame

rates lower than did BS, though still higher than the

BC and HT methods.

In the outdoor case, we see a larger difference.

The true positive rate rose considerably, nearly dou-

bling in the case of MG over BS. The false positive

rate dropped modestly for ID over BS, but dropped

off more dramatically for MG, falling to less than

half what the naive background subtraction had had.

Again, the frame rates are lower, representing the ef-

fect of the additional processing performed on each

frame.

4 EVALUATION

The main factor affecting the success of background

subtraction methods is the accuracy of the back-

ground model. Automated systems can make two

types of errors: false negative (the object is present,

but said to be missing) and false positive (the object is

absent, but a spurious detection happens). If we can

reduce the occurrences of false positives, we can be

more aggressive in what we consider acceptable, and

so reduce false negatives; alternatively, with a low rate

of false positives, we can perform interpolation on the

positives we obtain and have high conﬁdence that we

are not including spurious data points. We therefore

investigated the sources of false positives.

We manually examined the three videos which ex-

hibited the highest rates of false positive and tried to

characterize the types of errors that were made. Pos-

sible sources of error included (i) confusion with sim-

ilar objects; (ii) noise; and (iii) illumination changes,

especially shadows. Table 5 shows the results. The

overwhelming majority of errors arise from noise.

Because noise is the main factor causing false

positives, we are interested in seeing how many of

the ball candidates after background subtraction are

due to noise. We randomly selected two videos and

performed background subtraction using each of our

three methods; then, we looked at each frame after the

Table 5: Summary of sources of false positives.

Problem Occurrence

Similar objects 12%

Noise 83%

Shadows 4%

Other < 1%

background subtraction and manually counted how

many regions were generated by noise. The results

of this endeavor are reported in Table 6.

Table 6: Summary of number of noise regions.

Method Noise regions per frame

BS 16.3

ID 15.8

MG 15.4

The number of noise regions is highest for BS, and

lowest for MG: on average, MG had almost one can-

didate per frame less than BS. This has implications

both for speed (fewer candidates means less process-

ing, as fewer shape features need to be computed) and

for accuracy (since there is no chance of a false pos-

itive if a candidate is not presented). However, the

number of noise regions is still high. These results

suggest that there is still room for improvement in the

background subtraction phase.

We now report one ﬁnal evaluation. We are able to

achieve tennis ball tracking rates of around 90% with

fast and relatively simple algorithms. The question re-

mains: is 90% a good tracking rate, or can we reason-

ably expect to do better? To obtain data on which to

frame a response, we manually marked the positions

of the tennis ball on frames from 30 minutes of video

of a Wimbledon tennis match, about 32400 frames in

all. Our algorithms were not able to be applied to this

video, both because there is no background footage

available, and (more importantly) because we have as-

sumed a static camera. The Wimbledon video is com-

posed from multiple cameras that are controlled by

expert cameramen. The editor carefully selects video

sequences that provide high visibility for the ball to

create the ideal viewing conditions for the viewer. We

thus believe these videos give us best-case scenarios

for ball visibility. Despite the careful crafting of the

video, from the frames we looked at, the human eye

could determine the tennis ball’s location about 92%

of the time. The remaining 8% of the time, the ten-

nis ball is difﬁcult to locate. A sample frame from

the Wimbledon video appears in Figure 4; an exam-

ple of a frame in which the ball was present with poor

visibility is shown in Figure 5.

Of course, humans watching a tennis match can

Figure 4: Sample frames from the Wimbledon video. In

these frames, the ball is clearly visible.

achieve recognition rates higher than 90%.This is be-

cause they use additional cues to track the tennis ball.

They use trajectory information to predict the path of

the ball; this is likely the most important source of

information not used by our methods. Also, human

viewers can obtain secondary cues about the position

of the ball based on the reactions of the professional

tennis players, who are able to track the ball extremely

well. It is unlikely that such information will be used

by computer vision systems in the near future. Cues

of this type often enabled us to locate the ball in the

frames we labeled “poor visibility”, such as the ﬁrst

image in Figure 5, but it is not feasible even for the

human eye to locate the ball with high conﬁdence

from the single frame alone, despite all the context in-

formation and object recognition ability that humans

bring to the problem. We should comment also that

color information enhances the ball visibility in the

second image in Figure 5, but color information was

not available to our algorithms, owing to our use of a

high-speed monochrome camera.

Based on this experiment, we believe that our al-

gorithms are performing quite creditably. We were

able to achieve a recognition rate of 90% in the in-

door case, and while the human eye remains demon-

strably superior, we have gotten closer than previous

methods.

Figure 5: Examples of frames in which the ball is not clearly

visible. The red squares indicate the ball’s location.

5 CONCLUSIONS AND FUTURE

WORK

Our methods were able to achieve a true positive rate

of about 90%, with a false positive rate of only about

1%, in the indoor environment. This compares with

a true positive rate around 30% and a false positive

rate around 60% to 70% for the technique of boosted

classiﬁers and the Hough transform-based technique.

The outdoor case saw considerably more varia-

tion. Our techniques had between 20% and 40% true

positive and 25% to 60% false positive. Boosted clas-

siﬁers was able to achieve about 30% true positive and

50% false positive, while the Hough transform had

only about a 4% true positive rate and more than 75%

false positive rate. We attribute the poor performance

of all techniques to the rapidly changing background

caused by active weather.

One area for future work is to investigate deploy-

ment of the tracking system in conjunction with a

system that depends on knowing the location of the

tennis ball. Applications like robotic tennis-partner

and player training can beneﬁt from real-time track-

ing of the tennis ball. Our algorithm can be easily

deployed for real-time tennis applications by using 4

to 6 cameras watching different parts of the court. In-

stead of running 4 (or 6 depending on the number of

cameras) instances of the ball tracking algorithm we

would have 2 cameras monitoring the ground at any

given instance and when the ball leaves the ﬁeld-of-

view of one camera the next camera takes over the

tracking. To further improve the processing speed,

we can include various predictive tracking strategies

like Kalman ﬁltering.

We chose parameter settings (such as the aspect

ratio and expected size of the ball) manually for each

video. In the future, we would like to explore auto-

matic parameter settings, perhaps from a few sample

frames with the ball’s position marked manually. In

addition, we presently use static parameter settings

for an entire video; this worked well for the short

videos we tested with, but in future, we may want to

allow dynamic parameters so that very long video se-

quences will work.

We have not used much trajectory information in

discriminating among ball candidates, although tra-

jectory is critical to how humans perform ball track-

ing. Future systems will need to incorporate trajec-

tory information into their scene analysis.

Finally, both our image differencing technique

and our mixture of Gaussians technique gave some

improvement over simple background subtraction.

We can consider combining MG and ID in future.

ACKNOWLEDGEMENTS

Thanks go to the IMG lab and the HCI lab at the Uni-

versity of Saskatchewan.

This work was supported in part by NSERC RG-

PIN 299070-04.

REFERENCES

Assfalg, J., Bertini, M., Colombo, C., and Del, B. (2002).

Semantic annotation of sports video. Proceedings of

IEEE Transactions on Multi-Media, 9(2):52–60.

D’Orazio, T., Ancona, N., Cicirelli, G., and Nitti, M.

(2002). A ball detection algorithm for real soccer im-

age sequences. In ICPR ’02, International Conference

on Pattern Recognition. IEEE Computer Society.

Han, M., Hua, W., Xu, W., and Gong, Y. H. (2002). An

integrated baseball digest system using maximum en-

tropy method. In Proceedings of ACMM 2002, pages

347–350.

Lienhart, R. and Maydt, J. (2002). An extended set of haar-

like features for rapid object detection. In ICIP’02,

International Conference on Image Processing, pages

900 – 903.

Pingali, G., Opalach, A., and Jean, Y. (2000). Ball track-

ing and virtual replays for innovative tennis broad-

casts. In ICPR ’00, International Conference on Pat-

tern Recognition. IEEE.

Rano, I., Raducanu, B., and Subramanian, S. (2004). Hu-

man presence detection and tracking for a concierge

robot. In Proceedings of IFAC Symposium on Intelli-

gent Autonomous Vehicles 2004.

Ren, J., Orwell, J., Graeme, A., and Xu, M. (2004). A

general framework for 3d soccer ball estimation and

tracking. In ICIP ’04, International Conference on

Image Processing, pages 1935–1938.

Shapiro, L. and Stockman, G. (2001). Computer Vision.

Prentice-Hall, Upper Saddle River.

Stauffer, C. and Grimson, W. E. L. (1999). Adaptive

background mixture models for real-time tracking.

In CVPR’ 99, Computer Vision Pattern Recognition,

pages 246–252.

Sudhir, G., Lee, J., and Jain, A. K. (1998). Automatic clas-

siﬁcation of tennis video for high-level content-based

retrival. In CAIVD’98, International. Workshop on

Content-Based Access of Image and Video Databases,

pages 81–90.

Viola, P. and Jones, M. (2001). Rapid object detection using

a boosted cascade of simple features. In CVPR ’01, In-

ternational Conference on Computer Vision and Pat-

tern Recognition, pages 511–518.
