DOCUMENT IMAGE ZONE CLASSIFICATION

A Simple High-Performance Approach

Daniel Keysers, Faisal Shafait

German Research Center for Artiﬁcial Intelligence (DFKI) GmbH, Kaiserslautern, Germany

Thomas M. Breuel

Technical University of Kaiserslautern, Germany

Keywords:

Document Image Analysis, Zone Classiﬁcation.

Abstract:

We describe a simple, fast, and accurate system for document image zone classiﬁcation — an important sub-

problem of document image analysis — that results from a detailed analysis of different features. Using

a novel combination of known algorithms, we achieve a very competitive error rate of 1.46% (n = 13811)

in comparison to (Wang et al., 2006) who report an error rate of 1.55% (n = 24177) using more complicated

techniques. The experiments were performed on zones extracted from the widely used UW-III database, which

is representative of images of scanned journal pages and contains ground-truthed real-world data.

1 INTRODUCTION

One important subtask of document image processing

is the classiﬁcation of blocks detected by the physical

layout analysis system into one of a set of predeﬁned

classes. For example, we may want to distinguish be-

tween text blocks and drawings to pass the former to

an OCR system and the latter to an image enhancer.

For a detailed discussion of the task and its relevance

please see e.g. (Wang et al., 2006).

During the design of our block classiﬁcation sys-

tem we noticed that among the approaches we found

in the literature a detailed comparison of different fea-

tures was usually not performed, and in particular we

did not ﬁnd a comparison that included features as

they are typically used in other image classiﬁcation or

retrieval tasks. In this paper we address this shortcom-

ing by comparing a large set of commonly used fea-

tures for block classiﬁcation and include in the com-

parison three features that are known to yield good

performance in content-based image retrieval (CBIR)

and are applicable to binary images (Deselaers et al.,

2004). Interestingly, we found that the single feature

with the best performance is the Tamura texture his-

togram, which belongs to this latter class. Another re-

sult we transfer from experience in the area of CBIR

is that often a histogram is a more powerful feature

than using statistics of a distribution like mean and

variance only. We show that the use of histograms im-

proves the performance for block classiﬁcation signif-

icantly in our experiments. By combining a number

of different features, we achieve a very competitive

error rate of less than 1.5% on a data set of blocks ex-

tracted from the well-known University of Washing-

ton III (UW-III) database. In addition to the data used

in prior work we include a class of ‘speckles’ blocks

that often occur during photocopying and for which a

correct classiﬁcation can facilitate further processing

of a document image. Figure 1 shows example block

images for each of the eight types distinguished in our

approach. We also present a very fast (but at 2.1% er-

ror slightly less accurate) classiﬁer, using simple fea-

tures and only a fraction of a second to classify one

block on average on a standard PC.

2 RELATED WORK AND

CONTRIBUTION

We brieﬂy discuss some related work in this section,

for a more detailed overview of related work in the

ﬁeld of document zone classiﬁcation please refer to

(Okun et al., 1999; Wang et al., 2006). Table 1 shows

an overview of related results in zone classiﬁcation.

Inglis and Witten (Inglis and Witten, 1995)

Keysers D., Shafait F. and M. Breuel T. (2007).

DOCUMENT IMAGE ZONE CLASSIFICATION - A Simple High-Performance Approach.

In Proceedings of the Second International Conference on Computer Vision Theory and Applications - IU/MTSV, pages 44-51

 SciTePress

Table 1: Summary of UW zone classiﬁcation error rates from the literature along with the number of pages, zones and block

types used. Note that an exact comparison between all error rates is not possible.

reference # pages # zones # types error [%]

(Inglis and Witten, 1995) 1001 13831 3 6.7

(Liang et al., 1996) 979 13726 8 5.4

(Sivaramakrishnan et al., 1995) 979 13726 9 3.3

(Wang et al., 2000) 1600 24177 9 2.5

(Wang et al., 2006) 1600 24177 9 1.5

this work 713 13811 8 1.5

present a study of the zone classiﬁcation problem

as a machine learning problem. They use 13831

zones from the UW database and distinguish the three

classes text, halftone, and drawing. Using seven

features based on connected components and run

lengths, the authors apply various machine learning

techniques to the problem, of which the C4.5 decision

tree performs best at 6.7% error rate.

The review paper by Okun et al. (Okun et al.,

1999) succinctly summarizes the main approaches

used for document zone classiﬁcation in the 1990s.

The predominant feature type is based on connected

components (see also for example (Liang et al.,

1996)) and run-length statistics. Other features used

include the cross-correlation between scan-lines, ver-

tical projection proﬁles, wavelet coefﬁcients, learned

masks, and the black pixel distribution. The most

common classiﬁer used is a neural network.

The widespread use of features based on con-

nected components run-length statistics, combined

with the simplicity of implementation of such fea-

tures, led us to use these feature types in our exper-

iments as well, comparing them to the use of features

used in content-based image retrieval. Our CBIR fea-

tures are based on the open source image retrieval

system FIRE (Deselaers et al., 2004). We restrict

our analysis for zone classiﬁcation to those features

that are promising for the analysis of binary images

as described in the following section. (The overall

most successful features in CBIR are usually based

on color information.)

The most recent and detailed overview of the

progress in document zone classiﬁcation and a very

accurate system is presented in (Wang et al., 2006).

The authors use a decision tree classiﬁer and model

contextual dependencies for some zones. In our work

we do not model zone context, although it is likely

that a context model (which can be integrated in a

similar way as presented by Wang et al.) would help

the overall classiﬁcation performance. Wang et al.

use 24177 zones extracted from the UW-III database

to evaluate their approach. In our experiments we

use only 11804 labeled zones (plus 2007 additional

zones of type ‘speckles’) extracted from the UW-III

database because many zones occur in different ver-

sions in the database. In Section 5 we further illus-

trate this shortcoming and our approach to overcome

it. As the authors use 9-fold cross-validation to obtain

their results, it might be possible that the error rates

they present (the best result is an overall error rate of

1.5%) may be inﬂuenced positively by this fact, be-

cause it is likely that instances of blocks of the same

document occur in training and test set. In a simi-

lar direction, Wang et al. use one feature that “uses

a statistical method to classify glyphs and was exten-

sively trained on the UWCDROM-III document im-

age database.” It is not clear to us if this implies that

the glyphs that occur in testing have also been used in

the training of the glyph classiﬁer.

We expand on the work presented in (Wang et al.,

2006) in the following ways:

• We include a detailed feature comparison includ-

ing a comparison with commonly used CBIR fea-

tures. It turns out that the single best feature is

the Tamura texture histogram which was not pre-

viously used for zone classiﬁcation.

• We present results both for a simple nearest neigh-

bor classiﬁer and for a very fast linear classiﬁer

based on logistic regression and the maximum en-

tropy criterion.

• We introduce a new class of blocks containing

speckles that has not been labeled in the UW-III

database. This typical class of noise is important

to detect during the layout analysis especially for

images of photocopied documents.

• We present results for the part of the UW-III

database without using duplicates and achieve a

similar error rate of 1.5%.

• We introduce the use of histograms for the

measurements of connected components and run

lengths and show that this leads to a performance

increase.

VISAPP 2007 - International Conference on Computer Vision Theory and Applications

3 FEATURE EXTRACTION

We extract the following features from each block,

where features 1-3 are chosen based on their perfor-

mance in CBIR (Deselaers et al., 2004) feature 4 was

expected to help distinguish between the types ‘draw-

ing’ and ‘text’ and features 5-9 were chosen based on

their common use in block classiﬁcation (Okun et al.,

1999; Wang et al., 2006). Due to space limitations we

refer the interested reader to the references for imple-

mentation details.

1. Tamura texture features histogram (TTFH)

2. Relational invariant feature histograms (RIFH)

3. Down-scaled images of size 32 × 32 (DSI)

4. The ﬁll ratio, i.e. the ratio of the number of black

pixels in a horizontally smeared (Wong et al.,

1982) image to the area of the image (FR)

5. Run-length histograms of black and white pixels

along horizontal, vertical, main diagonal, and side

diagonal directions; each histogram uses eight

bins, spaced apart as powers of 2, i.e. counting

runs of length ≤ 1, 3, 7, 15, 31, 63, 127 and ≥ 128

(RL{B,W}{X,Y,M,S}H)

6. The vector formed by the total number, mean,

and variance of the runs of black and white pixels

along the horizontal, vertical, main diagonal, and

side diagonal directions as used in (Wang et al.,

2006) (RL{B,W}{X,Y,M,S}V)

7. Histograms (as in 5) of the widths and heights of

connected components (CCXH, CCYH)

8. The joint distribution of the widths and heights of

connected components as a 2-dimensional 64-bin

histogram (CCXYH)

9. The histogram of the distances between a con-

nected component and its nearest neighbor com-

ponent (CCNNH)

4 CLASSIFICATION

To evaluate the various features, we use a simple near-

est neighbor classiﬁer, that is, a test sample is clas-

siﬁed into the class the closest training sample be-

longs to. The distance measures used are the Jensen-

Shannon divergence for histograms and the Euclidean

distance for all other features (Deselaers et al., 2004).

If different feature sets are combined, the overall dis-

tance is calculated as the weighted sum of the indi-

vidual normalized distances. The weights are pro-

portional to the inverse of the error rate of a particu-

lar feature. No tuning with respect to these weights

or with respect to the distance measures has been

performed. Although a k-nearest-neighbor approach

gives better results in many cases we only evaluated

the 1-nearest-neighbor classiﬁer. The nearest neigh-

bor error rates are determined using leave-one-out

cross-validation.

The nearest neighbor classiﬁer serves as a good

baseline classiﬁer, although in many cases we can ﬁnd

a more suitable classiﬁer for a given task. As we con-

centrate on features in this paper, we did not test any

other classiﬁers. However, an important shortcoming

of the nearest neighbor classiﬁer is its requirement on

computational resources. Both memory and run-time

can be prohibitive for some applications. To explore

a very fast approach with minimum requirements on

computational resources, we also trained a log-linear

classiﬁer using the maximum entropy criterion (Key-

sers et al., 2002). The classiﬁcation using this clas-

siﬁer can be obtained by computing a dot product of

the feature vector with a weight vector for each class

and choosing the maximum, and is thus very fast.

As only these weight vectors need to be stored, the

memory requirement is also minimal. Furthermore,

the maximum entropy approach yields a probabilistic

model, such that we obtain an estimate of the poste-

rior probability for each class. The maximum entropy

approach was evaluated on a regular 50/50 split of the

data into training and test set and thus only uses half

the amount of training data. The histograms were not

normalized for the maximum-entropy approach, but

the absolute numbers were used instead to allow the

classiﬁer to utilize this additional information.

5 DATA SET

To evaluate our approach for document zone classiﬁ-

cation, we use the University of Washington III (UW-

III) database (Guyon et al., 1997). The database con-

sists of 1600 English document images with bound-

ing boxes of 24177 homogeneous page segments or

blocks, which are manually labeled into different

classes depending on their contents, making the data

very suitable for evaluating a block classiﬁcation sys-

tem, e.g. (Inglis and Witten, 1995; Wang et al., 2006).

The documents in the UW-III dataset are catego-

rized based on their degradation type as follows:

1. Direct scans of original English journals

2. Scans of ﬁrst generation English journal photo-

copies

3. Scans of second or later generation English jour-

nal photocopies

DOCUMENT IMAGE ZONE CLASSIFICATION - A Simple High-Performance Approach

Table 2: Leave-one-out nearest neighbor error rates and ex-

traction run-times for each feature and for combinations.

feature # features extr.-time [s] error [%]

TTFH 512 5.51 3.4

RIFH 512 12.59 7.8

DSI 1024 0.01 8.1

FR 1 0.02 27.3

RLBXH 8 0.01 7.9

RLWXH 8 0.01 5.1

RLBYH 8 0.01 8.2

RLWYH 8 0.01 5.6

RLBMH 8 0.01 11.8

RLWMH 8 0.01 6.6

RLBSH 8 0.01 10.5

RLWSH 8 0.01 6.2

RLBXV 3 0.01 12.9

RLWXV 3 0.01 9.7

RLBYV 3 0.01 14.6

RLWYV 3 0.01 12.1

RLBMV 3 0.01 17.2

RLWMV 3 0.01 12.6

RLBSV 3 0.01 16.7

RLWSV 3 0.01 12.2

CCXH 8 0.04 14.5

CCYH 8 0.04 14.9

CCXYH 64 0.04 6.2

CCNNH 8 0.05 19.0

RL**V, constant weight 4.1

RL**H, constant weight 1.8

RL*, CC*, 1/error weight 1.5

FR, RL*, CC*, 1/error weight 1.5

TTFH, FR, RL*, CC*, 1/error weight 1.5

RL*, CC*, logistic, 50/50 data split 2.1

show results for combined feature sets.

We can observe the following results:

• The Tamura texture feature is the single best fea-

ture but is more than 100 times slower to compute

than most other features.

• The use of histograms as descriptors of the run-

lengths distribution leads to much lower error

rates than the use of number, mean, and variance.

The combination of these histograms alone leads

to a very good error rate of 1.8%.

• Interestingly, the use of the white (background)

runs for the computation of features consistently

leads to better results than the use of black (fore-

ground) runs.

• Among the run-lengths based features, those

based on the horizontal runs lead to the best er-

ror rates.

• The ﬁll ratio as a single feature does not lead to

good results, which is not surprising as it consists

only of a single number. However, it is very use-

ful to distinguish drawings from text. This is how-

ever also achieved by using the distribution of the

white run lengths, such that the FR feature is not

part of the best observed feature set.

• By using a logistic classiﬁer trained with the max-

imum entropy criterion (training time a few min-

utes, time for one classiﬁcation in the order of a

few microseconds) on a feature set that is very

fast to extract, we can construct a zone type clas-

siﬁer that can classify more than ﬁve zones per

second even without performance tuning. At the

same time, the error rate is at 2.1% only slightly

higher than that of the best observed classiﬁer.

Table 3 shows the frequency of misclassiﬁcations

between different classes of the best classiﬁer. We can

observe that high recognition accuracy was achieved

for the text, ruling, speckles, math, halftone, and

drawing classes. However, our system failed to rec-

ognize logos correctly, and most of the logos were

misclassiﬁed as either text, or halftone/drawing. Note

that the accuracy rate for type ‘logo’ in (Wang et al.,

2006) is even lower at 0.0%. The reason for this ef-

fect is the very small number of samples for this class,

which on the other hand implies that it has only a very

small inﬂuence on the overall system error rate. Sim-

ilarly, the table detection accuracy was not high, and

about 21% of the tables were misclassiﬁed as text.

To visualize the errors made, we looked at the

nearest-neighbor images for each misclassiﬁed block.

Figure 3 shows some typical examples. It can be seen

that some of these images cannot be simply classiﬁed

correctly by using the block content alone, and even

humans are likely to make errors if they are asked to

classify these images.

7 CONCLUSION

From the analysis of the obtained results we can con-

clude that we can construct a very accurate classi-

ﬁer based on run-lengths histograms alone. These

features are very easy to implement and fast to ex-

tract and thus should be part of any practical baseline

system. Interestingly, the distribution of the back-

ground runs is more important for document zone

classiﬁcation than the distribution of the foreground

runs. Including a few more features based on run-

length and connected component measurements we

achieved a very competitive

error rate of below 1.5%

on zones extracted form the UW-III database without

For a comparison to our results also note that at most

0.2% (53/24177) of the error rate Wang et al. present is

DOCUMENT IMAGE ZONE CLASSIFICATION - A Simple High-Performance Approach

Table 3: Contingency table showing the distribution of the classiﬁcation of zones of a particular type in percent. (The total

number of errors equals 201 within 13811 tests.) The labels M, L, T, A, D, H, R, S correspond to the types math, logo, text,

table, drawing, halftone, ruling, and speckles, respectively.

M L T A D H R S error [%] # samples

M 90.8 0.0 8.6 0.0 0.0 0.6 0.0 0.0 9.2 476

L 9.1 27.3 36.4 0.0 9.1 9.1 0.0 9.1 72.7 11

T 0.1 0.0 99.8 0.0 0.0 0.0 0.0 0.0 0.2 10450

A 0.8 0.0 20.7 68.6 9.9 0.8 0.0 0.0 31.4 121

D 1.5 0.3 3.0 5.5 86.0 3.5 0.0 0.3 14.0 401

H 0.0 0.9 0.0 0.0 9.7 86.7 0.9 1.8 13.3 113

R 0.4 0.0 1.3 0.0 0.4 0.0 96.1 2.2 3.9 232

S 0.1 0.0 0.5 0.0 0.1 0.1 0.0 99.4 0.6 2007

the need for features based on glyphs or the Fourier

transform. By employing a fast logistic (log-linear)

classiﬁer trained using the maximum entropy crite-

rion on these features, we arrived at a fast and ac-

curate, yet easy to implement overall classiﬁer with

a slightly higher error rate of 2.1%. In our experi-

ments we did not use context information as done in

(Wang et al., 2006) and thus could keep the decision

rule very simple. However, context models are likely

to help in the overall classiﬁcation and an inclusion

of our approach into Wang et al.’s context model is

possible. Examining the errors made by the system

makes it seem likely that further improvements sig-

niﬁcantly below the reached error rate may be difﬁcult

to achieve without a signiﬁcantly increased effort, for

example by using a dedicated sub-classiﬁer to distin-

guish between text and table zones.

ACKNOWLEDGEMENTS

We wish to thank Oleg Nagaitsev for help with the im-

plementation and Thomas Deselaers for making avail-

able the open source image retrieval system FIRE,

which provided us with the implementation of some

of the features used. This work was partially funded

by the BMBF (German Federal Ministry of Education

and Research), project IPeT (01 IW D03).

REFERENCES

Deselaers, T., Keysers, D., and Ney, H. (2004). Features for

image retrieval: A quantitative comparison. In DAGM

2004, Pattern Recognition, 26th DAGM Symposium,

volume 3175 of Lecture Notes in Computer Science,

pages 228–236, T

ubingen, Germany.

caused by their distinction between the text classes of dif-

ferent font-sizes and the class ‘other’ with the remaining

classes. On the other hand, we add a new class ‘speckles’,

which is related to 0.15% (21/13811) error.

Guyon, I., Haralick, R. M., Hull, J. J., and Phillips, I. T.

(1997). Data sets for OCR and document image un-

derstanding research. In Bunke, H. and Wang, P.,

editors, Handbook of character recognition and doc-

ument image analysis, pages 779–799. World Scien-

tiﬁc, Singapore.

Inglis, S. and Witten, I. (1995). Document zone classiﬁca-

tion using machine learning. In Proc Digital Image

Computing: Techniques and Applications, pages 631–

636, Brisbane, Australia.

Keysers, D., Och, F.-J., and Ney, H. (2002). Maximum en-

tropy and Gaussian models for image object recogni-

tion. In Pattern Recognition, 24th DAGM Symposium,

volume 2449 of Lecture Notes in Computer Science,

pages 498–506, Z

urich, Switzerland. Springer.

Kise, K., Sato, A., and Iwata, M. (1998). Segmentation of

page images using the area Voronoi diagram. Com-

puter Vision and Image Understanding, 70(3):370–

382.

Liang, J., Phillips, I., Ha, J., and Haralick, R. (1996). Doc-

ument zone classiﬁcation using the sizes of connected

components. In Proc. SPIE, volume 2660, Document

Recognition III, pages 150–157, San Jose, CA.

Okun, O., Doermann, D., and Pietikainen, M. (1999). Page

Segmentation and Zone Classiﬁcation: The State of

the Art. Technical Report LAMP-TR-036, CAR-TR-

927, CS-TR-4079, University of Maryland, College

Park.

Sivaramakrishnan, R., Phillips, I. T., Ha, J., Su bramanium,

S., and Haralick, R. M. (1995). Zone classiﬁcation in

a document using the method of feature vector genera-

tion. In ICDAR ’95: Proceedings of the Third Interna-

tional Conference on Document Analysis and Recog-

nition (Volume 2), page 541ff.

Wang, Y., Haralick, R., and Phillips, I. (2000). Improve-

ment of zone content classiﬁcation by using back-

ground analysis. In Fourth IAPR International Work-

shop on Document Analysis Systems (DAS2000).

Wang, Y., Phillips, I. T., and Haralick, R. M. (2006). Doc-

ument zone content classiﬁcation and its performance

evaluation. Pattern Recognition, 39:57–73.

Wong, K. Y., Casey, R. G., and Wahl, F. M. (1982). Doc-

ument analysis system. IBM Journal of Research and

Development, 26(6):647–656.

VISAPP 2007 - International Conference on Computer Vision Theory and Applications
