FACE ANALYSIS FOR HUMAN COMPUTER INTERACTION

APPLICATIONS

Javier Ruiz-del-Solar, Rodrigo Verschae, Paul Vallejos and Mauricio Correa

Department of Electrical Engineering, Universidad de Chile, Santiago, Chile

Keywords: Human-Computer interaction through face analysis, boosting, nested cascade classifiers, face detection,

multiple target tracking.

Abstract: A face analysis system is presented and employed in the construction of human-computer interfaces. This

system is based on three modules (detection, tracking and classification) which are integrated and used to

detect, track and classify faces in dynamic environments. A face detector, an eye detector and face classifier

are built using a unified learning framework. The most interesting aspect of this learning framework is the

possibility of building accurate and robust classification/detection systems that have a high processing

speed. The tracking system is based on extended Kalman filters, and when used together with the face

detector, high detection rates with a very low false positive rate are obtained. The classification module is

used to classify the faces’ gender. The three modules are evaluated on standard databases and, compared to

state of the art systems, better or competitive results are obtained. The whole system is and the system is

implemented in AIBO robots.

1 INTRODUCTION

Face analysis plays an important role for building

human-computer interfaces that allow humans to

interact with computational systems in a natural

way. Face information is by far, the most used visual

cue employed by humans. There is evidence of

specialized processing units for face analysis in our

visual system. Faces allow us the localization and

identification of other humans, and the interaction

and visual communication with them. Therefore, if

we want that humans can interact with machines

with the same efficiency, diversity and complexity

used in the human-human interaction, then face

analysis should be extensively employed in the

construction of human-computer interfaces.

Currently, computational face analysis (face

recognition, face detection, eyes detection, face

tracking, facial expression detection, etc.) is a very

lively and expanding research field. The increasing

interest in this field is mainly driven by applications

related with surveillance and security. Among many

other applications we can mention video

conferencing, human-robot interaction, surveillance,

computer interfaces, video summarizing, image and

video indexing and retrieval, biometry, and drivers

monitoring.

Face detection is a key step in almost any

computational task related with the analysis of faces

in digital images. Moreover, in many different

situations face detection is the only way to detect

persons in a given scene. Knowing if there is a

person present on the image (or video) is an

important clue about the content of the image.

In the case of human computer interaction

applications, clues about the gender, age, race,

emotional state or identity of the persons give

important context information. When having this

kind of information, the application can be designed

to respond in a different way depending on who the

user is. For example, it can respond according to the

mood, gender or age of the user. Face recognition

systems can be improved by using other clues about

the face or by having specific models (for each

gender or rage). Obviously for this we require, first

to be able to detect the faces and to implement

accurate age, gender or race classification systems.

In this general context, the aim of this paper is to

propose a face analysis system, which can be used in

the construction of human-computer interaction

applications. The proposed face analysis system can

deal (detect, track and classify) faces in dynamic

Ruiz-del-Solar J., Verschae R., Vallejos P. and Correa M. (2007).

FACE ANALYSIS FOR HUMAN COMPUTER INTERACTION APPLICATIONS.

In Proceedings of the Second International Conference on Computer Vision Theory and Applications, pages 23-30

DOI: 10.5220/0002069400230030

 SciTePress

environments. It has been implemented on AIBO

robots and it performs with high accuracy as it will

be shown when evaluated on standard databases.

An essential requirement of this kind of system is

that it must be based in a highly robust and fast face

detector. Our face detector, eye detector and gender

classifier are built using a unified learning

framework based on nested cascades of boosted

classifiers (Verschae et al. 2006b; Verschae et al.

2006a). Key concepts used in the learning

framework are boosting (Schapire and Singer,

1999), nested cascade classifiers (Wu et al., 2004),

and bootstrap training (Sung and Poggio, 1998). The

tracking is implemented using extended Kalman

filters.

The article is structured as follows. In section 2

the learning framework that is used to train the

cascade classifiers is presented. In section 3 the face

detector is presented and some results of its

performance are outlined. In section 4 the tracking

system is described and evaluated. In section 5 the

implementation of the face analysis system on Aibo

robots is presented. Finally, some conclusions and

projections of this work are given in section 6.

2 LEARNING FRAMEWORK

Key concepts used in the learning framework are

boosting (Schapire and Singer, 1999), nested

cascade classifiers (Wu et al., 2004), and bootstrap

training (Sung and Poggio, 1998). A detailed

description of this framework is given in (Verschae

et al., 2006b).

Boosting is employed for finding (i) highly

accurate hypotheses (classification rules) by

combining several weak hypotheses (classifiers),

each one having a moderate accuracy, and (ii) self-

rated confidence values that estimate the reliability

of each prediction (classification).

Cascade classification uses several layers

(stages) of classifiers of increasing complexity (each

layer discards non-object patterns) for obtaining an

optimal system in terms of classification accuracy

and processing speed (Viola and Jones, 2001). This

is possible because of two reasons: (i) there is an

important difference in the a priori probability of

occurrence of the classes, i.e. there are much more

non-object than object patterns, and (ii) most of the

non-objects patterns are quite different from the

object patterns, therefore they can be easily

discarded by the different layers. Nested cascade

classification allows to obtain higher classification

accuracy by the integration of the different cascade

layers (Wu et al., 2004).

Other aspects employed in the proposed

framework for obtaining high-performance

classification systems are: using the bootstrap

procedure (Sung and Poggio, 1998) to correctly

define the classification boundary, LUTs (Look-Up

Tables) for a fast evaluation of the weak classifiers,

simple rectangular Haar-like features that can be

evaluated very fast using the integral image (Viola

and Jones, 2001), and LBP features (Fröba and

Ernst, 2004) that are invariant against changing

illumination.

2.1 Boosted Nested Cascade

A nested cascade of boosted classifiers is composed

by several integrated (nested) layers, each one

containing a boosted classifier. The whole cascade

works as a single classifier that integrates the

classifiers of every layer. A nested cascade,

composed of M layers, is defined as the union of M

boosted classifiers

each one defined by:

with

0)( =xH

and

the weak classifiers,

the

number of weak classifiers in layer k, and b

threshold value. It should be noted that a given

classifier corresponds to the nesting (combination)

of the previous classifiers. The output of

is a

real value that corresponds to the confidence of the

classifier and its computation makes use of the

already evaluated confidence value of the previous

layer of the cascade (see figure 1).

Figure 1: Block diagram of the boosted nested cascade

classifier.

bxhxHxH

−+=

∑

−

)()()(

(1)

VISAPP 2007 - International Conference on Computer Vision Theory and Applications

Figure 2: Block diagram of a face detection system.

Each weak classifier is applied over one feature

computed in every pattern to be processed. The

weak classifiers are designed after the domain-

partitioning weak hypotheses paradigm (Schapire

and Singer, 1999). Under this paradigm the weak

classifiers make their predictions based on a

partitioning of a feature domain F. A weak

classifier h will have an output for each partition

block, F

, of its associated feature f:

Fxfcxfh ∈∋= )())((

. Thus, the weak

classifiers prediction depends only on which block

a given sample (instance) falls into. For each

classifier, the value associated to each partition

block (c

), i.e. its output, is calculated for

minimizing a bound of the training error and at the

same time a bound on an exponential loss function

of the margin (Schapire and Singer, 1999). This

value is given by:

and

a regularization parameter (Schapire and

Singer, 1999).

A slightly modified version of the real

Adaboost learning algorithm (Verschae et al.

2006b) is employed for selecting the features and

training the weak classifiers taking into account the

nested configuration of the cascade.

3 DETECTION SYSTEM

In the following we briefly present the developed

face detection system. The block diagram of the

face detection systems is presented in figure 2.

First, for detecting faces at different scales a

multiresolution analysis is performed by scaling

the input image by a factor of 1.2 (Multiresolution

Analysis module). This scaling is performed until

images of about 24x24 pixels are obtained.

Afterwards, windows of 24x24 pixels are extracted

in the Window Extraction module for each of the

scaled versions of the input image. The extracted

windows can be then pre-processed for obtaining

invariance against changing illumination. Thanks

to the use of features which are invariant against

changing illumination to a large degree we do not

perform any kind of preprocessing.

Afterwards, the windows are analyzed by the

nested cascade classifier (Cascade Classification

Module) built with the framework described in

section 2. Finally, in the Overlapping Detection

Processing module, the windows classified as

faces are fused (normally a face will be detected at

different scales and positions) for obtaining the

size and position of the final detections. This

fusion is described in (Verschae and Ruiz-del-

Solar, 2003).

The eye detector works in the same was as the

face detector does, the only difference is that the

search is not done within the whole image, but

only within the face. As the face detector, the eye

detector woks on 24x24 windows, therefore it can

be used only on faces of 50x50 pixels or larger.

The gender classifier was built using the

learning framework as the eye and face detectors.

The gender classifier works on windows of 24x24

pixels and when the eye positions are available it

uses them for aligning the faces. In (Verschae et al.

2006a) we give a detailed description and

evaluation of the gender classifier.

⎟

⎠

⎞

⎜

⎝

⎛

−

(2)

1],)(Pr[ ±==∧∈= llyFxfW

(3)

FACE ANALYSIS FOR HUMAN COMPUTER INTERACTION APPLICATIONS

Table 1: Comparative evaluation (DR: Detection Rate) of the face detector on the BioID Database (1,521 images).

False Positives DB 0 1 2 3 6 15 17 25

Out Method UCHILE 87.8 88.0 94.8 98.5

Out Method FERET 98.7 99.5 99.7

Out Method BIOID 94.1 95.1 96.5 96.9 97.6 98.1

Fröba and Ernst 2004 BIOID ~50 ~65 ~84 ~98

Table 2: Comparative evaluation (DR) of the face detector on the CMU-MIT database (130 images, 507 faces). Notice that

in (Fröba et al. 2004) a subset of 483 (out of 507) faces is considered. This subset is called CMU 125 testset.

False Positives 0 3 5 6 10 13 14 19 25 29 31 57 65

Our Method 77.3 83.2 86.6 88 89.9 90.1 92.1

Fröba et al. 2004 ~66 ~87 ~90

Wu et al. 2004 89 90.1 90.7 94.5

Viola and Jones 2001 76.1 88.4 92

Rowley et al.1998 83.2 86

Schneiderman 2004 89.7 93.1 94.4

Li. et al. 2002 83.6 90.2

Delakis and Garcia 2004 88.8 90.5 91.5 92.3

For testing purposes we employed four databases

(BIOID, 2005), FERET (Phillips et al. 1998), CMU-

MIT (Rowley et al 1998), and (UCHFACE, 2006).

No single image from these databases was used for

the training of our systems. Selected examples of our

face detection, at work in the FERET, BIOID,

UCHFACE and MIT-CMU databases, are shown in

figure 3. The figures also show eyes detection and

gender classification.

The face detector was evaluated using two types

of databases: (a) BIOID and FERET, which contain

one face per image, and (b) CMU-MIT and

UCHFACE, which contain none, one or more faces

per image. Table 1 shows results of our method for

the FERET, BIOID and UCHILE databases as well

as the results for (Fröba and Ernst 2004) for the

BIOID database.

In the BIOID database, which contains faces

with variable expressions and cluttered backgrounds,

we obtain a high accuracy, a 94.1% detection rate

with zero false positives (in 1521 images), while on

the FERET database, which contains faces with

neutral expression and homogeneous background,

we obtain a very high accuracy, a 99.5% detection

rate with 1 false positive (in 1016 images). These

results were obtained without considering that there

is only one face per image.

In the UCHFACE database (343 images), which

contains faces with variable expressions and

cluttered backgrounds, we consider that the obtained

results are rather good (e.g. 88.0% with 3 false

positives, 98.5% with 17 false positives).

The table 2 shows comparative results with state

of the art methods fot the CMU-MIT database. In

the CMU-MIT database we also obtain good results

(e.g. 83.2% with 5 false positives and 88% with 19

false positives). If we compare to state of the art

methodologies in terms of DR and FP, we obtain

better results than (Viola and Jones, 2001; Rowley et

al, 1998), slightly better results than (Li et al, 2002),

slightly worse results than (Delakis and Garcia,

2004) (but our system is is about 8 times faster), and

worse results than (Wu et al. 2004) and

(Schneiderman, 2004). We think we have lower

detection rates than (Wu et al. 2004) and

(Schneiderman, 2004) mainly because of the size of

the training database. For example in (Wu et al.

2004) 20,000 training faces are employed while our

training database consists of 5,000 face images.

Notice that our classifier is among the fastest ones.

The ones that have a comparable processing time are

(Viola and Jones 2001), (Fröba et al. 2004), (Wu et

al. 2004) and (Li. et al. 2002).

The gender classifier performance was evaluated

in two cases: when the eyes were manually

annotated and when the eyes were automatically

detected. Table 3 shows results of this evaluation for

the UCHFACE. FERET and BIOID databases. It is

should be noticed that its behaviour is very robust to

changes in the eyes positions that are used for the

face alignment and that in two of the databases best

results are obtained when the eye detector is used.

VISAPP 2007 - International Conference on Computer Vision Theory and Applications

Table 3: Gender classification results: Percentage of

correct classification when eyes are annotated or detected.

Database Annotated eyes Detected eyes

UCHFACE 81.23 % 80.12%

FERET 85.56 % 85.89%

BIOID 80.91 % 81.46%

(a) (b)

Figure 3: Selected examples of our face detection, eyes

detection and gender classification systems at work on the

FERET (a), BIOID (b), UCHFACE (c) and MIT-CMU (d)

databases.

4 FACE TRACKING USING

KALMAN FILTERS

The tracking of the faces is based mainly on the use

of Extended Kalman Filters (EKFs). Although from

the theoretical point of view it can be argued that

Particle Filters (e.g. (Isard and Blake 1998) are

superior than EKF because of the Gaussianity

hypothesis (Dudek, and Jenkin, 2002), our

experience with self-localization algorithms for

mobile robotics (Lastra et al., 2004) tell us that the

performance of both kind of filters in tracking and

self-localization tasks is rather similar. Moreover, it

is possible to obtain a very fast implementation of

the EKF if the state vector is small, as in our case,

because for each tracked object a different EKF is

employed. This is very important when several

objects are tracked at the same time.

4.1 State Vectors and Parameters

Database

Each object (face) is characterized by its position in

pixels in the frame, its width, its height, and the

corresponding changing rates of these variables. The

eight variables are the state vector of a first order

EKF (

). The parameters database (DB) stores the

latest state vector (

1−k

) for each object under

tracking and its associated EKF. Since the detected

features do not include the change rate components,

these components are estimated as:

= z

−x

k−1

Δt

−x

k−1

Δt

−x

k−1

Δt

−x

k−1

Δt

⎛

⎝

⎜

⎞

⎠

⎟

(4)

With

the vector of observations. The update

model is:

0..0

10..:

010

0010

00010..0

−

⎟

⎠

⎞

⎜

⎝

⎛

⎟

⎠

⎞

⎜

⎝

⎛

−=

Δt xIx

(5)

4.2 Tracking Procedure

The block diagram of the multiple face detection and

tracking system is shown in figure 4. Input images

are analyzed in the Face Detector module, and

detected faces are further processed by the Detected-

Tracked Object Matching module. In this module

the detected faces are matched with the current

objects under tracking. Each new detection (a face

window) is evaluated in the Gaussian function

described by the state vector and its covariance

matrix on the Kalman filter of each object. In this

way, a matching probability is calculated. If the

matching probability is over a certain threshold, the

detected face is associated with the corresponding

object. If no object produces a probability value over

that threshold, then the detected face is a new

candidate object, and a new state vector (and

Kalman filter) is created for this new object (New

Object Generator module).

FACE ANALYSIS FOR HUMAN COMPUTER INTERACTION APPLICATIONS

Table 4: Face detection results on the sets A and B from

PETS-ICVS 2003.

Set A Detection Rate [%] 67,9 62,1 50,8 44,9 36,2

# False Positives 851 465 334 292 242

Set B Detection Rate [%] 67,2 60,9 53,5 44,7 37,9

# False Positives 88 50 37 32 22

Table 5: Face detection results, after tracking, on set A

from PETS-ICVS 2003.

Tracking

Parameters

MCF MCF

False

Positive

Detection

Rate [%]

False

Positive

Decremen

Detection

Rate

Increment

3 5 2.0 525 65,19 35,0% 10,7%

3 7 2.0 530 65,23 34,4% 11,0%

2 2 2.0 536 65,71 33,7% 11,8%

2 5 2.0 580 66,76 28,2% 13,6%

2 7 2.0 580 66,76 28,2% 13,6%

3 5 1.0 625 68,51 22,6% 16,5%

3 7 1.0 655 68,96 18,9% 17,3%

2 2 1.0 629 68,74 22,2% 16,9%

1 2 2.0 683 68,31 15,5% 16,2%

1 5 2.0 700 68,59 13,4% 16,7%

1 7 2.0 700 68,59 13,4% 16,7%

2 5 1.0 738 70,10 8,7% 19,2%

2 7 1.0 750 70,23 7,2% 19,5%

Table 6: Face detection results, after tracking, on set B

from PETS-ICVS 2003.

Tracking

Parameters

CTO MCF Q

False

Positive

Detection

Rate[%]

False

Positive

Decrement

Detection

Rate

Increment

3 5 1.0 69 68,9 21,6% 2,5%

3 7 1.0 71 68,9 19,3% 2,5%

2 2 1.0 71 689 19,3% 2,5%

1 2 2.0 72 68,0 18,2% 1,2%

1 5 2.0 76 68,1 13,6% 1,3%

1 7 2.0 76 68,1 13,6% 1,3%

2 5 1.0 80 69,8 9,1% 3,9%

2 7 1.0 80 69,9 9,1% 4,0%

3 5 0.5 85 70,7 3,4% 5,2%

2 2 0.5 87 70,6 1,1% 5,1%

3 7 0.5 88 70,7 0,0% 5,2%

For each object under tracking, the prediction

model estimates its a priori state (Object State

Prediction module). Then, the a priori state is

updated using all the detections associated with this

state in the matching stage (Object Update module).

If any candidate object accomplish the promote

rule (over a certain amount of detections in a

maximal amount of frames) then it becomes a true

object (Candidate Promoter module). Finally, if a

candidate object has more than a certain amount of

frames with not enough associated detections (below

a certain threshold), it is eliminated from the

database (Object Filter module). True objects with

state probability below a certain threshold are also

eliminated from the database.

4.3 Multiple Detection and Tracking in

Dynamic Environments

We have integrated the face detection and tracking

system, building a system for the tracking of

multiple faces in dynamic environments. As it will

be shown, this system is able to detect and track

faces with a high performance in real-world videos,

and with an extremely low number of false positives

compared to state of the art methodologies.

In order to test performance of our multiple face

detection and tracking system we employed the

PETS-ICVS 2003 dataset. The PETS initiative

corresponds to a very successful series of workshops

on Performance Evaluation of Tracking and

Surveillance. The PETS 2003 topic was gesture and

action recognition, more specifically the annotation

of a "smart meeting" (includes facial expressions,

gaze and gesture/action). The PETS-ICVS 2003

dataset (PETS, 2003) consists of video sequences

(frame from 640x480 pixels) captured by three

cameras on a conference room. Two cameras

(camera 1 and 2) were placed on opposite walls

capturing the participant on each side of the room,

and the third camera (camera 3) is an

omnidirectional camera on the desk center. The

dataset is divided in four scenarios A, B, C and D.

For this analysis frames from scenarios A, B, and D,

and cameras 1 and 2, were used. The ground truth

consists of the eyes coordinates for those frames

divisible by 10. In our experiments all frames were

processed, but for statistics just two sets of images

were considered: (i) Set A: all annotated frames, i.e.

frames with frame number divisible by 10, and (ii)

Set B: frames with frame number divisible by 100.

The set A contains 49,350 frames and 10,308

annotated faces, while the set B contains 4,950

frames and 1,000 annotated faces.

In table 4 are shown the detection results

obtained by our face detector (without the tracking)

on both sets. These results are much better than the

ones reported in (Cristinacce and Cootes, 2003),

where the Fröba-Kullbeck detector (Fröba and

Küblbeck, 2002) and the Viola&Jones detector

(Viola and Jones, 2001) were tested on the set B. In

that test the Viola&Jones detector outperforms the

Fröba-Kullbeck, but the results it obtains are very

poor, 50% DR with 202 false positives or 62.2% DR

VISAPP 2007 - International Conference on Computer Vision Theory and Applications

with 2,287 false positives. We can conclude that our

face detector performs very well in this real-world

dataset (4,950 frames), and that the amount of FP is

extremely low.

We analyzed the performance of our tracking

system and we quantify the improvement in the face

detection process when using such a system. We

have analyzed the behavior of three different

parameters of the tracking system:

• CTO (Candidate to true object) threshold:

A new detection is immediately added to

the database in order to track it, but it is not

considered as a true tracked object until

CTO other detections are associated with it.

• MCF (Max candidate frames): If a

candidate to object does not reach the CTO

threshold in MCF frames since it was added

to the database, it is eliminated.

• Q: This is the covariance of the process

noise in the Kalman filter.

In table 5 and 6 are shown the detection results after

applying the tracking system on sets A and B. It can

be seen that thanks to the tracking, the number of FP

decreases largely, up to 21% in set B and 35% in set

A, and that at the same time the DR increases.

5 PERSON DETECTION AND

TRACKING FOR AIBO

ROBOTS

Sony AIBO robots correspond to one of most

widespread and popular personal robots. Thousands

of children and researchers employ AIBO robots for

entertainment or research. We believe that in a near

future personal robots will be far more widespread

than today. One of the basic skills that personal

robots should integrate is the face-based visual

interaction with humans. Robust face analysis is a

key step in this direction. For implementing such a

system we adapted the face analysis system already

described for Sony AIBO robots model ERS7.

ERS7 robots have a 64bit RISC Processor (MIPS

R7000) from 576 MHz, 64MB RAM and a color

camera of 416x320 pixels that delivers 30fps. The

face and tracking detection system was integrated

with our robot control libraryU-Chile1 (Lastra et al

2004)(Ruiz-del-Solar et al, 2005b). U-Chile1 is

divided in five task-oriented modules: Vision, which

contains mostly low-level vision algorithms,

Localization, in charge of the robot self-localization,

Low-level Strategy, in charge of the behavior-based

control of the robots, High-level Strategy, in charge

of the high level robot behavior and strategy, and

Motion Control, in charge of the control of the robot

movements. U-Chile1 runs in real-time and after the

integration with the tracking system we were able of

running our face detection and tracking system at a

rate of 2fps. We included also eyes detection and

gender classification. In figure 5 are shown some

selected examples of face detection and tracking

using an AIBO ERS7. The system detects faces,

gender classification and eyes detection. More

examples can be seen in (UCHFACE, 2005).

6 CONCLUSIONS

Face analysis plays an important role for building

human-computer interfaces that allow humans to

interact with computational systems in a natural

way. Face information is by far, the most used visual

cue employed by humans. In this context in the

present article we have proposed face analysis

system that can be used to detect, track and classify

(gender) faces. The proposed system can be used in

the construction of different human-computer

interfaces.

The system is based on a face detector with high

accuracy, a high detection rate with a low number of

false positives. This face detector obtains the best-

reported results in the BioID database, the best

reported results in the PETS-ICVS 2003 dataset, and

the third best reported results in the CMU-MIT

database.

The face detector was integrated with a tracking

system for building a system for the tracking of

multiple faces in dynamic environments. This

system is able to detect and track faces with a high

performance in real-world videos, and with an

extremely low number of false positives compared

to state of the art methodologies. We also integrated

our face analysis and tracking system into the Sony

AIBO robots. In this way the AIBO robots can

interact with persons using the human faces and the

gender and eye information.

Beside the already mentioned projects, we are

currently applying our face analysis system for

developing a service robot that interacts with

humans using face information and on a retrieval

tool for searching persons on image and video

databases.

FACE ANALYSIS FOR HUMAN COMPUTER INTERACTION APPLICATIONS

ACKNOWLEDGEMENTS

This research was funded by Millenium Nucleus

Center for Web Research, Grant P04-067-F, Chile.

Portions of the research in this paper use the FERET

database of facial images collected under the FERET

program.

REFERENCES

BioID, 2005.Face Database. Available on August 2005 in:

http://www.bioid.com/downloads/facedb/index.php

Cristinacce, D. and Cootes, T., 2003. “A Comparison of

two Real-Time Face Detection Methods”, 4th IEEE

Int. Workshop on Performance Evaluation of Tracking

and Surveillance – PETS 2003, pp. 1-8, Graz, Austria.

Fröba, B. and Küblbeck, Ch., 2002. Robust face detection

at video frame rate based on edge orientation features.

5th Int. Conf. on Automatic Face and Gesture

Recognition FG - 2002, pp. 342–347.

Fröba, B. and Ernst, A., 2004. “Face detection with the

modified census transform”, 6th Int. Conf. on Face

and Gesture Recognition - FG 2004, pp. 91–96, Korea.

Delakis, M. and Garcia, C., 2004. “Convolutional face

finder: A neural architecture for fast and robust face

detection”, IEEE Trans. Pattern Anal. Mach. Intell.,

26(11):1408 – 1423.

Dudek, G., and Jenkin, M., 2002. Computational

Principles of Mobile Robotics, Cambridge University

Press.

Isard, M., and Blake, A., 1998. “Condensation –

Conditional Density Propagation for Visual Tracking”,

Int. J. of Computer Vision, Vol. 29, N. 1, pp. 5—28.

Lastra, R., Vallejos, P., and J. Ruiz-del-Solar, 2004.

“Integrated Self-Localization and Ball Tracking in the

Four-Legged Robot Soccer League”, 1st IEEE Latin

American Robotics Symposium – LARS 2004, pp. 54

– 59, Oct. 28 – 29, México City, México.

Li, S.Z., Zhu, L., Zhang, Z.Q., Blake, A., Zhang, H.J. and

Shum, H., 2002. “Statistical Learning of Multi-view

Face Detection”, 7th European Conf. on Computer

Vision – ECCV 2002, (Lecture Notes in Computer

Science; Vol. 2353), pp. 67 – 81.

PETS, 2003. Home Page. Available on August 2005 in:

http://www.cvg.cs.rdg.ac.uk/PETS-ICVS/pets-icvs-

db.html

Phillips, P. J., Wechsler, H., Huang, J.and Rauss, P., 1998.

“The FERET database and evaluation procedure for

face recognition algorithms,” Image and Vision

Computing J., Vol. 16, no. 5, pp. 295-306.

Rowley, H., Baluja, S. and Kanade, T., 1998. “Neural

Network-Based Detection”, IEEE Trans. Pattern Anal.

Mach. Intell., Vol.20, No. 1, 23-28.

Ruiz-del-Solar, J., Vallejos, P., Lastra, R., Loncomilla, P.,

Zagal, J.C., Morán, C., and Sarmiento, I., 2005b.

“UChile1 2005 Team Description Paper”, RoboCup

2005 Symposium, July 13 – 17, Osaka, Japan.

Schapire, R.E. and Singer, Y., 1999. Improved Boosting

Algorithms using Confidence-rated Predictions,

Machine Learning, 37(3):297-336.

Schneiderman, H., 2004. Feature-Centric Evaluation for

Efficient Cascade Object Detection, IEEE Conference

of Computer Vision and Pattern Recognition – CVPR

2004, pp. 29 - 36.

Sung, K. and Poggio, T., 1998. “Example-Based Learning

for Viewed-Based Human Face Deteccion”, IEEE

Trans. Pattern Anal. Mach. Intell., Vol.20, N. 1, 39-51.

UCHFACE, 2005. Computational Vision Group,

Universidad de Chile. Available on August 2005 in:

http://vision.die.uchile.cl/

Verschae, R. and Ruiz-del-Solar, J., 2003. “A Hybrid Face

Detector based on an Asymmetrical Adaboost Cascade

Detector and a Wavelet-Bayesian-Detector”, Lecture

Notes in Computer Science 2686 (IWANN 2003),

Springer, pp. 742-749, Menorca, Spain.

Verschae, R., Ruiz-del-Solar, J., Correa, M., 2006a.

Gender Classification of Faces Using Adaboost, In

Proc of CIARP, LNCS 4225.

Verschae, R., Ruiz-del-Solar, J., Correa, M. and Vallejos,

P. 2006b. A Unified Learning Framework for Face,

Eyes and Gender Detection using Nested Cascades of

Boosted Classifiers, Tech.Report UCH-DIE-VISION-

2006-02, Dept. of Elect. Eng., Universidad de Chile.

Viola, P. and Jones, M., 2001. "Rapid object detection

using a boosted cascade of simple features", IEEE

Conf. on Computer Vision and Pattern Recognition -

CVPR, Kauai, HI, USA, 2001, pp. 511 - 518.

Wu, B., AI, H. , Huang, C. and Lao, S., 2004. “Fast

rotation invariant multi-view face detection based on

real Adaboost”, 6th Int. Conf. on Face and Gesture

Recognition - FG 2004, pp. 79–84, Seoul, Korea.

Figure 5: Examples of the face detection and tracking

system for AIBO robots. The system detect faces and

performs gender classification. When the resolution of the

faces is larger than 50x50 pixels it detects also the eyes.

VISAPP 2007 - International Conference on Computer Vision Theory and Applications
