SECURING HEALTHGRID ENVIRONMENTS

Christos Ilioudis, Dimitrios Baltatzis, George Pangalos

Informatics Laboratory, Computers Division, Faculty of Technology, Aristotle University of Thessaloniki

54006, Thessaloniki, Greece

Christos Georgiadis

Department of Applied Informatics, University of Macedonia, 156 Egnatia Street

GR-540 06, Thessaloniki, Greece

Keywords: Authorizations, HealthGrid environment, Mobile agent systems, RBAC.

Abstract: Grid technologies promise to change the way that health organizations tackle complex problems by offering

unprecedented opportunities for resource sharing and collaboration. Healthgrids are Grid infrastructures

comprising applications, services or middleware components that deal with the specific problems arising in

the processing of biomedical data. Resources in Healthgrids are databases, computing power, medical

expertise and even medical devices. Securing this new environment in Health organizations is a major issue

today. Security considerations and more specifically authorization decisions is a critical problem. Personal

data is confidential, so access to the information must be restricted to authorized and authenticated persons.

Furthermore data must be protected to guarantee its confidentiality and integrity. This work provides a

suitable authorization mechanism that facilitates the usage of grid and agent technology in HealthGrid

environments. More specifically, our approach applies the RBAC access control model for dynamically

assigning security roles to visiting agents on hosts of the HealthGrid environment. Our methodology

proposes a flexible role decomposition method, which facilitates the role assignment process. The role

decomposition relies on a set of common Attribute Fields, shared between Grid’s hosts, filled with Attribute

values that every host evaluates according to its security goals. In any case, every host participating in the

grid retains its security policy without altering or compromising its security policy in order to participate in

the agent exchange process. The proposed process and the related assignment algorithms have been

experimentally implemented and applied in a typical health environment. The results have shown that the

proposed framework is applicable and implementable, and can be applied successfully in real life health

care environments.

1 INTRODUCTION

Healthgrids represent an innovative use of emerging

information technology to support broad access to

rapid, cost-effective and high quality healthcare.

Grid computing aims at the provision of a global

Information and Communication Technology

infrastructure that will enable a coordinated,

flexible, and secure sharing of diverse resources,

including computers, applications, data, storage,

networks, and scientific instruments across dynamic

and geographically dispersed organizations and

communities (Virtual Organizations). Goals of

HealthGrid infrastructures can be to provide

researchers with a broad spectrum of data for

analysis and to make it possible for patients to gain

access to their data regardless where they are and

where it is stored.

HealthGrid systems evolved as an important new

field, distinguished from conventional distributed

health systems in the sense that they involve large-

scale resource sharing guided by innovative

applications. Grids provide the necessary

infrastructure by which participant organizations

across widely distributed systems form and operate

for resource sharing (

Scott et all, 2004). The

infrastructure provides an efficient utilization of

existing resources by combining heterogeneous and

widely distributed computational resources into a

consistent environment. The central idea is that

394

Ilioudis C., Baltatzis D., Pangalos G. and Georgiadis C. (2007).

SECURING HEALTHGRID ENVIRONMENTS.

In Proceedings of the Second International Conference on Security and Cryptography, pages 394-401

DOI: 10.5220/0002123203940401

 SciTePress

computing and information sharing should be

reliable, pervasive and transparent for widely

distributed systems. Securing such Grid

infrastructures requires therefore suitable security

models and mechanisms.

In contrast, agent technology focuses on the

development of concepts, methodologies and

algorithms for autonomous problem solving engaged

in uncertain and dynamic environments in order to

achieve their objectives (Jennings 2001). Agents are

actually software entities that can move code, data

and state to remote hosts. An agent has the ability to

migrate from one host another in order to fulfil its

task. Their late ability to move computations across

the nodes of a widely distributed network makes

them an attractive paradigm, compared to the

traditional client-server paradigm. It can be said

however that the two technologies attend to service a

common environment that is, communities of large

distributed systems bound together by a common

goal or cause. They also face overlapping problems

as Grids seek to become more flexible and agile

while agent systems seek to become more reliable

and scalable. Various researchers have already

observed this. As noted for example by Foster et al

"For Grids to be effective in their goals, they must

be imbued with flexible, decentralized decision

making capabilities while agents need a robust

distributed computing platform that allows them to

discover, acquire, federate and manage the

capabilities necessary to execute their decisions"

(Foster et al, 2004).

It is clear that in medical data processing privacy

protection needs to be enforced much more

rigorously than in other application areas. The users

of such systems (patients, medical staff, etc.) are not

usually trained in computer security and thus need

easy to use and mostly transparent services.

Securing HealthGrid infrastructures therefore

requires suitable security models and mechanisms

with those characteristics, in order to support

authentication, data integrity, private

communications and access control.

This paper discusses the overall security problem

of HealthGrids and focuses on an authorization

policy for HealthGrid participant organizations,

which utilizes the advantages offered by both the

grid and the agent systems technology. We propose

a dynamic role assignment mechanism for Grid

participants and more specifically we describe an

authorization mechanism, which facilitates the use

of shared resources in such dynamic environments.

Every participant organization in the Grid preserves

and maintains its own local security policy, while

users active in the Grid retain the ability to access

common resources by acquiring local roles for

authorization. The proposed approach takes into

account and exploits the dynamic characteristics of

Grid systems and the flexibility of Role Based

Access Control Policies (Ferraiolo et al, 2001). In

our approach Grid participants that own resources

can specify the authorization policy using a well

defined access control language like the eXtensible

Access Control Markup Language (XACML)

(OASIS 2003) and the Security Assertion Markup

Language (SAML 2003). Grid users can also specify

their identity and security constraints in the same

manner.

2 THE SECURITY PROBLEM OF

HEALTHGRID INFORMATION

SYSTEMS

As already noted, security is an essential

consideration when accessing the shared resources

of a HealthGrid system. The main security

requirements for Grid systems that influence the

definition of the HealthGrid security requirements

are related to the following characteristics of a Grid

(Welch et al, 2003), (

Simpson et al, 2006).

2.1 Access Control Requirements

The different resources in a grid may have different

access policies, including how they authenticate and

authorize users. However, if there are no common or

overlapping authorizations among the resources,

they do not form a usable Grid. Grid service requests

can span multiple security domains. Trust

relationships among these domains play an

important role in the outcome of such end-to-end

traversals. A service needs to make its access

requirements available to interested client entities, so

that they understand how to securely request access

to it. Trust between end points can be presumed,

based on topological assumptions, or explicit,

specified as policies are enforced through the

exchange of some trust-forming credentials. In a

Grid environment, presumed trust is rarely feasible

due to the dynamic and distributed nature of inter

organizational relationships. Furthermore, trust

establishment may be a one-time activity per session

or it may be evaluated dynamically on every request.

The dynamic nature of the Grid can in some cases

make it impossible to establish trust relationships

among sites prior to application execution.

SECURING HEALTHGRID ENVIRONMENTS

395

2.2 Authorization Requirements

Authorization has several meanings in a Grid

environment. For example: the process of issuing a

proof of right, the proof of right itself (or reference

to it), the process of determining an authorization

decision by associating user attributes against access

control policies, etc. Our interest focuses mainly on

the third case because authorization is a key problem

associated with the efficient function of the Grid

environment, as authentication solely cannot

effectively determine user rights.

Let us consider a situation where a multi

organizational Grid shares resources. With current

approaches, every change in any of the

organizations’ personnel requires the determination

of new or changed user rights. This interaction

places barriers and administrative overheads to the

Grid functionality, as each participating organization

acts as a resource provider or resource consumer. In

such settings, expressing access control in terms of

direct trust relationships between resource providers

and consumers has the problems of scalability,

flexibility, expressability and lack of policy

hierarchy.

We can further classify the authorization

information into two categories: (a) the general

information regarding the user inside his own

organization, like groups or roles he belongs to,

along with other access control rights, and (b)

information - permissions regarding what the user is

allowed to do at the offered resources in the Grid.

The first type of information should definitely be

kept at the local users’ organization, while the

second one should be widely known or be able to

determined by the rest of the participant

organizations.

Finally, an authorization decision could be made

either at the entry point of the shared resource,

determining the user’s access control rights, or, at a

central point external to the shared’ s resource

organization. We argue that even though a central

decision mechanism offers certain advantages, this

should not overcome every organization’s ability to

decide for its own resources access permissions’.

We also argue that these permissions could be very

well modified during the organizations participation

in the Grid and, furthermore, that an organization

could decide to apply some granularity to these

permissions and not to leave it open (same

permissions) to anyone who wishes to use it.

2.3 Enforcement Mechanisms

The authorization problem can be further divided in

two sub-problems. First to determine the permission

set of a user and then to enforce access control rights

by using existing access control mechanisms. The

enforcement of access rights is usually done by

determining and assigning the appropriate rights to

the entitled user for the corresponding resources. In

a typical non-distributed system scenario, the

enforcement mechanism usually focuses on an

application; because it is through this that a user

actually accesses the underlying resource. The main

concern here is the access rights of the user to that

application and not the application’s to the resource,

as the application is a trusted software component

and its access rights are easily determined.

In a Grid context however we anticipate another

scenario. Resources are accessed by software

components not necessarily trusted by the resource

owners. The resources act as hosting environments

for these software components (services), which are

often transient and migrate between different

resources to meet performance criteria. This implies

that it is not possible to establish static trust

relationships between the service and the underlying

resource’s hosting platform, while it is essential to

examine the access rights of the user to the service

but most important the access rights of the service to

the current resource environment.

We can identify two categories of enforcement

mechanisms: the application dependent and the

application independent. Usually the application

dependent mechanisms are directly integrated in the

service and exercise access permissions before the

service attempt to access the resource. The problem

here is that the resource’s hosting platform should

trust the service’s code and therefore it is favoured

in situations where services are stationary. In the

Grid environments however we believe that the

application independent mechanisms are more

favourable. In the later case the mechanisms are

separate from the service’s implementation.

3 CURRENT APPROACHES

Current Grid security technology is sufficient to

address computational problems in healthcare.

However Healthgrid technology is not restricted to

the use of Grid technology for distributed computing

only. Eventually, Healthgrids should offer a generic

platform for all eHealth actors. Sharing of large

amounts of distributed heterogeneous (on various

SECRYPT 2007 - International Conference on Security and Cryptography

396

levels) data is therefore an important point of

attention.

There are several examples of existing systems

that attempt to address the authorization problem in

a grid-computing environment. In the community

authorization service (CAS) case for example, a

CAS server is in charge of authorization of a

community users, while resource providers in the

community only need authentication after delegating

authorization functions to the CAS server. In the

generic authorization and access control (GAA)

system, GAA API functions obtain policies from

local files, distributed authorization servers and from

credentials provided by the user. Its goal is to design

a flexible and expressive mechanism for

representing and evaluating these authorization

policies. The Global Grid Forum is another system

working on a grid security architecture standard

(

Lorch et all, 2003) which is based on Web Services

security studies and tries to define fine-grained and

coarse-grained authorization mechanisms under the

Open Grid Service Architecture (OGSA) framework

(Siebenlist et all, 2001). GEMSS is another approach

that is based on a public key infrastructure, and

implements end-to-end security mechanisms in line

with the web services security specifications (

Herveg

et all, 2004).

Several security authorization models have also

been proposed applying the RBAC access control

model. Al-Kahtani and R.Sandhu, proposed for

example a variation of the RBAC model, the rule-

based RBAC (Al-Kahtani and R.Sandhu, 2002).

According to their proposal Rule-based RBAC, rules

are used to produce roles. These rules are expressed

by attribute values, which the potential user presents

to the system. These values have some seniority

between them, which makes them comparable. The

model has been used in cases of hosts visited by a

huge number of visitors not known in advance by

the system. Al-Kahtani also proposed a series of

modified RBAC models which can very well

contribute to the theoretical basis of our work. The

PERMIS access control policy also provides a tool

that takes advantage of the RBAC model by

enabling roles to users. User’s attribute certificates

in the form of x.509 are compared against a list of

permitted roles in an LDAP directory and a decision

to grant or deny access is granted. An exact match is

however still required in order to acquire a role

(Chadwick, Otenko, 2002).

All these approaches are based however on

certain attributes and predefined permissions that

should be exactly fulfilled and thus they do not

adequately handle the dynamic nature of the

HealthGrid environments

4 A DYNAMIC AUTHORIZATION

FRAMEWORK FOR

HEALTHGRID

ENVIRONMENTS

Membership in such a complex and distributed

environment like the HealthGrid is dynamic as

participant organizations may join or leave any time.

Hence the relationships among participants are not

constant while access control policy at every

participant changes frequently. Authentication and

role assignment therefore represent a major problem

in HealthGrid environments. The following concepts

are essential for the proposed authorization

framework to be described later.

4.1 The Use of Mobile Agent

Technology

The use of mobile agent technology can be useful in

such environments. Mobile agents provide an

undoubting advantage over the traditional client-

server paradigm. The ability to move computations

across the nodes of a wide area network helps to

achieve the deployment of services and applications

in a more flexible, dynamic and customisable way.

Mobile Agents are often independent of particular

hardware or operating system, and can be deployed

in heterogeneous environments. Users belonging to

different participants of the HealthGrid system try to

access resources via the use of mobile agents. Once

let loose, mobile agents roam the Grid network, seek

information, carry out tasks on behalf of their

senders autonomously, and return to present the

results of their queries. A doctor for example

working in a hospital A may seek information

regarding a patient. This specific patient might have

been treated in other medical institutions where the

doctor obviously does not hold an account. Instead

the doctor could send an agent loaded with

credential which would help him to access a local

security role at every hospital that visits and thus

help him gather information regarding the specific

patient.

However, agent technology carries with it

associated security vulnerabilities that had to be

addressed in order that this new technology to be of

any use. A key requirement in the process is to find

a flexible, convenient and effective approach to deal

with the mobile agent authorization problem. The

approach that solves the problem, dynamically maps

an unknown user to predefined organizational roles

based on the unknown user’s credentials and role-

SECURING HEALTHGRID ENVIRONMENTS

397

assignment mechanism. The agents should have

proper authorization mechanisms for providing entry

to the agents. The mechanism should automatically

assign roles to agents. Our approach is based on the

principle that when an agent migrates to a specific

platform, the host decides what privileges to grant to

the requested agent. Instead of using the traditional

access control method via an access matrix, the

mobile agent acquires a role from the local role

hierarchy. This is a direct use of RBAC approach,

but with a flexible method of selecting the

appropriate role every time an agent arrives at a

hosting platform.

The different hosts constituting the HealthGrid

system are visited by mobile agents and should be

able to automatically assign them different roles.

This should mainly depend on a set of credentials

(values on attributes) that the agent carries with it,

the local security policy and constraints defined by

the host that provides the resources. In any case the

organization that provides the resource must have

the privilege, the authority and flexibility to define

the set of rules that define the security roles, applied

to the specific organization.

4.2 The Role Decomposition Process

The process that decomposes the security roles is

based on the following: the roles are defined using

rules, which are constituted by

Attribute_Expressions (A_E). These A_E are

actually constructed by using Attribute_Fields (A_F)

related to each other with some level of seniority as

we shall see later on. In order to define a specific

role, these A_Fs are filled with Attribute_Values

(A_V), which are the ones that finally describe the

role (fig 1).

Fig 1

Figure 1.

The key component in the above process is the

use of the A_Fs, because in order to be able to

exchange agents, the different hosts should refer to

common sets of credentials. This implies the

existence of common A_Fs between organizational

hosts, in order to define a common ground of

understanding. This assumption is already a

necessity in a Grid System environment as the

different organization‘s scope is to facilitate

resource sharing and problem solving.

The A_Vs that an agent carries with it might

correspond to the A_Fs required for a specific role.

In most cases however, they will not literally equal

them. And in the case that these A_Vs are not of

numeric type, a comparison between these two

Attribute Expressions is not possible, even though

they correspond to identical A_Fs. F. ex lets

consider an A_F: “Business_Position” and a role

requiring the A_V: Stuff Manager for this specific

A_F. What happens if a mobile agent presents an

A_V: General Manager? How could it be evaluated?

4.3 The Seniority Concept

A solution to the problem would be the introduction

of the concept of seniority between the A_Vs of an

A_Fs and furthermore seniority levels between

A_Fs. The seniority level between A_Vs indicates

which value dominates which in an actual

comparison while seniority levels between A_Fs

denotes which A_F consider higher in seniority to

another A_F when it comes to compare A_Vs

belonging to these two Fields. This leads us to the

definition of the concept of an A_F hierarchy. The

above mechanism permits a comparison between

A_Es even though they are not constituted by

exactly the same A_Fs. A_Es could be comparable

as long as they either have identical structure

(A_Fs), or A_Fs related each other with some level

of seniority.

Instead of storing and distributing lists of A_Vs,

which are difficult to manipulate, we introduce the

idea of transforming the nonnumeric values to

numeric. This makes the comparison between A_Vs

extremely ease and self-explanatory. Moreover the

A_Fs can contain not only the corresponding A_V

but also the scale that this value came from. This is

absolutely necessary, as different organizations

might not use exactly the same scale to describe the

A_Vs of the same A_F. Sending the scale with the

value would permit them to “transform’ it to their

own scale, performing sort of normalization. This is

another degree of liberal mechanism in our model,

as the main motivation remains always to permit

every participant organization to establish its own

security policy as independent as possible.

Obviously, this transformation is not working for

all kind of A_Fs. There are certain categories of A_s

which is meaningful to try to transform them into

Roles

Attribute Expressions

Attribute Fields

Attribute Values

SECRYPT 2007 - International Conference on Security and Cryptography

398

numeric (e.g. names). In these cases where the A_Vs

are discrete and determine, they should stay

unchanged and left to the hosting organization to

decide about the necessary seniority between these

A_Vs (e.g countries, locations).

By this, A_Fs can contain only numeric A_Vs.

The introduction of seniority between A_Fs and

between A_Vs eases the comparison between A_Es

because:

1. It imposes seniority between A_Fs, while it not

even necessarily agreed in advance between all

participants of the infrastructure. Instead every

participant reasons and evaluates the importance

of each A_F under his/her own judgment.

2. A_Fs are grouped and related with some level of

seniority according to their significance. Not all

A_Fs necessarily are related each other.

Introducing seniority between A_Fs with diverse

implication is meaningless, so only A_Fs with

similar significance are related to each other.

This leads us to groups of A_Fs with seniority

among them.

A role can be expressed in the form of an A_E as

follows:

where:

represents an A_F, i identifies the group it

belongs, j represents the rank number of the A_F

inside the group while X

ij’

represents the

corresponding A_V.

The above mechanism allows for two roles from

different role hierarchies R and R’ to be compared

for dominance.

5 THE ADAPTED MOBILE

AGENT STRUCTURE

The effective management of trust and policy within

a community in HealthGrid systems also requires

flexible, autonomous mechanisms able to take into

account, when organizing communities, not only the

semantics of policy statements, but also the ability to

negotiate policy terms and to manage restricted

delegation of rights. A procedure that is already

known in agent technology.

The mechanism presented earlier could therefore

be implemented easily using existing agent

technology. In this section we present such an

adaptation of agent technologies in order to enforce

a flexible and scalable authorization service, suitable

for complex HealthGrid system structures. We

assume that the authorization decisions must often

be made in the absence of strong existing trust

relationships. Furthermore we assume that the

proposed authorization service will use the existing

access control model at every participant node of the

Healthgrid. A suitable, flexible agent structure is

needed to anticipate the above requirements. The

proposed adapted mobile agent structure is based on

the following concepts:

When an author (programmer) constructs an

agent, for such an environment, he should therefore

include in this case the following:

• The source code

• The set of possible A_Fs, the agent is allowed

to carry

• Default A_Vs, for the corresponding A_Fs

which construct an A_E that yields to a

default agent role.

Accordingly, when a user is about to dispatch an

agent, he should include:

• All the previous, plus

• A set of A_Vs that correspond to the set or

subset of the A_Fs the author of the agent, permits it

to carry. These A_Vs derive from the role that the

user is already been assigned at the specific host.

Every mobile agent has a default agent role

defined by its author (programmer) and a user role

inherited by its user/sender. The corresponding

A_Vs do not change during the agent’s journey, as

they constitute its original identity, authority and

credibility.

Let us consider the generic case where an agent

initially launches on host H0 holding its default role

R0. The user (sender) loads his role R

on the agent

thus the A_Vs that actually constitute this role. We

assume that the agent will execute autonomously on

a set of network hosts (namely H

, H

…H

). When

agent is residing on the host H

, its current role is R

We have to distinguish the following different role

symbolisms:

• R

stands for the agent’s default role

• R

stands for the user (sender) role that is

initially assigned to the agent

• AR

stands for the agent role, the role which the

agent holds while migrating from host H

i+1

• R

stands for the role that the agent acquires on

host H

• R

i+1

stands for the final role that host H

i+1

grants to the agent.

This ultimate role assignment depends on the

role of the arriving agent AR

, the specific migration

method the agent followed to arrive at host H

i+1

and

the agent’s initial R

and default role R

. This means

that when an agent migrates from host H

to the next

host H

i+1

, its role (represented as AR

) is actually the

role R

that the agent obtained during its execution

SECURING HEALTHGRID ENVIRONMENTS

399

on host H

. According to (Lorch et all, 2003), the

agent migration to the next host can be initiated by

two different ways: either from the hosting place

(host), or from the agent itself, (the agent’s code

decides to move to the next place). The migration

can also take place with two different ways: either

by handoff (a principal hand his authority to another

principal), or by delegation (a principal is combining

his authority with another principal).

During the process of delegation, when one

principal (initiator) authorizes another principal

(delegate), the attached privileges, in the form of

A_Vs, are passed from initiator to the delegate. Te

proposed delegation mechanism supports the RBAC

access control by delegating roles and provides a

higher level of granularity than approaches limited

only to individuals. The proposed mechanism can be

summarised as follows:

Every host in the Grid is considered as a unique

entity and is able to delegate his authority. The four

distinct cases (namely the specific migration method

as well as the initiative) and our proposed role

decomposition methodology lead us to:

1. Place handoff:

The current host H

hands off his authority to the

next host H

i+1

. In this case the next role R

i+1

will

result from the following expression:

i+1

←AR

⇒ R

i+1

← R

The A_Vs the agent came with at the host H

are

presented and at the next host H

i+1

2. Place delegation:

Host H

delegates his authority to H

i+1

. In this

case the next role R

i+1

will result from the following

union expression:

i+1

← AR

⇒ R

i+1

← R

∪ AR

i-1

When the host delegates his authority to a visited

mobile agent, the A_Vs that constitute the role that

the host assigned to the agent, are transferred to the

delegated agent. The A_Vs of the roles R

the agent

acquired on host H

are combined with the ones that

came with from the previous host H

i-1

, in order to

obtain the next role R

i+1.

3. Agent handoff:

The agent directly hands off to H

i+1

. The next

role R

i+1

will result from the user’s initial role, the

role assigned by the agent’s user. The following

expression stands in this case:

i+1

← AR

⇒ R

i+1

← R

The A_Vs of role R

are presented to host H

i+1

order to obtain the next role R

i+1

4. Agent delegation:

The agent can delegate itself to H

i+1

. Since the

agent delegates his authority, his default role R

combined with the agent’s role R

. The next role

i+1

will result from the following expression:

i+1

← AR

⇒ R

i+1

← R

∪ R

The A_Vs of roles R

and R

are combined in

order to obtain the next role R

i+1

The above agent migration methods affect

decisively the agent’s ability to join the security

policy of the different Healthgrid organisations it

visits. This adapted agent structure can therefore

effectively address the authorization problem in

HealthGrid environments and thus facilitates

collaboration between participant health institutions

in order to establish an e-health environment. .

6 APPLICATION – RESULTS

The proposed process and the related assignment –

migration algorithms presented above have been

implemented and applied, using the Java

programming language. The implementation used as

an example a typical health care environment where

the ministry, local hospitals, hospital departments

(nutrition, etc), patients and health insurance

companies collaborate in order to exchange

information. We tried different role hierarchies at

every organization and we tested all different

migration methods. Every time the mobile agent

adopted a different suitable security role at the

organization that it visited.

The results have shown that the proposed

framework is applicable and implementable, and can

be applied in real life situations. Also the proposed

framework does not require any change of the

different local role hierarchies of the participating

organizations and it preserves their security

requirements. Based on those results, it can therefore

be said that the experimental implementation of the

proposed adapted agent structure, together with the

proposed earlier role assignment process, can

effectively address the authorization / security

problem in Grid based health environments

7 CONCLUSION AND FUTURE

WORK

Securing HealthGrid environments is a major issue

today. Current Grid security technology is sufficient

to address computational problems in healthcare.

Healthgrids are not restricted to the use of Grid

technology for distributed computing only.

Healthgrid should eventually offer a generic

platform for all eHealth actors. Sharing of large

amounts of distributed heterogeneous (on various

SECRYPT 2007 - International Conference on Security and Cryptography

400

levels) data is therefore an important point of

attention. In this paper we discussed the overall

security problem of such environments and we

presented a suitable a local authorization policy for

HealthGrid participating organizations, which

utilizes the advantages offered by both the grid and

the agent systems technology. More specifically, we

addressed the dynamic authorization problem of

HealthGrid environments by describing a flexible,

RBAC based role assignment mechanism. Our

approach proposes a secure and consistent solution

to the authorization problem in HealthGrid

environments, based on a role decomposition

process, that every organization is qualified to

perform according to its local security policy. The

main contribution of this work is that it proposes a

practical mechanism by applying the well-accepted

RBAC access control model to dynamic HealthGrid

based environments. The proposed methodology has

been successfully tested in a real life health

environment.

REFERENCES

Al-Kahtani, R.Sandhu, 2002 A model for Attribute-Based

User-Role Assignment. Proceedings of the 18th

Annual Computer Security Applications Conference,

Las Vegas.

Chadwick, Otenko, 2002. “The PERMIS X.509 Role

Based Privilege Management Infrastructure”,

Proceedings of the seventh ACM symposium on Access

control models and technologies SACMAT 2002,

Monterey, California, USA

Ferraiolo, Sandhu, Gavrila, Kuhn, Chandramouli: 2001

Proposed NIST standard for role-based access control.

TISSEC 4(3): 224-274.

Foster I, Jennings N, Kesselman C, Brain Meets Brawn:

2004 Why grid and Agents Need Each other,

AAMAS’04, NY, ACM.

Herveg, J., Crazzolara, F., Middleton, S. E., Marvin, D. J.

and Poullet, Y. 2004, “GEMSS: Privacy and security

for a Medical Grid”. In Proceedings of HealthGRID

2004, Clermont-Ferrand, France.

Jennings, N., 2001.An agent-based approach for building

complex software systems. Communications of the

ACM, 44(4). 35-41.

Lorch, B.Cowles, R.Baker, L,Gommans, P.Madsen,

A.McNab, L. Ramakrishnan, K.Sankar, D.Skow, M.

Thomson, 2004 Conceptual Grid Authorization

Framework and Classification, Global Grid Forum, ..

OASIS 2003, Security Services Technical Committee

XAMCL, extendible access control markup language

(XACML) committee specification 1.0.

SAML 2003 Security Services Technical Committee,

Assertions and protocol for the oasis security assertion

markup language (SAML), OASIS .

Scott Richard., Jennett Penny, Yeo Maryann, 2004,

Access and authorisation in a Glocal e-Health Policy

context, International Journal of Medical Informatics

Elsevier (2004) 73, 259—266

Siebenlist, V. Welch, S. Tuecke, I. Foster, N. Nagaratnam,

P. Janson, J. Dayka, A. Nadalin, 2002, OGSA security

roadmap, Open Grid Services Architecture Group.

Simpson Andrew, Power David, Slaymaker Mark, 2006,

On tracker attacks in health grids, SAC’06 April 2006,

Dijon, France

Welch, F. Siebenlist, I. Foster, J. Bresnahan, K.

Czajkowski, J. Gawor, C. Kesselman, S. Meder, L.

Pearlman, S. Tuecke, 2003. Security for Grid Services.

Twelfth International Symposium on High

Performance Distributed Computing (HPDC-12),

IEEE Press

SECURING HEALTHGRID ENVIRONMENTS

401
