A SECURE JAILING SYSTEM FOR CONFINING UNTRUSTED

APPLICATIONS

Guido van ’t Noordende,

am Balogh*, Rutger Hofman, Frances M. T. Brazier and Andrew S. Tanenbaum

Department of Computer Science, Vrije Universiteit, Amsterdam, The Netherlands

*Department of Algorithms and their Applications, E

otv

os Lor

and University, Budapest, Hungary

Keywords:

System Call Interception, Application Conﬁnement, Jailing.

Abstract:

System call interception based jailing is a well-known method for conﬁning (sandboxing) untrusted binary

applications. Existing systems that are implemented using standard UNIX debugging mechanisms are ren-

dered insecure by several race conditions. This paper gives an overview of the most important threats to

jailing systems, and presents novel mechanisms for implementing jailing securely on standard UNIX systems.

We implemented these solutions on Linux, and achieve competitive performance compared to existing jailing

systems. Performance results are provided for this implementation, and for an implementation that uses a

special-purpose extension to the Linux kernel designed to improve performance of the jailing system.

1 INTRODUCTION

Operating systems currently do not provide sufﬁ-

ciently ﬁne-grained protection mechanisms for pro-

tecting a user against the programs that he or she

executes. The UNIX protection model is based on

a discretionary access control model, where all pro-

grams executed by a user inherit the user’s permis-

sions with regard to accessing resources, such as

ﬁles. To safely execute untrusted programs on UNIX

systems, system-call interception based jailing sys-

tems can be used which protect the system and the

user’s resources, and which allow a user to conﬁg-

ure network addresses with which a jailed program

is allowed to communicate. System-call interception

based jailing systems (Goldberg et al., 1996; Alexan-

drov et al., 1999; Jain and Sekar, 2000; Provos, 2003;

Garﬁnkel et al., 2004) are based on a kernel-level trac-

ing mechanism (e.g.,

ptrace

) that allows a trusted

jailer to intercept all system calls of its child pro-

cess(es), and accept, deny, or modify arguments of

the system calls made by an untrusted process before

the kernel proceeds with executing the system call.

All jailing systems make use of a policy ﬁle which

describes which parts of the local ﬁle system may be

accessed, and which network addresses are reachable

by the jailed processes.

A number of jailing systems require modiﬁcations

to the operating system to function securely. Jailing

systems which are implemented in user-mode, using

the ptrace() or /proc debugging facilities offered on

standard UNIX, also exist. However, existing sys-

tems suffer from several race conditions, which al-

low an attacker to bypass the jailer’s control mecha-

nisms (Garﬁnkel, 2003). This paper describes novel

solutions to these race condition problems. These

solutions allows complex programs, including multi-

threaded programs that make use of IPC mechanisms

and signals, to be jailed effectively. The jailing sys-

tem presented in this paper provides sufﬁcient control

to allow for effective conﬁnement of untrusted pro-

grams using standard system call tracing mechanisms

available on most UNIX systems.

2 TERMINOLOGY

This paper uses the following terminology:

• The jailer is a trusted process that monitors an

untrusted application and enforces a policy on the

user’s behalf.

• A prisoner is an untrusted application that is be-

ing monitored by a jailer and is forced to adhere

414

van ’t Noordende G., Balogh Á., Hofman R., M. T. Brazier F. and S. Tanenbaum A. (2007).

A SECURE JAILING SYSTEM FOR CONFINING UNTRUSTED APPLICATIONS.

In Proceedings of the Second International Conference on Security and Cryptography, pages 414-423

DOI: 10.5220/0002129404140423

 SciTePress

Jailer Prisoner

Operating System

3/5 12/4

Figure 1: General positioning of a system call interception

system showing a jailer and a traced prisoner. When a pris-

oner makes a system call (step 1), the operating system sus-

pends the invoking thread and reﬂects the system call to the

jailer (step 2). The jailer inspects the system call’s argu-

ments and decides if it allows the system call or not. It

informs the operating system of its decision (step 3), which

results in the system call being continued or an error being

returned to the prisoner. Step 4 and 5 repeat step 2 and 3

after the system call has been made, so that the jailer can

inspect the result of the system call before returning control

to the prisoner.

to a predeﬁned jailing policy.

• The tracer is the interface offered by the oper-

ating system for debugging / tracing an applica-

tion. Every major UNIX system to date provides

one or more tracing interfaces, such as ptrace() or

System-V’s /proc interface.

The basic idea of system call interception is

demonstrated in ﬁgure 1. Most if not all current UNIX

systems provide some form of debugging support that

allows for catching and inspecting the system calls

that an application makes and its arguments. Linux

provides the

ptrace()

system call tracing interface,

which is rudimentary but still often used (e.g., by

gdb). We used this interface to implement our jail-

ing system. Since ptrace is about the most primitive

tracing interface possible, it demonstrates the mini-

mal requirements for implementing a user-level jail-

ing system well.

When a ptraced process makes a system call, this

call is trapped by the operating system and reﬂected to

the parent process, which can then inspect the child’s

the parent (jailer) can decide whether to let the sys-

tem call proceed or whether it should return an error

without being executed. Ptrace allows the jailer to

change the value of registers that contain the system

call’s arguments, before letting the kernel execute the

call. Ptrace intercepts every system call just before

it is executed by the kernel, and right after executing

it. Only after the jailer agrees to let the process con-

tinue on both the pre and post system call event, the

prisoner thread is resumed.

3 THREATS AND

VULNERABILITIES

Figure 1 illustrates a signiﬁcant problem in all sys-

tem call interception based jailing systems that sup-

port multithreaded applications or processes that use

shared memory. When the operating system suspends

the invoking thread and reﬂects the system call to the

jailer (step 2), the jailer has to make a decision on

whether to allow the system call based on its argu-

ments. These arguments often contain a pointer to

a string (e.g., a ﬁlename) in the prisoner’s address

space, which must be derefenced and checked by the

jailer. Between the time that an invocation was made

(step 1/2) and the decision has been passed back to

the operating system (step 3), a different thread of

the prisoner could have modiﬁed the argument in the

original thread’s address space. In this case, the sys-

tem call would end up using the modiﬁed system call

argument rather than the argument checked by the

jailer. This race condition is called a Time of Check

to Time of Use (TOCTOU) race, and it is a realistic

threat for all jailing systems that intend to support

multithreaded programs or programs that use shared

memory. This threat applies to all system calls that

take an argument residing in the prisoner’s address

space, such as a ﬁlename or an IP address.

Several solutions for the shared memory TOC-

TOU race have been proposed (Garﬁnkel, 2003;

Garﬁnkel et al., 2004; Provos, 2003; Goldberg et al.,

1996). The most secure among current approaches is

to let the kernel create a safe copy of the arguments

before reﬂecting that to a user-level policy enforce-

ment module (Provos, 2003).

TOCTOU race conditions are harder to solve for

systems that rely on existing tracing mechanisms such

as ptrace() or /proc, which provide no protection of

the arguments of a system call at the time of inspec-

tion. The approach closest to solving the shared mem-

ory race is described in (Jain and Sekar, 2000). This

solution is based on relocating a system call’s argu-

ment to a random location on the caller’s stack be-

fore checking it, so that another thread in the child’s

address space is unlikely to ﬁnd and replace this ar-

gument. However, it is certainly not impossible for

another thread to ﬁnd such a relocated argument and

replace it

. Other jailing systems simply completely

disallow thread creation, or suspend all threads of a

jailed process while a system call is being evaluated

Winning this race is not as far-fetched as it may seem,

since the prisoner knows the argument which it originally

speciﬁed itself and can tell another thread to search for it in

its address space.

http://www.subterfugue.org

A SECURE JAILING SYSTEM FOR CONFINING UNTRUSTED APPLICATIONS

415

Both approaches signiﬁcantly limit the applicability

of such systems for executing modern thread-based

applications.

Certain ﬁle system race conditions have also

been documented for system call interception sys-

tems (Garﬁnkel, 2003). These race conditions are

again caused by a lack of atomicity of argument

checking and system call invocation. Between the

time that a system call’s ﬁlename argument is veri-

ﬁed by the jailer and the time that the system call is

executed in the kernel, another prisoner thread (or a

different process running in the jail) may have sub-

stituted a part of the underlying ﬁlesystem path for a

symbolic link to a directory outside the paths that are

allowed by the policy

. Intermittent changes to the

current working directory can evoke similar race con-

ditions.

A weakness of most existing jailing systems is

that the only way they can handle system calls au-

tomatically is to either always allow or deny them al-

together, or to conditionally allow or deny the sys-

tem call by comparing its argument with, for exam-

ple, a set of ﬁlenames or network addresses in a user-

provided policy ﬁle. Another solution is to make a

callback to the user (Provos, 2003). However, it is a

hard task for a user to understand the meaning of the

arguments of every system call of the UNIX API and

the potential side-effects of allowing the call. For ex-

ample, some IPC calls or the kill system call take ar-

guments which indicate some kernel object of which

a user cannot easily determine whether access to it

should be allowed or not. This approach is also not

feasible when a large number of jailed processes are

running simultaneously on a system.

4 THE JAILING MODEL

To address the issues outlined above, our system pro-

vides a clear jailing model, which distinguishes an ap-

plication’s allowed actions within a jail from actions

that inﬂuence the world outside the jail. A jail always

starts with a single program, but this program may

(modulo policy)

fork

execve

other programs or

create new threads

. Child processes run under the

same policy as their parent (ﬁg. 2).

For example, the prisoner may invoke open with

/tmp/user/temp/passwd in the allowed path /tmp/user/temp,

and substitute the temp component for a symbolic link to

/etc, hoping that the system call will result in /etc/passwd to

be opened.

Multiple processes may run in a jail, for example a set

of processes executed by a shell script which communicate

via pipes.

process

first jailed

program

Jailer

JAIL

process

child

process

child

process

child

Figure 2: A jail’s process hierarchy. The jailer starts the

ﬁrst jailed process in its own jail, and controls this jail by

enforcing the jailing model and the jail’s policy. A jailed

process can create child processes (using fork and execve).

These processes are now in the same jail as their parent and

execute under the same policy as their parent. All processes

within a jail can communicate with each other using UNIX

IPC primitives (e.g., using pipes or shared memory primi-

tives like shmem or mmap) or signals, or by writing ﬁles in

their jailing directory. Communication with processes out-

side the jail is controlled by the jailer’s policy.

Within a jail, the jailer allows almost the full

UNIX API, including IPC mechanisms such as shared

memory (but no root privileged calls) to be used by

all processes within the same jail. Actions which may

inﬂuence the outside world, such as accessing the ﬁle

system or connecting to a network endpoint, are only

allowed when allowed by the jailer’s policy ﬁle. The

importance of this model is that it allows the jailer for

most system calls to automatically determine whether

they are allowed or not, even when these system calls

take arguments which are determined at runtime (see

sec. 3). The jailer keeps track of which communi-

cation endpoints or IPC channels were created inside

the jail, and only allows access to internal endpoints

or IPC channels. The jailer makes sure that a pris-

oner cannot set up connections to arbitrary processes

outside the jail. Jailed programs can send signals, but

only to processes running in the same jail.

The jail concept is quite suitable to describe

whether a set of processes may communicate with

each other or not: processes within a single jail may

freely communicate with each other, but communica-

tion with the outside world is not allowed unless ex-

plicitly permitted by policy. Because the jailer allows

most UNIX calls to be used freely within a jail, it al-

lows for execution of the majority of programs, even

modern multithreaded and multiprocess applications,

within the conﬁnement rules of the jail.

A jailed process is by default started up in a (nor-

The jailer also controls who may connect to a commu-

nication endpoint created in a jail, to prevent external pro-

cesses to initiate a connection to a jailed process.

SECRYPT 2007 - International Conference on Security and Cryptography

416

mally empty) scratch directory, which is read-write

accessible and not shared with other jailed processes.

Each jail has a simple policy using which the user can

deﬁne which parts of the local ﬁle system a jailed pro-

gram may access. Examples are /usr/bin and /usr/lib,

which contain ﬁles that may be used by programs

Any part of the ﬁle system may be marked read-only

or read-write accessible. The policy also allows for

’mounting’, and for change-rooting parts of the local

ﬁle system into the prisoner’s jailing directory. This

avoids that parts of the local ﬁle system have to be

copied to the prisoner’s jailing directory. More de-

tails on the policy ﬁle are given in (van ’t Noordende

et al., 2006). Except for the policy ﬁle, speciﬁc es-

capes from the default conﬁnement model and the

policy ﬁle can be speciﬁed on the jailer’s comman-

dline. Examples are IPC escapes, using which a user

can specify TCP addresses or UNIX domain sockets

which are reachable from a jail. In our experience,

it is generally not necessary to override the default

policy, as most applications and the libraries they use

simply run as expected within a jail

5 WINNING THE SHARED

MEMORY RACE

The most important implementation issue to solve is

how to secure the arguments of a system call in view

of the shared memory race conditions outlined in sec-

tion 3.

The basic idea implemented in our system is

shown in ﬁgure 3. When a new prisoner process is ex-

ecuted, it is provided with a region of shared memory

which is shared between the prisoner and the jailer.

The prisoner has read-only access to this region; the

jailer can write into it. We call this shared mem-

ory region Shared Read-Only memory, or ShRO in

short. The shared memory is set up in the prisoner’s

address space using a library preloading technique.

The preload library uses mmap() to read-only map

the memory region in the prisoner’s address space.

The preload library also contains some code which is

required for certain post-system call processing tasks

which are explained in section 8. Preloading avoids

patching the prisoner binary.

The jailing model allows a prisoner to execute pro-

grams from, e.g., /bin/, such as sh, perl, sed, or awk, given

that policy allows.

Libc turns out to make many calls which are denied,

e.g., to ﬁles in /etc. However, libc turns out to be quite

resilient to denied system calls, and most programs run as

expected in a jail.

Preloaded

executable

library

R/O memory

Preloaded

in prisoner’s

prisoner

shared with

to memory

R/W access

addr. space

process’

ress space

normal ad−

Jailer’s

address

space

Prisoner

Figure 3: The Shared Read-Only (ShRO) memory solution

for avoiding user-level multithreading and shared memory

race conditions. The shared memory region is mapped in

transparently at prisoner startup time. The prisoner pro-

gram itself is unmodiﬁed and normally not even aware of

the preloaded ShRO memory region and library in its ad-

dress space.

Once a system call is made, the jailer fetches the

arguments from the kernel using standard ptrace calls

(sec 2). The argument can be a ﬁlename or an IP ad-

dress, for example. The jailer makes a safe copy of

the arguments in ShRO and adjusts the argument reg-

isters (which are stored in the Linux kernel) to point

to the copied arguments. Then the jailer does a policy

check using the safe copy of the arguments in ShRO,

and informs the kernel of its decision to let the system

call proceed or not. If the system call is to proceed,

the kernel uses the safe argument copies to execute

the system call. No prisoner thread can modify the

registers or the safe copy of the arguments in ShRO.

The ShRO solution alone is not sufﬁcient to pre-

vent all race conditions. For example, there is a win-

dow of oppertunity for a malicious program to sub-

stitute a ﬁle in its read-write accessible jailing direc-

tory (which has its canonical ﬁlename stored safely in

ShRO) for a symlink to a ﬁle in a directory which is

normally not accessible, between the time where the

ﬁlename is stored in ShRO, and the time that the sys-

tem call is executed. We prevent this by serializing all

system calls that modify an object in a read-writeable

path in the jail while an open call is in progress.

Serializing is implemented by a readers/writers lock

around the open and modify/create/write-type system

calls. This provides an effective solution to the shared

ﬁle system TOCTOU race outlined in section 3.

6 JAILER ARCHITECTURE

The architectural design of our jailer separates

generic functionality (i.e., policy enforcement) from

platform-speciﬁc functionality. The jailer is split into

two layers. The lowest layer is called the interception

A SECURE JAILING SYSTEM FOR CONFINING UNTRUSTED APPLICATIONS

417

layer

Shared

memory

manager

Operating System

trace event syscall

Jailer process

Prisoner

process

Interception

Policy layer

ShRO memory region

shared with prisoner

Figure 4: The jailer’s internal architecture. The jailer con-

sists of an operating-system speciﬁc interception layer and

a portable policy layer. Both layers use a portable shared

memory manager module which manages the ShRO mem-

ory region(s) of the prisoner process(es) in the jail. The

interception layer drives the jailer by handling trace events

from the operating system and by calling the memory man-

ager and policy layer accordingly. The interception layer

also takes care of resuming the prisoner’s calling thread af-

ter policy evalutation is done, using an OS tracing primitive.

layer. This layer interfaces with the underlying sys-

tem call tracing interface, e.g., ptrace() or /proc. We

have currently implemented two interception layers,

one that uses ptrace() and one that uses a specially-

built in-kernel system call interception interface in

Linux, called kernel jailer. Above the interception

layer lies the policy layer, which enforces the jailing

policy. Both layers can access a shared memory man-

ager module, which manages the ShRO memory re-

gion. It has an interface which allows the interception

layer and the policy layer to allocate memory to write

system call arguments or stack frames into when re-

quired. The jailer architecture is shown in ﬁg. 4.

The interception layer handles the tracer-speciﬁc

mechanism for attaching to a prisoner process, and

it sets up the shared memory between the prisoner

and the jailer. There is no time when prisoner code

runs uncontrolled. The ﬁrst prisoner is created by

having the jailer fork, and the forked child attaches

to the jailer before it exec’s the prisoner code. Af-

ter the attach, the child lets the ELF dynamic loader

(ld.so) execute our jailing preload library (sec. 5).

The preloaded library sets up the ShRO region, and

connects to the jailer using a UNIX domain socket.

Preloading takes place in a mini jail environment,

in which the prisoner is only allowed to make those

system calls necessary to initialize the preload li-

brary. The way in which the ShRO region is set up is

completely controlled by the jailer, which checks the

correctness of the system calls and arguments made

during the preload phase. The prisoner’s own code

(main) is invoked only after preloading and ShRO

setup is complete.

The interception layer handles copying of the sys-

tem call arguments to ShRO, after which it passes

control to the policy layer. The policy layer decides

whether to allow or deny the system call depending on

the arguments. The policy layer also expands sym-

bolic links in ﬁlename arguments, such that it uses

an absolute pathname for comparison with the pol-

icy. If the system call is to be denied, this is speci-

ﬁed by returning a negative error code (correspond-

ing to errno) from the policy layer. Then, control is

returned to the interceptor layer to let the system call

proceed. How the arguments are fetched

from the

prisoner’s address space, and how registers are modi-

ﬁed are platform-speciﬁc issues which are hidden in-

side the interceptor layer.

7 IMPLEMENTATION

We implemented a user-level jailer under Linux using

the architecture outlined above. For the interception

layer, we used a modiﬁed version of the open-source

program strace

. Strace is a program that is used to

display all system calls that a process makes, e.g.

for debugging purposes. Strace provides interfacing

with a number of tracing systems (such as ptrace and

/proc), and it provides mechanisms for system call

normalisation for different platforms. This helped our

implementation effort and will probably make porting

the jailer to other platforms simpler.

A second interception layer has been implemented

which makes use of a modiﬁed Linux kernel. The

modiﬁcation is called kernel jailer, and consists of

an extra tracing system call. The kernel jailer dif-

fers from ptrace in that it allows for efﬁciently fetch-

ing system call arguments (registers and dereferenced

arguments such as ﬁle names) from a prisoner’s ad-

dress space, and in that it caches the policy evalu-

ation results for certain system calls. This prevents

repeated upcalls to the user-level jailing process for

system calls which are always allowed or always de-

nied. The kernel jailer automatically jails all children

of a traced process. System call events are exchanged

between the kernel jailer and the user-level jailer us-

ing a System-V message queue. Except for very short

arguments, this is more efﬁcient than ptrace, which

can only read one word at a time from a traced pro-

cess’s address space. Similar to ptrace, the kernel

Ptrace is rather inefﬁcient at reading data from a pris-

oner, as it allows only one word to be read at a time. How-

ever, most operating systems provide more efﬁcient mecha-

nisms (e.g., Linux has a /proc/mem device) for reading from

a child process’s address space, which can be used by the

interception layer.

http://www.liacs.nl/˜wichert/strace/

SECRYPT 2007 - International Conference on Security and Cryptography

418

jailer allows for updating system call argument reg-

isters in the Linux kernel. We wrote a new interceptor

layer for integrating the kernel jailer; other than that,

nothing was changed to the user-level jailing system’s

code. Because the kernel does not have to implement

a mechanism for securing system call arguments as

most other jailing systems must do, adding the kernel

tracer adds only about 390 lines of code to the Linux

kernel.

A number of implementation issues had to be re-

solved in the ptrace() based interception layer, which

are not unique to our system. For example, ptrace

does not always guarantee that forked children of a

prisoner are automatically traced (which is the case

in the kernel jailer). Linux allows setting a ﬂag on

the Linux variant of fork, clone(), which determines

whether the child is also traced. The interception

layer simply sets this ﬂag for each clone call by a

prisoner. For other systems we can use a solution de-

scribed in (Jain and Sekar, 2000), which consists of

placing a breakpoint just after fork(). This gives the

jailer the time to attach to the forked process using

a ptrace primitive, after which the jailer removes the

breakpoint and the child can continue execution

A new ShRO region must be preloaded at the time

that an execve() is done. We do this by modifying

the arguments of the execve() call such that the loader

forces preload of the ShRO environment. When a pro-

cess creates a thread (i.e., calls clone on Linux), this

thread shares the ShRO region with all other threads

of this process, so no further work is required; this

also applies to

fork

. The jailer makes sure that ShRO

is safe in view of concurrent access by multiple pris-

oner threads within a single jail.

The policy layer is called by the interception layer

using a very simple interface. The policy layer pro-

vides a syscall

pre and a syscall post method, which

are called at the system call entry point, and at

the time that the system call returns, respectively.

Whether syscall

pre or syscall post is called depends

on earlier results of calling the policy layer, depend-

ing on the call that was made. For example, the

syscall

pre method may return a code which indicates

that the policy layer is only interested in post-system

call notiﬁcation for this particular system call on fu-

ture events.

No policy decisions are hardwired in the intercep-

tor layer: the ﬁrst time a prisoner makes a particu-

Note that this is a potentially vulnerable solution, as

care must be taken that no process in the same jailer can

access the part of the prisoner’s address space where the

breakpoint resides (e.g., using mmap()), and remove it pre-

maturely. This can be mediated by suspending other pris-

oners during execution of a fork. Fortunately, we can avoid

this issue in the Linux implementation.

lar system call, the call is always passed to the pol-

icy layer in the user-level process which makes a de-

cision. The policy layer in some cases decides that

a system call is always allowed or always denied.

It notiﬁes the interception layer of this by returning

an appropriate return value to the interception layer.

The ptrace() based interception layer stores this return

value in its internal action table, such that if the same

system call is made again, the system call is imme-

diately allowed or denied. Similarly, the kernel jailer

maintains an action table in the kernel, to avoid mak-

ing upcalls (i.e., expensive context switches) to the

user-level jailer process for system calls which are al-

ways allowed or denied. This improves efﬁciency sig-

niﬁcantly. For example, read or write calls are almost

always safe, as they use a ﬁle descriptor that was re-

turned earlier by a succesful veriﬁed

open

or similar

system call, e.g.,

connect

When a system call is denied, the policy layer re-

turns this decision and a normalized error code (er-

rno) to the interception layer. Ptrace, unfortunately,

does not provide a straightforward mechanism for

denying a system call. Therefore, the ptrace() inter-

ceptor substitues a harmless getpid() call for the orig-

inal call, and replaces this call’s return value with the

errorcode speciﬁed by the policy layer.

8 POST-SYSTEM CALL POLICY

EVALUATION

The ShRO region provides an efﬁcient security mea-

sure for arguments that are speciﬁed by a prisoner be-

fore making a system call. However, there are a few

system calls for which a potentially policy sensitive

argument is known only after the system call has been

made. This applies in particular to TCP

calls

and UDP

recv

recvmsg

recvfrom

primitives: the

peer address is only known to the kernel after

recvfrom

took place. The problem here is that the

result of the call is written into the caller’s address

space by the kernel, and between the time that the re-

sult (e.g., peeraddr) is returned and the jailer checks

this, another thread of the prisoner could have mod-

iﬁed the returned value to make it it pass the jailer’s

policy check. Worse, in the case of accept the new

socket may already be used by another thread of the

prisoner, before the jailer even looked at the peeraddr,

because the operating system has already created the

ﬁle descriptor as the result of executing the call

Keeping the invoking thread from resuming until

checking is done is not feasible either, as the ﬁle descrip-

tor can be easily guessed and used by another thread.

A SECURE JAILING SYSTEM FOR CONFINING UNTRUSTED APPLICATIONS

419

To handle this issue we use the delegation mech-

anism ﬁrst introduced in the Ostia system (Garﬁnkel

et al., 2004), where every sensitive call (such as

open

) is executed by the jailer instead of the pris-

oner. As the jailer is the process that executes the

system call, it can be sure that the prisoner has no

possibility of using the ﬁle descriptor before a peer’s

address has been veriﬁed. Most sensitive system calls

return a ﬁle descriptor. The jailer can pass this ﬁle de-

scriptor to the prisoner over a UNIX domain socket,

after which the prisoner can use it in the normal way.

Ostia makes use of a loadable kernel module to fa-

cilitate ﬁle descriptor passing from the jailer to the

prisoner. This solution is not usable in our system,

as our jailer program must run on unmodiﬁed UNIX

systems without system administrator intervention.

Post-system call processing is required for a few

more system calls. The jailer may need to mod-

ify the directory names returned by

readdir()

and

getcwd()

to make them consistent with a modiﬁed

ﬁle system view (sec. 4) deﬁned in the jailer’s policy.

In our jailer, post-system call processing is im-

plemented using a trampoline construction. When a

post-system call routine has to be invoked by the pris-

oner after a system call has been made, the jailer sets

the return address (program counter) of the invoking

prisoner thread to the address of a dispatcher routine

in the preloaded executable library. When the jailer

tells the kernel to proceed with execution of the call,

the operating system will resume the calling thread at

the modiﬁed return address after executing the system

call. As a result, the dispatcher routine is run, which

calls an appropriate handler routine. This is used to

modify the string returned by getcwd(), for exam-

ple. The dispatcher routine then returns to the original

prisoner’s return address. The dispatcher routine con-

tains 20 lines of assembly language to handle certain

architecture speciﬁc things, such as saving/restoring

registers according to the i386 convention. For the

rest, all the jailer code is written in C.

The trampoline construction is also invoked for

delegated calls. The

accept()

call is invoked by

the jailer, which checks the peer’s address after the

call was made

. After that, the jailer passes the ﬁle

descriptor to the prisoner. To implement this trans-

parently, the jailer lets the prisoner invoke a harm-

less getpid() call, followed by a trampoline instruction

that reads the ﬁle descriptor from the UNIX domain

socket.

recvmsg()

on a UDP socket also requires

In order for accept() delegation to be implementable,

listen must also be post-processed, such that the jailer ob-

tains a copy of the allocated ﬁle descriptor (via a UNIX do-

main socket) so that it can later do an

accept()

on this ﬁle

descriptor.

handling in the jailer, but only if the policy speciﬁes

a limited set of peers that may send datagrams to the

prisoner.

9 PERFORMANCE

In this section we show performance results for both

jailing systems that we implemented, the ptrace()-

based jailer and the kernel jailer. We use micro-

benchmarks to investigate and analyse the overhead

of some representative system calls, and present the

performance of three applications whose performance

is dominated by system calls, so they represent a ”bad

case” for jailers.

All experiments were conducted on an Athlon 64

3200+ with a Linux 2.6.13.2 kernel, compiled with

our kernel jailing patches. We present benchmark

measurements for the ptrace() jailer and the kernel

jailer. For comparison we present the same bench-

marks run outside the jail, and run under control of

strace, modiﬁed to intercept all system calls but to

generate no tracing output. This latter comparison

exactly shows the overhead incurred by the ptrace()

mechanism, and the time spent in the jailer can be de-

duced from it.

We also evaluate the effects of the optimizations

offered by the kernel jailer.

9.1 Microbenchmarks

Table 1 presents the performance of microbench-

marks that each invoke one system call in a tight loop.

The time presented is the average time for one system

call. Measurements are presented for unjailed bench-

marks, benchmarks run under the control of strace

with output disabled, and under control of our ptrace

and kernel jailers.

Geteuid

is a system call that takes no argument

and is always allowed by the jailer. This benchmark

shows that the impact of ptrace() intervention is con-

siderable in comparison to system call times; the over-

head is dominated by context switching between the

benchmark process, the kernel and the jailer. This

benchmark does not require any argument fetching

or rewriting, or nontrivial policy logic by the jailer;

accordingly, the extra time added by the jailing part

is small, 1µs. Because this system call is always al-

lowed, the kernel jailer immediately allows it without

consulting the user-space policy engine. Its perfor-

mance is therefore comparable to the unjailed case.

Stat

takes a ﬁlename ”junk” as an argument and

returns this ﬁle’s status. It requires securing of the

ﬁlename in ShRO and updating the register for this

SECRYPT 2007 - International Conference on Security and Cryptography

420

Table 1: Microbenchmarks of selected system calls. Time

is in µs per system call

Syscall Unjailed Ptrace Ptrace Kernel calls in

jail jail loop

geteuid

0.07 5.1 6.2 0.08 100000

stat

0.85 7.2 14.0 14.3 10000

getcwd

0.51 6.4 12.7 9.5 10000

91 169 537 466 1000

connect

98 178 508 466 1000

argument in the kernel. The jailer keeps track of the

prisoner’s current directory, and uses this to convert

the relative pathname to an absolute pathname. The

ptrace jailer requires two

ptrace

system calls to re-

trieve the 5-byte ﬁle name from the prisoner, where

the kernel jailer requires a

msgsnd

and a

msgrcv

call.

However, the latter calls are each more expensive than

ptrace

system call. The contribution to the over-

head of various parts of the jailer is analysed below.

Getcwd

returns the prisoner’s current working di-

rectory. It requires a rewrite of the returned direc-

tory name in the prisoner’s address space using a post-

syscall processing routine when the prisoner runs in a

change-rooted directory. In this case, only the post-

syscall routine is called, but no rewriting is neces-

sary. The ptrace jailer requires seven

ptrace

system

calls to retrieve the directory name, whereas the ker-

nel jailer requires only one pair of system calls. This

difference makes the kernel jailer substantially faster.

and

connect

show that these calls are ex-

pensive even outside a jail. For these benchmarks,

a client and a server program were run on the same

machine, one in a jail and one free. Each connec-

tion setup therefore already requires some process

switches between benchmark processes.

uses

delegation, so the resulting descriptor is returned to

the prisoner over a Unix domain socket.

Connect

requires freezing the argument in ShRO. Both in the

ptrace and the kernel jailer, accept causes more over-

head than connect, compared to the unjailed case. The

delegation mechanism (section 8) requires the use of

different threads in the jailer. For the ptrace jailer, the

difference between accept and connect is larger than

with the kernel jailer. We attribute this difference to

threading peculiarities of the ptrace mechanism.

Table 2 shows a breakdown of the various parts

of the jailer code for a

stat

system call, measured

by nanosecond timers inserted into the jailer code.

As we ﬁnd from the

geteuid

call, bookkeeping in

the jailer costs 1.1µs. Reading the ﬁle name from

the prisoner address space is implemented by read-

ing a word at a time with the

ptrace

system call,

and this is the largest of the jailer costs; for the ker-

Table 2: Breakdown of the time spent by the jailer for

stat

(in µs, averaged over 10000 runs.)

jailer ptrace kernel

intercept bookkeeping 1.1 1.1

read syscall args 1.02 2.35

canonicalize args 0.86 0.81

check pathname 0.52 0.54

update kernel registers 0.27 0.58

microtimers, various 0.69 0.54

total jailer costs 4.46 5.93

basic tracer overhead 6.35 unknown

system call 0.85 0.85

kernel extra 2.34 unknown

total time 14.0 14.3

nel jailer, an even more expensive pair of System-V

IPC

msgsnd/msgrcv

calls is done. Calculation of

the canonical path name and checking this against the

policy paths is also a noticeable contribution. Another

ptrace or kernel jailer system call is involved in copy-

ing the pointer that points to the immutable copy of

the ﬁle name (in ShRO) into the prisoner’s register set.

For the ptrace jailer, the time spent in the jailer should

equal the difference between a jailed system call and

an unjailed, ptraced system call. However, 2.34µs re-

main unexplained. We found that this difference must

be attributed to kernel peculiarities.

9.2 Macrobenchmarks

To measure the overall performance of the jailing sys-

tem, we ran three macrobenchmarks which empha-

size different aspects of the jailing system. All mac-

robenchmarks are nontrivial for a jailing system, as

they do a large number of system calls compared to

the time used for doing computations, as shown in ta-

ble 3. Many applications will require far fewer system

calls than the benchmarks presented here.

The ﬁrst macrobenchmark is a conﬁgure shell

script for the strace source code tree. This script exe-

cutes a number of programs which try out availability

of required functionality on the operating system. It

presents a worst-case scenario for the jailing system:

execve

calls imply preloading and setting up a new

ShRO region for the new process.

The second macrobenchmark is a build of this

jailer system itself using make. To ﬁnd out de-

pendencies and compile accordingly, make and its

spawned subprocesses must open many ﬁles and gen-

erate many new ﬁles. This benchmark is dominated

less by system call time than the conﬁgure script.

The third macrobenchmark is a Java build system

(ant) which compiles a large Java source tree, con-

A SECURE JAILING SYSTEM FOR CONFINING UNTRUSTED APPLICATIONS

421

Table 3: Results of an strace conﬁgure script, a make build, and a build of a large Java source tree using ant. Times in seconds,

between brackets the percentages overhead imposed by jailing.

Unjailed Ptrace Ptrace jail Kernel jail

system user total total total jailer upcalls total jailer upcalls

conﬁgure 2.2 3.4 6.7 9.14 (36%) 14.3 (113%) 367,320 11.7 (75%) 147,947

make build 3.5 10 14.6 19.0 (30%) 27.4 (88%) 598,770 24.0 (64%) 264,815

ant build 1.2 15.5 16.7 22.4 (34%) 24.5 (47%) 669,557 18.1 (8%) 62,562

sisting of 1005 Java source ﬁles of a total length of

181073 lines (5554227 bytes). These are are com-

piled to Java bytecode using the IBM 1.4 Java com-

piler and virtual machine. Ant is a multithreaded Java

program. Considerable time is spent both in compil-

ing the source code and in reading and writing ﬁles.

What these benchmarks show is that it is possible

to run nontrivial, multithreaded or multiprocess ap-

plications within a jail with reasonable performance.

The measured applications make a large number of

system calls. Despite that, the overhead imposed by

the ptrace-based jailer is no more than 113%. The

columns “jailer upcalls” in table 3 show the number of

times that the user-level jailer process is consulted for

a policy decision. With conﬁgure and make, the ker-

nel jailer is capable of deciding the system call verdict

immediately from its action table, without dispatch-

ing to the jailer process, for about half the number of

system calls made by the prisoner. As a result, the

jailing overhead drops to 75% for make for the ker-

nel jailer. A signiﬁcant part of the jailing overhead in

these cases, although more so for conﬁgure than for

make, is caused by the expensive

execve

call.

The Ant Java build system incurs signiﬁcantly less

ptrace jailer overhead (47%), and most of this is con-

sumed by ptrace: Ant does relatively few expensive

system calls. With the kernel jailer, the user-level

jailing program is only consulted for one tenth of all

system calls. The majority of system calls that is im-

mediately allowed is for manipulation of thread sig-

nal masks, which Java appears to do very frequently.

This leads to a signiﬁcant performance gain for the

kernel jailer. In conformance with the relative time

spent in user mode and system mode, the total over-

head for jailing Ant is much smaller than for the other

two benchmarks, in both jailing systems.

For the many applications that spend the major-

ity of their time in user mode, we expect that per-

formance will be better than the performance of the

above benchmark tests. Indeed, we veriﬁed with

some applications (e.g., gzip of large ﬁles, results not

shown) that jailing overhead drops to nearly zero for

both jailers if the application spends only a tiny frac-

tion of its time in system mode.

10 RELATED WORK

There exist a number of system call interception based

jailing systems which depend on operating system

modiﬁcations (Garﬁnkel et al., 2004; Peterson et al.,

2002). These solutions have obvious deployment

drawbacks. Systrace (Provos, 2003) is an exception in

that it is deployed in several open-source BSD UNIX

systems. Systrace requires manual policy generation

for each program, which limits its usability for con-

ﬁning previously unknown programs automatically.

Another class of jailing systems were built that run

on unmodiﬁed UNIX systems using standard debug-

ging support such as ptrace() or /proc (Goldberg et al.,

1996; Jain and Sekar, 2000; Alexandrov et al., 1999;

Liang et al., 2003). However, these systems suffered

from a number of race conditions that rendered these

systems insecure for the majority of modern multi-

threaded applications (Garﬁnkel, 2003). Our system

is the ﬁrst that solves these issues securely in user

mode.

An alternative to system-call level jailing is

language-based sandboxing such as provided by, for

example, Java or Safe-Tcl (Ousterhout et al., 1997).

Compared to language-based systems, system call in-

terception based jailing has the important advantage

of being language-independent. Also, getting a lan-

guage’s security model right is far from easy (Back

and Hsieh, 1999; Wallach et al., 1997). Jailing can

effectively safeguard users from vulnerabilities in any

language’s security enforcement mechanism.

Various operating system level techniques or new

oprating systems have been proposed to achieve better

security, ﬂexibility, or software fault isolation for dif-

ferent concurrently executing applications. Notable

examples are (Ghormley et al., 1998; Engler et al.,

1995; Mazi

eres and Kaashoek, 1997; Efstathopoulos

et al., 2005). Several of these designs could increase

security or software fault isolation. Contrary to these

approaches, we aim at supporting secure conﬁnement

on top of existing, standard UNIX platforms.

Virtual machine approaches such as FreeBSD

jail (Kamp and Watson, 2000), VMware or Xen

(Dragovic et al., 2003) can also be used to conﬁne ap-

plications. However, virtual machines are relatively

SECRYPT 2007 - International Conference on Security and Cryptography

422

heavy-weight, which makes them unsuitable for iso-

lating a very large number of concurrently executing

programs individually.

11 CONCLUSION

The jailing system presented in this paper provides

a simple but effective jailing model that allows users

to run untrusted programs securely. Our solution is

the ﬁrst that presents an effective and secure solution

for alleviating shared memory and ﬁle system race

conditions, without requiring kernel support for se-

curing system call arguments. This solution is based

on copying sensitive system call arguments to a user-

level shared memory region to which the prisoner has

read-only access, before allowing the system call to

continue. This solution is in principle portable to any

(POSIX compliant) UNIX system, given that it has

rudimentary system call tracing support such as the

ptrace() or /proc system call tracing interfaces.

By differentiating between resources created in-

side and outside the jail, our jailing system has a

clear model for deciding which system calls to ac-

cept or deny, even when a system call takes a runtime-

determined kernel object as an argument. Actions that

inﬂuence the outside world are guarded by a simple,

user-deﬁned policy. Policy modiﬁcation, in particu-

lar to adapt the policy to the local system’s directory

structure, is straightforward, and generally required

only once. We have found that we can safely exe-

cute many programs (also nontrivial, multithreaded

programs that make a large number of system calls,

or programs executed from a script) in our jailing sys-

tem using the default policy. The overhead of our jail-

ing system is acceptable, although this depends on the

type of system calls made by a prisoner. Performance

is competitive compared to existing user-mode jailing

systems.

REFERENCES

Alexandrov, A., Kmiec, P., and Schauser, K. (1999). Consh:

Conﬁned execution environment for internet com-

putations. http://www.cs.ucsb.edu/˜berto/papers/99-

usenix-consh.ps.

Back, G. and Hsieh, W. (1999). Drawing the red line in

java. Workshop on Hot Topics in Operating Systems

(HotOS VII). pp. 116-121.

Dragovic, B., Fraser, K., Hand, S., Harris, T., Ho, A.,

Pratt, I., Warﬁeld, A., Barham, P., and Neugebauer., R.

(2003). Xen and the art of virtualization. Proc. ACM

Symposium on Operating Systems Principles (SOSP).

Efstathopoulos, P., Krohn, M., VanDeBogart, S., Frey, C.,

Ziegler, D., Kohler, E., Mazi

eres, D., Kaashoek, F.,

and Morris, R. (2005). Labels and event processes in

the asbestos operating system. Proc. 20th Symposium

on Operating Systems Principles (SOSP), Brighton,

United Kingdom.

Engler, D., Kaashoek, M., and O’Toole Jr., J. (1995).

Exokernel: an operating system architecture for

application-speciﬁc resource management. Proc. Fif-

teenth ACM Symposium on Operating Systems Princi-

ples (SOSP). pp. 251-266.

Garﬁnkel, T. (2003). Traps and pitfalls: Practical problems

in system call interception based security tools. Proc.

Symposium on Network and Distributed System Secu-

rity (NDSS). pp. 163-176.

Garﬁnkel, T., Pfaff, B., and Rosenblum, M. (2004). Ostia:

A delegating architecture for secure system call inter-

position. Proc. ISOC Network and Distributed System

Security Symposium (NDSS).

Ghormley, D., Rodrigues, S., Petrou, D., and Anderson., T.

(1998). Slic: An extensibility system for commodity

operating systems. USENIX 1998 Annual Technical

Conference.

Goldberg, I., Wagner, D., Thomas, R., and Brewer, E.

(1996). A secure environment for untrusted helper

applications - conﬁning the wily hacker. Proc. 6th

Usenix Security Symposium. San Jose, CA, USA.

Jain, K. and Sekar, R. (2000). User-level infrastructure

for system call interposition: A platform for intrusion

detection and conﬁnement. ISOC Network and Dis-

tributed System Security Symposium (NDSS). pp. 19-

34.

Kamp, P. and Watson, R. (2000). Jails: Conﬁning the om-

nipotent root. Proc. 2nd Intl. SANE Conference.

Liang, Z., Venkatakrishnan, V., and Sekar, R. (2003). Iso-

lated program execution: An application transpar-

ent approach for executing untrusted programs. 19th

Annual Computer Security Applications Conference

(ACSAC), Las Vegas, Nevada.

Mazi

eres, D. and Kaashoek, M. (1997). Secure applica-

tions need ﬂexible operating systems. Workshop on

Hot Topics in Operating Systems (HotOS).

Ousterhout, J., Levy, J., and Welch., B. (1997). The safe-

tcl security model. Sun Microsystems Laboratories

Technical Report TR-97-60.

Peterson, D., Bishop, M., and Pandey, R. (2002). A ﬂexible

containment mechanism for executing untrusted code.

Usenix Security Symposium.

Provos, N. (2003). Improving host security with system call

policies. Proc. 12th USENIX Security Symposium. pp.

257-272.

van ’t Noordende, G., Balogh, A., Hofman, R., Brazier, F.,

and Tanenbaum, A. (2006). A secure and portable jail-

ing system. Technical report IR-CS-025, Vrije Univer-

siteit.

Wallach, D., Balfanz, D., Dean, D., and Felten, E. (1997).

Extensible security architectures for java. 16th ACM

Symposium on Operating Systems Principles. pp. 116-

128.

A SECURE JAILING SYSTEM FOR CONFINING UNTRUSTED APPLICATIONS

423
