A NEURAL NETWORK-BASED SYSTEM FOR FACE

DETECTION IN LOW QUALITY WEB CAMERA IMAGES

Ioanna-Ourania Stathopoulou and George A. Tsihrintzis

Department of Informatics,University of Piraeus, Piraeus 185 34, Greece

Keywords: Face Detection, Multidimensional Signal Processing, Biometrics and Pattern Recognition, Neural Networks.

Abstract: The rapid and successful detection and localization of human faces in images is a prerequisite to a fully

automated face image analysis system. In this paper, we present a neural network–based face detection

system which arises from the outcome of a comparative study of two neural network models of different

architecture and complexity. The fundamental difference in the construction of the two models lies in

approaching the face detection problem either by seeking a general solution based on the full-face image or

by composing the solution through the resolution of specific portions/characteristics of the face. The

proposed system is based on the brightness contrasts between specific regions of the human face. We show

that the second approach, even though more complicated, exhibits better performance in terms of detection

and false-positive rates. We tested our system with low quality face images acquired with web cameras. The

image test set includes both front and side view images of faces forming either a neutral or one of the

“smile”, “surprise”, “disgust”, “scream”, “bored-sleepy”, “angry”, and “sad” expressions. The system

achieved high face detection rates, regardless of facial expression or face view.

1 INTRODUCTION

Automated detection of human faces is one of the

most difficult and important problems in the areas of

pattern recognition and computer vision. Images that

contain faces are instrumental in the development of

more effective and friendlier methods for human-

computer interaction. Vision-based human computer

interaction methods assume that information about a

user’s identity, state and intent can be extracted from

images, and that computers can then react

accordingly. This information can also be used in a

security control system to replace metal key,

password, plastic card, or PIN number. Moreover, it

can be used in criminology to uncover criminals.

Finally, automated face detection is important in the

area of biometric authentication, i.e., technologies

that measure and analyze human physical and

behavioural characteristics for authentication

purposes.

Given an image, the goal of face detection is to

determine whether there are any faces in the image

and, if so, return the face location and extent. Such a

problem is challenging because faces are not rigid

and have a high degree of variability in size, shape,

colour and texture. Furthermore, variations in pose,

facial expression, image orientation and conditions

add to the problem.

There have been developed three main approaches to

the face detection problem, based on: (1) correlation

templates, (2) deformable templates, and (3) image

invariants, respectively. Correlation template-based

approaches compute a difference measurement

between one or more fixed target patterns and

candidate image locations and the output is

thresholded for matches. The use of deformable

templates is similar in principle to the use of

correlation templates, except that the latter are not

rigid. In this approach, we try to find mathematical

and geometrical patterns that depict particular

regions of the face, fit the template to different parts

of the images and threshold the output for matches.

Finally, in image invariant-based approaches, the

aim is to find structural features that exist even when

pose, viewpoint and lighting conditions vary, and

then use them to detect faces.

In the past, several systems have been developed

that implement the above approaches. The system

proposed by Colmenarez et al. is template-based and

attempts to encode face images into a particular

prototype (Colmenarez and Huang, 1997). Yang et

al. (Yang and Huang 1994) and Lee et al. (Lee, Ham

and Park, 1996) proposed knowledge-based systems

Stathopoulou I. and A. Tsihrintzis G. (2007).

A NEURAL NETWORK-BASED SYSTEM FOR FACE DETECTION IN LOW QUALITY WEB CAMERA IMAGES.

In Proceedings of the Second International Conference on Signal Processing and Multimedia Applications, pages 53-58

DOI: 10.5220/0002134100530058

 SciTePress

that encode human knowledge of what constitutes a

face. Leung et al. (Leung, Burl and Perona, 1995).

applied a local feature detector to find faces in an

image. Other systems ( Rowley et al, 1997; Rowley

et al, 1998; Yang and Huang 1994; Juell et al., 1996)

use artificial neural networks to find faces. Lin et al.

(Lin and Fan, 2001) proposed a system that searches

for potential face regions, based on the triangle that

form the eyes and the mouth. Sung et al. (Sung and

Poggio, 1994) used metrics that measure the

distance between the input image and the cluster of

faces and non-faces. Lin Huang et al. (Huang and

Shimizu, 2006) designed three detection experts

which employ different feature representation

schemes of local image and then use a polynomial

neural network to determine whether or not there is a

face in an image. Castrillon et al. (Castrillon et al.,

2007) developed a system for real time detection of

faces in video sequences by means of cue

combination. S. Phimoltares et al. (Phimoltares,

Lursinsap and Chamnongthai, 2007) developed a

two-stage system, which first detects the faces from

an original image by using Canny edge detection

and their proposed average face templates and then

uses a neural visual model (NVM) to recognize all

possibilities of facial feature positions. Kadoury and

Levine (Kadoury and Levine, 2007) proposed a

novel technique which uses locally linear embedding

(LLE) to determine a locally linear fit so that each

data point can be represented by a linear

combination of its closest neighbors and use this

representation to train Support Vector Machines that

detect faces.

Most of the aforementioned methods limit

themselves to dealing with human faces in front

view. There are several drawbacks in these

approaches, such as: (1) They cannot detect a face,

which is smaller than 50 * 50 pixels. (2) They

cannot detect many faces (more than 3 faces) in

complex backgrounds. (3) They cannot detect faces

when we have images with defocus and noise

problems. (4) They cannot all address the problem of

partial occlusion of mouth or wearing sunglasses. (5)

It is not easy to detect faces in side view. Although

there are some researches that can solve two or three

of these problems, there is still no system that can

solve all of them.

In this paper, a new and efficient human face

detection system is proposed that combines artificial

neural networks and image invariants approaches.

Specifically, in Section 2, we present our face

detection algorithm. In Section 3, we discuss the

structures of two neural networks, which have

different performances. In Section 4, we present the

face image data acquisition geometry and evaluate

the performance of the two networks. Finally, we

draw conclusion in Section 5 and point to future

work in Section 6.

2 THE FACE DETECTION

ALGORITHM

Our system uses face detection algorithms which fall

within the third approach mentioned above.

Specifically, we define certain image invariants and

use them to detect faces by feeding them into an

artificial neural network. These image invariants

were found based on Sinha’s (Sinha, P.; Yang and

Ahuja, 2003) 14-by-16 pixel ratio template,

summarized next.

2.1 The Sinha Template

The method proposed by P. Sinha (Sinha, P.; Yang

and Ahuja, 2003) combines template matching and

image invariant approaches. P. Sinha aimed at

finding a model that would satisfactorily represent

some basic relationships between the regions of a

human face. More specifically, he found out that,

while variations in illumination change the

individual brightness of different parts of faces (such

as eyes, cheeks, nose and forehead), the relative

brightness of these parts remains unchanged. This

relative brightness between facial parts is captured

by an appropriate set of pairwise brighter - darker

relationships between sub-regions of the face.

Figure 1: The Sinha Template.

The Sinha template is shown in Figure 1, where we

observe 23 pair-wise relationships represented by

arrows. The darker and brighter parts of the face are

represented by darker and brighter shades of grey,

respectively.

Our proposed face detection algorithm is built on

this model. We pre-process a candidate image in

order to enhance the relationships in the Sinha

template and then feed the image into an artificial

SIGMAP 2007 - International Conference on Signal Processing and Multimedia Applications

neural network to determine whether or not there is a

face in the image.

2.2 The Algorithm

The main goal is to find the regions of the candidate

image that contain human faces. Our system uses

Artificial Neural Networks and operates in two

modes: training the neural network and using it to

detect faces in an image.

To train the neural network, we used a set of 285

images of faces and non-faces. We tried to find

images of non-faces that are similar to human faces,

so some of the non-face images contained dog,

monkey and other animal “faces”. These images

where gathered from sources of the World Wide

Web (Gender Classification (Databases)) and pre-

processed before entered into the neural network.

To detect faces in a candidate image we apply a

window, which scans the entire image, and pre-

process each image region, the same way we pre-

processed the images of the training set.

Specifically, our algorithm works as follows:

1. We load the candidate image. It can be any 3-

dimensional (color) image

2. We scan through the entire image with a 35-by-

35 pixel window. The image region defined by

the window constitutes the “window pattern”

for our system, which will be tested to

determine whether it contains a face. We

increase the size of the window gradually, so as

to cover all the possible sizes of a face in a

candidate image.

3. We pre-process the “window pattern”:

3.1. We apply Histogram Equalization

techniques to enhance the contrast within

the “window pattern”.

3.2. We compute the eigenvectors of the image

using the Principal Component Analysis

and the Nystrom Algorithm ((Fowlkes,

Belongie and Malik; Belongie, 2000; Shi

and Malik, 2000; Image Segmentation

using the Nystrom Method) to compute the

normalized cuts.

3.3. We compute three clusters of the image

using the k-means algorithm and color

each cluster with the average color.

3.4. We convert the image from colored to

grayscale (2D).

4. We resize the processed image into a dimension

of 20-by-20 pixels and use it as input to the

artificial neural network, which we present in

the next section.

3 THE ARTIFICIAL NEURAL

NETWORK STRUCTURES

To classify window patterns as “faces” or “non-

faces”, we developed two different artificial neural

networks, which are presented next.

3.1 The First Artificial Neural Network

This network takes as input the entire window

pattern and produces a two-dimensional vector

output. The network consists of three hidden layers

of thirty, ten and two neurons respectively, as in

Figure 2. Its input (“window pattern”) has dimension

of 20-by-20 pixels. The neural network classifies the

window pattern as “face” or “non-face”. The output

vector is of dimension 2-by-1 and equals to [1;0] if

the window pattern represents a face or [0;1], else

wise.

Figure 2: The First ANN’s Structure.

3.2 The Second Artificial Neural

Network

The second neural network has four hidden layers

with one, four, four and two neurons, respectively. It

is fed with the following input data: (1) the entire

“window pattern” (20-by-20 pixels), (2) four parts of

the “window pattern”, each 10-by-10 pixels and (3)

another four parts of the “window pattern”, 5-by-20

pixels. Each of the three types of inputs is fed into

different hidden layers of the network. The first,

second, and third sets of inputs are fed into the first,

second, and third hidden layer, respectively, while

the output vector is the same as for the first network.

Clearly, the first network consists of fewer hidden

layers with more neurons and requires less input

data compared to the second.

A NEURAL NETWORK-BASED SYSTEM FOR FACE DETECTION IN LOW QUALITY WEB CAMERA IMAGES

Figure 3: The Second ANN’s Structure.

4 PERFORMANCE EVALUATION

4.1 Test Data Acquisition

The test image data were acquired with a three-

camera system, as in Figure 4. Specifically, three

identical cameras of 320-by-240 pixel resolution

were placed with their optical axes on the same

horizontal plane and successively separated by 30-

degree angles. Subjects were asked to form facial

expressions, which were photographed by the three

cameras simultaneously.

Figure 4: The geometry of the data acquisition setup.

The final dataset consisted of 250 different subjects,

each forming the eight expressions: “neutral”,

“smile”, “sad”, “surprise”, “angry”, “disgust”,

“scream” and “bored-sleepy”. Typical example

images are shown in Table 3.

4.2 Performance Evaluation

To train the system networks, we used a common

training set of 285 face and non-face images of

relatively high quality. During the training process,

the first and second networks reached an error rate

of 10

-1

and 10

-10

, respectively.

We required that, for both networks, the output

vector value be close to [1;0] when the window

pattern represented a face and [0;1] otherwise. This

means that the output vector corresponds to the

degree of membership of the image in one of the two

clusters: “face-image” and “non-face-image”.

We tested the two networks with average quality

face images first. Some results of the two neural

networks can be seen in Table 1. The first network,

even though it consisted of more neurons than the

second one, did not detect faces in the images to a

satisfactory degree, as did the second network. On

the other hand, the execution speeds of two networks

are comparable. Therefore, the second network was

found superior in detecting faces in images and was

decided to be used in our system.

Table 1: Results of the two neural networks for various

images.

Input image

Pre-

processed

window

pattern

First

ANN’s

output

Second

ANN’s

output

[0.5;

0.5]

[0.947;

0.063]

[0.6;

0.4]

[ 1 ; 0 ]

[0.5;

0.5]

[0.9717;

0.0283]

[0.5;

0.5]

[ 0 ; 1 ]

[0.5;

0.5]

[ 0 ; 1 ]

[0.5;

0.5]

[ 0 ; 1 ]

SIGMAP 2007 - International Conference on Signal Processing and Multimedia Applications

4.3 Evaluation on Low Quality face

Images

The aim of this evaluation was to examine whether

the neural network was able to generalize

satisfactorily with low quality face images and/or

with the subject forming facial expressions and/or

images acquired in side view. For this purpose, we

tested our face detection system with 535 of the face

images acquired with the three-camera system in

Section 4. The dataset included a random selection

of images in front and side view and images

acquired from subjects forming one of the eight

expressions: “neutral”, “smile”, “sad”, “surprise”,

“angry”, “disgust”, “scream” and “bored-sleepy”.

Table 2: Face detection results for male and female face

images.

Face Detection Results

Genre

Face

Detected

Face no

Detected

Success

percentage

rate

Female

115 90 56,09%

Male

275 55 83,33%

Sum

390 145

72,89%

The system managed to detect face with 72,89%

success rate. Errors (misses) occurred mostly

because of overly bright illumination conditions

which did not allow the extraction of facial features

during k-means clustering.

Table 3: Application of the proposed algorithm on low

quality images.

It was also observed that the detection of female

faces was more difficult than the detection of male

faces, possibly because facial features in female

faces are not as tense as those in male faces. The

results from these two groups are summarized in

Table 2.

Some typical results of the face detection system are

depicted in Tables 3 and 4. In Table 3, we show

some results of applying the Face Detection

Algorithm on the low quality web camera face

images. In Table 4, we show the results of applying

the algorithm to more complex images containing

several rotated and partially occluded faces.

Table 4: Application of the proposed algorithm on two

images.

6/8

2/2

5 SUMMARY AND

CONCLUSIONS

In this work, we presented a neural network-based

face detection system and tested it on low quality

images acquired with a web camera set up. Although

the neural network had been trained with a set of

higher (digital camera) quality of images, it was able

to generalize and detected the faces in images at a

satisfactory rate. Occasionally, errors (e.g., failure to

detect all faces in an image) occurred, especially

with faces whose characteristics were not so clear.

However, the system performance is expected to

improve by widening the training set of the network.

Original Image

Window

Pattern

Pre-

processed


Network’s

Response

[1;0]

[0,836;

0,164]

[0,9531;

0,0469]

A NEURAL NETWORK-BASED SYSTEM FOR FACE DETECTION IN LOW QUALITY WEB CAMERA IMAGES

6 FUTURE WORK

We plan to extend our work in the following three

directions: (1) We will improve our system by

retraining the neural network with a set that covers a

wider range of poses and cases of low quality

images. (2) We will examine face localization

techniques localization to make the face detection

task more rapid (3) Wee will integrate this system

with a fully automated facial expression

classification system, which we currently

developing.

ACKNOWLEDGEMENTS

Support for this work was provided by the General

Secretariat of Research and Technology, Greek

Ministry of Development, under the auspices of the

PENED-2003 basic research program.

REFERENCES

Belongie S. (2000). “Notes on Clustering Point-sets with

Normalized Cuts”.

Castrillon, M. et al. (2007). ENCARA2: Real-time

detection of multiple faces at different resolutions in

video streams, Journal of Visual Communication and

Image Representation –In Press.

Colmenarez, A. J. and Huang, T.S. (1997). “Face

detection with information-based maximum

discrimination”, Computer Vision and Pattern

Recognition, 782–787.

Gender Classification (Databases):

http://ise0.stanford.edu/class/ee368a_proj00/project1

5/intro.html

http://ise0.stanford.edu/class/ee368a_proj00/project1

5/append_a.html

Fowlkes, C., Belongie, S. and Malik, J. ” Efficient

Spatiotemporal Grouping Using the Nystrom Method”

Huang, Lin-Lin and Shimizu, Akinobu (2006). A multi-

expert approach for robust face detection. Pattern

Recognition 39(9): 1695-1703.

Image Segmentation using the Nystrom Method:

http://rick.ucsd.edu/~bleong/.

Juell, P. and Marsh, R. (1996). “A hierarchical neural

network for human face detection”, Pattern

Recognition 29 (5), 781-787.

Kadoury, Samuel and Levine, Martin D. (2007). “Face

detection in gray scale images using locally linear

embeddings”, Computer Vision and Image

Understanding, 105: 1–20.

Lee, S.Y., Ham, Y.K., Park, R.H. (1996). “Recognition of

human front faces using knowledge-based feature

extraction and neuro-fuzzy algorithm”, Pattern

Recognition 29,1863-1876 (11) .

Leung, T.K., Burl, M.C. and Perona, P. (1995). “Finding

faces in cluttered scenes using random labeled graph

matching”, Fifth International Conference on

Computer Vision, pages 637–644, Cambridge,

Massachusetts, IEEE Computer Society Press.

Lin, C. and Fan, K. (2001). “Triangle-based approach to

the detection of human face”, Pattern Recognition 34,

1271-1284.

Phimoltares, S., Lursinsap, C., Chamnongthai, K. (2007,

May). “Face detection and facial feature localization

without considering he appearance of image context”,

Image and Vision Computing Volume 25 , Issue 5:

741-753.

Rowley, H.A., Baluja, S., and Kanade T. (1997).

“Rotation Invariant Neural Network-Based Face

Detection” CMU-CS-97-201.

Rowley, H.A., Baluja, S., and Kanade T. (1998). “Neural

Network-based face detection”, IEEE Transactions on

Pattern Analysis and Machine Intelligence, 20(1).

Shi, J. and Malik, J. (2000). “Normalized Cuts and Image

Segmentation”, IEEE Transactions On Pattern

Analysis and Machine Intelligence, Vol. 22(8).

Sinha, P. “Object Recognition via image-invariants”.

Sung, K.K., Poggio, T. (1994). “Example-based learning

for view-based human face detection”, Proceedings on

Image Understanding Workshop, Monterey, CA, 843-

850.

Yang, G. and Huang, T.S. (1994). “Human face detection

in a complex background”, Pattern Recognition,

27(1):53–63 .

Yang, M.–H., Ahuja, N. (2003). “Face Detection and

Gesture Recognition for Human- computer

Interaction”, Kluver Academic Publishers.

SIGMAP 2007 - International Conference on Signal Processing and Multimedia Applications
