DATA MINING CLUSTERING TECHNIQUES IN ACADEMIA

Vasile Paul Breşfelean, Mihaela Breşfelean, Nicolae Ghişoiu

Babeş-Bolyai University, Faculty of Economics and Business Administration, Teodor Mihali 58-60

400591,Cluj-Napoca, România

Călin-Adrian Comes

Petru Maior University, Nicolae Iorga 1,540088, Târgu-Mureş, România

Keywords: Cluster, data clustering, K-means algorithm, students, analysis, percentage relation.

Abstract: In the present paper the authors exemplify the connections among the undergraduate studies, continuing

education and professional enhancement on the foundations required by Romania’s integration in EU’s

structures. The study was directed to the senior undergraduate students and master degree students from the

Faculty of Economics and Business Administration, Babeş-Bolyai University of Cluj-Napoca, using

questionnaires in a collaborative approach, and processing the collected data by data mining clustering

techniques, graphical and percentage representations, through Weka’s implemented algorithms.

1 INTRODUCTION

Clustering is one of the fundamental operations in

data mining and can be defined as the process of

organizing objects in a database into clusters/groups

such that objects within the same cluster have a high

degree of similarity, while objects belonging to

different clusters have a high degree of dissimilarity

(San et al, 2004).

The notion of similarity can be expressed in very

different ways, according to the purpose of the

study, to domain-specific assumptions and to prior

knowledge of the problem (Grira et al, 2005).

Clustering divides, or partitions, a data set into

regions of high similarity, as defined by some

distance metric, called clusters. In most instances, a

cluster is identified by a prototypical vector called

the cluster center. Therefore, the problem of cluster

optimization is twofold: optimization of cluster

centers and number of clusters (Lee and Antonsson).

This process has developed into a widely studied

problem in a diversity of application areas, such as

data mining and knowledge discovery, statistical

data analysis, data classification and compression,

medical image processing and bioinformatics (Hung

et al, 2005).

In this article, the authors illustrate a series of

analysis and correlations conducted through

clustering techniques on Weka workbench, graphical

and percentage representations, over significant data

collected from senior undergraduate students and

master degree students at the Faculty of Economics

and Business Administration Cluj-Napoca.

2 THE CLUSTERING

ALGORITHM

The clustering algorithms can be categorized along

different dimensions (Zhao and Karypis, 2005)

based either on the underlying methodology of the

algorithm; the structure of the final solution; the

characteristics of the space in which they operate; or

the type of clusters that they discover.

Clustering algorithms generally follow

hierarchical or partitional approaches. Several

algorithms have been proposed in the literature for

clustering among whom the K-means and its

variants, such as the fuzzy c-means algorithm, are

the most popular algorithms.

In our research we used the clustering method

called FarthestFirst which implements the

transversal algorithm of Hochbaum and Shmoys,

quoted by Sanjoy Dasgupta (Witten and Frank,

2005), a simple, fast, approximation method based

on K-means algorithm. The general algorithm was

407

Paul Bre¸sfelean V., Bre ¸sfelean M., Ghi ¸soiu N. and Comes C. (2007).

DATA MINING CLUSTERING TECHNIQUES IN ACADEMIA.

In Proceedings of the Ninth International Conference on Enterprise Information Systems - AIDSS, pages 407-410

DOI: 10.5220/0002370404070410

 SciTePress

introduced by Cox in 1957, and it was first named

K-means by Ball and Hall, and MacQueen in 1967,

and since then it has become widely popular and is

classified as a partitional or non-hierarchical

clustering method (San et al, 2004).

The K-means algorithm gives good results only

when the initial partitioning is close to the optimal

solution (Hourani et al, 2004).In the FarthestFirst in

order to find k cluster centers, must follow the steps:

1. randomly choose one point as the first center

2. for i = 2 up to k

next center = point with maximal min-

distance to current centers.

3 DATA CLUSTERING AND

ANALYSIS

3.1 The Undergraduate Senior

Students’ Questionnaire

In our studies we used data collected from senior

undergraduate ad master degree students at the

Faculty of Economics and Business Administration

in Cluj-Napoca, using on-line and written surveys in

a collaborative approach, in the attempt to appraise

the impulse in preferring a certain the specialization,

the contentment upon the educational process and

cognitive skills and to evaluate their motivation in

continuing their education with post university

studies (master degree, Ph.D. studies). The collected

data was drawn off in Excel worksheets, resulting

400 articles with 35 attributes (Breşfelean et al,

2006). Our study work is based on Weka, a

machine-learning library developed at the University

of Waikato, providing Java implementations of

several methods for machine learning, data

preprocessing, and evaluation, and using the

Attribute-Relation File Format (ARFF) for input of

training and testing data.

3.1.1 Clustering and Cluster Representation

Using the FarthestFirst clustering method based on

K-means algorithm, we initialized the k cluster

centers to k randomly chosen points from the data,

which was partitioned based on the minimum

squared distance criterion (Maulik and

Bandyopadhyay, 2002). In our experiment, the k

parameter is 3, corresponding to students’ 3 choices

in continuing their post university studies: disagree,

neutral, agree. The cluster centers were then updated

to the mean or the centroid of the points belonging

to them. This entire process was repeated until either

the cluster centers did not alter or there was no

major change in the J values of two successive

iterations. At this point, the clusters were stable and

the clustering process ended.

By using the clustering process we separated the

students in clusters with dissimilar behavior, the

students from the same cluster embrace the closest

behavior, and the ones from different clusters have

the most different one. This process will help the

higher education institution to elaborate the most

efficient strategies for individuals (Breşfelean,

2006), (UBB, 2003), without the need to deal with

each individual student.

The students were divided into 3 clusters

(Breşfelean et al, 2006) each presenting specific

centroids, with a optimistic result after Weka

validation (27.4151 % of the instances were

incorrectly clustered):

Cluster 0: Students agree to continue their post

university studies (master degree, Ph.D. studies);

Cluster 1: Students do not agree to continue their

post university studies;

Cluster 1: Students are neutral to continue their post

university studies.

The present paper is focused on the students

belonging to Cluster 1 (the most unenthusiastic in

continuing their education), characterized by the

following choices:

-belong to the Marketing department (Mk);

-they do not agree to continue their education;

-gender: female;

-graduated a agricultural specialization high school;

-do not agree their expectations regarding the

specialization are fulfilled;

-are not satisfied with the fundamental knowledge

they obtained;

-do not agree they were given sufficient books,

course materials, case studies of the highest quality;

-do not agree the curricula were relaxed and gave

time to individual studying;

-are neutral regarding the fact that the faculty has a

good quality endowment;

-do not agree they have made contact to

specialization’s real problems, in curricula’s

practical activities;

-did not take part to grants/research contracts;

-do not agree to recommend the specialization to

future students;

-have a bad opinion about courses teaching methods

in the years of study;

-have a part-time job;

-do not benefit at all of parents’ material support;

-believe to find a job in Romania in Mk;

ICEIS 2007 - International Conference on Enterprise Information Systems

408

-scholastic situation: 3-4 exams were not passed.

The needed information is extracted from the

clusters’ centroids. Following this, we determined

that there were no common values fields for the

three clusters, and as a result all the fields contain

relevant information for the segmentation process.

“Programa_relax” attribute (opinion on relaxed

curricula) plays a substantial part in differentiating

the clusters population: cluster 0 - agree; cluster 1 -

disagree; cluster 1 - neutral. The same situation is

observed in the case of the following attributes:

”Asteptari” (opinion on expectations’ fulfillment

regarding the specialization), ”Recomanda” (opinion

on recommending the specialization to future

students), and the opinion on the quality of courses

teaching methods in the first and the last years of

study (“Anul_1” and “Anul_4”).

In order to obtain a graphical representation

(Figure 1) on the clusters (Breşfelean et al, 2006),

we chose 2 of the most significant attributes

(Programa_relax – opinion on relaxed curricula, and

Anul_4 – opinion on the 4th year of study).

Figure 1: Cluster graphical representation -dependent on

Programa_relax and Anul_4 attibutes.

3.2 Correlations with the Master

Degree Questionnaires

The understanding of students’ opinions,

satisfactions and discontentment regarding the each

component of the educational process, and the

option in continuing their education is a necessary

concern for every higher education institution

manager. It is important to associate the data

extracted from terminal year students’

questionnaires with graduate students’ data, at

present master degree students. Using the

information mined in the master degree

questionnaires, we prepared the next correlations

and analysis (Breşfelean et al, 2006): correlations

and percentage relations between the graduated

specialization and the master degree specialization,

between the current job and the graduated

specialization, between the current job and the

master degree specialization.

In the next table we present the data mined from

the master degree questionnaires, filtered to include

only the students from Mk master degree area.

Table 1: Mk master degree students on specific

cathegories.

Cathegories

No. of

studen

Total Mk master degree students 40

Total Mk specialization graduates (40%) 16

Total other than Mk graduates (60%) 24

Job in other areas than the graduated

specialization

Similar job to the graduated specialization 9

Job in other areas than the master degree

specialization

Similar job to the master degree

specialization

Unemployed Mk master degree students 20

The following figures cover the correlations

linking diverse features of the research:

Figure 2: Correlation between the current job and the

graduated specialization.

Figure 3: Correlation between the current job and the

master degree specialization.

4 CONCLUSIONS

From the data clustering, analysis, correlation and

percentage relations presented in this study, we can

conclude that: - An important segment of the

DATA MINING CLUSTERING TECHNIQUES IN ACADEMIA

409

undergraduate senior Mk students are reluctant on

continuing their education;

- A small percent (22,5%) of the Mk master degree

students found a similar job to the graduated

specialization, and 17,5% of Mk master degree

students have an occupation similar to the master

specialization;

- Half of the Mk master degree students (50%) are

unemployed for different reasons, not mentioned in

the questionnaires;

- There is a tendency in the Mk master degree area

to attract a large number of graduate students from

other areas (60%) because of the financial support

obtained from different companies, banks etc.

Our research in the data mining area and

students’ behavior start with the clustering

techniques (Bresfelean et al, 2006) and continue

with decisional trees, various correlation with the

data extracted from the master degree students to

exemplify detailed behavioral models.

ACKNOWLEDGEMENTS

This paper was partially supported by the Faculty of

Economics and Business Administration, by the

CNCSIS Consortium Grant 8/2005, “Collaborative

Information Systems in the Global Economy” and

by the Babeş-Bolyai University Priority Themes

Grant 2/2005, “Collaborative Decision Support

Systems in Academic Environments”.

REFERENCES

Angelini, L., Nitti, L., Pellicoro, M., Stramaglia, S., 2001.

Cost functions for pairwise data clustering. Physics

Letters A 285, 279–285, 2001

Bação, F., Lobo, V., Painho, M., 2004. Clustering census

data: Comparing the performance of self-organising

maps and k-means algorithms. KDNet Symposium,

Knowledge-based Services for the Public Sector,

Bonn, Germany, June 2004

Breşfelean, V.P., 2006. Development Strategies for The

Universities’ Management Using Information And

Communication Technologies, InfoBUSINESS'2006

International Conference, "Alexandru Ioan Cuza"

University of Iaşi, Iaşi, Romania, 2006

Breşfelean, V.P., Breşfelean, M., Ghişoiu, N., Comes,

C.A., 2006. Continuing education in a future EU

member, analysis and correlations using clustering

techniques, Proceedings of EDU '06 International

Conference, Tenerife, Spain, December 2006, 195-200

Ghişoiu, N., Breşfelean, V.P., Faur,G., Vereş, O., 2006.

Collaborative Software Systems, The 3rd international

Workshop IE&SI, Timişoara, Editura Mirton, 2006

Grira, N., Crucianu, M., Boujemaa, N., 2005.

Unsupervised and Semi-supervised Clustering: a Brief

Survey. Review of Machine Learning Techniques for

Processing Multimedia Content, Report of the

MUSCLE European Network of Excellence (6th

Framework Programme). August 15, 2005

Hinneburg, A., Keim, D. A., 2000. Clustering Techniques

for Large Data Sets, From the Past to the Future.

University of Halle, PKDD 2000

Hung, M. C., Wu, J., Chang, J.H., Yang, D. L., 2005. An

Efficient K-Means Clustering Algorithm Using Simple

Partitioning. Journal of Information Science and

Engineering 21, 1157-1177, 2005

Jain, A.K., Murty, M.N., Flynn, P.J., 1999. Data

clustering: a review, ACM Computing Surveys 31,

1999

Jung, Y., Park, H., Du, D.Z., Drake, B., 2003. A Decision

Criterion for the Optimal Number of Clusters in

Hierarchical Clustering, Journal of Global

Optimization 25: 91–111, Kluwer Academic

Publishers 2003

Koren, Y., Harel, D., 2003. A Two-Way Visualization

Method for Clustered Data. KDD’03 Washington, DC,

USA, ACM 2003

Lee, C.-Y., Antonsson, E.K., 2000. Dynamic Partitional

Clustering Using Evolution Strategies, Proceedings of

the Third Asia Pacific Conference on Simulated

Evolution and Learning

, IEEE, New York, 2000

Lipai, A., 2003. Finding Costumer Profile using Data

Mining, The Sixth International Conference On

Economic Informatics, Academy of Economic Studies,

Bucharest, Romania, May 8-11, 2003

Maulik, U., Bandyopadhyay, S., 2002. Performance

Evaluation of Some Clustering Algorithms and

Validity Indices, IEEE Transactions on Pattern

Analysis and Machine Intelligence, Vol. 24, No. 12,

December 2002

MacQueen, J., 1967. Some methods for classification and

analysis of multivariate observation. 5th Berkeley

Symposium on Mathematical Statistics and

Probability. 1967: University of California Press.

San, O. M., Huynh, V. N., Nakamori, Y., 2004. An

Alternative Extension of The K-Means Algorithm for

Clustering Categorical Data. Int. J. Appl. Math.

Comput. Sci., Vol. 14, No. 2, 241–247, 2004

Universitatea Babeş-Bolyai Cluj-Napoca, România, UBB

2003. Plan Strategic de dezvoltare a Universităţii

Babeş-Bolyai 2004-2007, Cluj-Napoca 2003

Witten, I. H., Frank, E., 2005. Data mining : practical

machine learning tools and techniques, 2nd ed.,

Morgan Kaufmann series, Elsevier Inc., 2005

Zhao, Y., Karypis, G., 2005. Data Clustering in Life

Sciences. Molecular Biotechnology, Volume 31,

Humana Press Inc., 2005

ICEIS 2007 - International Conference on Enterprise Information Systems

410
