AN OVERVIEW OF THE OBJECT-ORIENTED DATABASE

PROGRAMMING LANGUAGE DBPQL

Markus Kirchberg

Information Science Research Centre and Department of Information Systems

Massey University, Private Bag 11 222, Palmerston North 5301, New Zealand

Keywords:

Database Programming Language, Object-Oriented Programming, Query Language, Impedance Mismatch,

and Object Database Management System.

Abstract:

In this paper, we present a new approach to the integration of object-oriented programming languages, database

programming languages and query languages. While object-oriented programming languages and languages

that are supported by object database systems appear to be closely related, there are a number of signiﬁcant

differences that affect language design and implementation. Such issues include the degree of encapsulation,

persistence, the incooperation types and classes, inheritance, concurrency,

NULL

values, garbage collection etc.

In this paper, we outline the respective challenges that affect language design and provide a brief overview of

the integrated object-oriented database programming and querying language DBPQL.

1 INTRODUCTION

Traditionally, programming languages (PLs) focus on

processing. In turn, data storage and data sharing only

play a minor role. Long-term data is ‘exported’ to a

ﬁle system or database system (DBS). DBSs, on the

contrary, have been built to support large bodies of ap-

plication programs that share data. The emergence of

object-oriented PLs (OOPLs) have brought those two

concepts closer together, i.e. data is at the centre of

attention. Nevertheless, in OOPLs, the messages ob-

jects accept are most important while DBSs largely

evolve around object persistence and data sharing.

This, of course, results in a number of common (i.e.

object-related) concepts being dealt with differently.

Such concepts include the degree of encapsulation,

treatment of transient and persistent data, incorpora-

tion of types and classes, inheritance, concurrency,

NULL

values, garbage collection etc.

In todays database (DB) marketplace, (object-

)relational DBSs ((O)RDBSs) are dominant. Object-

oriented DBSs (ODBSs) were originally thought of to

replace RDBSs because of their better ﬁt with object-

oriented programming. However, high switching

costs, the inclusion of object-oriented (OO) features

in RDBSs, and the emergence of object-relational

mappers (ORMs) have made RDBS successfully de-

fend their dominance in the DB marketplace. ODBSs

are now established as a complement, not a replace-

ment for (O)RDBSs. Especially the open source com-

munity has created a new wave of enthusiasm that is

fuelling the rapid growth of ODBS installations.

In general, DBSs provide support for query lan-

guages (QLs), most commonly SQL-like languages.

It has been common practice for decades to link

the PLs and DBSs domains by embedding QLs into

PLs. However, the embedded approach suffers from

problems collectively known as impedance mismatch.

Alternative integrated approaches circumvent these

problems. While the majority of them either represent

a PL with added query constructs (e.g. DBPL (Atkin-

son and Buneman, 1987)) or a QL with added pro-

gramming abstractions (e.g. Oracle PL/SQL (Feuer-

stein and Pribyl, 2002)), only a few research projects

(e.g. LOQIS (Subieta, 1991)) have attempted a seam-

less integration of programming and querying lan-

guages. We follow the latter line of research.

In this paper, we brieﬂy discuss issues that af-

fect the integration of OOPLs and DB languages.

Subsequently, an overview of the integrated object-

oriented database programming and querying lan-

guage DBPQL is presented.

573

Kirchberg M. (2007).

AN OVERVIEW OF THE OBJECT-ORIENTED DATABASE PROGRAMMING LANGUAGE DBPQL.

In Proceedings of the Ninth International Conference on Enterprise Information Systems - DISI, pages 573-576

DOI: 10.5220/0002371205730576

 SciTePress

2 PRELIMINARIES

In this section, we ﬁrst discuss the impedance mis-

match. Subsequently, attention shifts to issues that

affect the integration of DB languages and OOPLs.

2.1 The Impedance Mismatch

The term impedance mismatch refers to an inadequate

or excessive ability of one system to accommodate

input from another. The object-relational impedance

mismatch is often named a central problems of DB

research. It refers to a set of conceptual and tech-

nical difﬁculties, which are often encountered when

an (O)RDBS is being used by a program written in

an OOPL. Robert Greene highlights in (Cook et al.,

2006) that ‘Objects in the language and Relations in

the database have always been at odds, as articu-

lated in the classic problem known as “impedance

mismatch”.’ Two fundamental ways in which this

mismatch materialises, i.e. as developer burden and in

slower performance, are identiﬁed. While standardis-

ation of mapping has brought relief to the former, the

latter still poses a signiﬁcant burden.

2.2 On the Integration of PLs and QLs

The relationship between QLs and PLs has been stud-

ied for decades. Among others, (Leontiev et al., 2002)

reviews existing integrated DBPLs. The review was

written as part of the TIGUKAT project (

Ozsu et al.,

1995), which aimed at developing a novel ODBS.

TIGUKAT researchers proposed a novel object model

whose identifying characteristics include a purely be-

havioural semantics and a uniform approach to ob-

jects. However, research has been terminated without

addressing problems that arise when including data

creation, data manipulation and programming lan-

guage constructs into a behavioural DBPL.

Another, from a practitioners point of view, more

interesting approach is presented in (Subieta et al.,

1993). The seamless integration of a QL with a PL

is investigated. Researchers follow an extended ap-

proach to stack-based machines as known from clas-

sical PLs such as Pascal. This Stack-Based Approach

(SBA) includes the SBQL language.

While the TIGUKAT project is based upon a pow-

erful type system (resulting in implementation chal-

lenges and performance problems), the SBA approach

rejects any type checking mechanism that originates

from type theory. In addition, SBA lacks of any ef-

forts that aim towards efﬁcient evaluation. Concepts

such as concurrent processing, transactions and distri-

bution are neglected by both approaches altogether.

2.3 DBPLs Vs. Conventional PLs

Fundamental issues that are dealt with differently in

OOPLs and in DB languages have been discussed in

various papers (Bloom and Zdonik, 1987; Atkinson

et al., 1989; Kim, 1993).

While OOPLs evolve around the messages an ob-

ject accepts, DBSs expose both the structure and be-

haviour of objects. Hence, encapsulation is inter-

preted differently. Without relaxing the encapsulation

property support for ad-hoc querying is impossible.

(Atkinson et al., 1989) suggests that the support of

encapsulation is essential but it may be violated un-

der certain conditions.

The interpretation of the terms class and type

largely vary even in the OOPL domain. However, we

focus on corresponding differences between ODBSs

and OOPLs. While types / classes commonly serve

as data structuring primitive, they also serve as means

of object access. Hence, types / classes must have

(system-maintained) collections of objects associated.

This is not the case in OOPLs, in fact, such a property

is not even desired. Not only does it disable garbage

collection it may also violate data abstraction. The

latter is true since objects become accessible through

the type / class even though they were meant to be ac-

cessible only through an abstract layer. In addition, a

collection approach does not make sense for all type

/ class deﬁnitions since there might be no meaningful

relationship between the respective objects.

Support of inheritance is an essential feature in

both domains. However, there is no agreement on

which inheritance types to support. Most arguments

evolve around the question whether multiple imple-

mentation inheritance has its advantages. While mod-

ern OOPLs (e.g. Java and C#) chose not to support it,

DBSs consider it as a necessary language feature.

Another issue concerns the life-time of objects.

Persistence was always at the core of DBSs in con-

trast to PLs. The latter tended to rely on ﬁle systems

or DBSs to maintain long-term data. This resulted

in a non-uniform treatment of transient and persis-

tent data. It is commonly accepted that persistence

should be orthogonal (i.e. each object, independent

of its type or class, is allowed to become persistent

without explicit translation) (Atkinson and Buneman,

1987).

Further issues encompass the inclusion of

NULL

values and the different focus of concurrency sup-

port. The former has only recently found its way into

OOPLs, i.e. into the second release of C#. The lat-

ter is commonly centred around transactions in DBSs

(i.e. competition for resources) and around multi-

threading in PLs (i.e. cooperation).

ICEIS 2007 - International Conference on Enterprise Information Systems

574

3 A DISTRIBUTED OBJECT BASE

(Kirchberg et al., 2007) proposes the architecture of

a distributed ODBS that is based on a sound theoret-

ical framework. The lack of standard object seman-

tics still is one of the main disadvantages of ODBSs.

Research in previous decades has investigated com-

plex values and references between data. The OO data

model OODM from (Schewe and Thalheim, 1993) al-

lows these different aspects to be combined. Starting

from an arbitrary underlying type system a schema

is deﬁned as a set of classes, each of which com-

bines complex values and references. In a distributed

DBS, the fragmentation and allocation of an OODM

schema will be still an OODM schema, but each class

will be allocated to exactly one DBS node. Thus, each

global object is now represented by multiple local ob-

jects. However, the structure of these local objects is

still complex whereas efﬁcient storage and retrieval

requires to provide just records stored on pages. This

implies to further decompose objects. The operational

system adopts the basic idea of the SBA approach

to implement DBS functionality. Stack-based ma-

chines are extended in a way that they execute simul-

taneously, support transactions and orthogonal persis-

tence, and reﬂect operations on higher DBS levels.

4 OVERVIEW OF DBPQL

In a truly distributed ODBS, users are not aware of the

distributed nature of the system. In fact, data indepen-

dence and network and fragmentation transparency

are key system properties. Thus, user requests are

free of location- and communication-speciﬁc infor-

mation. Only during the compilation, fragmentation,

code rewriting, linking and optimisation processes

such information is added.

Assume that user requests arrive in the form of

DBPQL

programs / modules. The DBS component

that processes requests consists of a DBPQL com-

piler, code optimisers, code rewritters (e.g. to map

operations on global OODM objects to local OODM

objects) etc. Here, we follow a black box approach

assuming that incoming DBPQL modules are trans-

formed into optimised evaluation plans, which are

formulated in iDBPQL code.

iDBPQL code is then evaluated by a network of

agents, which are realised as stack-based machines.

DBPQL is a high-level DBPL based on the lower-level

iDBPQL language. DBPQL is a modular language that sup-

ports transactions, query processing, generic requests, type,

class and object creation / manipulation commands etc. We

only refer to DBPQL aspects that stem from iDBPQL.

MetaData

Optimisation, Target Code Generation,

Code Analysis, Type Checking, Code

(Query) Optimisation, Fragmentation,

Reflection Support, Code Translation, ...

MetaDataFormulated in iDBPQL Code

(Optimised) Evaluation Plan

Network of Agents

DBPQL Module

DBS Run−Time

iDBPQL

DBPQL

Object−Oriented

global

Data Model

fragmented

Imported

DBPQL Modules

DBPQL Module InterfaceDBPQL Module Interface

Collection of

(global)

values / objects

Collection of

(fragmented)

values / objects

Reverse

Fragmentation

Figure 1: User Requests, Data Models and (i)DBPQL.

Agents are aware of the distributed DBS nature, know

about transactions and utilise simultaneous and dis-

tributed processing. While agents process evaluation

plans, they also interpret annotations that have been

added by the optimiser.

Figure 1 provides a more abstract view of the rela-

tionship between DBPQL, iDBPQL, conceptual data

models and associated processes. A high-level user

is exposed to a few of these elements only (refer to

dotted rectangles in Figure 1), which are as follows:

• A programmer codes a DBPQL Module and

its DBPQL Module Interface(s). Modules are

compile-time abstractions that support the devel-

opment of large-scale programs through the sup-

port of service imports and exports. Hence, infor-

mation hiding is supported naturally.

• Within a module, DBPQL module interfaces of

existing modules are imported. A DB schema

is regarded as just another module interface with

(possibly) a reduced degree of encapsulation. Fol-

lowing our discussions in Section 2.3, we may

have regular module interfaces that strictly follow

the traditional PL-interpretation of encapsulation

while DB schemata expose both structure as well

as behaviour. Thus, desired support for ad-hoc

querying can be provided.

• Modules return results (i.e. collections of (global)

object / values) as speciﬁed in their interface(s).

When processing DBPQL modules, code is anal-

ysed, type checked, fragmented, optimised etc. We

will not consider such processes but only their result:

• DBPQL’s

MAIN

method that initiates the execution

is transformed into an optimised evaluation plan,

the Main Evaluation Plan. An Evaluation Plan

may have an Initialisation Block, which permits

the initialisation of global and local elements be-

fore the start of the evaluation, an evaluation block

and a number of associated metadata structures.

An Evaluation Block consists of iDBPQL state-

ments and expressions. Concepts such as mod-

AN OVERVIEW OF THE OBJECT-ORIENTED DATABASE PROGRAMMING LANGUAGE DBPQL

575

ules, interfaces, type and class deﬁnitions, code

structuring primitives etc. have been removed.

• One or more schemata from the DBS metadata

catalogue may be associated with the main eval-

uation plan. The DBS MetaData catalogue is a

collection of compiled DB schemata. All schema

imports result in such associations. Due to frag-

mentation, a single DBPQL import may result in

a number of associated iDBPQL schemata.

• One or more run-time metadata catalogue entries

are associated with each evaluation plan. The

Run-Time MetaData catalogue is a collection of

type and class deﬁnitions introduced in the user’s

source code or its imported modules. While

DBS metadata catalogue entries describe persis-

tent, shared data, run-time metadata catalogue en-

tries relate to transient, non-shared data.

Evaluation plans are associated with every non-

abstract behaviour speciﬁcation. Classes may have

static variables declared outside of any method. Such

declarations are captured in the class’s initialisation

block. When invoking a method, the corresponding

evaluation plan is executed.

Finally, we want to underline some important

properties of evaluation plans. They differ from the

original DBPQL modules in the following ways:

• iDBPQL code refers to DBS metadata or transient

data (i.e. run-time metadata). Original code frag-

ments have been amended in a way that references

to higher-level features have either been removed

or replaced by macros formulated in iDBPQL.

• A user program is translated into a main evalu-

ation plan together with associated metadata en-

tries. In turn, these metadata entries and refer-

ences to iDBPQL library features may have fur-

ther evaluation plans associated. Thus, program

execution results in an evaluation of the main eval-

uation plan together with all evaluation plans that

are encountered during its evaluation.

• Data deﬁnitions are removed from evaluation

plans and now part of the metadata catalogues.

• iDBPQL statements and expressions are allocated

to DBS nodes. Thus, an indication about the loca-

tion of the evaluation is provided.

• Evaluation plans consist of

...

ENDDO

blocks,

which are used to group statements together,

form atomic execution units, model local and

distributed transactions and support simultaneous

processing.

• Indices and other information used to optimise

processing are added (i.e. as annotations) to sup-

port the evaluation of iDBPQL statements.

5 CONCLUSION

We presented an overview of the DB program-

ming and querying language DBPQL. This integrated

language circumvents the impedance mismatch and

unites properties from OOPLs, QLs and DBPLs.

REFERENCES

Atkinson, M., Bancilhon, F., DeWitt, D., Dittrich, K.,

Maier, D., and Zdonik, S. (1989). The object-oriented

database system manifesto. In Proceedings of the 1st

International Conference on Deductive and Object-

Oriented Databases, pages 223–240, Kyoto, Japan.

Atkinson, M. P. and Buneman, P. (1987). Types and per-

sistence in database programming languages. ACM

Computing Surveys (CSUR), 19(2):105–170.

Bloom, T. and Zdonik, S. B. (1987). Issues in the design

of object-oriented database programming languages.

In Conference proceedings on Object-oriented pro-

gramming systems, languages and applications, pages

441–451, New York, NY, USA. ACM Press.

Cook, W. R., Greene, R., Linskey, P., Meijer, E., Rugg, K.,

Russell, C., Walker, B., and Wittig, C. (2006). Objects

and databases: State of the union in 2006. Panel at

the International Conference on Object-Oriented Pro-

gramming, Systems, Languages, and Applications.

Feuerstein, S. and Pribyl, B. (2002). Oracle PL/SQL Pro-

gramming. O’Reilly & Associates, Inc., Sebastopol,

CA, USA.

Kim, W. (1993). Object-oriented database systems:

Promises, reality, and future. In Proceedings of the

19th International Conference on Very Large Data

Bases, pages 676–687, San Francisco, CA, USA.

Morgan Kaufmann Publishers Inc.

Kirchberg, M., Schewe, K.-D., Tretiakov, A., and Wang,

B. R. (2007). A multi-level architecture for dis-

tributed object bases. Data & Knowledge Engineer-

ing, 60(1):150–184.

Leontiev, Y.,

Ozsu, M. T., and Szafron, D. (2002). On

type systems for object-oriented database program-

ming languages. ACM Computing Surveys (CSUR),

34(4):409–449.

Ozsu, M. T., Peters, R. J., Szafron, D., Irani, B., Lipka, A.,

and Mu

noz, A. (1995). TIGUKAT: A uniform behav-

ioral objectbase management system. VLDB Journal,

4(3):445–492.

Schewe, K.-D. and Thalheim, B. (1993). Fundamental con-

cepts of object oriented databases. Acta Cybernetica,

11(1-2):49–84.

Subieta, K. (1991). LOQIS: The object-oriented database

programming system. Lecture Notes in Computer Sci-

ence, 504:403–421.

Subieta, K., Beeri, C., Matthes, F., and Schmidt, J. W.

(1993). A stack-based approach to query languages.

Technical Report 738, Institute of Computer Science

Polish Academy of Sciences, Warszawa, Poland.

ICEIS 2007 - International Conference on Enterprise Information Systems

576
