A COMPARATIVE STUDY BETWEEN WEB SERVICE AND

GRID SERVICE DEVELOPMENTS IN A MDA FRAMEWORK

Marcos López Sanz, Valeria de Castro, Esperanza Marcos

Kybele Research Group

Department of Information Systems and Languages

Rey Juan Carlos University

C/ Tulipan S/N – 28933 Móstoles

Madrid, Spain

José Luís Bosque

Department of Computer Architecture

Rey Juan Carlos University

C/ Tulipan S/N – 28933 Móstoles

Madrid, Spain

Keywords: Grid Services, Web Services, MDA, Platform Specific Models.

Abstract: The application of the MDA approach to the development of service-oriented systems facilitates the system

migration over different platforms. The specific features of each platform are reflected in the PSM level of

MDA. In this paper a comparison between the development of systems based on Web services and the de-

velopment of systems based on Grid services is presented. The comparative study is carried out through a

case study implemented on both a standard Web Service platform and a Grid platform based on the Globus

Toolkit 4 middleware. After the study we conclude that a subdivision of the MDA’s PSM level in two layers

is needed: an upper layer with the characteristics shared by any service-based platform (a WSDL model and

a model of the service code) and a lower layer with all the elements required to deploy the services success-

fully over the concrete execution platform.

1 INTRODUCTION

Current evolution of the information systems aims at

the construction of systems in which the design,

management, integration and evolution costs are

minimized. This trend can be seen today in several

research scopes of software development, from the

definition of new design techniques to the emer-

gence of new implementation approaches.

In the first case, approaches such as MDA

(Model Driven Architecture) have come up. Follow-

ing the idea of separating the specification of the

system functionalities from the implementation de-

tails, MDA promotes the portability, interoperability

and re-use degree of the systems (OMG, 2001). To

achieve this, MDA specifies three levels of models

to face the development of a system: CIM (Compu-

tation Independent Models), PIM (Platform Inde-

pendent Models) and PSM (Platform Specific Mod-

els).

In the second case, the different technological

approaches for system development, one of the most

promising proposals at the moment is the service

oriented paradigm (SOA – Service Oriented Archi-

tecture). This architectural approach is based on the

interconnection of systems with light protocols such

as SOAP (Simple Object Access Protocol) (Gudgin

M. et al, 2003) and WSDL (Web Service Description

Language) (W3C, 2003). With these protocols it is

possible to communicate, through the Web and effi-

ciently, software entities called “services”. The main

framework where this architecture is used is in the

Web Services platforms because this is the environ-

ment which the previous protocols were developed

for, although it is not the only one. Other field where

this paradigm has been recently adopted is the Grid

114

López Sanz M., de Castro V., Marcos E. and Luís Bosque J. (2007).

A COMPARATIVE STUDY BETWEEN WEB SERVICE AND GRID SERVICE DEVELOPMENTS IN A MDA FRAMEWORK.

In Proceedings of the Ninth International Conference on Enterprise Information Systems - ISAS, pages 114-121

DOI: 10.5220/0002382301140121

 SciTePress

Computing field (Foster I. and Kesselmann C.,

1998) with the definition of OGSA –Open Grid Ser-

vice Architecture (Foster I. et al., 2002) –. The

OGSA architecture bases the creation of Grid plat-

forms on Web Services, they are called generically

as “Grid Services”.

The combination of both approaches, MDA and

SOA, results in the coming out of new methods for

the development of systems which are versatile, ser-

vice-oriented, and which development is based on

the specification of models defining the system

structure from several points of view and different

abstractions levels.

The main objective of this paper is to compare

the development of service-oriented systems in a

MDA framework. In particular, we make a compari-

son between the development with Web Services

and with Grid Services. To carry out this comparison

we use, as case study, the development of a system

for the management of medical images. Firstly, we

use a method for the MDA development of Web In-

formation Systems (WIS) based on services, and

secondly, we implement that system over a Grid

platform. After implementing the systems on both

platforms, a standard-based Web Service platform

(following the W3C recommendations and not tak-

ing into account other Web Service models such as

REST (Fielding et al., 2000)) and a Grid platform,

we make a study of the differences and similarities

of both approaches. The interpretation of the com-

parison leads us to outline a proposal for the devel-

opment of service-oriented systems based on MDA.

For a better comprehension we first explain the

lessons learned, as a result of the study, and after

that, we depict the concrete aspects of the study

showing the aspects in common and main differ-

ences in the development with Web Services and

Grid Services.

The rest of the article is organized as follows: in

Section 2 we present an overview of the proposal for

the subdivision of the MDA’s PSM level for the de-

velopment of service-oriented systems. In Section 3

the case study is described as well as the comparison

of the development, at PSM level, with Web Ser-

vices and Grid Services. Section 4 presents some re-

lated works describing the main benefits and contri-

butions of our proposal and, finally, Section 5

concludes the paper and outlines some future works.

2 LESSONS LEARNED: A

PROPOSAL FOR THE

DEVELOPMENT OF

SERVICE-ORIENTED

SYSTEMS IN A MDA

FRAMEWORK

The study we have carried out consists on the im-

plementation of a service over both a standard Web

Service platform and a Grid platform. After that

work, we extracted and compared the main charac-

teristics of each approach.

In this study we have detected several similarities

in the development with both types of services (Web

and Grid). Specifically, we have verified that both

the WSDL description of the service and the code of

the service itself are needed in both cases. These fea-

tures are very similar for any type of service inde-

pendently of the underlying technology used to im-

plement the service.

However, there are some aspects that depend

completely on the technology of the supporting in-

frastructure. This is the reason why we propose, for

the MDA development of service-oriented applica-

tions, a separation of the PSM level in two sublayers

that we name, alike other works (Muller P.A. et al.,

2005): Platform Dependent Layer and Technology

Dependent Layer. The specific characteristics that

differentiate the development with Web Services

and Grid Services and that have led us to suggest

this subdivision are explained in Section 3.

The division of the PSM layer for both technolo-

gies can be seen in Figure 1. The main elements to

be defined in each layer are:

• Platform Dependent Layer (PD-PSM), at the up-

per level of the PSM layer: in this sublevel the

models to be defined include, on the one hand,

the WSDL description model (using guidelines

such as the ones defined in (Marcos E. et al.,

2003)), and, on the other hand, a model of the

process that carries out the service. Both models

should be obtained from the latest model defined

in the PIM level.

• Technology Dependent Layer (TD-PSM), at the

lower level of the PSM layer: in this sublevel the

elements to be defined include those related to the

specific technology of the execution platform. In

case of using a standard Web Services platform

for example, the elements of this level would be

the code of the service itself and the code of the

WSDL description. In contrast, when using a

Grid platform such as Globus Toolkit 4 (Foster I.,

A COMPARATIVE STUDY BETWEEN WEB SERVICE AND GRID SERVICE DEVELOPMENTS IN A MDA

FRAMEWORK

115

2005) (GT4 from now onwards) there are some

extra elements that need to be defined: a WSDD

(Web Service Deployment Descriptor) file and

JNDI (Java Naming and Directory Interface) file.

Those elements are required because the devel-

opment of Grid services over GT4 includes an

explicit process of deployment (see Section 3.3

for more details). The preceding files need to be

compiled together with the WSDL file and the

service code itself prior to the deployment proc-

ess.

Figure 1: Proposal for the PSM level in the development

of service-oriented systems.

3 COMPARATIVE AT PSM

LEVEL: DEVELOPMENT

WITH WEB SERVICES AND

GRID SERVICES

As we have mentioned in the introduction, the com-

parative study starts from a MDA method for the

development of WIS framed in the MIDAS method-

ology (Caceres P. et al, 2003). This method specifies

the PIM models for a service-oriented system (De

Castro V. et al, 2006) and the PSM models for the

particular case of a system based on Web Services.

Next, we depict the main features of the case study

in which we centre the comparison, describing also

the models created at PIM level for this case study.

After that we explain the development at PSM level

with both standard Web Services and Grid Services.

Finally, we summarize the results of the comparative

study by extracting the main similarities and differ-

ences.

3.1 Case Study

The case study we use as basis for the comparative

study comes up from the necessity of extending the

features offered by GESiMED, a WIS for the man-

agement of medical images (Acuña C. et al., 2004).

In particular, what we wanted to add to this sys-

tem is the capability of performing, in a unique

process, the acquisition of images from a database

and its subsequent processing in order to be dis-

played on a Web page. At this moment, GESiMED

offers both functionalities but in separated processes.

So, the main goal of the new service (“to obtain im-

ages” from now onwards) will be to obtain the im-

ages and to process them for a correct visualization

afterwards. The interest of using a Grid Platform for

the case study is based on the opportunity of getting

computational benefits when executing some parts

of the developed service over a Grid environment.

The processing of the images, for example, is a task

whose algorithm can be easily parallelized or dis-

tributed; this also occurs with the extraction of the

images from the original files.

In (De Castro V. et al, 2006), the PIM models for

this case study are described in detail: user services

model, extended use cases model, service process

model and finally the service composition model. In

this paper we reproduce only the last one, the ser-

vices composition model (see figure 2) because it is

the model from which all the models that will be de-

fined at PSM level will be derived. This model is

represented through an activity diagram. On it, the

sequence of tasks that needs to be performed in or-

der to achieve the objective of the service is identi-

fied. Apart from the tasks performed by the system

itself, this model also reflects the collaborators of the

system, which are external entities that perform spe-

cific tasks unable to be done by the system itself and

required to complete the service.

The corresponding tasks of the “to obtain images”

service can be seen in figure 2 and include the iden-

tification and validation of the user in the system,

the payment of fees to perform the task selected by

the user, the selection of the query criteria, the exe-

cution of the query in the database, the extraction of

the images from the result files and, finally, the

presentation of the results to the user offering the op-

tion of downloading the obtained result files.

In this point of the description we have to distin-

guish between two types of tasks: on the one hand,

those ones carried out by the system itself (in Figure

2 those ones in the “Neuroscience researcher” swim-

lane) and, on the other hand, the tasks performed by

the collaborators (“Medical Images Management

Services Composition

Model

...

PSM

PD-PSMTD-PSM

WSDL

Model

Coordination

Process

Model

WSDL Grid

Model

WSDL

Web S.

Code

WSDL

Grid S.

Code

WSDD

JNDI

.GAR

GRID Platform

PIM

WEB Platform

Representation of a physical file

Services Composition

Model

...

PSM

PD-PSMTD-PSM

WSDL

Model

Coordination

Process

Model

WSDL Grid

Model

WSDL

Web S.

Code

WSDL

Grid S.

Code

WSDD

JNDI

.GAR

GRID Platform

PIM

WEB Platform

Representation of a physical file

ICEIS 2007 - International Conference on Enterprise Information Systems

116

System” and “Storage Service”). The part of this

diagram on which we will focus at the PSM level

will be the one related with the tasks of the system

itself, that is, the composition of the invocations to

the operations of the collaborators.

3.2 Web Service PSM

At the PSM level of the MDA approach we have to

define all the models that reflect the specific features

of the platform that will be used as execution sup-

port infrastructure for the developed service. When

using a service-oriented approach, and especially an

approach based on Web Services, a WSDL model

describing the main operations offered by the service

at the PSM level is needed and also a representation

of the code of the service itself.

Because we start from a service which coordi-

nates the invocations of several external services, the

composition process can be represented, for exam-

ple, using a language for the description of processes

such as BPEL – Business Process Execution Lan-

guage (Andrews T. et al., 2003).

Figure 3 shows a representation of the WSDL

model corresponding to the service “to obtain im-

ages”. This model has been built using the guide-

lines explained in (Marcos E. et al., 2003). From this

model it will be possible to obtain a WSDL file that,

together with the code of the service itself, represent

the final elements of the development process of our

case study with Web Services. The files with the

WSDL description and the code of the service are

the only ones needed to deploy and execute a service

over a server which executes Web Services accord-

ing to the WSDL and SOAP standards. In our case

we have used the Apache AXIS framework as exe-

cution platform for the developed Web Services.

The deployment over this kind of platform consist of

just copying the Web Service files in the right server

folder, consequently, we suppose that there are no

needed specific elements for this purpose.

Figure 3: WSDL model of the Web Service.

3.3 Grid Service PSM

When facing the development of a system on a Grid

platform there are several concepts that have to be

understood previously, starting from the concept of

“Grid Service” itself. As it is defined in OGSA, a

Grid Service can be considered as a concrete appli-

cation of a Web Service but in a Grid Computing

Figure 2: Services Composition Model.

-targetNamespace = http://ariadna.escet.urjc.es:8080/axis/Orchestrator.jws

«DEFINITION»Orchestrator

«MESSAGE»

testExecQueryResponse

«MESSAGE»

testExecQueryRequest

-Type : string

«PART»

testGetImageReturn

-Type : string

«PART»

testExecQueryReturn

«OPERATION»

testGetImage

«OPERATION»

testExecQuery

«output»

«input»

«output»

xmlns:apachesoap="http://xml.apache.org/xml-soap"

xmlns:impl="http://ariadna.escet.urjc.es:8080/axis/Orchestrator.jws"

xmlns:intf="http://ariadna.escet.urjc.es:8080/axis/Orchestrator.jws"

xmlns:soapenc="http://schemas.xmlsoap.org/soap/encoding/"

xmlns:wsdl="http://schemas.xmlsoap.org/wsdl/"

xmlns:wsdlsoap="http://schemas.xmlsoap.org/wsdl/soap/"

xmlns:xsd="http://www.w3.org/2001/XMLSchema

«PORT TYPE»

Orchestrator

«SERVICE»

OrchestratorService

«BINDING»

OrchestratorSoapBinding

-location = http://ariadna.escet.urjc.es:8080/axis/Orchestrator.jws

«PORT»

Orchestrator

«MESSAGE»

testGetImageResponse

«MESSAGE»

testGetImageRequest

A COMPARATIVE STUDY BETWEEN WEB SERVICE AND GRID SERVICE DEVELOPMENTS IN A MDA

FRAMEWORK

117

environment. Similarly to Web Services, Grid Ser-

vices are communicated through SOAP and are de-

scribed with WSDL. The main difference is in the

goal of the platforms on which both types of services

are executed. On the one hand, the objective of the

Web services is to put at the disposal of the users a

concrete functionality available through the Web, on

the other hand, in the Grid Services case, this avail-

ability is referred to the possibility of sharing soft-

ware resources in a distributed virtual organization.

As stated previously, in both cases a WSDL de-

scription is needed; however, there are some restric-

tions to be taken into account when creating the

WSDL description of the Grid Service:

• It is not necessary to specify neither <binding>

nor <service> elements because in the Grid Ser-

vice compilation process the compilation tool will

add these elements automatically.

• Although in the WSDL description of the Web

Service a definition of the data types used in the

invocations and responses of the service opera-

tions is not always established, in the Grid Ser-

vice case it is mandatory to define them by speci-

fying a <type> element containing a fragment of

XML Schema whose targetNamespace attribute

be the WSDL file itself.

• To complete the definition it is necessary to add

to the <definition> element those references to

the namespaces used in the body of the WSDL

file (that will be relative to the Grid platform)

The execution of Grid Services over the GT4

middleware involves a previous phase of compila-

tion and deployment. In the compilation phase, apart

from the WSDL description and the code of the ser-

vice itself, two auxiliary files are needed:

• WSDD (Web Service Deployment Descriptor,

2005) file: contains a description of the deploy-

ment process and is used to communicate to the

platform how the service should be published on

the Grid. The WSDD code for our case study can

be seen in figure 4.

• JNDI (Java Naming and Directory Interface,

2006) file: this file is related to the concept of re-

source associated to any Grid application. In the

Grid Services case, the resource to be controlled

consists on the maintenance of the service state

between different invocations to the same service.

Due to the properties of the case study, we don’t

need to maintain the state of our Grid Service in

any case; but, and because of the characteristics

of the platform, the existence of this file is man-

datory. In our case, this file will contain exclu-

sively a reference to the generic resource factory

provided by GT4. The code of this file can be

seen in figure 5.

<?xml version="1.0" encoding="UTF-

8"?>

<deployment

name="defaultServerConfig"

xmlns=http://xml.apache.org/axis

/wsdd/

xmlns:java=http://xml.apache.org

/axis/wsdd/providers/java

xmlns:xsd="http://www.w3.org/200

1/XMLSchema">

<service

name="prueba1/Ochestrator"

provider="Handler"

use="literal"

style="document">

<wsdlFile>share/schema/Orchestra

tor_instance/Orchestra-

tor_service.wsdl

</wsdlFile>

<parameter

name="className"

value="prueba1.impl.Orchestrator

"/>

<parameter

name="allowedMethods"

value="*"/>

<parameter

name="handlerClass"

value="org.globus.axis.

provid-

ers.RPCProvider"/>

<parameter

name="scope"

value="Application"/>

<parameter

name="providers"

value="GetRPProvider"/>

<parameter

name="loadOnStartup"

value="true"/>

</service>

</deployment>

Figure 4: Content of the WSDD file.

ICEIS 2007 - International Conference on Enterprise Information Systems

118

<?xml version="1.0" encoding="UTF-

8"?>

<jndiConfig

xmlns="http://wsrf.globus.org/jn

di/config">

<service

name="prueba1/Orchestrator">

<resource

name="home"

type="org.globus.wsrf.impl.

ServiceResourceHome">

<name>factory</name>

<value>

org.globus.wsrf.jndi.BeanFactory

</value>

</parameter>

</resourceParams>

</resource>

</service>

</jndiConfig>

Figure 5: Code of the JNDI file.

3.4 Summary of the Comparative

Study

After completing the development of the case study

with both Web services and Grid Services, we have

detected that the main difference in the development

with both types of services is found in the moment

of deploying the service on a specific execution plat-

form: while traditional Web Services doesn’t need a

explicit phase of deployment, Grid Services, on the

contrary, demand a deployment process that in-

volves other files apart from the ones defined be-

cause of its condition of Web Services. The need to

create extra files and to adapt the WSDL description

to the Grid platform leads to the necessity to define

concrete models in the MDA’s PSM level. Our pro-

posal of models for this level is the one described in

Section 2.

In relation to the code that orchestrates the com-

position in the “to obtain images” service, the differ-

ences between the Web Service code and the Grid

Service code are negligible. The unique remarkable

differences take place in the moment of referencing

the libraries and data types used to perform the func-

tionality of the service. These references will corre-

spond to specific paths of the execution platform.

The process of invocation of the collaborators is

quite similar in both cases because they use standard

protocols to call the external Web Services. Table 1

summarizes the main differences and similarities

found in the comparative study.

4 RELATED WORKS

The application of the MDA approach to the design

of Grid systems and applications is not so original.

Recently, some proposals for the model driven de-

velopment of Grid applications have come up.

Smith et al. (2006) suggest the division of the

MDA’s PSM level in two parts, separating the func-

tionality of the application from the Grid logic con-

cerns. The authors specify a UML profile for the de-

scription of Grid services at PSM level. Although

their proposal separates the logic of the client who

uses the service from the classes that form the Grid

service itself, this separation is made in a unique

model for the PSM level. In our case, we also pro-

pose a subdivision of the PSM level but with some

slight differences. Since our proposal is framed in

the MIDAS methodology, the interaction with the

client of the system is modelled separately, specifi-

cally in the hypertext aspect of the development ar-

chitecture proposed by MIDAS (see (Caceres P. et

al., 2003) for more details). As a result, we only

have to focus on the modelling of the system busi-

ness logic. Moreover, we base our division of the

PSM level on the identification of the service com-

mon features shared by the underlying implementa-

tion platforms.

In Manset et al. (2006), an architecture-centric

approach for the automatic generation of Grid appli-

cations is presented. The authors define a model

driven engineering process for the generation of ap-

plications based on a formal specification of the

Grid architecture. Their proposal demands that the

designers involved in the engineering process have a

specific knowledge in architecture description lan-

guages. The main difference with our proposal is

that the Manset et al. proposal focuses exclusively

on the development of Grid applications over Grid

platforms whereas ours aims to facilitate the migra-

tion of systems also over non-Grid platforms such as

standard Web Service based platforms.

5 CONCLUSIONS AND FUTURE

WORKS

In this paper we have presented a comparative study

between the MDA development of systems based on

Web services and the MDA development of systems

A COMPARATIVE STUDY BETWEEN WEB SERVICE AND GRID SERVICE DEVELOPMENTS IN A MDA

FRAMEWORK

119

Table 1: Summary of the comparative study: Web Services vs. Grid Services.

based on Grid Services as implementation technol-

ogy. To carry out this comparison we have used, as

case study, the development of a service that allows

to obtain a set of images from a database and that

process them in order to be displayed on a Web

page.

In the comparative study we have detected that, in

the developments of systems with Web Services and

Grid Services, there are some elements in common

as well as other that depend completely on the un-

derlying technology of the execution platform. Be-

cause of that, in this paper we have outlined a pro-

posal for the division of the MDA’s PSM level in

two sublayers: an upper layer, PD-PSM, where all

the shared aspects of the service-oriented develop-

ment should be modelled; and a lower layer, TD-

PSM, where the models with all the specific features

and restrictions of the execution platform should be

defined and which will be used to obtain the final

code of the service.

At this moment there are guidelines for the defini-

tion of some PSM models, for example the ones de-

scribed in (Marcos et al., 2003) to create the WSDL

model. These definitions could be used also in the

development process of Grid Services, both for the

WSDL model of the PD-PSM layer and the WSDL

Grid model of the TD-PSM layer. In the last case a

definition of an extension to the UML-WSDL

metamodel should be done in order to include the

Grid characteristics.

There is a lot of work to be completed from the

proposal depicted in this paper: first, all the models

included in every PSM sublayer should be better de-

fined; second, the guidelines for the transformation

of the last model defined at PIM level to the PD-

PSM models as well as the models transformations

between the PD-PSM and TD-PSM level should also

be defined. Finally, the automatic generation rules of

executable code form the lowest models of the archi-

tecture should also be defined.

ACKNOWLEDGEMENTS

This research is partially granted by projects: GOLD

(TIN2005-00010) and “Virtual trainers with low

cost platforms” (TIC2003-08933-C02-00), financed

by the Ministry of Science and Technology of Spain

and “GATARVISA: Algorithms, Techniques and

Applications of Virtual Reality and Advance Simu-

lation” (S-0505/DPI/0235), financed by the Science

and Technology Council of the government of Ma-

drid (Spain).

REFERENCES

Acuña C., Marcos E., de Castro V. & Hernández J.A.

2004. A Web Information System for Medical Image

Management. 5th International Symposium on Bio-

RID SERVICES WEB SERVICES

Goal of the execution platform

To create virtual organizations based on

resource sharing

To have software resources available

through a network

Service description Modified WSDL Standard WSDL

− Description of types used in

operations

Mandatory Optional

− binding and service elements

Established in a later compilation proc-

ess

Established in the moment of creating

the WSDL description

Service coding Language supported by the platform Language supported by the platform

Compilation and deployment

process

Mandatory Not needed

Auxiliary files JNDI / WSDD NO

ICEIS 2007 - International Conference on Enterprise Information Systems

120

logical and Medical Data Analysis. Barcelona, Spain.

Springer-Verlag. LNCS 3337. pp. 49-59.

Andrews, T., Curbera, F., Dholakia, H. et al. 2003. Busi-

ness Process Execution Language for Web Services,

Version 1.1. Specification, BEA Systems, IBM Corp.,

Microsoft Corp., SAP AG, Siebel Systems.

Cáceres, P., Marcos, E. & Vela, B. 2003. A MDA-Based

Approach for Web Information System Development.

Workshop in Software Model Engineering

(WiSME@UML'2003) in conjunction with UML Con-

ference. Octubre, 2003. San Francisco, USA.

De Castro V., Marcos E. & López M. 2006. A Model

Driven Method for Service Composition Modeling: A

Case Study. Int. Journal of Web Engineering and

Technology, Vol. 2, No. 4, pp. 335-353.

Foster I. & Kesselman C. The Grid: Blueprint for a New

Computing Infrastructure. Ed. Morgan Kauffmann,

1998. ISBN 1558604758.

Foster I. 2005. Globus Toolkit Version 4: Software for

Service-Oriented Systems. IFIP International Confer-

ence on Network and Parallel Computing, Springer-

Verlag LNCS 3779, pp 2-13.

Fielding R. T. and Taylor R. N. 2000. Principled design of

the modern Web architecture. In Proceedings of the

2000 International Conference on Software Engineer-

ing (ICSE 2000), Limerick, Ireland, June 2000, pp.

407–416

Gudgin M., et al. 2003. Simple Object Access Protocol.

W3C recommendation, W3C. Retrieved June, 2006,

from http://www.w3.org/TR/soap12-part1

Java Naming and Directory Interface (JNDI). 2006. Re-

trieved November 2, 2006, from

http://java.sun.com/products/jndi/.

Marcos, E., De Castro, V. & Vela, B. 2003. Representing

Web Services with UML: A Case Study. The First In-

ternational Conference on Service Oriented Comput-

ing (ICSOC03). M.E. Orlowska, S. Weerawarana,

M.P. Papazoglou, J. Yang (Eds.). LNCS 2910,

Springer Verlag, pp.15-27.

Manset D., Verjus H., McClatchey R. & Oquendo F. 2006.

A Formal Architecture-Centric Model-Driven Ap-

proach For The Automatic Generation Of Grid Appli-

cations, Proceedings of the 8th International Confer-

ence on Enterprise Information Systems, Paphos,

Cyprus, pp. 23 - 27.

Muller, P.-A, Studer, P., Fondement, F. & Bézivin, J.

2005. Platform Independent Web Application Model-

ing and Development with Netsilon. Journal on Soft-

ware and Systems Modeling (SoSyM), Vol. 4 Nr. 4,

Best papers of the <<UML>>'03 conference, Springer,

pages 424 - 442

OMG, 2001. OMG Model Driven Architecture. Miller, J.,

Mukerji, J. (eds.). Document Nro. ormsc/2001-07-01.

Available at: http://www.omg.com/mda.

Foster I., Kishimoto H, Savva A. et al. 2005. Open Grid

Services Architecture version 1.0 – OGSA. Retrieved

January, 2005, from http://forge.gridforum.org/ pro-

jects/ogsa-wg/document/draft-ggf-ogsa-spec/en/ 23.

Smith, M., Friese, T., and Freisleben, B. 2006. Model

Driven Development of Service-Oriented Grid Appli-

cations. In Proceedings of the Advanced int'L Confer-

ence on Telecommunications and int'L Conference on

Internet and Web Applications and Services (February

19 - 25, 2006). AICT-ICIW. IEEE Computer Society,

Washington, DC, 139. DOI=

http://dx.doi.org/BBA0CE2A-94C5-4D2C-BA23-

ABE1A82CB45D

W3C Web Services Description Language (WSDL). 2003.

Version 1.2. W3C Working Draft 3. Retrieved from:

http://www.w3.org/TR/wsdl12/

Web Service Deployment Descriptor (WSDD). (2005).

Reference Guide. Retrieved August 17, 2006, from

http://ws.apache.org/axis/java/reference.html#Deploy

mentWSDDReference

A COMPARATIVE STUDY BETWEEN WEB SERVICE AND GRID SERVICE DEVELOPMENTS IN A MDA

FRAMEWORK

121
