DOING THINGS RIGHT OR DOING THE RIGHT THINGS?

Proposing a Documentation Scheme for Small to Medium Enterprises

Josephine Antoniou, Panagiotis Germanakos and Andreas S. Andreou

Computer Science Department, University of Cyprus, CY-1678 Nicosia, Cyprus

Keywords: Documentation scheme, software maintenance, Small to Medium Enterprises.

Abstract: Coping with the initial and finest systems’ functionality and performance is indeed one of the major

problems nowadays, due to the rapid increase and continuous change of customer demands. Hence, it is

crucial to move on with a research analysis in an attempt to identify whether documentation, the most

reliable source for preserving a software system’s quality over the years, is properly created, updated and

used in Small to Medium Enterprises (SME) operating in small EU markets, focusing both on the

development process and the maintenance activities. Henceforth, the main objective of this paper is to

propose a minimum documentation set required to fulfil both the Software Engineering principles and the

SME practical needs by comparing literature suggestions with empirical findings. In further support of our

documentation set suggestion, we present and discuss the results of a small survey conducted in nine IT-

oriented SME in Cyprus and Greece.

1 INTRODUCTION

Software documentation may be conceived as the

cornerstone of future maintenance activities. As

such, the importance of a complete, updated and

accurate documentation set is appraised by the

Software Engineering community (e.g.

(Sommerville, 2007; Pfleeger, 2001; Schach, 2005;

Pressman, 2005). This paper aims to uncover the

importance of documentation design and

maintenance in Small to Medium Enterprises (SME)

in small but growing European markets.

The methodology used is based on the

construction of a questionnaire (Georgiou &

Germanakos, 1999) and its further application on

selected SME. in the area of software development

and support. The SME that contributed to this work

are located in Greece and Cyprus; nevertheless, the

findings may be considered applicable to other

developing European regions (e-MINDER). The

results from the survey are analyzed and juxtaposed

with an ideal documentation model resulting from a

literature review, to closely examine any procedural

documentation areas that need to be improved. This

was not an easy task as the process should devise

questions that would result in the gathering of the

necessary information for inference purposes as

regards to current and future documentation plans.

The latter are associated with the profile and status

of a SME as well as the comparison between

existing documentation practices and those

suggested by the literature. Specifically, documents

created during system development, as well as ones

actually used during system maintenance were

targeted. Furthermore, the questionnaire aspired to

examine the percentage of time spent on

documentation during the different phases of the

system development cycle to conclude on effects of

possible time limitations for documentation

development and usage (Baldassarre et al., 2006).

An extensive analysis of the data collected via

the questionnaires is included in an attempt to

identify the attitudes, reactions, suggestions and

perceptions of both the management and rest

employees. This work aspires to provide a way for

assessing the SME’s efficiency in “doing things

right” and effectiveness in “doing the right things”

within the given market space, which is crucial if a

competitive advantage is to be achieved.

The rest of the paper is organized as follows:

Section 2 provides a short related literature

overview. The complete methodology of our

investigation, including the analysis of collected

results, is described in Section 3. Consequently, in

408

Antoniou J., Germanakos P. and S. Andreou A. (2007).

DOING THINGS RIGHT OR DOING THE RIGHT THINGS? - Proposing a Documentation Scheme for Small to Medium Enterprises.

In Proceedings of the Ninth International Conference on Enterprise Information Systems - DISI, pages 408-414

DOI: 10.5220/0002383604080414

 SciTePress

Section 4, a proposal for an “optimal”

documentation set is presented based on conclusions

drawn from the findings of our survey. Finally, we

conclude in Section 5 and also provide some future

research steps.

2 BASIC LITERATURE REVIEW

A brief literature review and an outline of various

life-cycle models is presented in this section. Several

researchers have focused on documentation issues

such as accuracy, timeliness, flexibility and low cost

(Arisholm et al., 2005). The authors of “System

Documentation as Software” (Dibb et al., 1994)

observe that due to new software technology, along

with the greater productivity of higher level (4G)

programming languages, there is a longer response

time for documenting software. As a result, the

dilemma of accuracy versus timeliness arises.

Similar issues for a specific case study are looked at

in (McGregor, 1982), a work concentrating on the

important factor of identifying the recipients of the

documentation set. Sickler (Sickler, 1982)

encourages empirical research in order for creators

of documentation to use the best available

technology. This is because it has been observed that

there is a lack of commitment on behalf of the

programming personnel to prepare accurate

documentation (Pfleeger & Kitchenham, 2001).

The Waterfall model was first put forward by

Royce (Royce, 1970), involving a straightforward,

trickledown approach to design and development.

The resulting documentation provides a solid

foundation of information for the writer as well as to

track the progress of the project. It comprises a

complete system documentation set and provides a

theoretical model to be used as a basis of

comparison with the documentation sets actually

produced by the SME presented later in this paper.

The rapid prototype is a working model

functionally equivalent to a subset of the product.

With the incremental model, software is constructed

step by step, in the same way that a building is

constructed. The extreme programming model

(Beck, 1999) is a new approach to software

development based on the incremental model. The

synchronize-and-stabilize model refers to a version

of the incremental model (Cusumano & Selby,

1997). The spiral model is as a waterfall model with

each phase preceded by risk analysis. Eventually,

object-oriented models explicitly reflect the need for

iteration, e.g the fountain model (Henderson-Sellers

& Edwards, 1990).

The only documentation-driven model is the

waterfall model which requires deliverable

documents in order for each step of the system life

cycle to be regarded as complete. Therefore, special

emphasis on documentation is given compared to

other models and that is why it perfectly satisfies the

objectives of this paper. It should be noted at this

point that we target companies belonging to one of

the first three levels of the Capability Maturity

Model, namely the Initial level (ad-hoc process), the

Repeatable level (basic project management) and the

Defined level (process definition), as we concentrate

on small software providers with the typical

characteristics of SME striving to survive in the

software industry (Otoya & Cerpa, 1999).

3 A METHODOLOGY FOR

DOCUMENTATION ANALYSIS

AND ASSESSMENT

In order to analyze and assess the documentation set

used in the targeted SME, nine companies situated in

Greece and Cyprus were approached. A number of

employees from each company (3 to 5 persons

varying from IT developers, IT Consultants,

Business Solutions Consultants, and Information &

Media) were asked to fill in a specially prepared

questionnaire, which comprises two parts: Part A

aims at constructing the profile of an SME by

identifying the type and size of each company thus

forming the necessary background to record and

assess managers’ and employees’ opinions and

perceptions as regards system documentation. Part B

aims to evaluate whether system documentation is

equally treated and stressed emphasis upon during

the development phases. The methodology used in

the paper for information gathering combines both

primary and secondary research methods (Glass V.

G., 1976).

It was considered vital that the directors of the

SME consented to the proposed research methods.

All the relevant information is based around the

activities and general functioning of a company in

the scope of developing, assessing and maintaining

systems’ documentation delivering, eventually,

coherently and cohesively the expected output to

their customers. The authors’ prime task was to

accumulate realistic and spontaneous feedback with

reference to the answers and attitudes by the

respondents.

On the other hand, importance was given to the

analysis and creation of a documentation model that

DOING THINGS RIGHT OR DOING THE RIGHT THINGS? - Proposing a Documentation Scheme for Small to Medium

Enterprises

409

would bridge potential gaps and handle misleading

issues of existing models used by the SME at the

time of the survey.

The work reported in section 3 is summarized in

the following steps: (i) constructing and

disseminating the questionnaire, (ii) analyzing the

results (iii) proposing an optimal documentation set,

and, (iv) providing initial validation of the proposal.

3.1 Constructing the Questionnaire

A questionnaire may be defined as:

“An instrument used for eliciting and recording

responses in many, but not all, research projects

employing the questioning approach” (Dibb et al.,

1994).

Although it may seem that designing

questionnaires is a simple process, experienced

researches are quick to point out that nothing is

further from the truth (Dibb et al., 1994).

Our major concerns when designing our

questionnaire with respect to the targeted SME

revolved around the following aims:

(a) To identify the type and size of the participating

companies using a system documentation

process.

(b) To gain deeper understanding of managers and

employees’ opinions and perceptions for the

development of system documentation.

every development phase and is equally treated

and stressed emphasis upon.

(d) To identify the gaps and weaknesses of existing

system documentation models and

methodologies currently followed.

(e) To propose a minimum set of documents

adequate and efficient for SME to create,

maintain and use.

It is vital to clarify at this point that a “sloppy”

questionnaire could lead to a great deal of distortion

in the communication, from the researchers to the

respondents and vice versa. Bearing in mind this, for

each question included in the study the following

attributes had to be considered:

• Conciseness

• Clarity

• Well structured

• Easy to respond

• Providing clear direction

• On target

In order for the above attributes to be met, a set

of potential questions were formulated at first,

targeting both the managers and the employees.

Next, certain critical checks of the draft questions set

were performed to decide the most appropriate form

of each question (structured or non-structured, open-

end, close-end, etc.), whether each question was

relevant and properly worded to obtain meaningful

and valid responses, whether the sequencing of the

questions was likely to introduce any bias, and if the

layout and appearance of the questionnaire was

conducive to accurately and easily collect the data.

The questionnaire was divided into two parts:

Part A included a set of questions related to the role

of the respondents, their experience, their

employment history in the SME and also to the size,

type and number of projects undertaken, along with

some additional development information (e.g.

operating system platforms, programming languages

etc.). Part B involved a full documentation scheme

reported in various classic textbooks, the separate

documents of which the respondents should mark to

indicate production and usage during original

development or/and maintenance activities.

3.2 Experimental Analysis – The

Proposed Optimal Documentation

Set

As previously mentioned, the questionnaire was

distributed among the management and employees

of each company, focusing on their culture and

opinions, with main emphasis stressed upon

perceptions and attitudes towards the system

documentation design and maintenance. The next

step after collecting the responses was to analyze

and assess the information gathered.

In order to organize the results we targeted the

two parts of the questionnaire separately. Part A

provided results that helped us characterize the

survey sample and identify the profile of each

company in terms of personnel and nature of the

projects undertaken. Part B provided the core

information for the type of documentation actually

used during development and maintenance activities.

Nine companies provided answers to the

questionnaire with a total of 31 people, 11 of which

are employed as management staff (Directors,

Managers, IT Managers, and Project Managers) and

20 are employed as technical staff (Analysts,

Programmers, and Team leaders). It is, therefore,

straightforward to observe that the survey sample is

well balanced, taking into account both the

management and the technical perspective,

something that plays its own role in deciding upon a

globally accepted documentation set as will be

described later on.

ICEIS 2007 - International Conference on Enterprise Information Systems

410

The employment period in the specific

companies as well as the overall experience in the IT

field for both groups of employees ranges from less

than 1 year to more than 5 years, with most of the

management staff having more than five years

experience. As one can notice here, the experience is

fair to good for technical personnel and good for

managers. Both these factors (history, experience)

play a decisive role in the objectiveness, credibility

and significance of the responses. For example, staff

with rich experience and long employment history is

more appropriate to convey the necessary

documentation information as, in general, they know

the procedures and practices followed in the

company better than newly recruited personnel and

have been involved with an adequately large number

of projects thus forming a more accurate picture of

specific development aspects.

Overall, the percentage of time spent on the

seven SDLC phases is uniformly distributed among

company employees, i.e. the employees divide their

time almost equally between the different SDLC

stages. Therefore, one may not anticipate dramatic

reduction in the time spent for documentation issues.

D11

D13

D15

Documentation Component

Managers <1

Technical <1

Managers 1 to 3

Technical 1 to 3

Managers 3 to 5

Technical 3 to 5

Managers > 5

Technical > 5

Figure 1: Documentation versus employment period for

managers and technical employees in the specific

company.

D11

D13

D15

Documentation Component

Managers <1

Technical <1

Managers 1 to 3

Technical 1 to 3

Managers 3 to 5

Technical 3 to 5

Managers > 5

Technical > 5

Figure 2: Documentation versus overall experience period

for managers and technical employees in the IT field.

Concentrating on the role of the respondents and

their employment history on one hand and their

experience on the other in contrast with the creation

and usage of the documents listed on the

questionnaire, we mapped the associated survey

results on figures 1 and 2. Further analysis of these

results aimed at identifying how the usage of the

proposed documentation set varies for different roles

(i.e. management and technical staff) and experience

both during system development (we will call this

phase A) and system maintenance (we will call this

phase B).

There is an apparent difference in the above two

graphs. While during system development it seems

that the managerial staff participates in the

documentation development, this participation is

considerably decreased in the usage of the

documentation set during maintenance. This is quite

expected as technical staff does the actual

maintenance.

We decided to take into consideration the staff

differences in the subsequent analysis by assigning

different weights to the suggestions of the

managerial and technical staff based on the

employment and overall experience periods of the

two categories of employees. Higher significance

was given to the management during system

development, while the answers of the technical

staff were rated more important during the

maintenance phase. Our goal was to conclude on the

preference percentages for each of the

documentation components by taking into account

the type of personnel that is more involved with and

has the highest stake in the particular phase. More

specifically, the following weighting scheme in the

scale [1, 5] (1 is the least significant) was applied:

Phase A – Development

Management

 w

=5 for experience and employment over 5

years

 w

=3 for experience between 3 and 5 years,

and employment between 1 and 5 years

Technical

 w

=4 for experience and employment over 5

years

 w

=2 for experience between 3 and 5 years,

and employment between 1 and 5 years

Rest Management/Technical: w

Phase B – Maintenance

Management

 w

=3 for experience and employment over 5

years

 w

=2 for experience between 3 and 5 years,

and employment between 1 and 5 years

DOING THINGS RIGHT OR DOING THE RIGHT THINGS? - Proposing a Documentation Scheme for Small to Medium

Enterprises

411

Technical

 w

=5 for experience and employment over 5

years

 w

=3 for experience between 3 and 5 years,

and employment between 1 and 5 years

 Rest Management/Technical: w

After rating a certain respondent the assigned weight

determined the times a document selected was

inserted in the pool of the survey. For example, if

document D1 was marked during maintenance and

the responded was rated important with a weight

equal to 5 then D1 was inserted 5 times in the

general pool of selected documents. This way our

sample takes into account the key concepts of role,

experience and employment history.

100

1 3 5 7 9 111315171921 23252729

Documentation component

Preference percentage

50% line

Total Preference with

weights - Phase A

Total Preference with

weights - Phase B

Figure 3: Total percentage of documentation components

used for phase A (development) and B (maintenance).

The results regarding the preferences of the

survey sample using the above weights are depicted

in Figure 3.

Table 1: Documents gathering most responses with

weighted scheme.

System Life Cycle

Phase or Activity

Proposed Document

Components

Requirements

Definition

System Overview

Operations Overview

Specification Analysis

System Constraints

Development

Assumptions

Data Flow or Object

oriented Diagrams

Requirements

Analysis

Data Dictionary

Preliminary

Design

Design Overview

Design Description

Detailed Design

Data Interfaces

Implementation Test Description

System Testing

Presentation/Discussion

of Results

System Overview

Acceptance Testing

System description

The results shown in Table 1 indicate which of

the documents listed in the questionnaire mostly

created and used (i.e. received the vote of above

50% of the respondents) during the development and

maintenance phase. The set comprises 15

documentation components covering all 7 phases of

the SDLC, that combine high usage only during

system development since none of the documents

used for system maintenance received more than

50% of the votes.

It is apparent that during maintenance there is a

reduced usage of the developed documentation set.

Additionally, in order to detect potential

documentation gaps, we first identified the

documentation components missing from the list of

preferred deliverables. This provided an indication

of what the participating SME do not consider

important and can skip in the documentation

process, in order to effectively manage their time

and resources.

To arrive to the proposed documentation set we

have isolated the documents that the technical staff

has indicated to mostly use during maintenance and

checked whether they are covered by the

deliverables gathering above 50% preference during

system development. Since we have used weights to

reflect overall experience and employment period,

the preferences in Figure 3 reflect familiarity of

respondents with the specific company’s policies as

well as experience in the field, achieving a more

complete picture of both development and

maintenance activities and capturing the business

targets and goals of the SME. Since none of the

documentation components used in phase B reached

50% of the employee votes, we have selected to

check which of the documents reach and surpass the

30% of the votes. Lowering the preference threshold

does not bias the results since it became evident that,

as in many SME around the world, our sample of

companies seems to be more production than

maintenance-oriented. Thus, those employees that

give emphasis on maintenance issues, although a

minority, may pave the way for improving the

processes followed within the SME by suggesting

documentation usage for maintenance purposes.

A total of 10 documentation components appear

to gather the 30% preference during the maintenance

phase. However, there is an inconsistency between

the selected set presented in Table 1 and these 10

deliverables. Out of these 10 deliverables, 3 are not

included in the preferred set with the 50% threshold.

These are: (a) Operations Overview of the Detailed

Design phase (b) Detailed description of input and

output of the Acceptance testing phase and (c)

ICEIS 2007 - International Conference on Enterprise Information Systems

412

Internal Storage Requirements of the Acceptance

Testing Phase. Thus, to propose a complete

documentation set covering all indicated needs of

the participating SME we decided to add these 3

documentation components in the list presented in

Table 1. Table 2 lists the complete proposed

documentation set which comprises now 18

documentation components.

Table 2: Proposed (“optimal”) Documentation Set.

System Life

Cycle Phase or

Activity

Proposed Document

Components

Requirements

Definition

System Overview

Operations Overview

Specification Analysis

System Constraints

Development Assumptions

Data Flow or Object oriented

Diagrams

Requirements

Analysis

Data Dictionary

Preliminary

Design

Design Overview

Operations Overview

Design Description

Detailed Design

Data Interfaces

Implementation Test Description

System Testing

Presentation/Discussion of

Results

System Overview

System description

Detailed Description of input and

output

Acceptance

Testing

Internal Storage Requirements

Our final task was to compare the final set with

that suggested by literature and identify critical

documents that might be missing from the proposed

list. As one may observe, Table 2 includes indeed a

more or less complete documentation basis with

Requirements, Specification and Design fully

covered. Implementation and Testing also seem

complete although more documents may be added

here (e.g. implementation strategy). It should be

noted, however, that we did not include an

exhaustive list of documents in the questionnaire as

we were addressing SME with limited resources

(time, budget, staff) and therefore we expected a

bearing minimum in documentation management.

3.3 Experimental Validation

The only way to validate the proposed

documentation scheme was to consult the SME

participated in our survey. Therefore, we went back

to the nine companies and discussed mostly with

employees (both management and technical

personnel) that marked less documents than those in

the “optimal” list, attempting to trace the reasons for

not creating or using certain types of documents. It

was interesting to notice that the majority of the

discussion outcomes agreed on the following:

i. Time is very critical and often at the expense of

proper documentation

ii. There is absence of a disciplined process to guide

and monitor documentation related issues

Additionally, some of the respondents raised a

significant issue that is worthy of mentioning here

and was related to what type of documents is

considered necessary when producing software and

why. This issue roots back to the lack of

fundamental knowledge and experience as regards

the true value of documentation which is usually lost

somewhere between the struggle to win new

software contracts and the race to catch up with

deadlines. In this context, insufficient and inefficient

project management results in less control of

documentation produced and used, something which

was strongly confirmed by the survey participants.

As a final step we asked the respondents to study

the proposed documentation scheme and comment

on completeness, value and potential difficulties for

practical application. The general feeling was that

indeed the proposed scheme is critical and extremely

helpful especially at the maintenance stage.

Nevertheless, the price to be paid in time overhead

was estimated to range between 5-15% of the total

development time currently spent so as to add the

proposed missing documents. Additionally, in 5 out

of 9 companies surveyed at least one case was

identified where the problems faced during

enhancements or improvements of the delivered

software product would have been avoided if the

proposed documentation scheme was adopted and

followed.

4 CONCLUSIONS

The initial question posed by this paper was whether

things should be done “right” or instead doing the

right things is better. Doing things right in our case

requires for a complete documentation set according

to the theoretical model that follows the Waterfall

SDLC. However, as has been indicated several times

in this work, SME are usually pressured to deliver a

complete system with documentation within a

certain time frame and with limited resources. It is,

therefore, not possible to develop a complete

DOING THINGS RIGHT OR DOING THE RIGHT THINGS? - Proposing a Documentation Scheme for Small to Medium

Enterprises

413

documentation set. This is seen from our survey

results, as the companies do not develop all of the

documentation components indicated by our

theoretical model.

This work’s ultimate goal was to present an

empirical investigation of documentation issues and

propose a minimum set of documents required to

satisfy both the theory and the companies’ needs. In

the proposed set we included the documents mostly

developed and used by the companies enquired and

excluded those less developed and used. For the

components that are sometimes used we draw a

decision based on the importance of those

documents in the theoretical model.

For the research conducted, nine SME have

been approached and with the use of a

comprehensive questionnaire, the authors were in a

position to gather all the necessary information for

the analysis process. These results, in combination

with a balanced literature review, as well as the use

of the Waterfall system development life cycle

model as a guide, enabled the identification of the

apt minimum set of documents to be used for the

specific type of enterprises.

Future work will concentrate on extending the

survey sample including SME with different profile

characteristics. Our goal will be to link better certain

SME organizational and procedural factors with the

size and quality of documentation produced and

utilized, as well as to trace the sources better and

investigating in depth the origin of neglecting such a

significant set of activities. Further, additional

validation is planned where the obtained results will

be cross-checked by new companies that will adopt

them.

REFERENCES

Arisholm E., Briand L.C., Hove S.E., and Labiche Y.,

2005. The Impact of UML Documentation on

Software Maintenance: An Experimental Evaluation,

Proceedings of the International Conference on

Software Engineering Research and Practice

(SERP'05), Monte Carlo Resort, Las Vegas, Nevada,

USA, June 27-30, Technical Report SCE-05-11,

Version 2.

Baldassarre M.T., Caivano D., and Visaggio G., 2006.

Software Product Lines in Value Based Software

Engineering. Proceedings of the 10th International

Conference on Evaluation and Assessment in Software

Engineering (EASE 2006), April 10-11 (to appear).

Beck K., 1999. Embracing Change with Extreme

Programming, IEEE Computer, pp. 70-77.

Boehm W. B., 1988. A Spiral Model of Software

Development and Enhancement, IEEE Software, pp.

61-72.

Cusumano A. M., Selby W. R., 1997. How Microsoft

Builds Software, Communications of the ACM, pp. 53-

61.

Dibb, Simkin, Pride, Ferell, 1994. Marketing: Concepts

and Strategies,.5

European edition, Houghton

Mifflin.

e-MINDER: Electronic Commerce, Leveraging Network

for Developing European Regions,

http://www.eminderproject.com

Georgiou S., Germanakos P., 1999. Assessing the Services

Quality and Relationship Marketing Parameters of

KAI Computer Services Ltd. In the U.K. and the

Factors that need to be Considered when Venturing

into the European Market via the Internet, M.Sc. final

year thesis, Leeds University Business School, Leeds,

U.K.

Glass V. G., 1976. Primary, Secondary, and Meta-

Analysis of Research . Educational Researcher, Vol.

5, No. 10, pp. 3-8 doi:10.2307/1174772.

Henderson-Sellers B., Edwards M. J., 1990. The Object-

Oriented Systems Life Cycle, Communications of the

ACM, Vol.33:9, pp. 142-159.

McGregor L. S., 1982. Improving Documentation.

Otoya S., Cerpa N., 1999. An Experience: A Small

Software Company Attempting to Improve its Process,

IEEE Computer Society Washington, DC, USA, pp.

153-160.

Pfleeger L.S., Kitchenham A.B., 2001. Principles of

Survey Research. Part1: Turning Lemons into

Lemonade. ACM SÌGSOFT, Software Engineering

Notes, vol. 26 no 6, pp. 16-18.

Pfleeger S.L. 2001. Software Engineering, Theory and

Practice (2nd edition). Prentice Hall: New Jersey.

Pressman RS. 2005. Software engineering: A

practitioner’s approach, 6

Ed. McGraw-Hill: London.

Royce W., 1998. Managing the Development of Large

Software Systems: Concepts and Techniques, 1970

WESCON Technical Papers, Western Electronic Show

and Convention, Los Angeles, August 1970, pp. A/1-1

– A/1-9. Reprinted in Proceedings of the 11

International Conference on Software Engineering,

Pittsburgh, May 1989, pp. 328-38.

Schach SR. 2005. Classical and Object-Oriented Software

Engineering, 6

Ed. McGraw-Hill: London.

Sickler J.G., 1982. System Documentation as Software,

Proceedings of the 1

annual international conference

on Systems documentation, ACM Special Interest

Group for Design of Communication, ACM Press,

NY,USA, pp. 139-142.

Sommerville I. 2007. Software Engineering, 8

Ed.,

Addison-Wesley.

ICEIS 2007 - International Conference on Enterprise Information Systems

414
