INTEGRATING AGENTS INTO COOPERATIVE INTELLIGENT

DECISION SUPPORT SYSTEMS

Abdelkader Adla

IRIT, Paul SABATIER University, 118 Route de Narbonne, Toulouse, France

Department of Computing, Oran University, Algeria

Keywords: Decision Support Systems, Cooperative Intelligent DSS, Agent-based DSS.

Abstract: In this paper, we propose to integrate agents in a cooperative intelligent decision support system. The

resulting system, ACIDS (Agent-based Cooperative Intelligent Decision-support System) is a decision

support system designed to support operators during contingencies by giving them detailed, real-time

information, allowing them to integrate and interpret it and then transmit and monitor their decisions

through the chain of incident command. During the contingency, the operator using the ACIDS should be

able to: gather information about the incident location; access databases related to the incident; activate

predictive modelling programs; support analyses of the operator, and monitor the progress of the situation

and action execution. The decision making process, applied to the boilers management system, relies in

ACIDS on a cycle that includes recognition of the causes of a fault (diagnosis), plan actions to solve the

incidences and, execution of the selected actions.

1 INTRODUCTION

Decision Support Systems (DSS) were designed to

resolve ill or non-structured decision problems.

Problems where priorities, judgements, intuitions

and experience of the decision-maker are essential,

where the sequence of operations such as searching

for a solution, formalization and structuring of

problem is not beforehand known, when criteria for

the decision making are numerous, in conflict or

hard dependent on the perception of the user and

where resolution must be acquired at restricted time.

Successful cooperative intelligent DSS and their

subsystems act intelligently and cooperatively in a

complex domain with potentially high data rates and

make judgements that model the very best human

technicians. It is also crucial that human technicians

maintain control over the final judgments, either by

focusing the system on particular reasoning goals, or

by modifying the basic knowledge on which the

systems judgements rely.

In this way, the cooperative intelligent DSS is

able to capture the domain knowledge and provide

intelligent guidance during the process. While the

data and model manipulations are done through the

DSS, decision makers can focus solely on the

process issues.

In this paper, we propose a cooperative

intelligent decision support system based on a multi-

agent architecture. The use and the integration of

software agents in the decision support systems

provides an automated, cost-effective means for

making decisions

The rest of the paper is organized as follows:

First we present a literature review of some related

work in section 2. Then we propose a multi-agent

architecture for cooperative intelligent decision

support systems in section 3. We also present an

example application to illustrate the feasibility of the

idea in section. Finally, we conclude with a

summary and future research direction in section 4.

2 LITERATURE REVIEW

2.1 Decision Support

Decision support systems (DSS) are computer-based

systems designed to support and enhance managerial

decision making. Since 1970s, the field has evolved

440

Adla A. (2007).

INTEGRATING AGENTS INTO COOPERATIVE INTELLIGENT DECISION SUPPORT SYSTEMS.

In Proceedings of the Ninth International Conference on Enterprise Information Systems - AIDSS, pages 440-446

DOI: 10.5220/0002388904400446

 SciTePress

from the disciplines of management science and

management information systems.

It has come to include personal decision support

systems, group decision support systems, negotiation

support systems, intelligent decision support

systems, knowledge management based DSS,

executive information systems/business intelligence

systems, and data warehouses (Power, 2000).

According to Turban and Aronson (1998), the

central purpose to a DSS is to support and improve

decision making. Zarate (2005) defines DSS as a

“model-based set of procedures for processing data

and judgements to assist a manager in his decision

making”. He argues that to be successful such a

system needs to be adaptive, easy to use, robust and

complete on important issues. These features are

desired but not required in a DSS. Holtzman (1989)

defines a DSS as a computer-based system

consisting of three interacting components: a

language system, a knowledge system and a problem

processing system. This definition covers both old

and new DSS designs, as the problem processing

system could be a model-base or an ES or an agent-

based system or some other system providing

problem manipulation capabilities.

While each type of DSS varies in their

technologies, their common purpose is to aid human

judgement in decision making. A DSS might

achieve this through advanced capabilities in

information storage and retrieval. Using

mathematical modelling techniques, a DSS may also

provide forecasting capabilities, including

calculations of the best solutions to “what-if”

scenarios.

A number of frameworks or typologies have

been proposed for organizing our knowledge about

decision support systems (Power, 2000). The two

most widely implemented approaches for delivering

decision-support are Data-Driven and Model-Driven

DSS. Data-Driven DSS help managers organize,

retrieve, and synthesize large volumes of relevant

data using database queries, OLAP techniques, and

data mining tools. Model-Driven DSS use formal

representations of decision models and provide

analytical support using the tools of decision

analysis, optimization, stochastic modelling,

simulation, statistics, and logic modelling. Three

other approaches have become more wide spread

and sophisticated because of collaboration and web

technologies: Communication-Driven DSS rely on

electronic communication technologies to link

multiple decision makers who might be separated in

space or time, or to link decision makers with

relevant information and tools. Knowledge-Driven

DSS can suggest or recommend actions to managers.

Finally, Document-Driven DSS integrate a variety of

storage and processing technologies to provide

managers document retrieval and analysis. Classic

standalone DSS tool design comprises components

for: (1) database management capabilities with

access to internal and external data, information and

knowledge; (2) powerful modelling function

accessed by a model management system; and (3)

user interface design that enable interactive queries,

reporting and graphic functions.

2.2 Intelligent Decision Support

Systems

Intelligent decision support systems (IDSSs) are

interactive computer-based systems that use data,

expert knowledge and models for supporting

decision makers in organizations to solve complex,

imprecise and ill-structured problems by

incorporating artificial intelligence techniques. They

draw on ideas from diverse disciplines such decision

analysis, artificial intelligence, knowledge-based

systems and systems engineering. In general, the

need for IDSS derives from: (i) the growing need for

relevant and effective decision support to deal with a

dynamic, uncertain and increasingly complex

management environment, (ii) the need to build

context-tailored, not general purpose systems, and

(iii) standard support technology is becoming

obsolete as a way to improve decision quality and

work productivity (Ribeiro et al., 2006).

Intelligent decision support systems (IDSSs) use

Expert Systems (ES) technology to enhance the

capabilities of decisions makers in understanding a

decision problem and selecting a sound alternative.

Because of the people-centred focus of such

technologies, it is important not only to assess their

technical aspects and overall performance but also to

seek the views of potential users. Turban and

Aronson (2001) suggested two fundamental ES/DSS

integration models: (1) ES is integrated into DSS

components, and (2) ES is a separate component in

the DSS. In (Power, 2000), the second model is

used, where the DSS is responsible for both data and

model manipulation, while the ES provides domain

knowledge and recommends resolutions during the

planning the process. The proposed architecture

signifies the integration of a DSS and an ES. During

the process, data and models are manipulated

through the DBMS and model base management

system (MBMS), respectively. Instructions for data

modifications and model execution may come from

the ES interface directly. The MBMS obtains the

relevant input data for model executions from the

INTEGRATING AGENTS INTO COOPERATIVE INTELLIGENT DECISION SUPPORT SYSTEMS

441

DBMS and, in return, results generated from model

executions are sent back to DBMS for storage. The

database also provides facts for the ES as part of the

knowledge base. Using these facts together with the

predefined rules, the inference engine of the ES

performs model validations and planning

evaluations, according to what a domain expert is

supposed to do. Conclusions and recommendations

are then passed to the interface, where they are

displayed to the decision maker and transferred to

the MBMS and DBMS, in the form of procedures

calls for various actions.

However, making a simple machine act

intelligently may be much less useful or important

than being able to cooperate in an environment with

the users. It is found that “lack of attention to the

human and organizational aspects of IT is a major

explanatory factor and is manifest in a failure to

involve users appropriately (Guerlain, 2000)

Indeed, despite their impressive functionalities,

DSS of all of types are focused on supporting, not

replacing, a human decision maker for important

decision tasks, as many of the problem situations

faced by managers are unstructured in nature and

require the use of reasoning and human judgement.

Therefore, as articulated by Lévin and Pomerol

(1995), “the DSS and the decision maker form a

united problem solver”. In DSS, the user is defined

by physical and purposeful interaction with the

system. Therefore, a system might have one, or

many users, each interacting with the system in

different ways, for different purposes, and with

varying frequencies. As Keen (1981) stated, decision

support systems “support, rather than replace,

judgement in that they do not automate the decision

process nor impose a sequence of analysis on the

user”. Therefore, judgement and decision making

must occur throughout the entire problem solving

process, that is, during the user’s physical interaction

with the system, and as the final human decision is

being made. Because of this, the user’s decision

processes must be factored into the design process of

successful cooperative intelligent decision support

systems.

Some other advantages proposed by Marakas

(2003) gives the advantages of using intelligent

components with DSSs as opposed to plain DSSs as

increased timeliness in making decisions, improved

consistency in decisions, improved explanations and

justifications for specific recommendations,

improved management of uncertainty, and

formalisation of organisational knowledge. The most

useful of these advantages is the improved

explanations and justifications which is an extremely

useful feature particularly in the fields like medicine,

etc. where it helps if the real expert can validate the

machine reasoning.

2.3 Multi-Agent Systems

Using agent provides a means of modelling the

various information flows and interactions with the

user and within the environment. The working

definition of an agent is adapted from (Jennings,

1996): an agent is an artificial, computational entity

that can perform certain tasks with a certain degree

of autonomy or initiative whilst intelligently

adapting to its environment. Note that a human is

not an agent in this definition.

The definition of multi-agent systems (MAS) is

well known and accepted as a loosely coupled

network of agents that work together to find answers

to problems that are beyond the individual

capabilities or knowledge of each agent and there is

no global control system. An agent’s architecture is

a particular design or methodology for constructing

an agent. Wooldridge and Jennings refer to an

agent’s architecture as a software engineering model

of an agent (Jennings, 1996). Using these guidelines,

agent architecture is a collection of software

modules that implement the desired features of an

agent in accordance with a theory of agency. This

collection of software modules enable the agent to

reason about or select actions and react to changes in

its environment.

A broad range of architectures for agents

(including reactive, deliberative…) have been

studied. Properties that distinguish the version agent

architectures include reasoning capabilities, resource

limitations, control flow, knowledge handling,

autonomy, user interaction, temporal context, and

decision making.

Integrated architectures that include both

deliberative or classical planning and reactive

components can support a more autonomous agent

than either architecture can support alone. An

integrated architecture provides a mechanism that

enables an agent to both deliberate and respond

efficiently to exogenous events.

ICEIS 2007 - International Conference on Enterprise Information Systems

442

3 AGENT-BASED

COOPERATIVE

INTELLIGENT DSS

3.1 Cooperative Intelligent DSS

To cooperate, particularly means distributing tasks

to be carried out among both the system and the

user. Sharing tasks is a condition to implement

cooperation between the two agents. The task that is

the subject of cooperation is decomposed in

consistent subsets. The decision to be made is

modelled in tasks and sub-tasks as well as the

associated methods to achieve them. This modelling

is based on a hierarchy (tree) of tasks and sub-tasks

introducing then a relation of order between the

different tasks to be achieved.

The task distribution between the system and the

user is dynamically made, according to the

performances of the couple man/machine and of the

workload of the user. Competences of the user and

the system are sometimes complementary,

sometimes “redundant”. In the latter case, user and

system are often able to play the same role. The

choice question of the appropriate agent which will

have to play one role settles therefore. According to

the context, different indications could be made to

direct this choice. The set of indications on the

manner to allocate different roles to the agents

defines the cooperation modes.

For the implementation of the system/user

cooperation, we use a structure based principally on

conceptual models of expertise: Domain Conceptual

Model Task Conceptual Model (of the application

for the system, but also of the users). The proposed

architecture (Adla, 2006) for the design of a

cooperative intelligent decision support system

extends that of Soubie (1998) developed for

cooperative knowledge-based systems.

The proposed architecture is composed of the

following main components:

Data Base Management System (DBMS):

mainly contains a relational database which is

managed by a software program called the database

management system, and which provides speed data

retrieval, updating, and appending. The data in a

DSS database are usually extracts or copies of

operational databases, so using a DSS does not

interfere with critical operation systems.

Model Base Management System (MBMS):

The model base subsystem includes many statistical,

management scientific models, or other quantitative

models that offer the system’s analytical or

forecasting capability to solve future outcomes.

There are many types of models: Statistical models

generally contain the full range of expected

statistical functions including means, medians,

deviations and scatter plots, Optimization models,

such linear programming and dynamic

programming, are often adopted to determine the

optimal resource allocation to maximize or minimize

an objective function.

Knowledge Base Management System

(KBMS): it can support any of the other subsystems

or play an independent role. It suggests alternatives

or actions to decision makers. Additionally, it can be

inter-connected with the knowledge base.

Task Management Tool (Control): This tool

has as objective to offer resolutions or parties of

resolutions to the users. It insures the task

decomposition in sub-tasks as well as the assignment

of roles to the system or to the user. This planning

tool allows collaboration between the machine and

the user, and assigns the tasks beforehand modelled

to them. Particularly, this planning tool is able to

manage this task allocation in a dynamic way and, to

change planning initially implemented according to

the controls of the different tasks. This tool

constitutes essential provision in cooperation

management. The man-machine cooperation is

possible only if this task management tool allows a

quick re-planning as well as a re-counting of

allocations if there is a context modification or an

evolution of the problem. This approach insures the

dynamic character of the tool.

3.2 Integrating Agents

3.2.1 The Boilers Management System

The management system of the boiler combustion is

one of the most critical systems for the good

functioning of the plant and has a high impact on the

methods of cogitation and apprehension of various

problems related to maintenance. The exploiting

staff is often confronted with situations that impose

a quick reaction of decision-making. This requires

consequent human and material resources and

adapted skills. We experiment our system on a case

of boiler breakdown to detect a functioning defect of

the boiler, to diagnose the defect and to suggest one

or several appropriate cure actions.

Usually, in a situation of contingency

(breakdown of a boiler), the exploiting engineers

(the process administrator and the direct operators),

tent to identify the breakdown, to analyse and

diagnose it on the local site, to make contact with

INTEGRATING AGENTS INTO COOPERATIVE INTELLIGENT DECISION SUPPORT SYSTEMS

443

other exploiting engineers of the parent company

and send for the technicians of the boilers

constructor company, in general located abroad.

This type of situation, compel the plant to work in

degraded functioning if not to stop the process (case

of shutdown alarm) waiting for the problem solving.

Different sensors are set up to detect anomalies

at different stages of the process. Breakdown can be

automatically signposted by means of an alarm or

intercepted by the exploiting engineers (case of

defectiveness of the sensor where no alarm is

triggered off but the boiler does not work). If there is

a defect, an alarm will be triggered off. In case an

alarm is signposted to the operator: the flag (the

reference given to every alarm) is pointed out on the

board (control room). It acquaints with an alarm and

locates the defect. To solve this problem, diagnosis

and actions of cure are generated by the system.

Otherwise, a breakdown is directly raised by the

operator (not triggered off alarm). This scenario

occurs when a sensor defect doesn’t allow to

automatically signpost the breakdown. In this case,

the operator must explore a large research space of

potential defects with a series of tests. In both cases,

the operator tries to solve the problem by using the

Agent-based Cooperative Intelligent DSS (ACIDS).

Managing this process is a complex activity which

involves a number of different

sub-tasks: monitoring

the process, diagnosing faults, and planning and

carrying out maintenance when faults occur.

3.2.2 The Multi-agent Architecture

Agents were integrated into the DSS for the purpose

of automating more tasks for the user, enabling more

indirect management, and requiring less direct

manipulation of the DSS. Specifically, agents were

used to collect information outside of the

organisation and to generate decision-making

alternatives that would allow the user to focus on

solutions that were found to de significant.

A set of agents is integrated to the system and

placed in the DSS components, according to our

architecture of Cooperative Intelligent DSS (figure

1). Note that agents have placed in each of the

components.

The Interface Agent (IA): continuously

receives data from the process – e.g. alarm messages

about unusual events and status information about

the process components. From this information, the

IA periodically produces a snapshot which describes

the entire system state at the current instant in time.

It also performs a preliminary analysis on the data it

receives from the process to determine whether there

may be a fault. Interface agents have the following

knowledge: User models and knowledge of what

must be displayed to the user and in what way. User

models could be interactively updated. The main

functions of an interface agent include; 1) collecting

relevant information from the user to initiate a task,

2) presenting relevant information including results

and explanations, 3) asking the user for additional

information during problem solving, and 4) asking

for user confirmation, when necessary. From the

user’s viewpoint, interacting only through a relevant

interface agent for a task hides the underlying

information gathering and problem solving

complexity.

A Task Management Agent (TMA) performs

most of the autonomous problem solving. It exhibits

a higher level of sophistication and complexity than

other agents.

Figure 1: The ACIDS multi-agent architecture.

IRA

Decision

Maker

ICEIS 2007 - International Conference on Enterprise Information Systems

444

A TMA (1) receives user delegated task

specifications from an IA, (2) interprets the

specifications and extracts problem solving goals,

(3) forms plans to satisfy these goals, (4) identifies

information seeking sub-goals that are present in its

plans, (5) decomposes the plans and coordinates

with appropriate Information Retrieval Agent (IRA),

Modelling Agent (MA), Diagnosis Agent (DA) and

Action Agent (AA) for plan execution, monitoring,

and results composition. A TMA has the following

knowledge: 1) knowledge for performing the task

(e.g. query decomposition, sequencing of task steps),

2) information gathering needs associated with the

task model, 3) knowledge about relevant

information, modelling, diagnosis, and action agents

that it must coordinate with in support of its

particular task, 5) protocols that enable coordination

with the other relevant agents.

An Information Retrieval Agent (IRA)

primarily provides intelligent information services.

The simpler of these services is a shot retrieval of

information in response to a query: a more enhanced

information service is constant monitoring of

available database for the occurrence of predefined

information patterns. An even more advanced

information agent can, in addition to communication

with other agents, monitor its data base for the

appearance of particular patterns. A typical

information specific agent knows: 1) model and

associated meta-level information of the databases

that it is associated with, such size, average time it

takes to answer a query, 2) procedures for accessing

databases, 3) conflict resolution and information

fusion strategies, and 4) protocols for coordination

with other relevant software agents.

A Modelling Agent (MA): anticipates the

occurrence of contingencies using mathematical and

computational models. It integrates data from

different sources with mathematical and

computational models that model the contingency in

order to predict its behaviour and consequences.

A Diagnosis Agent (DA) is activated by the

receipt of information from TMA which indicates

that there might be a fault. It uses IA snapshot

information to update its knowledge model of the

process on which its diagnosis is based. It pinpoints

the approximate region of the fault then it generates

and verifies the cause of the fault in the process.

The Action Agent (AA) generates a plan of

action which can be used to repair the process once

the cause and location of the fault have been

determined.

The DA (respectively AA) takes as input a set of

goals: faults (respectively causes) and produces a

plan that satisfies the goals.

3.3 Task Resolution

When the task management agent (TMA) receives a

task from an interface agent (IA), it decomposes the

task based on the domain knowledge it has and then

delegates the primitive tasks to the other agents

(IRA, MA, DA or AA). The task management agent

will take responsibility for retrieving data,

modelling, diagnosing fault, planning action,

resolving conflicts, coordinating among the related

agents and finally reporting to the interface agent

which conveys the results to the user.

The task management agent first gets input data

through the interface agent. Next, the modelling

agent searches for rules to select a suitable model

and to execute the model to get analytical results.

Additionally, all the parameters values needed by

the models are retrieved from the database via the

information retrieval agent. After finishing model

analysis, the diagnosing and the action agents use

the results of the model analysis to identify the fault

causes and to perform a suggested action plan. Of

course, sometimes, the diagnosis and the action

agents may independently infer knowledge rules

without using any model.

Different methods to achieve a task can be

envisaged. Given a task, the system can then choose

a method dynamically to achieve it. In order to do

that, given the name of the task to be solve (wording

of problem), the system constructs an action plan to

be carried out (a sub-graph of tasks-methods

hierarchy).

To this end, first candidate actions are proposed.

Next, these candidates are checked upon feasibility

and relevance. Finally from the approved actions a

repair plan is prepared. The execution of this plan

(guided by the human operator) is monitored

cooperatively by IA, which groups any alarm

messages coming from the process, and DA which

checks that PA’s predictions about the various

intermediate states of its recover plan are in fact

reflected in the real process.

Obviously, one of the major issues involved in

multi-agent systems is the problem of

interoperability and communication between the

agents. In our framework, we use the KQML

language for inter-agent communication. Agents

communicate through messages. An agent transfers

its request to one or more agents and receives the

information requested as a result through messages.

When an action is performed, the related

information is also transferred by the IA to the

decision maker as messages.

INTEGRATING AGENTS INTO COOPERATIVE INTELLIGENT DECISION SUPPORT SYSTEMS

445

4 CONCLUSIONS

The multi-agent system paradigm represents one of

the most promising approaches to address decision

making problems. We have integrated agents into

DSS for the purpose of automating more tasks for

the user, enabling more indirect management, and

requiring less direct manipulation of the DSS.

Specifically, agents were used to collect information

and generate alternatives that would allow the user

to focus on solutions that were found to be

significant.

The proposed architecture is under

implementation and experimentation on the boilers

management system. The next phase in our research

could be the validation of the prototype and testing

its value par practitioners.

Proposal for future research is to integrate this

architecture in a distributed one for cooperative

intelligent decision system where several decision

makers are geographically dispersed and work to

reach a common decision.

REFERENCES

Adla, A., 2006. Système coopératif d’aide à la décision,

IHM’06, Montréal, Canada.

Adla, A., Soubie, J-L., Zarate, P., 2006. A distributed

architecture for cooperative decision support systems.

EuroWorgroup Workshop on decision support

systems, London, England.

Arnott, D., Pervan, G. 2005. A critical analysis of decision

support systems research. Journal of Information

Technology, 20(2), pp67-87.

Courtney, J.F., 2001. Decision making and knowledge

management in inquiring organizations: toward a new

decision making paradigm for DSS. Decision Support

Systems 31/1, pp17-38.

DeSanctis, G., Gallup, B., 1997. A foundation for the

study of group decision support systems. Management

Science, Vol. 13 No 12, pp1589-1609.

Gachet, A., 2003. A Software Framework for Deloping

Disributed Cooperative Decision Support Systems.

Inaugural Dissertation. University of Fribourg,

Switzerland.

Guerlain, G., 2000. Interactive advisory systems. In

Proceedings of HPSAA Conference, Savannah, GA.

Holtzman, S., 1989. Intelligent decision systems. Addison

Wesley.

Jennings, E., 1996. Using intelligent agents to manage

business processes. In B. Crabtree and N. R. Jennings

editors, Proceedings of the 1

international

conference on practical applications of intelligent

agents and multi-agent technology (PAAM96), pp345-

360.

Keen, P.G.W., 1981. Value analysis: Justifying Decision

Support Systems. MIS Quaterly, 5(1), pp15-25.

Lévine, P., Pomerol, J-C., 1995. The role of decision

maker in DSSs and representation levels. In

Proceedings of Hawaii International Conference on

System sciences, pp42-51.

Marakas, G., 2003. Decision support systems in the 21st

century. Prentice Hall.

Power D. J., 2000. Supporting Decision-Makers: An

Expanded Framework, http://dssresources.com,

version 1.0, December 15.

Ribeiro, R., 2006. Intelligent Decision Support Tool for

Prioritizing Equipment Repairs in Critical/Disaster

Situations. In Proceedings of the workshop On

Decision Support Systems.

Soubie, J.L., 1998. Modelling in cooperative based

systems. In Proceedings of COOP’98, Cannes France,

may.

Turban, E., Aronson, J., 2001. Decision support systems

and intelligent systems. Prentice-Hall International,

Upper Saddle River, New Jersey.

Zarate, P., 2005. Des systèmes interactifs d’aide à la

décision aux systèmes coopératifs d’aide à la décision:

Contributions conceptuelles et fonctionnelles.

Mémoire HDR, INP de Toulouse.

ICEIS 2007 - International Conference on Enterprise Information Systems

446
