A WEB TOOL FOR WEB DOCUMENT AND DATA SOURCE

SELECTION WITH SQLFI

Marlene Goncalves and Leonid Tineo

Universidad Simón Bolívar, Departamento de Computación, Apartado 89000, Caracas 1080-A, Venezuela

Keywords: Queries, fuzzy queries, database, Web interface, SQL.

Abstract: WWW is composed of a great volume of documents that are stored by several data sources. Normally, a

user is interested in those documents that include certain keywords. However, these documents might be

incomplete, ancient or huge, and therefore, the user would have to discard irrelevant ones. An ideal Web

search tool might select the best documents in base on user criteria defined over quality parameters such as

completeness, recentness, frequency of updates and granularity. Traditional query languages are very

restrictive in expressing preference-based queries. Therefore new query languages, such as SQLf, are

needed. We present a tool that allows the selection of the best data sources and documents in terms of user

preferences. Documents and data sources are described according to quality parameters. User preferences

are expressed by means of SQLf queries. Our tool contains a wizard to retrieve the best documents and data

sources. Thus, the user is oriented by a set of steps where a preference query that involves quality

parameters is built easily.

1 INTRODUCTION

Two problems exist when a user wants to specify

preference using a traditional querying language,

such as SQL. First, a traditional query might return

empty answers if user criteria are very restrictive

and none of the rows satisfy the criteria. Second, a

lot of answers might be retrieved if criteria are so

soft and therefore, the user must discard irrelevant

ones. For these two reasons, preference querying

languages have been defined mainly.

SQLf is a preference querying language based on

fuzzy logic (Bosc and Pivert, 1995). SQLf2 and

SQLf3 are two SQLf extensions that consider SQL2

(ANSI X3, 1992) and SQL3 (Melton, 1992)

standards, respectively (Goncalves and Tineo,

2001a, 2001b). In this work, we have adopted SQLf

extensions due to the best of our knowledge none of

the existing preference querying languages include

SQL2 and SQL3 features in order to get a higher

expressivity in the queries.

We think that it is not sufficient to propose fuzzy

query languages, but also make a real

implementation of fuzzy querying systems. In this

sense, we have developed SQLfi (Eduardo,

Goncalves and Tineo, 2004) which is a fuzzy

querying system that implements SQLf, SQLf2 and

SQLf3 languages, and it is conceived to be used on

Internet.

On the other hand, high volume of available data

sources and documents on the Web leads us to select

what are the best ones that must be used for any

search. Both documents and data sources might be

incomplete, ancient or huge. Thus, the best ones

might be selected in terms of user criteria defined

over quality parameters such as completeness,

recentness, frequency of updates and granularity.

As ever, if the selection is based on traditional

querying languages, there are risks of empty answers

and a lot of undiscriminated answers. As we are

selecting not the documents but the data sources, the

problem is intensified, because a bad selection might

leads to a lot of undesired answers and unacceptable

performance. Additionally, a user may spend a lot of

superfluous time examining a huge undiscriminated

answer. In consequence, SQLfi might be used to

choose the best data sources and documents.

However, a SQLfi user needs to know SQLf

language. So, an amateur user requires a wizard that

builds a preference query where the best data

sources and documents are retrieved. In this work,

we present a Web tool that allow to select the best

documents and data sources in base on user criteria

defined over quality parameters and using SQLfi.

449

Gonçalves M. and Tineo L. (2007).

A WEB TOOL FOR WEB DOCUMENT AND DATA SOURCE SELECTION WITH SQLFI.

In Proceedings of the Ninth International Conference on Enterprise Information Systems - DISI, pages 449-452

DOI: 10.5220/0002393704490452

 SciTePress

Our tool has two components. The first, a preference

query wizard to give the user guidance on the choice

of the best documents building a preference query

that involve quality parameters. The second, a

catalog manager that describes documents and data

sources by means of quality parameters.

The paper comprises 5 sections. In Section 2, we

briefly describe related works and background. In

Section 3, we present a motivating example for

selecting of the best documents and data sources. In

Section 4, we show the architecture of our Web

selection tool. Finally, in Section 5, the concluding

remarks and future work are pointed out.

2 RELATED WORKS AND

BACKGROUND

On one hand, several works have been proposed to

provide flexible querying database systems; some of

them are: (Loo and Lee, 2000; Galindo, Urrutia and

Piattini, 2006). However, none of these systems

allow to specify fuzzy queries with both SQL2 and

SQL3 features, and therefore they have less

expressivity capabilities. On the other hand, various

researches have focused their interest in Web

querying languages: (Konopnicki and Shmueli,

1995; Mendelzon, Mihaila and Milo, 1997; Mihaila,

Raschid and Tomasic, 1998). But, none of these

previous works have incorporated fuzzy features.

Finally, Goncalves and Tineo (2005) proposed

solving Web data source selection problem by

means of SQLfi use.

A SQLf query has the following syntax:

SELECT <attributes> FROM <relations>

WHERE <fuzzy condition>

WITH CALIBRATION [n|λ|n,λ]

Its result is Cartesian product of the relations in

the FROM clause, selecting those rows that satisfied

the fuzzy condition and taking the fuzzy projection

of attributes in the SELECT clause. In the WHERE

clause, some logical expressions can be used with

user-defined terms (atomic predicates, modifiers,

connectors, comparators and quantifiers) and

predefined fuzzy operators (Bosc and Pivert, 1995).

The WITH CALIBRATION clause specify a

tolerance which may express a maximum number

“n” of best rows (quantitative) or may specify a

satisfaction degree “λ” where returned row must

have degree greater or equal to “λ” (qualitative).

SQLf also allows nesting subqueries and

partitioned queries. Additionally, SQL2 features

have incorporated into SQLf2 (Goncalves and

Tineo, 2001a). Such features includes: relational

algebra operators, integrity constraints, views, date

and time data types, subqueries in the FROM clause,

data manipulation operations. On the other hand,

SQLf3 (Goncalves and Tineo, 2001b) includes

features of deductive, active and object oriented

databases. For simplicity and space restrictions, we

do not present here the features of SQLf2 and SQLf3

in detail.

3 MOTIVATING EXAMPLE

Consider a collection of WWW data sources

covering different domains. Data quality is described

in terms of parameters, such as: completeness (a

subset of data domain may be contained by a data

source), recentness (the last date of data updating),

frequency of updates (updating rates of data) and

granularity (different levels of aggregations are

possible in different data sources).

A query does not have to be answered by a single

source. For example, the querying system must

combine multiples sources data because they might

contain incomplete documents. In this case, the

source selection must be done in base on

completeness parameter.

We assume the existence of a catalog containing

information about Web documents stored in diverse

registered data sources and their quality parameters.

We can suppose that the Web users score each

necessary quality parameter, and thus, the catalog is

loaded. Finally, the catalog schema is described by:

− SOURCE that contains information about

registered data sources. Its attributes are: sid

(primary key), name, country, city,

completeness, recentness, frequency.

− DOCUMENT that is characterized by did

(primary key), sid (foreign key to SOURCE

relation), keywords, text, url and date attributes.

It contains all the data about Web documents

belonging to registered data sources.

Our problem is to select the best Web data

sources and their documents needed to solve any

Web search. This selection is specified by a SQLf

statement and involves criteria that are based on

quality properties of the data sources.

Now, suppose that someone is interested for

getting documents with the keyword ‘fuzzy queries’

due to his research. A query that system may

perform in order to select the best data sources is:

Query 1 What are the 10 best data sources that

contains very recent Web documents with a high

ICEIS 2007 - International Conference on Enterprise Information Systems

450

frequency of updates and whose keywords include

the phrase ‘fuzzy queries’?

Query 1 may be specified in SQLf as:

SELECT s.* FROM SOURCE s, DOCUMENT d

WHERE (d.idSource = s.id AND

d.keywords LIKE ‘%fuzzy queries%’

AND s.recentness = very current

AND s.frequency = highFrequency)

WITH CALIBRATION 10;

Where the highFrequency and current predicates

in Figure 1 and Figure 2, and very modifier must be

previously defined with the following three

sentences:

CREATE FUZZY PREDICATE current ON DATE

AS (‘01/01/2007’,‘03/01/2007’,∞,∞);

CREATE FUZZY PREDICATE highFrequency

AS (1/daily,0.8/weekly,0.6/bimonthly,

0.5/monthly,0.3/quarterly,

0.1/semestral,0/yearly);

CREATE FUZZY MODIFIER very AS POWER 2;

Moreover, we want to facilitate user’s task by

means of a generator of fuzzy queries as Query 1.

1999

2003

200

Figure 1: Current predicate.

daily

week

bim

thly

mont

rly

Figure 2: High Frequency predicate.

4 WEB TOOL ARCHITECTURE

For building the Web tool for data source and

document selection, we have used a three layers’

architecture. The lowest, data layer, is the RDBMS

SQLfi. The middle is the logical layer. The upper

layer is the client’s interface.

The system has three types of users. First, the

unregistered user may search documents in terms of

criteria and terms by default. Second, the registered

user may create him own terms and quality

parameters, and make searches based on them.

Third, the administrator registers data sources,

documents and links.

The main components inside the Web tool are:

− User Management: Any user may register and

connect him to the system. Additionally, a

registered user and administrator may update his

user data.

− Catalog Management: The administrator may

add, delete or update data sources which will be

accessible by all users. Each data source is

characterized by its name, country, city, url and

quality parameters, documents and links. A data

source is added via interface or loading a XML

document specified by the user. Subsequently,

Web user may score each data source and the

quality parameters are updated. Also, the data

sources are queried, eliminated and modified.

− Criteria Management: A registered user may

add, delete or update his fuzzy criteria or default

ones; and the administrator may add, delete or

update fuzzy criteria by default.

− Terms Management: A registered user may

update his fuzzy terms or default ones; and the

administrator may update default terms.

− Fuzzy Searching: Two types of searches are

provided. The first is the basic search where one

(or more) keyword is specified by the user in

order to verify if it is contained in a document.

The second is the advanced search that builds a

fuzzy query orienting the user during the

process.

− Favorites Management: A registered user may

add his favorite documents to favorite list and

then, query them.

− Key Management: A user may add keywords to

a document for a better search. Also, he may

delete, update and query them.

− Historical Management: A registered user may

review and delete his historical queries made

previously.

An important component of this architecture is the

catalog. It contains metadata describing data

sources, such as: data source content description,

data source capacity, data source completeness, data

source performance and use statistics, equivalence

between data sources, and physical properties of

network and data sources. In the catalog, both

documents and data sources have quality parameters.

The catalog contains the following entities:

− Category is the category name in which several

A WEB TOOL FOR WEB DOCUMENT AND DATA SOURCE SELECTION WITH SQLFI

451

documents have common features.

− Criterion is the parameter name that measures

the quality of documents or data sources.

− Document is the file that contains information

of interest for the user. It is characterized by an

identifier, a title, a size, a size unit, a city,

keywords, a URL, a country, a language, a date,

a last updating date, a format, authors and an

abstract.

− Data Source is a document container described

by identifier, name, country, city and URL.

− Historical is the user-search historical whose

attributes are date, keyword phrase, search type

and query.

− Data Source instance is the data source

category.

− User described by login, password, user type

and e-mail.

5 CONCLUSIONS

We have addressed here a solution for the problem

of selecting web data sources by means of SQLfi

use. This system has fuzzy querying capabilities that

are useful for expressing quality criteria and

selecting data sources with discrimination between

them. Expression of such criteria would be very

difficult with traditional querying languages.

We have presented a web data source selection

tool based on SQLf. It is a complete and friendly

system that facilitates the execution of fuzzy queries

on a web data source and documents catalog. This

tool allows storing the preferences of each user

enlarging the degree of satisfaction with the results

obtained. This system could be improved or

expanded; nevertheless we are sure that its current

state already represents a great aid for the end user.

We have not deal here with the performance

issue of fuzzy querying and information retrieval

systems. Nevertheless the querying system uses an

evaluation strategy based on relationship between

fuzzy sets and crisp sets. This mechanism is known

as the derivation principle and has shown to posses

the best performance between proposed evaluation

mechanisms. It is matter of further work the whole

implementation of the data source selection system

and its performance study.

At present time, we only give support to finding

data sources that are registered in existing relational

catalogs. Therefore, it is also necessary to extend the

system in order to support discovering data sources

that publish Web documents. A step more would be

to integrate this system with a Web tool for

discovering information. Thereafter it would be

possible to define and implement an intelligent Web

querying tool that automatically optimize user

request with available data sources on the Web.

ACKNOWLEDGEMENTS

We would like to acknowledge the contribution of

our development team conformed by the Computer

Engineering students Fabio Canache, Irwing

Herrera, Felix González, Giuseppe Pellegrino, Jesús

Graterol and Denise Videtta. This work has been

made with the subsidy of FONACIT via the project

G-2005000278. Finally we acknowledge Jesus

Christ, our all time helper, who gives us the

inspiration for working, creating and living.

REFERENCES

ANSI X3, 1992. Database Language SQL, 135-1992,

American National Standards Institute, New York.

Bosc, P. and Pivert, O., 1995. SQLf: A Relational

Database Language for Fuzzy Querying. IEEE

Transactions on Fuzzy Systems, 3.

Eduardo, J., Goncalves, M and Tineo, L., 2004. A Fuzzy

Querying System based on SQLf2 and SQLf3.

Proceedings of CLEI.

Galindo J., Urrutia A., Piattini M., (2006). Fuzzy

Databases: Modeling, Design and Implementation.

Idea Group Publishing Hershey.

Goncalves, M and Tineo, L., 2001. SQLf Flexible

Querying Language Extension by means of the norm

SQL2. In Proceedings of FUZZ-IEEE, 1.

Goncalves, M and Tineo, L., 2001. SQLf3: An extension

of SQLf with SQL3 features. In Proceedings of FUZZ-

IEEE, 3.

Goncalves, M and Tineo, L., 2005. WWW Data Source

Selection with SQLfi. In Proceedings of FUZZ-IEEE.

Konopnicki, D. and Shmueli, O., 1995. W3QS: A query

system for the World Wide Web”. In Proceedings of

VLDB, 54-65.

Loo, G. and Lee, K., 2000. An Interface to Databases for

Flexible Query Answering: A Fuzzy-Set Approach”.

In Proceedings of DEXA, 654-663.

Melton, J., 1992. ISO/ANSI Working Draft: Database

Language SQL (SQL3), X3H2-93-091/ISO DBL

YOK-003.

Mendelzon, A., Mihaila, G. and Milo, T., 1997. Querying

the World Wide Web. Journal of Digital Libraries, 68-

88.

Mihaila, G., Raschid, L. and Tomasic, A., 1998. Equal

time for data on the Internet with WebSemantics. In

Proceedings of EDBT, 87-101.

ICEIS 2007 - International Conference on Enterprise Information Systems

452
