USING DECISION TREE LEARNING TO PREDICT

WORKFLOW ACTIVITY TIME CONSUMPTION

Liu Yingbo, Wang Jianmin

School of Software, Tsinghua University, Beijing, China

Sun Jiaguang

School of Information Science and Technology, Tsinghua University, Beijing, China

Keywords: Time analysis, Workflow management system, Machine learning.

Abstract: Activity time consumption knowledge is essential to successful scheduling in workflow applications.

However, the uncertainty of activity execution duration in workflow applications makes it a non-trivial task

for schedulers to appropriately organize the ongoing processes. In this paper, we present a K-level

prediction approach intended to help workflow schedulers to anticipate activities' time consumption. This

approach first defines K levels as a global measure of time. Then, it applies a decision tree learning

algorithm to the workflow event log to learn various kinds of activities' execution characteristics. When a

new process is initiated, the classifier produced by the decision tree learning technique takes prior activities'

execution information as input and suggests a level as the prediction of posterior activity's time

consumption. In the experiment on three vehicle manufacturing enterprises, 896 activities were investigated,

and we separately achieved and average prediction accuracy of 80.27%, 70.93% and 61.14% with K = 10.

We also applied our approach on greater values of K, however the result is less positive. We describe our

approach and report on the result of our experiment.

1 INTRODUCTION

Time is always precious. An accurate knowledge of

time consumption is serviceable to an enterprise's

workflow management system to schedule the

ongoing processes. However, strong interactions

between human and computer in workflow

applications often make it difficult for schedulers to

anticipate activity's time consumption, which is an

important reason that prevents existing scheduling

techniques from being used in workflow (Greg et al.,

2004).

Consider, an example of enterprises we

investigated, within a period of 31 months (from

Oct-31-2003 to Jun-06-2006), there are 922

activities that have been executed at least once and

147 performers left 99765 event entries in the

workflow event log. Statistics of this event log

shows a great variety of activity execution duration

ranging from a low of only 1 second to a maximum

of 252 days. Even if we exclude those outliers by

neglecting top and bottom 5% of observed execution

duration, the range is still greater than 16 hours.

Thus, an essential first step in achieving good

scheduling in workflow management system is to

look for ways of predicting activity time

consumption.

As a means of anticipating workflow activities'

time consumption, we present a K-level prediction

approach. This approach uses a machine learning

technique to recommend to a workflow scheduler a

level as the prediction of possible time consumption.

This information can benefit a workflow application

in at least two aspects: it may help activity

performers to pick up suitable work items from their

work lists. And, it may help a workflow scheduler to

figure out feasible priority of ongoing processes.

Our approach requires an enterprise's workflow

system to have had an event log for some period of

time and the workflow models from which the

patterns of activities' time consumption can be

learned. We believe this information is generally

available for most of current workflow management

systems.

Yingbo L., Jianmin W. and Jiaguang S. (2007).

USING DECISION TREE LEARNING TO PREDICT WORKFLOW ACTIVITY TIME CONSUMPTION.

In Proceedings of the Ninth International Conference on Enterprise Information Systems - AIDSS, pages 69-75

DOI: 10.5220/0002404900690075

 SciTePress

In the experiment on three vehicle

manufacturing enterprises, a total number of 896

activities were investigated, and we have been able

to correctly suggest the level of time consumption

with an average prediction accuracy of 80.27%,

70.93% and 61.14% respectively with K = 10. We

have also applied our approach on greater values of

K, however, the prediction accuracy decreases

monotonically. When K reaches 100, the average

prediction accuracy decreases to only 46.91%,

36.06% and 30.91%. In addition, we also found that

the operation time of workflow has a positive

influence on the prediction accuracy.

This paper makes two contributions: It presents

an approach for helping workflow schedulers to

anticipate activity time consumption and it evaluates

the approach on the data sets from three real world

enterprises.

The remainder of this paper is organized as

follow: we begin by presenting background

information about workflow, and we provide an

overview on workflow application in three

enterprises (Section 2). Given this background, we

describe our K-level approach to predict activity

time consumption (Section 3) and evaluate the

results of applying our approach on real data sets

(Section 4). In the followed section, related efforts

of time management and scheduling in workflow

systems are presented (Section 5). Finally, we

summarize the paper (Section 6).

2 BACKGROUND

Understanding our approach requires a basic

knowledge of workflow. These concepts will be

covered in this section. In addition, we provide an

overview of workflow application in three

enterprises.

2.1 Workflow Structure and Event Log

We first present a set of definitions that will be used

throughout this paper.

A workflow or workflow model is a description

of a business process in sufficient detail that it is

able to be directly executed by a workflow

management system. A workflow is composed of a

number of activities or tasks, which are connected in

the form of a directed graph. An executing instance

of a workflow is called workflow instance or case.

There may be multiple instance of a particular

workflow running simultaneously, however each of

these instances is assumed to have an independent

existence and they typically execute without

reference to each other(Russell et al., 2005).

In the discussion of this paper, we treat activities

in a workflow as a single unit of work, which will be

undertaken by some actors or performers. Each

invocation of an activity that executes is termed a

work item. In general, a work item is directed to an

actor for execution. An activity's time consumption

or execution duration is the interval calculated from

the time when the work item is accepted by an actor

to the time that work item is committed by him.

Once the actor commits a work item, corresponding

activity will be marked as completed and other

activities will be invoked, mean while, an event

entry is created to log the actor's operation, including

work item's time stamp, actor's identity and

workflow instance id etc. These event entries form a

workflow system's event log.

2.2 Overview of Workflow Event Log

in Enterprises

In previous section, we have outlined basic concepts

of workflow management system. As a further

introduction to the background, we provide

information about three enterprises. All these three

enterprises are vehicle manufacturing enterprises.

We investigate them because workflow is

successfully used in many aspects of their business,

Table 1: General overview of three enterprises' workflow event log.

Enterprise A B C

Operation Time 117 days 421 days 949 days

Event Entries 10808 42099 99765

Number of Actors 179 244 147

Workflow Models 21 24 49

Max Duration 22 days 122 days 252 days

95 Percentile Duration 11 hours 20 hours 17 hours

5 Percentile Duration 7 seconds 5 seconds 7 seconds

Min Duration 2 seconds 1 second 1 second

ICEIS 2007 - International Conference on Enterprise Information Systems

like: configuration change, order processing, design

review, technical notification, standard release, and

new material classification etc.

Table 1 is a general overview of workflow event

confidential, we use A, B and C to represent them.

As illustrated in the table, the workflow system in

these enterprises has a different length of operation

time. Besides, there are many actors who have left

lots of event entries, which clearly reveals the fact

that workflow has been heavily used. Nevertheless,

in all these enterprises, the activity time

consumption varies greatly, which leads to the

introduction of our K-level prediction approach.

3 K-LEVEL ACTIVITY TIME

CONSUMPTION PREDICTION

Our approach of activity time consumption

prediction is based on machine learning, its rationale

is illustrated in figure 1. First, we define K levels so

as to make different observation of time

consumption uniformly distributed into the ranges of

levels. Then, for a given activity, each event entry of

this activity can be viewed as a training sample (or

instance) and the event entries of those prior

activities in the same workflow instance can be

viewed as this training sample’s features. The

training sample may have a label that indicates its

time consumption level. A supervised machine

learning algorithm takes as input a set of training

samples with known labels and generates a

classifier. The generated classifier can then be used

to assign a label to an unknown sample, which, in

the context of workflow, is the time consumption

level of unexecuted activity. The process of creating

a classifier from a set of instances is known as

training the classifier.

As is typical in machine learning, we evaluate

the performance of each classifier using 10-fold

cross-validation(Jiawei and Kamber, 2001).

In order to train a classifier, we take following

steps:

– Selecting appropriate levels and target activities

– Determining features activities from workflow

model

– Constructing training set from event log

– Applying machine learning to obtain a classifier

3.1 Selecting Appropriate Levels and

Target Activities

The first step of our approach is to discretize

observed time consumption into K levels so as to

assign appropriate label to a given event entry.

However, it is unwise to simply divide the maximum

duration by K, and equally segment the time into K

levels, because, in real situation, the frequency

distribution of time consumption skews greatly. In

our experiment, we use a-quantile (a=1/K, 2/K,

…

of observed time consumption as levels, this

selection makes the interval between consecutive

levels changes according to the density of time

consumption distribution. Figure 2 is an example of

10-level selection in three enterprises.

In practice, K indicates the resolution of

prediction. Higher value of K means finer

granularity and stronger comparability of prediction

result. Although, a higher resolution tends to make

workflow schedulers to be more sensible, it, as we

will see in the experiment results, usually leads to

lower prediction accuracy.

After levels have been defined, each event entry

can be assigned a label. The following step of

selecting target activity is quite simple. In order to

Workflow Model

Feature

Activity

Feature

Activity

Feature

Activity

Target

New Workflow Instance

Initiator

Past Workflow Instance

Actor A Actor B Actor C

Actor D

Training

Classifier

Features

Training

Samples

Generate

Prediction

Initiator

Actor A Actor B Actor C

Feature

Vector

Figure 1: Machine learning based activity time

consumption prediction.

0 0.5 1 1.5 2 2.5

Enterprise A

Level 0 Level10

0 1 2 3 4 5

Enterprise B

0 1 2 3 4 5 6 7

Execution Duration (x 10 Seconds)

Enterprise C

Figure 2: 10-Level selection of three enterprises.

USING DECISION TREE LEARNING TO PREDICT WORKFLOW ACTIVITY TIME CONSUMPTION

cover as many activities as possible, we just

excluded those activities whose event entries is not

sufficient for 10-fold cross-validation and finally

896 activities are included in our investigation. The

numbers of activities in three enterprises are listed in

Table-2.

Table 2: Investigated activities in three enterprises.

Enterprise

A B C

Total Activities 256 399 922

Investigated Activities 104 243 522

3.2 Determining Feature Activates

from Workflow Model

In order to train a classifier for a given activity, we

need to find out which event entries are similar to

each other, so that typical time consumption patterns

can be derived by learning algorithm. The similarity

is based on characteristics of prior activities' event

entries in the same workflow instance. We find out

these precedence activities by first excluding edges

in a workflow model that might cause loop

execution, and we make the relation on activities to

be a directed acyclic graph, thus for any activity its

precedence activities set can be obtained.

3.3 Constructing Training Set from

Event Log

After feature activities have been selected, each

event entry of the target activity can be characterized

by a feature vector, and the associated label for this

event entry is represented by the time consumption

level.

However, there is a substantial amount of

information in event entries that can be used as

feature. Which part of information is selected

fundamentally determines the performance of

classifiers. In our experiment, we use three parts of

information as features:

– The first part is actor's identity for those prior

activities. We make this selection because it is

commonly believed that, staff assignment has a

strong influence on activity time consumption;

– The second part is prior activity's time

consumption, this selection is based on the

assumption that prior activity's time

consumption may reveal posterior activities'

characteristics in a workflow instance;

– The last part is the start time of prior activities

calculated from the time corresponding

workflow instance started, we choose this part of

information because actors are not always

interacting with workflow systems, a pending

work item means there are some external reasons

that prevent the instance from being completed,

hence, it might has some influence on posterior

activity's time consumption.

Finally, we construct the training set by collecting

all the features of target activities' event entries from

the workflow event log.

3.4 Applying Decision Tree Learning to

Obtain a Classifier

In the final step, we use C4.5 decision tree(Quinlan,

1993) to obtain a classifier, we choose this algorithm

because it is proposed by previous research(Ly et al.,

2006). For the purpose of this paper is to testify the

applicability of machine learning approach in

activity time consumption prediction, we use

existing tool WEKA (Witten and Frank, 2005) to

train our classifiers and to perform the test.

4 EXPERIMENT RESULT AND

EVALUATION

To demonstrate how well our approach can be used

in real world applications and to see the relationship

between prediction accuracy and resolution. We

applied our approach on three enterprises' data sets

with K = 10, 20, 40, 60 and 100.

Because, considerable number of classifiers is

going to be trained in the data sets of each

enterprise, we use average prediction accuracy of

all classifiers as a global measure to represent the

main feature of the performance of our approach.

4.1 Experiment Results

The exact numbers of average prediction accuracy

are listed in Table-3 and the trend of prediction

accuracies with regard to different values of K are

depicted in Figure 3.

Table 3: The exact number of average prediction accuracy

in three enterprises.

Levels Enterprise A Enterprise B Enterprise C

10 61.14 70.93 80.27

20 51.88 59.94 72.77

40 43.56 48.52 62.55

60 38.03 43.15 54.95

80 34.52 38.10 50.85

100 30.91 36.06 46.91

ICEIS 2007 - International Conference on Enterprise Information Systems

In Figure 3, the trends of prediction accuracy in

three enterprises are rather alike, but the absolute

value is different. Our approach always performs the

best in Enterprise C (with the best accuracy of

80.27%) while the worst in Enterprise A (with the

best accuracy of just 61.14%).

We believe this is mainly because of the quality

of training set. As shown in the discussion of

previous sections, the performance of our approach

depends on activity time consumption pattern and on

how clearly the pattern displays itself in event log.

However, it is quite rare for the situation to be so

obvious, especially, in the initial phase of workflow

application. Comparing with the data listed in Table-

1, one may find that the workflow operation time in

Enterprise A is rather short(less than 4 months),

which means, typical time consumption patterns are

not so clear to be generalized by C4.5 learning

algorithm. Hence, the performance of classifiers is

not likely to be good. Whereas, the workflow

operation time of enterprise C is much longer than

that of the other two. This long operation time has

lead to a larger number of event entries and more

importantly, bigger sample space for C4.5 algorithm

to learn. Therefore, we believe, as time goes by, the

prediction accuracy in Enterprise A and B will

steadily increase.

4.2 Evaluation on Applicability

In our opinion, whether or not our approach is

acceptable for scheduling will depend on

requirement. According to experiment results, there

appears to be a contradiction between accuracy and

resolution, but the overall performance of our

approach will gradually increase as time goes by.

Therefore, a workflow scheduler needs to tradeoff

between accuracy and resolution according to

workflow operation time.

For example, if a scheduler requires some fixed

prediction accuracy, then, at the beginning, this

prediction have to be based on indefinite resolution

and few activities can be well predicted, so,

decisions have to be made on a vague knowledge of

time consumption, and, these decisions tends to be

rough. While, after a period of time, with resolution

level becomes higher and higher and well predicted

activities becomes more and more, the schedule can

be more specific.

However, to the best of our knowledge, most of

scheduling approaches presented in the literature of

workflow (Combi and Pozzi, 2006) (Greg et al.,

2004) (Johann et al., 2003) haven't consider too

much about adaptively adjusting the scheduling

strategies according to given condition. While, we

believe the results reported in this paper is sufficient

to warrant the development of such an adaptive

scheduling approach.

5 RELATED WORKS

Our work is related to workflow time management

and workflow scheduling.

5.1 Workflow Time Management

Analysis and Management of temporal information

in workflow is by no means straightforward, its

difficulty mainly comes form two aspects: the first is

undetermined execution sequence of tasks and the

second is variety of activities' time consumption.

In (Johann et al., 1999), Johann Eder et al

investigated various time constrains in workflow.

And, they presented a framework for computing

activity deadlines so that the overall process

deadline is met and all external time constraints are

satisfied. Later on, he and Euthimios Panagos

presented a method for incorporating detailed time

information into workflow management

systems(Eder and Panagos, 2000), their method is

based on extend PERT(Pozewaunig et al., 1997). By

adding elements like duration, deadline, earliest

possible start time, earliest possible end time etc.,

their method can express different possibility of

process execution time. In their paper, they also

discussed issues in runtime handling of workflow

time information.

In complex workflow models, the existence of

conditional structures in the control flow may result

in many execution paths, which makes it difficult to

analyze task duration. Therefore, in (Johann et al.,

0 20 40 60 80 100

100

K-Levels

Average Prediction Accuracy

Enterprise A

Enterprise B

Enterprise C

Figure 3: Average prediction accuracy of three enterprises

with different values of K.

USING DECISION TREE LEARNING TO PREDICT WORKFLOW ACTIVITY TIME CONSUMPTION

2003) (Eder and Pichler, 2002), Johann Eder and

Horst Picler et al introduced the concept of time

histogram. Their approach requires a well-formed

workflow and probabilistic information about

branching behavior of a process, then for each

activity, possible execution time can be calculated.

They also discussed ways to apply their approach to

automatic process scenario like composite web-

service process(Eder and Pichler, 2004). The

probabilistic time management approach is also used

by Martin Bierbaumer et al to analysis the

phenomenon of unnecessary delay caused by fixed

date constraints (Bierbaumer et al., 2005a)

(Bierbaumer et al., 2005b). In order to assist

participants of workflow appropriately select their

work items, they use time histogram to calculate the

delay time of ongoing process, and remind

participants about possible delay according to the

calculated result.

In addition to Johann Edier's works, there are

some other researches that are related to workflow

time management, In (Aalst and Reijers, 2003),

Aalst et al use stochastic petri-nets to analysis

workflow performance. and Carlo Combi et al also

developed a set of models to address time constrains

in organizational point of view(Combi and Pozzi,

2003b) (Combi and Pozzi, 2003a).

Previous work of workflow time management

and time analysis concerns the variety of execution

time caused by complex workflow model and

branching probability. However, the variety of

activity execution duration caused by interactions

between human and workflow management system

are not discussed. Our work focuses on this kind of

variety.

5.2 Workflow Scheduling

Scheduling, however, despite its successful

application in manufacturing fields, is not widely

accepted in workflow.

Grego'rio Baggio Tramontina et al discussed

some of the problems that prevent existing

scheduling techniques from being used in workflow

(Greg et al., 2004), in addition, they proposed a

"Gauss and Solve" scheduling approach. Their

approach consists of two steps, first, making a guess

on the execution times and routes the case will

follow, and second, solving the corresponding

deterministic scheduling problem using a suitable

technique. In the simulation, they used genetic

algorithms as a means to schedule artificially

generated cases. According to their result, if the

error in guessing is bound by 30%, their approach is

better than the commonly used FIFO rules regarding

the number of late jobs. Besides, they envisioned the

approach of using machine learning or statistical

techniques to predict activity time consumption,

however, in their paper, they didn't provide much

detail. Our work can be viewed as a complementary

effort to their work.

In (Combi and Pozzi, 2006), Carlo Combi and

Giuseppe Pozzi focuses on temporalities in the

conceptual organizational model and task

assignment policies. They proposed a temporal

organizational model, which extends traditional

organizational models, to describe different temporal

constrains of resources(Combi and Pozzi, 2003b)

(Combi and Pozzi, 2003a), like availability

constrains, and deadline constrains etc. Based on the

description of these constrains, they designed a

scheduling algorithm, which evaluates the priority of

tasks according to the expected deadline for

completion and expected duration. As a proof-of-

concept, a running prototype implements the

algorithms of the temporal scheduler for a WfMS.

Despite works that mainly concerns macro-level

scheduling from workflow system's point of view,

the work of Johann Eder et al(Johann et al., 2003)

provides us another view on workflow scheduling:

the personal scheduling. By admitting a commonly

overlooked fact that people are actually the driving

force of workflow(Moore, 2002), they changed their

objective of scheduling from ordering cases in

workflow system to assisting individual workflow

participants. To meet this end, they provide

workflow participants information about upcoming

tasks so that they can proactively take measures to

prepare for those tasks. Their approach is based on a

probabilistic time management system(Eder and

Pichler, 2002) which uses duration histograms to

express the uncertainty of workflow time

consumption.

Other work about workflow scheduling concerns

scheduling in a single workflow instance, In (Senkul

et al., 2002) (Senkul and Toroslu, 2005), Pinar

Senkul and Ismail H. Toroslu proposed a

architecture which provides a specification language

that can model resource information and resource

allocation constraints, and a scheduler model that

incorporates a constraint solver in order to find

proper resource assignments. Particularly, they use

constraint programming to schedule workflows with

resource allocation constraints.

6 SUMMARY

In this paper, we have discussed a K-level approach

to anticipate activity time consumption in workflow

management system. Our approach uses a

supervised machine learning algorithm that is

ICEIS 2007 - International Conference on Enterprise Information Systems

applied to workflow event log. In the experiment on

three enterprises, a total number of 869 activities

were investigated and our approach separately

achieved an average prediction accuracy of 80.27%,

70.93% and 61.14% with K = 10. In addition to

presenting these results, we have analyzed the

performance trend of different values of K, however

the results is less positive. In addition, we also found

that the operation time of workflow system has a

positive influence on the performance of our

approach.

We believe that our approach shows some

promise for improving the current state of workflow

scheduling. Our future plans include an investigation

of additional sources of information, further

development of adaptive scheduling approaches, and

simulation using real data sets to test the

applicability of workflow scheduling.

ACKNOWLEDGEMENTS

We are grateful to Tsinghua InfoTech Company for

providing the workflow event-log data of their

TiPLM system. This work is supported by the

Project of National Natural Science Foundation of

China (No. 60373011) and the 973 Project of China

(No.2002CB312006).

REFERENCES

Aalst, W. M. P. V. D. & Reijers, H. A. (2003) Analysis of

Discrete-time Stochastic Petrinets. Journal of the

Netherlands of Society for Statics and Operations

Research, 58.

Bierbaumer, M., Eder, J. & Pichler, H. (2005a)

Accelerating Workflows with Fixed Date Constraints

24th International Conference on Conceptual

Modeling. Klagenfurt, Austria.

Bierbaumer, M., Eder, J. & Pichler, H. (2005b)

Calculation of Delay Times for Workflows with

Fixed-date Constraints. Seventh IEEE International

Conference on E-Commerce Technology, CEC 2005.

Combi, C. & Pozzi, G. (2003a) Temporal Conceptual

Modelling of Workflows Conceptual Modeling - ER

2003. Springer Berlin / Heidelberg.

Combi, C. & Pozzi, G. (2003b) Towards Temporal

Information in Workflow Systems Advanced

Conceptual Modeling Techniques. Springer Berlin /

Heidelberg.

Combi, C. & Pozzi, G. (2006) Task Scheduling for a

TemporalWorkflow Management System. Thirteenth

International Symposium on Temporal Representation

and Reasoning, Time'06.

Eder, J. & Panagos, E. (2000) Managing Time in

Workflow Systems. IN FISCHER, L. (Ed.) Workflow

Handbook 2001. Future Strategies Inc., USA.

Eder, J. & Pichler, H. (2002) Duration Histograms for

Workflow Systems. Working Conference on

Engineering Information Systems in the Internet

Context (IFIP TC8/WG8.1). Kanazawa, Japan.

Eder, J. & Pichler, H. (2004) Response time histograms

for composite Web services. IEEE International

Conference on Web Services, 2004

Greg, Rio, B., Jacques, W. & Clarence, E. (2004)

Applying Scheduling Techniques to Minimize The

Number of Late Jobs in Workflow Systems.

Proceedings of the 2004 ACM symposium on Applied

computing. Nicosia, Cyprus, ACM Press.

Jiawei, H. & Kamber, M. (2001) Data Mining : Concepts

and Techniques San Francisco, Morgan Kaufmann.

Johann, E., Euthimios, P. & Michael, R. (1999) Time

Constraints in Workflow Systems. 11th International

Conference on Advanced Information Systems

Engineering: , CAiSE'99,. Heidelberg, Germany, June

1999.

Johann, E., Horst, P., Wolfgang, G. & Michael, N. (2003)

Personal Schedules for Workflow Systems.

Proceedings on Business Process Management:

International Conference, BPM 2003, Eindhoven, The

Netherlands, June 26-27, 2003.

Ly, L., Rinderle, S., Dadam, P. & Reichert, M. (2006)

Mining Staff Assignment Rules from Event-Based

Data. Lecture Notes in Computer Science Vol. 3812.

Moore, C. (2002) Common Mistakes in Workflow

Implementations. Giga Information Group, Cambridge

MA(2002).

Pozewaunig, H., Eder, J. & Liebhart, W. (1997) ePERT:

Extending PERT for Workflow Management Systems.

1 st East European Symposium on Advances in

Database and Information Systems ADBIS ' 97. St.

Petersburg, Russia.

Quinlan, R. (1993) C4.5: Programs for Machine

Learning, San Mateo, CA., Morgan Kaufmann

Publishers.

Russell, N., Hofstede, A. H. M. T., Edmond, D. & Aalst,

W. M. P. V. D. (2005) Workflow Resource Patterns.

Eindhoven, Eindhoven University of Technology.

Senkul, P., Kifer, M. & Toroslu, I. H. (2002) A Logical

Framework for Scheduling Workflows Under

Resource Allocation Constraints. Proceedings of the

Twenty-eighth International Conference on Very

Large Data Bases, 694-705.

Senkul, P. & Toroslu, I. H. (2005) An Architecture for

Workflow Scheduling Under Resource Allocation

Constraints. Information Systems, 30, 399-422.

Witten, I. H. & Frank, E. (2005) Data Mining: Practical

Machine Learning Tools and Techniques, San

Francisco, Morgan Kaufmann.

USING DECISION TREE LEARNING TO PREDICT WORKFLOW ACTIVITY TIME CONSUMPTION
