GENERIC BUSINESS MODELLING FRAMEWORK

Christopher John Hogger and Min Li

Department of Computing, Imperial College London, South Kensington Campus, London SW7 2AZ, United Kingdom

Keywords: Business models, business processes, enterprise management, requirements, constraint evaluation.

Abstract: We present a position paper setting out the essentials of a new declarative framework named GBMF

intended for modelling the higher-level aspects of business. It is based upon logic programming including,

where appropriate, finite-domain constraints. Business plans, processes, entity constraints, assets and

business rules are representable in GBMF using an economical repertoire of primitive constructs and

without requiring overly-burdensome programming effort. The framework, which has been fully

implemented, has been applied so far to small-scale business exemplars. Our more general future aim,

however, will be to demonstrate the framework's generic character by providing precise semantic mappings

between it and other business modelling frameworks that rely upon specialized languages and engines.

1 INTRODUCTION

The modelling of businesses, their methods and their

processes has been pursued within many

frameworks and perspectives. Our work aims to

establish a generic framework serving as an abstract,

but implementable, representation of core features of

the more concrete and established frameworks now

existing, and so provide a common semantic basis

facilitating their comparison and inter-translation.

Our generic business modelling framework,

GBMF, is built upon the general notion of activities

operating upon entities. The latter may be variously

physical (manufacturing parts, resources), electronic

(databases, emails, websites), financial (accounts,

budgets), human or any typical business entities.

Activities performed upon them are composed from

atomic basic actions organized into action sets,

which are in turn organized into larger programmatic

hierarchies called business plans. A plan might

embody the actions entailed in a production process

from inception to delivery, with attendant impacts

upon financial and temporal aspects of the business.

Such a plan may be applied on multiple occasions,

possible concurrently. GBMF therefore treats a plan

as a template capable of spawning distinct instances

called processes, each acting upon its own vector of

business entities. The instigations and progressions

of processes are governed by business process rules,

whilst the internal relationships between their

entities are governed by the underlying procedures

that define the basic actions and, (if required) by

separately given business entity constraints. Many

entities in a process will have a transient existence,

being only intermediates for creating the eventual

deliverables of that process. When the process

terminates, these intermediates have no further

significance and are discarded. Those entities to

which this does not apply are the deliverables that

must survive, referred to as business assets. Thus the

macroscopic behaviour of an executing GBMF

instance is the transformation of an asset space, as

various processes are spawned, possibly exploiting

pre-existing assets and, usually, creating new assets.

Sections 2 , 3 and 4 introduce plans, processes

and business entity constraints, respectively. The

notion of assets is introduced in Section 5, and

business process rules in Section 6. Related work is

compared with GBMF in Section 7 whilst Section 8

states conclusions and future intentions.

2 GBMF PLANS

GBMF represents each basic action as a term of the

form Action-name(Ontvars) in which Ontvars is a

vector of ontological variables each representing an

entity. By convention, the last argument in this

vector always represents the time interval over

which the action is performed. Each basic action A

appears within an action declaration whose simplest

422

John Hogger C. and Li M. (2007).

GENERIC BUSINESS MODELLING FRAMEWORK.

In Proceedings of the Ninth International Conference on Enterprise Information Systems - ISAS, pages 422-427

DOI: 10.5220/0002407704220427

 SciTePress

form is action(S, I, A) where S names an action set

and I is a position index for A within S.

Figure 1: The ‘dohire’ action set.

Figure 1 shows action declarations, indexed 1-4,

expressing an entire action set named ‘dohire’. The

general syntax of an action declaration is

action(S, I, X).

or action(S, I, C, X)

or action(S, I, C, X1, X2)

in which each of X, X1, X2 is a basic action or an

action set name and C is a predicate, over one or

more ontological variables, expressing a condition or

a decision. The first form above appears throughout

in Figure 1, but at index 3 expresses that another

action set, ‘recordexpense’, is to be performed

unconditionally. The second form expresses that if C

holds then X is performed, whilst the third form

expresses that if C holds then X1 is performed but

otherwise X2 is. Neither of these conditional forms

is needed in ‘dohire’. The ‘dohire’ action set is

implemented as the activity of satisfying a customer

request (to hire a tool) by finding such a tool already

in stock and thereby entering a hiring agreement,

then looking up the administrative expense to the

business of doing all this, then recording the expense

(charging it to an account) and finally making the

hiring ‘public’ in the sense of making it available as

an asset for other processes to operate upon.

The names of action sets are chosen freely by the

user (modeller). The names (e.g. ‘hire’ above) of

basic actions are either freely user-defined or belong

to a small set of system-defined names (e.g.

‘publish’ above) having fixed meanings in the

framework.

The ability of one action set to invoke others,

conditionally or otherwise, inherently organizes a

complete GBMF model into a set of plans. A plan

comprises a root action set - characterized by being

invokable by no other - together with all those other

action sets that it may invoke directly or (through

those others) indirectly. This allows an action set to

belong to more than one plan, if required, to

economize on the use of common knowledge.

A plan P has an associated ontology ont(P)

which contains the alphanumeric arguments in the

user-defined basic actions in P. It also contains the

arguments of system-defined basic actions in P that

are known - from a separate framework dictionary -

to be ontological variables. In the ‘publish’ action,

for example, it is known that only its first and third

arguments are of this kind So, if P uses the ‘dohire’

action set then, from Figure 1, ont(P) must include at

least {request, tool, hiring, expense, t4, t5, t6}. The

names of ontological variables are chosen freely.

Each action set has an associated control

declaration which is either of the assertions

control(seq) or control(con). This specifies whether

the basic actions in the set are to be performed

sequentially or concurrently. The former case uses

the action declarations’ indices to determine the

temporal order, whilst the latter case ignores them.

3 GBMF PROCESSES

A GBMF process is an executing instance of a plan.

At any time in the animation of a model there may

exist zero or more active instances of each plan, at

various stages in their executions. The factors

governing process initiation, progression and

termination will be outlined in the next section.

A process is denoted P

where P is a plan and i is

a unique instance identifier. P

has its own binding

environment

) containing a pair (V, Val) for

each V

∈ont(P) signifying that V is bound to the

value Val. When P

is initiated,

) consists of null

bindings, i.e. P

’s variables are uninstantiated.

As P

executes, its variables become instantiated

by various ways - clock-binding, action performance

and constraint evaluation. Clock-binding instantiates

the start (s) or the end (e) in the time-interval value

(s, e) of the temporal variable in a basic action A

when A is about to be performed or has just been

performed. It instantiates s or e with the current time

as given by the clock in the model’s execution

manager. Performing A entails consulting an Action

Knowledge Base (AKB) containing, for each basic

action type, an associated procedure. If A is user-

defined then its procedure will have been supplied in

the AKB by the modeller. The primary effect of

executing the procedure is to update

). A

secondary effect, relating to asset management, will

be described presently, as will constraint evaluation.

Figure 2 shows the items described so far in a

run of a given model. On the left are static resources

including the plans - defined entirely by action

declarations and control declarations - and the AKB.

To the right is the dynamic component consisting of

action(dohire, 1, hire(request, tool, hiring, t4)).

action(dohire, 2, hireadmincost(expense, t5)).

action(dohire, 3, recordexpense).

action(dohire, 4, publish(hiring, nc, t6)).

GENERIC BUSINESS MODELLING FRAMEWORK

423

a pool of active (unterminated) processes, their

binding environments

and their activation records

representing their states of progress.

Figure 2: Active process pool.

4 ENTITY CONSTRAINTS

Business entity constraints in GBMF are required

relations over ontological variables. A constraint

declaration takes the form constraint(C) where C is

some predicate having a supporting constraint

definition capable of evaluating it - for example:

constraint(hiring_span(t4, t6)).

hiring_span((S, _), (_, E)) if (E - S) < 6.

Referring to the example in Figure 1, this constraint

requires the total duration of the activity entailed in

the ‘dohire’ action set to be less than 6 time units. In

the operating model, this constraint applies to every

process that potentially binds (incarnations of) t4

and t6. In the tool-hire model these two variables

jointly occur in a single plan, ‘toolhire’ but, more

generally, constraints may be imposed on processes

spawned from different plans. For example, the

constraint con25 in the declaration

constraint(con25(v3/plan4, v5/plan1)).

constrains the relation between v3 in ont(plan4) and

v5 in ont(plan1) and is applied to every process pair

(π

, π

) such that π

and π

are instances of plan4 and

plan1, respectively.

In the running model, constraints are evaluated

by a separate constraint manager acting in concert

with the execution manager responsible for

spawning and advancing processes. In the current

implementation of GBMF they are tested each time

an action is performed. More generally, however,

constraints may be tested at any time. Their

definitions may if required, be FD-constraint logic

programs which effectively bind selected variables

to finite domains of feasible values. The domains

become successively narrowed by the various effects

of clock-binding and/or action-performance, and for

as long as these domains remain non-empty the

constraints remain satisfiable. Constraints of this

kind can be evaluated even prior to such events,

enabling forward planning in respect of such things

as resource allocation, budgeting and scheduling.

Currently, the satisfiability of constraints is not

enforced in GBMF - instead, the implementation just

reports constraint violation if and when it occurs.

However, constraints can facilitate collaboration

between the various agents within a business. In a

simpler model (Hogger, 2004) precursive to GBMF,

plans and constraints are fluidly associated with

agent roles and can be consistency-tested at role-

formation time. If constraints become subsequently

violated as concrete plan instances proceed, failure

analysis can identify the agents responsible, who can

then confer upon appropriate remedies such as

constraint revision. In due course we hope to add

these features to GBMF and further combine them

with collaborative treatment of the model’s business

process rules, discussed in Section 6.

5 ASSETS

By default, the termination of a process would leave

no trace of its prior existence, since its bindings are

then automatically garbage-collected. Instances of

relations between its ontological variables would

have been constructed or verified by the effects of

actions and constraints, but would not survive to the

lasting benefit of the modelled business as a whole.

In order to enable processes to manipulate

business entities of greater permanency, GBMF

allows the modeller to declare, for any basic action

type, that some of its arguments denote durative

assets. Concretely, such an asset is a value Val - in

general a compound structure conforming to a

schema declared in the AKB for a particular asset

type - tagged with a unique identifier, a type, a status

and an origin. When it comes to exist, during the

running of the model, it will do so within an asset

space that is adjoint to the process pool. The status

of the asset, at any instant, is either public, i.e. it is

available for use by any process, or is owned, i.e. it

belongs (at this moment) to a particular process. Its

origin identifies the process π

from which it

originated together with the name of the variable V

that became bound to Val by executing π

and the

plans

(P1)

(P7)

(Q3)

processes

bindings

ICEIS 2007 - International Conference on Enterprise Information Systems

424

time interval of the particular action in π

that

created the asset. Equivalently, the asset can be seen

as a tagged copy of the binding (V, Val) that was

constructed in the environment

(π

). Assets may

serve many purposes relating to process inter-

dependence, including message-passing.

Figure 3 shows an asset created in a run of a

tool-hire business model, of which the action set in

Figure 1 is a small fragment. This asset, of type

‘administration:toolcatalogue’, is a list of tooltypes.

Its originating process was an instance ‘270’ of a

‘stock’ plan which, in the interval from s=303 to

e=304, performed an action that bound the variable

‘updatedinventory’ to this list. Since then, the asset

has passed to the ownership of another process,

namely instance ‘327’ of a ‘toolhire’ plan.

Figure 3: Concrete asset.

Each process π has an associated asset register,

denoted areg(π) and initially empty, which records

the assets currently owned by π. Each entry is a pair

(id, V) where id is the asset’s unique (and invariant)

identifier and V is a variable in π’s ontology.

Besides the action-defining procedures, the AKB

contains asset declarations specifying any asset-

handling entailed in each action type. For some basic

action A, such declarations may express that some of

A’s variables variously denote pre-assets, post-

assets or consumed-assets. However, not all actions

need involve handling assets.

When a process π starts to perform A, π is

expected to own an asset for each of A’s pre-asset

variables. One way this can arise is by π having

already performed system-defined actions available

for acquiring or copying public assets. However, if a

pre-asset variable V in A is not already associated

with a π-owned asset then the asset space is searched

for a public one whose type matches the schema for

V given in the AKB and whose value is compatible

with the binding of V in

(π). If one is found then a

copy of it is assigned to π’s ownership and is duly

associated with V in areg(π), otherwise A suspends

until an appropriate asset becomes available.

When a process π is about to finish performing

A, the values to which A’s post-asset variables (if

any) are bound in

(π) are used to construct new

assets belonging to π and the associations of these

assets with these variables are recorded in areg(π).

Further, when a process π finishes performing A,

the assets with which A’s consumed-asset variables

(if any) are associated in areg(π) are deleted from

the asset space and from areg(π) itself.

For example, the tool-hire model’s AKB contains

these asset declarations for the ‘hire’ action type:

pre_assets(hire(Request, Tool, _, _), [Request, Tool]).

post_assets(hire(_, _, Hiring, _), [Hiring]).

consumed_assets(hire(Request, Tool, _, _),

[Request, Tool]).

They require that when a ‘hire’ action begins it must

have pre-assets associated with variables Request

and Tool, and when the action ends it must convert

its value for Hiring to a post-asset and moreover

consume (delete) the assets associated with Request

and Tool. The latter is just a nuance allowing one to

exercise fine control over asset lifetimes. It is not

essential because, when a process π terminates,

assets that it owns are in any case garbage-collected.

This last remark implies that if any of π’s assets

are required to survive π’s termination then π must

beforehand make them public. To do so it can

perform a system-defined basic action ‘publish’.

This is seen in Figure 1 where the asset associated

with Hiring is made public. When a complete run of

the model terminates, what survives is just the set of

public assets still remaining in the asset space. These

are the only observable deliverables of the business.

6 BUSINESS PROCESS RULES

The plans and the AKB’s asset declarations in a

model induce a directed plan-asset dependency

graph whose nodes are the model’s plan names.

Each edge directed from P to Q is labeled by the set

of those variables in ont(P) that P potentially

delivers as assets to Q. Although these dependences

are logical consequences of the model and can be

mechanically compiled from it, it serves the

modeller’s interest to assert them explicitly in a

[stepladder, ladder, carjack, mower, ..., powerdrill]

332

administration : toolcatalogue

toolhire

327

( stock

270

updatedinventory,

(303, 304) )

owner

type

origin

GENERIC BUSINESS MODELLING FRAMEWORK

425

separate component of the model called the Business

Process Rulebase (BPR). This is because they

contribute to the formulation of business process

rules regulating process creation and behaviour,

though not all such rules refer to asset handling.

Figure 4 outlines a small fraction of the graph for

the tool-hire business model.

Figure 4: Plan-asset dependency graph.

Thus we see that a ‘toolhire’ process expects, at the

least, to be served by a tool asset from a ‘stock’

process and a request asset from a (customer’s)

‘toolrequest’ process, and to deliver a hiring asset or

a reservation asset to yet other processes.

In the BPR each edge of the graph is declared by

an assertion of the form

plan_asset_dep(P, Assetvars, Q).

e.g. plan_asset_dep(stock, [tool], toolhire).

Business process rules in the BPR may or may not

exploit plan-asset dependences. Examples are:

initiate_process(Q) if Q \= setup,

plan_asset_dep(P, Assetvars, Q),

member(V, Assetvars),

asset_space_has(V), origin(V, P), status(V, public),

not_engaged(Q, V).

initiate_process(setup) if asset_space_lacks(inventory).

These declare that a process for any plan Q, other

than one for ‘setup’, be initiated if the asset space

contains a public asset originating from a variable V

in ont(P), provided V contributes to the dependence

of Q upon P and provided no other process for Q is

already engaged to make use of that asset. On the

other hand, a process for ‘setup’ - of which only one

will ever be executed - should be initiated if no

inventory (which it is the exclusive duty of ‘setup’ to

create) has yet appeared in the asset space.

More generally, the BPR’s business process rules

can express any requirements about the behaviour of

the process pool if these are expressible as logical

conditions over existing processes, their associated

binding environments or activation records or the

contents of the asset space. They are consulted by

the model’s execution manager to drive the model

forwards and to ensure that each process is spawned

to serve a declared purpose and that its subsequent

behaviour satisfies any declared conditions.

7 RELATED WORK

Many recommendations exist as to the macroscopic

concepts that need to be considered in business

modelling. For (Fox, 1998) these concepts need to

be based fundamentally on well-defined ontologies.

For (Hamel, 2000) they include strategic resources,

cost interfaces and value networks, for (Alt, 2001)

they include mission, processes and revenues, whilst

for (Affua, 2003) they include dynamics, taxonomy

and value. There are clearly intersections and

exclusions among these concept sets, but

ascertaining this precisely is difficult since not all of

them are given sufficiently formal anchorage.

Existing business models vary from the most

abstract, e.g. very general axiomatizations, to mid-

level ones exposing more detailed commitments to

representation, logic and behaviour, down to

concrete, context-specific implementations. GBMF

lies in the middle level. The latter has been broadly

characterized by (Chen-Burger, 2002) as expressing

conditions and actions of business processes,

relationships between them and constraints on the

data they deal with. Other concept-focused

examplars here include ENTERPRISE (Uschold,

1998) and e3value (Gordijn, 2003), the latter being

compared in detail by (Gordijn, 2005) with BMO

(Business Modelling Ontology) (Osterwalder, 2005).

Instances of BMO, implemented in XML and

OWL, are enterprise-specific representations of,

chiefly, offers, customer interfaces, infrastructure

and - especially - the logic entailed in earning

revenue. Unlike GBMF models, concrete instances

of BMO do not operate under the control of an

executable enterprise-independent superstructure.

Besides those frameworks that constrain the

structure of business models, there are many others

intended for facilitating their design and

implementation. Early exemplars include the BSDM

Business System Development Method (IBM, 1992),

setup

stock

toolrequest

satreserv

toolhire

{ inventory,

hirecharges }

{ request }

{ tool }

{ reservation }

{ hiring, ... }

ICEIS 2007 - International Conference on Enterprise Information Systems

426

the Ordit organisational modelling method (Dobson,

1994) and the business process modelling methods

IDEF0 (NIST, 1993) and PSL (Schlenoff, 1997).

The one most similar to, but more mature than,

GBMF is the Fundamental Business Process

Modelling Language FBPML (Chen-Burger, 2002 &

2004; Kuo, 2003), a sophisticated amalgamation and

extension of features drawn from PSL and IDEF3.

FBPML is declarative, using logic to describe

features of, and relations over, business processes. It

further includes tools for developing, testing and

analysing models, and also an engine for eliciting

workflow animations from them.

Though sharing similarities with GBMF’s basic

representations of actions, preconditions, entities and

of process logic and behaviour, FBPML is a special-

purpose language requiring its own custom-built

engines and tools, whereas GBMF models are

written directly in the general-purpose Prolog

language and so freely inherit all the representational

and executional power of that formalism, besides the

standardized and well-understood stable model

semantics of normal-clause logic. An additional and

significant difference is that GBMF can, as we have

indicated earlier, exploit the expressiveness and

computational power of finite-domain constraints.

8 CONCLUSIONS

We have outlined a declarative, context-independent

and implementable framework for modelling aspects

of business. Formulating this in logic programming

gives the benefits of general-purpose expressiveness

and well-understood execution regimes, so avoiding

the need for a special-purpose engine supporting a

specialized modelling language. Process plans,

constraints and asset management are expressible

transparently using a small range of basic constructs.

Our main aim is to exploit the well-understood

semantics of logic programs in a future programme

of work intended to map other frameworks such as

FBPML to GBMF and thus to establish the generic

nature of the latter and to facilitate inter-framework

comparison and translation as explored in, for

example, the work of (Chen-Burger, 2001).

REFERENCES

Afuah, A., Tucci, C.L., 2003. Internet business models

and strategies. McGraw Hill. Boston.

Alt, R., Zimmermann, H., 2001. Business models. In EM-

Electronic Markets 11(1).

Chen-Burger, Y-H., 2001. Knowledge sharing and

inconsistency checking on multiple enterprise models.

In IJCAI’01, 17

International Joint Conference on

Artificial Intelligence, Workshop on Knowledge

Management and Organizational Memories.

Chen-Burger, Y-H., Tate, A., Robertson, D., 2002.

Enterprise Modelling: A declarative approach for

FBPML. In European Conference on Artificial

Intelligence: Workshop on Knowledge Management

and Organizational Memories.

Chen-Burger, Y-H., Robertson, D., 2004. Automating

business modelling. Book Series of Advanced

Information and Knowledge Processing, Springer

Verlag. Berlin.

Dobson, J.E., Blyth, A.J.C., Chudge, J., Strens, M.R.,

1994. The ORDIT approach to organizational

requirements. In Requirements Engineering: Social

and Technical Issues. Academic Press. London.

Fox, M.S., Gruninger, M., 1998. Enterprise modeling. In

AI Magazine 19(3).

Gordijn, J., Akkermans, H., 2003. Value-based

requirements engineering: exploring innovative e-

commerce ideas. In Requirements Engineering 8(2).

Gordijn, J., Osterwalder, A., Pigneur, Y., 2005.

Comparing two business model ontologies for

designing e-business models and value constellations.

In 18

Bled e-Conference on e-Integration in Action.

Hamel, G., 2000. Leading the revolution. Harvard

Business School Press. Boston.

Hogger, C.J., Kriwaczek, F.R., 2004. Constraint-guided

enterprise portals. In ICEIS-2004, 6

International

Conference on Enterprise Information Systems.

IBM, UK, 1992. Business System Development Method:

Business Mapping Part 1: Entities, 2

edition.

Kuo, H-L., Chen-Burger, Y-H., Robertson, D., 2003.

Knowledge management using business process

modeling and workflow techniques. In IJCAI’03, 18

International Joint Conference on Artificial

Intelligence, Workshop on Knowledge Management

and Organizational Memories.

NIST - National Institute of Standards and Technology,

1993. Integration Definition for Function Modelling

(IDEF0). NIST. Gaithersburg.

Osterwalder, A., Pigneur, Y., Tucci, C.L., 2005. Clarifying

business models: origins, present, and future of the

concept. In Communications of the Association for

Information Systems, 16.

Schlenoff, C., Knutilla, A., Ray, S., 1997. In Proceedings

of the Process Specification Language (PSL)

Roundtable. NIST. Gaithersburg.

Uschold, M., King, M, Moralee, S., Yannis Zorgios, Y.,

1998. The enterprise ontology, In Knowledge

Engineering Review, 13.

GENERIC BUSINESS MODELLING FRAMEWORK

427
