A SEMANTIC WEB APPROACH TO ENRICH INFORMATION

RETRIEVAL ANSWERS

R. Carolina Medina-Ram

ırez and V

ıctor M. Ramos R.

UAM-Iztapalapa, San Rafael Atlixco 186, 09340 Iztapalapa, Mexico

Keywords:

Semantic web, document retrieval.

Abstract:

In previous works, we have presented the advantages of using a domain ontology and annotations for infor-

mation retrieval (Medina-Ram

ırez et al., 2002b) as well as the translation problems between languages with

different expression semantic levels (Medina-Ram

ırez et al., 2002a). In this paper we focus on the view point

of the end-user. In fact, we explore the impact and helpfulness of a domain ontology, semantic annotations

relying on this ontology and semantic resource descriptions so as to enrich end-user answers extracted from an

information retrieval system. A system that embodies this approach is presented. We argue that it is necessary

to improve the format of end-user answer in order to share and re-use knowledge.

1 INTRODUCTION

Huge amounts of heterogeneous data (structured data,

semi-structured data, textual data, multimedia data),

on the present Web is mainly addressed to human

users of the Web. The Semantic Web (Berners-Lee

et al., 2001; Shadbolt et al., 2006) aim to enable ma-

chines to understand, process and reason about re-

sources in order to provide better and more comfor-

table support for humans. The semantic contents de-

scription of Web resources, also called semantic anno-

tations, relying on ontologies contribute to reach this

goal. They could be processed by automated tools.

In the last few years, a new generation of

ontology-guided Information Retrieval systems have

been proposed –SHOE (Luke et al., 1997), Onto-

Broker (Fensel et al., 1999), OntoSeek (Guarino

et al., 1999), WebKB (Martin and Eklund, 2000),

Corese (Corby et al., 2004), RDFQ (Gaspari and

Guidi, 2003), Ontoweb (Kim, 2005)–. They fo-

cus on ontology knowledge representation languages

and propose an ontology-guided retrieval of annotated

documents.

The Web Community is invested in developing

new semantic search techniques, but the question of

improving the interaction with web content is at hand.

Web users aim at retrieving resources or services sa-

tisfying speciﬁc criteria or constraints. They want to

watch the retrieved resources in a personalized for-

mat. Particularly, results from desktop search engines

are still limited.

On current widely deployed search engines, the

result format is simple consisting of a set of lines des-

cribing the documents found which match a submitted

query. This description is based on the keywords sub-

mitted in the query and appears in the retrieved docu-

ment. Important information ﬁelds such as: document

type (journals, proceedings or informal notes), pub-

lication date, author names, journal and conferences

name is missing in a typical answer from the web. The

presence of such information in the returned results is

of relevant importance to select the pertinent docu-

ment from a speciﬁc user query. A much richer ex-

pressiveness than simple keywords for describing re-

sources is considered by the semantic web approach.

Languages like XML let us on one hand represent

more explicitly the structure of electronic documents,

and on the other hand they let us manage such infor-

mation in an easy way. Specialized document bases

such as PubMed (Database, 2002), use this approach.

We claim that an effort has to be made in the dis-

playing of results to submitted queries for a better

comprehension and transfer of knowledge.

299

Carolina Medina-Ramírez R. and M. Ramos R. V. (2007).

A SEMANTIC WEB APPROACH TO ENRICH INFORMATION RETRIEVAL ANSWERS.

In Proceedings of the Ninth Inter national Conference on Enterprise Information Systems - SAIC, pages 299-302

DOI: 10.5220/0002409402990302

 SciTePress

ESCRIRE

Format

Interactions

Figure 1: Escrire format.

2 ESCORSERVER

ARCHITECTURE

The process of representing the meaning of docu-

ments in a better suited form to processing by com-

puters (called semantic annotations) is of key impor-

tance in the semantic web approach.

The information retrieval needs on the Web are

present in different scales in scientiﬁc communities,

also called corporate Semantic Webs. The framework

of the semantic Web can be applied on these com-

munities in order to gain beneﬁt from that approach.

In particular, among the heterogeneous resources be-

Abtracts

Translator

RDF

Annotations

RDFS

Corese

C-RESESCrire:

Escrire

result Cosntructor

Documents

List

Escrire

Annotations

Escrire

Ontology

GraphicInterface

SELECT

FROM

WHERE

Query

TradRESEscrire

Escrire query translator

Medline

Annotations

Hyperdocuments

GenDocVir:

Virtual documents generator

Figure 2: EsCorServerArchitecture.

longing, for example, to a scientiﬁc community or

a company, documents (in electronic or paper form)

constitute a signiﬁcant source of knowledge needing

to be represented, handled, queried and diffused.

The ESCRIRE project (R. et al., 2000) is focused

on the context of corporate semantic webs. The aim

of the ESCRIRE project is the representation and han-

dling of document contents for document retrieval. In

ESCRIRE, a test base composed of a set of 4500 abs-

tracts of articles in biology from PubMed with seman-

tic annotations on their contents has been used. The

result format used to display the answers retrieved

is a list of pertinent documents (similar to the major

search engines) including also the query submitted by

the user. This query is included in order to refresh the

user’s goals or information needs so as to help him/her

to select from the list the best document match. Such

format is presented in Figure 1.

In order to capitalize and diffuse the knowledge on

genetic interactions in the documentary memory, we

proposed EsCorServer. EsCorServer is a document

server to handle, share and capitalize explicit knowl-

edge (document content and data) from a speciﬁc do-

main (Drosophila melanogaster’s gene interactions)

for information retrieval. EsCorServer is based on an

ontology-guided information retrieval, semantic an-

notations of domain articles abstracts, PubMed des-

criptions and adaptive hypermedia techniques. The

heterogeneous aspects of this documentary memory

reside on the nature of its resources and on its docu-

ment content representation format. Figure 2 shows

ICEIS 2007 - International Conference on Enterprise Information Systems

300

Authors

Title

PubMed

Interaction

Information

Answer Documents Query donne

Publication year

Abstract

Figure 3: Enriched end-user approach.

the EsCorServer architecture.

Typical information retrieval systems present

problems in the adequacy of queries like representa-

tions of informations needs. In order to improve these

problems, an interface is provided in EsCorServer to

help users to get from goals or information needs

to structured queries. This interface charged of in-

troducing, translating and displaying results from a

query. The translation and retrieving mechanism are

described in (Medina-Ram

ırez et al., 2002a; Medina-

Ram

ırez et al., 2002b). The main element in Es-

CorServer is the GenDocVir module which generates

on-demand the virtual interaction information docu-

ment. We describe this document in Section 3.

3 ENRICHED END-USER

ANSWER APPROACH

There has been much experimental research focus in

information retrieval on the processes of text repre-

sentation, organization and comparison. They do not

traditionally care about the individual searcher, pre-

ferring instead to focus on the development of global

retrieval techniques rather than those adapted for the

needs of the individual. We focus on providing a more

personalized retrieval experience and on helping users

to choose among retrieval alternatives. In order to

achieve this goal, we use ontology and resources des-

cription to enrich the answer given to the user. We

can easily access annotated information by exploiting

Figure 4: Interaction information generated on-demand.

the Corese semantic search engine (Corby and Faron-

Zucker, 2002).

The enriched end-user answer approach shown in

Figure 3 consists of creating a hyperdocument com-

posed of the abstracts of documents retrieved by the

Corese search engine. Besides, this hyperdocument

includes links to additional documents: the original

document in PubMed, the submitted query and the

interaction informations created on-demand. The au-

thor’s name, publication date, journal and PubMed

identiﬁer are included in the hyperdocument to pro-

vide additional useful information .

Our main contribution is an approach to inte-

grate semantic descriptions of gene interactions (Es-

crire annotations) and the concepts of a domain on-

A SEMANTIC WEB APPROACH TO ENRICH INFORMATION RETRIEVAL ANSWERS

301

tology, in order to generate on-demand a virtual inter-

action information document. This document intends

to clarify the concepts involved in the retrieved docu-

ments. Figure 4 shows the virtual interaction informa-

tion document. This document contains speciﬁc in-

formation such as: genes description –scientiﬁc gene

names, belonging family, activation or inhibition ef-

fects, participant genes names of interactions men-

tioned in the article.

The challenge is to create such document by

adding semantic resource descriptions according to

user interests, so as to display them in a manner that

facilitates exploration and encourages the user. More

speciﬁc learning scenarios and proﬁles must improve

the adequacy between the annotation contents and the

end-user requests.

4 CONCLUSION AND FUTURE

WORK

The innovative aspect of the approach described in

this paper and the contribution to the ﬁeld of adap-

tive hypermedia documents is the merging of different

resource descriptions. This approach provides robust-

ness to end-user answers to a query as well as a way

of accessing information annotated. This is done by

exploiting the Corese semantic search engine.

From the experience got from this work, we be-

lieve that manual annotation of resources is over-

whelming to domain experts or teachers when they

face a large amount of resources. So, it is impera-

tive to automate as much as possible the extraction of

knowledge from structured format documents.

Preliminary evaluations of our prototype have pro-

duced encouraging results. So, our future work will

focus on an extension of our prototype to analyze

additional results on this direction. We would like

to apply information ﬁltering techniques in a corpo-

rate semantic web. In particular, we are interested in

implementing proﬁles as a correct speciﬁcation of in-

formation interest. These proﬁles are built based on

repeated uses of the system, by a person or persons

with long-term goals or information needs.

REFERENCES

Berners-Lee, T., Hendler, J., and Lassila, O. (2001). The

semantic web. Scientiﬁc American, 284(5):35–43.

Corby, O., Dieng-Kuntz, R., and Faron-Zucker, C. (2004).

Querying the semantic web with corese search engine.

In Proceedings of the 16th Eureopean Conference on

Artiﬁcial Intelligence, ECAI’2004, including Presti-

gious Applicants of Intelligent Systems, PAIS 2004,

Valencia, Spain, August 22-27, 2004, pages 705–709.

Corby, O. and Faron-Zucker, C. (2002). Corese: A cor-

porate semantic web engine. In Proceedings of the

WWW2002 Workshop on Real World RDF and Seman-

tic Web Applications, Honolulu, Hawai, USA.

Database, M. (2002). http://www.ncbi.nlm.nih.gov/PubMed.

Fensel, D., Angele, J., Decker, S., Erdmann, M., Schnurr,

H.-P., Staab, S., Studer, R., and Witt, A. (1999).

On2broker: Semantic-based access to information

sources at the WWW. In Proceedings of the World

Conference on the WWW and Internet: WebNet, pages

366–371.

Gaspari, M. and Guidi, D. (June 2003). Towards an

ontology-guided search engine. tecnical Report

UBLCS-2003-8.

Guarino, N., Masolo, C., and Vetere, G. (1999). Ontoseek:

Content-based access to the Web. IEEE Intelligent

Systems, 14(3):70–80.

Kim, H. H. (2005). Ontoweb: Implementing an ontology-

based web retrieval system. Journal of the Ameri-

can Society for Information Science and Technology,

56(11):1167–1176.

Luke, S., Spector, L., Rager, D., and Hendler, J. (1997).

Ontology-based web agents. In Proceedings of

the First International Conference on Autonomous

Agents, pages 59–68.

Martin, P. and Eklund, P. W. (2000). Knowledge retrieval

and the World Wide Web. IEEE Intelligent Systems,

15(3):18–25.

Medina-Ram

ırez, C., Corby, O., and Dieng-Kuntz, R.

(2002a). A conceptual graph and RDF(S) approach

for representing and querying do cument content. In

Advances in Artiﬁcial Intelligence-IBERAMIA 2002,

8th Ibero-American conference on AI. Ganjo Fran-

cisco J., Riquelme J. Crist

obal., Toro M. (Eds.). LNCS

2527,Seville, Spain., pages 121–130.

Medina-Ram

ırez, C., Corby, O., and Dieng-Kuntz, R.

(2002b). Querying a heterogeneous corporate seman-

tic web: A translation approach. In Proceedings of

the international workshop on “Knowledge Manage-

ment through Corporate Semantic Webs”. During the

EKAW conference, Sing

uenza, Spain., pages 53–63.

R., A.-H., Corby, O., Dieng-Kuntz, R., Medina-Ram

ırez, J.

E. R. C., Napoli, A., and Troncy, R. (2000). Three

knowledge representation formalisms for content-

based manipulation of documents. In Proceedings of

the KR 2002 Workshop on Formal Ontology, Knowl-

edge Representation and Intelligent Systems for the

World Wide Web (Semweb).

Shadbolt, N., Berners-Lee, T., and Hall, W. (2006). The

semantic web revisited. IEEE Intelligent Systems,

21(3):96–101.

ICEIS 2007 - International Conference on Enterprise Information Systems

302
