RFID Privacy Protection Scheme for Secure Ubiquitous

Computing

Hyun-Seok Kim, Jung-Hyun Oh and Jin-Young Choi

Dept. of Computer Science and Engineering, Korea University

Seoul, Korea

Abstract. A Radio-Frequency-Identiﬁcation (RFID) tag is a small and inexpen-

sive device that consists of an IC chip and an antenna which communicate by ra-

dio frequency. It emits an ID in response to a query from a radio communication

device called as a reader. For this reason, the RFID tag is used for management

of goods and it is used as a substitute for a bar code. However, RFID system may

infringe on a consumer’s privacy because it has a strong tracing ability. In this

paper we describe problems of previous works on RFID security protocols and

specify several known attacks and introduce PPP(Privacy Protection Protocol) for

a RFID security protocol which serves as a proof of concept for authentication

an RFID tag to a reader device using the vernam and standard encryption as a

cryptographic primitive. To verify our protocol, we use model checking method-

ology, that is, Casper(A Compiler for Security Protocol), CSP(Communicating

Sequential Processes) and then verify security properties such as secrecy and au-

thentication using FDR(Failure Divergence Reﬁnement) tool.

1 Introduction

Recently, the mass deployment of Radio Frequency Identiﬁcation systems (RFID)[1][2]

has taken place. These systems comprise of Radio Frequency (RF) tags or transponders,

and RF readers or transceivers. Tag readers broadcast an RF signal to access resistant

data stored in tags. One of the main differences with barcodes is that RFID tags provide

an unique identiﬁer, or a pseudonym that allows accessing to this unique identiﬁer. The

use of RFID tags offers several advantages over barcodes: data can be read automati-

cally, without line of sight, and through a non-conducting material such as cardboard or

paper, at a rate of hundreds of times per second, and from a distance of several meters.

Despite all the advantages RFID technology offers there are serious concerns about

security and privacy as well. To minimize the above concerns, security protocols play

an essential role. As with any protocol, the security protocol comprises a prescribed

sequence of interactions between entities, and is designed to achieve a certain end. A

diplomatic protocol typically involves a memorandum of understanding exchange, in-

tended to establish agreement between parties with potentially conﬂicting interests. Se-

curity protocols are, in fact, excellent candidates for rigorous analysis techniques: they

are critical components of distributed security architecture, very easy to express, how-

ever, extremely difﬁcult to evaluate by hand. They are deceptively simple: literature is

full of protocols that appear to be secure but have subsequently been found to fall prey

Kim H., Oh J. and Choi J. (2007).

RFID Privacy Protection Scheme for Secure Ubiquitous Computing.

In Proceedings of the 1st International Workshop on RFID Technology - Concepts, Applications, Challenges, pages 117-124

DOI: 10.5220/0002411201170124

 SciTePress

to a subtle attack, sometimes years later. Cryptographic primitives are used as building

blocks to achieve security goals such as conﬁdentiality and integrity authentication.

Formal methods play a very critical role in examining whether a security protocol is am-

biguous, incorrect, inconsistent or incomplete. Hence, the importance of applying for-

mal methods, particularly for safety critical systems, cannot be overemphasized. There

are two main approaches in formal methods, logic based methodology [3], and tool

based methodology [5][6][7]. In this paper, we specify the hash[1] based RFID authen-

tication protocols as the previous works which employs hash functions to secure the

RFID communication using Casper[6], CSP[5]. Then we verify whether or not it satis-

ﬁes security properties such as secrecy and authentication using FDR model checking

tool[7]. After running FDR tool, we reconﬁrm the existence of known security ﬂaws in

this protocol and propose the scheme of PPP(Privacy Protection Protocol) based on ver-

nam and standard encryption for secure RFID communication. The contribution of this

paper is designing and verifying the secure authentication protocol, which is widely re-

searched in RFID systems using formal methods. This paper is organized as follows. In

brief, Section 2 describes related work on RFID security and authentication schemes. In

Section 3, the use of model checking is outlined for analyzing security protocols. Our

analyzed result of the protocol will be described in Section 4. The proposed security

scheme associated with encryption are presented in Section 5. Finally, the conclusion

and our future work are addressed in the last section.

2 Related Work

Several researchers have attempted to resolve the security concerns related to the use

of RFID tags and have proposed protocols that claim either to achieve secure authen-

tication or to prevent unauthorized traceability. Most of these solutions only apply for

weak adversary model (see e.g., [1][4]). In particular, those protocols for which a back-

end server is a trusted third party and the channel between the reader and the server is

insecure, are susceptible to man-in-the-middle attacks. Weis-Sarma-Rivest-Engels [1]

propose an RFID system as follows; A reader deﬁnes a “Lock” value by computing lock

= hash(key)[1] where the key is a random value. This lock value is sent to a tag and the

tag will store this value into its reserved memory location (i.e. a metaID value), and

automatically the tag enters into the locked state. To unlock the tag, the reader needs to

send the original key value to the tag, and the tag will perform a hash function on that

key to obtain the metaID value. The tag then has to compare the metaID with its current

metaID value. If both of them are matched, the tag unlocks itself. Once the tag is in

unlocked state, it can respond its identiﬁcation number such as the Electronic Product

Code (EPC)[2] to readers’ queries in the forthcoming cycles.

3 Formal Methods for Security Protocol

3.1 Casper and FDR

Over the last few years, a method for analyzing security protocol that ﬁrst models com-

munication security protocol using CSP[5], then veriﬁes its secrecy, authentication and

118

other properties using FDR(Failure-Divergence Reﬁnement)[7]. In this method, the

main difﬁculty is specifying the security protocol’s behavior using CSP. Creating the

description of the security model with CSP is a very error-prone and difﬁcult task. To

simplify the expression of the security protocol, and render this process more error

free, Casper(A Compiler of Security Protocol Analyzer)[6] was developed by Gavin

Lowe[8]. This tool enables a non-expert who is unfamiliar with CSP to express the se-

curity protocol’s behavior more easily, without being familiar with the notation used

by CSP notation, using various key types, messages, security properties and intruder

knowledge descriptions contained in Casper. In brief, Casper is a compiler that trans-

lates a more simple and concise description of a security communication model into

CSP code.

3.2 CSP

CSP(Communicating Sequential Processes)[5] is a language for process speciﬁcation

specially designed to describe communication processes, and it can describe both a

pure parallelism and interleaving semantics. In CSP, the former(a pure parallelism) is

expressed as “ k ”and the latter(interleaving semantics) as “ k|”. The combination of

a client, server and intruder are regarded as a process. The use of two different con-

currency concepts is well suited to the description and analysis of network protocols.

For example, security communication systems operated in distributed networks can be

modeled brieﬂy as follows.

SYSTEM =(CLIENT1 ||| CLIENT2 ||| SERVER) || INTRUDER

4 The Modeling and Analysis of the RFID Authentication Protocol

using Casper and FDR Tool

4.1 The Speciﬁcation of Hash Unlocking Protocol

Firstly, we model the behavior of hash unlocking protocol at the hash lock scheme and

attacker in Casper script. The general overview of above protocol(Fig.1) was already

Table 1. The Hash Lock Scheme Notation.

T RF tag’s identity

R RF reader’s identity

DB Back-end server’s identity that has a database

Xkey Session Key generated randomly from X

metaID Key generated from reader using hash functioon

ID Information value of tag

Xn A random nonce generated by X

H Hash function

described in section 2[1].

119

Message 1. R − > T : Query

Message 2. T − > R : metaID

Message 3. R − > DB : metaID

Message 4. DB − > R : RKey, ID

Message 5. R − > T : RKey

Message 6. T − > R : ID

Fig.1. The hash unclocking protocol.

#Protocol description

0. -> T : R

1. T -> R : (H(Rkey)) % metaID

2. R -> DB : metaID % (H(Rkey))

3. DB -> R : Rkey, Id

4. R -> T : Rkey

5. T -> R : Id

Before explaination of # Protocol description, we will describe % notation to show

speciﬁc notation. The % notation is used so that the metaID can be forwarded to other

participants. This is why a reader can not construct the metaID, since the other reader

does not know the value of hash function where m is a message and v is a variable,

denoting that the recipient of the message should not attempt to decrypt the message m,

but should instead store it in the variable v. Similarly, v % m is written to indicate that

the sender should send the message stored in the variable v, and the recipient should

expect a message of the form given by m. Therefore, metaID is the certain not know-

ing result value of hash function for T. In # Protocol description header, to unlock the

tag, at the ﬁrst line, Message 0 means that T(Tag) must communicate with R(Reader).

The reader needs to send query to the tag and the tag sends the metaID to authenticate

with reader.(Message 1). The reader forwards this metaID to DataBase to be ensured

his identity.(Message 2). The DataBase has to compare the metaID with its current

metaID value and ,if both of them are matched, lets the reader know the key and Id of

tag.(Message 3). The reader authenticates his identity with the tag sending key received

by database. (Message 4). As a result, if both of them are matched, the tag unlocks

itself. Once the tag is in unlocked state, it can respond its identiﬁcation number(Id) to

queries of readers in the forthcoming cycles.(Message 5).

#Specification

Secret(R, Rkey, [T])

Secret(R, Id, [T])

Agreement(T, R, [Id, Rkey])

In hash unlocking protocol Casper script, #Speciﬁcation description represents secrecy

and authentication properties. The line starting with Secret expresses secrecy property

associated with data privacy in RFID system. For example, the ﬁrst statement is inter-

preted as “ R believes that Rkey is a secret which should be known only to R and T”

120

and the second statement is “ R believes that Id is a secret which should be known only

to R and T”. If R, T or DB is an intruder in this protocol, secret information will be

leaked to him, in which case a man-in-the-middle attack is considered to have occurred.

The line starting with Agreement deﬁne that authentication property associated with

authentication between a tag and a reader. For example, the third line means that “ T is

authenticated to R with Id, Rkey”

#Intruder Information

Intruder = Mallory

IntruderKnowledge = {Tag, Reader, DataBase}

The above shows the intruder deﬁnition (#Intruder Information).

4.2 Protocol Goals

Using CSP[5], we describe the properties, i.e. secrecy property associated with data pri-

vacy, authentication property associated with authentication between a tag and a reader.

The following predicate is implemented in CSP language.

SECRET_SPEC_0(s_) =

signal.Claim_Secret?T_!s_?Rs_ -> (if member(Mallory,Rs_)

then SECRET_SPEC_0(s_)

else SECRET_SPEC_1(s_)) []leak.s_-> SECRET_SPEC_0(s_)

The SECRET SPECT 0 and SECRET SPECT 1 represent secret property of above

#Speciﬁcation section meet in the system. Formally speaking, if T has completed a pro-

tocol run apparently with R(signal.Claim

Secret?T !s ?Rs ), and R is honest and

uncompromised, then the key accepted during that run by T is not known to anyone

other than R(SECRET

SPECT 1), otherwise the key is known by someone in the sys-

tem(leak.s ). Similarly, if R has completed a run with the honest and uncompromised

T, then the key accepted by R is not known to anyone other than T.

AuthenticateINITIATORToRESPONDER

Agreement_0(T) =

signal.Running1.INITIATOR_T.R

-> signal.Commit1. RESPONDER_R.T -> STOP

Formally speaking, the events of the form Running1.INITIATOR

T.R in T’s run of the

protocol are introduced to mark the point that should have been reached by the time that

R performs the Commit1.RESPONDER T.R event. Occurrence of Running1.INITIATOR

T.R run means simply that Agent T is following a protocol run apparently with R.

4.3 The Result of Veriﬁcation

In this paper, we show veriﬁcation results of the safety speciﬁcation in hash unlock-

ing scheme, we use traces reﬁnement provided in FDR tool. Through debugging the

counter-example trace events, we reconﬁrm that hash unlocking protocol may be sus-

ceptible to a sniff and spoof attack by an intruder due to unsecured communication

121

channel between reader and tag. A general attack scenario, which could be found in

this protocol is described as below; I Agent means an intruder who can sniff messages

and spoof his identity.

1. Tag -> I_Reader : H(RKey)

2. I_Mallory -> DataBase : H(RKey)

3. DataBase -> I_Mallory : RKey, Id

The notation I

x represents the intruder I imitating some participant to fake or intercept

a message. Through the man-in-the-middle attack of the hash unlocking protocol, an in-

truder masquerading as Reader in Message 1, 2 could forward the message H(Rkey)and

in Message3, an intruder masquerading as Reader could intercept the RKey, ID.

5 The Design and Veriﬁcation of Privacy Protection Protocol for

RFID System

5.1 The PPP (Privacy Protection Protocol)

In the previous scheme [9], they assumed that R(reader) is a TTP(Trusted Third Party)

and the communication channel between R(reader) and DB(database) is secure. How-

ever, we assume that R is not a TTP and the communication channel is insecure like

the current wireless network. The PPP(Privacy Protection Protocol) for establishing a

session key involves the exchange of four messages; it is illustrated in Figure.2. below.

When the initiator Tag transmits the information to the responder Reader, he transmits

Message 1. T − > R : Anonymous(T)∗

Message 2. R − > DB : Anonymous(T)∗, E

DBpublic

{T, P rivacy(R), SkeyR}

Message 3. DB − > R : SkeyR (+) SkeyT

Message 4. R − > T : E

SkeyT

{R}

Anonymous(T)∗ : E

DBpublic

{R, P rivacy(T ), SkeyT }: will be just forwarded to DataBase

Fig.2. The privacy protection protocol for secure RFID system.

a anonymous value that contains reader’s identity(R) he can receive in this system, pri-

vacy value(Privacy(T)) of Tag, and session key(SkeyT) of Tag (for Reader which the

server will later transmit the session key to be decrypted by authenticated Reader),

then sends it to the server DB (Message 1). Since the responder Reader can not ac-

knowledge the Anonymous(T), he forward the message to the Server(DataBase) with

encrypted message that contains tag’s identity(T) he want to access in this system, pri-

vacy value(Privacy(R)) of Reader, and session key(SkeyR) of Reader, then encrypt it

with DataBase’s public key and transmit the all messages to DataBase(Message 2). The

server DB forms the Vernam encryption of the two keys(SkeyT, SkeyR) he has received,

and returns these to Reader. When Reader receives this message, he can decrypt the

SkeyT using the SkeyR(Message 3). Finally, Reader can transmit the his real identity to

122

Tag using session key(SkeyT) securely(Message 4). After all steps ﬁnishing, Tag can

transmit his information to the authenticated Reader.

5.2 Modeling the Privacy Protection Protocol using Casper

In this section we give brief description of how we can model the PPP(Privacy Protec-

tion Protocol) in Casper. We give a brief overview instead of whole script due to the

limitation of space.(you can ﬁnd the whole script at[10])

#Protocol description

0. -> R : T

1. T -> R : {R, privacy(T), kT}{pkdb}%AnonyT

2. R -> DB : {T, privacy(R), kR}{pkdb},

AnonyT%{R, privacy(T), kT}{pkdb}

3. DB -> R : kT (+) kR

4. R -> T : {R}{kT}

In # Protocol description, to authenticate the reader from database and tag, at the

ﬁrst line, Message 0 means that R(Reader) must communicate with T(Tag). In Message

1, T transmits the encrypted value with DB’s public key(pkdb) to R and the encrypted

value include R’s identity(R), anonymous value(privacy(T)) of T’s identity using pri-

vacy function, and session key(kT) generated from T. This message would be used to

forward from T to DB using % notation. In Message 2, R forwards the AnonymousT

with the message that contains tag’s identity(T), privacy value(Privacy(R)) of Reader,

and session key(kR) of Reader, then encrypt it with DB’s public key(pkdb) and transmit

the all messages to DB. In Message 3, we introduce exclusive-or(+) technique called

Vernam encryption into this protocol. After DB received the two session keys from R

and T, he forms the Vernam encryption and transmits these to the R. As a result, if R

get the another session key, they will use it to communicate their information such as

EPC[2] and thus mutual authentication between them can be satisﬁed. In message 4, R

can transmit the his real identity(R) to T using session key(kT) securely.

5.3 The Result of Veriﬁcation

In this paper, we show veriﬁcation results of the safety speciﬁcations in PPP(Privacy

Protection Protocol) scheme, we use traces reﬁnement provided in FDR tool. After

running the FDR model checking tool, this protocol satisﬁes the Secret and Agreement

requirements in Casper script and the testing result of the protocol can be described in

CSP like below.

– Secret

R,T

(tr) = ∀ m • signal.Claim

Secret.R.T.m in tr ∧ R ∈ Honest ∧ T ∈ Honest

⇒ ¬ (leak.kR.kT in tr)

For all message m, through trace speciﬁcation(tr), the session key kR and kT were

not leaked by an intruder. That is, at the message 1, 3, conﬁdentiality of the kR and

kT can be ensured through public key encryption scheme. It prevents a replay and

man-in-the-middle attack between agents.

123

– Secret

T,R

(tr) = ∀ m • signal.Claim Secret.T.R.m in tr ∧ T ∈ Honest ∧ R ∈ Honest

⇒ ¬ (leak.kR.kT in tr)

For all message m, through trace speciﬁcation(tr), the session key kR and kT were

not leaked by an intruder. T can believe the authentication through the kR and kT

because all the messages was transmitted using exclusive-or technique from DB.

– R ∈ Honest ⇒ signal.Running

Initiator.T.R.kT.Kr precedes signal.Commit Respo-

nder.R.T.kT.kR

In this protocol, we can guarantee that the corresponding Running signal has oc-

curred provided we assume that the initiator is honest: that R ∈ Honest. This results

in a successful key agreement between two agents through authenticated channel

by kR and kT.

6 Conclusions

Mobile and Ubiquitous computing is deﬁned as environments where users can receive

network services for anytime and anywhere access through any device, connected with

a wired and wireless network to information appliances including the PC. In this en-

vironment, there are many security threats that violate user privacy and interfere with

services. In this paper, we focus on proposal of Ensuring Privacy Protocol which can

be widely researched in RFID system and safety analysis of the protocol using Casper,

CSP, and FDR. In verifying this protocol with FDR tool, we were able to conﬁrm pre-

vent this protocol from some of the known security vulnerabilities which are likely to

occur in RFID system.

References

1. Sarma, S., Weis, S., Engels,D.: RFID systems and security and privacy implications. Work-

shop on Cryptographic Hardware and Embedded Systems(CHES) 2002. LNCS No. 2523

(2003) 454-469

2. EPCGLOBAL INC.: http://www.epcglobalinc.org.

3. Gong, L., Needham, R., Yahalom, R.: Reasoning about Belief in Cryptographic Protocols.

The 1990 IEEE Symposium on Security and Privacy (1990) 18-36

4. Juels, A., and Weis, Stephen.: Authenticating Pervasive Devices with Human Protocols. Ad-

vances in Cryptology - CRYPTO (2005), LNCS, volume 3621, 293-308.

5. Hoare, C.A.R.: Communicating Sequential Processes. Prentice-Hall. Englewood Cliffs. NJ

(1985)

6. Lowe, G.: Casper: A compiler for the analysis of security protocols. Proceeding of the 1997

IEEE Computer Security Foundations Workshop X. IEEE Computer Society. Silver Spring.

MD (1997) 18-30

7. Formal Systems Ltd. FDR2 User Manual. Aug. (1999)

8. Ryan, P. Y. A., Schneider, S. A.: Modelling and Analysis of Security Protocols: the CSP

Approach. Addison-Wesley (2001)

9. Ohkubo, M., Suzuki, K., Kinoshita, S.: Hash-Chain Based Forward-Secure Privacy Protec-

tion Scheme for Low-Cost RFID. Proc. of the SCIS 2004. (2004) 719-724

10. http://formal.korea.ac.kr/∼hskim/PPP

124
