A Framework for Business Process Integration - An

Agent-mediated Approach

Zheng Zhao, Virginia Dignum and Frank Dignum

Department of Information & Computing Sciences, Utrecht University, The Netherlands

Abstract. Coordination of business processes within and across organizations

attracts more and more attention because of the growth of e-commerce and the

implicit boundaries of organizations. Current approaches are not ﬂexible enough

to support decision making concerning Business Process Integration (BPI) solu-

tions that take into account economic, social, and technical aspects. In this paper,

we will analyse the problems that currently exist and propose an agent-based

framework for mediation. We identify the requirements of this agent-mediated

framework and argue the advantages of using self-adaptive agent organizations

as model for mediation.

1 Introduction

Nowadays executing a typical business process may involve several different resources,

databases, application systems and business rules, which can be either located within or

across organizations. In order to execute a business process properly, organizations must

deal with problems of heterogeneity of interfaces, ontology, communication languages,

and interaction protocols. Therefore, coordination of such business processes becomes

an important and non-trivial issue. Many efforts have been made to develop middleware

for integrating and automating enterprise business processes over the past decade [1],

however, current Business Process Integration (BPI) solutions (such as Tibco , Web-

methods, Seebeyond, ebXML, IBM websphere and Cordys) are not ﬂexible enough to

support decision making that take into account both economic and technical aspects.

Most systems consider only the technical aspects, such as the synchronization of work-

ﬂows, resource retrieval, etc. However, economic and social aspects also play very im-

portant roles in system design. A system is attractive to users (organizations) only when

the users can beneﬁt by using it. Moreover the beneﬁt one can get has to be shown be-

fore the user decides to join the system. Furthermore, coordinating business processes

across organizations needs to consider the independent nature of each organization. In

order to guarantee the cooperative outcomes, social aspects such as organizational cul-

ture and norms have to be taken into account.

Two fundamental architectural choices for process integration can be recognized.

One is that parties interact directly, which is also called unmediated communication.

The other is to use a third entity that mediates or supports the communication. The

latter approach has several names, such as orchestration (Microsoft), choreography

(SAP/Sun), brokering or mediation. We will use the term “mediation” in this paper.

Zhao Z., Dignum V. and Dignum F. (2007).

A Framework for Business Process Integration - An Agent-mediated Approach.

In Proceedings of the 4th International Workshop on Computer Supported Activity Coordination, pages 13-24

DOI: 10.5220/0002412100130024

 SciTePress

One important advantage of mediation is that participants do not need to know each

other or each other’s standards since the central party is capable to exchange informa-

tion among them. Of course, mediation also has its drawbacks, i.e. it brings overhead

costs and needs a proper IT governance solution to manage it. Therefore, it is important

for our research to clearly deﬁne situations where mediation is an advantage.

From the agent perspective, the term “mediator” was probably used in Computer

Science for the ﬁrst time in [2] for active middleware that mediates between the users’

workstations and data resources. The mediation used here focused on data and was

unidirectional. Nowadays, we often read about mediators or broker agents in the ﬁeld

of Multi-agent systems. However, it is rarely discussed in-depth whether they are really

needed and under what circumstances they are needed or whether they are preferable to

other solutions.

Multi-agent systems (MAS) are widely considered as suitable abstractions to model

coordination and communication issues because of the characteristics they exhibit [3]:

– Are typically open and have no centralized designer;

– Contain autonomous, heterogeneous and distributed agents, with different ‘person-

alities’ (cooperative, selﬁsh, honest, etc.);

– Provide an infrastructure to specify communication and interaction protocols.

In this paper, we analyze what types of mediators are really needed for what kind of

situations and propose an agent-mediated framework. In Section 2, we give an overview

of existing techniques. In Section 3, we investigate the requirements of Agent-mediated

Business Coordination (ABC) method. Scenario for the ABC framework is presented in

Section 4. Section 5 shows the different types of mediators. And we conclude in Section

6 with the direction of our future work.

2 An Overview of Current Techniques

In this section, we will give an overview of current existing mediation techniques based

on agent technology. We don’t mean to make exhaustive comparisons with these tech-

niques from different aspects, but give an introduction to their working mechanisms.

2.1 TuCSoN

TuCSoN [4,5] is an agent coordination infrastructure as well as a model for the (objec-

tive) coordination of Internet agents, particularly suitable to mobile information agents.

The TuCSoN model is based on the notion of (logic) tuple centres, each of which is

an independent interaction space that abstracts the role of the environment. Tuple cen-

tres are coordination artifacts that mediate and govern agent interaction according to

coordination laws that deﬁne their reactive behavior. For example, consider a scenario

with three tasks A, B, and C, which must be coordinated according to the following

workﬂow rule: task C can start only when both task A and task B have been success-

fully completed. In order to provide this speciﬁc coordination service, the tuple centre

is programmed by a set of reactions, i.e. agents that are responsible for executing task

A and task B provide the result of a task by inserting a tuple task done(...) after the

task is executed. When both task

done(...) tuples of task A and task B are inserted into

the tuple centre, a tuple task todo(...) for task C can be made observable by the tuple

centre. The agent that is responsible for task C can then be aware of the task to execute

by observing the task

todo(...) tuple and start executing it by retrieving this tuple from

the tuple centre.

TuCSoN is developed in Java and directly supports the integration between hetero-

geneous information sources. Its tuple centres are powerful coordination abstractions

that act as intelligent information mediators that map knowledge to knowledge. Because

of this, participants do not need to change their model of knowledge representation and

new participant can be easily integrated dynamically. This dynamic behavior speciﬁca-

tion is also the key property that allows TuCsoN to support heterogeneity at the process

level. It stores coordination rules outside the interacting entities, and as such governs

their interaction in a predictable way.

From the technical point of view, TuCSoN encapsulates the workﬂow rules as coor-

dination laws and separates the workﬂow participants from the workﬂow engines, thus

effectively achieves the dynamic coordination among participants.

2.2 JBees

JBees [6] is a prototype Workﬂow management systems (WfMSs) that is based on agent

technology. It provides a mechanism for communication of distributed components in

order to support inter-organizational WfMS. JBees is based on Opal (a Java-based agent

platform) [7] and uses the Coloured Petri Net (CPN) execution tool JFern [8]. The idea

of JBees is that the work associated with running a WfMS has been partitioned among

various collaborating agents that are interacting with each other by following standard

agent communication protocols. The system consists of seven Opal agents that provide

the functionality to control the workﬂow:

– Management agent: It provides the user interface for the human workﬂow manager;

– Storage agent: It manages the persistent data of the workﬂow, such as the deﬁnitions

of tasks, roles and processes, and the monitored data. It also notiﬁes all management

agents if the data has been changed;

– Process agent: It is in charge of executing one particular case. A new process agent

is created for each work case and for each sub-work case. The process agent uses

JFern to execute the CPN model provided by the management agent or by the “par-

ent” process agent;

– Resource agent: It is the user interface for the human resource or the interface for

tools such as printers and scanners;

– Resource broker agent: It is responsible for the resource management;

– Monitor agent: It gathers the data in the system that is necessary to analyze work-

ﬂows and sends the data associated with a particular case to the storage agent for

persistent storage after the case is ﬁnished;

– Control agent: It provides the feedback mechanism required for process re-

engineering.

By combining the CPN-formalism and the collaborating software agents, JBees pro-

vides a high level of ﬂexibility and adaptability. Its monitoring and feedback mecha-

nisms also make it possible to study and analyze the various processes and cases.

JBees guarantees process consistencies at each step of the process execution, thus

technically provides the basic executing elements of coordinating multiple business pro-

cesses.

2.3 mPower

mPower [9] is a component-based layered framework developed for easing the devel-

opment of multi-agent systems. It builds on the JADE-LEAP platform that provides a

homogeneous layer over diverse operating systems and hardware devices. In mPower, a

business process is viewed as a linked set of conversations among participating process

actor roles. The services for executing business tasks are provided by conversational

components (C-COMs) via interaction with other agent roles. A C-COM consists of

two main building blocks, which are an interaction protocol and the role components.

The interaction protocol deﬁnes the sequence of asynchronous messages sent between

the role components, and the role components perform the actions necessary accord-

ing to the interaction protocol to achieve the service goal. For each C-COM, there are

two generic role components – initiator (starts by sending a message) and respondent

(activated when receiving a message).

The mPower framework consists of four layers – foundation, components, generic

workﬂow and applications. The foundation layer contains the supporting functionality,

such as message transportation, ontology support, language support, etc. The compo-

nents layer consists of ontology components and service components (C-COMs). The

ontology components map the common ontology items into the hierarchy’s predeﬁned

categories and detail the attributes of the items in target domains, whereas C-COMs

abstract and implement the common message-based interactions between participating

agents in target domains. The generic workﬂow layer provides architectural patterns

that can be used as templates to automate domain- or organization-speciﬁc business

processes. The application layer consists of customized collection of components from

the layers beneath it.

The layered mPower framework provides a ﬂexible infrastructure for process co-

ordination. Moreover, the generic workﬂow layer pre-deﬁnes workﬂow templates that

avoid redundant development of similar business processes.

2.4 RETSINA

RETSINA [10] is an implemented open MAS infrastructure that supports communities

of heterogeneous agents and has been applied in many ﬁelds, such as ﬁnancial portfo-

lio management and logistic planning. The MAS infrastructure is deﬁned as the set of

services, conventions, and knowledge that support complex social interactions among

participating agents. The abstract infrastructure consists of 9 layers that provide differ-

ent services to a MAS:

– Operating Environment: A layer on which a MAS relies, including physical com-

puters, operating system, networks;

– Communication Infrastructure: This layer transfers messages between the agents

as well as between the agents and the MAS infrastructure;

– ACL (Agent Communication Language) Infrastructure: This layer provides the

speciﬁcation of a language that can be spoken and understood by all the agents

in the system community;

– Multiagent Management Services: This layer provides additional system opera-

tion services, such as logging facilities, management tools, installation services and

launching services;

– Performance Measurement: This layer monitors the performance of the heteroge-

neous agents which differ in their ability, efﬁciency, reliability etc;

– Security: Since agents in an open MAS, which have been designed by different

development groups, can join and leave the society dynamically, it is necessary to

have a security layer that ensures agents do not misbehave;

– Mapping Names to Agent Locations: This layer maps the agent name dynamically

to the agent location that provides the basis for agent mobility;

– Mapping Capabilities to Agents: This layer maps capabilities to agents by means

of Middle Agents, which match agents’ requests and agents’ advertisements;

– Interoperation: This layer provides real-time interoperation between different MASs

that may have their own architecture-speciﬁc features.

RETSINA is implemented on the basis of this infrastructure. It implements dis-

tributed infrastructural services that facilitate the relations between the agents. It is

based on two types of communication channels:

1. Direct message transfer, which provides peer to peer communication between the

agents;

2. Multicast based discovery process, which connects agents to the infrastructure com-

ponents.

It provides an ontology based on diverse domain-speciﬁc taxonomies of concepts,

as well as a protocol engine and a protocol language. RETSINA uses middle agents

called Matchmakers to allow agents to search what services are available in the MAS

and who provides the services. Each Matchmaker records a mapping between agents

in the system and the services that they provide. One important characteristic of the

RETSINA Matchmakers is that they do not stay in the middle of the interaction between

the providers and the requesters. Because of this, the system becomes more robust.

The RETSINA-OAA InterOperator in the RETSINA MAS infrastructure provides a

bridge between the RETSINA system and the OAA (Open Agent Architecture) system.

It allows any agent in one system to access any service or information provided by

agents of another system.

Technically speaking, Matchmakers in RETSINA act successfully as middlemen

that match the agents and the services each agent provides, which show an important

basic functionality of a mediator that facilitates business process coordination.

2.5 Insufﬁciencies of Current Techniques

Although the techniques described in this section can solve process coordination prob-

lems to some degree, these systems are quite passive. The systems just work as middle

machines that receive tasks and then execute them.

Each technique has its own characteristics:

– TuSCoN focuses on objective coordination, which is coordination outside the agents.

The workﬂow rules are encapsulated as coordination laws and then superimposed

on the agents.

– JBees focuses on the simulation, analysis, and monitoring of the process execution

in order to identify potential inconsistencies and improve process performance.

– mPower considers conversations among participating process actor roles as the core

of the framework.

– In RETSINA, coordination structure emerges from the relations between the agents

that are facilitated by the distributed infrastructural services. RETSINA also uses

Matchmakers to match between agents and the services they provide.

All these infrastructures focus on the step by step execution of business processes.

None of them cares whether (at a certain step) there is another possible solution that may

give more beneﬁts. The middleware doesn’t have its own goals. However, industrial

solutions often require reactive and proactive mediator agents that have their own goals

(such as ﬁnd best partner for job, ﬁnd cheapest component for solution, etc), and are

able to reason about the goals and motivations of the different parties. This means that

besides the technical aspect, both the economic and the social aspects of the system

must be considered in a way such that business objectives, organizational culture and

norms can be taken into account in the proposed interactions.

3 Requirements of the ABC Method

In section 2, we gave an overview of the current techniques. Although those techniques

provide relatively good infrastructures for process coordination, they do not consider

the economic and social aspects of the solutions.

3.1 Economic Requirements for Mediation

Since one main objective that organizations coordinate their business processes is to

reduce costs, solutions that don’t consider the economic aspects are not sufﬁcient.

Integration is key to e-business, therefore, extensive research has been done towards

theories on process integration. Johannesson and Perjons present design principles for

process modeling in Enterprise Application Integration (EAI) [11]. They argue for a

Process Broker architecture and propose a high-level modeling language BML (Busi-

ness Model Language) for application integration. Gordijn designs the e3-value model

[12] that introduces and combines several aspects that have to be taken into account

when combining applications. Some researchers have also argued for a separation of

coordination aspects from the application functionality, where the coordination aspects

are described by contract. However, all of these are ingredients for BPI, such that the

problem of how the integration should be performed hasn’t yet been indicated.

In [13], it is mentioned that by reducing the costs of coordination, information tech-

nology will lead to an overall shift toward proportionately more use of markets to co-

ordinate economic activity. With the increasing use of IT, companies may deal with

customers directly (e.g. via internet), which removes the intermediaries, such as dis-

tributor, wholesaler, broker, or agent. This is also called cutting out the middleman

(disintermediation). However, there are also possibilities for reintermediation, which

is the reintroduction of an intermediary between consumers and producers after dis-

intermediation has occurred. The new roles for intermediaries include trust provision,

aggregation, one-stop shopping, information exchange facilitator, and information ﬁl-

tering brokers. Current interorganizational systems do not often succeed because the

added-value for the stakeholders is hard to quantify and guarantee. The situation can be

considered as a prisoner’s dilemma: collaboration on the basis of system integration is

proﬁtable for all parties, but only if all parties do cooperate. Therefore, there is a need

to analyze the problem and come up with workable business models, particularly for

the situation where the intermediary party is independent.

Companies try to enter the market and want to gain as much beneﬁts as possible.

Consumers that use mediators can beneﬁt by receiving more information and services.

When mediators hold a big amount of customers, companies would like to join medi-

ators as well because of the huge market mediators have. However, mediators won’t

work for nothing. As an independent middle party, mediators also want to beneﬁt from

the services they provide. Thus, contracts or norms are needed to enforce companies

and consumers remaining in the participation.

3.2 Social Requirements for Mediation

Mediation across organizations has to deal with self-interested agents in open envi-

ronment, where heterogeneous participants that have either cooperative or competitive

goals can join and leave dynamically. In order to ensure the cooperative outcomes for

tasks that are not doable individually, trust among participants is an important factor.

One possible solution that can provide a certain level of trust is to regulate the environ-

ment to enforce appropriate types of participant’s behavior.

Norms play an important role in open multi-agent systems (MAS) and allow for

the development of trust and reputation mechanisms [14]. Having norms is necessary

but not yet sufﬁcient by itself, because agents will not voluntarily submit themselves to

associated penalties when deviation occurs. Therefore, mechanisms such as Electronic

Institution (EI) [15] are needed to enforce norm compliance. An Electronic Institution

(EI) provides the necessary level of trustable environment by enforcing norms and pro-

viding speciﬁc services.

When multiple solutions are available, participants’ preferences should also be taken

into account in order to provide more satisﬁed services.

4 Scenario for the ABC Framework

We propose an Agent-mediated Business Coordination (ABC) model that focuses on

the analysis of requirements of mediators, and on the development of workable media-

tion models that consider technical, economic and social aspects.

In this section, we use a travel example (see Figure 1) to illustrate scenario for the

ABC framework. The situation is that people want to travel and they need to arrange

air tickets, hotels, excursions, or car rental, etc. The objective of the arrangement is to

meet the criteria mentioned by the consumer, e.g. low price, hotel should locate in the

center, the trip should be on a certain date, etc. There are three possible ways to arrange

the travel:

– Arrange the travel by contacting companies that provide the services directly, which

means arranging everything without any intermediaries (a travel agency, a ticket

agency, etc).

– Arrange the travel by consulting some agencies.

– Arrange the travel using a mediator.

When arranging the travel by contacting the companies directly, one can choose the

exact air company and hotel he or she prefers. However, the person needs to arrange

each step separately and ﬁnally combine them together, which can take a long time and

the process is quite complicated.

When arranging the travel by consulting agencies, there are many possibilities as

well. One can go to a ticket agency that provide tickets from different companies with

different prices, or go to a travel agency that provides information of both tickets and

hotels. Different agencies may give different promotions, but mostly they cannot pro-

vide information that cover all companies.

...

Comparison

Spain?

Mediator

Airline Company

Hotel Chain

Car Rental

Air Tickets

Hotels

Excursions

Air T. & Hotels Hotels & Excur.

Combined Services

Trip 1

Trip 2

Fig.1. Travel Example.

Another important point is that the consumer wants to travel as cheap as possible

when the qualities of services meet the consumer’s requirements. As a consequence,

the consumer may want to compare the prices and the qualities of services they can

get from different arranging methods and make decision based on the comparison. It is

obvious that it is quite hard to compare all the information without any help.

We propose a way that arranges the travel using a mediator. Some possible func-

tionalities of a mediator in this example are as follows:

– As a normal agency, the mediator is capable to aggregate information of different

companies and provide it to consumers. One important aspect of mediator is to

group as much information as possible.

– The mediator should be able to compare the results obtained from the two previ-

ously mentioned methods using the criteria proposed by consumers.

– Mediator should also take into account the norms of different agents. For example,

maybe advertisement cannot be sent to consumers if they didn’t request it, or it is

not allowed to pass personal information to others.

– Another issue is to take into account the preferences of agents: likes to travel in

groups or not, prefers single room or a room with cheaper price, etc.

– The mediator can be proactive, i.e. when it has some information of a potential

promotion, the mediator can broadcast the information and gather people. For ex-

ample, a hotel informed the mediator that there will be 10 rooms free in the coming

week, if the mediator can gather 10 people, the hotel can ask for half of the price

(the price of 5 rooms). In this case, the mediator can broadcast the promotion and

try to gather enough people.

– Proactive can be bi-directional, i.e. when a group of people want to book hotel

rooms, they can ask the mediator whether they can get any discount. The mediator

can then negotiate with hotels on whether they would like to give discount to the

group of people.

– Further more, when a customer wants to travel to a certain place (e.g. Spain), he/she

may consult the mediator whether anybody else wants to go to Spain. The mediator

can check it and reply to the customer. From the information provided by the medi-

ator, the customer can gather people who want to go to Spain and ask the mediator

for discount of the trip.

We will use this scenario to help us to generate ideas about when to use a mediator.

It can also help us to build and test our future business models, and help us to identify

the value of a mediator.

5 Different Types of Mediators

In different situations, it is necessary to have mediators with different power and func-

tionalities that act in different ways. Considering the travel example in Figure 1, medi-

ators that deal with hotels and those that deal with air tickets should act differently.

Mediators that deal with hotels can be quite powerful in a way that they can set

contracts with the hotels to force them selling rooms via the mediators. They can also

be proactive to give suggestions to the customers or the hotels. From the economic

point of view, setting up exclusive contract can ensure the proﬁts of the mediators. This

is obvious since without a contract, hotels and customers can set up their own business

relationship after getting information from the mediators. However, both advantages

and disadvantages exist for hotels that decide to set up a contract with the mediator.

The result depends on how many customers the mediator holds. If the mediator has a

huge amount of customers, the hotels can beneﬁt from such a big market and will enjoy

the contract. On the other hand, if the mediator has just a few customers, the contract

would force the hotels remain in the undesired situation.

Mediators that deal with airline companies cannot perform in the same way as deal-

ing with hotels, because airline companies are quite powerful and have dominant po-

sitions in the market. What mediators can do is to gather as much ﬂights (promotion)

information as possible and provide it to the customers. Mediators can also be proac-

tive in this case, but only to the customers. The reason is that mediators can not tell an

airline company to arrange a ﬂight on a speciﬁc date and time. However, they can query

customers when promotions are available. For example, if a mediator knows Jane goes

to Spain several times each month, and currently there are discount tickets to Spain, it

can inform Jane and ask her whether she wants to book a ticket. Economically, the more

valuable information a mediator can gather, the more proﬁt it can gain, i.e. if a media-

tor has a dominant position among systems that provide ﬂight information, customers

would have the preference to go to the mediator.

The necessity of different types of mediators indicates that a simple model of medi-

ator is not sufﬁcient. What we need is to identify different business models of mediators

and the factors that determine the applicability of these models to different situations.

There are several reasons of using agents to model mediators. In real-world practice

of mediation, some of the most common aspects of a mediator codes of conduct may

inspire the design of a mediation system [16], which are as follows:

– Mediators must adopt a neutral stance towards all parties to the mediation;

– Mediators must conduct the mediation in an impartial manner;

– Within the bounds of the legal framework, any information gained by the mediators

should be treated as conﬁdential;

– Mediators should not offer legal advice, but direct participants to appropriate sources

that are useful for the participants’ decision-making;

– Mediators should seek to maintain their skills by engaging in ongoing training in

the mediation process;

– Mediators should practice only in the ﬁelds in which they have expertise gained by

their own experience.

Intelligent agents can be considered as the most appropriate paradigm in order to

handle these aspects, because of their intrinsic capabilities, such as autonomy, reactivity,

pro-activeness, and sociality. Agents have goals, and can adapt to changing environment

by continuous learning and updating their knowledge.

Agents can be endowed with both economic and social goals. As a consequence,

interaction rules and norms should be incorporated into existing technical infrastruc-

ture in order to support the agents’ coordination. Since mediators are domain-speciﬁc,

one (or more) mediator(s) may be preferred to the others under certain circumstances.

Therefore, coordination is needed when multiple agents (mediators) coexist.

6 Conclusions

Mediators should be able to reason about motivations and goals of the different par-

ties, such that they can adapt to their (changing) needs. By understanding goals and

motivations, the mediator is able to provide meaningful alternatives for the requests of

different parties.

In this paper, we presented the initial work towards a mediation architecture for

business process integration across organizations. We discussed existing solutions and

their shortcomings and identiﬁed economic and social requirements for a more compre-

hensive solution. However, our work has just started. In the following we indicate the

direction of our current research and describe the research methods we propose to use

in this project.

Different research methods will be used in the research. Firstly, to come up with an

interdisciplinary theory of mediation in the context of BPI, we will do literature survey

on coordination mechanisms, economy and agent society. In order to be able to support

the choice of an appropriate type of mediator for a particular situation, we will develop

a mediator decision process. Different types of mediators and their adaptability will be

tested in an agent society test bed, which will also be developed.

In section 4, we proposed the idea of using a mediator for the travel problem. We

will generalize the problem to cover general business process coordination cases. First

of all, it is necessary to analyze the business coordination context in which mediation

is required or can give outstanding performance. According to the analyzed results,

mediation models that have different functionalities can be designed. Generalization

can be achieved by combining the diverse, but not conﬂict functionalities of different

mediation models.

The ﬁnal objective of our research is to develop a uniﬁed framework of media-

tion that takes into account technical, economic, and social aspects. In order to achieve

this, we need to classify mediators according to their characteristics and functionali-

ties. Based on the classiﬁcations, different models will be built up to represent different

types of meditators. Furthermore, these models should be able to adapt to the continu-

ous change in the environment.

Acknowledgements

This research is supported by NWO, under the project “Agent-mediated Business Co-

ordination”.

References

1. Dayal, U., Hsu, M., Ladin, R.: Business process coordination: State of the art, trends, and

open issues. In: The VLDB Journal. (2001) 3–13

2. Wiederhold, G.: Mediators in the architecture of future information systems. In Huhns,

M.N., Singh, M.P., eds.: Readings in Agents. Morgan Kaufmann, San Francisco, CA, USA

(1997) 185–196

3. Dignum, V.: A model for Organizational Interaction:Based on Agents, Founded in Logic.

PhD thesis, Utrecht University (2004)

4. Ricci, A., Denti, E., Omicini, A.: Agent coordination infrastructures for virtual enterprises

and workﬂow management. Volume 2182/2001 (2001) 235–246

5. Morini, S., Ricci, A., Viroli, M.: Integrating a mas coordination infrastructure with web

services. (2004)

6. Ehrler, L., Fleeurke, M., Purvis, M.: Agent-based workﬂow management systems (wfmss).

Information Systems and E-Business Management Volume 4 (2005) 5–23

7. Purvis, M., Craneﬁeld, S., Nowostawski, M., Carter, D.: (Opal: A multi-level infrastructure

for agent-oriented software development)

8. Nowostawski, M.: Jfern - java-based petri net framework. (2003)

9. Shepherdson, J.W., Lee, H., Mihailescu, P.: mpower: a component-based development

framework for multi-agent systems to support business processes. British Telecom tech-

nology journal Volume 21 (2003) 92–103

10. Sycara, K., Paolucci, M., van Velsen, M., Giampapa, J.: The RETSINA MAS infrastructure.

Technical Report CMU-RI-TR-01-05, Robotics Institute, Carnegie Mellon (2001)

11. Johannesson, P., Perjons, E.: Design principles for process modelling in enterprise applica-

tion integration. Information Systems 26 (2001) 165–184

12. Gordijn, J.: Value based requirements engineering: Exploring innovative e-commerce ideas.

PhD thesis, VU Amsterdam (2002)

13. Malone, T.W., Yates, J., Benjamin, R.I.: Electronic markets and electronic hierarchies. Com-

mun. ACM 30 (1987) 484–497

14. Cardoso, H.L., Rocha, A.P., Oliveira, E.: Virtual organization support through electronic

institutions and normative multi-agent systems. (2006)

15. Dignum, V., Dignum, F.: Modelling agent societies: Co-ordination frameworks and institu-

tions. In: Portuguese Conference on Artiﬁcial Intelligence. (2001) 191–204

16. Boulle, L., Nesic, M.: Mediation: Principles, Process, Practice. LexisNexis UK (2001)
