Obtaining Use Cases and Security Use Cases from Secure

Business Process through the MDA Approach

Alfonso Rodríguez

and Ignacio García-Rodríguez de Guzmán

Departamento de Auditoría e Informática, Universidad del Bío-Bío, Chillán, Chile

ALARCOS Research Group, Information Systems and Technologies Department

UCLM-Soluziona Research and Development Institute

University of Castilla-La Mancha, Ciudad Real, Spain

Abstract: MDA is an approach based on the transformation of models for

software development. It is complemented with QVT as a language for

transformations specifications. This approach is being paid much attention by

researchers and practitioners since it promotes the early specification of

requirements at high levels of abstractions, independently of computation, that

will be later part of models closer to the software solution. Taking into account

this approach, we can create business process models incorporating

requirements, even those of security, that will be later part of more concrete

models. In our proposal, based on MDA, we start from secure business process

specifications and through transformations specified with QVT, we obtain use

cases and security use cases. Such artifacts complement the first stages of an

ordered and systematic software development process such as UP.

1 Introduction

Business processes are important for enterprises because they allow us to obtain an

advanced marketplace position, and then, these enterprises can optimize and assure

the quality of their products and services. Moreover, business processes allow

enterprises to describe, standardize, and adapt the way they react to certain types of

business events, and how they interact with suppliers, partners, competitors, and

customers [21]. At the same time, the new business scene, where there are many

participants and an intensive use of communications and information technologies,

implies that enterprises not only expand their businesses but also increase their

vulnerability. As a consequence, with the increase of the number of attacks on

systems, it is highly probable that sooner or later an intrusion can be successful [17].

This security violation causes losses. Therefore, it is necessary to protect computers

and their systems with a high security level in relation to the given limitations.

A way to face security problem is that of incorporating it early into the business

processes specifications. At this level, it is possible to capture security requirements

that take into account the point of view of business analysts.

Nowadays, models transformation is being paid attention by the community of

researchers and practitioners due to the fact that it is focused on solving the problems

Rodríguez A. and García-Rodríguez de Guzmán I. (2007).

Obtaining Use Cases and Security Use Cases from Secure Business Process through the MDA Approach.

In Proceedings of the 5th International Workshop on Security in Information Systems, pages 209-219

DOI: 10.5220/0002421502090219

 SciTePress

of time, cost and quality associated with software creation. The Object Management

Group (OMG) proposal for this approach is composed of: Model Driven Architecture

(MDA) [16]; a framework for software development that allows the creation of

models independent of the technological implementation, and

Query/View/Transformations (QVT) [18]; a standard for models transformation.

Our proposal is based on the MDA approach. To do so, we use a profile that

allows us to specify Secure Business Processes (SBP) corresponding to Computation

Independent Models (CIM). From these requirements and applying transformation

rules, we can obtain UML artifacts used to describe the problem in the context of

Platform Independent Models (PIM). Use cases (UC) and secure use cases are

obtained. Such artifacts let us complement the requirements capture defined in the

Unified Process (UP) [10].

The structure of the remainder of the paper is as follows: in Section 2, we will

present a background and related works. In Section 3, we will summarize the main

issues in security in business processes. In Section 4, we will present our proposal.

Finally, in Section 5, we will put forward an example and in Section 6 our

conclusions will be drawn.

2 Background and Related Works

In this section, we will briefly state the elements considered in our proposal and the

works related to for obtaining use cases from business processes models.

UP is a software development process composed of a set of activities necessary

for transforming user’s requirements into a software system. Additionally, it can be

understood as a methodology that provides us with generic recommendations that can

be instantiated by different projects classes where not only the project itself but also

the product with their different maturity levels and versions are included [15].

MDA is a framework for software development that allows the creation of models

independent of the technological implementation, and QVT [18], a standard language

for models transformation. In MDA approach the Computation Independent

viewpoint focuses on the environment of the system, the Platform Independent

viewpoint focuses on the operation of a system while hiding the details necessary for

a particular platform and the Platform Specific viewpoint combines the platform

independent viewpoint with an additional one focused on the details of the use of a

specific platform by a system [16]. In addition, QVT offers us the possibility of

manipulating models taking into consideration three factors: (i) queries that take a

model as an input and select specific elements from it according to a search pattern,

(ii) views corresponding to models that are derived from other models and finally,

(iii) transformations that take as a reference one or more input models to obtain an

output model or result.

In the works related to security and use cases (or misuse case) [2, 6, 11, 23], these

are used to capture security requirements but differently of our proposal, they are not

directly obtained from UML 2.0 Activity Diagrams (UML 2.0-AD) security

specifications.

In the works related to for obtaining use cases from business processes

specifications, we have found that in [22], it is suggested the possibility of obtaining

210

use cases from a business process specification made with Business Process Modeling

Notation (BPMN). In [12], it is proposed the automatic for obtaining UML artifacts

from a business process description that was made using BPMN. Authors extend

BPMN (Extension Level-1) to add information about the sequence and the input and

output flows. This allows them to apply rules from which use cases, state diagrams,

sequence and collaboration are achieved. In [24], it is stated a transformation

performed from a business process described with UML 2.0-AD to use cases and

finally. In [4], use cases are obtained from business process models that are not

represented by activity diagrams. The differences with our proposal are basically the

following: (i) even in works where there are automatic transformations, previous

manual intervention is required, ii) transformations are not described by using

languages specially designed with this purpose iii) the result of transformations does

not appear to be linked to a business process development finally, and iv) none of

them is related to security aspects.

3 Security in Business Process

A business process is the combination of a set of activities within an enterprise with a

structure describing their logical order and dependence whose objective is to produce

a desired result. A model is a simplified view of a complex reality. It is a means by

which to create abstraction, thus allowing one to eliminate irrelevant details and to

focus upon one or more important aspects at a time. Business process models enable a

common understanding and facilitate discussion among different stakeholders in a

business [1, 5].

Those works, which are related to the specification of security requirements in

business processes [3, 8, 9, 14, 20, 25], coincide in the idea that it is necessary to

capture the point of view of the business expert with regard to security, and to include

these specifications within the software development process.

However, at the moment is possible to capture at a high level security

requirements easily identifiable by those who models business processes, because: (i)

the business process representation has improved in UML 2.0 version, (ii) the security

requirement will tend to have the same basic kinds of valuable and potentially

vulnerable assets [7], and (iii) empirical studies show that it is common at the

business process level that customers and end users are able to express their security

needs [13]

Therefore, we have addressed the problem of including security in business

processes [19] by extending the UML 2.0-AD to allow the security requirements

specification. The proposed extension, called BPSec, basically considers the graphical

representation of security requirements taking from the taxonomy proposed in [7]. We

consider the following security requirement: Attack Harm Detection, Access Control,

Audit Register, Integrity, Privacy and Non Repudiation. We have used a padlock,

standard de facto, to graphical represent security requirements. The set of security

requirements, not exclusive, are described in

211

Table 1.

212

Table 1. Security Requirement definitions.

Access Control (AC): This corresponds to the limitation of access to resources by authorized users only. The specification o

this requirement by the business analyst implies the limitation of access to a set of resources that are considered important

enough to be protected in a special way. From the security perspective, this specification consists of the definition of roles

that may be assigned to individuals, entities, programs, devices or other systems and the definition of permission to access

objects included in the field of the access control specification. In addition, this requirement may have an audit register

specification

Attack Harm Detection (AD): This is defined as the detection, register and notification of an attempted attack or threat,

whether it is successful or not. From the business analyst perspective, this requirement represents an attention signal

covering the elements which are indicated. Furthermore, it can be interpreted as a previous step to an access control

specification. From the security point of view, this specification implies the maintenance of the events register (attacks o

threats) which have occurred to potentially vulnerable elements. This requirement can only be specified with an audit

Integrity (I): This is related to the protection of components from intentional and non-authorized corruption. The integrit

specification is valued as low, medium, and high. From the business analyst perspective, an integrity specification (at an

degree) is related to the importance of the information contained in the data store or data flow. The integrity

specification, from the perspective of the expert in security, implies the registration of the involved role and the date and

time of access to the data store or data

flow. Additionally, security measures are specified according to the degree o

integrity. This requirement is always associated with the audit register

Non Repudiation (NR): This establishes the need to avoid the denial of any aspect of the interaction (e.g. message,

transaction, transmission of data). From the business analyst perspective, Non Repudiation represents the need to protect a

determined interaction so that any potential problems (e.g. legal and liability) in relation to any interaction are minimized.

From the security perspective, this specification implies the generation of at least two security roles and alternatively the

audit register. This requirement may additionally have an audit register specification

Privacy (P): This is related to conditions of information protection concerning a determined individual or entity, thus limiting

access to sensitive information by non-authorized parties. From the point of view of the business analyst, the privacy

specification implies the non-revelation (confidentiality) and non-storage (anonymity) of the information regarding a

determined role. From the security viewpoint, the specification of privacy with confidentiality implies the protection of the

information of a role not to be revealed to third parties. In the case of privacy with anonymity, it implies that information

must not be stored either. This fact implies the creation of generic roles that expire along with the work session.

Additionally, this requirement may have a specification of audit register

Such security requirements are related to UML 2.0-AD elements according to the

restrictions presented in Table 2, indicating in each case if the security requirement

can (9) or cannot (―) be associated with each activity diagram element.

Table 2. Security Requirements and UML 2.0-AD Elements.

UML 2.0 element for containment in activity diagrams

Stereotypes for secure

activity specification

Action

Activity

Partition

DataStore

Node

Interruptible

ActivityRegion

ObjectFlow

(data)

AccessControl

9 9 9 9 9

AttackHarmDetection ―

9 9 9 9

Integrity ― ―

―

NonRepudiation ― ― ― ―

Privacy ―

―

It is important to mention that the security specifications performed with the

business processes model are very abstract. Nonetheless, as we move towards more

concrete models more detailed specifications will be performed. As a result of the

BPSec application, a Secure Business Process (SBP) is obtained.

4 Our proposal

A business process built by a business analyst apart from being useful in the specific

business field, it is very useful in a process of software construction. From it, we can

obtain system requirements, a stage taken into account by all modern development

processes. In our proposal, CIM to PIM transformations (C2P) are aimed for

obtaining useful artifacts in software development. The basic aspects of our proposal

are shown in Figure 1. The first column (on the left) show two types of models which

213

conform to the MDA. In the last column we can see the UP disciplines. The central

part shows our proposal and the artifacts which are derived from its application. The

business process specification is made by using UML 2.0-AD and BPSec. We applied

a set of transformation rules and checklists to obtain a subset of use cases and security

use cases that facilitate the understanding of the problem. SBP is used in a “Business

Modeling” and uses cases are used in “Requirement” and “Analysis & Design”

disciplines of UP.

Platform

Independent

Model

C2P - 1 C2P - 2

Analysis-

level Class

Use Case

Requirement

Analysis & Design

Model Driven

Architecture

Computation

Independent

Model

UML 2.0-

BPSec

Our Proposal

Secure

Business

Process

Model

Unified Process

(disciplines)

Business

Modeling

Fig. 1. An overview for our proposal.

Use cases are derived from UML 2.0-AD by applying a set of QVT rules (see

Table 3), refinement rules (see Table 4) and checklists (see Table 5).

The rules that do not consider security specifications (R1, R2 and R3), are

oriented to identify actors and related use cases. The rule R4 from a security

requirement (AC, AD, I, NR or P) the subject (or package) name is obtained and R5

from a security requirement use case actor (Actor) that will take the name “Security

Staff” it is obtained. In Table 3, all rules expressed in textual QVT are described.

Table 3. Mapping between Activity Diagrams and Use Case elements.

transformation ActivityDiagram2UseCaseDiagram

top relation R1 // from Activity Partition to Actor

{

checkonly domain uml_ActivityDiagram ap:ActivityPartition {name = n}

enforce domain uml_UseCaseDiagram a:Actor{name = n}

where {

ap.containedNode Æ forAll(cn:Action|R3(cn))

}

top relation R2 // from Interruptible Activity Region to Actor

{

checkonly domain uml_ActivityDiagram iar:InterruptibleActivityRegion {name = n}

enforce domain uml_UseCaseDiagram a:Actor {name = n}

where { ap.containedNode Æ forAll(cn:Action|R3(cn))

}

relation R3 // from Action to UseCase

{

checkonly domain uml_ActivityDiagram ac:Action {name = n, inPartition=ap}

enforce domain uml_UseCaseDiagram uc:UseCase {name = n, subject= ACTORS: Set(Actor)};

where { ACTORSÆincluding (a:Actor{name=ap.name})

}

transformation BPSec2UseCaseDiagram

top relation R4 // from Security Requirement to subject

{

checkonly domain bpsec_BPSec sr:SecurityRequirement {requirementtype = n}

enforce domain uml_UseCaseDiagram c:Clasifier {name=n}

}

top relation R5 // from Security Requirement to subject

{

checkonly domain bpsec_BPSec sr:SecurityRequirement

enforce domain uml_UseCaseDiagram a:Actor {name=”Security Staff”}

}

214

Refinement rules, described in Table 4, are focused on enriching the specifications

obtained in the previous section.

Table 4. Rules to refine use cases.

RR 1: Subject name (not related to security specification) is obtained from the business process name

RR 2: Subject name obtained from C2P_2-R4 must be complemented with the name of the UML 2.0-AD element

where security requirement has been specified

RR 3: Region Name is obtained by linking the Activity Partition names where Interruptible Activity Region is

contained

RR 4: Main Actor corresponds to the Activity Partition or region name where Initial Node is present

RR 5: Actor Generalization is obtained from top and middle Activity Partitions

RR 6: Redundant specifications must be eliminated

In Table 5, a checklist that allows us to complete use cases related to security

specifications is presented. For each security requirement a set of generic tasks that

must be applied over a specific SBP are exposed.

Table 5. Checklist for the obtention of security use cases.

Access Control

«Preconditions» Secure Role, and Permissions over the objects in the secure role scope

«Postconditions» Secure role validated to access to resources, Permissions over the validated objects, and Audit Register

(optional)

− Assign secure role to the partition, region or action

− Validate the secure role. This task is divided into: identify, authenticate and authorize the secure role

− Verify permissions over the objects in the role secure field. This implies a review of the permissions granted to the

objects that are within the field of access control specification

− If audit register has been specified, then the information related to the security role, the security permissions and the

objects in the access control specification field must be stored

AttackHarmDetection

«Preconditions» Secure Role

«Postconditions» Audit Register

− Assign secure role (origin and destination in the case of ObjectFlow).

− Register the type of element over which security requirements and date and time when an access to that element is

produced were specified

Integrity

«Preconditions» Secure Role

«Postconditions» Audit Register

− High-integrity specification implies: ask for permissions over data store, verify permissions, make security copies

(backups), and produce audit register

− Medium-integrity specification implies: send a warning message related to the data operation, make security copies, and

produce audit register

− Low-integrity specification implies produce audit register

NonRepudiation

«Preconditions» Secure Roles (origin and destination)

«Postconditions» Valid roles, and Audit Register (optional)

− Assign origin and destination roles

− Validate roles: This task is divided into: identify, authenticate and authorize the secure role

Privacy

«Preconditions» Secure Role

«Postconditions» Audit Register (optional)

− Assign a secure role (if anonymity was specified, then the role is generic and expires together with the session)

− Validate roles: This task is divided into: identify, authenticate and authorize the secure role

− Verify revelation permissions (anonymity and confidentiality)

− Verify storage permissions (only anonymity)

− Verify audit register specification

− If audit register has been specified, then the information related to the security role must be stored

5 Example

Our illustrative example (see Fig. 2) describes a typical business process for the

admission of patients in a health-care institution. In this case, the business analyst

identified the following Activity Partitions: Patient, Administration Area (which is a

215

top partition that is divided into Admission and Accounting middle partitions), and

the Medical Area (divided into Medical Evaluation and Exams).

The business analyst has considered several aspects of security. He/she has

specified «Nonrepudiation» has been defined over the control flow that goes from the

action “Fill Admission Request” to the actions “Capture Insurance Information” and

“Check Clinical Data” with the aim of avoiding the denial of the “Admission

Request” reception. «Privacy» (confidentiality) and «AccessControl» has been

defined over the Interruptible Activity Region. A «SecurityRole» can be derived from

this specification. Admission/Accounting will be a role. All objects in an interruptible

region must be considered for permissions specification. Access control specification

has been complemented with an audit requirement. The audit requirement implies that

it must register information about the role and permissions. Finally, the business

analyst has specified Integrity (high) requirement for Data Store “Clinical

Information”.

AD-001: Patient Admission

Patient Admission

Medical Evaluation

Exams

Medical Area Administration Area

Fill out Admission

Request

Check Clinical

Data

[non exist]

Accounting

Admission

Request

Create Empty

Clinical Data

Capture

Insurance

Information

Pre-Admission

Test

Evaluation Patient

Exams

Clinical Data

Make Exams

[exams]

Accounting

Information

Clinical

Information

Fill out Cost

Information

Fill out Patient

Information

Fill out

Clinical Data

Receive Medical

Evaluation

Medical

Evaluation

Complete

Accounting

Information

Complete

Clinical

Information

Store Data

Accounting Data

Fig. 2. Patients Admission in a Medical Institution.

In Table 6, the results of the application of the transformations defined with QVT

as well as the application of refinement rules are described.

Table 6. QVT and refinement rules applied to Patient Admission Business Process.

Rule Use case element

R1 Actors: Patient, Administration Area, Admission, Accounting, Medical Area, Medical Evaluation, and Exams

R2 Actor: Region 01

R3 Use cases: Fill out Admission Request, Receive Medical Evaluation, Capture Insurance Information, Check Clinical

Data, Create Empty Clinical Data, Fill out Cost Information, Store Data, Pre-Admission Test, Evaluation Patient

Exams, Fill out Clinical Data, Fill out Patient Information, Complete Accounting Information, Make Exams and

Complete Clinical information

R4 Subjects: Access Control and Privacy, Non Repudiation, and Integrity

R5 Actor: Security Staff

RR1 Subject: Patient Admission

RR2 Subjects: Access Control and Privacy in AdmissionAccounting, Non Repudiation in Admission Request, and Integrity

(high) in Clinical Information

RR3 Actor: AdmissionAccounting

RR4 Main Actor: Patient

RR5 Actors: Administration Area (Admission and Accounting) and Medical Area (Medical Evaluation and Exams)

RR6 Use Cases: Capture Insurance Information, Check Clinical Data and Create Empty Clinical Data in Admission

Partition and AdmissionAccounting Region. Fill out Cost Information and Store Data in Accounting Partition and

AdmissionAccounting Region

216

In Fig. 3, use cases derived from the business process specifications for the

admission of patients are graphically shown. On the right side, the use case related to

the security requirements “Access Control” and “Privacy” is shown. In this figure, we

have omitted the tasks related to the actor “AdmissionAccounting” because they have

already been included in the general use case (left side)

Patient

Main Actor

Fill out Admission

Request

Receive Medical

Evaluation

Patient Admission

Administration Area

Capture Insurance

Information

Check Clinical Data

Create Empty

Clinical Data

Fill out Cost

Information

Store

Data

Admission

Accounting

Pre-Admission

Test

Evaluation

Patient Exams

Fill out Clinical

Data

Fill out Patient

Information

Complete Accounting

Information

Make

Exams

Complete Clinical

Information

Medical Area

Medical Evaluation

Exams

AdmissionAccounting

Security

Staff

Identification

Enter

Role

Authentication

Role

Authorization

Check

Permission

Check for "Capture

Insurance Information"

Check for "Check

Clinical Data"

Check for "Create

Empty Clinic al Data"

Check for "Fill out

Cost Information"

Check for

"Accounting Data"

Check for

"Data Store"

Audit Register

<<Pre conditions>> Security Role, Permissions to the object in Role scope

<<Post-conditions>> Valid role, Valid Permissions

Access Control and Privacy

in Admission Accounting

Avoid disclosed

sensitive role

information

AdmissionAccounting

Role Alloc ate

Admission

Accounting

Role

Validation

Security Peri mission

event register

Security Role

event register

Role

Identification

<<include>>

Fig. 3. Patient Admission and Access Control/Privacy use cases specification.

In Fig. 4, use cases related to the security requirements “Integrity” and “Non

Repudiation” specified in the activity diagram are shown. In them, we have also

omitted the use cases related to the actors “Exams”, “Patient” and “Admission” since

they have been considered in the general use case (Fig. 3).

Exams

Integrity (high) in Cinical Information

Security

Staff

Identification

Enter

Check

Kind Protection

Check Special

Permission

<<include>>

<<extend>>

<<Pre conditions>> Security Role

<<Post conditions>> Audirt Register

Make security

backup

Audit Register

Make Tasks for

High Permission

<<include>>

Make Tasks for

Medium Permission

<<extend>>

Make Tasks for

Low Permission

<<include>>

Secure Role

Allocated

<<include>>

Patient

Receive "Admission

Request"

Admission

NonRepudiation in

Admission Request

Send "Admission

Request"

Security

Staff

Identification

Enter

Role

Authentication

Role

Authorization

Source Role

Allocate

Roles

Validation

Role

Identification

<<include>>

Receive Role

Allocate

Identification

Enter

<<Pre conditions>> Security Roles (Source and Receive)

<<Post conditions>> Valid Roles

Fig. 4. Integrity and Non Repudiation security use cases specification.

217

6 Conclusions and Ongoing Work

The improvement presented by the UML 2.0 language related to business process

specification allow us to consider such specifications as a source of requirements to

be used as an input in any software development process. In previous works, we have

proposed an extension to the UML 2.0 Activity Diagram through which it is possible

to specify security requirements at a high level of abstraction. In this paper, we have

presented a set of CIM to PIM transformations that let us obtain, from a business

process built by a business analyst, use cases, without and with security, that can be

used in a systematic and ordered software development process.

Ongoing work is oriented to enrich transformations to make it possible to obtain

more complete use case models. Together with it, our future work has the purpose of

instantiating UP with the objective of incorporating the artifacts that we have

generated. Finally, our future work has the aim of optimizing the prototype that we

have created to carry out the transformations necessary for improving specification

reuse and documentation.

Acknowledgements

This research is part of the following projects: DIMENSIONS (PBC-05-012-1), and

MISTICO (PBC06-0082) both partiality supported by FEDER and the “Consejería de

Ciencia y Tecnología de la Junta de Comunidades de Castilla-La Mancha”, Spain,

COMPETISOFT (506PI287), granted by CYTED, ENIGMAS (PIB-05-058), and

FAMOSO (2006: FIT-340000-2006-67).

References

1. Aguilar-Savén, R. S.; Business process modelling: Review and framework, International

Journal of Production Economics. Vol. 90 (2). (2004). pp.129-149.

2. Alexander, I. F.; Misuse Cases: Use Cases with Hostile Intent, IEEE Software. Vol. 20 (1).

(2003). pp.58-66.

3. Backes, M., Pfitzmann, B. and Waider, M.; Security in Business Process Engineering,

International Conference on Business Process Management (BPM). Vol. 2678, LNCS.

Eindhoven, Netherlands. (2003). pp.168-183.

4. Dijkman, R. M. and Joosten, S. M. M.; An Algorithm to Derive Use Cases from Business

Processes, 6th IASTED International Conference on Software Engineering and

Applications (SEA). Boston, MA, USA,. (2002). pp.679-684.

5. Eriksson, H.-E. and Penker, M., Business Modeling with UML, OMG Press. (2001).

6. Firesmith, D.; Security Use Case, Journal of Object Technology. Vol. 2 (3). (2003). pp.53-

64.

7. Firesmith, D.; Specifying Reusable Security Requirements, Journal of Object Technology.

Vol. 3 (1), January-February. (2004). pp.61-75.

8. Herrmann, G. and Pernul, G.; Viewing Business Process Security from Different

Perspectives, 11th International Bled Electronic Commerce Conference. Slovenia. (1998).

pp.89-103.

218

9. Herrmann, P. and Herrmann, G.; Security requirement analysis of business processes,

Electronic Commerce Research. Vol. 6 (3-4). (2006). pp.305-335.

10. Jacobson, I., Booch, G. and Rumbaugh, J., The Unified Software Development Process,

(1999). 463 p.

11. Jürjens, J.; Using UMLsec and goal trees for secure systems development, Proceedings of

the 2002 ACM Symposium on Applied Computing (SAC). Madrid, Spain. (2002). pp.1026-

1030.

12. Liew, P., Kontogiannis, P. and Tong, T.; A Framework for Business Model Driven

Development, 12 International Workshop on Software Technology and Engineering

Practice (STEP). (2004). pp.47-56.

13. Lopez, J., Montenegro, J. A., Vivas, J. L., Okamoto, E. and Dawson, E.; Specification and

design of advanced authentication and authorization services, Computer Standards &

Interfaces. Vol. 27 (5). (2005). pp.467-478.

14. Maña, A., Montenegro, J. A., Rudolph, C. and Vivas, J. L.; A business process-driven

approach to security engineering, 14th. International Workshop on Database and Expert

Systems Applications (DEXA). Prague, Czech Republic. (2003). pp.477-481.

15. Monfort, V. and Kadima, H.; Extending The Unified Process With Composition, Electronic

Notes in Theoretical Computer Science. Vol. 65 (4). (2002). pp.1-13.

16. Object Management Group; MDA Guide Version 1.0.1. In

http://www.omg.org/docs/omg/03-06-01.pdf. (2003).

17. Quirchmayr, G.; Survivability and Business Continuity Management, ACSW Frontiers

2004 Workshops. Dunedin, New Zealand. (2004). pp.3-6.

18. QVT, Meta Object Facility (MOF) 2.0 Query/View/Transformation Specification, OMG

Adopted Specification ptc/05-11-01, (2005). 204 p.

19. Rodríguez, A., Fernández-Medina, E. and Piattini, M.; Towards a UML 2.0 Extension for

the Modeling of Security Requirements in Business Processes, 3rd International Conference

on Trust, Privacy and Security in Digital Business (TrustBus). Vol. 4083. Krakow-Poland.

(2006). pp.51-61.

20. Röhm, A. W., Pernul, G. and Herrmann, G.; Modelling Secure and Fair Electronic

Commerce, 14th. Annual Computer Security Applications Conference. Scottsdale, Arizona.

(1998). pp.155-164.

21. Roser, S. and Bauer, B.; A Categorization of Collaborative Business Process Modeling

Techniques, 7th IEEE International Conference on E-Commerce Technology Workshops

(CEC 2005). Munchen, Germany. (2005). pp.43-54.

22. Rungworawut, W. and Senivongse, T.; A Guideline to Mapping Business Processes to

UML Class Diagrams, WSEAS Transactions on Computers. Vol. 4 (11). (2005). pp.1526-

1533.

23. Sindre, G. and Opdahl, A.; Capturing Security Requirements through Misuse Cases,

Proceedings of Norsk informatikkonferanse (NIK). Trondheim, Norway. (2001). pp.219-

230.

24. Štolfa, S. and Vondrák, I.; A Description of Business Process Modeling as a Tool for

Definition of Requirements Specification, Systems Integration 12th Annual International

Conference. Prague, Czech Republic. (2004). pp.463-469.

25. Vivas, J. L., Montenegro, J. A. and Lopez, J.; Towards a Business Process-Driven

Framework for security Engineering with the UML, Information Security: 6th International

Conference, ISC. Bristol, U.K. (2003). pp.381-395.

219
