THE SWS MEDIATOR WITH WEBML/WEBRATIO AND

JABC/JETI: A COMPARISON

Tiziana Margaria

∗

, Christian Winkler

∗

, Christian Kubczak

†

, Bernhard Steffen

†

∗

Institute for Informatics, University of Potsdam, 14482 Potsdam, Germany,

†

Department of Computer Science, University of Dortmund, 44227 Dortmund, Germany,

Marco Brambilla

‡

, Stefano Ceri

‡

, Dario Cerizza

, Emanuele Della Valle

, Federico M. Facca

‡

, Christina Tziviskou

‡

Dipartimento di Elettronica e Informazione, Politecnico di Milano, Milano, Italy

CEFRIEL, Milano, Italy

Keywords:

Semantic Web, Web services, jABC, WebML.

Abstract:

In this paper we compare the SWS Challenge Mediator solutions provided using the WebML/Webratio and

the jABC/jETI approaches.

1 INTRODUCTION

In this paper we compare two solutions to the medi-

ation scenario of the SWS challenge

that are based

on the use of WebML (Ceri et al., 2002) and of the

jABC (Steffen et al., 2006; jABC Website, 2007) as

modelling and execution platforms.

We compare only the solutions to the ﬁrst version

of the SWS Challenge scenario, since the jABC solu-

tion was discussed at the SWS review workshop only

for this ﬁrst Phase. Nevertheless, the technical com-

parison of the approaches is of general interest and

valid also for the second phase of the scenario.

Both groups adopt a model based approach, sup-

ported by model driven design tools and environ-

ments. This allows modelling the mediator in a graph-

ical high level modelling language and supports the

derivation of an executable mediator from these mod-

els. The solutions are thus similar in their spirit, and

we provide here a ﬁrst description and comparison of

the similarities and differences, at the modelling, lan-

guage, tool, and change management levels.

In the following, we brieﬂy describe the two con-

crete solutions (Sect. 2 and 3) from the point of view

of the used technologies, then we sketch a comparison

(Sect. 4), we present a reduction of the two solutions

to their mere, common essence (Sect. 5), and ﬁnally

we conclude in Sect. 6.

http://sws-challenge.org

2 WEBML

The speciﬁcation of a WebML application (Ceri et al.,

2002) consists of a set of models: the application data

model (an extended Entity-Relationship model), one

or more hypertext models (i.e., different site views

or different service views), expressing the navigation

paths and the page composition of the Web applica-

tion or the chain of operations needed to describe a

Web service; the presentation model, describing the

visual aspects of the pages for user views. WebML

covers also the development of B2B Web applica-

tions implementing business processes, thereby sup-

porting full-ﬂedged collaborative workﬂow-based ap-

plications, spanning multiple individuals, services,

and organizations. In such case the service view or

site view is partially generated by a BPMN model

representing the workﬂows involved in the applica-

tion. The core elements of a WebML diagram are

units. Each WebML unit has its own well deﬁned

semantic and its execution complies with its seman-

tic. The composition of different units leads to the

description of the semantic of hypertext or Web ser-

vices. WebML provides standard units for querying

data (e.g. Index unit, Selector unit), modifying

data (e.g. Modifying unit). The WebML conceptual

model has been also extended with a service model

that includes a set of Web service units (Manolescu

et al., 2005), corresponding to the WSDL classes of

422
