A POLICY-BASED PRIVACY

STORAGE APPROACH

Julien Nowalczyk and Frédérique Tastet-Cherel

Thales Communications, France

Keywords: Privacy, Security, Policies, Management, Database.

Abstract: Current information systems rely on complex databases, where information is provided and retrieved by

many actors interacting with many items during many operations. Data access and transfer must be

protected from external access as well as from any unauthorized internal access. We propose a light and

scalable mechanism to secure the storage of such a database. First, we define storage and access control

policies to record information. Then we specify a secured storage proxy that applies these policies. If

required, sensitive data are transferred and stored encrypted according to the previous decided security

policy.

1 INTRODUCTION

Companies databases gather an increasing amount of

sensitive data coming from multiple sources. All

these data can be finally stored in a back-end

database system held by a third party responsible for

preserving the privacy and the security of all these

aggregated data. Within current database systems,

the data owner usually delegates the privacy of its

data to the service provider.

Most of databases integrate more and more

complex security functions dealing with network

security as well as data security. Yet, all these

security mechanisms, such as authentication,

confidentiality, integrity or access control, only

relate to an organizational control over the

information, and not to a personal one.

The current approaches do not directly provide

privacy, i.e. freedom of choice, control and self-

determination. For example, data encryption

functions proposed by the most of databases allow to

make the data unintelligible of an external attacker

who successes to gain access to the database. But, a

database administrator (DBA) could gain a complete

access to these data by getting the encryption key,

often stored in the database. Another measure

aiming at ensuring data privacy is to maintain

historical traces of data and operations, but this can

only be considered as intrusion detection measure.

Finally, all the proposed mechanisms often remain

obsolete in comparison to the current privacy threat.

In the SMMART project (SMMART), a huge

amount of data are collected through sensors and

RFID networks, and finally gathered in a central

back-end database ready to be processed afterwards.

All these data belong to different companies and

require security mechanisms that guarantee their

own privacy levels. In SMMART, the service

provider not only proposes a storage service, but

especially a set of high-level services in order to

manage the logistics supply chain (SMMART).

In order to fulfil these security requirements, the

proposed policy-based privacy storage mechanism

must be enough configurable to allow user to define

its own data privacy policies, with no impact on the

overall system.

Moreover, data security is commonly based on

the definition of a secret in order to apply

cryptographic functions. The main issue consists in

managing this secret. In SMMART, we propose to

externalize this secret by delegating it to the data

owner who has a total control over its data privacy.

In this paper, we first review the existing in

database security and privacy by considering what

they could bring to the SMMART approach. Finally,

we describe our security mechanism proposal.

605

Nowalczyk J. and Tastet-Cherel F. (2007).

A POLICY-BASED PRIVACY STORAGE APPROACH.

In Proceedings of the Ninth International Conference on Enterprise Information Systems, pages 605-608

 SciTePress

2 DATABASE PRIVACY ISSUES

Database privacy is an issue of a significant interest.

Many works, particularly on privacy of data

transmission exist. This paper only focuses on

privacy of stored data.

Access control is a widespread and mandatory

security mechanism to prevent access to the database

from outsiders. (Oracle Database) presents a fine-

grained access control (FGAC) mechanism for

databases. FGAC allows to implement security

policies with functions and then to use those security

policies to implement row-level security on tables

and views. Although access control mechanisms

become more refined, they are not sufficient to

guarantee data privacy from an insider. Another

approach in database privacy is multi-level security

(Jajodia and Sandhu). Whereas access control

approach usually offers a per-table granularity, both

data and entities are assigned security levels in

multi-level approach. Multilevel security extends

access control, but it does not provide the necessary

control to the data owner over its data.

Thus, some paper opt for an individual centric

privacy approach. (Marchiori) proposes a solution

allowing corporations to define their own privacy

policies. The organization is here considered as

trustful. Therefore, considering as uncomfortable the

philosophy of trusting corporations to protect

privacy, (Aggarwal et al.) exports the privacy

policies from the organization to the data owner, and

seeks to enable the data owner to retain control over

its personal information even after its release to an

organization.

(Bawa et al.) adopts a completely different approach

by splitting the information over several providers.

A index allows to reconstruct the original

information. The problem comes down to provide

privacy-preserving search over distributed access

controlled content.

Other research papers introduce statistical databases

(Adam and Worthman). The main idea is to enable

queries on aggregate of information without

revealing individual records. This interesting

approach does not fit our requirement because we

need to minimize impact on existing database

system.

Finally, (Adam and Worthman) explores data

privacy issues in the “databases as service” (DAS)

paradigm. DAS systems provide its customers

seamless mechanisms to create, store, and access

their databases at the host site. Data privacy is

ensured by data storage in encrypted form. The main

challenge, on top of the key management, is the

execution of SQL queries by the service provider

over encrypted database without decrypting the data.

This innovative approach completely exports the

database query processor to the client side.

3 SMMART SECURE STORAGE

APPROACH

3.1 Overview

Providing a privacy policy-based storage mechanism

is a real challenge because of the complexity of

relational database and the major issue of executing

SQL queries over encrypted data. This section

presents the SMMART secure storage approach.

At the service level, two main entities are involved:

the service provider, i.e. the company that hosts the

SMMART system and all the associated services,

and the client, which consumes the service. At the

data level, the client uses several devices to collect

its data. Vehicles of client company embed RFID

and sensors networks in order to collect information,

and a data concentrator unit (DCU) to gather it.

Then, information is accessible either through the

mobile device or through the back-end database,

which synchronize with the DCU.

The figure 1 presents the overall SMMART system.

Figure 1: Simplified view of the SMMART system.

Finally, the goal of the privacy policy-based storage

mechanism lies in providing to the client the mean to

control its own data privacy. To address this issue

the client defines privacy policies to attribute a

privacy level to its data (section 2.2). According to

this privacy level, the client’s data are finally stored

in the service provider backend database. Moreover,

client manages its own encryption material, that

means database encryption is based on user-supplied

keys (section 2.3).

3.2 Policy-based Privacy

Policies allow the client to fully control its own data

privacy. Figure 2 gives a very simple example of

ICEIS 2007 - International Conference on Enterprise Information Systems

606

rely on the actor and the data type. The action

enables (or not) data privacy by encrypting (or not)

the data in the back-end database system.

Figure 2: Privacy policy example.

The privacy policy management module manages

the privacy policies (component architecture

presented in Figure 3). For each query, the query

management module consults and applies the

policies defined in the privacy policy management

module. Finally, the main role of policy based

system is finally to define the data encryption

granularity in the database.

3.3 Component Architecture

The challenge in designing such a component is to

allow the client, which manages all the security

material, to execute SQL queries over an encrypted

database. This is the role of the Query management

module (Figure 3).

Figure 3: Architecture overview.

We illustrate this process on a specific SMMART

table, which maintains information about DCU

management, defining by the following statement:

CREATE TABLE smmart_table

( dcu_id integer PRIMARY KEY

date data

location varchar(25)

release integer PRIVATE

);

The

PRIVATE attribute means the release column in

the

smmart_table intervenes in client privacy

policies. The elements of that column are encrypted

regarding to the privacy policy. One encryption key

is defined per column, and the Encryption

Management module maintains all these keys. That

means, the module knows all the column marked as

private, and all the associated cryptographic keys.

To insert an new record, the client executes the

following request:

INSERT INTO smmart_table_ VALUES (101,

2007/01/23, ‘tarnos-fr’, 46785123);

The SQL query is fully transparent for the client.

The Query management module receives this query

and interacts with the Privacy Policies Management

module in order to consult and apply the privacy

policies defined by the client. Then, it calls the

encryption module in order to encrypt the right

fields (the release field in the previous example)of

the SQL query. The query is finally sent to the

server, in the following way:

INSERT INTO smmart_table VALUES (101,

2007/01/23, ‘tarnos-fr’,ee2cbd4);

The back-end database stores the release number

encrypted. When the client needs to access the

previous release number, it issues the following

request:

SELECT release FROM smmart_table

WHERE dcu_id = 101;

The request is simply forwarded to the back-end

database. When receiving the response, the client

needs to decrypt the release number, which is stored

encrypted in the database, with the encryption key of

the release column. For that, the Query Management

module asks the Encryption Management module to

decrypt the release field. All the process is also

transparent to the final user.

Finally, encryption process needs an entity that

provides the cryptographic keys. We propose to

fully delegated the key management to the client.

The key distribution is centralized in order to allow

group encryption. Thus, Alice and Bob can work on

the same column with the same encryption keys,

which are given by the key distribution module.

Moreover the key distribution can rely on a

certificate-based infrastructure to authenticate user

during the distribution.

A POLICY-BASED PRIVACY STORAGE APPROACH

607

4 CONCLUSION

This paper presents an approach to ensure data

privacy within the scope of SMMART, but many

challenges still remains. This first one is the

encryption cost. A trade-off needs to be made

between encryption techniques (software/hardware

encryption) and data granularity for encryption. The

introduction of privacy policies allows to set and

optimize this data granularity.

The second challenge is the execution of SQL

query over encrypted data and the impact of it on the

storage model. In SMMART, we try to keep the

original service provider data model, by restricting

SQL queries to basic selection queries. But the

execution of more complex queries (with the join,

grouping ,aggregation or sorting operators) raises a

lot of new issues, and may imply afterwards the

definition of new storage model.

Then, key management plays an important role

by enabling the encryption process. The exportation

of the key management to the client side increases

the data privacy level.

Finally, this paper insists on the necessity for the

user to keep control over its personal information in

order to enable data privacy. Database

infrastructures need to be improved to allow the

definition of such security architectures.

REFERENCES

SMMART project website.

http://smmart.iao.fraunhofer.de/plone

Oracle Database 10g Family Product

www.oracle.com/technology/products/database/oracle

10g/pdf/twp_general_10gdb_product_family .pdf

S. Jajodia and R. Sandhu, Toward a multilevel secure

relational data model.

M. Marchiori (Ed.), The Platform for Privacy Preferences

1.0 (P3P1.0) Specification.

G. Aggarwal, M. Bawa, H. Garcia-Molina, K. Kenthapadi,

N. Mishra, R. Motwani, U. Srivastava, D. Thomas, J.

Widom, Y. Xu, Vision Paper: Enabling Privacy for the

Paranoids.

M. Bawa, R. J. Bayardo Jr.,R. Agrawal, Privacy-

Preserving Indexing of Documents on the Network.

N. R. Adam and J. C. Worthman, Security-Control

Methods for Statistical Databases: A Comparative

Study

H. Hacýgümüs, B. Iyer, S. Mehrotra, Providing Database

as a Service.

ICEIS 2007 - International Conference on Enterprise Information Systems

608
