MEDICAL IMAGE UNDERSTANDING THROUGH THE

INTEGRATION OF CROSS-MODAL OBJECT RECOGNITION

WITH FORMAL DOMAIN KNOWLEDGE

Manuel Möller, Michael Sintek, Paul Buitelaar

German Research Center for Artiﬁcial Intelligence, Trippstadter Str. 122, 67663 Kaiserslautern, Germany

Saikat Mukherjee

Siemens Corporate Research, 755 College Road East, Princeton, USA

Xiang Sean Zhou

Siemens Medical Solutions, 51 Valley Stream Parkway, Malvern PA, USA

Jörg Freund

Siemens Medical Solutions, Hartmannstr. 16, 91052 Erlangen, Germany

Keywords:

Semantic Web, Ontologies, NLP, Medical Imaging, Image Retrieval.

Abstract:

Rapid advances in medical imaging scanner technology have increased dramatically in the last decade the

amount of medical image data generated every day. By contrast, the software technology that would allow

the efﬁcient exploitation of the highly informational content of medical images has evolved much slower.

Despite the research outcomes in image understanding and semantic modeling, current image databases are

still indexed by keywords assigned by humans and not by the image content. The reason for this slow progress

is the lack of scalable and generic information representations capable of overcoming the high-dimensional

nature of image data. Indeed, most of the current content-based image search applications are focused on the

indexing of certain image features that do not generalize well and use inﬂexible queries. We propose a system

combining medical imaging information with semantic background knowledge from formalized ontologies,

that provides a basis for building universal knowledge repositories, giving clinicians a fully cross-lingual and

cross-modal access to biomedical information of all forms.

1 INTRODUCTION

Rapid advances in imaging technology have dramat-

ically increased the amount of medical image data

generated daily by hospitals, pharmaceutical compa-

nies, and academic medical research

. Technologies

such as 4D 64-slice CT, whole-body MR, 4D Ul-

trasound, and PET/CT can provide incredible detail

and a wealth of information with respect to the hu-

man body anatomy, function and disease associations.

This increase in the volume of data has brought about

signiﬁcant advances in techniques for analyzing such

For example, University Hospital of Erlangen, Ger-

many, has a total of about 50 TB of medical images. Cur-

rently they have approx. 150.000 medical examinations pro-

ducing 13 TB per year.

data. The precision and sophistication of different im-

age understanding techniques, such as object recogni-

tion and image segmentation, have also improved to

cope with the increasing complexity of the data.

However, these improvements in analysis have not

resulted in more ﬂexible or generic image understand-

ing techniques. Instead, the analysis techniques are

very object speciﬁc and not generic enough to be ap-

plied across different applications. Throughout this

paper we will address this fact as “lack of scalabil-

ity”. Consequently, current image search techniques,

whether for Web sources or for medical PACS (Pic-

ture Archiving and Communications System), are still

dependent on the subjective association of keywords

to images for retrieval.

One of the important reasons behind this lack

134

oller M., Sintek M., Buitelaar P., Mukherjee S., Sean Zhou X. and Freund J. (2008).

MEDICAL IMAGE UNDERSTANDING THROUGH THE INTEGRATION OF CROSS-MODAL OBJECT RECOGNITION WITH FORMAL DOMAIN

KNOWLEDGE.

In Proceedings of the First International Conference on Health Informatics, pages 134-141

 SciTePress

of scalability in image understanding techniques has

been the absence of generic information represen-

tation structures capable of overcoming the feature-

space complexity of image data. Indeed, most current

content-based image search applications are focused

on indexing syntactic image features that do not gen-

eralize well across domains. As a result, current im-

age search technology does not operate at the seman-

tic level and, hence, is not scalable.

We propose to use hierarchical information rep-

resentation structures, which integrate state-of-the-art

object recognition algorithms with generic domain se-

mantics, for a more scalable approach to image under-

standing. Such a system will be able to provide direct

and seamless access to the informational content of

image databases.

Our approach is based on the following main tech-

niques:

• Integrate the state-of-the-art in semantics and im-

age understanding to build a sound bridge be-

tween the symbolic and the subsymbolic world.

This cross-layer research approach deﬁnes our

road-map to quasi-generic image search.

• Integrate higher level knowledge represented by

formal ontologies that will help explain different

semantic views on the same medical image: struc-

ture, function, and disease. These different se-

mantic views will be coupled to a backbone on-

tology of the human body.

• Exploit the intrinsic constraints of the medical

imaging domain to deﬁne a rich set of queries for

concepts in the human body ontology. The ontol-

ogy not only provides a natural abstraction over

these queries but also statistical image algorithms

could be associated to semantic concepts for an-

swering these queries.

Our focus is on ﬁlling the gap between what is cur-

rent practice in image search (i. e., indexing by key-

words) and the needs of modern health provision and

research. The overall goal is to empower the medical

imaging content-stakeholders (clinicians, pharmaceu-

tical specialists, patients, citizens, and policy makers)

by providing ﬂexible and scalable semantic access to

medical image databases. Our short term goal is to de-

velop a basic image search engine and prove its func-

tionality in various medical applications.

In 2001 Berners-Lee and others published a vi-

sionary article on the Semantic Web (Berners-Lee

et al., 2001). The use-case they described was about

the use of meta-knowledge by computers. For our

goals we propose to build a system on existing Se-

mantic Web technologies like RDF (Brickley and

Guha, 2004) and OWL (McGuinness and van Harme-

len, 2004) which were developed to lay the founda-

tions of Berners-Lee’s vision. From this point of view

it is also a Semantic Web project.

Therefore we propose a system that combines

medical imaging information with semantic back-

ground knowledge from formalized ontologies and

provides a basis for building universal knowledge

repositories, giving clinicians cross-modal (indepen-

dent from different modalities like PET, CT, ultra-

sound) as well as cross-lingual (independent of par-

ticular languages like English and German) access to

various forms of biomedical information.

2 GENERAL IDEA

There are numerous advanced object recognition al-

gorithms for the detection of particular objects on

medical images: (Hong et al., 2006) at anatomical

level, (Tu et al., 2006) at disease level and (Comani-

ciu et al., 2004) at functional level. Their speciﬁcity is

also their limitation: Existing object recognition algo-

rithms are not at all generic. Given an arbitrary image

it still needs human intelligence to select the right ob-

ject recognizers to apply to an image. Aiming to gain

a pseudo-general object recognition one can try to ap-

ply the whole spectrum of available object recognition

algorithms. But it turns out that in generic scenar-

ios even with state-of-the-art object recognition tools

the accuracy is below 50 percent (Chan et al., 2006;

Müller et al., 2006).

In automatic image understanding there is a se-

mantic gap between low-level image features and

techniques for complex pattern recognition. Existing

work aims to bridge this gap by ad-hoc and applica-

tion speciﬁc knowledge. In contrast our objective is to

create a formal fusion of semantic knowledge and im-

age understanding to bridge this gap to support more

ﬂexible and scalable queries.

For instance, human anatomical knowledge tells

us that it is almost impossible to ﬁnd a heart valve next

to a knee joint. Only in cases of very severe injuries

these two objects might be found next to each other.

But in most cases the anatomical intuition is correct

and, hence, the background knowledge precludes the

recognition of certain anatomical parts given the pres-

ence of other parts. It is in this use of formalized

knowledge that ontologies

come into play within our

framework.

In the context of medical imaging it is necessary to

deﬁne image semantics for parts of human anatomy.

According to Gruber (Gruber, 1995), an ontology is a

speciﬁcation of a (shared) conceptualization.

MEDICAL IMAGE UNDERSTANDING THROUGH THE INTEGRATION OF CROSS-MODAL OBJECT

RECOGNITION WITH FORMAL DOMAIN KNOWLEDGE

135

In this domain the expert’s knowledge is already for-

malized in comprehensive ontologies like the Founda-

tional Model of Anatomy (Rosse and Mejino, 2003)

for human anatomy or the International Statistical

Classiﬁcation of Diseases and Related Health Prob-

lems (ICD-10)

of World Health Organization for a

classiﬁcation of human diseases. These ontologies

represent a rich medical knowledge in a standardized

and machine interpretable format.

In contrast to current work which deﬁnes ad-hoc

semantics, we take the novel view that within a con-

strained domain the semantics of a concept is deﬁned

by the queries associated with it. We will investigate

which types of queries are asked by medical experts

to ensure that the necessary concepts are integrated

into the knowledge base. We believe that in IR ap-

plications this view will allow a number of advances

which will be described in the following sections.

We chose the medical domain as our area of appli-

cation. Unlike common language and many other sci-

entiﬁc areas the medical domain has clear deﬁnitions

for its technical terms. Ambiguities are rare which

eases the task of ﬁnding a semantic abstraction for

a particular text or image. However, our framework

is generic and can be applied to other domains with

well-deﬁned semantics.

3 ASPECTS OF USING

ONTOLOGIES

Ontologies (usually) deﬁne the semantics for a set of

objects in the world using a set of classes, each of

which may be identiﬁed by a particular symbol (ei-

ther linguistic, as image, or otherwise). In this way,

ontologies cover all three sides of the "semiotic tri-

angle" that includes object, referent, and sign (see

Fig. 1). I. e., an object in the world is deﬁned by

its referent and represented by a symbol (Ogden and

Richards, 1923—based on Peirce, de Saussure and

others). Currently, ontology development and the Se-

Object

Sign

experience

perception convention

Referent

Figure 1: Semiotic Triangle.

mantic Web effort in general have been mostly di-

http://www.who.int/classiﬁcations/icd/en/

rected at the referent side of the triangle, and much

less at the symbol side. To allow for automatic mul-

tilingual and multimedia knowledge markup a richer

representation is needed of the linguistic and image-

based symbols for the object classes that are deﬁned

by the ontology (Buitelaar et al., 2006).

From our point of view a semantic representation

should not be encapsulated into a single module. In-

stead we think that a layered approach as shown in

Fig. 2 has a number of advantages.

Text

Other

Media

...

content

features

Images

associations

ontology

English

Text

German

feature

Figure 2: Interacting Layers in Feature Extraction and Rep-

resentation.

Once there is a representation established at the

semantic level there are a number of beneﬁts com-

pared to conventional IR systems. For a more detailed

description of the abstraction process see Sect. 4.

Cross-Modal Image Retrieval. Current systems

for medical IR depend on the modality of the stored

images. But in medical diagnosis very different imag-

ing techniques are used such as PET, CT, ultrasonog-

raphy, or time series data from 4D CT etc. Each tech-

nique produces images with characteristic appear-

ance. For tumor detection, for example, often PET

(to identify the tumor) and CT (to have a view on the

anatomy) are combined, to formulate a precise diag-

nosis with a proper localization of the tumor. The

proposed system will allow to answer queries based

on semantic similarity and not only visual similarity.

Full Modality Independence. Cross-Modality

even can be driven another step forward by inte-

grating documents of any format into one single

database. We plan to also include text documents

like medical reports and diagnoses. On the level

of semantic representation they will be treated like

the images. Accordingly, the system will be able to

answer queries not only with images but also with

HEALTHINF 2008 - International Conference on Health Informatics

136

text documents including similar concepts as in the

retrieved images.

Improved Relevance of Results. Current search

engines retrieve documents which contain the key-

word from the query. The documents in the result set

are ranked by various techniques using information

such as their inter-connectivity, statistical language

models, or the like. For huge datasets search by key-

word often returns very large result sets. Ranking by

relevance is hard.

This holds for low-level image retrieval as well.

Here only two similarity measures are applicable:

through visual similarity which can be completely in-

dependent from the object and context and via a com-

parison between keywords and image annotations.

With current IR systems the user is forced to use pure

keyword-based search as a detour while in fact he or

she is searching for documents and/or images includ-

ing certain concepts.

Our notion of keyword-based querying goes be-

yond current search engines by mapping keywords

from the query to ontological concepts. Our system

provides the user with a semantic representation. That

allows the user to ask for a concept or a set of con-

cepts with particular relationships. This allows far

more precise queries than a simple keyword-based re-

trieval mechanism and likewise better matching be-

tween query and result set.

Inferencing of Hidden Knowledge. By mapping

the keywords from a text-based query to ontological

concepts and the use of semantics the system is able to

infer

implicit results. This allows us to retrieve im-

ages which are not annotated explicitly with the query

concepts but with concepts related to them through

the ontology.

To represent the complex knowledge of the med-

ical domain and allow a maximum of ﬂexibility in

the queries we will have to enrich the ontology by

rules and allow to use rules in the queries. Another

point will be an integration of spatial representation

of anatomical relations as well as an efﬁcient imple-

mentation of spatial reasoning.

4 LEVELS OF SEMANTIC

ABSTRACTION

Our notion of semantic imaging is to ground the se-

mantics of a human anatomical concept on a set of

We aim at using standard OWL reasoners like Racer,

FaCT++ or Pellet.

queries associated with it. The constrained domain of

a human body enables us to have a rich coverage of

these queries and, consequently, deﬁne image seman-

tics at various levels of the hierarchy of the human

anatomy.

Fig. 3 gives an overview of the different abstrac-

tion levels in the intended system. For the proposed

system we want to take a step beyond the simple di-

chotomy between a symbolic and subsymbolic rep-

resentation of images. Instead, from our perspective

there is a spectrum ranging from regarding the images

as simple bit vectors over color histograms, shapes

and objects to a fully semantic description of what is

depicted. The most formal and generic level of repre-

sentation is in form of an ontology (formal ontologi-

cal modeling). The ontology holds information about

the general structure of things. Concrete entities are

to be represented as semantic instances according to

the schema formalized in the ontology.

To emphasize the difference to the dichotomic

view, we call the lower end of this spectrum infor-

mal and the upper end formal representation. From

our perspective the abstraction has to be modeled as a

multi-step process across several sublevels of abstrac-

tion. This makes it easier to close the gap between the

symbolic and subsymbolic levels from the classic per-

spective. Depending on the similarity measure that is

to be applied for a concrete task different levels of the

abstraction process will be accessed.

If a medical expert searches for images that are

looking similar to the one he or she recently got from

an examination, the system will use low-level features

like histograms or the bit vector representation. In

another case the expert might search for information

about a particular syndrome. In that case the system

will use features from higher abstraction levels like

the semantic description of images and texts in the

database to be able to return results from completely

different modalities.

We believe that text documents have to be under-

stood in a similar way. Per se, a text document is

just a string of characters. This is similar to regard-

ing an image as a sheer bit vector. Starting from the

string of characters, in a ﬁrst step relatively simple

methods can be used to identify terms. In further

steps technologies from concept based Cross Lan-

guage Information Retrieval (CLIR)

are applied to

map terms in the documents to concepts in the on-

tology (Volk et al., 2003; Vintar et al., 2003; Car-

bonell et al., 1997; Eichmann et al., 1998). CLIR

currently can be divided into three different methods:

approaches based on bilingual dictionary lookup or

The research project MUCHMORE

(http://muchmore.dfki.de/) was focused on this aspect.

MEDICAL IMAGE UNDERSTANDING THROUGH THE INTEGRATION OF CROSS-MODAL OBJECT

RECOGNITION WITH FORMAL DOMAIN KNOWLEDGE

137

query either through sample images, or pose struc-

tured queries using conceptual descriptors, or use nat-

ural language to describe queries. In the following,

we explain each of these different methods.

Query by Sample Image. Basically there are two

different approaches to image based queries. The ﬁrst

approach retrieves images from the database which

are looking similar. Only low-level image features are

used to select results for this type of query. The abil-

ity to match the image of a current patient to similar

images from a database of former medical cases can

be of great help in assisting the medical professional

in his diagnosis (see Sect 4) we believe that image

understanding has to be an abstraction over several

levels. To answer queries by sample image we will

make use of the more informal features extracted from

the images. The support for these queries is based on

state-of-the-art similarity-based image retrieval tech-

niques (Deselaers et al., 2005).

Today there are various image modalities in mod-

ern medicine. Many diseases like cancer require to

look at images from different modalities to formulate

a reliable diagnosis (see example in Sect. 3). The

second approach therefore takes the image from the

query and extracts the semantics of what can be seen

on the image. Through mapping the concrete image

to concepts in the ontology, an abstract representation

is generated. This representation can be used for a

matching on the level of image semantics with other

images in the database. Applying this method makes

it possible to use a CT image of the brain to search for

images from all available modalities in the database

(see Fig. 4–6).

Query by Conceptual Descriptions. Similar to

the use of SQL for querying structured relational

databases, special purpose languages are also required

for querying semantic metadata. Relying on well-

established standards we propose using a language on

top of RDF, such as SPARQL, for supporting generic

structured semantic queries.

Query by Natural Language. From the point of

the medical expert having a natural language interface

is very important. Through a textual interface the user

directly enters keywords which are mapped to ontol-

ogy concepts. Current systems like the IRMA-Project

(see Sect. 6) only allow to search for keywords which

are extracted ofﬂine and stored as annotations. Since

our system has to compose a semantic representation

of each query, the ontological background knowledge

can be used in an iterative process of query reﬁne-

ment. Additionally, it will be possible to use complete

text documents as queries.

In cases where the system cannot generate a se-

mantic representation—due to missing knowledge

about a knew syndrome, therapy, drug or the like—

it will fall back to a normal full text search. If the

same keyword is used frequently this can be used as

evidence that the foundational ontology has to be ex-

tended to cover the corresponding concept(s).

6 RELATED WORK

Most current work in content based image retrieval

models object recognition as a probabilistic inferenc-

ing problem and use various mathematical methods

to cope with the problems of image understanding.

These techniques use image features which are tied to

particular applications and, hence, suffer from a lack

of scalability.

Among extant work in fusing semantics with im-

age understanding, (Hunter, 2001) describes a tech-

nique for modeling the MPEG-7 standard, which is

a set of structured schemas for describing multime-

dia content, as an ontology in RDFS. There has been

some research (Barnard et al., 2003; Lavrenko et al.,

2003; Lim, 1999; Carneiro and Vasconcelos, 2005;

Town, 2006; Mezaris et al., 2003; Mojsilovic et al.,

2004) on semantic imaging relying primarily on as-

sociating word distributions to image features. How-

ever, these works used hierarchies of words for se-

mantic interpretation and did not attempt to model im-

age features themselves in levels of abstraction. Fur-

thermore, the lack of formal modeling made these

techniques susceptible to subjective interpretations of

the word hierarchies and, hence, were not truly scal-

able. Especially in the context of medical imaging,

our notion of semantics is tied to information gath-

ered from physics, biology, anatomy, etc. This is in

contrast to perception-based subjective semantics in

these works.

The goal of the project “Image Retrieval in Med-

ical Applications” (IRMA) (Lehmann et al., 2003)

was an automated classiﬁcation of radiographs based

on global features with respect to imaging modality,

direction, body region examined and the biological

system under investigation. The aim was to identify

image features that are relevant for medical diagno-

sis. These features were derived from a database of

10.000 a-priori classiﬁed and registered images. By

means of prototypes in each category, identiﬁcation

of objects and their geometrical or temporal relation-

ships are handled in the object and the knowledge

layer, respectively. Compared to the system proposed

MEDICAL IMAGE UNDERSTANDING THROUGH THE INTEGRATION OF CROSS-MODAL OBJECT

RECOGNITION WITH FORMAL DOMAIN KNOWLEDGE

139

Buitelaar, P., Sintek, M., and Kiesel, M. (2006). A lexicon

model for multilingual/multimedia ontologies. Pro-

ceedings of the 3rd European Semantic Web Confer-

ence (ESWC06).

Carbonell, J. G., Yang, Y., Frederking, R. E., Brown, R. D.,

Geng, Y., and Lee, D. (1997). Translingual informa-

tion retrieval: A comparative evaluation. International

Journal of Computational Intelligence and Applica-

tions, 1:708–715.

Carneiro, G. and Vasconcelos, N. (2005). A database cen-

tric view of semantic image annotation and retrieval.

SIGIR ’05: Proceedings of the 28th annual interna-

tional ACM SIGIR conference on Research and devel-

opment in information retrieval, pages 559–566.

Chan, A. B., Moreno, P. J., and Vasconcelos, N. (2006). Us-

ing statistics to search and annotate pictures: an eval-

uation of semantic image annotation and retrieval on

large databases. Proceedings of Joint Statistical Meet-

ings (JSM).

Comaniciu, D., Zhou, X., and Krishnan, S. (2004). Robust

real-time myocardial border tracking for echocardio-

graphy: an information fusion approach. IEEE Trans-

actions in Medical Imaging, 23 (7):849–860.

Deselaers, T., Weyand, T., Keysers, D., Macherey, W., and

Ney, H. (2005). FIRE in ImageCLEF 2005: Combin-

ing content-based image retrieval with textual infor-

mation retrieval. Working Notes of the CLEF Work-

shop.

Eichmann, D., Ruiz, M. E., and Srinivasan, P. (1998).

Cross-language information retrieval with the UMLS

metathesaurus. Proceedings of the 21st annual inter-

national ACM SIGIR conference on Research and de-

velopment in information retrieval, pages 72–80.

Gruber, T. R. (1995). Toward principles for the design

of ontologies used for knowledge sharing. In Inter-

national Journal of Human-Computer Studies, vol-

ume 43, pages 907–928.

Hong, W., Georgescu, B., Zhou, X. S., Krishnan, S., Ma,

Y., and Comaniciu, D. (2006). Database-guided si-

multaneous multi-slice 3D segmentation for volumet-

ric data. In Leonardis, A., Bischof, H., and Prinz, A.,

editors, Journal of the European Conference on Com-

puter Vision (ECCV 2006), volume 3954, pages 397–

409. Springer-Verlag.

Hunter, J. (2001). Adding multimedia to the semantic web -

building an MPEG-7 ontology. International Seman-

tic Web Working Symposium (SWWS).

Laender, A., Ribeiro-Neto, B., Silva, A., and Teixeira, J.

(2002). A brief survey of web data extraction tools. In

Special Interest Group on Management of Data (SIG-

MOD) Record, volume 31 (2).

Lavrenko, V., Manmatha, R., and Jeon, J. (2003). A model

for learning the semantics of pictures. Proceedings

of the Neural Information Processing Systems Con-

ference.

Lehmann, T., Güld, M., Thies, C., Fischer, B., Spitzer, K.,

Keysers, D., Ney, H., Kohnen, M., Schubert, H., and

Wein, B. (2003). The IRMA project. A state of the

art report on content-based image retrieval in medical

applications. Proceedings 7th Korea-Germany Joint

Workshop on Advanced Medical Image Processing,

pages 161–171.

Lim, J.-H. (1999). Learnable visual keywords for image

classiﬁcation. In DL ’99: Proceedings of the fourth

ACM conference on Digital libraries, pages 139–145,

New York, NY, USA. ACM Press.

Ling, C., Gao, J., Zhang, H., Qian, W., and Zhang, H.

(2002). Improving encarta search engine performance

by mining user logs. International Journal of Pattern

Recognition and Artiﬁcial Intelligence, 16 (8).

McGuinness, D. L. and van Harmelen, F. (2004). OWL web

ontology language overview.

Mechouche, A., Golbreich, C., and Gibaud, B. (2007). To-

wards an hybrid system using an ontology enriched

by rules for the semantic annotation of brain MRI im-

ages. In Marchiori, M., Pan, J., and de Sainte Marie,

C., editors, Lecture Notes in Computer Science, vol-

ume 4524, pages 219–228.

Mezaris, V., Kompatsiaris, I., and Strintzis, M. (2003). An

ontology approach to object-based image retrieval. In-

ternational Conference on Image Processing (ICIP).

Müller, H., Deselaers, T., Lehmann, T., Clough, P., Kim,

E., and Hersh, W. (2006). Overview of the Im-

ageCLEFmed 2006 medical retrieval and annotation

tasks. In Accessing Multilingual Information Repos-

itories, volume 4022 of Lecture Notes in Computer

Science. Springer-Verlag.

Mojsilovic, A., Gomes, J., and Rogowitz, B. (2004).

Semantic-friendly indexing and querying of images

based on the extraction of the objective semantic cues.

International Journal of Computer Vision, 56:79–107.

Ravichandran, D. and Hovy, E. (2002). Learning surface

text for a question answering system. Proceedings of

the Association of Computational Linguistics Confer-

ence (ACL).

Rosse, C. and Mejino, R. L. V. (2003). A reference ontol-

ogy for bioinformatics: The Foundational Model of

Anatomy. In Journal of Biomedical Informatics, vol-

ume 36, pages 478–500.

Town, C. (2006). Ontological inference for image and video

analysis. International Journal of Machine Vision and

Applications, 17(2):94–115.

Tu, Z., Zhou, X. S., Bogoni, L., Barbu, A., and Comaniciu,

D. (2006). Probabilistic 3D polyp detection in CT im-

ages: The role of sample alignment. IEEE Computer

Society Conference on Computer Vision and Pattern

Recognition, 2:1544–1551.

Vintar, S., Buitelaar, P., and Volk, M. (2003). Semantic rela-

tions in concept-based cross-language medical infor-

mation retrieval. In Proceedings of the ECML/PKDD

Workshop on Adaptive Text Extraction and Mining

(ATEM).

Volk, M., Ripplinger, B., Vintar, S., Buitelaar, P., Raileanu,

D., and Sacaleanu, B. (2003). Semantic annotation for

concept-based cross-language medical information re-

trieval. International Journal of Medical Informatics.

MEDICAL IMAGE UNDERSTANDING THROUGH THE INTEGRATION OF CROSS-MODAL OBJECT

RECOGNITION WITH FORMAL DOMAIN KNOWLEDGE

141
