PROTECTING PRIVACY IN MEDICAL DATABASES

Efﬁcient Local Generation of System-Wide Unique Health IDs

Peter Schartner and Martin Schaffer

Institute of Applied Informatics, System Security Group

Klagenfurt University, 9020 Klagenfurt, Austria

Keywords:

Privacy protection, anonymity, linkability, pseudonyms, nyms, medical registers, medical databases.

Abstract:

In this paper we will introduce a replacement for linkable unique health identiﬁers: locally generated system-

wide unique digital pseudonyms. The presented techniques are based on a novel technique called collision

free number generation which is discussed in the introductory part of the article. After this brief introduc-

tion, we will pay attention onto two speciﬁc variants of collision-free number generation: one based on the

RSA-Problem and one based on the Elliptic Curve Discrete Logarithm Problem. The main part of the arti-

cle focuses on two applications of unique digital pseudonyms: centralized medical records and anonymous

medical databases.

1 INTRODUCTION

In this paper we will present an application of dig-

ital pseudonyms in the scope of unique health iden-

tiﬁers (health IDs) and digital medical records. So

far, unique health IDs are issued by some sort of cen-

tralized agency, in order to guarantee the system-wide

uniqueness of the employed identiﬁers. This enables

linking between the Health ID (and indirectly the pa-

tient’s name) and the medical record. Hence, there

are severe privacy concerns which are documented by

the presence of “Health IDs & Privacy” in the me-

dia (Institute for Health Freedom, 2000; CNN, 2000)

or even special web-sites which are protesting against

such identiﬁers (Medical Privacy Coalition, 2007).

It is obvious that in some scenarios (e.g. electronic

prescription) there must be a link between the health

ID and the individual’s name, but there are several

scenarios, where such a link is not necessaryor is even

not wanted. Consider centralized medical records or

anonymized databases for certain diseases (e.g. can-

cer registers). In these scenarios, the only requirement

is that all data concerning a speciﬁc person is added to

the right medical record. So, the real identity (i.e. the

unique Health Identiﬁer) can be replaced by a digital

pseudonym, which has again to be unique (Pﬁtzmann

and K¨ohntopp, 2001).

A critical problem is, how one can efﬁciently generate

provably unique pseudonyms. The straightforward

solution is to issue these pseudonyms by a centralized

instance, which we have to trust completely. This,

however, is an unrealistic assumption since there is

no single instance whom one can trust. The ideal so-

lution would be, that each individual generates the

pseudonym on his own. Without cross-checking,

however, there is a risk that some pseudonyms are

chosen to be identical. This drawback can be over-

come by using the technique of collision-free num-

ber generation for the establishment of pseudonyms.

Pseudonyms are then

1. generated locally, i.e. derived from a system-wide

unique identiﬁer, and they are

2. system-wide unique without being linkable to the

original identiﬁer, from which they are derived.

The remainder of this paper is organized as fol-

lows. After going through some preliminaries we will

brieﬂy describe a scheme, that allows the individual to

locally generate almost random numbers, which are

globally (in particular system-wide) unique (Schart-

ner and Schaffer, 2005; Schaffer et al., 2007). These

numbers can be used as pseudonyms and hence they

can be used to replace the original health ID. The in-

dividual’s name and the corresponding ID (thus the

Schartner P. and Schaffer M. (2008).

PROTECTING PRIVACY IN MEDICAL DATABASES - Efﬁcient Local Generation of System-Wide Unique Health IDs.

In Proceedings of the First International Conference on Health Informatics, pages 51-58

 SciTePress

medical record) are then computationally unlinkable.

After describing the original scheme with two prac-

tical implementations, we will present two applica-

tion scenarios. In the ﬁrst, we will discuss centralized

databases which store a medical record for each indi-

vidual in order to improve the quality and security of

ongoing and later treatments. In the second, we will

discuss databases for medical records of speciﬁc dis-

eases which are used to statistically investigate them.

2 PRELIMINARIES

Henceforth, l

denotes the bit-length of x.

AES Encryption (NIST, 2001). Let k be a random

secret AES-key. The AES-encryption of a binary

message m is given through

AES

(m) = c

where c is the computed ciphertext. For simplicity,

the decryption process is denoted similarly:

AES

−1

It is assumed that if the message is large, the encryp-

tion is carried out by using and appropriate mode of

operation with a standardized padding scheme.

RSA Encryption (Rivest et al., 1978). Let n be

the product of two safe (or strong) primes p and q.

The public key e is chosen at random (or system-

wide static), such that gcd(e,ϕ(n)) = 1. The corre-

sponding private key d is computed such that ed ≡

1 (mod ϕ(n)) holds. Given (e,n), a message m ∈ Z

is encrypted through the function RSA

(e,n)

, deﬁned as

follows:

RSA

(e,n)

(m) = m

MOD n

A ciphertext c ∈ Z

can be decrypted through the

function RSA

−1

(d,n)

deﬁned as follows:

RSA

−1

(d,n)

MOD n

The security of the scheme relies on the problem of

factoring n and computing e-th roots modulo n. The

problem of ﬁnding m, given c and (e,n) is sometimes

called the RSA-Problem and deﬁned as follows:

Deﬁnition 2.1 Let n = pq, where p and q are primes,

e ∈ Z

∗

ϕ(n)

, m ∈ Z

and c = m

MOD n. The RSA-

Problem is the following: given c and (e, n), ﬁnd m.

Like all state-of-the-art implementations of RSA

we employ optimal asymmetric encryption padding

OAEP (Jonsson and Kaliski, 2002), which ist as spe-

cial form of padding, securing RSA against chosen

ciphertext attacks.

Elliptic Curve Cryptography (ECC). To speed up

computations, discrete logarithm-based cryptosys-

tems are often run over an elliptic curve group, or

in particular on a subgroup of prime order. A good

introduction to ECC can be found in (D. Hankerson,

2004). We use scalar multiplication in such groups

as a one-way function. The corresponding intractable

problem is deﬁned in the following:

Deﬁnition 2.2 Let E(Z

) be an elliptic curve group,

where p is an odd prime. Let P ∈ E(Z

) be a point of

prime order q, where q|#E(Z

). The Elliptic Curve

Discrete Logarithm Problem (ECDLP) is the follow-

ing: given a (random) point Q ∈ hPi and P, ﬁnd k ∈ Z

such that Q = kP.

To avoid confusion with ordinary multiplication we

henceforth write SM(n,P) to express the scalar multi-

plication nP in E(Z

). It is currently believed that the

ECDLP using l

≈ 192 and l

≈ 180 is secure against

powerful attacks like Pollard’s rho algorithm (D. Han-

kerson, 2004).

ECC Point Compression (IEEE, 2000). A point on

an elliptic curve consists of two coordinates and so

requires 2l

bits of space. It is a fact that for every x-

value at most two possible y-values exist. Since they

only differ in the algebraic sign, it sufﬁces to store

only one bit instead of the whole y-value. We therefor

deﬁne the point compression function CP : E(Z

) →

× {0,1} as follows:

CP((x,y)) = (x,y MOD 2)

Storing (x,ey) instead of (x,y) requires only l

+ 1 bits

of space. To uniquely recover (x, y) from (x, ˜y) ∈ Z

{0,1} one needs a decompression function DP : Z

{0,1} → E(Z

), such that

DP((x, ˜y)) = (x, y)

How y is uniquely recovered depends on the kind of

elliptic curve that is used and on how p is chosen. For

instance, consider an elliptic curve deﬁned through

the equation y

≡ x

+ ax + b (mod p), where a, b

are some appropriate public domain parameters. If

p ≡ 3 (mod 4), one can recover y form (y, ey) through

one modular exponentiation:

0,1

≡ ±(x

+ ax+ b)

(p+1)/4

(mod p)

where y = y

. This is a very efﬁcient way to compute

square roots modulo a prime and is also used in the

Rabin cryptosystem.

ElGamal Encryption (ElGamal, 1985). In this pa-

per, we use a particular variant of the ElGamal en-

cryption scheme. Let E(Z

) be the elliptic curve

group as described above and P a point of order

q. Then d ∈

denotes the private key whereas

Q = SM(d,P) denotes the corresponding public key.

If done straightforwardly according to (ElGamal,

1985), a message M ∈ E(Z

) can be encrypted by

ﬁrst choosing a random r ∈ Z

and then computing

the ciphertext-pair (A, B) = (SM(r,P),M +SM(r,Q)).

Given (A, B) and d, M can be obtained through B +

SM(− d, A). However, it is not trivial to map a binary

message m to a point M on an elliptic curve. An efﬁ-

cient method to overcome this drawback is to choose

a cryptographic hash-function H : E(Z

) → {0, 1}

where l

denotes the bit-length of the binary message

m, and deﬁne the ElGamal encryption function ElG

ElG

(m) = (SM(r,P),m⊕ H (SM(r,Q))), r ∈

Given the ciphertext-pair (A,B) ∈ E(Z

) × {0,1}

and d, m can be obtained through ElG

−1

ElG

−1

((A,B)) = H (SM(−d,A)) ⊕ B

The correctness of this ElGamal variant is obvious.

3 COLLISION-FREE NUMBER

GENERATION

In (Schaffer et al., 2007) we proposed a general

method for generating system-wide unique numbers

in a local environment, whilst preserving the privacy

of the generating individual. The described genera-

tor, called collision-free number generator (CFNG),

fulﬁls the following requirements:

R1 (Uniqueness). A locally generated number is

system-wide unique for a certain time-interval.

R2 (Efﬁciency). The generation process is efﬁcient

regarding communication, time and space.

R3 (Privacy). Here we distinguish two cases:

1. Hiding: Given a generated number, a poly-

bounded algorithm is not able to efﬁciently iden-

tify the corresponding generator.

2. Unlinkability: Given a set of generated numbers,

a poly-bounded algorithm is not able to efﬁciently

decide which of them have been generated by the

same generator.

In the following subsection we summarize two gen-

eral principles of collision-free number generation,

formerly introduced in (Schaffer et al., 2007).

3.1 General Construction

For efﬁciency reasons, an identiﬁer-based approach

is used. Every generator is (once) initialized with a

system-wide unique identiﬁer, which we denote by

UI. The idea is, to derive several unique numbers

from UI, such that none of them is linkable to UI.

Uniqueness Generation. As a ﬁrst step a routine is

needed, which derives a unique number u from UI

in every run of the generation process. We call such

a routine uniqueness generator and denote it by UG.

UG can be designed as follows:

u = UG(), u = UI||cnt||pad

where pad is a suitable padding for later use of u and

cnt is an l

cnt

-bit counter initialized by cnt ∈

{0,1}

cnt

and incremented modulo 2

cnt

in every round. So, the

output of UG is unique for at least 2

cnt

−1 rounds. So

far, the privacy is not preserved, sinceUI is accessible

through u.

Pre

f π

Figure 1: Collision-Free Number Generator CFNG1.

Uniqueness Randomization. A ﬁrst step to provide

privacy is to transform u such that the resulting block

looks random. Hereby, we use an injective function

, where r is chosen from a set R. The idea is that u is

randomized by r and hence we call f

the uniqueness

randomization function. We suggest to either use an

injective mixing-transformation for f

(e.g. symmet-

ric encryption) or an injective one-way function based

on an intractable problem (e.g. the Discrete Loga-

rithm Problem). In both cases, r is chosen at ran-

dom. The output of f

is obviously not guaranteed

to be unique: let u,u

′

, u 6= u

′

and r, r

′

random, where

r 6= r

′

. Then f

(u) = f

′

) may hold since two dif-

ferent injective functions f

and f

′

map on the same

output space. On the other hand, this problem cannot

happen if r = r

′

, since f

is injective. To generate a

unique block o, sufﬁcient information about the cho-

sen function f

has to be attached to its output. Hence,

o can be deﬁned as o = f

(u)||r. The concatenation

of two blocks by writing them in a row is an unnec-

essary restriction. The bits of the two blocks can be

concatenated in any way. This leads to the following

construction (cf. Figure 1):

o = π( f

(u),r), u = UG(), r = Pre()

where π is a (static) bit-permutation function (or bit-

permuted expansion function) over the block f

(u)||r

and the generation of r is done by a routine called

pre-processor, denoted by Pre. The main-task of Pre

is the correct selection of r. This can include a key

generation process if f

is an encryption function.

Theorem 3.1. Let u be a system-wide unique number,

be an injective function and r ∈ R. Furthermore, let

π be a static bit-permutation function or bit-permuted

expansion function. Then o = π( f

(u),r) is system-

wide unique, for all r ∈ R.

Proof. Let o

′

= π( f

′

),r

′

) and u 6= u

′

. The case

where r 6= r

′

obviously guarantees that the pairs

( f

(u),r) and ( f

′

),r

′

) are distinct. Now consider

the case where r = r

′

. Since u 6= u

′

holds per as-

sumption f

(u) 6= f

′

) holds due to the injectiv-

ity of f

and the fact that r = r

′

. Thus, we have

( f

(u),r) 6= ( f

′

),r

′

) for all r,r

′

∈ R. It remains to

show that o 6= o

′

. This is obviously the case, because

π is static and injective.

Privacy Protection. Given o = π( f

(u),r), comput-

ing π

−1

(o) = (a,b) is easy since π is public. Concern-

ing f, two cases might occur concerning the obtain-

able information about u and hence about UI:

1. Computing f

−1

(a) = u is computationally hard.

Then we are done, since obtaining u is hard.

2. Computing f

−1

(a) = u is easy. Then an exten-

sion of the basic construction is necessary, which

is sketched in the following.

To keep ﬁnding u hard, we suggest using an injective

one-way function g to hide π( f

(u),r). We call g the

privacy protection function. The new output o is de-

ﬁned as follows (cf. Figure 2):

o = g(π( f

(u),r)), u = UG(), r = Pre()

The extended construction still outputs unique num-

bers, which is shown by the following corollary.

Pre

f π

Figure 2: Collision-Free Number Generator CFNG2.

Corollary 3.1. Let u be a system-wide unique num-

ber, f

be an injective function and r ∈ R. Further-

more, let π be a static bit-permutation function or bit-

permuted expansion function and g an injective one-

way function. Then o = g(π( f

(u),r)) is system-wide

unique, for all r ∈ R.

Proof. Let o

′

= g(π( f

′

),r

′

)) with u 6= u

′

. By The-

orem 3.1 π( f

(u),r) 6= π( f

′

),r

′

). Since g is injec-

tive, o 6= o

′

for all r,r

′

∈ R.

3.2 Practical Approaches

In the following two examples are given, how CFNG1

and CFNG2 can be implemented for the generation

of system-wide unique pseudonyms. The ﬁrst one is

based on the RSA-Problem and the second is based on

AES and the ECDLP. For both variants, we will only

discuss the principle operation, but no details (e.g. bit

lengths) are given.

In order to guarantee the proper generation of the

pseudonyms we assume that each individual has been

provided with a system-wide unique identiﬁer UI

(which could be the original health identiﬁer or the

ICCSN () of a smartcard). Henceforth, we assume

that all computations are done in a smartcard.

3.2.1 RSA-based CFNG1

In order to generate a system-wide unique pseudonym

N, the smartcard generates an RSA key pair consist-

ing of the public exponent e, the random private expo-

nent d and the random modulus n (consisting of two

appropriately chosen large prime factors). Now, the

smartcard calculates the pseudonym N as follows:

N = RSA

(e,n)

(u)||(e,n)

Setting f = RSA, r = (e,n) and π = ||, Theorem 3.1

can be applied and thus N is system-wide unique.

Moreover, the encryption process is hard to invert,

given only N. Hence, obtaining u from N is infea-

sible for a poly-bounded algorithm which leads to a

sufﬁcient privacy-protection.

Pre

(e,n)

RSA

Figure 3: RSA-based Pseudonym Generation.

To keep the bit-length of N as short as possible, every

user might use the same public key e. In this case,

there is no need to embed e in N:

N = RSA

(e,n)

(u)||n

Figure 3 shows the principle design of the RSA-based

CFNG. Here Pre denotes a key generator, which gen-

erates the key (e,n) and padding material for the en-

cryption process. The system parameters includes the

bit-length of n and of the padding.

General Practitioner

Central Medical Register Hospital

data

authenticationauthentication

data

Figure 4: Centralized Medical Registers.

3.2.2 ECC-based CFNG2

In this variant, we employ a symmetric encryption

algorithm to conceal the identity of the patient. As

above, the randomly chosen key used for this encryp-

tion process (this time k) has to be concatenated to

the output the ciphertext. However, this construction

is not sufﬁcient for privacy protection, since one can

easily invert the encryption process (it is symmetric).

According to the design of CFNG2, one has to choose

a privacy protection function g. For efﬁciency, we use

scalar multiplication in an elliptic curve group as a

one-way function. The pseudonym N is deﬁned as:

N = SM(AES

(u)||k,P)

Figure 5 shows the principle design of the ECC-based

generation process. Here, the system parameters in-

clude the system-wide constant point P, and the bit

lengths of the primes p and q and the key k.

Pre

AES

Figure 5: ECC-based Pseudonym Generation.

Setting f = AES, r = k and g = SM, Corollary 3.1 can

be applied and system-wide uniqueness is achieved.

Notice that AES

(u)||k is highly random and hence

inverting the ECC point multiplication process is hard

due to the ECDLP. Thus, the requirement for privacy

is fulﬁlled sufﬁciently for practical use.

4 UNIQUE PSEUDONYMS IN

MEDICAL REGISTERS

4.1 Centralized Medical Records

In the ﬁrst scenario, we employ a centralized medi-

cal database which stores a medical record for each

individual. From the individual’s point of view it is

essential, that

• there is no link between the medical record and

the real identity,

• no unauthorized person gets read or write access

to the medical record, and

• additional data which is stored in the course of

time is accumulated in the correct medical record.

4.1.1 Initialization

In this application we will employ smartcards which

are equipped with an ECC-based CFNG2 for efﬁ-

ciency reasons. Hence, the digital pseudonym is of

the form N = CP(SM(AES

(u)||k,P)), where u =

UI||cnt||pad (cf. Section 3.1) and UI the patient’s

identiﬁer. Notice that we apply the point compression

function CP to make N as short as possible. Whenever

additional medical data has to be stored in the medical

record, this pseudonym will unambiguously identify

the record belonging to the holder of the pseudonym.

4.1.2 Data Storage

Prior to adding some data to his medical record, the

patient has to prove that he owns the necessary rights.

To protect the privacy of the patient, the authentica-

tion process (cf. Figure 4) must not include secret in-

formation on server side (this excludes symmetric en-

cryption based authentication). An idea is to consider

Patient Medical Database

(A,B)

select N

ElG

−1

((A,B)) = c||K

AES

(m||c) = C

DP(N) = Q

c ∈

{0,1}

K ∈

{0,1}

ElG

(c||K) = (A,B)

AES

−1

′

Store m if c = c

′

reject otherwise.

Figure 6: Authentication and Data Storage.

Q = (x,y), where N = CP(Q), as the public key of

the ElGamal encryption scheme described in Section

2. The corresponding private key is d = AES

(u)||k,

since N = CP(Q) and Q = SM(AES

(u)||k,P). This

enables an indirect asymmetric authentication and

key-exchange protocol, that provides anonymity of

the patient, conﬁdentiality of the sent medical data

and freshness of the sent messages (cf. Figure 6):

1. To start the upload of medical data, the patient’s

smartcard contacts the server that stores the med-

ical records, and sends his pseudonym N.

2. The server generates a random challenge c of

length l

and a session key K of length l

such that l

+ l

= l

and l

with respect to the

involved symmetric encryption algorithm (here

AES). Then he encrypts c||K with Q using

ElG

as described in Section 2. The resulting

ciphertext-pair (A,B) is returned to the smartcard.

3. The smartcard decrypts (A,B) by using ElG

−1

with the private key d and retrieves c and K. The

medical data m (extended by the server’s chal-

lenge) is encrypted to C = AES

(m||c) and sent

to the server.

4. The server decrypts the encrypted message, com-

pares the received challenge to the sent one and

updates the medical record if they are identical.

Otherwise he rejects the update request.

The authentication process only succeeds, if the pa-

tient knows d, such that Q = SM(d,P). The probabil-

ity of computing a correct C (that contains the same

challenge as generated by the server) without know-

ing d is negligible.

4.1.3 Data Retrieval

In principle, the data retrieval process is similar to

the data storage process. At the beginning the patient

needs to authentication himself to the server. Thereby,

the server generates a session key. The data retrieval

message is encrypted with the session key and pro-

vides the server with some data to identify the re-

quested section of the medical record. The server se-

lects this section, encrypts it with the session key and

returns it to the patient’s smartcard. Here, the mes-

sage is decrypted and the medical data can be pro-

cessed by the speciﬁc application.

4.1.4 An Extension

So far, the pseudonym is of the form N =

CP(SM(AES

(u)||k,P)), and provides full access to

the medical record. The medical record could be split

into several (unlinkable) parts, if we append SID

(the

identiﬁer of section i) to UI and generate

= CP(SM(AES

)||k

,P))

where u

contains UI||SID

. A pseudonym N

will

now identify and grant access to a speciﬁc section of

the medical record, which enables access control and

unlinkability on a ﬁner level.

4.1.5 Security & Efﬁciency

The pseudonym is generated by a collision-free num-

ber generator that protects the privacy of the gener-

ating instance. In the current context this means that

computing UI from a pseudonym is computationally

hard, i.e. requires solving the ECDLP. The generation

process is very efﬁcient since only one symmetric en-

cryption and one scalar multiplication is necessary.

The authentication process reveals no information

about UI. The user can only respond correctly

(apart from some negligible cheating probability) to

the challenge, if he knows the pre-image of the

pseudonym. The authentication process only requires

the exchanging of three messages between server and

smartcard. The smartcard only performs one scalar

multiplication, one run of a hash algorithm and some

symmetric encryption. The server performs one run

of the point decompression function DP which equals

Database 1 Smartcard Database 2

CFNG

DBID

mutually unlinkable

authenticationauthentication

data

Figure 7: Anonymous Medical Databases.

to one modular exponentiation if p ≡ 3 (mod 4). Fur-

thermore, two scalar multiplications are done and

some symmetric decryption. All computations only

require minimal temporary space.

4.2 Anonymous Medical Databases

Centralized medical databases are quite commonly

used to provide some anonymized data for statisti-

cal investigations of certain diseases like cancer, in-

ﬂuenza, or tuberculosis. Here, data like date of diag-

nosis, applied treatment, medication, chronology, and

mortality are of special interest. The privacy prob-

lem with these medical databases is how to provide

the anonymity of the patient. Of course, the server

storing the database may be trusted, but especially

in the scope of medical records, the sensitivity for

privacy-endangeringtechnologies is very high. So the

best method is to remove the identifying information

as soon as possible. Unfortunately, the medical data

concerning the disease of a speciﬁc patient is most

commonly generated over a larger period of time and

hence we need some identiﬁer to link the separate data

records. Here again, we can use collision-free num-

ber generators. The authentication of the data storing

party (cf. section 4.1.2) will be moved to the applica-

tion level. The smartcard of the patient provides only

the unique identiﬁer of the medical record, which now

depends on the patient’s identiﬁer (UI) and the iden-

tiﬁer of the database (DBID).

4.2.1 Initialization

The smartcard issuer has to generate appropriate

system parameters, which are stored in the smart-

card. Every time a new medical database is con-

nected (cf. Figure 7), the smartcard receives the

database identiﬁer DBID and generates the corre-

sponding pseudonym. This pseudonym will be stored

in the smartcard for later usage.

4.2.2 Data Storage

During the authentication the smartcard retrieves the

session key from the database server. In order to store

data, all personal data of the current medical record is

removed and the remaining data is encrypted by use

of the session key (established during the authentica-

tion process). The resulting ciphertext is sent to the

database server. The message is decrypted and the

medical data is stored in the record identiﬁed by the

pseudonym.

4.2.3 Data Retrieval

This application scenario does not provide data re-

trieval for the individual patient. Only medical institu-

tions may retrieve data from the centralized medical

and conﬁdential goes beyond the scope of this paper.

4.2.4 Security & Efﬁciency

Security and efﬁciencycan be considered analogously

to the previous application scenario. Unlinkabil-

ity is again achieved through the privacy protection

that holds through the design of the used ECC-based

collision-free number generator.

5 CONCLUSIONS

In this paper, we introduced a replacement for link-

able unique health identiﬁers: locally generated but

nevertheless system-wide unique digital pseudonyms.

To achieve this replacement, we used so called

collision-free number generators, which have been

brieﬂy discussed in den introductory part of this ar-

ticle. Here we presented two variants: one based

on the RSA-Problem, the other based on the Ellip-

tic Curve Discrete Logarithm Problem. Both variants

fulﬁll the requirements uniqueness of the generated

pseudonyms, privacy in terms of hiding the origina-

tors identiﬁer and unlinkability of individualdata sets.

Since the second variant is more efﬁcient in terms of

computational costs and space it has been suggested

for the use within smartcards.

Beside proposing two practical generators, a proto-

col has been proposed through which a smartcard

can efﬁciently authenticate anonymously to a medi-

cal database (with respect to a pseudonym). Based

on this protocol medical registers can be extended

and updated anonymously by the patient. Further-

more such an authentication protocol can be used to

make entries in several databases. For each database,

a fresh pseudonym is used so that entries of different

databases are mutually computationally unlinkable.

Concerning collision-free number generation further

information on implementation issues and extended

constructionscan be found in (Schaffer and Schartner,

2007) and (Schaffer, 2007) respectively.

REFERENCES

CNN (2000). National Health Identiﬁer: Big Help or Big

Brother? http://www.cnn.com/HEALTH/bioethics/

9807/natl.medical.id.

D. Hankerson, A. Menezes, S. V. (2004). Guide to Elliptic

Curve Cryptography. Springer.

ElGamal, T. (1985). A Public Key Cryptosystem and a

Signature Scheme Based on Discrete Logarithms. In

Blakley, G. R. and Chaum, D., editors, Advances in

Cryptology – CRYPTO’84, volume 196 of Lecture

Notes in Computer Science, pages 10–18. Springer.

IEEE (2000). IEEE 1363-2000: IEEE Standard Speciﬁca-

tions for Public-Key Cryptography. IEEE.

Institute for Health Freedom (2000). What’s Hap-

pening with the “Unique Health Identiﬁer” Plan?

http://www.forhealthfreedom.org/Publications/

privacy/UniqueId.html.

Jonsson, J. and Kaliski, B. (2002). Public-

Key Cryptography Standards (PKCS)

#1: RSA Cryptography Speciﬁcation.

http://www.rsa.com/rsalabs/node.asp?id=2125.

Medical Privacy Coalition (2007). Elim-

inate Unique Health Identiﬁer.

http://www.medicalprivacycoalition.org/unique-

health-identiﬁer.

NIST (2001). FIPS PUB 197: Speciﬁcation

of the Advanced Encryption Standard (Na-

tional Institute of Standards and Technology).

http://csrc.nist.gov/publications/ﬁps/ﬁps197/ﬁps-

197.pdf.

Pﬁtzmann, A. and K¨ohntopp, M. (2001). Anonymity, Un-

observability, and Pseudonymity – A Proposal for Ter-

minology. In Federrath, H., editor, Proceedings of

Workshop on Design Issues in Anonymity and Unob-

servability, volume 2009 of Lecture Notes in Com-

puter Science, pages 1–9. Springer.

Rivest, R. L., Shamir, A., and Adleman, L. M. (1978). A

Method for Obtaining Digital Signatures and Public-

Key Cryptosystems. Commun. ACM, 21(2):120–126.

Schaffer, M. (2007). Collision-Free Number Generation:

Efﬁcienty Constructions, Privacy Issues, and Crypto-

graphic Aspects. PhD-Thesis, Klagenfurt University.

Schaffer, M. and Schartner, P. (2007). Implement-

ing Collision-Free Number Generators on JavaCards.

Technical Report TR-syssec-07-03, University of Kla-

genfurt.

Schaffer, M., Schartner, P., and Rass, S. (2007). Univer-

sally Unique Identiﬁers: How to ensure Uniqueness

while Preserving the Issuer’s Privacy. In Alissi, S. and

Arabnia, H. R., editors, Proceedings of the 2007 In-

ternational Conference on Security & Management –

SAM’07, pages 198–204. CSREA Press.

Schartner, P. and Schaffer, M. (2005). Unique User-

Generated Digital Pseudonyms. In Gorodetsky, V.,

Kotenko, I. V., and Skormin, V. A., editors, Proceed-

ings of Mathematical Methods, Models, and Architec-

tures for Computer Network Security – MMM-ACNS

2005, volume 3685 of Lecture Notes in Computer Sci-

ence, pages 194–205. Springer.
