COMPARATIVE STUDY OF SEVERAL NOVEL ACOUSTIC

FEATURES FOR SPEAKER RECOGNITION

∗†

Vladimir Pervouchine,

∗

Graham Leedham,

∗‡

Haishan Zhong,

∗

David Cho and

∗†

Haizhou Li

∗

Nanyang Technological University, School of Computer Engineering, N4 Nanyang Ave, Singapore 639798

†

Institute for Infocomm Research, 21 Heng Mui Keng Terrace, Singapore 119613

‡

Panasonic Singapore Laboratories, 1022 Tai Seng Avenue, #06-3530 Tai Seng Ind Est, Singapore 534415

Keywords:

Speaker recognition, feature extraction, feature evaluation.

Abstract:

Finding good features that represent speaker identity is an important problem in speaker recognition area.

Recently a number of novel acoustic features have been proposed for speaker recognition. The researchers

use different data sets and sometimes different classiﬁers to evaluate the features and compare them to the

baselines such as MFCC or LPCC. However, due to different experimental conditions direct comparison of

those features to each other is difﬁcult or impossible. This paper presents a study of ﬁve new recently proposed

acoustic features using the same data (NIST 2001 SRE), and the same UBM-GMM classiﬁer. The results

are presented as DET curves with equal error ratios indicated. Also, an SVM-based combination of GMM

scores produced on different features has been made to determine if the new features carry any complimentary

information. The results for different features as well as for their combinations are directly comparable to each

other and to those obtained with the baseline MFCC features.

1 INTRODUCTION

Speaker recognition is the process of automatic iden-

tiﬁcation or veriﬁcation of a speaker using the in-

formation obtained from his/her speech. Veriﬁcation

permits access control by voice as well as facilitates

in crime investigation if recordings of phone conver-

sations are available. Speaker recognition systems in-

cludes speaker identiﬁcation and speaker veriﬁcation;

however, studies usually focus on speaker veriﬁcation

only. Text-independent veriﬁcation has gained much

attention because does not require a user to speak any

pre-deﬁned phrases for the system to operate and thus

is an attractive method of personal veriﬁcation.

To represent a speaker features extracted from the

audio ﬁle are used. It is supposed that different speak-

ers can be represented differently in the feature space.

Therefore by building statistical models that approxi-

mate the distribution of feature vectors for different

speakers, the conditional probability of the speaker

being who he claims can be estimated.

Finding good features with low intra-speaker vari-

ation and high inter-speaker variation, as well as not

too sensitive to channel type, is an important prob-

lem in speaker recognition. Commonly used features

are Linear Prediction (LP) based features such as Lin-

ear Predictive Cepstral Coefﬁcients (LPCC) and Mel

Frequency Cepstral Coefﬁcients (MFCC) (Gish and

Schmidt, 1994). Although recently research focus has

been shifted mostly to developing methods of elimi-

nation of channel effects, a number of new and novel

features have been proposed (Wang and Wang, 2005;

Sant’Ana et al., 2006; Cordeiro and Ribeiro, 2006; Sri

Rama Murty and Yegnanarayana, 2006). New classi-

ﬁcation method to be used with the new features has

also been proposed in (Sant’Ana et al., 2006). Re-

searchers use different data sets to compare perfor-

mance of speaker veriﬁcation systems with their fea-

tures to that of the baseline systems. Therefore, it is

often difﬁcult or impossible to compare the effective-

ness of the new features to each other and to baseline

features (such as MFCC).

This paper presents a comparative study of ﬁve

new features proposed in 2005–2006 publications.

The features studied are Mean Energy within Critical

Bands (MECB) and Difference of Mean Energy within

Critical Bands (DMECB) (Wang and Wang, 2005),

pH features based on Hurst parameter and fractional

220

Pervouchine V., Leedham G., Zhong H., Cho D. and Li H. (2008).

COMPARATIVE STUDY OF SEVERAL NOVEL ACOUSTIC FEATURES FOR SPEAKER RECOGNITION.

In Proceedings of the First International Conference on Bio-inspired Systems and Signal Processing, pages 220-223

DOI: 10.5220/0001060302200223

 SciTePress

Brownian motion model (Sant’Ana et al., 2006), Mel

Line Spectrum Frequencies (MLSF) (Cordeiro and

Ribeiro, 2006), and Residual Phase (Sri Rama Murty

and Yegnanarayana, 2006). The paper is organised as

follows. Section 2 shortly describes the features and

section 3 presents the feature combination scheme.

Section 4 discusses the experimental setup and the re-

sults, and section 5 draws the conclusions.

2 FEATURES STUDIED

Mel Frequency Cepstral Coefﬁcients. Commonly

used MFCC features were taken as the baseline. The

data set audio ﬁles were divided into frames of 30 ms

length with 1/3 overlap using Hamming window.

Twelve MFCC coefﬁcients were calculated for each

frame along with their ﬁrst and second differences

(∆MFCC and ∆∆MFCC) resulting in 36-dimensional

feature vectors. The feature values were normalised

by subtracting the mean and dividing by the standard

deviation.

Mel Line Spectrum Frequencies. Mel Line Spec-

trum Frequencies (MLSF) are similar to Line Spec-

trum Frequencies calculated from Linear Prediction

(LP) coefﬁcients. The difference is in taking an

advantage of mel frequency warping, emphasising

the information in lower frequencies (Cordeiro and

Ribeiro, 2006). To extract MLSF features, the signal

was divided into 30 ms frames windowed using Ham-

ming window with 1/3 frame overlap. Fast Fourier

Transform (FFT) and mel ﬁlter bank were used to

generate mel spectrum. Then the inverse Fourier

transform was applied to get the mel autocorrelation

of the signal. The MLSF features were then calcu-

lated via the Levinson-Durbin recursion. An LP ﬁlter

of order 16 was used resulting in 16-dimensional fea-

ture vectors. The feature values were normalised by

subtracting the mean and dividing by the standard de-

viation. Since addition of the ﬁrst and second differ-

ences (∆MLSF and ∆∆MLSF) might increase the ver-

iﬁcation accuracy both differences were calculated. In

the original paper MLSF features were evaluated on

NIST 2002 SRE database.

Residual Phase. A person’s vocal tract can be mod-

elled as an excitation source and a set of ﬁlters that

characterise the vocal tract shape. While LP coefﬁ-

cients approximate the vocal tract shape, the excita-

tion source can be evaluated from the residual signal:

= s

∑

k=1

n−k

(1)

where s

is the signal, a

are the LP coefﬁcients.

Examples of features calculated from the residual

signal include Haar Octave Coefﬁcients of Residue

(HOCOR) (Zheng and Ching, 2004) and Residual

Phase (Sri Rama Murty and Yegnanarayana, 2006).

The latter was evaluated on NIST 2003 SRE database.

To extract the residual phase, the analytic signal R

+ jh

is calculated from the residual signal r

where h

is the Hilbert transform h

of r

. The phase

is then calculated from the analytic signal as:

= arccos



+ R



(2)

Authors (Sri Rama Murty and Yegnanarayana, 2006)

recommend to calculate the residual phase from short

segments of speech of around 5 ms, which is justiﬁed

by the period of the bursts in the excitation source. In

the our study the signal was divided into 6 ms frames

with 1/3 overlap. LP of orders 6 and 10 were tried.

Hurst Parameter Features. Hurst parameter

features were proposed for speaker recogni-

tion (Sant’Ana et al., 2006) and evaluated on

BaseIME database developed in the Instituto Militar

de Engenharia. The feature vector is a vector of Hurst

parameters calculated for frames of a speech signal

via Abry-Veitch Estimator using discrete wavelet

transform. To extract the features the speech signal

was divided into 80 ms frames with 1/2 overlap,

which were chosen to make the extraction similar

to that presented in the original paper. Daubechies

wavelets with 4, 6, and 12 coefﬁcients were used,

thus resulting in pH

, pH

, and pH

features. The

depth of wavelet decomposition was to be 5, 4, and 3

for pH

, pH

, and pH

respectively.

Mean Energy within Critical Bands. Fractional

Fourier transform (FrFT) is a generalisation of the

ordinary (integer) Fourier transform. Mean Energy

within Critical Bands (MECB) features based on the

fractional Fourier transform were proposed in (Wang

and Wang, 2005) and evaluated on a custom data set.

The critical bands are formed by warping frequency

according to the mel or bark scale. MECB

are cal-

culated by taking the fractional Fourier transform of

order p of each frame of the signal. For i-th critical

band f

... f

i+1

the log of mean energy is

= log

i+1

F( f )

d f

i+1

− f

(3)

For two MECB features of orders p

and p

the dif-

ference MECB (DMECB) features are calculated as:

DMECB

−p

= MECB

− MECB

(4)

COMPARATIVE STUDY OF SEVERAL NOVEL ACOUSTIC FEATURES FOR SPEAKER RECOGNITION

221

In our study the signal was divided into 30 ms long

frames with 1/3 overlap. MECB of orders p =

0.5,0.6,. ..,1.0 were extracted. DMECB were calcu-

lated for a ﬁxed p

of 1.0 and p

0.5...0.9.

3 COMBINATION OF FEATURES

Combining different acoustic features can be per-

formed in a number of ways. One way is to concate-

nate the feature vectors of the corresponding frames.

However, this leads to feature vectors of very high

dimensionality, which means much more data is re-

quired for reliable training of a classiﬁer. Thus the

concatenation was only done for low-dimensional

feature vectors pH, while for the high-dimensional

features another method was used. A GMM en-

ables modelling the conditional probability density

functions in the feature space for each class. A

GMM classiﬁer returns a score for each given pattern,

which is an estimation of the log likelihood ratio for

the hypothesis that the speaker is who he claims to

be (Reynolds and Rose, 1995). These scores from

GMM classiﬁers for each of the acoustic features

were used as features. The resulting score feature vec-

tors were used with an SVM classiﬁer.

4 EXPERIMENTS AND RESULTS

All experiments were conducted on NIST 2001

Speaker Recognition Evaluation (SRE) database,

single-speaker ﬁles. The audio ﬁles sampled at 8 kHz

were pre-emphasised with ﬁlter coefﬁcient of 0.97

and divided into frames as described above. For all

features a Gaussian Mixture Model (GMM) classiﬁer

of 512 multivariate normal distributions with diagonal

covariance matrices was used (Reynolds and Rose,

1995). The Universal Background Models (UBM)

were trained on samples from 82 male and 56 fe-

male speakers. The resulting Detection Error Trade-

off (DET) curves and the Equal Error Ratios (EER)

are shown in Fig. 1(a)–(g).

Individual Features. The results achieved with

MFCC features with the ﬁrst and second differences

were taken as the baseline (Fig. 1(a)). As seen from

the DET curves in Fig. 1(b), adding the ﬁrst difference

to MLSF improves the speaker veriﬁcation accuracy,

which is in agreement with the results in (Cordeiro

and Ribeiro, 2006). Adding the second difference im-

proves the accuracy further. Because of high dimen-

sionality of the resulting feature vectors (48) more

training data may lead to better system performance.

Fig. 1(c) shows the DET curves for Residual

Phase features and two different order LP ﬁlters. The

difference in the LP ﬁlter order does not result in a

signiﬁcant difference in the speaker veriﬁcation accu-

racy. It was also found that adding the ﬁrst difference

features does not change the system performance ei-

ther, so the second difference was not tried.

Features pH

4+6+12

were obtained by concatenat-

ing feature vectors pH

, pH

, and pH

for each

frame. It was found that performance of the speaker

veriﬁcation system is similar when either one of pH

, pH

are used. Concatenating them into 12-

dimensional pH

4+6+12

vectors leads to a dramatic im-

provement in the accuracy with EER dropping from

29.0% to 20.8% (Fig. 1(d)).

The accuracy of speaker veriﬁcation for MECB

features declines with p of FrFT (Fig. 1(e)). This is

in accordance with the results reported in (Wang and

Wang, 2005), while the results for DMECB

1.0−p

fea-

tures with various p

(Fig. 1(f)) are different from

that reported in the paper: the highest speaker veri-

ﬁcation accuracy was achieved for p

= 0.5 and for

= 0.6...0.9 the accuracy decreased with increase

of p

. Adding the difference features to MECB and

DMECB did not lead to accuracy improvement.

Table 1: Equal error rates for MECB features of different

orders.

MECB

, p 1.0 0.9 0.8 0.7 0.6 0.5

EER, % 17.6 18.7 21.2 24.2 27.5 31.4

Table 2: Equal error rates for DMECB features of different

orders.

DMECB

1.0−p

, p

0.9 0.8 0.7 0.6 0.5

EER, % 19.7 19.4 18.9 18.3 17.8

Table 3: Summary of equal error rates for different feature

types and their SVM combination.

Feature type

EER, % Feature type EER, %

MFCC+∆+∆∆ 9.5 Residual phase 21.5

MLSF+∆+∆∆ 16.0 pH

4+6+12

20.8

MECB

1.0

17.6 DMECB

1.0−0.5

17.8

Combined 8.7

Combination of Features. To make the results

comparable to those of acoustic features alone a 5-

fold cross-validation scheme was applied. The test

set of speakers was divided into 5 approximately

equal parts. Every time one different part was left

for testing and four others were used for training

the SVM, resulting in 5 experiments in total. The

SVM was designed to produce a soft decision, which

BIOSIGNALS 2008 - International Conference on Bio-inspired Systems and Signal Processing

222

0.1 0.2 0.5 1 2 5 10 20 40

0.1

0.2

0.5

False acceptance rate (%)

False rejection rate (%)

MFCC+!+!! EER 9.5%

(a) MFCC

0.1 0.2 0.5 1 2 5 10 20 40

0.1

0.2

0.5

False acceptance rate (%)

False rejection rate (%)

MLSF EER 18.8%

MLSF+! EER 16.4%

MLSF+!+!! EER 16.0%

(b) MLSF

0.1 0.2 0.5 1 2 5 10 20 40

0.1

0.2

0.5

False acceptance rate (%)

False rejection rate (%)

LP 6, EER 21.5%

LP 10, EER 22.0%

0.1 0.2 0.5 1 2 5 10 20 40

0.1

0.2

0.5

False acceptance rate (%)

False rejection rate (%)

EER 29.0%

EER 29.1%

EER 29.0%

4+6+12

EER 20.8%

(d) pH

0.1 0.2 0.5 1 2 5 10 20 40

0.1

0.2

0.5

False acceptance rate (%)

False rejection rate (%)

MECB

0.5

EER 31.4%

MECB

0.6

EER 27.5%

MECB

0.7

EER 24.2%

MECB

0.8

EER 21.2%

MECB

0.9

EER 18.7%

MECB

1.0

EER 17.6%

(e) MECB

0.1 0.2 0.5 1 2 5 10 20 40

0.1

0.2

0.5

False acceptance rate (%)

False rejection rate (%)

DMECB

1.0!0.5

EER 17.8%

DMECB

1.0!0.6

EER 18.3%

DMECB

1.0!0.7

EER 18.9%

DMECB

1.0!0.8

EER 19.4%

DMECB

1.0!0.9

EER 19.7%

(f) DMECB

Figure 1: DET curves for different feature types.

0.1 0.2 0.5 1 2 5 10 20 40

0.1

0.2

0.5

False acceptance rate (%)

False rejection rate (%)

MFCC+!+!! EER 9.5%

SVM Combination EER 8.7%

Figure 2: DET curve for combination of acoustic features.

was then treated as a score for plotting the DET

curve and calculating the EER. It was decided to

combine MFCC+∆ + ∆∆, MLSF+∆ + ∆∆, Resid-

ual Phase with LP of order 6, pH

4+6+12

, MECB

1.0

and DMECB

1.0−0.5

, choosing one feature from each

group with the best performance. The results of the

combination are shown in Fig. 2 with the EER in Ta-

ble 3 with the DET curve for the MFCC+∆+∆∆ plot-

ted for comparison.

5 CONCLUSIONS

As assessed on NIST 2001 SRE database, none of the

novel acoustic features considered in this study out-

performed the MFCC features. MLSF and MECB

features have performance that is comparable to that

of MFCC. Features pH showed a high accuracy of

speaker veriﬁcation taking into account their low di-

mensionality (5, 4, and 3 for pH

, pH

, and pH

re-

spectively), hence they may be attractive when lim-

ited training data is available. Combination of several

different acoustic features resulted in signiﬁcantly

higher accuracy of speaker veriﬁcation. We can con-

clude that the studied features carry additional infor-

mation about speakers. How big is the contribution of

each of the features into the speaker veriﬁcation accu-

racy, however, needs to be established. To determine

this either all possible feature combinations have to

be tried, or feature selection methods have to be used.

REFERENCES

Cordeiro, H. and Ribeiro, C. (2006). Speaker characteriza-

tion with MLSF. In Odyssey 2006: The Speaker and

Language Recognition Workshop, San Juan, Puerto

Rico.

Gish, H. and Schmidt, M. (1994). Text-independent speaker

identiﬁcation. IEEE Signal Processing Magazine,

pages 18–32.

Reynolds, D. and Rose, R. (1995). Robust text-independent

speaker identiﬁcation using Gaussian mixture speaker

models. IEEE Trans. Speech Audio Process., 3(1):72–

83.

Sant’Ana, R., Coehlo, R., and Alcaim, A. (2006). Text-

independent speaker recognition based on the Hurst

parameter and the multidimensional fractional Brow-

nian motion model. IEEE Trans. Acoust., Speech, Sig-

nal Process., 14(3):931–940.

Sri Rama Murty, K. and Yegnanarayana, B. (2006). Com-

bining evidence from residual phase and MFCC fea-

tures for speaker recognition. IEEE Signal Process.

Lett., 13(1):52–55.

Wang, J. and Wang, J. (2005). Speaker recognition using

features derived from fractional Fourier transform. In

4th IEEE Workshop on Automatic Identiﬁcation (Au-

toID 2005), Buffalo, NY, USA.

Zheng, N. H. and Ching, P. C. (2004). Using Haar

transformed vocal source information for automatic

speaker recognition. In Proc. IEEE ICASSP, vol-

ume 1, pages 77–80, Montreal, Canada.

COMPARATIVE STUDY OF SEVERAL NOVEL ACOUSTIC FEATURES FOR SPEAKER RECOGNITION

223
