THE CONTRIBUTION OF COMPRESSION TO VISUAL

PATTERN RECOGNITION

Gunther Heidemann

Intelligent Systems Group, University of Stuttgart, Universit

atsstr. 38, D-70569 Stuttgart, Germany

Helge Ritter

Neuroinformatics Group, Bielefeld University, Universit

atsstr. 25, D-33615 Bielefeld, Germany

Keywords:

Compression, mutual information, Lempel-Ziv, gzip, bzip2, object recognition, texture, image retrieval.

Abstract:

Most pattern recognition problems are solved by highly task speciﬁc algorithms. However, all recognition

and classiﬁcation architectures are related in at least one aspect: They rely on compressed representations

of the input. It is therefore an interesting question how much compression itself contributes to the pattern

recognition process. The question has been answered by Benedetto et al. (2002) for the domain of text, where

a common compression program (

gzip

) is capable of language recognition and authorship attribution. The

underlying principle is estimating the mutual information from the obtained compression factor. Here we show

that compression achieves astonishingly high recognition rates even for far more complex tasks: Visual object

recognition, texture classiﬁcation, and image retrieval. Though, naturally, specialized recognition algorithms

still outperform compressors, our results are remarkable, since none of the applied compression programs

(

gzip

bzip2

) was ever designed to solve this type of tasks. Compression is the only known method that

solves such a wide variety of tasks without any modiﬁcation, data preprocessing, feature extraction, even

without parametrization. We conclude that compression can be seen as the “core” of a yet to develop theory

of uniﬁed pattern recognition.

1 INTRODUCTION

Pattern recognition is a task that has to be solved

by many biological organisms and technical systems

alike. Though applicable solutions have been found in

branches like speech recognition or computer vision,

neither a unifying theory of pattern recognition ex-

ists nor even a broadly usable algorithmic method. To

date, almost any pattern classiﬁcation system is tai-

lored to a speciﬁc task — not only by its particular

processing design, but also by a concomitant usually

very careful parameterization. Almost all approaches

in pattern recognition, however, have one property in

common, regardless of the particular domain: They

use some kind of compressed representation of the

original input data, partly for redundancy reduction,

partly for ﬁltering out only the most discriminative

constituents.

In a vigorously discussed paper (Benedetto et al.,

2002), Benedetto et al. relate compression to pat-

tern recognition in an amazingly straightforward way:

They used the common

gzip

compressor for lan-

guage recognition (see also (Benedetto et al., 2003),

for comments see (Cho, 2002; Ball, 2002; Khmelev

and Teahan, 2003)). The method is surprisingly sim-

ple: There are n versions T

. . . T

of a text in differ-

ent languages. Each text ﬁle T

is compressed using

gzip

, the resulting bit length S(T

) of the compressed

ﬁle has to be memorized. Now the language i

∗

of a

new text T

∗

(written in one of the n languages) can be

recognized in the following way: T

∗

is appended to

each of the uncompressed texts T

. . . T

to obtain the

enlarged ﬁles T

∗

. . . T

∗

. Then the enlarged ﬁles are

compressed, their bit lengths being S(T

∗

). . . S(T

∗

The language i

∗

of T

∗

is then obtained by i

∗

argmin

(S(T

∗

) −S(T

)), i.e., given by the language

of the text T

∗

which exhibits the smallest increase

S(T

∗

) − S(T

) of its compressed length after append-

ing T

∗

The principle of this method is straightforward.

The

gzip

program is based on the Lempel-Ziv al-

gorithm (LZ77) (Lempel and Ziv, 1977), which de-

Heidemann G. and Ritter H. (2008).

ON THE CONTRIBUTION OF COMPRESSION TO VISUAL PATTERN RECOGNITION.

In Proceedings of the Third International Conference on Computer Vision Theory and Applications, pages 83-89

DOI: 10.5220/0001078000830089

 SciTePress

tects repeatedly occurring symbol sequences within

the data, such that a dictionary can be established. A

repeated symbol sequence can then be replaced by the

symbol deﬁned in the dictionary. Thus, it is not sur-

prising that compression of a text appended to another

one in the same language proﬁts from the availability

of shared constituents caused by the similarity of text

strings. However, the accuracy reported in (Benedetto

et al., 2003) is astonishing, it is possible not only to

recognize language and to attribute authorship, but to

reconstruct entire language trees.

The question arises if the good performance compres-

sion achieves for recognition is just the result of a ju-

dicious combination of a particular algorithm (LZ77)

with a particular recognition task (text). In this pa-

per, we investigate the two crucial questions that must

be answered to allow generalization of the results re-

ported by Benedetto et al.:

1. Text is a linear sequence of symbols, which makes

recognition by compression easy. It can thus be

objected that the method would fail for a more dif-

ﬁcult pattern recognition task, in particular, when

sensor data are to be evaluated. We will therefore

apply the method to three real world vision tasks.

2. Using compression for recognition might depend

on the particular way LZ77 performs compres-

sion, which explicitly searches for repeated sym-

bol sequences. We will therefore apply also an

alternative compression algorithm (

bzip2

) rely-

ing on different principles (Burrows and Wheeler,

1994; Hirschberg and Lelewer, 1990).

In this paper we will show that, surprisingly, both ob-

jections do not hold: Recognition by compression is

neither limited to text, nor is it bound to a particular

compressor. As a consequence, compression appears

to be a very essential aspect of pattern recognition and

may be a ﬁrst step towards a unifying theory. The ap-

proach can be connected with the concept of mutual

information (cf. Section 2.2), which has already been

used by several authors to gain a uniﬁed perspective

on various important operations in pattern recognition

systems (Sinkkonen and Kaski, 2002; Hulle, 2002;

Imaoka and Okajima, 2004; Erdogmus et al., 2004).

Section 2 describes the method itself, its theoretical

background and the applied compression algorithms.

In Section 3, experiments are carried out for three dif-

ferent problems: Object recognition, texture classiﬁ-

cation, and image retrieval. The concluding Section 4

discusses the results and implications.

2 COMPRESSION FOR

RECOGNITION

2.1 Method

Following the approach of Benedetto et al.

(Benedetto et al., 2002), we compare two images I

by considering the similarity measure

Comp

, I

) = S(I

) + S(I

) − S(I

), (1)

where S(.) denotes the bit size of a compressed im-

age. I

is the “joint” image obtained as juxtaposi-

tion of pixel arrays I

and I

. In the experiments de-

scribed in Section 3, both images I

and I

are ﬁrst

compressed in isolation to obtain the bit size S(I

) and

S(I

) of their compressed representation, respectively.

The original images I

and I

are then merged to be-

come a single image I

. Compressing the merged

image I

yields the bit size S(I

Note that the method is applied to the raw images,

without any preprocessing or adaptation.

2.2 Theoretical Background

The idea of Eq. (1) lies in information theory, which

relates the size of the shortest possible message length

for an information source I to its entropy H(I). The

compression factor, i.e. the bit length of the output

of a compressor algorithm divided by the bit length

of the uncompressed message can, therefore, be seen

as an approximation of its entropy H(I) — as long

as the compressor works close to optimal. For LZ77,

the compression factor indeed tends to H(I) when the

length of the message tends to inﬁnity (Lempel and

Ziv, 1977; Wyner, 1994).

Thus, D

Comp

, I

) can be seen to approximate the

mutual information H(I

, I

) of I

and I

, which in

information theory measures the amount of informa-

tion that I

can predict about I

and vice versa (Cover

and Thomas, 1991). A large positive value of D

Comp

thus indicates that I

and I

are very similar, while the

smallest possible value of zero is obtained when the

two images are completely unrelated. D

Comp

, I

)

measures similarity, but can not be used as a distance

measure in a strict sense.

The idea to judge pattern similarity by compres-

sion properties is not new per se and is related to

the Minimum-Description-Length (MDL) principle

for model selection (Rissanen, 1978; Vitanyi and Li,

1996). In image processing, MDL has been applied as

a global criterion to optimize segmentation (Leclerc,

1989; Keeler, 1990; Kanungo et al., 1994). How-

ever, such approaches operate on the level of regions,

VISAPP 2008 - International Conference on Computer Vision Theory and Applications

which are deﬁned by task dependent similarity cri-

teria. So, the uses of compression-based and related

methods were restricted to low-dimensional data. Ap-

plication on raw data (of much higher dimension)

helps not only avoid the problematic stage of feature

extraction, but opens up the possibility to treat signals

stemming from different sources in a uniﬁed way.

2.3 Compression Algorithms

We used two standard lossless compression tools

which rely on different principles: The

gzip

pro-

gram

, which is based on LZ77 (Lempel and Ziv,

1977), and the

bzip2

program

bzip2

was cho-

sen for comparison with

gzip

because it relies on

a completely different compression technique: the

Burrows-Wheeler block sorting text compression al-

gorithm (Burrows and Wheeler, 1994) with sub-

sequent Huffman coding (Hirschberg and Lelewer,

1990). Thus, it can be shown that the ability to judge

pattern similarity is not a result of the particular way

LZ77 builds up a compressed representation.

2.4 Discussion of the Similarity

Measure

There are obvious methods that would improve the

performance of the approach. In particular, special-

ization to the domain of images would probably in-

crease recognition rates:

•

gzip

and

bzip2

perform lossless compression.

But to judge image similarity, minor variation of

gray values should be tolerated. So, tuning the

compressors to a certain level of data loss would

probably improve performance.

• The compression algorithms are neither optimal

to approximate the mutual information, nor are

they the best compression techniques on the mar-

ket. Compression can be improved when algo-

rithms specialized to a particular data type are

used.

• The measure is applied only for judging similarity

of complete images. An additional segmentation

would help to identify objects or patterns in the

presence of varying background, however, seg-

mentation is a specialized computer vision tech-

nique.

But we did not make use of any of these measures,

since this would destroy the simplicity of the method

In version

gzip 1.2.4

available from

http://www.gzip.org

In version

bzip2 1.0.1

, available from

http://sources.redhat.com/bzip2

and its universal applicability to entirely different data

domains. It is not the aim of this paper to build an ac-

tually usable recognition system but to demonstrate

the capability of the approach in a way easy to re-

produce and transferable to other domains. For this

demonstration,

gzip

and

bzip2

were used in their

original Unix-implementation without any modiﬁca-

tion.

3 EXPERIMENTS

3.1 Object Recognition

The ﬁrst experiment was an object recognition task.

Images were taken from the COIL-100 library (Nene

et al., 1996), which is a standard benchmark data set

for object recognition

. It comprises for each of 100

different objects 72 rotational views (128 × 128 pixel

resolution, 5

rotation angle separation) of the object

centered on a dark background. Since color facilitates

recognition, we discarded color information and used

only the gray level version of each image.

For each test, the COIL-100 was partitioned into a

set M

of “memorized” object views and the comple-

mentary set U

of “unknown” object views. Several

test sets were created, whose partitions differed by

the chosen view angle spacing α of successive views

selected for the “memorized” set M

(e.g., M

con-

tains poses of 0, 15, 30 . . . degrees and U

poses of

5, 10, 20, 25. . . degrees).

For recognition of an unknown image I

∈ U

computed its similarities D

Comp

, I

) with each of

the memorized images I

∈ M

, using Eq. (1) and

either

gzip

bzip2

to obtain the size values S(.).

The memorized image I

leading to maximal D

Comp

was then taken to identify the “unknown” image I

Figure 1 shows the results of the object classiﬁca-

tion task. Naturally, object representations including

more memorized views (smaller angular spacing α)

lead to better recognition. For α = 10

gzip

reaches

99.4% correct classiﬁcations (chance level is 1%).

Remarkably, even for very sparse sampling recogni-

tion is considerable: α = 120

(3 views) still leads to

82.0% correct classiﬁcations. Different levels of com-

pression by which the tradeoff between computational

efﬁciency and compression factor can be inﬂuenced

lead only to minor performance changes.

To give an estimate of the difﬁculty of the task,

two complementary basic methods were used: Corre-

lation based matching shows how much of the recog-

Available from

http://www.cs.columbia.edu/

CAVE/research/softlib/coil-100.html

ON THE CONTRIBUTION OF COMPRESSION TO VISUAL PATTERN RECOGNITION

100

360

180

120

Correct classifications [%]

Spacing of memorized views [deg]

Number of views

gzip

bzip

Corr

Hist

Error [%]

gzip gzip gzip bzip2 Corr Hist

level 1 default level 9

2.83 %

1.70 %

1.72 %

9.81 %

5.28 %

10.1 %

α = 20

Figure 1: Object recognition results for a gray value version

of COIL-100. Compression based on

gzip

performs better

than correlation based matching, histogram matching, and

compression using

bzip2

Above: The percentage of correct classiﬁcations decreases

with the number of memorized object views. The advantage

gzip

becomes clear especially for large angular spacing

α of memorized views.

Below: Error rates for a ﬁxed angular spacing α = 20

memorized views.

gzip

is superior for all compression

levels. Compression level 1 biases the tradeoff between

compression and speed for best speed, level 9 for compres-

sion. The default setting selects level 6 as a compromise

between these two.

nition results can be explained by a simple compar-

ison of the spatial gray value distribution, whereas

gray value histogram matching is independent of the

spatial structure. For classiﬁcation from correlation,

instead of D

Comp

the similarity measure D

Corr

based

on the pixel correlation of the normalized images

and

was used:

Corr

, I

) =

∑

(x, y) ·

(x, y) with k

1,2

k = 1. (2)

100

Error [%]

gzip bzip2 Corr Hist

22.0 %

25.0 %

94.0 %

51.0 %

Figure 2: Recognition results for 50 gray level VisTex tex-

ture image pairs.

gzip

and

bzip2

outperform correlation

based matching and histogram matching.

Histogram based similarity is calculated by

Hist

, I

) = −

∑

i=1

) −C

))

, (3)

where C

) denotes the count of pixels of image I

with gray values in histogram bin i ∈ {1. . . q}. We

use bin boundaries equidistant in the range [0. . . 255].

Throughout the paper a value q = 6 was used because

on average it yields the best results.

Comp

based on

gzip

performs clearly much bet-

ter than both D

Corr

and D

Hist

(Figure 1), which in-

dicates that

gzip

implicitly uses a combination of

the spatial structure and the gray value frequencies

for recognition.

bzip2

performs between D

Corr

and

Hist

, but as correct classiﬁcation is still over 90%,

results are good also for

bzip2

3.2 Texture Classiﬁcation

In the second experiment, the capability of D

Comp

discriminate textures was tested. From the VisTex

database (Picard et al., 1995) 50 image pairs were se-

lected, each showing two different views of the same

texture at resolution 512 ×512 pixels and transformed

to gray scale. The database comprises both natural

and artiﬁcial textures and includes difﬁculties like dif-

ferent perspectives, scaling and distortions. This time,

the sets M and U were formed of all “ﬁrst” and “sec-

ond” views of the 50 pairs, respectively. Figure 2 de-

picts the percentage of errors in assigning views of U

to their partner views in M. Both

gzip

and

bzip2

reach much better results than correlation and his-

togram matching. Naturally, techniques specialized

on texture classiﬁcation would yield still better re-

sults, but it has to be kept in mind that D

Comp

is treated

here as a general purpose recognition method.

VISAPP 2008 - International Conference on Computer Vision Theory and Applications

3.3 Image Retrieval

With the upcoming of large image collections on the

Internet or in databases, a major challenge is image

retrieval and indexing. The inherent diversity of this

domain makes the extraction of good general features

particularly difﬁcult. Consequently, retrieval systems

still mostly rely on color and texture information,

while potentially more powerful structural features

are only rarely exploited (for an overview see e.g.

(Smeulders et al., 2000)).

Therefore, in the third experiment it was tested

if LZ77 can discriminate image categories. As a

database, 20 categories were formed from the Corel

database (Corel, 1997), each consisting of 80 images.

Since for some categories color is known to provide

an exceptional feature that facilitates discrimination,

again all images were transformed to gray level. Fig-

ure 4 shows some example images.

A typical retrieval task is to ﬁnd similar images by

100

Error [%]

gzip bzip2 Corr Hist chance

26.2 %

20.4 %

72.5 %

43.6 %

95.0 %

100

654321

Success rate

Number of returned images

gzip

bzip2

Corr

Hist

chance

Figure 3: Recognition results for the retrieval task.

Above: Error rates if only one image is returned for a query

(k = 1), this case resembles a mere classiﬁcation-type task.

Below: In an actual retrieval system, usually more than one

image is returned (k > 1). A query is counted a “success” if

at least one image of the correct category is returned.

speciﬁcation of a query image. We calculated for each

of the 1599 non-query images the k images that were

most similar to the query image in terms of D

Comp

A query was counted a success if among the k query

results there was at least one of the correct category.

Figure 3 shows the results: Even for k = 1, about three

out of four query results yield the correct category, for

k = 4, the success rate rises to over 90% for both

gzip

and

bzip2

. This last experiment appears particularly

impressive, because most visual categories are much

broader than single object classes (Tarr and B

ulthoff,

1998).

4 CONCLUSIONS

For each of the three types of tasks presented here

carefully specialized recognition architectures exist

(e.g. (Murase and Nayar, 1995; Paulus et al., 2000;

Rui et al., 1999; Laaksonen et al., 2000)), which can

achieve better results, at least in the case of object

and texture recognition. What makes the compression

based approach unique is its simplicity and applicabil-

ity to entirely different types of domains: Without any

designed feature extraction and without tuning of pa-

rameters, even “of the shelf” compression programs

achieve remarkable results for vision tasks as well as

text. Most astonishing appears the performance for

image retrieval based on gray values — most such

systems heavily depend on color (Smeulders et al.,

2000).

Naturally, the unmodiﬁed

gzip

and

bzip2

pro-

grams are not yet the optimal or fastest solution for

entropy approximation — they were chosen to illus-

trate the principle in a “pure” and reproducible form.

As pointed out in (Khmelev and Teahan, 2003), nth

order Markov chain models outperform

gzip

on cer-

tain text recognition tasks. But the fact that the results

do not depend on the particular choice of LZ77 raises

hope that compression is a fundamental mechanism

that will open up a new perspective on pattern recog-

nition. Though we do not yet have a universal theory

of pattern recognition, compression is very likely to

be one of its key components.

ON THE CONTRIBUTION OF COMPRESSION TO VISUAL PATTERN RECOGNITION

Figure 4: As a retrieval task, query images had to be found in 20 categories, each comprising 80 gray level images (color

was discarded). Here, 12 categories are shown by four images each. From left to right and top to bottom: “Polo”, “blos-

soms”, “mushrooms”, “desert”, “porcelain”, “stalactite caves”, “food on the table”, “interiors: hotels”, “surﬁng”, “interiors:

kitchens”, “busses”, “car racing”. The complete dataset can be made available on demand.

VISAPP 2008 - International Conference on Computer Vision Theory and Applications

REFERENCES

Ball, P. (2002). Algorithm makes tongue tree. Nature Sci-

ence Update.

Benedetto, D., Caglioti, E., and Loreto, V. (2002). Lan-

guage Trees and Zipping. Phys. Rev. Lett., 88(4).

Benedetto, D., Caglioti, E., and Loreto, V. (2003). Zipping

out relevant information. Computing in Science and

Engineering, 5:80–85.

Burrows, M. and Wheeler, D. J. (1994). A Block-sorting

Lossless Data Compression Algorithm. Research Re-

port 124, Digital Systems Research Center.

Cho, A. (2002). Reading the Bits of Shakespeare. Scien-

ceNOW.

Corel (1997). Corel GALLERY

Magic 65000. Corel

Corp., 1600 Carling Ave., Ottawa, Ontario, Canada

K1Z 8R7.

Cover, T. M. and Thomas, J. A. (1991). Elements of Infor-

mation Theory. Wiley, New York.

Erdogmus, D., Hild, K. E., Rao, Y. N., and Pr

ıncipe, J. C.

(2004). Minimax Mutual Information Approach for

Independent Component Analysis. Neural Computa-

tion, 16(6):1235–1252.

Hirschberg, D. S. and Lelewer, D. A. (1990). Efﬁcient De-

coding of Preﬁx Codes. Communications of the ACM,

33(4):449–459.

Hulle, M. M. V. (2002). Joint Entropy Maximization in

Kernel-Based Topographic Maps. Neural Computa-

tion, 14(8):1887–1906.

Imaoka, H. and Okajima, K. (2004). An Algorithm for

the Detection of Faces on the Basis of Gabor Features

and Information Maximization. Neural Computation,

16(6):1163–1191.

Kanungo, T., Dom, B., Niblack, W., and Steele, D. (1994).

A fast algorithm for MDL-based multi-band image

segmentation. In Proc. Conf. Computer Vision and

Pattern Recognition CVPR.

Keeler, A. (1990). Minimal length encoding of planar sub-

division topologies with application to image segmen-

tation. In AAAI 1990 Spring Symposium of the Theory

and Application of Minimal Length Encoding.

Khmelev, D. V. and Teahan, W. J. (2003). Comment on

”Language Trees and Zipping”. Physical Review Let-

ters, 90(8):089803–1.

Laaksonen, J. T., Koskela, J. M., Laakso, S. P., and Oja,

E. (2000). PicSOM – Content-Based Image Retrieval

with Self-Organizing Maps. Pattern Recognition Let-

ters, 21(13-14):1199–1207.

Leclerc, Y. G. (1989). Constructing simple stable descrip-

tions for image partitioning. Int’l J. of Computer Vi-

sion, 3:73–102.

Lempel, A. and Ziv, J. (1977). A Universal Algorithm for

Sequential Data Compression. IEEE Trans. Inf. Th.,

23(3):337–343.

Murase, H. and Nayar, S. K. (1995). Visual Learning and

Recognition of 3-D Objects from Appearance. Int’l J.

of Computer Vision, 14:5–24.

Nene, S. A., Nayar, S. K., and Murase, H. (1996). Columbia

Object Image Library: COIL-100. Technical Report

CUCS-006-96, Dept. Computer Science, Columbia

Univ.

Paulus, D., Ahrlichs, U., Heigl, B., Denzler, J., Horneg-

ger, J., Zobel, M., and Niemann, H. (2000). Active

Knowledge-Based Scene Analysis. Videre, 1(4).

Picard, R., Graczyk, C., Mann, S., Wachman, J., Picard,

L., and Campbell, L. (1995). Vision Texture Database

tute of Technology.

Rissanen, J. (1978). Modeling by Shortest Data Descrip-

tion. Automatica, 14:465–471.

Rui, Y., Huang, T. S., and Chang, S.-F. (1999). Image Re-

trieval: Current Techniques, Promising Directions and

Open Issues. J. of Visual Communications and Image

Representation, 10:1–23.

Sinkkonen, J. and Kaski, S. (2002). Clustering Based on

Conditional Distributions in an Auxiliary Space. Neu-

ral Computation, 14(1):217–239.

Smeulders, A. W. M., Worring, M., Santini, S., Gupta, A.,

and Jain, R. (2000). Content-Based Image Retrieval

at the End of the Early Years. IEEE Trans. on Pat-

tern Analysis and Machine Intelligence, 22(12):1349–

1380.

Tarr, M. J. and B

ulthoff, H. H. (1998). Image-Based Object

Recognition in Man, Monkey and Machine. Cogni-

tion, 67:1–20.

Vitanyi, P. M. B. and Li, M. (1996). Ideal MDL and its

Relation to Bayesianism. In Proc. ISIS: Information,

Statistics and Induction in Science World Scientiﬁc,

pages 282–291, Singapore.

Wyner, A. D. (1994). 1994 Shannon Lecture. Typical Se-

quences and All That: Entropy, Pattern Matching, and

Data Compression. AT & T Bell Laboratories, Murray

Hill, New Jersey, USA.

ON THE CONTRIBUTION OF COMPRESSION TO VISUAL PATTERN RECOGNITION
