EFFICIENT OBJECT DETECTION USING PCA MODELING AND

REDUCED SET SVDD

Rudra N. Hota and Venkataramana Kini B.

Research and Technology Unit, Honeywell Technology Solutions Lab, Bangalore, India

Keywords:

Object Detection, PCA modeling and reduced set SVDD.

Abstract:

Object detection problem is traditionally tackled as two class problem. Wherein the non object classes are

not precisely deﬁned. In this paper we propose cascade of principal component modeling with associated test

statistics and reduced set support vector data description for efﬁcient object detection, both of which hinge

mainly on modeling of object class training data. The PCA modeling enables quick rejection of comparatively

obvious non object in initial stage of the cascade to gain computation advantage. The reduced set SVDD is

applied in latter stages of cascade to classify relatively difﬁcult images. This combination of PCA modeling

and reduced set support vector data description leads to a good object detection with simple pixel features.

1 INTRODUCTION

The object detection is a process of isolating the ob-

ject of interest from it’s surroundings, e.g. detection

of people in an image snapshot. We human beings

can do this effortlessly but when it comes to doing the

same automatically by using machines we encounter

many problems, in terms of scales at which they are

present, orientation, illumination etc.

Traditionally in machine learning paradigm of ob-

ject detection problem is tackled using two class prob-

lem, i.e. by having positive and negative class (ob-

ject and non-object classes respectively) training data

sets. The training procedure strives to ﬁnd a optimal

boundary between these two classes in the space of

features with the expectation of good generalization.

This kind of approach is followed successfully ((Vi-

ola and Jones, 2001), (Romdhani et al., 2001), (Row-

ley et al., 1997)) by the researchers by having variety

of object class data in terms of several thousands and

hundred thousands from non-object class. It is nat-

ural to include variety of data (by applying different

afﬁne transformations such as orientation, scale and

with different illumination) for positive class, but for

negative class we can not deﬁne precisely what is va-

riety of data to collect. Hence, the negative class re-

mains ill deﬁned. We could collect few hundreds of

thousands (or more) of negative class data, but it is

insufﬁcient as negative class is of virtually inﬁnite in

size.

Another framework for object detection problem

often used by the machine learning community is

of developing a model /data description (which de-

scribes structure in the data) only for the positive

class. The negative class data is used mostly for ﬁne

tuning of the boundary around positive class. The

classiﬁcation (detection in true sense) involves look-

ing for object features in given image. If such features

are found, then object is detected otherwise the image

is labeled as non-object.

The simple model for this kind of approach is

Principal Component Analysis(PCA). This appears to

be natural way of describing the objects. The PCA

features in the form of eigenfaces (Moghaddam and

Pentland, 1997) has been applied successfully for face

recognition and related tasks. In this paper we uti-

lize PCA features for describing the structure in tar-

get object class data. The test data is projected onto

this model represented by major principal directions.

These principal directions being few in number, lead-

ing to quick rejection of obvious negative samples.

We utilize the test statistics which are traditionally

used in fault detection (Venkatasubramanian et al.,

2003) (Yue and Qin, 2001) community. These statis-

tics provide thresholds which are effectively used to

discard non-object images. Here, it should be noted

that the PCA model is used as a coarse model for

object class data, the different directions might have

different discriminatory power (Sun et al., 2002), but

overallmodel for object class based on dominantprin-

222

N. Hota R. and Kini B. V. (2008).

EFFICIENT OBJECT DETECTION USING PCA MODELING AND REDUCED SET SVDD.

In Proceedings of the Third International Conference on Computer Vision Theory and Applications, pages 222-227

DOI: 10.5220/0001079402220227

 SciTePress

cipal directions gives an envelop around object class

data and provides strategy for quick rejection of non-

object class data.

The kernel methods have been proposed for the

task developing data based models as well. The

traditional data based modeling technique PCA is

extended to handle higher order correlations in the

data by mapping into higher dimensional feature

space - Kernel Principal Component Analysis(KPCA)

(Scholkopf et al., 1998). It is simple enough com-

pared to PCA in terms of just ﬁnding eigen value

decomposition. It ﬁnds the uncorrelated features in

higher dimensional space, explaining structure of pos-

itive class data. But in object detection problems as

we use many thousands of object class data for train-

ing of KPCA, the run-time computational complexity

blows up.

In this work, we applied cascaded structure for

object detection, in which the removal negative sam-

ples are taken care in different stages according to

their degree of closeness to positive class distribution.

Therefore, it it required to have strong classiﬁers in

the later stages for separating difﬁcult negative sam-

ples from positive class. Hence, for discriminating

non-objects which are like objects, we need to resort

to strong classiﬁers (Heisele et al., 2003). Tradition-

ally artiﬁcial neural networks are developed as strong

classiﬁer. However, neural networks demand lengthy

training, convergence of the training process is some-

times uncertain and choice of network architectures

remains somewhat of an art. In early 1990s, the kernel

methods (Vapnik, 1999) such as Support Vector Clas-

siﬁers(SVC), regressors are developed for classiﬁca-

tion and function approximation tasks. The advan-

tage of these methods over neural network methods is

that they implicitly solve the nonlinear problem. Also

they exhibit good generalization capability because of

their regularization properties.

Another data based modeling technique in ker-

nel feature space is Support Vector Data Description

(SVDD)(Tax and R.P.W, 2004). It tries to ﬁnd a en-

closing sphere of minimal volume for positive class

data in high dimensional feature space unlike SVC,

which tries to ﬁnd the hyperplane between positive

and negative class training data. This kind of model is

particularly suited for object detection problem (Seo

and Ko, 2004) (Tax and R.P.W, 2004). But, the daunt-

ing disadvantage with SVDD when applied to object

detection is the number of kernel computations in-

volved. The number of kernel computations involved

is order of the number of support vectors generated

during training procedure. In typical problems of ob-

ject detection (face detection and people detection)

that we are targeting, these support vectors are as high

as few thousands. Because of these high number of

Support Vectors (SVs) the computational cost may be

sometimes between half a minute to few minutes.

In this paper to tackle this computational cost, we

propose to “leverage the technique of reducing the

number of support vectors (Romdhani et al., 2001)

into SVDD”. The number of support vectors can

be reduced to few hundreds from thousands without

compromising much on accuracy.

The quick rejection of non-object data using lin-

ear PCA and associated test statistics, followed by

Reduced Set SVDD leads to a good balance between

speed and accuracy. Hence, we propose a efﬁcient

(both in terms of speed and accuracy) method for the

problem of object detection by novel cascade of lin-

ear PCA modeling and series of Reduced Set SVDD

(RSSVDD) with increasing number of reduced set

SVs.

The outline of the paper is as follows. The method

for quick rejection based on PCA modeling is ex-

plained in next section. The RSSVDD is explained in

section 3. The overall approach of cascaded PCA and

RSVDDs is explained in section 4. Section 5 gives ex-

periments and results of object detection (speciﬁcally

on face data). In section 6 we draw some conclusions

of this work and plans for future work.

2 PCA MODELING OF OBJECT

CLASS AND THRESHOLDING

STATISTICS

PCA is a versatile data analysis tool. It can be consid-

ered as data modeling tool, the major principal com-

ponents capturing most of the variance in the covari-

ance matrix of data. The rest of the components are

assumed to represent noise in the data. The steps in-

volved in PCA modeling is summarized in below al-

gorithm. PCA based feature extraction has received

considerable attention in computer vision area. In

previous works (Moghaddam and Pentland, 1997) the

image is represented by features in a low dimensional

space spanned by the principal components. These

features are further utilized in classiﬁer. PCA is pre-

dominantly used for extracting features and dimen-

sionality reduction, the modeling perspective is miss-

ing.

PCA is traditionally applied by Chemometrics with

modeling perspective for the purpose of fault detec-

tion. Fault detection using PCA models is normally

accomplished by applying two statistics. The squared

prediction error SPE , which indicates the amount by

which a sample deviates from the model, is deﬁned

EFFICIENT OBJECT DETECTION USING PCA MODELING AND REDUCED SET SVDD

223

Table 1: Algorithm for PCA model training on Object class

data.

1. Given the data set X = x

. . .x

from object class ﬁnd the mean vector

µ =

∑

2.Find the covariance matrix C =

n−1

∑

− µ)(x

− µ)

′

3.Eigen value decompose the covariance matrix C = PΛP

4. Choose the principal components

P corresponding dominant eigen

values and remaining eigen vectors

P represent minor components.

SPE = x

′

x (1)

Hotellings T

statistic, which measures deviation of a

sample inside the model, takes the form

= x

′

PΛ

−1

′

x (2)

Both of these indices follow chi square distribution

under the normality assumption of object class data.

The δ

and τ

limits (for SPE and T

respectively)are

found for given conﬁdence level. It is to be noted

that SPE departs from limits whenever the covariance

structure breaks down, where as T

violation happens

whenever the different contributors (PCA scores) go

out of range. For object detection problem, when-

ever any one of these indices crosses limits, we can

infer that image is from non-object class. Therefore it

makes sense to combine them. (Yue and Qin, 2001)

has proposed combination index deﬁned as:

ρ = c

SPE

+ (1− c)

, c ∈ (0, 1) (3)

Since ρ is linear combination of T

and SPE the limits

can be found using chi square distribution.

3 REDUCED SET SVDD

First we introduce the notation by explaining SVDD

(Tax and R.P.W, 2004) in input space. Given the

positive class data-set, SVDD tries to ﬁnd enclosing

sphere around data which has minimum volume. By

minimizing the sphere volume, SVDD minimizes the

detection error (i.e. the chance of accepting outlier

objects).

Given positive class data X = {x

. . . x

} the

SVDD attempts to ﬁnd a hyper-sphere with center c

and radius R which encloses most of the data, i.e. the

volume of the hyper-sphere is minimized. That is to

minimizing the objective function:

F(R, c) = R

s.t.kx

− ck

≤ R

∀i (4)

The positive class data set might contain some out-

liers. To allow such possible outliers, introducing

slack variables ξ

into 4 leads to primal solution:

F(R, c) = R

∑

s.t.kx

− ck

≤ R

+ ξ

≥ 0 ∀i (5)

The parameter C is a regularization parameter. In-

troducing Lagrange multipliers and setting the partial

derivatives w.r.t. R, c and ξ

leads to dual solution:

L =

∑

· x

) −

∑

i, j

· x

) (6)

When 0 < α

< C implies kx

− ck

= R

, i.e. these

data points lie on boundary of SVDD solution. For

any test data point x, label is decided to be belonging

to object class based on distance to center smaller or

equal than the radius:

kx− ck

= (x· x)− 2

∑

(x·x

) −

∑

i, j

· x

) ≤ R

(7)

is found by substituting for x with any of the SVs.

For ﬂexible data descriptions the dot products are

replaced by corresponding kernel dot products, i.e.

x 7→ Φ(x). Also the negative data objects can be uti-

lized in ﬁne tuning the data description boundary of

SVDD (Tax and R.P.W, 2004).

As discussed in introduction, (section 1) the solu-

tion generated by SVDD involves large percentage of

data points as SVs, resulting in high run-time com-

plexity in object detection problems.

In this work, the methodology adopted to reduce

the number of SVs is derived from (Romdhani et al.,

2001). Let N

number of SVs obtained for SVDD

training. The sum of SVs weighted by non-zero α is

given by

Ψ =

∑

i=1

Φ(x

) (8)

By approximating the N

number of SVs by new N

number of SVs we can reduce the computationalcom-

plexity. The approximation of Ψ is:

Ψ =

∑

i=1

Φ(ˆx

) (9)

Where, β ∈ ℜ and ˆx

are approximate SVs. We can

usually achieve N

≪ N

with out loss of much ac-

curacy. To achieve this, (Romdhani et al., 2001) has

suggested to minimize the norm kΨ−

Ψk

, which can

VISAPP 2008 - International Conference on Computer Vision Theory and Applications

224

−10 −5 0 5

−10

−5

Feature 1

Feature 2

−10 −5 0 5

−10

−5

Feature 1

Feature 2

−10 −5 0 5

−10

−5

Feature 1

Feature 2

(a) (b) (c)

Figure 1: Dotted boundary represents (a) RSVDD with 30% SVs (b) RSVDD with 40% SVs (c) RSVDD with 60% SVs.

Table 2: Algorithm for RSSVDD training on Object class.

1. Given the data set X = x

. . . x

ﬁnd ﬁnd SVs using SVDD algorithm

2.Find the reduced set SVs by minimizing kΨ−

Ψk

3. Choose the cascade of RSSVDDs starting from a minimum number

of reduced set SVs decided based on classiﬁcation performance on

training data set

be rewritten in terms of only kernel dot products.

They also provide an iterative algorithm for ﬁnding

reduced SVs, starting from one SV. The Figure 1

shows a simple banana data example, wherein star

shaped positive class data is modeled using differ-

ent percentages of original SVs. The solid line en-

velop around positive class represents original SVDD

boundary. The algorithm for RSSVDD is summarized

in Table 2.

4 OUR APPROACH - EFFICIENT

CASCADE OF PCA AND SVDD

ALGORITHM FOR OBJECT

DETECTION

In object detection problems, such as face detection,

the object can occur at any position of the image and

in several scales. Under such cases the automated

object detection algorithm has to search the image

either with a ﬁxed size of sub-window in a pyramidal

structure or by varying the scale of the search window

starting from a desired scale. For a standard size

image the percentage of sub-windows containing

target object is usually less than one percent of

windows to be scanned for the whole image. This

problem demands a coarse-to-ﬁne cascade classiﬁer

strategy to search the target object, i.e. in the initial

stage of the detector it should be able to remove as

many negative patterns as possible, retaining almost

all positive patterns. As the level increases the task of

separating the object like negative class objects from

the target object becomes tougher. Hence cas-

caded classiﬁer with better accuracy at later stage

(where we can afford higher computational complex-

ity) of the detector is suitable. Our approach uses

cascade of linear PCA model followed by series of

one-class RSSVDD classiﬁers with increasing num-

ber of support vectors. There are many possible good

features for face detection, presented in literature.

For simplicity we consider only pixel values of the

image sub-window as feature vector. Our method can

also be applied with other sophisticated features

Table 3: Algorithm for Object detection using PCA and

RSVDD cascaded classiﬁers.

1. Training: Given target object class image data X = {x

. . .x

} perform

(1.a) PCA model training (Table 1) and ﬁnd the threshold by using

equation (3)

(1.b) SVDD training and ﬁnd Reduced set SVs (Table 2), decide

on minimum number of RSSV

2. Testing: Given the test image, form the sub-windows and for

each vector x representing sub-window

(2.a) Project x onto principal directions found in (1.a) and

if it crosses the threshold,

discard the sub-window as non-object and continue with

new sub-window,

else

Start with RSSVDD with least number of SVs in cascade, if

accepted by current RSVDD continue with next RSVDD in

cascade until ﬁnal RSVDD is reached, label accordingly.

(Gabor, Haar wavelet, etc.) to improve the perfor-

mance. The overall approach (training and testing) is

explained in below algorithm.

5 EXPERIMENTS AND

DISCUSSION

Usually, in object detection problem the number neg-

ative sample is much more as compared to that of

positive samples. This is because the negative class

is always ill deﬁned as we have discussed in ear-

lier section. To discard comparatively easier negative

samples we applied PCA modeling and more difﬁcult

false alarms are handled by reduced set SVDD in cas-

EFFICIENT OBJECT DETECTION USING PCA MODELING AND REDUCED SET SVDD

225

0 0.5 1 1.5 2 2.5 3

100

150

200

250

300

350

400

450

Combined Test Statitic

Frequency

Figure 2: Quick rejection of non faces using PCA with test

statistics.

30 40 50 60 70 80 90 100

9.5

10.5

11.5

12.5

# of SVs

% of False alarm

Figure 3: Percentage of reduced SVs vs false alarm rate.

caded structure.

Data set: In our experiments of face

detection we used CBCL face data set

[http://www.ai.mit.edu/projects/cbcl/ software-

dataset/index.html], which contains 2429 faces and

4585 non face samples for training and 472 faces

and 23573 non face sample for testing. For our

experiment we have selected randomly 2000 each

from face and non-face samples from training set for

training purpose and rest of the samples are used for

testing.

After applying initial ﬁltering by PCA model with

associated combined test statistics the negative pat-

terns which are difﬁcult to classify are fed to SVDD.

The PCA model is able to discard more than 50%

of non-face class data, retaining almost all face class

data. The number of principal components retained

is equal to the components which captures 90% of

the variance (which is equal to 8 principal direc-

tions). The threshold based on chi square distribu-

tion is found to be equal to 1.08 (with c = 0.5 as

shown in Figure 2 by dashed vertical line. The two

frequency curves (solid and dashed respectively) rep-

resents frequency with which face class data and non-

face class data appears corresponding to combined

statistic. Here, randomly 2000 number face and non

face class data is utilized to show the quick rejection

capability of non-faces at the same retaining almost

all face class data. Out of these 2000 face class data

Table 4: Performance of RSSVDD on Face detection.

% of SV retained Detection rate False Alarm

(%) (%)

100 94 9.5

60 94 10

40 94 9.8

30 94 12

PCA Modeling

with

Test Statistics

Reduced Set

SVDD

(40% SVs)

SVDD

Figure 4: Cascade structure for face detection.

700 data points which have higher value of ρ (eqn 3)is

retained for SVDD training and non-face data which

have ρ less than 1.5 retained for ﬁne tuning of SVDD

boundary in next stage of cascade. The detection rate

on test data the by applying PCA model is found to be

99.3% with false alarm rate of 58%.

With the data retained by PCA we analyzed the

performance of SVDD by increasing the number of

reduced support vectors (as explained in section 3).

By using 100% of the support vectors for the trained

SVDD we achieved 94% detection accuracy during

testing with 9.5% of false alarm. By reducing the

support vector to 30% (originally SVDD training pro-

duced 139 SVs from 700 face class training data) the

false alarm rate increases to near about 12% with re-

taining same accuracy of detection rate. With 40%

and 60% of SVs, the false alarm rate further reduces

to around 10% and 9.8% respectively. The plot of

percentage of support vectors vs false alarm rate is

depicted in Figure 3. Further increase in reduced set

of support vectors lead to better performance in terms

of lesser false alarm at the same level of detection

rate. This can be because of some generalization ca-

pability provided by approximate reduced SVs. When

we reduce the SVs by certain percentage, the runtime

computational complexity also reduced by approxi-

mately same percentage. Hence, we could reduce the

runtime computational complexity of SVDD with out

much compromising on the accuracy (false alarm in-

creased by just 0.3% when SVs reduced to 40% from

100% with same detection rate). Therefore, we pro-

pose a cascade structure shown in Figure 4 for face

detection problem. The combination of PCA model-

ing and RSSVDD drastically reduced overall compu-

tational complexity by about 80% as compared to a

single monolithic SVDD classiﬁer.

It is to be noted that in (Seo and Ko, 2004) by us-

ing the color information in SVDD false alarm rate

VISAPP 2008 - International Conference on Computer Vision Theory and Applications

226

was as low as 1% at same detection rate as that of

our experiments. Hence, by making use of color fea-

tures or other sophisticated features and preprocess-

ing techniques the false alarm rate can be reduced

substantially. However, in this work the goal was to

show the efﬁcacy of the PCA and RSSVVD cascade

approach for the problem of face detection.

6 CONCLUSIONS AND FUTURE

WORK

In this paper we proposed cascade of PCA model-

ing with associated test statistic and reduced set sup-

port vector data description for efﬁcient object detec-

tion. The PCA modeling enabled quick rejection up to

40− 50% of comparatively obvious non-faces to gain

computation advantage. The reduced set SVDD ap-

plied in later stage of cascade to classify relatively dif-

ﬁcult images. This novel combination of PCA mod-

eling and RSSVDD lead to good face detection at re-

duced computational cost by using only simple pixel

features.

Motivated by these results, in future we plan to ap-

ply this approach to other object detection tasks such

as vehicle, people detection. Further in future we plan

to improve the performance of object detection using

more sophisticated feature set.

REFERENCES

Heisele, B., Serre, T., Prentice, S., and Poggio, T. (2003).

Hierarchial classiﬁcation and feature reduction for fast

face detection with support vector machines. In Pat-

tern Recognition Society.

Moghaddam, B. and Pentland, A. (1997). Probabilistic vi-

sual learning for object representation. In IEEE Trans-

actions on Pattern Analysis and Machine Intelligence.

Romdhani, S., Torr, P., Scholkopf, B., and Blake, A. (2001).

Computationally efﬁcient face detection. In 8th Int.

Conf on Computer vision.

Rowley, H. A., Baluja, S., and Kanade, T. (1997). Rota-

tion invariant neural network based face detection. In

Computer Science technical report CMU-CS-97-201.

Scholkopf, B., Smola, A., and Muller, K. (1998). Nonlinear

component analysis as a kernel eigenvalue problem.

In Neural Computation, 10(5):1299-1319.

Seo, J. and Ko, H. (2004). Face detection using support

vector domain description in color images. In ICASSP,

54, 4566,.

Sun, Z., Bebis, G., and Miller, R. (2002). Object detection

using feature subset selection. In Pattern Recognition,

37, 21652176.

Tax, D. and R.P.W, D. (2004). Support vector data descrip-

tion. In Machine Learning, 54, 4566,.

Vapnik, V. N. (1999). The Nature of Statistical Learning

Theory. Springer-Verlag, New York, 2nd edition.

Venkatasubramanian, V., Rengaswamy, R., Yin, K., and

Kavuri, S. N. (2003). A review of process fault de-

tection and diagnosis. In Part I:Quantitative model-

based methods. Comput. Chem.

Viola, P. and Jones, M. (2001). Rapid object detection us-

ing boosted cascaded of simple features. In Conf. on

Computer Vision and Pattern Recognition.

Yue, H. and Qin, S. J. (2001). Reconstruction based

fault identiﬁcation using combined index. In I & EC

Reasearch, 40, 4403-4414.

EFFICIENT OBJECT DETECTION USING PCA MODELING AND REDUCED SET SVDD

227
