MPEG-7 DESCRIPTORS BASED CLASSIFIER FOR

FACE/NON-FACE DETECTION

Malek Nadil

Department of Computer Science USTHB, Algiers, Algeria

Abdenour Labed

Department of Computer Science Polytechnic School of Bordj El Bahri, Algiers, Algeria

Feryel Souami

Department of Computer Science USTHB, Algiers, Algeria

Keywords: Image retrieval, MPEG-7, Classification, Semantic.

Abstract: In this paper we present a high level Face/Non-face classifier which can be integrated to a content based

image retrieving system. It will help to extract semantics from images prior to their retrieving. This two-

steps retrieval allows reducing effects of semantic gaps on the performance of existing systems. To

construct our classifier, we exploit a standardized MPEG-7 low level descriptor. Experiments performed on

images taking from two data bases, showed that our technique outperforms others presented in the literature.

1 INTRODUCTION

Several content based images retrieving systems

(CBIR) such as Virage (Bach et. al, SPIE Conf. on

Vis. Commun.and Image Proc.), (Virtual

Information Retrieval Image Engine) have been

developed. Virage was based on color (color layout,

composition), texture, and the object boundary

structure information to help in the visualization

management. It not only provided static images

retrieval facilities but offered some video retrieval

functions as well. QBIC (Flicker et. al, 1995),

(Query by Image Content) is an other system

developed by IBM Almaden Research Center. It was

the first image database retrieval system. It provided

a color similarity comparison and was very suit for a

scenic photo retrieving. Photobook(Pentland et. al,

1996) proposed by MIT multimedia laboratory

contained three sub-books: Appearance book, Shape

book, and Texture book. It provided different

retrieving algorithms and also got most closely to

some domains. VisualSEEK (Smith and Chang,

1996) developed by Image and ATV Lab of

Columbia University, provided both image and

video query by using examples.

However, in spite of numerous attempts to design

reliable engines, all developed systems still suffer

from the semantic gap between user’s inquiry and

results provided by these systems. The main reason

is the fact that they are based on low level

descriptors characterized by semantic lacking.

Indeed, they can not use high level descriptors like

annotation since this latter is still extracted by hand,

which is practically a tedious task. That is why we

introduce an idea in between. It consists of adding a

classification step before starting the retrieving

process. As a first step (prior to searching in a data

base), we use our classifier to detect if the user’s

query contains human faces or not and hence

minimizing irrelevant (aberrant) results suggested as

answers to the query. This general problem is often

referred to as “bridging the semantic gap” (Lew and

Huijsmans, 1996). This classifier not only improves

the pertinence of the results but shortens the time

response of searching engines as well; since the

original searching space has been partitioned into

two smaller parts. Tests on the data bases persons

and no_bike_no_person of the Institute of Electrical

329

Nadil M., Labed A. and Souami F. (2008).

MPEG-7 DESCRIPTORS BASED CLASSIFIER FOR FACE/NON-FACE DETECTION.

In Proceedings of the Third International Conference on Computer Vision Theory and Applications, pages 329-332

DOI: 10.5220/0001090303290332

 SciTePress

Measurement and Measurement Signal Processing

of Graz University of Technology (Austria)

demonstrated the good performance of our classifier.

This paper is organized as fellows: in section 2, we

describe the classifier construction steps, beginning

by features extraction and ending by validation, in

section 3, we present some experimental results and

we end by conclusions in section 4.

2 CLASSIFIER CONSTRUCTION

We first recall that MPEG-7 visual descriptors

(ISO\IEC, 2001) standardized for the image content

description are a compressed description of image

features, which are represented in terms of primitive

image features such as color, texture, and shape of

the image. Among the MPEG-7 visual descriptors,

we have chosen the edge histogram descriptor

(EHD) (Won et. al, 2002) as features of images to be

classified in two classes (Face/Non-Face).

To construct our classifier, an image data base is

needed for its training and testing. In our work we

used a data set of 470 images among which 214

contain human faces. Whilst for features (image

descriptors) extraction, we used the MPEG-7 XM

module (Manjunath et. al, 2001), to get the Edge

Histogram Descriptor.

2.1 Edge Histogram Descriptor (EHD)

The EHD of the MPEG-7 visual descriptors

represents the distribution of five edge types, namely

vertical, horizontal, 45- degree diagonal, 135-degree

diagonal, and non-edge types (ISO\IEC, 2001),

(Won et .al, 2002). The distribution of five edge

types is represented by 16 local edge histograms.

Each local histogram is generated from each sub-

image. A sub-image is a non-overlapping 4x4

partition of the given image space. That is, an image

is divided into non-overlapping 4x4 sub-images.

Then, each sub-image is used as a basic region to

generate an edge histogram, which consists of five

bins with vertical, horizontal, 45-degree diagonal,

135-degree diagonal and non-directional edge types.

Note that the image block may or may not have an

edge in it. If there is an edge in the block, the

counter of the corresponding edge type is increased

by one. Otherwise, the image block has monotonous

gray levels and no histogram bin is increased. After

examining all image blocks in the sub-image, the 5-

bin values are normalized by the total number of

blocks in the sub-image. Thus the sum of the

normalized five bins is not necessarily 1. Finally, the

normalized bin values are quantized for the binary

representation. Since there are 16 (4 x 4) sub-

images, each image yields an edge histogram with a

total of 80 (16 sub-images x 5 bins/sub-image) bins.

These normalized and quantized 80 bins constitute

the EHD of the

MPEG-7. That is, arranging edge

histograms for the sub-images in the raster scan

order (bloc order is done according to that of lines),

16 local histograms are concatenated to have an

integrated histogram with 80 (16x5) bins.

Once EHD descriptors have been recovered,

Independent Component Analysis (ICA) is then

applied to obtain independent parameters and keep

just pertinent information. We have fixed a

percentage of retained information in the

prewhitening step by Principle Component Analysis

(PCA).

For the classification step, we tried many

classifiers (Bayes classifiers, support vectors

machine, K-nearest neighbors,…) but we limit our

selves here to a brief description of classifiers that

gave satisfactory results: the Nearest Mean

Classifier (NMC) and Linear Fisher Discrimenant

Classifier (LFDC) . For the tests of classification

scores, the cross-validation (mainly the leave one

out) strategy has been adopted. All our tests were

performed with the Matlab Toolbox PRTools4

(http://prtools.org/).

2.2 Nearest Mean Classifier

Nearest mean classifier calculates the centers of in-

class and out-class training samples and then assigns

the upcoming samples to the closest center. This

classifier gives two distance values as output and

should be modified to produce a posterior

probability value. A common method used for K-

NN classifiers can be utilized (Arlandis et. al, 2002).

According to this method, distance values are

mapped to posterior probabilities by the formula:

(1)

where W

refers to the i

class (i=1,2.), d

and d

are distances from the i

and j

class means,

respectively. In addition, a second measure

recomputes the probability values below a given

certainty threshold by using the formula (Arlandis

et. al, 2002):

(2)

∑

)/(

mjmi

xWP

=)/(

VISAPP 2008 - International Conference on Computer Vision Theory and Applications

330

where N

is the number of in-class training samples

whose distance to the mean is greater than x, and N

is the total number of in-class samples. In this way, a

more effective nearest mean classifier can be

obtained.

2.3 Linear Fisher Discriminant

Classifier

Linear Fisher discriminant (LFD) is a well-known

two-class discriminative technique. It aims to find

the optimal projection direction such that the

distance between the two mean values of the

projected classes is maximized while each class

variance is minimized.

The optimal discrimination mask can be

computed explicitly in a closed form by the

following formula (Duda et. al, 2004):

maxarg

(3)

Where:

(4)

is the mean (center) of the j

class, l the total

number of training samples of all classes, and l

the number of samples in the j

class. and:

(5)

is the covariance within classes.

3 EXPERIMENTS

Table 1 summarizes the classification results for

nearest mean classifier (NMC) and linear Fisher

discriminant classifier (LFDC). The first column

gives the percentage of retained information, the

second contains the dimensionality of the space

corresponding to each percentage. While the third

and the fourth columns give the classification error

(in %) obtained by the leave one out procedure for

the NMC and the LFDC respectively. We can

notice that the best scores are obtained for 83% of

retained information (36 components) for both

classifiers. This error is 12.979% for NMC and

13.404% for LFDC.

These errors are illustrated on the figure 1 below.

The retained information (%) is represented on X-

axis while the Y-axis represents classification error.

Table 1: Leave one out classification error for NMC and

LFD based on ICA preceded by a PCA whitening.

NM C

80 90

re tained inform ation (%)

classification

error (%)

(a)

LFDC

13,5

14,5

15,5

16,5

80 90

re taine d inform ation (%)

classifi cation error ( %)

(b)

Figure 1: Classification error evolution according to

variation of retained information.

Error (%)

Retained

Information

(%)

Number of

components

NMC LFDC

80 32 14.255 13.83

81 33 13.617 13.83

82 35 13.404 13.617

83 36 12.979 13.404

84 38 13.404 13.617

85 39 13.191 13.617

86 41 13.191 13.617

87 43 13.83 13.83

88 45 14.468 14.468

89 46 14.681 14.255

90 48 14.894 14.681

91 50 14.681 15.319

92 53 15.532 15.532

93 55 15.319 15.957

94 58 14.468 14.894

95 60 15.957 15.532

96 63 15.745 15.532

97 67 15.957 15.957

98 70 16.383 15.745

99 75 16.17 15.745

)(

mmS

−=

−

jiW

mxmxS

)()(

−−=

∑∑

∑

MPEG-7 DESCRIPTORS BASED CLASSIFIER FOR FACE/NON-FACE DETECTION

331

Hereafter, examples of well classified and

misclassified images are given for both classes

(Face/Non-Face). For instance, the images below,

have been well classified:

Figure 2: Examples of well classified images.

We can notice that the first pair refers to scenes in

which human faces are present, while in the next

pair there are no human faces.

The case of misclassified images is also

illustrated below:

Figure 3: Examples of misclassified images.

4 CONCLUSIONS

We have constructed a classifier based on EHD as

discriminating features and the nearest mean rule for

supervised classification, to classify images from

two classes: Face/Non-Face.

About 87% of good classification score as been

obtained, which is slightly better than the scores

obtained by the team of SHEMA Reference

system(Mezaris et. al, the Schema

Reference System). Hence, we consider that our

approach is able to produce satisfactory results.

In a future work, we intend to expand our

approach to the case of more than two classes (sky,

trees, water, animals, etc). For the classification rule

we will try the classifiers combining.

REFERENCES

J.R. Bach. et.al. The Virage Image Search Engine: an

OPRN Framework for Image Management. in PROC.

SPIE Conf. on Vis. Commun.and Image Proc.

M. Flicker. et.al. Query by Image and Video Content: The

QBIC System. IEEE Computer. Vol.28. Nº9. pp.23-

32. 1995.

A. Pentland. et.al. Photobook: Content-based

Manipulation of image databases. International Jounal

of Computer Vision 1996.

J. R. Smith, S.F. Chang. Visual SEEK: a fully automated

content-base image query system.

Proceeding of ACM International Conference Multimedia.

boston. MA. pp.87-98. November. 1996.

M.S. Lew, N. Huijsmans. Information Theory and Face

Detection. In Proceedings of the International

Conference on Pattern Recogntion, Vienna, Austria,

601-605. 1996.

ISO/IEC 15938-3: Multimedia Content Description

Interface - Part 3: Visual. 2001.

C. S. Won, D. K. Park, S.-J. Park. Efficient use of MPEG-

7 edge histogram descriptor. ETRI Journal. 24. pp.23-

30. 2002.

B. S. Manjunath, P. Salembier and T. Sikora. Introduction

to MPEG-7: Multimedia Content Description

Standard. Wiley. New York. 2001.

J. Arlandis, J.C Perez-Cortes and J. Cano. Rejection

Strategies and Confidence Measures for a k-NN

Classifier in an OCR Task. IEEE 2002.

R. O. Duda, P. E. Hart and D. G. Stork, Pattern

Classification. New York: Wiley-Interscience, 2001.

Vasileios Mezaris et al. An Extensible Modular Common

Reference System For Content-Based Information

Retrieval: The Schema Reference System.

VISAPP 2008 - International Conference on Computer Vision Theory and Applications

332
