ONLINE LEARNING OF GAUSSIAN MIXTURE MODELS

A Two-Level Approach

Arnaud Declercq and Justus H. Piater

Monteﬁore Institute, University of Li

ege, B-4000 Li

ege, Belgium

Keywords:

Online learning, Gaussian mixture model, Uncertain model.

Abstract:

We present a method for incrementally learning mixture models that avoids the necessity to keep all data points

around. It contains a single user-settable parameter that controls via a novel statistical criterion the trade-off

between the number of mixture components and the accuracy of representing the data. A key idea is that each

component of the (non-overﬁtting) mixture is in turn represented by an underlying mixture that represents

the data very precisely (without regards to overﬁtting); this allows the model to be reﬁned without sacriﬁcing

accuracy.

1 INTRODUCTION

Mixture models are used for many purposes in com-

puter vision, e.g. to represent feature distributions or

spatial relations. Given a ﬁxed data sample, one can

ﬁt a mixture model to it using one of a variety of meth-

ods. However, in many applications, it is not possible

or convenient to ﬁx a model at the outset; one would

rather learn it over time. For example, this would al-

low the deployment of generic recognition or tracking

systems with minimal set-up effort, and training them

over time on the task at hand.

However, learning and reﬁning a mixture model

incrementally is not an easy task. How is a given

model to be updated when new data points arrive?

If the data points underlying the current model have

been discarded, then there is no general answer to this

question. On the other hand, keeping all data around

defeats the purpose of learning parametric models in-

crementally. Thus, a compromise needs to be found.

We need to keep around enough information to be

able to reﬁne a model without sacriﬁcing model accu-

racy, but the quantity of this information should grow

much more slowly than the number of raw data points.

We address this problem by seeking to represent

the data points with (1) sufﬁcient ﬁdelity that we can

safely discard them, while at the same time (2) com-

mitting to no more predictive precision as the original

data support.

These two objectives are mutually exclusive, as

the former tends to overﬁt and the latter to underﬁt

the data. We therefore propose a two-level representa-

tion. The ﬁrst level seeks to summarize the data with

high precision, allowing us to discard underlying data

without signiﬁcantly impairing our ability to reﬁne

the model. We therefore call it the precise model. The

second level provides a model that represents no more

detail than is supported by the underlying data and

then avoids counterproductive bias in future predic-

tions; we call it the uncertain model. Each uncertain

component is then represented by a precise mixture

model that allows it to be split appropriately when it

turns out that it oversimpliﬁes the underlying data. In

the following development, we use Gaussian mixture

models, but most of the principles are applicable to

other types of mixture models.

2 LEVEL 1: THE PRECISE

MIXTURE MODEL

When a GMM is learned from a data set of n ob-

servations, the main difﬁculty lies in the choice of

the mixture complexity (i.e. the number of Gaus-

sian components in the mixture). The most popular

ofﬂine method is Expectation Maximization (Demp-

ster et al., 1977) for ﬁtting a sequence of GMMs,

each with a speciﬁed number of components. The

optimal model is then selected using a penalty func-

tion (Akaike, 1973; Rissanen, 1978; Schwarz, 1978).

Online ﬁtting is even more difﬁcult; since the data

points have been discarded, they cannot be used to

evaluate the ﬁtted models. The problem is then ad-

605

Declercq A. and H. Piater J. (2008).

ONLINE LEARNING OF GAUSSIAN MIXTURE MODELS - A Two-Level Approach.

In Proceedings of the Third International Conference on Computer Vision Theory and Applications, pages 605-611

 SciTePress

dressed through a split and merge criterion. However,

these methods are either too slow for online learning

(Hall and Hicks, 2005), assume that data arrives in

chunks (Song and Wang, 2005) or does not guarantee

the ﬁdelity of the resulting model (Arandjelovic and

Cipolla, 2005). Here we propose a new efﬁcient on-

line method that explicitly guarantees the accuracy of

the model through a ﬁdelity criterion.

2.1 Update of the Gaussian Mixture

Model

Suppose we have already learned a precise GMM

from the observations up to time t:

(x) =

∑

i=1

g(x;µ

)

∑

i=1

(1)

where each Gaussian is represented by its weight

, its mean µ

and its covariance C

. We then re-

ceive a new data point represented by its distribution

(x;µ

) and its weight π

. C

here represents the

observation noise. As suggested by Hall and Hicks

(Hall and Hicks, 2005), the new resulting GMM is

computed in two steps:

1. Concatenate – produce a model with N + 1 com-

ponents by trivially combining the GMM and the

new data into a single model.

2. Simplify – if possible, merge some of the Gaus-

sians to reduce the complexity of the GMM.

The GMM resulting from the ﬁrst step is simply

(x) =

∑

i=1

t−1

g(x;µ

t−1

) + π

(x;µ

)

∑

i=1

t−1

+ π

(2)

The goal of the second step is to reduce the complex-

ity of the model while still giving a precise descrip-

tion of the observations. Hall and Hicks (Hall and

Hicks, 2005) propose to group the Gaussians using

the Chernoff bound to detect overlapping Gaussians.

Different thresholds on this bound are then tested and

the most likely result is kept as the simpliﬁed GMM.

Since this method is too slow for an on-line process,

we use a different criterion proposed by Declercq and

Piater (Declercq and Piater, 2007) for their uncertain

Gaussian model. This model provides a quantitative

estimate λ of its ability to describe the associated data

that takes on a value close to 1 if the data distribu-

tion is Gaussian and near zero if it is not. This value,

called the ﬁdelity in the sequel, is useful to decide if

we can merge two given Gaussians without drifting

from the real data distribution.

2.2 Estimating the Fidelity of a

Gaussian Model

To estimate the ﬁdelity λ of a Gaussian model, we ﬁrst

need to compute the distance between this model and

its corresponding data set. This is done with a method

inspired from the Kolmogorov-Smirnoff test,

D =



F(x) − F

(x)



dx, (3)

where F

(x) is the empirical cumulative distribution

function of the n observations,

F(x) is the correspond-

ing cumulative Gaussian distribution, and I is the in-

terval within which the two functions are compared.

To simplify matters, the distance D is assumed to have

a Gaussian distribution, which leads to the pseudo-

probabilistic weighting function

λ = e

−D

, (4)

where T

is a user-settable parameter that represents

the allowed deviation of observed data from Gaus-

sianity. Whereas the sensitivity of the Kolmogorov-

Smirnov test grows without bounds with n, λ provides

a bounded quantiﬁcation of the correspondence be-

tween the model and the data. Therefore, this crite-

rion is more appropriate for our case since we need

to estimate the correspondence of the data with the

model and not their possible convergence to a Gaus-

sian distribution.

Thus, the original data are not required anymore

if we keep in memory an approximation of their cu-

mulative distribution within a given interval. Since

the number of dimensions of the data space can be

large, we compute the distance D for each dimension

separately to keep the computational cost linear in the

number of dimensions. The total distance is then sim-

ply the sum of these individual distances.

2.3 Simpliﬁcation of the Gaussian

Mixture Model

To decide whether two Gaussians G

and G

can

be simpliﬁed into one, we merge them together and

check if the resulting Gaussian has a ﬁdelity λ close

to one, say, exceeding a given threshold λ

min

= 0.95.

The resulting Gaussian is computed using the usual

equations supplemented by the combination of the cu-

VISAPP 2008 - International Conference on Computer Vision Theory and Applications

606

3.1 The Uncertain Gaussian Model

The uncertain Gaussian model represents a distribu-

tion with an appropriately weighted sum of informa-

tive (Gaussian) and uninformative (uniform) compo-

nents

q(x) = λ exp



−

(x − µ)

−1

(x − µ)



+ (1 − λ)

(14)

where

C is an augmented covariance that bounds

the risk of underestimating the true covariance, i.e.,

C ≤ C) = α, where conventionally α = 0.05. Since

empirical estimates of variance follow a χ

distribu-

tion,

C =

n−1

(α)

C, (15)

where n is the number of observations used to learn

the model and

C is its maximum-likelihood covari-

ance matrix. Thanks to the new threshold λ

−

min

and the

uncertain Gaussian model, we are now able to learn a

GMM that is kept as general as possible until there is

sufﬁcient evidence that the model can be made more

speciﬁc.

The drawback of this solution is that it is now im-

possible to recover the data from it. For example, the

data in ﬁgure 3(a) suggest that the underlying distribu-

tion is poorly represented by two Gaussians. Unfortu-

nately, when this fact is detected, it is already too late:

The observations are not in memory anymore, leaving

you with a poor model that can no longer be reﬁned.

This motivates our two-level mixture model where the

data are represented by the uncertain mixture model,

and where each uncertain Gaussian contains a precise

mixture model to describe itself. Thus, when we want

to reﬁne an uncertain Gaussian, we can split it accord-

ing to its underlying mixture components.

3.2 Updating a Two-Level Gaussian

Mixture Model

The algorithm used to update the GMM proceeds

along the following steps:

1. Merge the new data point with the nearest uncer-

tain Gaussian,

2. if the resulting Gaussian has a value of λ below

the corresponding λ

−

min

, replace it with two Gaus-

sians learned from its underlying GMM with EM

(Dempster et al., 1977),

3. else continue to merge the current uncertain Gaus-

sian with its nearest neighbour until the resulting

Gaussian has a value of λ lower than the corre-

sponding λ

−

min

Merging two uncertain Gaussians also involves

merging their respective underlying mixture models.

This can be done by simply summing the components

from both mixtures, and using the simpliﬁcation step

only on the precise Gaussian that contains the new ob-

servation. Even if other precise Gaussians could pos-

sibly be merge together, we leave that for later when

they merge with the current observation. This way,

we distribute the computational cost through different

time instants.

3.3 Discussion

Figure 3 shows an example of the evolution of the

GMM with data points generated from an arc-shaped

distribution. This time the complexity of the GMM

only increases when there is enough evidence that

the observed distribution is too complex for the cur-

rent model. If we compare ﬁgure 3 with ﬁgure 1,

we see that the two-level GMM and the precise mix-

ture model converge to the same distribution. The

two-level approach then provides a more stable non-

overﬁtted model that can still become more accurate

thanks to the precise model level.

4 EXPERIMENTS

4.1 Empirical Analysis of the Behaviour

of the 2-Level Model

To analyze the relation between the model complex-

ity and the only parameter T

, we generated data from

a circular distribution for different values of T

from

0.01 to 0.25. We ran 30 tests per value of T

and

stopped each test after 500 observations. As we can

see in ﬁgure 4(a), T

provides us with a simple way to

specify the desired trade-off between the model com-

plexity and its accuracy.

Since the learning is incremental, we may won-

der if the model will always converge to qualitatively

the same result. We therefore performed the same ex-

periment with T

= 0.04 and with angular velocities

between 0.01 and 2 rad/frame for the process that gen-

erates the observations. As shown in ﬁgure 4(b), the

model complexity is nearly independent of the order

of the observations.

4.2 A Vision Application

Our method provides an under-ﬁtted probability den-

sity estimation of the partially observed distribution.

ONLINE LEARNING OF GAUSSIAN MIXTURE MODELS - A Two-Level Approach

609

5 CONCLUSIONS

We presented a method for incrementally learning a

Gaussian mixture model based on a new criterion for

splitting and merging mixture components. This cri-

terion depends on a single user-settable parameter that

allows easy tuning of the trade-off between the com-

plexity and the accuracy of the mixture model. Our

two-level approach provides a solution to the over-

ﬁtting problem of small data sets without any com-

promise on the model accuracy. As more data arrive,

the mixture complexity can be increased without any

propagation of errors due to a previously underﬁtted

model. As we have demonstrated empirically, this

method is nearly independent of the order in which

the data are observed.

ACKNOWLEDGEMENTS

This work is supported by a grant from the Belgian

National Fund for Research in Industry and Agricul-

ture (FRIA) to A. Declercq and by the EU Cognitive

Systems project PACO-PLUS (IST-FP6-IP-027657).

REFERENCES

Akaike, H. (1973). Information theory and an extension of

the maximum likelihood principle. Second Interna-

tional Symposium on Information Theory.

Arandjelovic, O. and Cipolla, R. (2005). Incremental learn-

ing of temporally-coherent gaussian mixture models.

BMVC.

Declercq, A. and Piater, J. H. (2007). On-line simultaneous

learning and tracking of visual feature graphs. Online

Learning for Classiﬁcation Workshop, CVPR’07.

Dempster, A. P., Laird, N. M., and Rubin, D. B. (1977).

Maximum likekihood from incomplete data via the em

algorithm. Journal of the Royal Statistical Society,

39:1–38.

Hall, P. and Hicks, Y. A. (2005). A method to add gaussian

mixture models. Tech. Report, University of Bath.

Rissanen, J. (1978). Modeling by shortest data description.

Automatica, vol. 14, pp. 465-471.

Schwarz, G. (1978). Estimating the dimension of a model.

Annals of Statistics, pages 6:461–464.

Song, M. and Wang, H. (2005). Highly efﬁcient incremental

estimation of gaussian mixture models for online data

stream clustering. Intelligent Computing: Theory and

Application.

ONLINE LEARNING OF GAUSSIAN MIXTURE MODELS - A Two-Level Approach

611
