A MULTI-CAMERA FRAMEWORK FOR INTERACTIVE VIDEO

GAMES

Tom Cuypers, Cedric Vanaken, Yannick Francken, Frank Van Reeth and Philippe Bekaert

Hasselt University - Expertise Centre for Digital Media, Transnationale Universiteit Limburg

Wetenschapspark 2, 3590 Diepenbeek, Belgium

Keywords:

Interactive Video Games, Video-Based Rendering, Human Computer Interaction.

Abstract:

We present a framework that allows for a straightforward development of multi-camera controlled interactive

video games. Compared to traditional gaming input devices, cameras provide players with many degrees of

freedom and a natural kind of interaction. The use of cameras can even obsolete the need for special clothing

or other tracking devices. This partly accounted for the success of the currently popular single-camera video

games like the Sony Eyetoy. However, these games are fairly limited in the use of 3D scene information.

Using multi-camera setups, this limitation can be surpassed, but typically many different image processing

and computer vision techniques are involved. Our framework divides multi-camera based games into basic

algorithms that are easily combinable into several sequentially executed stages. Therefore the amount of effort

to develop new games can signiﬁcantly be reduced. The capabilities of our framework are demonstrated

with a number of conceptual games, proving that multi-camera controlled video games can be created with

off-the-shelf hardware.

1 INTRODUCTION

Video game companies have recently started broad-

ening their range of traditional input devices - mouse,

keyboard, joystick - with alternative devices such as

motion sensors and cameras. Sony successfully re-

leased camera based Eyetoy games for the Playstation

2 (Eyetoy Sony, 2003) and furthermore created best-

sellers that are controlled with other non traditional

input devices like microphones (Singstar Sony, 2004)

and guitars (Guitar Hero Sony, 2005). Last year, Nin-

tento released the Wii console (Nintendo Wii, 2006)

of which the user-input is mainly based on the tracked

motion of the Wii-Remote. The success of these

games shows that a consumer demand exists for al-

ternative input devices to control video games.

We choose to work with cameras because they

provide multiple degrees of freedom as well as a nat-

ural kind of interaction for the gamer. Current image

processing and tracking techniques eliminate the need

for wearing special clothing or tracking devices. The

live-captured images in camera controlled games fur-

thermore allow for creating an immersive augmented

reality.

Many commercial camera controlled video games

and webcam applications have already been released,

but the Playstation Eyetoy has set the standard for

most of them. Albeit that these products do have

some limitations. The use of a single camera restricts

the developer to only work with 2D scene informa-

tion. Without depth information, the gameplay will

often only feel natural when the user performs move-

ments in a plane parallel to the camera’s image plane.

Many 3D movements are undetectable due to the 2D

projection on the camera’s image plane, substantially

restricting the range of interaction possibilities. The

resulting interaction with the game will often be un-

intuitive and unsatisfying.

When working with multiple synchronized cam-

eras that are viewing a scene from different positions

and/or angles, 3D information of the scene can be re-

constructed. This reconstructed information allows

for creating games that are controlled by 3D human

motions, providing players with a natural way of con-

trolling a virtual avatar.

In this paper we present a framework that allows

for easily creating video games that are controlled

with several cameras. The framework is built keeping

a highly modular paradigm in mind. The video games

are created by implementing up to ﬁve different pro-

gramming stages that are executed sequentially. Tra-

ditional or new image/video processing or computer

443

Cuypers T., Vanaken C., Francken Y., Van Reeth F. and Bekaert P. (2008).

A MULTI-CAMERA FRAMEWORK FOR INTERACTIVE VIDEO GAMES.

In Proceedings of the Third International Conference on Computer Graphics Theory and Applications, pages 443-449

DOI: 10.5220/0001096904430449

 SciTePress

vision techniques can be individually supplied to each

stage.

Our framework consists of the following ﬁve

stages:

Input: capturing the scene and player using a num-

ber of calibrated and synchronized cameras

Video Processing: transforming the captured video

frames into a format better suited for the efﬁcient

extraction of relevant data in subsequent steps

Depth Extraction: combining 2D information of the

images to reconstruct 3D information

Post-processing: using the reconstructed 3D infor-

mation to control the game

Output: composing visual output

An in-depth overview of these stages will be dis-

cussed later, as well as suggestions for algorithms that

can be used in each stage. Some examples of video

games that were created using our framework will be

presented and discussed in the results section.

2 RELATED WORK

Cameras have been previously used as input hardware

for various human computer interaction and virtual

reality applications as well as for computer games.

The quality of these applications is highly dependent

on the hardware and computer vision software used.

Several suitable vision algorithms along with possible

interaction applications are discussed by Crowley et

al. (Crowley, 1997; Crowley et al., 2000).

Camera controlled human computer interaction

applications are also being used by persons with phys-

ical disabilities who are not able to conveniently use

a mouse or a keyboard. These kind of interactions

can be achieved by ﬁlming and analyzing certain

body features (Betke et al., 2002) like eg. a person’s

eyes (Chen et al., 2001) or nose (Gorodnichy et al.,

2002).

Balcisoy and Thalmann (Balcisoy and Thalmann,

1997) describe a technique that allows to record a real

actor and place him into a virtual reality world. The

actor can then interact with virtual characters, where

the virtual characters’ actions are chosen from pre-

recorded key-actions by a human operator. De Decker

et al. (De Decker et al., 2007) propose a technique for

interactive collision detection and response between

real objects/people and virtual objects using multiple

cameras.

Mitsubishi Electronics made a considerable con-

tribution to the area of camera controlled interactive

video games. To answer the need for low cost hard-

ware and high speed processing power, they invented

the Artiﬁcial Retina Chip (Kyuma et al., 1994; Free-

man et al., 1996; Freeman et al., 1998), this by anal-

ogy with biological retinas that combine the functions

of detection and processing. The chip has a built-in

detector for mereley 32× 32 to 256 × 256 resolution

images and was used by Sega Saturn (Sega Saturn,

1994) and Nintendo Gameboy (Nintendo Gameboy,

1998). Current days, the most famous camera con-

trolled games are those of Sony Playstation’s Eye-

toy (Eyetoy Sony, 2003).

Camera controlled applications receive their pri-

mary input from ﬁlmed objects and/or actors. These

individual subjects can be located and tracked by

using object tracking techniques (Metaxas and Ter-

zopoulos, 1993; Wren et al., 1997).

Most traditional camera based applications are re-

stricted to using only one 2D video input stream.

With a number of calibrated cameras this input

stream can be extended to obtain 3D information

using vision techniques such as dense depth esti-

mation (Scharstein and Szeliski, 2002) and visual

hull reconstruction (Laurentini, 1994), each having

its (dis)advantages. Depth estimation is especially

useful when two cameras are used in a small base-

line setup. Scharstein and Szeliski (Scharstein and

Szeliski, 2002) have published an overview of differ-

ent modern stereo depth estimation algorithms. The

purpose of these algorithms is to create a disparity

map from two small baseline cameras for one of the

reference images. Alternatively, visual hull recon-

structions represent an estimated 3D model of an ac-

tor or object. This 3D model is acquired by using sil-

houettes extracted from different video streams (Lau-

rentini, 1994). The accuracy of visual hull reconstruc-

tions is higher when two or more cameras are placed

in a wide baseline setup.

3 MULTI-CAMERA

INTERACTION FRAMEWORK

In this section a more detailed description of our

framework will be given. We subdivide the produc-

tion process of camera controlled games into ﬁve high

level stages, namely input, video processing, depth ex-

traction, post-processing and output. For each stage,

several appropriate algorithms are proposed. The

combination of these stages allows to create interac-

tive video games as well as general purpose applica-

tions. However, we mainly focus on real-time game

interaction.

Although we present ﬁve different stages, not all

of them need to be executed. For instance, by ig-

noring the depth extraction stage, regular single cam-

GRAPP 2008 - International Conference on Computer Graphics Theory and Applications

444

era games (Eyetoy Sony, 2003; Freeman et al., 1996;

Freeman et al., 1998) can be created. For real-time

user-interaction, one will most likely need to make

a tradeoff between speed and quality, sometimes even

resulting in eliminating or combining different stages.

The implementation of each stage will furthermore

depend highly on the kind of video game that needs to

be developed, combined with the used camera setup,

processing hardware etc.

3.1 Input

Typically two or three digital cameras are used to

capture a real world actor that controls the vir-

tual world. Nevertheless, other setups are possible,

eg. remote network cameras, infrared cameras, pre-

recorded videos or alternative input hardware.

3.2 Video Processing

In this stage the video frames received from the in-

put devices are transformed into a format better suited

for efﬁcient extraction of relevant data in subsequent

stages.

One commonly used video processing operation

is camera noise reduction. The necessity of this op-

eration depends on the quality of the digital cameras

as well as the lighting conditions in the scene. Input

video frames can be denoised in the spatial, frequency

and temporal domain (Dubois and Sabri, 1984; Gon-

zalez and Woods, 1992), typically having a loss of

high frequency detail as a side effect.

Another commonly used technique in this stage is

background subtraction. Camera controlled applica-

tions are mostly interested in foreground objects or

actors, therefore background subtraction is inevitable

(eg. shape-from-silhouette, see section 3.3). Interac-

tive applications require the background to be elimi-

nated in real-time. Blue or green screen matting tech-

niques (Mishima, 1993; Smith and Blinn, 1996) fulﬁll

this requirement, as well as (less efﬁcient) techniques

that handle more natural backgrounds (Cheung and

Kamath, 2004; McIvor, 2000).

Many other image or video processing ﬁlters

like motion detection (Spacek, 1986), skin detec-

tion (Vezhnevets et al., 2003), etc. also ﬁt perfectly

into this stage.

3.3 Depth Extraction

Given the ﬁltered and annotated video frames, the re-

quired 3D information can be extracted.

When reconstructing the body of the actor with-

out focussing on speciﬁc features, standard 3D re-

construction techniques such as dense depth esti-

mation (Scharstein and Szeliski, 2002; M¨uhlmann

et al., 2002) and visual hull modeling (Laurentini,

1994; Erol et al., 2005) are appropriate. Certain lo-

cal dense depth estimation algorithms (Woetzel and

Koch, 2004; Yang and Pollefeys, 2003) can get a

signiﬁcant speed boost when parallelized on multi-

processor systems such as those featured on current

graphics hardware.

Visual hull methods are best suited for setups that

contain at least three cameras, especially when novel

views need to be synthesized. Although visual hull re-

construction is practically independent of image res-

olution, full model reconstruction has to be avoided

whenever possible because of the high computational

load. For example, in situations where the visual hull

is only needed to determine physical collisions and

responses, calculations can be performed directly in

image space (De Decker et al., 2007).

Depending on the type of game, the full actor’s

motion or a selection of his body parts needs to be

tracked. When it sufﬁces to focus on particular body

parts such as hands and head, standard object track-

ing (Kalman, 1960; Metaxas and Terzopoulos, 1993;

Wren et al., 1997; Isard and Blake, 1998; Li et al.,

2003) can be applied.

3.4 Post-processing

Up until this stage the necessary 2D/3D information

has been gathered and processed to provide interac-

tion between the real scene and the virtual scene. Us-

ing a standard physics engine, this can be achieved by

applying collision detection and response between the

player and virtual objects.

Also alternative avatar approximations and inter-

actions are possible. A very plausible method to cre-

ate an avatar for the player can consist of using kine-

matics. The player is represented by a skeleton and its

pose is deﬁned by the degrees of freedom of the joints.

This pose can be obtained with forward kinematics

by tracking the joints separately (Rubio et al., 2006),

or with inverse kinematics (Welman, 1993; Parent,

2001) by tracking only the end-effectors and estimat-

ing the intermediate joints (Jaume et al., 2006). This

skeleton provides many interaction possibilities from

simple collision detection to 3D motion recognition

etc.

3.5 Output

During the ﬁnal stage, the visual output for the game

has to be composed. Depending on the speciﬁcations,

2D and/or 3D data is rendered to a display. Since real

A MULTI-CAMERA FRAMEWORK FOR INTERACTIVE VIDEO GAMES

445

input frames were obtained at the input stage, a vir-

tual but realistic approximation of the avatar can be

integrated into the output using video-based render-

ing methods (Magnor, 2005). This virtual/augmented

reality data can be displayed on a TV or computer

screen, but can also be rendered to alternative output

devices like 3D glasses.

4 RESULTS

In this section we demonstrate the power and the ease

of use of our framework by discussing how the ﬁve

stages are implemented for a number of conceptual

interactive games. The optimal setup to capture 3D

scene information is a blue/green screen environment

that contains many cameras. Unfortunately, creating

and setting up this kind of construction is often un-

practical and using it may be computationally very ex-

pensive. Therefore we discuss severaldifferent games

that make use of alternative setups. The presented

games run at a framerate between 10 and 15 fps on a

Pentium Mobile 1.5 GHz laptop, which is sufﬁciently

accurate and usable for real-time interaction.

4.1 Frogger

This game is a camera controlled version of the clas-

sic Frogger game, introduced by Konami (Konami,

1981). The goal of Frogger is to cross the street with-

out getting hit by cars. The player is ﬁlmed head-on

and can move in any direction to navigate the avatar

in the game. The setup consists of three small base-

line Point Grey Research Flea2 (Point Grey Research,

2007) cameras and a diffuse green background. Nav-

igation is achieved by locating the player in the in-

put images using green screen matting (Smith and

Blinn, 1996), applying local dense depth map estima-

tion (Yang and Pollefeys, 2003) and calculating the

center of mass. Because of the green screen mat-

ting, almost no specularities are visible, allowing us

to make use of a local depth estimation method to ro-

bustly detect the center of mass. A structural scheme

is shown in Figure 1.

4.2 Depth based Drawing

The goal of this game is to paint a given sequence

of letters or symbols on the screen. The setup

consists of three small baseline Point Grey Research

Flea2 (Point Grey Research, 2007) cameras that ﬁlm

the player head-on. To make sure that moving per-

sons in the background do not disrupt the gameplay,

background changes behind a certain depth threshold

DepthEstimation

Locating Avatar

INPUT

VIDEOPROCESSING

DEPTH

EXTRACTION

POST

PROCESSING

OUTPUT

Background

Subtraction

Background

Subtraction

Background

Subtraction

Figure 1: Scheme of Frogger.

NoiseReduction

SkinDetection

DepthEstimation

Depth Thresholding

INPUT

VIDEO

PROCESSING

DEPTH

EXTRACTION

POST

PROCESSING

OUTPUT

LetterRecognition

Figure 2: Scheme of the depth based drawing game.

are discarded. Skin detection (Vezhnevets et al.,

2003) is performed on one image and a local depth

estimation technique (Yang and Pollefeys, 2003)

is executed on the skin-classiﬁed pixels. Due to

the skin detection, possible specular highlights are

automatically ignored, which makes a local depth

estimation sufﬁcient. Unfortunately, fast player

movements are often undetected because of an excess

of motion blur. The depth-thresholded skin-pixels are

then fed into a letter recognition algorithm that we

have built upon the LibStroke library (Willey, 1997).

An overview is depicted in Figure 2.

GRAPP 2008 - International Conference on Computer Graphics Theory and Applications

446

Background

Subtraction

VisualHull

Physics

INPUT

VIDEO

PROCESSING

DEPTH

EXTRACTION

POST

PROCESSING

OUTPUT

Background

Subtraction

Background

Subtraction

Figure 3: Scheme of Dodge-it.

4.3 Dodge-it

The goal of this game is to dodge the virtual ob-

jects that fall into the scene. A wide baseline setup

is used that consists of three Point Grey Research

Flea2 (Point Grey Research, 2007) cameras that ﬁlm

the player head-on and sideways. More cameras can

be used in this setup, ﬁlming the player from an

other side of the room, or from in-between angles

etc., however note the trade-off between accuracy and

speed. Green screen background subtraction (Smith

and Blinn, 1996) is ﬁrst performed on every image,

and visual hulls (Laurentini, 1994) are calculated for

the foreground objects and actors. Note that visual

hulls are used because dense depth maps only allow

for limited physical collisions. A voxel based vi-

sual hull is created of the foreground objects (Mar-

tin and Aggarwal, 1983). This model is used to

check for collision detection and response with vir-

tual objects, handled by ODE (Open Dynamics En-

gine, 2001). The output is a combination of a virtual

rendered scene and a billboard of the player. Shad-

ows have been added to provide an extra depth cue.

An overview is given in Figure 3.

4.4 Spiral

Spiral is a digital version of an old traditional folk

game where one must navigate a metal ring around

a curved tube while avoiding collisions between the

ring and the tube. Herefore an object, containing three

different colors, is tracked using a wide baseline setup

of two (or three) Point Grey Research Flea2 (Point

ParticleFiltering

TransformingObject

INPUT

VIDEO

PROCESSING

DEPTH

EXTRACTION

POST

PROCESSING

OUTPUT

CollisionDetection

Figure 4: Scheme of spiral.

Grey Research, 2007) cameras. We use the Conden-

sation algorithm (Isard and Blake, 1998) - a popular

variant of the particle ﬁlter - to track this object in

the depth extraction stage. The calculated location

and orientation is then mapped into the virtual world.

Figure 4 shows this game where the player holds the

tracked object that controls the ring in the game. Col-

lision detection between the ring and the spiral is per-

formed to deﬁne the player’s score. The output is a

pure virtual world.

4.5 Roboshoot

The purpose of Roboshoot is to shoot moving virtual

3D objects in the scene. The player is ﬁlmed head-on

by a Point Grey Research Bumblebee (Point Grey

Research, 2007) camera and can move his arms in the

direction he wants to aim his virtual guns at. First,

skin detection (Vezhnevets et al., 2003) is performed

to locate the hands and face of the player in one of

the input images. This 2D location is expanded to

a 3D location in the depth extraction stage by using

the depth map which is automatically created by

the Bumblebee camera. The transposed Jacobian

method (Welman, 1993) for inverse kinematics is

then used with these locations to estimate the upper-

body pose of the player, deﬁning the movements of

the avatar. Although these virtual movements are not

always exactly corresponding to the real movements,

this proves to be a very efﬁcient and plausible pose

approximation method. However, problems may

occur when bodyparts other than face and hands are

exposed. Figure 5 contains a synopsis of the game.

A MULTI-CAMERA FRAMEWORK FOR INTERACTIVE VIDEO GAMES

447

SkinDetection

FaceandHand Tracking

INPUT

VIDEO

PROCESSING

DEPTH

EXTRACTION

POST

PROCESSING

OUTPUT

InverseKinematics

Figure 5: Scheme of Roboshoot.

5 CONCLUSIONS

We have presented a framework targeted at creating

video games that are controlled by input from multi-

ple cameras. Our framework embodies ﬁve modular

stages from which each serves a different role in the

execution of the game. While the purpose of each

stage is ﬁxed during the lifetime of a video game,

novel algorithms can easily be plugged in to replace

or complement already used algorithms. A proof of

concept is provided by discussing several interactive

video games that were implemented using the frame-

work. These multi-camera controlled games not only

show the usability of the framework, but also prove to

be an asset to standard game interaction techniques.

We believe that our framework is applicable to vari-

ous other forms of human computer interaction.

6 FUTURE WORK

Currently our framework mainly focuses on single

setup vision-based interaction methods. Integrating a

speciﬁc network layer could allow for creating online

camera-based multiplayer video games. Providing

multi-modal interaction possibilities such as combi-

nations with standard game controllers, speech recog-

nition etc. can furthermore strengthen of this frame-

work.

Although we believe that off-the-shelf technology

is ready for multi-camera computer games for home

users, user friendly setup calibration methods still

need further investigation. While ﬁxed pre-calibrated

cameras such as the Bumblebee (Point Grey Re-

search, 2007) are already available, wide baseline se-

tups are location dependent and need to be calibrated

on the spot. In general, adaptive scene dependent es-

timation of the setup parameters such as camera cal-

ibration data, image resolutions, exposure times, en-

abling or disabling denoising, etc. is an interesting fu-

ture direction.

Experimenting with other hardware such as an in-

frared projector-camera combination might also im-

prove our system, however this hardware is less com-

monly used.

ACKNOWLEDGEMENTS

We gratefully express our gratitude to the European

Regional Development Fund (ERDF), the Flemish

Government and the Flemish Interdisciplinary insti-

tute for Broadband Technology (IBBT), which are

kindly funding part of the research at the Exper-

tise Centre for Digital Media. Part of the work is

also funded by the European research project IST-2-

511316-IP : IP-RACINE (Integrated Project Research

Area CINE). We also like to thank our colleagues,

especially Maarten Dumont and Steven Maesen, for

their time and effort in this work.

REFERENCES

Balcisoy, S. and Thalmann, D. (1997). Interaction be-

tween real and virtual humans in augmented reality.

In CA ’97: Proceedings of the Computer Animation,

page 31, Washington, DC, USA. IEEE Computer So-

ciety.

Betke, M., Gips, J., and Fleming, P. (2002). The Camera

Mouse: visual tracking of body features to provide

computer access for people with severe disabilities.

Neural Systems and Rehabilitation Engineering, IEEE

Transactions on [see also IEEE Trans. on Rehabilita-

tion Engineering], 10(1):1–10.

Chen, Y., Su, C., Chen, J., Chen, C., Hung, Y., and Fuh, C.

(2001). Video-based eye tracking for autostereoscopic

displays. Optical Engineering, 40:2726.

Cheung, S. S. and Kamath, C. (2004). Robust techniques

for background subtraction in urban trafﬁc video. Pro-

ceedings of Video Communications and Image Pro-

cessing, 5308:881–892.

Crowley, J. L. (1997). Vision for man machine interaction.

Robotics and Autonomous Systems, 19(3-4):347–359.

Crowley, J. L., Coutaz, J., and Brard, F. (2000). Things that

see: Machine perception for human computer interac-

tion. ICommunications of the A.C.M., 43(3):55–64.

De Decker, B., Mertens, T., and Bekaert, P. (2007). In-

teractive collision detection for free-viewpoint video.

In GRAPP 2007: Proceedings of the Second Interna-

tional Conference on Computer Graphics Theory and

Applications, pages 114–120.

GRAPP 2008 - International Conference on Computer Graphics Theory and Applications

448

Dubois, E. and Sabri, S. (1984). Noise Reduction in Im-

age Sequences Using Motion-Compensated Tempo-

ral Filtering. Communications, IEEE Transactions on

[legacy, pre-1988], 32(7):826–831.

Erol, A., Bebis, G., Boyle, R. D., and Nicolescu, M.

(2005). Visual hull construction using adaptive sam-

pling. In WACV-MOTION ’05: Proceedings of the

Seventh IEEE Workshops on Application of Computer

Vision (WACV/MOTION’05) - Volume 1, pages 234–

241, Washington, DC, USA. IEEE Computer Society.

Eyetoy Sony (2003). http://www.eyetoy.com.

Freeman, W. T., Anderson, D. B., Beardsley, P. A., Dodge,

C. N., Roth, M., Weissman, C. D., Yerazunis, W. S.,

Kage, H., Kyuma, K., Miyake, Y., and Tanaka, K.

(1998). Computer vision for interactive computer

graphics. IEEE Comput. Graph. Appl., 18(3):42–53.

Freeman, W. T., Tanaka, K., Ohta, J., and Kyuma, K.

(1996). Computer vision for computer games. In FG

’96: Proceedings of the 2nd International Conference

on Automatic Face and Gesture Recognition (FG ’96),

page 100, Washington, DC, USA. IEEE Computer So-

ciety.

Gonzalez, R. C. and Woods, R. E. (1992). Digital Im-

age Processing. Addison-Wesley Longman Publish-

ing Co., Inc., Boston, MA, USA.

Gorodnichy, D., Malik, S., and Roth, G. (2002). Nouse Use

your nose as a mouse-a new technology for hands-free

games and interfaces. Proceedings of International

Conference on Vision Interface (VI2002), pages 354–

361.

Guitar Hero Sony (2005). http://www.guitarherogame.com.

Isard, M. and Blake, A. (1998). Condensation – conditional

density propagation for visual tracking. International

Journal of Computer Vision, 29(1):5–28.

Jaume, A., Varona, J., Gonzalez, M., Mas, R., and Perales,

F. J. (2006). Automatic human body modeling for

vision-based moion capture. WSCG.

Kalman, R. (1960). A new approach to linear ﬁltering

and prediction problems. Transactions of the ASME–

Journal of Basic Engineering, 82(Series D):35–45.

Konami (1981). http://www.konami.com.

Kyuma, K., Lange, E., Ohta, J., Hermanns, A., Banish, B.,

and Oita, M. (1994). Artiﬁcial retinas-fast, versatile

image processors. Nature, 372(6502):197–198.

Laurentini, A. (1994). The visual hull concept for

silhouette-based image understanding. IEEE Trans.

Pattern Anal. Mach. Intell., 16(2):150–162.

Li, P., Zhang, T., and Pece, A. (2003). Visual contour track-

ing based on particle ﬁlters. Image Vision Comput.,

21(1):111–123.

Magnor, M. A. (2005). Video-Based Rendering. AK Peters

Ltd.

Martin, W. and Aggarwal, J. K. (1983). Volumetric descrip-

tions of objects from multiple views. IEEE Transac-

tions on Pattern Analysis and Machine Intelligence,

5(2):150–158.

McIvor, A. M. (2000). Background subtraction techniques.

Metaxas, D. and Terzopoulos, D. (1993). Shape and non-

rigid motion estimation through physics-based syn-

thesis. IEEE Trans. Pattern Anal. Mach. Intell.,

15(6):580–591.

Mishima, Y. (1993). Soft edge chroma-key generation

based upon hexoctahedral color space. U.S. Patent

5,355,174.

M¨uhlmann, K., Maier, D., Hesser, J., and M¨anner, R.

(2002). Calculating dense disparity maps from color

stereo images, an efﬁcient implementation. Int. J.

Comput. Vision, 47(1-3):79–88.

Nintendo Gameboy (1998). http://www.gameboy.com.

Nintendo Wii (2006). http://wii.com.

Open Dynamics Engine (2001). http://www.ode.org/.

Parent, R. (2001). Computer animation: algorithms and

techniques. Morgan Kaufmann Publishers Inc., San

Francisco, CA, USA.

Point Grey Research (2007). http://www.ptgrey.com.

Rubio, J. M. B., L´opez, F. J. P., Hidalgo, M. G., and Varona,

X. (2006). Upper body tracking for interactive appli-

cations. AMDO.

Scharstein, D. and Szeliski, R. (2002). A taxonomy and

evaluation of dense two-frame stereo correspondence

algorithms. Int. J. Comput. Vision, 47(1-3):7–42.

Sega Saturn (1994). http://www.sega.com.

Singstar Sony (2004). http://www.singstargame.com.

Smith, A. R. and Blinn, J. F. (1996). Blue screen matting. In

SIGGRAPH ’96: Proceedings of the 23rd annual con-

ference on Computer graphics and interactive tech-

niques, pages 259–268, New York, NY, USA. ACM

Press.

Spacek, L. A. (1986). Edge detection and motion detection.

Image Vision Computing, 4(1):43–56.

Vezhnevets, V., Sazonov, V., and Andreeva, A. (2003). A

survey on pixel-based skin color detection techniques.

Graphics and Media Laboratory, Faculty of Compu-

tational Mathematics and Cybernetics, Moscow State

University, Moscow, Russia.

Welman, C. (1993). Inverse kinematics and geometric con-

straints for articulated ﬁgure manipulation. Master’s

thesis, B.Sc. Simon Fraser University.

Willey, M. (1997). Design and implementation of a stroke

interface library.

Woetzel, J. and Koch, R. (2004). Real-time multi-stereo

depth estimation on gpu with approximative disconti-

nuity. 1st European Conference on Visual Media Pro-

duction (CVMP 2004), pages 245–254.

Wren, C. R., Azarbayejani, A., Darrell, T., and Pentland,

A. P. (1997). Pﬁnder: Real-time tracking of the hu-

man body. IEEE Trans. Pattern Anal. Mach. Intell.,

19(7):780–785.

Yang, R. and Pollefeys, M. (2003). Multi-resolution real-

time stereo on commodity graphics hardware. cvpr,

01:211.

A MULTI-CAMERA FRAMEWORK FOR INTERACTIVE VIDEO GAMES

449
