6 EXPERIMENTAL RESULTS
An experimental platform, called RoPa, has been
conceived. The RoPa platform is a complex of
MATLAB programs for simulation and control of
walking robots evolving in uncertain environments
according to SSTA control strategy.
A number of eight causality orderings of the
robotic structure have been implemented on RoPa.
Figure 4 presents the interface of this application
for the causality structure with four free joints. The
four degrees of freedom are thus consumed: one to
fulfil the kinematics restriction; one to ensure the
desired value of the θ angle of the robot body and
two for the desired values
000
xz
ˆ
O(O,O)
of the robot
body.
The causal ordering is activated by selecting the
causal variable cz=[15 25 0].
Figure 4: RoPa Graphic User Interface.
The stability of this evolution is graphical
represented by a stability certificate of the evolution.
This certificate attests the stability index of the
active pair of legs in any moment.
7 CONCLUSIONS
The experiments performed on RoPa demonstrate
the efficacy and adaptability of the proposed method
when the walking robots evolve in uncertain
environments. All the causal orderings are perfectly
integrated in RoPa structure proving the correctness
of the theoretical results.
The mathematical model developed in the paper
becomes an element of the VCDS walking robot
model. The robustness of this mathematical model
was proved by many experimental results
.
Further investigations will be directed towards a
hexapod robot performing a task in uncertain
environment.
REFERENCES
Cubero S., 2001. A 6-Legged Hybrid Walking and
Wheeled Vehicl
e. 7-th International Conference on
Mechatronics and Machine Vision in Practice, USA.
CWR, 2003. The Climbing and Walking Robots, Home
Page,
www.uwe.ac.uk/clawar.
Fulgenzi, C., Spalanzani A., Laugier C., 2007. Dynamic
Obstacle Avoidance in uncertain environment
combining PVOs and Occupancy Grid,
Robotics and
Automation
, 2007, pp.1610-1616.
Galt S., Luk L., 1999. Intelligent walking gait generation
for legged robots
. Proc. 2-th International Conference
on Climbing and Walking Robots
, pp.605-613.
Jung, S., Hsia, T.C., Bonitz, R., 2004. Force Tracking
Impedance Control of Robot Manipulators Under
Unknown Environment.
IEEE Transactions on
Control Systems Technology,
12(3), 474-483.
Kiguchi, K., Watanabe, K., Izumi, K., Fukuda, T., 2000.
Application of Multiple Fuzzy-Neuro Force
Controllers in an Unknown Environment Using
Genetic Algorithms,
Proc. of IEEE International
Conference on Robotics and Automation
, pp. 2106-
2111.
Kiguchi, K., Miyaji, H., Watanabe, K., Izumi, K., Fukuda,
T.,2000. Design of Neuro Force Controllers for
General Environments Using Genetic Programming,'
Proc. of the Fourth Asian Fuzzy Systems Symposium
(AFSS2000)
, pp. 668--673.
Nanayakkara, T., Watanabe K., Izumi, K., Kiguchi, K.,
2001. Evolutionary Learning of a Fuzzy Behavior
Based Controller for a Nonholonomic Mobile Robot in
a Class of Dynamic Environments,
Journal of
Intelligent and Robotic Systems
, Vol. 32, No. 3, pp.
255--277.
Nanayakkara, T., Watanabe, K., Kiguchi, K., Izumi, K.,
2001. Fuzzy Self-Adaptive Radial Basis Function
Neural Network-Based Control of a Seven-Link
Redundant Industrial Manipulator,
Advanced
Robotics,
Vol. 15, No. 1, pp. 17--43.
Sisil Kumarawadu, Keigo Watanabe, Kazuo Kiguchi, and
Kiyotaka Izumi, Neural Network-Based Optimal
Adaptive Tracking Using Genetic Algorithms,
Proc.of
4th Asian Control Conference,
pp105-110.
Schmuacer U., Schneider A. Ihme T., 1996. Six Legged
Robot for Service Operations.
Proc. of EOROBOT’96;
IEEE Computer Society Press
, pp:135-142.
Thirion, B., Thiry, L., 2001. Concurent Programming for
the Control of Hexapod Walking.
7-th International
Conference on Mechatronics and Machine Vision in
Practice,
USA.
