MODELING THE WEB AS A FOREST OF TREES

Fathi Tenzakhti

Computer Science Department, University of Nizwa, Oman

Keywords: Internet, Web, Replication, Tree model, Response time, Dynamic Programming.

Abstract: This study tries to demonstrate that the World Wide Web (the Web for short) could be modeled as a forest

of trees. Each Web site has its own tree for which it is the root. Since trees were extensively studied in the

literature, many problems related to performance, fault-tolerance and availability of the Web could be

understood more easily and the existing body of knowledge about trees could be applied to solve these

problems.

1 INTRODUCTION

The World Wide Web (Web for short) is a very

important source of information, and Web services

are being promoted as the next generation

technology for Business to Business (B2B) and

Business to Consumer (B2C) E-commerce.

Unfortunately, the Web suffers from some

drawbacks from which we state slow response time

and high rate of unavailability especially in the

EAST. Solving these problems in an efficient and

simple way requires understanding the topology of

the Web and how information travels from a Web

site to its clients.

In this study, we try to show that it is safe and

sound to model the Web as a forest of trees. Each

Web site is the root of a tree along which

information from the Web site to its clients travels.

The argument is that in a given period of time

(around 6 hours), each Web site has a set of clients

accessing it. Given that the Internet routes are stable

(V. Paxon, 1997), the information traveling from the

Web site to its clients take the same root during this

period of time

Consequently, each Web site is the root of a tree

whose leafs are the clients of this Web site during

the period

. The internal nodes of the tree are

intermediary nodes that could be clients to the Web

site. Information from the Web site to its clients

travels along the path of this tree. Since the Web is a

collection of Web sites, it is safe to say that the Web

could be modeled as a forest of trees. Each Web site

being the root of its tree.

In the rest of the paper, section 2 presents studies

that have assumed that the Web is modeled as a

forest of trees. Section 3 presents the organization of

the Web and tries to show that the tree modeling is

safe and accurately describes how the information

flows between the Web site and its clients. Section 4

presents the benefits of such modeling and how it

affects the way the replica placement problem in the

Web is solved. Finally section 5 concludes the

paper.

2 RELATED WORK

To the best of my knowledge, the first study that has

assumed the Web as a set of trees is the one in (B.Li

et al., 1997) The authors assumed the Web as a

forest of trees (the tree model for short); each tree is

rooted at the target Web server. This tree model

reduced the problem of placing Web proxies to

placing copies on a tree and helped optimize a

performance measure for the target Web server

subject to system resources and traffic pattern.

Specifically, the study was interested in finding the

optimal placement of multiple web proxies (M)

among potential sites (N) under a give traffic

pattern.

The study in (F. Tenzakhti, 2006) has assumed

that the routes along witch information flows from

Web servers to clients form a tree rooted at the Web

server. It then considered the problem of finding a

minimum cost residence set that optimizes the cost

of servicing access requests in a read-only

environment taking into account the capacity

constraint of the links.

216

Tenzakhti F. (2008).

MODELING THE WEB AS A FOREST OF TREES.

In Proceedings of the Fourth International Conference on Web Information Systems and Technologies, pages 216-219

DOI: 10.5220/0001513302160219

 SciTePress

3 WWW AS A FOREST OF

TREES

The tree model that we advocate for the Web

depends on the stability of the Internet routing

methods. If the routes on the Internet are stable, the

routes used by clients to access the Web server will

form a shortest path tree (or routing tree) rooted at

the server. Existing studies in (V. Paxon, 1997) have

pointed out that in practice most routes in the

Internet are stable. It has been found that 80% of

routes change at a frequency lower than once a day.

(Krishnan et al, 2000) have traced the routes from

Bell Lab’s Web server to 13,533 destinations. They

have found that almost 93% of the routes are stable

during their experiments. Therefore the stability of

Internet routing is a realistic assumption that can

reduce the Web arbitrary topology to a forest of

trees.

Given the stability of Internet routing (V. Paxon,

1997) , an object requested by a client

and located

at server

s travels through a path

s →

r →

r …→

r → c , called a preference path

and is denoted by

),( cs

. The preference path

consists of a sequence of nodes with the

corresponding routers. Routes from

to the various

clients form a routing tree along which requests are

propagated. Consequently, for each server

s , a tree

T rooted at s could be constructed to depict the

routing tree, and the entire Web could be represented

as a collection of such routing trees, each routed at a

given Web server. Formally, a routing tree is the

union of the preference paths.

Each server

s knows the preference path from

itself to any client

. This information can be

extracted and periodically refreshed from the routing

database kept by the routers (Anne Benoit et al,

2006). The routing information allows the

comparison of network distances (e.g. number of

hops) among servers within a given platform. A user

issues one request at a time for a Web page, which is

fetched to the user as a single unit.

In the tree

, when a client c sends a request to

access a server s, the request is always sent to the

root along the preference path. If the server is

replicated, the request meets a replica on its way and

the requested object is available, it is served by the

replica. Otherwise it has to travel all the way to the

root where it is serviced by s. Note that if there is a

replica closer to the client

c but not enroot between

c and s, it is ignored.

According to this tree model, the network

topology is thus represented by a graph

G = (V, E)

where

= V is the number of nodes and E is the

set of edges and represent physical links connecting

these nodes. Nodes are routers, Web servers or a

combination of both (servers provide the

information a client is looking for). Routers are

connected via wide-area links to form the

communication network.

Some routers, called

gateways, provide connections to the outside

Internet. These are the gateways through which all

requests enter the system.

4 BENEFITS OF TREE

MODELLING

Replication is a technique of storing copies of shared

objects on servers where they are frequently

accessed. It is used to address the scalability

problem of popular sites (Anne Benoit et al, 2006).

Replication improves efficiency by allowing

operations to use local replicas instead of remote

ones (Anne Benoit et al, 2006, F. Tenzakhti et al,

2003).

The replica placement problem deals with many

issues. It tries to find how many replicas are needed

in the replicated system, where to place these

replicas, how to route requests to the appropriate

replica etc… (F. Tenzakhti et al, 2003, B.Li et al.,

1997). In this study, we are mainly interested in

where to place a given number of replicas. Along the

study, we propose to use the word proxy to mean a

replica of the whole site. The proxies discussed in

this paper are transparent proxies. They are located

along the routes from clients to a Web server and are

transparent to the clients. A proper placement of

proxies would lead most client requests to be served

at proxies, without letting them travel further to the

server. Since the access patterns of clients and the

sizes of the trees are different, the allocation and

placement of proxies have significant impact on the

overall system performance. To formally define our

problem, we introduce the following notations. Let

),( vud be the distance between any two vertices u

and

v in the tree graph,

T ),( vud is equal to the

length of the shortest path

),( vu

∑

∈

),(),(

vuyx

yxdvud

(1)

Let

),( svp

be the first proxy met while traveling

MODELING THE WEB AS A FOREST OF TREES

217

from

T . This will be referred to as the

optimal proxy. This could be v itself if v is a proxy

if no proxy is met on the way to the root

server. Let

)(vf

be the access frequency from client

to server

during a period of time

and )(v

the load that node

imposes on the proxy ),( svp .

is the replication scheme (the set of proxies for

the tree

T associated with the ),( svp function),

then the total distance to access the proxies is

∑

∈

svpvdPd )),(,()( and the total cost of

accessing the data is given by:

∑

∈

svpvdvfPTC )),(,()()(

(2)

Any node

v whose optimal proxy is ),( svpu

imposes a load

)(v

on u . As a constraint, the set

of nodes whose optimal proxy is

u should not

impose a load that is greater than the capacity

of u . Consequently, if

}),(:{ usxpTxP

∈=

then the following equality must be

satisfied

∑

≤

κβ

)( . Now, for a fixed number of

proxies

1≥k

, let us find the optimal replication

scheme

that minimizes the total access cost

),,(

PTC

over the tree

T , taking into

consideration the capacity constraints

of the

proxies (

being a vector storing the node

capacities). The problem thus reduces to finding:

)},,({),,(

min

κκ

PTCkTC

kPTP

=⊆

= , (3)

subject to

Pux

∈∀≤

∑

,)(

κβ

(4)

We will use dynamic programming to compute the

above recurrence, and therefore find the optimal

replication scheme. Consider tree

T rooted at s

with a set

V of vertices. Assume that the children of

each non-leaf vertex are ordered from left-to-right so

that given any two siblings

u and v , we are able to

determine that

u is to the left of v or vice versa.

For

Tv ∈ , let

T be the subtree of

T rooted at v .

For any

Tu ∈ , we can partition

T into 3 subtrees:

1) Subtree

containing all nodes to the left

u .

2) Subtree containing all nodes in

T .

3) Subtree

.,uv

R containing the rest of the nodes.

Formally, we write:

• }ofleftthetois::{

uxTxxL

vuv

∈

•

T subtree of

T rooted at u

• },:{

,, vuuvuv

LTxTxxR ∪

∉

∈

The central issue here is to divide the problem into

small-scale sub problems. For this reason, we need

to further partition

into smaller subtrees. For

any

∈

, we introduce

}':{

,',,

uofleftthetoisyandRyyL

uvuuv

∈

Given the recursive nature of the solution, equation

3 applied to

T yields

)},({

min

),,(

PTCkTC

kPTP

=⊆

(5)

and

Pux

∈∀≤

∑

,)(

κβ

(6)

where

),,(

kTC

is the minimum access cost

obtained by placing

k proxies in

given the load

capacity

of each node

Tu ∈ .When 1=k , the

only proxy is always placed at root

v . When 1>k ,

we can always find a node

u ,

Tu ∈ and

≠

which satisfies:

1. A proxy is placed at

u ;

2. No proxy is placed in

uvL , ;

3. No proxy is placed in

},{),( vuvu −π .

Assuming

T is partitioned at the node u , and

that

'k proxies are placed in

T , 1 1'

−

≤≤ kk ,

then

'kk

−

proxies are placed in

For all k proxies, we need to find all possible

partitioning points

∈

and all possible values 'k .

Recursively, the proxies are allocated to

T and

the same way as in

T . The dynamic

programming approach can thus be formulated by

the equations (8).

WEBIST 2008 - International Conference on Web Information Systems and Technologies

218

We can therefore write

)',',(),',(),(),,(

,, vuvuuvuvvv

kkRCkTCLkTC

−

+= A , where

∑

∈

−=

)('

βκκ

(7)

⎪

⎩

⎪

⎨

⎧

>≤

∑

∈

−++

≤≤∈

∑∑

=≤

∈∈

kand

xifvxdxf

kand

yif

OtherwiseUndefined

kTC

1)(),()(

)()}'',,

()',,(),

({

min

),,(

κβ

κβκκκ

(8)

In equation (8),

),(

, vuv

A is a constant that could

be undefined if the total load of the nodes in

higher then the capacity

of the node v .

),',(

kTC

is recursively defined in

T with a

capacity constraint

of node u and

all ∈

is further partitioned into

',, uuv

L ,

and

',uv

R around the node 'u where a proxy is put.

The capacity constraint of

with respect to

proxy v is the remaining capacity

obtained by

subtracting from the capacity

of v the total loads

imposed on

v by the nodes in

5 CONCLUSIONS

In this study, we have showed that it is safe and

sound to assume that the Web is a forest of trees.

Each tree is rooted at a Web site. The leaves of the

tree are the client of the Web site during a given

period of time

and the interior nodes are either

clients or routers used to route the requests and

information from and to the client. With this simple

topology, many of the problems related to the

performance and availability of the Web could be

studied easily and simple algorithms based on the

tree topology could be easily developed to solve

these Web problems. In this study, we have shown

how and algorithm for replication in the Web for

performance could be easily developed once the tree

structure is assumed.

REFERENCES

Anne Benoit, V. Rehn, and Y. Robert., 2006. Impact of

QoS on Replica Placement in Tree Networks.

Research Report 2006-48, LIP, ENS Lyon, and

France. Available at graal.ens-lyon.fr/~yrobert/.

B. Li, M.J. Golin, F. Italiano, X. Deng, K. Sohraby., 1999.

On the Optimal Placement of Web Proxies in the

Internet, Proc. IEEE INFOCOM, pp. 1282-1290.

F. Tenzakhti, 2006. Optimal Placement of Web Proxies in

the Internet with Link capacity constraints, Journal of

Digital Information Management, Vol.4. No. 4.

F. Tenzakhti, M. Ould Khaoua, K. Day, 2003. On the

Availability of Replicated Content in the Web.

International Journal on computing and information

Sciences, Vol 1. No.1, pp. 51-60.

P. Krishnan, D. Raz, and Y. Shavitt, 2000. The cache

Location Problem, IEEE/ACM Transactions on

Networking, vol. 8, no. 5, pp. 568-582.

V. Paxson, 1997 End-to-End Routing Behavior in the

Internet, IEEE/ACM Transactions Networking, vol. 5,

no. 5, pp. 601-615.

MODELING THE WEB AS A FOREST OF TREES

219
