TAXONOMY LEARNING FOR THE ROMANIAN LANGUAGE

USING SOTA AND WORDNET

Viorica R. Chifu, Ioan Salomie

Department of Computer Science, Technical University of Cluj-Napoca, Romania

Emil Şt. Chifu, Corina Grumazescu

Department of Computer Science, Technical University of Cluj-Napoca, Romania

Keywords: Ontologies, taxonomy learning, unsupervised neural network.

Abstract: Ontologies are widely used today in various domains such as information retrieval, semantic Web, NLP

tasks or for describing specific domains like certain branches of medicine. While there are many tools that

can be used for learning domain ontologies for English, when learning domain specific ontologies for

Romanian, we face a lack of available tools and resources. Moreover, due to the complexity of the

Romanian grammar, processing of Romanian text corpora is also difficult. This paper focuses on building a

domain specific ontology for the Romanian language using machine learning techniques. The taxonomy

learning process is based on an unsupervised neural network. The resulting modules are intended to be used

for semantic annotations of traceability services in meat industry.

1 INTRODUCTION

Today, digital technologies generate a huge quantity

of information. Most of this information can be

found in text format on the Internet as Web pages

and other resources. This large amount of

information would be useless if it could not be

searched, extracted and processed. The problem is

that usually the extracted information is not always

relevant for users’ purposes. In order to ensure an

information extraction that is useful for the user, a

search mechanism that provides maximum of

relevant information and minimum of irrelevant one

is necessary. In the traditional way of using popular

search engines such as Google, the information is

looked up by keywords specified by the user. Thus,

the retrieved documents are only those that contain

the specified keywords, although many documents

contain the desired semantic information where

synonyms are used instead of the searched

keywords. A solution to this problem would be the

embedding/association of semantic information

into/with the documents, the so called Semantic

Web.

This can be done by documents annotation using

a set of specific markup tags and using ontologies to

specify the meaning of the annotations. Such an

approach implies the creation of a domain specific

ontology. Ontology building is a time consuming

and complex task which requires a high degree of

human intervention. This is the reason why

nowadays there is a considerable research effort in

the domain of automatic ontology building.

This paper presents the automatic building of a

domain specific taxonomy out of textual

descriptions from Web sites (Maestro, 2007)

(CrisTim, 2007) of Romanian meat industry

companies. Our taxonomy learning tool is based on

SOTA (Self-Organizing Tree Algorithm) (Herrero,

2001) and WordNet. The learned taxonomy is part

of an ontology used for semantic annotation of Web

services. The concepts in the taxonomy are semantic

descriptions of the inputs and outputs of the

operations provided by a Web service.

The paper is organized as follows. Section 2

reviews several ontology learning frameworks,

while section 3 presents the taxonomy learning tool.

Section 4 gives a qualitative evaluation of the

experimental results. Conclusions and future

directions are presented in sections 5.

169

R. Chifu V., Salomie I., ¸St. Chifu E. and Grumazescu C. (2008).

TAXONOMY LEARNING FOR THE ROMANIAN LANGUAGE USING SOTA AND WORDNET.

In Proceedings of the Fourth International Conference on Web Information Systems and Technologies, pages 169-174

DOI: 10.5220/0001521601690174

 SciTePress

2 RELATED WORK

There is a multitude of reported ontology learning

frameworks investigated by survey works of

(Buitelaar, 2005) (Gómez-Pérez, 2003). We only

enumerate two such frameworks as being the most

related to ours.

In (Alfonseca, 2002), the terms are represented

with distributional (contextual) signatures, similar

with our vectors of occurrences in different

documents (contexts). The ontology learning is a

top-down process. The cited work uses decision tree

learning.

Witschel combines decision trees and text

mining techniques to extend a taxonomy (Witschel,

2005). The word similarities are calculated by

comparing words only on sentence-based co-

occurrences. A small sub-tree of the GermaNet

hierarchy (the German equivalent of WordNet) is

used as training data.

Another category of approaches is based on

lexico-syntactic patterns, known as Hearst patterns

(Hearst, 1992), which contain phrases suggesting

taxonomic relations: such as, (and | or) other,

including, especially, is a. In (Cimiano and Staab,

2005) (Cimiano, 2005) a combination of clustering

and Hearst patterns is used.

Our ontology learning is based on SOTA and

WordNet. In the case of SOTA, the concept

clustering is done in a top-down manner, the upper

levels being generated before the lower levels

(which are more detailed). The growth of the tree

can be stopped at any desired level of the hierarchy,

thus obtaining a more general or a more specific

ontology. We use SOTA and WORNET to learn a

domain specific ontology for Romanian language.

3 TAXONOMY BUILDING

Our domain taxonomy has been automatically built

from a domain text corpus consisting of html pages

with information about meat products. The pages

were colleted from Web sites of Romanian meat

industry companies (Maestro, 2007) (CrisTim,

2007). The taxonomy learning process has two

steps: term extraction, and taxonomy building and

pruning. In the term extraction step, the relevant

terms (words or phrases) for the taxonomy building

are extracted from the domain text corpus. These

extracted terms become the candidates for the

concept names in the final learnt taxonomy.

In the

taxonomy building and pruning step, the identified

terms become concepts, and taxonomic (isA)

relations are established between them, by actually

building a tree having the concepts in its nodes. The

pruning phase avoids the potentially uninteresting

concepts for the taxonomy. The term extraction

process and the taxonomy building and pruning are

presented in detail in the following two subsections.

3.1 Term Extraction

The candidates for concept names are identified in a

three phase text mining process over the domain

corpus. In the first phase a linguistic analysis is

performed on the corpus, in the second phase a set of

linguistic patterns are applied in order to identify

domain specific terms, while in the third phase a

morphological analysis is performed.

3.1.1 Linguistic Analysis

In the linguistic analysis phase, the domain text

corpus is first annotated with information about the

part of speech (POS) of every word with the help of

the Brill POS tagger (Brill, 1999). Brill tagger can

only be trained by a supervised learning process

starting from an already POS tagged corpus. In order

to train Brill tagger for Romanian, we used ROCO,

an annotated Romanian text corpus which consists

of articles from Romanian newspapers (a collection

of 40 million words) collected from the Web. The

ROCO corpus was tokenized and POS tagged with

the RACAI tools (Tufiş, 1999), having an annotation

accuracy of 98%.

Our original (untagged) corpus consists of 130

documents collected from Web sites of Romanian

meat industry companies (Maestro, 2007) (CrisTim,

2007). The evaluation of the trained tagger was

performed on our corpus and the accuracy,

calculated as the ratio of correct tags out of the total

number of tags, was 91%.

3.1.2 Identifying Domain Specific Terms

The phase of identifying domain specific terms is

based on recognizing linguistic patterns (noun

phrases) in the domain text corpus. To extract

domain specific terms from the corpus, we have

implemented a noun phrase (NP) chunker which

identifies noun phrases in the linguistically

annotated text corpus. Our NP chunker is written by

using lex and yacc.

The written yacc syntax rules of

the grammar essentially consist of a head noun

together with its pre/post-modifiers (attributes). The

pre-modifiers of a head noun can be indefinite

determiners and adjectives. The post-modifiers of

the head noun can be possessive pronouns,

WEBIST 2008 - International Conference on Web Information Systems and Technologies

170

adjectival phrases and prepositional phrases.

In the

Romanian language, like in the other languages, a

noun phrase can be nested within another noun

phrase, with no depth limit. This nesting process is

represented in the grammar by recursive rules. Our

noun phrase chunker works well on the sublanguage

of meat processing and product descriptions. For

instance, consider the sentence: “Oferta de produse

cuprinde aproximativ 65 de sortimente, punctul forte

fiind reprezentat de specialitatile si produsele crud

uscate.” (The product offer includes about 65

assortments, the strong point being represented by

the specialties and the dry cruel products.) The

chunker identifies “Oferta de produse”,

”sortimente”, “punctul forte”, “specialitati”, and

”produse crud uscate” as noun phrases .

3.1.3 Morphological Analysis

Since the concepts of our taxonomy are designated

by noun phrases, we decided to do morphological

analysis only for nouns, adjectives and pronouns.

The morphological analysis is done in three steps. In

fact, it is not a proper morphological analysis, but

rather a lemmatizing process. For each token (word)

we extract its lemma – the base form of the word,

with no suffixes like definite articles or plural

endings. This would be a simple task in case of the

English language, since the plural ending is usually

“-s” (with some exceptions in case of irregular

nouns). However, the lemma extraction for the

Romanian language is quite complex. Unlike

English, the determined article is a suffix, so it must

be removed. What actually complicates things is the

fact that Romanian is the only neo-Latin language

that has preserved the three genders (masculine,

feminine and neuter). When considering removing

the plural endings, the problem lies in the fact that

neuter nouns have similar plural endings with

feminine nouns, while considering removing an

article for singular nouns the neuter nouns will have

similar suffixes with the

masculine nouns. Also, the

case of a noun having different suffixes in

nominative and accusative case than in genitive or

dative case should be considered.

A lemmatizing process would be much easier if

more information concerning the nouns would be

available, such as gender or case. The only

information currently available in the pre-processed

texts is the number: singular or plural. In order to

extract the lemma, we have written a lex lemmatizer

working in a three step approach which is

implemented as a set of regular patterns. The first

step of the lemmatizing process was to remove the

definite article from both singular nouns and plural

nouns. In the second step, the plural endings from

the plural nouns were removed. The third step looks

for adjectives and removes their plural endings and

then looks for the nouns determined by each

adjective trying to keep a gender and case agreement

between them.

We have used the words' lemmas and we have

enforced the preservation between adjective and

noun in order to avoid redundant information. The

redundant information is that when two flexional

forms (for example a plural form and a form with

definite article) of the same noun phrase are

considered as occurrences of two different tokens,

not as the same token. Moreover, because we use

WordNet lookup for the common hypernym of two

taxonomy siblings, it will search for the word's

lemma which is common for the two siblings.

WordNet uses a morphological component, in order

to remove the plural endings of the words searched,

but this works for English words. As we populate

the WordNet database with Romanian lemmas of the

words (nouns and nounphrases), it is obvious why

lemma extraction is needed.

3.2 Taxonomy Building and Prunning

For learning the domain ontology, we use the SOTA

algorithm, an unsupervised neural network with a

binary tree topology which is available as SOTArray

(Herrero, 2001). The SOTArray classifies the initial

data set only in the leaves of the binary tree that it

develops, the inner nodes being empty. Because of

this, we decided to label the inner nodes starting

from the leaves to the root (bottom-up), and to do

that we will search the WordNet database for the

most specific common hypernym of every two

sibling nodes. We consider an isA relationship

between a node and its parent. Since WordNet

contains only English words, we have modified the

WordNet database, by populating it with Romanian

nouns and noun phrases. A more detailed description

of the learning process is presented in the following

sections.

3.2.1 The Learning Process

The taxonomy learning is based on the Self-

Organizing Tree Algorithm (SOTA) (Herrero,

2001). A learned SOTA hierarchy is playing the role

of a learned taxonomy.

In our setting, the noun phrases identified in the

corpus are considered as terms, and these terms are

classified in a SOTA tree during the process of

taxonomy building. To make possible the SOTA

TAXONOMY LEARNING FOR THE ROMANIAN LANGUAGE USING SOTA AND WORDNET

171

classification of the terms, a term document matrix

representation for each term has to be chosen. The

term document matrix contains a term vector on

each row. On each row, the first column entry is the

actual term (noun or noun phrase), then the next

entries represent the number of occurrences of the

word in each document. So the size of the

association dictionary will be n x m, where n is the

total number of terms taken into consideration

(nouns and noun phrases) and m is the total number

of documents + 1.

In order to obtain the term document matrix, a

processing of the corpus is needed. We have written

some C and yacc programs for this task. The term

document matrix is given as input to SOTArray and

the ontology is obtained.

The SOTA algorithm combines aspects of

hierarchical clustering with SOM (Dittenbach,

2002). The clustering algorithm in SOTA is a top-

down process: the tree grows starting from its root,

and then developing into more detailed

classifications in the lower hierarchical levels. This

growing stops when a predefined level of

classification detail is reached. The level of detail is

set according to the distribution of probability

obtained by randomization of the data set to be

classified. The SOTA algorithm can be applied to

any data set in which the data items can be encoded

as numerical vectors in a vector space. Moreover, a

measure of similarity between data items in the

vector space has to be defined. The output of SOTA

is a binary tree that follows the principles of the

growing cell structures algorithm (Fritzke, 1994). In

this algorithm, a binary tree is trained by adapting its

nodes to the characteristics latent in the input data

set. In both SOTA and the growing cell structures,

the tree-like output space can freely grow until

adapting as much as possible to the variability of the

input data space.

When classifying terms in a SOTA tree, the

development of new nodes can be stopped at a

taxonomic level corresponding to the desired level

of classification detail. Alternatively, new nodes can

grow until reaching a complete classification of the

terms extracted from the corpus, i.e. until having a

single term in every leaf of the tree.

Taxonomy pruning is achieved by avoiding

terms occurring in too few documents of the corpus,

specifically in less than 1-2% of the total number of

documents in the corpus. Such terms cannot be

considered as relevant to become concepts of the

domain.

3.2.2 Integrating WordNet with SOTArray

The ontology structure obtained with the SOTA

algorithm has the form of a binary tree of noun

phrases. In every leaf we have one noun phrase. This

means that SOTArray classifies the terms so that

only the leaves have terms from the corpus. This is

why we need to label all the interior nodes by

integrating WordNet into SOTArray. The labelling

process is achieved in a bottom-up recursive tree

traversal. The goal is to find the most specific

common WordNet hypernym for every pair of

sibling nodes, starting from the leaves and ascending

towards the root in the tree hierarchy. A list of all

the direct and indirect hypernyms for all the

meanings of the term is obtained for each sibling

node by querying WordNet. The two lists associated

to the two siblings are compared and intersected

such that all the common hypernyms are found and

only the most specific of them is kept. This most

specific hypernym, which is the lowest in the

WordNet taxonomy, will be associated to the parent

node of the two sibblings.

In order to be able to label the tree inner nodes

with most specific common hypernyms of the

descendants, such hypernyms must be present in the

WordNet database. As the WordNet database is for

English, we had to populate it with Romanian nouns

and noun phrases. This was done by using WNgrind.

The WNgrind tool generates WordNet database files

from WordNet source files, also known as

“lexicographer files”. The lexicographer files

contain synsets (sets of synonyms). The format of a

lexicographer file for Romanian language is

presented below.

{parizer_pentru_copil, parizer,@ }

{parizer_cu_ciuperci, parizer,@ }

{parizer_cu_ardei, parizer,@ }

..................

Figure 1: A part of a lexicographer file for the Romanian

language.

There is only one synset per line. Inside a synset, the

entities are separated by spaces or tabs. There are

also two types of supported pointers: lexical

pointers, which illustrate relations between word

forms, and semantic pointers, which illustrate

relations between word semantics. We are more

interested in semantic pointers (hypernym) in order

to focus on the isA relationships in a taxonomy.

Figure 3 presents the populated WordNet with

Romanian concepts.

WEBIST 2008 - International Conference on Web Information Systems and Technologies

172

Figure 2: The populated WordNet with Romanian

concepts.

3.2.3 OWL Translation

The obtained taxonomy is in the SOTA Newick

format and we decided to translate it into the OWL

standardized format (OWL, 2006). The reason for

our choice is that OWL ontologies are used in a

large variety of applications, since OWL is

recommended by W3C. We have written a Newick -

OWL translator in C++ to translate the taxonomy

into the OWL format.

Figure 3: A part of learned taxonomy.

4 EXPERIMENTAL RESULTS

In Figure 3 a part of the learned ontology view with

the Protégé (Noy, 2003) ontology editor is illustrated.

The English translations of some taxonomy concepts

are given in italics.

Table 1 shows the lexical precision and recall of

the learned taxonomy. Recall (1) is defined as the

ratio of (manually classified as) relevant terms that

are correctly extracted from the analyzed corpus

over all the terms extracted from the corpus, and

Precision (2) is the ratio of correctly extracted terms

over all the extracted terms.

Recall

corpus

extracted

all

correct

(1)

Precision

extracted

all

correct

(2)

In our method the precision is much better than the

recall. The modest value of the recall is due to the

low grammatical quality of the corpus (spelling and

punctuation mistakes, the lack of diacritical marks).

Table 1: Evaluation results for learned taxonomy.

Recall Precision Learned

Taxonomy

62% 87%

5 CONCLUSIONS

In this paper we have presented an unsupervised

taxonomy learning approach for the automatic

building of a domain specific taxonomy from textual

descriptions presented in Web sites of Romanian

meat industry companies. The taxonomy has been

built in the framework of the Maestro project

(Maestro, 2007).

The proposed learning method is based on the

SOTA algorithm and WordNet. WordNet is obtained

by populated WordNet with concepts for the

Romanian language. The advantages of SOTA are

its efficiency and the short convergence time.

Moreover, SOTA was used, since one of the

interests of this paper is the correlation between

terms which is fulfilled by clustering. This method is

rather general and can be applied to any set of data

that can be encoded as data item vectors and allows

the measurement of the similarity between data

items. We are especially interested in the correlation

between terms (the similarity of terms in a given

context) rather than in term synonymy. The obtained

ontology is a set of concepts and relations between

TAXONOMY LEARNING FOR THE ROMANIAN LANGUAGE USING SOTA AND WORDNET

173

them and it can offer an abstract view of the

application domain.

As future directions, we intend to process the

Romanian texts in order to exploit more complex

lexical information about the parts of speech, like

gender, case, and so on. This would be very helpful

in lemma extraction and other tasks concerning

automated text analysis. Another development

possibility would be a more complex and complete

WordNet database for Romanian. This would help to

illustrate more complex relations between concepts

(like part-of) and will lead to a more complex

ontology. Also, we plan to experiment in the future

with other corpora from different domains.

ACKNOWLEDGEMENTS

This work was supported by the PI-1020 (333/2007)

project within the framework of the “Research of

Excellence” program initiated by the Romanian

Ministry of Education and Research.

REFERENCES

Alfonseca E., and Manandhar, S., 2002. Extending a

lexical ontology by a combination of distributional

semantics signatures. In A. Gómez-Pérez, V.R.

Benjamins, eds., 13th International Conference on

Knowledge Engineering and Knowledge Management,

LNAI, Springer, pp. 1-7.

Brill, E.,1999. A simple rule-based part-of-speech tagger.

ANLP’92, 3rd Conference on Applied Natural

Language Processing, pp. 152-155.

Buitelaar, P., Cimiano, P., Grobelnik, M., and Sintek, M.,

2005. Ontology learning from text. Tutorial at the

ECML/PKDD workshop on Knowledge Discovery and

Ontologies.

Cimiano, P., Staab, S.,2005. Learning concept hierarchies

from text with a guided hierarchical clustering

algorithm. ICML workshop on Learning and

Extending Lexical Ontologies with Machine Learning

Methods.

Cimiano, P., Pivk, A., Schmidt-Thieme, L., and Staab, S.,

2005. Learning taxonomic relations from

heterogeneous sources of evidence. In P. Buitelaar, P.

Cimiano, B. Magnini, eds., Ontology Learning from

Text: Methods Applications and Evaluation, IOS

Press, pp. 59-73.

M. Dittenbach, D. Merkl, and A. Rauber, Organizing and

exploring high-dimensional data with the Growing

Hierarchical Self-Organizing Map”, In L. Wang, et al.,

eds., 1st International Conference on Fuzzy Systems

and Knowledge Discovery, vol. 2, 2002, pp. 626-630.

Gómez-Pérez, A., and Manzano-Macho, D., 2003. A

survey of ontology learning methods and techniques.

OntoWeb Deliverable 1.5.

Hearst, M. A.,1992. Automatic acquisition of hyponyms

from large text corpora. 14th International Conference

on Computational Linguistics.

Herrero, J., Valencia, A., and Dopazo, J., 2001. A

hierarchical unsupervised growing neural network for

clustering gene expression patterns. Bioinformatics 17,

pp.:126–136.

Khan, L., and Luo, F., 2002. Ontology construction for

information selection. 14th IEEE International

Conference on Tools with Artificial Intelligence, pp.

122-127.

Miller, G., A., Beckwith, R., Fellbaum, C., Gross, D., and

Miller, K., 1993. Introduction to WordNet: An on-line

lexical database. Technical report, Princeton. CSL

Report 43, revised March.

Noy, N.F., Crubézy, M.,et al., 2003. Protégé-2000: An

Open-Source Ontology-Development and Knowledge-

Acquisition Environment. AMIA Annual Symposium

Proceedings.

Studer, R., Benjamins, V., and Fensel, D., 1998.

Knowledge Engineering: Principles and Methods,

Data and Knowledge Engineering, 25(1-2), pp.:161 –

197.

Tufiş, D., 1999. Tiered Tagging and Combined Classifiers,

In F. Jelinek and E. Nöth, eds., Text, Speech and

Dialogue, Lecture Notes in Artificial Intelligence

1692, Springer.

Witschel, H. F.,2005. Using Decision Trees and Text

Mining Techniques for Extending Taxonomies. In

Proceedings of Learning and Extending Lexical

Ontologies by Using Machine Learning Methods

Workshop at ICML-05.

Maestro: http://www.maestro.ro/, 2007

CrisTim: http://www.cirstim.ro/, 2007.

OWL: http://www.w3.org/TR/owl-guide/, 2006

WEBIST 2008 - International Conference on Web Information Systems and Technologies

174
