AN EXTREME PROGRAMMING RELEASE PLAN THAT

MAXIMIZES BUSINESS PERFORMANCE

Marcelo C. Fernandes, Antonio Juarez Alencar

Institute of Mathematics, Federal University of Rio de Janeiro, P.O. 68530, Rio de Janeiro, Brazil

Eber Assis Schmitz

Electronic Computer Center, Federal University of Rio de Janeiro, Rio de Janeiro, Brazil

Keywords:

XP, release planning, project management and business performance.

Abstract:

This paper proposes a multi-criteria method to evaluate the value of XP release plans to business. The method,

which is based upon information economics and stochastic modeling, helps XP practitioners to select the

release plan that maximizes business performance, with considerable consequences for the use of information

technology as a competitive advantage tool.

1 INTRODUCTION

eXtreme Programming (XP) is the most well-known

and the most used of the many agile methodologies

available (Noble et al., 2004). It best ﬁts circum-

stances where neither the software customers nor the

development team are sure about how the software

should be built. In these circumstances, as presented

in the Agile Manifesto (Beck et al., 2001), XP en-

courages the continuous alignment of development

goals with the needs and expectations of software

customers. Note that this approach differs substan-

tially from the initial ﬁxed plan suggested by tra-

ditional methodologies (Jayaswal and Patton, 2006).

For XP practitioners (developers and software cus-

tomers) software development plans are just well-

intended estimates of what should be done in the im-

mediate future. Therefore, they should be revised fre-

quently (Beck and Fowler, 2000).

Building a release plan is one of the ﬁrst and

most important tasks of the XP software development

process. To organize the activities that should take

place prior to the next software release the develop-

ment team does the following: estimates how long

it will take to build each story, assesses the release

velocity

, warns software customers about technical

risks and provides them with an overall budget. Also,

How many manhours are available to be spent in each

release.

software customers help to specify and prioritize sto-

ries and deﬁne their business value (Beck et al., 2001;

Beck and Fowler, 2000). It is a joint effort between

software customers and the development team requir-

ing the involved parties to be collaborative, repre-

sentative, committed, knowledgeable and have the

necessary decision powers to reach a consensus by

negotiation (Boehm and Turner, 2004). These re-

quirements create a pluralist and complex decision-

making environment due to the diverse backgrounds,

attitudes, goals, and cognitive dispositions of soft-

ware customers and software development profes-

sionals(Cavaleri and Obloj, 1993).

This environment is particularly difﬁcult to soft-

ware developers accustomed to solitary computer-

related activities, where the ideas of shared learning,

reﬂection workshops, collaborative decision making,

business opportunities, value, risk and strategy may

be overwhelming. Not to mention the difﬁculties fre-

quently faced by laymen customers in determining

what can and cannot be technically achieved. All

of this makes the selection of a release plan a chal-

lenging task, especially with the vague requirements

and uncertain environment that are frequently associ-

ated with the development of complex systems (Nerur

et al., 2005).

This paper presents a more realistic decision mak-

ing me-thod to be used in the eXtreme Programming

Release Planning phase. The method helps XP prac-

titioners to select the release plan that maximizes the

C. Fernandes M., Juarez Alencar A. and Assis Schmitz E. (2008).

AN EXTREME PROGRAMMING RELEASE PLAN THAT MAXIMIZES BUSINESS PERFORMANCE.

In Proceedings of the Tenth International Conference on Enterprise Information Systems - ISAS, pages 12-22

DOI: 10.5220/0001670100120022

 SciTePress

business performance from a multi-criterion point of

view. The paper starts by considering multiple fea-

sible release plans as proposed by Li et al. in (Li

et al., 2006). Then it extends Li’s model to allow it to

deal properly with uncertainty. Subsequently, in the

same fashion, information economics, as described

by Parker et al. in (Parker et al., 1988), is extended to

link business performance to software development in

an uncertain environment.

The remainder of this paper is organized as fol-

lows. Section 2 presents a review of both information

economics and the release plan strategy presented by

Li et al. Section 3 introduces the method proposed in

this paper with the help of a case study. Section 4 for-

malizes the proposed method. Section 5 discusses the

implications of the method for different dimensions

of XP management. Finally, Section 6 presents the

conclusions of this paper.

2 LITERATURE REVIEW

2.1 Information Economics

Information Economics (IE) is a multi-criterion ap-

proach to the evaluation of IT investments conceived

in the IBM Research Center at Los Angeles and

Washington State University by Parker et al. (Parker

et al., 1988) in the 1980’s and later perfected by

Parker (Parker, 1995). In the information economics

paradigm the evaluation of an IT investment takes into

account two different dimensions: the ﬁrst concerns

the impact of the project on the business itself and

the second on IT. In formal terms, given an IT related

project P and the weights w

, w

, ··· , w

Value(P) = BB

+ ITB

− BR

− ITR

(1)

where

• BB

, the business beneﬁts, reﬂects the beneﬁts to

a business directly yielded by investing in P;

• ITB

, the information technology beneﬁts, ex-

presses the beneﬁts to information technology

yielded by the investment;

• BR

, the business risk, represents the risk incurred

by a business as a result of making the investment;

and

• ITR

, the information technology risk, is a mea-

surement of the risk concerning the IT aspects of

The business beneﬁts yielded by investing in

project P, BB

, is the weighted sum of ﬁve different

value factors, i.e.

= w

× ROI

+ w

× SM

+ w

× CA

× MI

+ w

× CR

where

• ROI

, the return on investment, is the ratio of

money gained or lost by investing in P in the

course of time;

• SM

, the strategic match, is the valueyielded from

directly supporting the implementation of existing

business strategies;

• CA

, the competitive advantage, is the value that

stems from creating a new business strategy, a

new service or product, or a new approach to over-

coming a competitive barrier;

• MI

, the management of information, is the value

derived from information support to one or more

critical success factors of an enterprise or line of

business; and

• CR

, the competitive response, reﬂects IT

projects intended to catch up with competition.

In turn, ITB

is the result of w

× SA

, where

, the strategic architecture, indicates the degree of

alignment of the investment with the overall IT strat-

egy (the IT blueprint).

The business risk BR

is the result of w

× OR

where OR

is the organizational risk, i.e. the degree

to which the organization is capable of implement-

ing the changes required by the project. Components

of the capacity of implementing such changes should

include: management support, maturity in the use of

computers and a realistic assessment of the business

functions, and processes that have to be modiﬁed to

complete the project successfully.

Finally, the IT risk ITR

is the weighted sum of

three risk factors:

ITR

= w

× DU

+ w

× TU

+ w

× IR

where

• DU

, the deﬁnitional uncertainty, is a measure of

the degree to which requirements have been prop-

erly elici-ted and speciﬁed. It also assesses the

probability of nonroutine changes;

• TU

, the technical uncertainty, indicates the readi-

ness of the technology domain to undertake the

project. For example, are the technical skills re-

quired by the project readily available or can they

be easily obtained? Are the hardware dependen-

cies easily overcome? Are there difﬁcult software

interconnectivity problems to be resolved? Etc.;

• IR

, the infrastructure risk, assess the nonproject

investment necessary to accommodate the project

itself, such as: faster and more reliable forms of

communication, improved methods of data access

AN EXTREME PROGRAMMING RELEASE PLAN THAT MAXIMIZES BUSINESS PERFORMANCE

and new data dictionary facilities required by the

project.

Factors ROI

, SM

, CA

, MI

, CR

and SA

take

value in the set { 0, 1, ··· , 5}, where zero indicates that

a given factor does not contribute to the value cre-

ated by the project and ﬁve that its contribution is

paramount. Intermediate values indicate intermediate

contributions. The risk factors OR

, DU

, TU

and

also take value in the set {0, 1, ··· , 5}. However,

in this case, zero indicates that no meaningful risk is

associated with a factor and ﬁve that the associated

risk is considerable. Intermediate values indicate in-

termediate risk intensity. In (Parker et al., 1988) one

ﬁnds a complete descriprion of possible meanings to

both beneﬁts and risk factor scores. Tables 1 and 2

are examples of such meanings.

Table 1: Return on investment worksheet.

Score Return on Investment

0 zero or less

1 1% to 299%

2 300% to 499%

3 500% to 699%

4 700% to 899%

5 900% and over

Table 2: Strategic match worksheet.

Score Meaning

0 The project has no direct or indirect relationship to the

achievement of stated corporate (or departmental) strategic

goals.

1 The project has no direct or indirect relationship to such

goals, but it will improve operational efﬁciency.

2 The project has no direct relationship to such goals, but the

project is a prerequisite system (precursor) to another system

that achieves a portion of a corporate strategic goal.

3 The project has no direct relationship to such goals, but the

project is a prerequisite system (precursor) to another system

that achieves a corporate strategic goal.

4 The project directly achieves a portion of a stated corporate

strategic goal.

5 The project directly achievesa stated corporate strategic goal.

The weights w

, w

, ··· , w

are used to indicate

the relative importance of value and risk factors. It

should be noted that the value of each weight may

vary from business to business and that they should

be chosen in accordance with business mission and

goals. Saaty’s analytic hierarchical process (AHP)

may be used to choose the values of these weights ac-

cordingly (Saaty, 2001). Table 3 presents a summary

of the evaluation of a XP release plan using Informa-

tion Economics.

2.2 The XP Risk-Driven Method

The Risk-Driven Method for eXtreme Programming

release planning conceived by Li et al. (Li et al.,

2006) is a technique that allows XP practitioners to

make better decisions about selecting the functional-

ities that are going to be implemented in the next re-

lease. The method advocates the creation of many

feasible release plans whose value to business, risk

and required effort are presented to a decision maker.

For example, based on data collected from pre-

vious projects the development team has deﬁned a

time frame of six weeks for each release size, 200

manhour as the release velocity and that there is a

set S = {S

, S

} of ﬁve stories to be im-

plemented in the ﬁrst release. After some consider-

ation the development team and software customers

have described in some detail what the software is

supposed to do in each one of these ﬁve stories. As

a result, a dependency relation has been established

among the stories, together with their relative busi-

ness value and development effort. Figure 1 presents

the dependenciesamong the stories and Table 4 shows

the relative business value of each story, as deﬁned by

the software customers using AHP (Saaty, 2001), and

the development effort, as estimated by the develop-

ment team, using the “Yesterday’s Weather” concept

(Ganis et al., 2005).

1 S

Figure 1: Stories dependency network.

The next step in the method is to rank all feasible

release plans by business value, where each feasible

Table 3: Information economics summary worksheet.

Domain Factor Score Weight Weighted Score

ROI 2 5 10

SM 4 5 20

Business CA 0 1 0

MI 4 2 8

CR 0 1 0

OR 2 5 10

SA 4 2 8

DU 2 2 8

IT TU 1 2 2

IR 3 2 6

Value 48

Risk 24

ICEIS 2008 - International Conference on Enterprise Information Systems

Table 4: Stories’ business values and development effort.

Story Relative Business Value (%) Effort (manhour)

40 70

35 80

15 40

5 50

5 25

Total 100 270

release plan is a set of stories that complies with the

release velocity and the stories’ dependencyrelations.

The ranking algorithm starts by building a binary tree

where the tree root S

is a dummy story, which re-

quires no effort to be implemented, and each other

node represents a real story. Moreover, arcs connect-

ing a child node to its father are decorated with the

expressions “Implement” and “Do not implement” in-

dicating whether that story is part of a release plan.

Figure 2 shows part of this tree.

Implement Don’t implement

Implement Don’timplement

Figure 2: A partial representation of a solution space tree.

Note that in such a tree each path from the root

to a leaf represents a possible release plan and that

all possible release plans are represented in the tree.

However, only those release plans that comply with

the release velocity and the stories’ dependency rela-

tions are the feasible release plans. For the given set

S of stories Table 5 shows the corresponding feasible

release plans.

Table 5: The feasible release plans and their stories.

Feasible Release Plans

Identiﬁer Stories

FRP

, S

FRP

, S

FRP

, S

FRP

The next step in the method consists in the iden-

tiﬁcation and evaluation of the risks concerning each

story, using requirement, estimation, technology and

personnel uncertainties as main criteria. Table 6

presents these criteria together with the corresponding

risk factors. The risk of each story is then evaluated

against the seven risk factors. Table 7 shows the risk

exposure mechanism used for each evaluation and Ta-

ble 8 the meaning of the risk scores.

For example, being exposure = probability ×

impact, if the story size estimation of S

has a high

probability of being wrong and this leads to a medium

impact on the project ﬁnances, then the risk exposure

is assessed as “Unacceptable” and 4 points are added

to the story risk exposure. Table 9 shows the risk ex-

posure of each story.

Table 6: Risk Taxonomy.

Risk Type Risk Factors Risk Description

Requirement Unstable Story Story is volatile because of the

volatile environment

Vague Story Story is unclear in businessgoals

or for system design

Estimation Story Size Wrong estimations of story size

Team

Productivity

Wrong estimations of team pro-

ductivity

Technology Architecture Con-

ﬂict

How to combine new stories into

existent architecture

Difﬁcult

Implementation

How to implement stories

Personnel Customers Customers are not domain ex-

perts in business

Table 7: A qualitative mechanism for risk assessment.

Risk Exposure Probability

Low Medium High

Low 1 2 3

Impact Medium 2 3 4

High 3 4 4

Finally, Table 10 shows all information provided

to software customers for decision making about the

feasible release plan to be implemented. Note that the

total risk scored by a feasible release plan is the sum

of the risks scored by each of its composing stories.

Both the total business value and the total effort re-

quired to build the release plan are calculated in the

same manner.

3 AN EXAMPLE

According to Seneca (4 BC - 65 AD ), the Roman

philosopher: “rules make the learners path long, while

examples make it short and successful”. As a result,

the method proposed in this paper is introduced step-

by-step with the help of a real-world inspired exam-

ple. In Section 4 the method is formalized.

AN EXTREME PROGRAMMING RELEASE PLAN THAT MAXIMIZES BUSINESS PERFORMANCE

Table 8: Scores for risk exposure.

Score Meaning

4 Unacceptable

3 Critical

2 Signiﬁcant

1 Minor

Table 9: Stories’ ranked risk.

Risk Factor S

Unstable Story 3 2 2 1 1

Vague Story 2 3 2 2 1

Story Size 3 3 2 2 1

Team Productivity 2 2 2 1 1

Architecture Conﬂict 2 1 1 1 1

Difﬁcult Implementation 3 3 2 2 1

Customers 1 1 1 1 1

Total 16 15 12 10 7

3.1 Context Information

Performance management (also known as perfor-

mance appraisal, performance evaluation or perfor-

mance review) is the process of creating a work en-

vironment where people are able to perform to the

best of their abilities. The process begins when a job

position is recognized as needed in an organization.

A job description is then written, describing the du-

ties, responsibilities, qualiﬁcations, hierarchical po-

sition and reporting structure of its occupant. This

is done through job analysis, an activity concerned

with the understandingof the competencies, skills and

goals required to accomplish the needs of an organi-

zation.

The next step in performance management is to

develop a performance measurement model that indi-

cates how well each employee is performing his job

and whether his individual goals are aligned with cor-

porate objectives. The 360 degree or multi-rater is the

most widely used measurement model. It provides

employees with performance feedback from super-

visors, co-workers, peers, customers, suppliers and

reporting staff. Finally, the organization is able to

design a performance development plan, a key step

to effective performance management, where the fol-

lowing actions take place:

• Providing effective orientation, education and

training;

• Designing effective compensation and recogni-

tion models that reward people for their contribu-

tions to business performance;

• Selecting appropriateworkers with a due selection

process;

Table 10: Risks, business values and efforts for each FRP.

Feasible Total Risk Total Business Total Effort

Release Plan Score Value (%) (manhour)

FRP

23 90 190

FRP

23 80 200

FRP

17 75 150

FRP

9 40 70

• Providing on-going coaching and feedback;

• Conducting performance development discus-

sions;

• Providing career development opportunities; and

• Assisting with exit interviews to understand why

valued employees leave the organization.

Obviously, all of this is of paramount importance

when building lasting high-performance organiza-

tions (Armstrong, 2006).

3.2 Step 1: The Release Plan Size and

Velocity

Initially, based on statistical data of previous projects

software customers together with the development

team have established a time frame of six weeks for

each system release and 200 manhour as the release

velocity.

3.3 Step 2: Deﬁning the Set of Stories

Also, they have deﬁned that the ﬁrst release should,

at most, contemplate the stories listed in Table 11 and

that these stories are constrained by the dependency

relations shown in Figure 1.

Table 11: Candidate stories to the ﬁrst system release.

Story Description

Label Name

Employee

Data

Import the necessary employee data from

the payroll system into the performance

management database.

Competency

Dictionary

Develop user interfaces for viewing,

searching, and changing information

about competencies.

Job

Description

Implement interfaces that make it possi-

ble to establish competency-employee re-

lationship.

Appraisal

Matrix

Create user interfaces to build the ap-

praisal matrix by appraiser.

Performance

Development

Plan

Develop user interfaces to ﬁll out the em-

ployee performance development form.

ICEIS 2008 - International Conference on Enterprise Information Systems

3.4 Step 3: Determining All Feasible

Release Plans

The next step in the method is to estimate the value of

the development effort for each story. Because these

activities have not been executed yet, their duration

can only be estimated.

Unfortunately, in most projects in the real-world

one does not know for certain the value of each dura-

tion. Those have to be estimated by experts, who use

past project information, their own opinion or a com-

bination of both to express the uncertainty related to

duration in the form of Probability Density Functions

(PDFs) (Vose, 2000). See (Hubbard, 2007) for a dis-

cussion on how these estimates may be obtained in

real-world projects.

With the support of past projects information (XP

Yesterday’s Weather concept), three point estimates

have been provided for each story, indicating their

minimum, most likely and maximum expected devel-

opment effort. Table 12 presents these ﬁgures.

Table 12: Total effort for performance appraisal stories.

Effort (manhour)

Story Minimum Most Likely Maximum

62 70 80

72 80 85

35 40 48

45 50 66

22 25 30

Following the footsteps of (Li et al., 2006) a tree

similar to the one described in Figure 2 is built. In

such a tree each node is further decorated with a tri-

angular probability density function (TPDF), indicat-

ing the estimated effort required to develop the story

in the node. The TPDF is one of the most widely

used functions to describe activity development effort

(Chung, 2003). Figure 3 partially presents such a tree.

Implement Don’t implement

Implement Don’timplement

0.00

0.02

0.04

0.06

0.08

0.10

0.12

62 68 74 80

Effort

Probability

0.00

0.02

0.04

0.06

0.08

0.10

0.12

62 68 74 80

Effort

Probability

0.00

0.02

0.04

0.06

0.08

0.10

0.12

0.14

0.16

72 74 76 78 80 82 84 86

Effort

Probability

0.00

0.02

0.04

0.06

0.08

0.10

0.12

0.14

0.16

72 74 76 78 80 82 84 86

Effort

Probability

Figure 3: The partial representation of a decorated solution-

space tree.

Note that, in a similar fashion, each path from the

root to a leaf represents a possible release plan con-

taining the stories in the path. Also, it should be noted

that all possible release plans are represented in the

tree. Table 13 connects stories to their respective pos-

sible release plans.

Table 13: Possible release plans.

Possible Release Plans

Identiﬁer Stories

PRP

, S

PRP

, S

PRP

, S

PRP

, S

PRP

, S

PRP

, S

PRP

, S

PRP

In order to determine which possible release

plans are feasible, considering the 200 manhour

release velocity, a Monte Carlo stochastic simu-

lation model has been built, with the support of

the software @Risk, from Palisade Corporation

(www.palisade.com). Each scenario in the simulation

process is composed of a random number indicating

the effort necessary to implement each story. The to-

tal effort required to develop each release plan is the

sum of the efforts necessary to develop the stories in

the release. Table 14 presents the ﬁgures collected

during simulation.

Table 14: Simulation results.

Variable Scenario

1 2 3 4 . . . n

76.0 65.5 70.7 77.7 .. . 68.7

75.9 74.4 78.4 77.7 .. . 82.7

38.1 42.0 43.6 36.8 .. . 43.5

48.2 58.4 52.5 46.5 .. . 63.3

24.4 23.8 28.3 25.5 .. . 22.9

PRP

224.6 222.1 230.1 227.3 . . . 237.6

PRP

200.2 198.3 201.7 201.8 . . . 214.7

PRP

224.6 222.1 230.1 227.3 . . . 237.6

PRP

214.5 205.7 221.1 217.7 . . . 217.8

PRP

200.1 198.3 201.6 201.9 . . . 214.7

PRP

190.0 181.9 192.7 192.2 . . . 194.8

PRP

152.0 139.9 149.2 155.3 . . . 151.4

PRP

76.0 65.5 70.7 77.7 .. . 68.7

Due to the random nature of the Monte Carlo

method the data concerning the effort required to de-

velop a release plan, collected during simulation, pro-

vide an estimate for the cumulative density function

that describes the actual release effort (Chung, 2003).

System users together with the development team

have determined that only the release plans comply

with the stories’ dependency constraints and that have

AN EXTREME PROGRAMMING RELEASE PLAN THAT MAXIMIZES BUSINESS PERFORMANCE

at least an estimated 80% chance of complying with

the release velocity are considered to be feasible.

For example, Figure 4 shows the cumulative den-

sity function of possible release plan 6 (PRP

), built

using the data presented in Table 14. Note that in 80%

of all simulated scenarios the release requires 195.14

manhour to be developed, indicating that the chance

of this release complying with the release velocity

threshold of 200 manhour is actually higher than 80%.

There are only two other possible release plans that

satisfy this requirement: PRP

, that requires 153.62

manhour to be completed in 80% of all simulated sce-

narios, and PRP

, that requires 73.99 manhour.

X <=195.14

80%

0.2

0.4

0.6

0.8

175 182 189 196 203 210

Effort

Probability

Figure 4: The Cumulative Density Function of PRP

effort.

3.5 Step 4: Evaluating the Business

Value of All Feasible Release Plans

Subsequently the feasible release plans are subjected

to evaluation using the multi-criterion approach of In-

formation Economics. For the purpose of the IE eval-

uation each release plan is considered to be a project

on its own. Because the three feasible release plans

PRP

, PRP

and PRP

have not been developed yet,

the score of each IE factor can only be estimated. As

a result, three point estimates have been provided for

each one of these factors. Table 15 presents these ﬁg-

ures.

The weights w

, w

, ··· , w

indicate the relative

relevance of each factor and may vary from business

to business in accordance with strategy, mission and

goals. Table 16 presents the weights deﬁned by high

management, using AHP (Saaty, 2001), considering

the reality of the health insurance business .

In order to determine the IE score of each feasi-

ble release plan a Monte Carlo stochastic simulation

model has been built, with the support of the soft-

ware @Risk. Each scenario in the simulation process

is composed of a random number indicating a valid

score for each IE factor, together with the total score

Table 15: Feasible Release Plan’s Scores.

Information Feasible Estimate

Economics Release Minimum Most Maximum

Factors Plan Likely

PRP

4 5 5

ROI PRP

2 3 4

PRP

1 1 2

PRP

4 5 5

SM PRP

2 3 5

PRP

0 0 1

PRP

1 2 3

IR PRP

0 1 3

PRP

0 0 1

Table 16: Relative weights of each factor.

Weight Factor Relative Weight

15%

Total 100%

calculated as shown in Equation (1). Table 17 shows

the data collected during simulation of PRP

Table 17: IE simulation results for PRP

Variable Scenario

1 2 3 4 . . . n

ROI 5 4 5 4 . . . 5

SM 4 5 5 4 . . . 4

CA 4 5 4 4 . . . 4

MI 4 5 4 5 . . . 5

CR 3 5 5 4 . . . 5

SA 5 4 5 5 .. . 5

OR 0 1 3 0 . . . 0

DU 1 0 1 2 . . . 1

TU 3 4 4 3 . . . 3

IR 1 3 2 1 . . . 2

BB 2,06 2,20 2,13 2,14 ... 2,05

BR 0 0 0 0 . . . 0

ITB 0.75 0.75 0.75 0.75 . . . 0.75

ITR 0.65 0.65 0.65 0.63 . . . 0.65

Value(PRP

) 2,16 2,30 2,23 2,26 . . . 2,15

The data concerning the value of each feasible

release plan, collected during simulation, provide

an estimate for the cumulative density function that

ICEIS 2008 - International Conference on Enterprise Information Systems

describes the actual feasible release plan IE value

(Chung, 2003). Figure 5 shows the cumulative den-

sity function for the feasible release plans PRP

PRP

and PRP

PRP

0.2

0.4

0.6

0.8

0.4 0.9 1.4 1.9 2.4

IE Value

Probability

Figure 5: The Cumulative Density Function for the IE value

of PRP

, PRP

and PRP

In this case, the choice of the release plan that

maximizes business performance is straightforward

as the PRP

commutative density function dominates

the others, i.e., always yields higher values. For more

complex decisions under uncertainty one may ﬁnd it

useful to consult (Wang, 2002; Baird, 2004).

4 THE METHOD

To successfully maximize business performance

through the selection of XP release plans, one should

take the following steps:

1. With the help of software customers and the de-

velopment team, establish the size of the release

plan and its velocity;

2. Deﬁne the set of stories that should, at most, be

contemplated in the release, together with its de-

pendency relations;

3. Determine all feasible release plans using the

stochastic risk-driven method, i.e.

(a) Provide three point estimates for the devel-

opment effort of each story, indicating their

minimum, most likely and maximum expected

value;

(b) Build the solution-space tree. Note that each

path from the root to a leaf represents a differ-

ent but possible release plan;

ability density function that indicates the devel-

opment effort of the story represented by the

node;

(d) Build a Monte Carlo simulation model that

properly represents the solution-space tree;

(e) Run the simulation process;

(f) For each scenario of the simulation process

record the release plan total effort, i.e. the sum

of the duration of all stories that are part of that

release plan;

(g) Build the cumulative density function that de-

scribes the effort required by each possible re-

lease plan; and

(h) Discard those release plans that do not com-

ply with the stories’ constraints and that are un-

likely to comply with the release velocity. The

remaining release plans are the feasible ones.

4. Evaluate the business value of each feasible

release plan using an Information Economics

stochastic model, i.e.

(a) For each feasible release plan, provide three

point estimates for each IE factor;

(b) Use AHP to deﬁne relative relevance of each IE

factor;

properly represents the business value of each

feasible release plan;

(d) Run the simulation process;

(e) Build the cumulative density function that de-

scribes the business value of by each possible

release plan;

(f) Choose the feasible release plan that maximizes

business performance.

5 DISCUSSION

At the outset of this paper we undertook to present

a more realistic decision making method to be used

in the eXtreme Programming release planning phase.

Below we answer some key questions about this

method and discuss the implications of their existence

for different dimensions of XP project management.

5.1 Why have the Risk-Driven Method

and the IE Evaluation Model been

Extended?

Since IE was presented in the 1980’s and perfected in

the 1990’s (Parker, 1995; Parker et al., 1988), IE and

its many variants have been used to evaluate IT in-

vestment worldwide in a variety of different circum-

stances (Cumps et al., 2006; Serafeimidis and Smith-

son, 2003; Stewart and Mohamed., 2002). Not sur-

AN EXTREME PROGRAMMING RELEASE PLAN THAT MAXIMIZES BUSINESS PERFORMANCE

prisingly, IE is one of the most frequently referred IT

investment evaluation method in the literature

It is important to mention that Li et al.’s is not the

only XP release planing proposal available in the lit-

erature (Beyer et al., 2004; Boehm and Turner, 2003).

However, as they point out in (Li et al., 2006), the

premises of all these other proposals is that the busi-

ness value of a release plan is not a relevant issue in

the XP paradigm and that detailed requirements and

architectural design are available before implementa-

tion. However, in XP practice, it is rare to come by

a case where these premises hold (Beck and Fowler,

2000). All of this makes both IE and Li et al.’s meth-

ods worth extending.

In the increasingly complex world we live in soft-

ware projects are known to face many different kinds

of uncertainties, whether they are managerial, techni-

cal, political, economical, social, educational or eth-

nical, among others. In such a complex environment

it is neither easy to obtain accurate estimates for the

effort required by a release plan, composed of mul-

tiple stories, nor for the business values of the plans

that are feasible.

To overcome these difﬁculties project managers

need methods and tools that are able to deal properly

with the uncertainties that naturally arises in each esti-

mate upon which they have to rely. By allowing three

point estimates, together with Monte Carlo simula-

tion, to be used in both Li et al.’s Risk-Driven method

and Information Economics we provide a stochastic

model that better reﬂects the reality in which these es-

timates are made. The results yielded by the extended

models are cumulative density functions that, when

properly analyzed, provide a better and more reliable

basis for decision making (Wang, 2002; Baird, 2004).

5.2 How do XP Practitioners Beneﬁt

from Selecting a XP Release Plan

that Maximizes Business

Performance?

XP is an interactive incremental software develop-

ment paradigm based upon the delivery of small in-

crements of functionality, high customer involvement

and commitment to the software project, constant

code improvement and egoless computer program-

ming. As a result, in many circumstances, XP is able

to deliver value to business relatively faster than more

classic methodologies, specially in uncertain environ-

ments.

A consult to Google Scholar (www.scholar.google

.com) easily supports this claim.

However, Denne and Cleland-Huang (Denne and

Cleland-Huang, 2004) have shown that the order in

which software functionalities are delivered may not

only increase its value to business, but may also re-

duce the development cost, allowing expensive and

complex systems to be developed from a proportion-

ately small investment. According to Denne and

Cleland-Huang the selection of the right delivery

planning of software functionalities may allow for:

• Competitive differentiation - when the functional-

ities anticipates the creation of service or product

features that are valued by customers and that are

different from anything else being offered in the

market;

• Revenue generation - although the software func-

tionalities do not provide any unique valuable fea-

tures to customers, they do provide extra revenue

by allowing the organization to offer the same

quality as other products on the market for a better

price;

• Cost savings - when the software functionalities

allow businesses to save money by making one or

more business processes cheaper to run;

• Brand projection - when the software functionali-

ties allow an organization to project itself as being

customer conscious or technologically advanced;

and

• Enhanced customer loyalty - the software fun-

cionalities inﬂuences customers to buy more,

more frequently or both.

Therefore, more value to business delivered ear-

lier tends to reduce costs, increase customer involve-

ment, high management commitment to software de-

velopment, provide a better alignment between the IT

efforts and business strategy, and contributeto the cre-

ation of competitive advantage elements. All of this

tends to increase the attractiveness of XP practices to

business and the market value of XP practitioners.

5.3 Why is the Method Proposed in this

Paper any Better than Li’s Method?

Table 18 compares the method proposed in this pa-

per against the Risk-Driven Method conceived by (Li

et al., 2006), with clear advantage to the former. Fur-

thermore, the proposed method can be easily autom-

atized with the help of macros and a Microsoft Excel

spreadsheet. Note that this has actually being done

with the help of @Risk, an add-in to Excel, to make

it easier to analyze the example introduced in Section

ICEIS 2008 - International Conference on Enterprise Information Systems

Table 18: A comparison between the Risk-Driven Method

and the method proposed in this paper.

Criterion Risk-Driven Proposed

Method Method

Deals properly with uncertain estimates. χ

Evaluates the values of a release plan

from a multi-criterion point of view; in-

cluding beneﬁts to business and IT.

Provides a more accurate evaluation of

the business value of a release plan.

Clearly indicates the criteria to be used

to evaluate a release plan.

Technical and business risks are evalu-

ated by both the development team and

software customers.

Favors more strongly softwarecustomers

evolvement with and high management

commitment to software development.

5.4 Why should XP Practitioners

Embrace the Method Proposed in

this Article?

One of the main goals of the XP software develop-

ment process is to deliver valuable software to busi-

ness on a continuous basis. This is accomplished

by keeping development goals aligned with business

goals at all times, and, as frequently as possible, up-

dating the software being developed with features that

fulﬁll customer’s needs and expectations.

The method propose in this paper helps to estab-

lish a common language between software developers

and business stakeholders, by allowing each release

plan to provide the best possible value to business

from well established multi-criterion point of view.

Moreover, it is important to keep in mind that XP

is not the only agile method available and that its

competitors are continuously improving their devel-

opment strategies and tactics aiming at adding more

value to business. In this sense, the method proposed

in this paper helps to better position XP in the bat-

tle for the preference of software developers and cus-

tomers.

6 CONCLUSIONS

This paper demonstrates the viability of success-

fully extending and combining Li et al.’s Risk-Driven

Method for eXtreme Programming release planning

with Parker’s Information Economics to provide XP

practitioners with more effective means of select-

ing the release plan that maximizes business perfor-

mance.

The resulting method takes into considerations

multiple aspects of business to evaluate the value of

a release plan, deals more easily with the uncertain

estimates that are so common in software projects,

helps to better align the IT efforts with business strat-

egy and favors the establishment of better working re-

lations between system development teams and their

hiring organizations. Furthermore, the method is not

difﬁcult to use and automatize, favoring customer in-

volvement with software development, better deci-

sion making and high management commitment to

the software development process within their orga-

nizations.

REFERENCES

Armstrong, M. (2006). Performance Management: Key

Strategies and Practical Guidelines. Kogan Page, 3

edition.

Baird, B. F. (2004). Managerial Decisions Under Uncer-

tainty: An Introduction to the Analysis of Decision

Making.

Beck, K. and Fowler, M. (2000). Planning Extreme Pro-

gramming. Addison-Wesley, 1

edition.

Beyer, H., Holtzblatt, K., and Baker, L. (2004). An agile

customer-centered method: Rapid contextual design.

In 4

Conference on Extreme Programming and Agile

Methods, pages 50–59, Calgary, Canada.

Boehm, B. and Turner, R. (2003). Using risk to bal-

ance agile and plan-driven methods. IEEE Computer,

36(6):57– 66.

Boehm, B. and Turner, R. (2004). Balancing Agility and

Discipline: A Guide for the Perplexed. Addison-

Wesley.

Cavaleri, S. A. and Obloj, K. (1993). Management Sys-

tems: A Global Perspective. Wadsworth Publishing

Company.

Chung, C. A. (2003). Simulation Modeling Handbook: A

Practical Approach. CRC Press.

Cumps, B., Viaene, S., and Dedene, G. (2006). Manag-

ing for better business-it alignment. IT Professional,

8(5):17–24.

Denne, M. and Cleland-Huang, J. (2004). The incremental

funding method: Data driven software development.

IEEE Software, 21(3):39–47.

Ganis, M., Leip, D., Grossman, F., and Bergin, J. (2005).

Introducing agile development (XP) into a corporate

webmaster environment - an experience report. In

Proceddings of the Agile Conference, pages 145–152,

Denver, CO (USA).

Hubbard, D. W. (2007). How to Measure Anything: Finding

the Value of “Intangibles” in Business. John Wiley.

Jayaswal, B. K. and Patton, P. C. (2006). Design for Trust-

worthy Software: Tools, Techniques, and Methodol-

ogy of Developing Robust Software. Prentice Hall.

AN EXTREME PROGRAMMING RELEASE PLAN THAT MAXIMIZES BUSINESS PERFORMANCE

Li, M., Huang, M., Shu, F., and Li, J. (2006). A risk-

driven method for extreme programming release plan-

ning. Proceeding of the 28th international conference

on Software engineering.

Beck et al., K. (2001). Manifesto for agile software devel-

opment. Available at www.agilemanifesto.org. Last

visited on January 19

, 2007.

Nerur, S., Mahapatra, R., and Mangalaraj, G. (2005). Chal-

lenges of migrating to agile methodologies. Commu-

nications of the ACM, 48(5).

Noble, J., Marshall, S., Marshall, S., and Biddle, R.

(2004). Less extreme programming. Proceedings of

the sixth conference on Australasian computing edu-

cation, pages 217–226.

Parker, M. M. (1995). Strategic Transformation and Infor-

mation Technology. Prentice-Hall, 1

edition.

Parker, M. M., Benson, R. J., and Trainor, E. (1988). Infor-

mation Economics. Linking Business Performance to

Information Technology. Prentice-Hall.

Saaty, T. L. (2001). Decision Making for Leaders. RWS

Publications, 3

edition.

Serafeimidis, V. and Smithson, S. (2003). Information sys-

tems evaluation as an organizational institution: expe-

rience from a case study. Information Systems Jour-

nal, 13:251–274.

Stewart, R. and Mohamed., S. (2002). IT/IS projects selec-

tion using multi-criteria utility theory. Logistics Infor-

mation Management, 15(4):254–270.

Vose, D. (2000). Risk Analysis: A Quantitative Guide. John

Wiley, 2

edition.

Wang, J. X. (2002). What Every Engineer Should Know

About Decision Making Under Uncertainty. CRC.

ICEIS 2008 - International Conference on Enterprise Information Systems
