ARCHITECTURE FOR END USER-DRIVEN COMPOSITION OF

UNDERSPECIFIED, HUMAN-CENTRIC BUSINESS PROCESSES

Todor Stoitsev, Stefan Scheidl

SAP Research, SAP AG, Bleichstr. 8, Darmstadt, Germany

Felix Flentge, Max Mühlhäuser

Telecooperation Group, Darmstadt University of Technology, Darmstadt, Germany

Keywords: Software architectures, distributed applications, end user development, computer supported cooperative

work, ad-hoc workflow.

Abstract: Enterprises are constantly struggling to optimize their business processes in order to gain competitive

advantage and to survive in the fast evolving global market. Often, the only ones to understand the matter

and complexity of these processes are the people, who actually execute them. This raises the need for novel

business process management approaches, which can enable business users to proactively express process

knowledge and to participate in the business process management and design according to their actual

expertise and problem solving strategies. The presented paper describes an architecture, which supports a

framework for end user-driven composition and management of underspecified, human-centric business

processes. The solution builds up on email-integrated task management and enables dynamic generation of

decentralized-emerging process structures through web service-based activity tracking. The captured

process execution examples are shared in central enterprise repositories for further adaptation and reuse.

This enables “seeding, evolutionary growth, and reseeding” of user-defined, weakly-structured process

models towards global best-practice definitions.

1 INTRODUCTION

A significant shift in the view on enterprise

processes has been recognized in the last years.

While conventional workflow solutions are well

suited for static, predefined processes, the

importance of unstructured, knowledge-intensive

work in enterprises raises new flexibility

expectations (Aalst et al., 1999; Schwarz et al.,

2001). This is accompanied with the increasing

demand to enable business users to develop and

exchange substantial business process knowledge,

which could increase the overall enterprise

efficiency (Wiig, 2004). Recent analyst reports

clearly revealed that the traditional enterprise

process modeling perspective is being replaced by

tailoring of business processes according to the

individual point of view and connecting them

towards the achievement of common enterprise

goals (Gartner, 2006). This novel view raises new

challenges for the next generation Business Process

Management (BPM) by stating the fundamental

need to leverage individual expertise of business

users towards the definition and management of

agile business processes.

In the literature End User Development (EUD) is

defined as “a set of methods, techniques, and tools

that allow users of software systems, who are acting

as non-professional software developers, at some

point to create, modify, or extend a software

artifact.” (Lieberman et al., 2006). Within the

presented paper a process model is considered as a

software artifact, which can be enacted and reused to

support underspecified, human-centric processes.

The presented paper is motivated through the

possibility to “render” appropriation of process

models to end users and to “exploit the potential of

opportunity-based and emergent changes” from the

introduction of groupware in enterprises (Wulf &

Jarke, 2004). The paper describes a generic

architecture for enabling EUD of decentralized-

emerging, weakly-structured process models. The

165

Stoitsev T., Scheidl S., Flentge F. and Mühlhäuser M. (2008).

ARCHITECTURE FOR END USER-DRIVEN COMPOSITION OF UNDERSPECIFIED, HUMAN-CENTRIC BUSINESS PROCESSES.

In Proceedings of the Tenth International Conference on Enterprise Information Systems - DISI, pages 165-172

DOI: 10.5220/0001689501650172

 SciTePress

architecture is implemented in the Collaborative

Task Manager (CTM) prototype. The latter is not

explicitly discussed in the paper whereas references

to certain functionalities are mentioned as

clarifications for the presented concepts.

The paper is organized as follows. Section 2

presents related work in the area of agile process

support. Section 3 provides an overview of a

framework for light-weight composition and

management of ad-hoc business processes,

supported through the presented architecture. The

architecture is described in section 4. Conclusions

and future research directions are given in section 5.

2 RELATED WORK

Riss et al. (2005) discuss the challenges for the next

generation BPM by proposing the reuse of emerging

“task patterns” and “process patterns” as alternative

to static workflows. A further task-centric approach

which enables Proactive Information Delivery (PID)

on tasks and instance-based task reuse is presented

by Holz et al. (2005). Task centric approaches

bridging routine and ad-hoc work are also known

(Bernstein, 2000; Jorgensen, 2004). The above

studies present comprehensive strategies for

supporting knowledge work. However, they do not

consider methods or architectures for embedding ad-

hoc process support in the existing working

environment of end users. We suggest that this issue

is important as similarly to tailoring of software

systems, tailoring of ad-hoc processes through the

definition, adaptation and reuse of user-defined task

hierarchies should be ensured through “gentle slope

of complexity” (MacLean et al., 1990), where users

with different business and Information Technology

(IT) background can efficiently shape and exchange

reusable task definitions.

Evidences from related literature show that user

strategies for organizing daily activities are far from

any process or case-definition context and mostly

rely on common office tools such as email (Bellotti

et al., 2005) or personal to-do lists (Bellotti et al.

2004). Agostini et al. (1997) cross the boundaries of

the personal workspace and integrate to-do lists and

email within email-based workflows. However, the

authors do not discuss mechanisms for decoupling

email-based workflows from the system as explicit

process models, and how such models can be

exchanged, adapted or reused. As end users have

different level of technical expertise and attitudes

towards maintaining process data, we suggest that it

is important to consider possibilities for “seeding,

evolutionary growth, and reseeding (SER)” (Fisher

et al., 2004) of user-defined task structures for their

refinement and complementation.

This paper presents a distributed architecture for

supporting enterprise-wide “programming by

example” (Liebermann, 2001) of weakly-structured

process models. This EUD technique supports

unobtrusiveness by enabling generation of ad-hoc

workflows from captured, executed activities, and

yet allowing users to proactively tailor the emergent

processes at use time. The system tracks user actions

on tasks in users’ personal to-do lists and replicates

task data on central server instance. There, personal

to-do lists of different process participants are

integrated to end-to-end processes based on tracked

email exchange for task delegation. Captured data is

disseminated in different server repositories which

enables multiple perspectives on processes: process,

resource or user -centric.

3 FRAMEWORK OVERVIEW

The architecture described in this paper, supports a

framework for light-weight composition and

management of ad-hoc business processes (Stoitsev

et al., 2008). This section provides a high-level

overview of the framework to clarify the

architectural entities described further in the paper.

Aalst et al. (1999) discuss business process

flexibility by suggesting three basic dimensions of a

workflow – “case”, “process” and “resource”

dimension. Human activities thereby comprise cases,

which are handled through corresponding processes,

executed through a sequence of tasks by using

appropriate resources. Unpredictability of ad-hoc

activities implies dynamic adaptations of tasks and

resources and deviations in case handling. The used

framework considers these dimensions through its

entities: tasks, artifacts, human actors and Task

Patterns (TP) (see also Riss et al., 2005).

A framework overview is shown in Figure 1. A

case repository with reusable task structures,

generated through user activities, is shown on the

left hand side – case information is available in

individual workspaces of various users and is

additionally replicated on central enterprise

repositories as described further in this section.

Tasks A and B are part of a concrete collaborative

process. Tasks C and D represent process fragments,

elaborated by domain experts and may be part of

running processes or explicit case descriptions. On

the right hand side, the provision of resources by

external artifact managers is shown. Different type

ICEIS 2008 - International Conference on Enterprise Information Systems

166

of artifacts and their association to tasks is discussed

further in this section.

While user U

interacts with a hierarchical task

list (tasks A … A

2.1

depicted through gray ellipses)

in the local workspace, the system uses web services

to track and replicate all task structure and context

information on three central enterprise repositories:

(i) task tracking repository – holding task structure

and context information associated to task objects

(e.g. subject, description status etc.); (ii) artifact

repository – providing central storage for task

attachments (artifacts); (iii) user repository – storing

information about the involved persons (human

actors) that can be provided as expertise

recommendation if a task is reused later on.

Task delegation over email (A

Æ B) is tracked

to bind the individual task hierarchies (to-do lists) to

a Task Delegation Graph (TDG) (Stoitsev et al.,

2008), which in Figure 1 includes only two users

and is hence highly simplified. Changes on task

instances in running processes are propagated with

notifications iteratively throughout the TDG. This

allows stakeholders to adapt their corresponding

tasks according to the current situation by changing

content or status information.

Tasks may contain references to Externally

Managed Tasks (EMT) (B

Æ C). An EMT

represents a possible execution (breakdown) of a

given task. An EMT reference can be used to fetch

the complete EMT task hierarchy including context

information of the contained task instances from the

server. An EMT can contain further EMT

references. The reference chain ends with a task

without further references (task D). Changes on

EMT trigger notifications to the reusing task

instances. Stakeholders can update to the new

structure or preserve the locally used EMT copy and

release the reference, which corresponds to an apply

TP operation as discussed further in this section.

A task instance can contain different types of

artifacts. Artifacts are files, e.g. Microsoft

Word/Excel documents, archive (zip) files or even

executable files, which are used or generated during

task execution and are associated to tasks e.g. as

attachments. Artifacts can be: (i) locally managed,

non-externalized i.e. not replicated in a remote

repository (black circle in A

2.1

in the client

workspace) – used to store confidential resources;

(iii) Externalized Artifact (EA) (white circle in A

2.1

represents local EA reference to an EA in the artifact

repository – gray circle with a black outline). EAs

are implicitly replicated and matched based on

binary checksums on the server and allow detection

of common tasks based on the usage of similar

resources (e.g. C

and D use the same EA), which

assists towards document-based PID (Holz et al.,

2007); (iii) Externally Managed Artifact (EMA)

(white circle with a black dotted outline in D

2.2

represents an EMA reference to an EMA in the

artifact repository - gray circle with a black dotted

outline). EMAs are notifications-enabled and allow

2.2

External Task

Managers

Task Requester

LOCAL

USER

WORKSPACES

TASK

REPOSITORY

ARTIFACT

REPOSITORY

Task Recipient

External Artifact

Managers

tracking

Task Pattern (XML)

Case Expert

PROCESS

CASE

REPOSITORY

(GUIDANCE)

ancestor

descendant

USER

REPOSITORY

owner /

recipient

2.1

1.1

2.1

2.2

2.1

ÆP

Æ…

1G1

nG1

author

Figure 1: Framework overview.

ARCHITECTURE FOR END USER-DRIVEN COMPOSITION OF UNDERSPECIFIED, HUMAN-CENTRIC

BUSINESS PROCESSES

167

dynamic synchronization of artifacts used in

personal tasks with changes of domain experts. As

an extension to the original framework we suggest

storing data for EMA author in the user repository.

Task-related expertise is stored through basic

user information - user name and id (email address).

Two roles are supported: (i) owner – pointing at the

person, whose individual to-do list contains the task

(e.g. U

); (ii) recipient(s) – pointing at the person(s),

who have received a delegated task in a

collaborative process (e.g. U

The reuse of emerging task hierarchies is

enabled through TPs. A TP contains a task with its

complete sub task hierarchy and context information

of all contained task instances, including artifacts

and human actors. A TP can be exported from an

arbitrary task in the to-do list in the local workspace

or a complete TDG under a given task can be

exported from the task tracking repository. TP can

be stored to local or remote Task Pattern

Repositories (TPR). Local TPR are XML files

(Stotisev et al., 2008). Remote TPR store global

best-practices (TPs) and are extensions to the

original framework, enabling activation of end-to-

end process examples throughout the enterprise

without exchanging TP XML files but through

referring to centrally stored TPs. One implicit

central TPR is the task tracking repository.

When a TDG is extracted, personal task

hierarchies of different process participants are

saved as separate TPs and requester tasks receive

EMT references to the corresponding recipient TPs.

The recipient tasks are generally considered as

suggested TPs for further handling of the requester

tasks. Weakly-structured process models hence

emerge as TPs (process fragments) which are

interlinked based on suggestions. The collaborative

flow is defined through suggested recipients in tasks.

Applying a TP creates the complete task

structure in the local user workspace by feeding all

context information and setting all references to

suggested TPs (EMTs) and used artifacts. EAs and

EMAs are fetched from the artifact repository and

attached to the local tasks in the workspace. All

tasks resulting form TP application are accordingly

replicated on the task tracking repository. Users can

change the prescribed collaborative flow of an

enacted process example by entering different than

the suggested recipients. References to suggested

TPs (EMTs) can be forwarded with delegations or

used by the task owner to fetch the corresponding

EMT and execute the tasks themselves. This allows

opportunity-based and emergent adaptations of

enacted process examples. If a user applies a TP

with suggested TP references (EMTs) from a local

TPR, the locally referenced structures can be

exported iteratively in a default, user-specific remote

TPR so that they can be reused by other users.

To allow tracing of deviating cases,

ancestor/descendant relationships are maintained.

These are set iteratively in task hierarchies, resulting

from TP application (ÆP in A, ÆP

in A

etc.).

Copy/paste operations of task fragments executed

during TP editing in a visual environment also

produce such references. These references allow

comparison of resulting with originating entities

(ancestor – descendant) and comparison of resulting

entities with same origin (descendant – descendant).

As each task instance preserves its ancestor

reference, fine-grained, instance-based traceability

of task reuse is enabled.

4 ARCHITECTURE

This section presents the architecture supporting the

above framework. The term “office applications”

used in the following is a conceptual term and does

not explicitly refer to Microsoft Office or imply the

features offered by this environment. The presented

architecture is implemented in the CTM prototype,

which is integrated in Microsoft Outlook (OL) by

exploiting the fact that tasks and email are offered in

the same office application.

The system has a three-tier architecture

consisting of client, server and persistence layers as

shown in Figure 2. The client layer contains the

logic for the personal task management. The server

layer comprises the components, providing the

tracking functionality, the overall repository access

and data retrieval, and the business logic (e.g.

notifications handling). The persistence layer

encompasses the runtime data storage for task

tracking and the user, artifact and TP repositories.

4.1 Client Layer

The client-side components are integrated in the

office applications environment of the end user. The

focus is set on the email client, which may contain

also certain task management and calendar

functionality.

4.1.1 Office Applications Integration Layer

The task management system is coupled to the office

applications over an Office Applications Integration

Layer (OAIL). The latter enables the usage of email

ICEIS 2008 - International Conference on Enterprise Information Systems

168

for the purposes of the task management system, by

serving as a proxy and enabling email pre-formatting

of outgoing emails and appropriate handling of

incoming emails with task-related content. If task

management functionality is included to some extent

in the office applications environment, the

integration layer should preferably make use of it by

enabling tracking of task-related operations (e.g.

edit, create, delete) through web services. The

integration layer should also provide functionality to

embed the user interface of the task management

system in the office applications environment.

Concretely the CTM front-end is delivered as an OL

Add-In, where the OAIL comprises classes with

proprietary extensions of OL mail and task items,

adding custom properties and a set of event handlers.

Office Applications

Tracking

Repository

TaskMail Calendar

Office Applications Integration Layer

Plug

WS Clients

Mail Server

WS Clients

External

Web

Services

Task

Management

Web Client

Local TaskPattern

Repositories

Persistence

Layer

Server

Layer

Web Services

Client

Layer

Task Pattern

Repositories

Task Management Server

Task Pattern Service

Repository Managers

Task Patterns

Explorer/Editor

Office-Integrated Task

Management Client

Artifact

Repositories

Artifact Service

Repository Managers

Local Artifact

Repositories

HTTPSMTP/IMAP

SMTP/IMAP

SQL SQL/File I/O

SOAP/HTTP

Tracking Service

SQL/File I/O

Artifacts

Explorer

User

Repository

SQL

Figure 2: System architecture.

4.1.2 Office-Integrated Task Management

Client (OITMC)

The Office-Integrated Task Management Client

(OITMC) holds the complete presentation logic for

the task management system within the selected

office application (i.e. the email client). The OITMC

also contains the composition environment for the

personal to-do lists. Additional extended

functionality for the inspection and adaptation of

existing task structures is provided through a Task

Pattern Explorer/Editor (TPE). It enables editing of

local TPs (exported to XML files) as well as the

complete functionality for creating, retrieving and

editing remote TPRs and TP instances. Artifact

handling is provided in an Artifact Explorer (AE)

component. It enables users to add EMAs and

explore their version and history and to further

explore EAs and their referencing tasks through

querying data from the server.

Important parts of the OITMC are the task

management Web Service (WS) clients. These are

responsible for tracking of task related actions on the

task management server and executing updates and

queries on the remote repositories. Additional WS

clients can be plugged in the OITMC to execute

task-related operations on external systems e.g. to

trigger transactions in a workflow or Enterprise

Resource Planning (ERP) system. A simple

approach for binding such external WS in tasks is

e.g. through executable attachments (artifacts).

4.1.3 Local Task Pattern Repositories

Although reuse of task structures should be utilized

on enterprise basis, some task structures can still be

stored locally. On the one hand local TPs can hold

personal best-practices in a private, non-distributed

manner. On the other hand, a local TPR may be used

by caching mechanisms, included in the OITMC, to

store local copies of once retrieved remote TPs in

order to avoid communication overhead for repeated

TP retrieval. Currently local TPRs are XML files,

containing one or more TP definitions as described

by Stoitsev et al. (2008) in an additional repository

element.

4.1.4 Local Artifact Repositories

Artifacts are generally managed in globally

accessible, remote Artifact Repositories (ARs). At

the same time, artifacts can be stored also within

local AR to ensure that sensitive documents will not

be implicitly externalized throughout the enterprise -

such are the locally managed, non-externalized

artifacts. Local ARs can be organized as file system

folders. Additionally, the OITMC can include

caching mechanisms for storing once retrieved

remote artifacts in a local AR, from where these will

be retrieved on subsequent requests.

4.1.5 Task Management Web Client

(TMWC)

The TMWC provides overview of the evolving task

structures beyond the boundaries of the personal

workspace. It allows inspection of the complete

TDGs, where all attributes of the task nodes can be

viewed – status, percent complete, due date etc. as

ARCHITECTURE FOR END USER-DRIVEN COMPOSITION OF UNDERSPECIFIED, HUMAN-CENTRIC

BUSINESS PROCESSES

169

well as artifact lists (attachments). Detailed

overview of the dialog flow for task delegation is

enabled in the TMWC. The overall purpose of this

component is to provide system independent

environment for process navigation, where advanced

users with higher process expertise can inspect work

distribution and identify potential bottlenecks and

optimization possibilities. The TMWC in CTM can

be shown through “Process Info” links in tasks and

emails in the OITMC. Although in CTM the TMWC

currently provides only an overview of the emerging

processes, in advanced implementations this

component may include functionality for dynamic

task changes in the displayed, shared-accessible task

hierarchies (cf. Bernstein, 2000). These should be

accordingly reflected in the OITMC and supplied

with notifications.

4.2 Server Layer

The server layer encompasses two major

components – the mail server and the task

management server. External WS e.g. from ERP

systems (cf. 4.1.2) can also be considered in this

layer. The different components from the server

layer do not necessarily reside on the same host.

4.2.1 Mail Server

The mail server is implicitly included in the

architecture as the exchange of tasks is realized over

email, i.e. this component is used by the office

applications email client and could be e.g. a

Microsoft Exchange server. Furthermore, email can

be used for the propagation of notifications from the

back-end to the clients. Therefore a bidirectional

relation from the task management server to the mail

server is depicted in Figure 2. However the

presented architecture does not rely exclusively on

“computational email” as known email-based

workflows (Agostini et al., 1997) but utilizes WS to

increase performance and extensibility.

4.2.2 Task Management Server

The task management server application provides all

basic services for the system and realizes the

connection of the clients to the remote repositories.

The Tracking Service updates the persistent state

of tasks on the server when these are created or

updated on the client. The service handles

additionally the collaborative flow. All task-related

email exchange is stored in dialog instances, mapped

to the appropriate requester and recipient tasks. All

messages are available in the tracking repository

with text and attachments. The attachments are

replicated to a remote AR. The tracking service

feeds also owner and recipient data in the user

repository to dynamically fill the expertise database.

Notifications on task instance changes (cancel,

complete, delete request) are also propagated though

the tracking service to allow stakeholder adaptations.

The support of offline system usage (personal task

adaptations in a disconnected client) is a complex

issue and is not discussed explicitly in the presented

paper. This mode is generally supported through

tracking buffers on client and server side. On client

side such is a local tracking record file. On server

side, unconsumed notification events are kept in a

DB table. Switching in online mode triggers

evaluations of the client and server records, aiming

to avoid collisions on task actualization e.g. increase

of percent complete for a delegated task cancelled

by the requester. The compensation mechanisms and

collision prevention are not final and still under

research. However, synchronous tracking support

seems currently sufficient as CTM test use takes

place in offices, where users are online.

The Task Pattern Service updates remote TPs,

enables search in the remote TPRs and delivers

remote TP structures to the clients. It further

provides functionality for delivering notifications on

reused, suggested TPs (EMTs). Multiple Repository

Managers can realize the connection to multiple

TPRs of the same or different kind (e.g. database or

file system based). User data is fed to the user

repository analogously to the task tracking.

The Artifact Service provides functionality for

the replication of EAs and for the management of

EMAs on remote ARs. This includes all update,

search and retrieval functionalities. The service can

handle different repository types (e.g. database or

file system based) through appropriate artifact

Repository Managers. Author information of EMAs

is stored in the user repository.

The Tracking Service and the TP Service

communicate with each other to enable setting and

retrieval of ancestor/descendant relationships

between tracked tasks and explicit TP instances.

Both services communicate with the Artifact

Service, to maintain associations of artifacts within

active (tracked) tasks and TPs. All services have

access to the user repository to feed expertise (task

owner/recipient) and (EMA) author information. In

CTM all services are based on the Simple Object

Access Protocol (SOAP) and integrated into a java

application server.

ICEIS 2008 - International Conference on Enterprise Information Systems

170

4.3 Persistence Layer

The persistence layer comprises the task tracking

repository and the user, artifact and TP repositories.

Components used to store different types of data can

reside on physically different hosts. This would

require additional repository mapping functionality

in the respective services for relating the different

entities – tasks, users, artifacts and TP. Currently

CTM implements the different repositories as tables

in a single DB for simplicity reasons. Thereby

entities from the different repositories are associated

through foreign-key relations.

4.3.1 Tracking Repository

This repository stores the data, generated through

tracking of client-side user operations, on the server.

The latest state of all user tasks from the personal

workspaces is replicated in this repository. The

tracking repository provides the input for the web-

based overview of a TDG (generated enterprise

process flow) in the TMWC and stores also all task-

related dialogs, generated through task delegation.

4.3.2 User Repository

The user repository stores human actor information.

Such can be added in the following ways: (i) through

tracking of evolving tasks in running processes i.e.

task creation feeds owner data, task delegation

delivers recipient information; (ii) saving of a

remote TP, containing human actor information

(owner, suggested recipients); (iii) adding and

editing of EMA adds author information. This

approach enables user-based navigation throughout

document and task repositories and tracing what

process fragments and resources are accessed or

submitted by a given user. No domain-specific roles

are introduced currently as this could harm the

generic character of the approach and its ability to

support various user activities in different

enterprises from different business domains.

4.3.3 Remote Task Pattern Repositories

A remote TPR holds reusable task structures. More

than one repository can be maintained within the

system. One implicit TPR is the tracking repository.

However, while task structures in the tracking

repository may be changed frequently when a user

updates their personal to-do list in the OITMC, the

idea of a remote, central TPR is to keep reusable

process fragments in a more consistent manner and

to provide global best-practices. As a TP can

represent an EMT, TP changes must be supported

with appropriate notifications handling to allow

stakeholder adaptations. Remote TPRs can be

implemented using DB tables. Access and

management of different repository types should be

provided in a unified manner by the Task Pattern

Service. Currently CTM supports only one remote,

DB-based TPR in parallel to the tracking repository.

4.3.4 Remote Artifact Repositories

A remote AR holds globally reusable artifacts. One

or more ARs of the same or different kind, e.g. DB

or file system based, should be managed in a unified

manner through the Artifact Service. Currently CTM

uses a single combined AR – a DB table with

artifact context information as name, checksum,

version etc. and links to actual artifact content (files)

on the server file system. All remote artifacts – EAs

and EMAs are currently kept in the same repository

(DB table) where EMAs have additional version

attributes. This can enable conversion of EA to

EMA through extending the EA attributes’ set.

5 CONCLUSIONS & FUTURE

WORK

The paper presents an architecture which

implements an integrated approach, leveraging user

experience with standard office tools for

collaboration and task management towards the

definition of weakly-structured process models by

end users. The underlying approach aims at ensuring

a “gentle slope of complexity” for users engaging in

process tailoring activities. To achieve that, the

architecture enables enterprise-wide “programming

by example” of distributed-emergent, ad-hoc

processes through web service-based activity

tracking. An important aspect is the provided

possibility for “seeding, evolutionary growth, and

reseeding (SER)” of weakly-structured process

models in shared enterprise repositories. This

enables refinement of generic processes towards

global best-practice definitions in organizations. The

presented architecture enables SER by distributing

and interconnecting data in various repositories –

tracking, user, artifact and TP repositories. This

enables different perspectives on processes: (i)

process perspective – describing the end-to-end

process flow where tasks contain all relevant artifact

and human actors’ information and additionally

allow tracing of evolutionary task reuse

(ancestor/descendant hierarchies); (ii) resource

ARCHITECTURE FOR END USER-DRIVEN COMPOSITION OF UNDERSPECIFIED, HUMAN-CENTRIC

BUSINESS PROCESSES

171

perspective - enabling detection of similar tasks

based on similar resources, i.e. exploration of EA

and EMA references in tasks; (iii) human actor

perspective – enabling tracing of user expertise and

contributions based on associated tasks and

resources, i.e. task owner/recipient, EMA author

relationships. These extensive data mining

capabilities and the enabling of end users to model

and enact end-to-end process execution examples by

combining existent and new TP, user and artifact

data go beyond known email-based and evolutionary

workflows.

A long term CTM evaluation is planned which

will allow scalability assessments for the entities,

managed through this architecture. This evaluation

should further reveal possibilities for automatic

detection of rigidly recurring process facets. We

further plan to investigate the mapping of user-

defined process descriptions to formal process

modeling notations towards automation of rigidly

recurring process fragments.

ACKNOWLEDGEMENTS

The work, this paper is based on, was supported

financially by the German Federal Ministry of

Education and Research (project EUDISMES,

number 01 IS E03 C).

REFERENCES

Aalst, W.M.P. v. d., Basten, T., Verbeek, H. M. W.,

Verkoulen, P. A. C., Verhoeve, M., 1999. Adaptive

Workflow: On the interplay between flexibility and

support. In ICEIS’99, Setubal, Portugal, pp. 353-360.

Agostini, A., De Michelis, G., 1997. Rethinking CSCW

systems: the architecture of Milano. In ECSCW’97,

Springer, pp. 33-48

Bellotti, V., Dalal, B., Good, N., Flynn, P., Bobrow, D. G.,

Ducheneaut, N., 2004. What a To-Do: Studies of Task

Management towards the Design of a Personal Task

List Manager. In CHI’04, ACM Press, pp. 735-742.

Bellotti, V., Ducheneaut, N., Howard, M., Smith, I.,

Grinter, R., 2005. Quality Versus Quantity: E-Mail-

Centric Task Management and Its Relation With

Overload. Human-Computer Interaction, Lawrence

Erlbaum Associates, Vol. 20 (2005), pp. 89-138.

Bernstein, A., 2000. How Can Cooperative Work Tools

Support Dynamic Group Processes? Bridging the

Specificity Frontier. In CSCW’00, ACM Press, pp.

279-288.

Fischer, G., Giaccardi, E., Ye, Y., Sutcliffe, A.,

Mehanjiev, N., 2004. Meta-Design: A Manifesto for

End-User Development. Communication of the ACM,

Vol. 47, No. 9 (Sep. 2004).

Gartner Research, 2006. Person-to-Process Interaction

Emerges as the 'Process of Me’, Gartner Inc.

Holz, H., Maus, H., Bernardi, A., Rostanin, O., 2005.

From Lightweight, Proactive Information Delivery to

Business Process-Oriented Knowledge Management.

Journal of Universal Knowledge Management, Vol. 0,

No. 2 (Nov. 2005), pp. 101-127.

Jorgensen, H. D., 2004. Interactive Process Models. Ph.D.

Thesis, Norwegian University of Science and

Technology, Trondheim, Norway.

Lieberman, H., 2001. Your Wish is My Command:

Programming by Example, Morgan Kaufmann.

Lieberman, H., Paterno, F., Wulf, V., 2006. End-User

Development, Springer.

MacLean, A., Carter, K., Lövstrand, L., Moran, T, 1990.

User-tailorable systems: pressing the issues with

buttons. In CHI’90, ACM Press, pp. 175-182.

Riss, U., Rickayzen, A., Maus, H., van der Aalst, W.M.P.,

2005. Challenges for Business Process and Task

Management. Journal of Universal Knowledge

Management, Vol. 0, No. 2 (Nov. 2005), pp. 77-100.

Schwarz, S., Abecker, A., Maus, H., Sintek, M., 2001.

Anforderungen an die Workflow-Unterstützung für

wissensintensive Geschäftsprozesse. In WM’01, 1st

Conference for Professional Knowledge Management,

Baden-Baden, Germany.

Stoitsev, T., Scheidl, S., Spahn, M, 2008. A Framework

for Light-Weight Composition and Management of

Ad-Hoc Business Processes, LNCS 4849, Springer, pp.

213–226.

Wiig, K. M., 2004. People-focused knowledge

management: how effective decision making leads to

corporate success, Elsevier Butterworth–Heinemann.

Wulf, V., Jarke, M, 2004. The Economics of End-User

Development. Communications of the ACM, Vol. 47,

N. 9 (Sep. 2004).

ICEIS 2008 - International Conference on Enterprise Information Systems

172
