SORCER: COMPUTING AND METACOMPUTING INTERGRID

Michael Soblewski

Texas Tech University, Lubbock, TX, U.S.A.

Keywords: Metacomputing, metaprogramming, grid computing, service-oriented architectures, service-oriented

programming.

Abstract: This paper investigates grid computing from the point of view three basic computing platforms. Each

platform considered consists of virtual compute resources, a programming environment allowing for the

development of grid applications, and a grid operating system to execute user programs and to make solving

complex user problems easier. Three platforms are discussed: compute grid, metacompute grid and

intergrid. Service protocol-oriented architectures are contrasted with service object-oriented architectures,

then the current SORCER metacompute grid based on a service object-oriented architecture and a new

metacomputing paradigm is described and analyzed. Finally, we explain how SORCER, with its core

services and federated file system, can also be used as a traditional compute grid and an intergrid—a hybrid

of compute and metacompute grids.

1 INTRODUCTION

The term “grid computing” originated in the early

1990s as a metaphor for accessing computer power

as easy as an electric power grid. Today there are

many definitions of grid computing with a varying

focus on architectures, resource management,

access, virtualization, provisioning, and sharing

between heterogeneous compute domains. Thus,

diverse compute resources across different

administrative domains form a grid for the shared

and coordinated use of resources in dynamic,

distributed, and virtual computing organizations

(Foster, 2002). Therefore, the grid requires a

platform that describes some sort of framework to

allow software to run utilizing virtual organizations.

These organizations are dynamic subsets of

departmental grids, enterprise grids, and global

grids, which allow programs to use shared

resources—collaborative federations.

Different platforms of grids can be distinguished

along with corresponding types of virtual

federations. However, in order to make any grid-

based computing possible, computational modules

have to be defined in terms of platform data,

operations, and relevant control strategies. For a grid

program, the control strategy is a plan for achieving

the desired results by applying the platform

operations to the data in the required sequence,

leveraging the dynamically federating resources.

We can distinguish three generic grid platforms,

which are described below.

Programmers use abstractions all the time. The

source code written in programming language is an

abstraction of the machine language. From machine

language to object-oriented programming, layers of

abstractions have accumulated like geological strata.

Every generation of programmers uses its era’s

programming languages and tools to build programs

of next generation. Each programming language

reflects a relevant abstraction, and usually the type

and quality of the abstraction implies the complexity

of problems we are able to solve. For example, a

procedural language provides an abstraction of an

underlying machine language. An executable file

represents a computing component whose content is

meant to be interpreted as a program by the

underlying native processor. A request can be

submitted to a grid resource broker to execute a

machine code in a particular way, e.g., parallelizing

it and collocating it dynamically to the right

processors in the grid. That can be done, for

example, with the Nimrod-G grid resource broker

scheduler (“Nimrod”, 2008) or the Condor-G high-

throughput scheduler (Thain, 2003). Both rely on

Globus/GRAM (Grid Resource Allocation and

Management) protocol (Foster, 2002). In this type of

grid, called a compute grid, executable files are

moved around the grid to form virtual federations of

Soblewski M. (2008).

SORCER: COMPUTING AND METACOMPUTING INTERGRID.

In Proceedings of the Tenth International Conference on Enterprise Information Systems - ISAS, pages 74-85

DOI: 10.5220/0001690700740085

 SciTePress

required processors. This approach is reminiscent of

batch processing in the era when operating systems

were not yet developed. A series of programs

("jobs") is executed on a computer without human

interaction or the possibility to view any results

before the execution is complete.

A grid programming language is the abstraction

of hierarchically organized networked processors

running a grid computing program—metaprogram—

that makes decisions about component programs

such as when and how to run them. Nowadays the

same computing abstraction is usually applied to the

program executing on a single computer as to the

metaprogram executing in the grid of computers,

even though the executing environments are

structurally completely different entities. Most grid

programs are still written using compiled languages

such as FORTRAN, C, C++, Java, and scripting

languages such as Perl and Python the way it usually

works on a single host. The current trend is to have

these programs and scripts define grid computational

modules. Thus, most grid computing modules are

developed using the same abstractions and, in

principle, run the same way on the grid as on a

single processor. There is presently no grid

programming methodologies to deploy a

metaprogram that will dynamically federate all

needed resources in the grid according to a control

strategy using a kind of grid algorithmic logic.

Applying the same programming abstractions to the

grid as to a single computer does not foster

transitioning from the current phase of early grid

adopters to public recognition and then to mass

adoption phases.

The reality at present is that grid resources are

still very difficult for most users to access, and that

detailed programming must be carried out by the

user through command line and script execution to

carefully tailor jobs on each end to the resources on

which they will run or for the data structure that they

will access. This produces frustration on the part of

the user, delays in adoption of grid techniques, and a

multiplicity of specialized “grid-aware” tools that

are not, in fact, aware of each other that defeat the

basic purpose of the grid.

Instead of moving executable files around the

grid, we can autonomically provision the

corresponding computational components as

uniform services on the grid. All grid services can be

interpreted as instructions (metainstructions) of the

metacompute grid. Now we can submit a

metaprogram in terms of metainstructions to the grid

platform that manages a dynamic federation of

service providers and related resources, and enables

the metaprogram to interact with the service

providers according to the metaprogram control

strategy.

We can distinguish three types of grids

depending on the nature of computational

components: compute grids (cGrids), metacompute

grids (mcGrids), and the hybrid of the previous

two—intergrids (iGrids). Note that a cGrid is a

virtual federation of processors (roughly CPUs) that

execute submitted executable files with the help of a

grid resource broker. However, an mcGrid is a

federation of service providers managed by the

mcGrid operating system. Thus, the latter approach

requires a metaprogramming methodology while in

the former case the conventional procedural

programming languages are used. The hybrid of

both cGrid and mcGrid abstractions allows for an

iGrid to execute both programs and metaprograms

(intergrid applications) as depicted in Figure 1,

where platform layers P1, P2, and P3 correspond to

resources, resource management, and programming

environment correspondingly.

One of the first mcGrids was developed under

the sponsorship of the National Institute for

Standards and Technology (NIST)—the Federated

Intelligent Product Environment (FIPER) (“FIPER”,

2008; Röhl, 2000; Sobolewski 2002). The goal of

FIPER is to form a federation of distributed services

that provide engineering data, applications and tools

on a network. A highly flexible software architecture

had been developed (1999-2003), in which

engineering tools like computer-aided design

(CAD), computer-aided engineering (CAE), product

data management (PDM) optimization, cost

modeling, etc., act as federating service providers

and service requestors.

Figure 1: Three types of grids: compute grid,

metacompute grid, and intergrid. A cybernode provides a

lightweight dynamic virtual processor, turning

heterogeneous compute resources into homogeneous

services available to the metacomputing OS (“Project

Rio”, n.d).

SORCER: COMPUTING AND METACOMPUTING INTERGRID

The Service-ORiented Computing EnviRonment

(SORCER) (Sobolewski, 2007; Sobolewski, 2008)

builds on the top of FIPER to introduce a

metacomputing operating system with all basic

services necessary, including a federated file system,

to support service-oriented metaprogramming. It

provides an integrated solution for complex

metacomputing applications. The SORCER

metacomputing environment adds an entirely new

layer of abstraction to the practice of grid

computing—exertion-oriented (EO) programming.

The EO programming makes a positive difference in

service-oriented programming primarily through a

new metaprogramming abstraction as experienced in

many grid-computing projects including systems

deployed at GE Global Research Center, GE

Aviation, Air Force Research Lab, and SORCER

Lab (Burton, 2002; Kolonay, 2002; Sampath, 2002;

Kao, 2003; Lapinski, 2003; Khurana, 2005;

Sobolewski, 2006; Berger, 2007; Turner, 2007;

Goel, 2005; Goel, 2007; Kolonay, 2007; “SORCER

Research”, 2008).

The paper is organized as follows. Section 2

provides a brief description of two service-oriented

architectures used in grid computing with a related

discussion of distribution transparency; Section 3

describes the SORCER metacomputing philosophy

and mcGrid; Section 4 describes the SORCER

cGrid, Section 5 the metacomputing file system, and

Section 6 the SORCER iGrid; Section 7 provides

concluding remarks.

2 SOA = SPOA+SOOA

Various definitions of a Service-Oriented

Architecture (SOA) leave a lot of room for

interpretation. Nowadays SOA becomes the leading

architectural approach to most grid developments. In

general terms, SOA is a software architecture using

loosely coupled software services that integrates

them into a distributed computing system by means

of service-oriented programming. Service providers

in the SOA environment are made available as

independent service components that can be

accessed without a priori knowledge of their

underlying platform or implementation. While the

client-server architecture separates a client from a

server, SOA introduces a third component, a service

registry. In SOA, the client is referred to as a service

requestor and the server as a service provider. The

provider is responsible for deploying a service on

the network, publishing its service to one or more

registries, and allowing requestors to bind and

execute the service. Providers advertise their

availability on the network; registries intercept these

announcements and add published services. The

requestor looks up a service by sending queries to

registries and making selections from the available

services. Queries generally contain search criteria

related to the service name/type and quality of

service. Registries facilitate searching by storing the

service representation and making it available to

requestors. Requestors and providers can use

discovery and join protocols to locate registries and

then publish or acquire services on the network.

We can distinguish the service object-oriented

architecture (SOOA), where providers, requestors,

and proxies are network objects, from the service

protocol oriented architecture (SPOA), where a

communication protocol is fixed and known

beforehand by the both provider and requestor.

Using SPOA, a requestor can use this fixed protocol

and a service description obtained from a service

registry to create a proxy for binding to the service

provider and for remote communication over the

fixed protocol. In SPOA a service is usually

identified by a name. If a service provider registers

its service description by name, the requestors have

to know the name of the service beforehand.

Figure 2: Service object-oriented architecture.

In SOOA (see Figure 2), a proxy—an object

implementing the same service interfaces as its

service provider—is registered with the registries

and it is always ready for use by requestors. Thus,

the service provider publishes the proxy as the active

surrogate object with a codebase annotation, e.g.,

URLs to the code defining proxy behavior in Jini

ERI (“Package net.jini.jeri”, n.d.). In SPOA, by

contrast, a passive service description is registered

(e.g., an XML document in WSDL for Web/OGSA

services (McGovern, 2003; Sotomayor, 2005) or an

interface description in IDL for CORBA (Ruth,

1999)); the requestor then has to generate the proxy

ICEIS 2008 - International Conference on Enterprise Information Systems

(a stub forwarding calls to a provider) based on the

service description and the fixed communication

protocol (e.g., SOAP in Web/OGSA services, IIOP

in CORBA). This is referred to as a bind operation.

The binding operation is not needed in SOOA since

the requestor holds the active surrogate object

obtained from the registry.

Web services and OGSA services cannot change

the communication protocol between requestors and

providers while the SOOA approach is protocol

neutral (Waldo, n.d.). In SOOA, the way an object

proxy communicates with a provider is established

by the contract between the provider and its

published proxy and defined by the provider

implementation. The proxy’s requestor does not

need to know who implements the interface, how it

is implemented, or where the provider is located—

three neutralities of SOOA. So-called smart proxies

(e.g., provided by Jini ERI) grant access to local and

remote resources. They can also communicate with

multiple providers on the network regardless of who

originally registered the proxy, thus separate

providers on the network can implement different

parts of the smart proxy interface(s).

Communication protocols may also vary, and a

single smart proxy can also talk over multiple

protocols including application specific protocols.

SPOA and SOOA differ in their method of

discovering the service registry. SORCER uses

dynamic discovery protocols to locate available

registries (lookup services) as defined in the Jini

architecture (“Jini Architecture”, 2001). Neither the

requestor who is looking up a proxy by its interfaces

nor the provider registering a proxy needs to know

specific registry locations. In SPOA, however, the

requestor and provider usually do need to know the

explicit location of the service registry—e.g., a URL

for RMI registry (Pitt, 2001), a URL for UDDI

registry (McGovern, 2003), an IP address and port

of a COS Name Server (Ruh, 1999)—to open a

static connection and find or register a service. In

deployment of Web and OGSA services, a UDDI

registry is sometimes even omitted; in SOOA,

lookup services are mandatory due to the dynamic

nature of objects identified by service types.

Interactions in SPOA are more like static client-

server connections (e.g., HTTP, SOAP, IIOP) in

many cases with no need to use service registries at

all.

Crucial to the success of SOOA is interface

standardization. Services are identified by interfaces

(service types, e.g., Java interfaces) and additional

provider’s specific properties if needed; the exact

identity of the service provider is not crucial to the

architecture. As long as services adhere to a given

set of rules (common interfaces), they can

collaborate to execute published operations,

provided the requestor is authorized to do so.

Let us emphasize the major distinction between

SOOA and SPOA: in SOOA, a proxy is created and

always owned by the service provider, but in SPOA,

the requestor creates and owns a proxy which has to

meet the requirements of the protocol that the

provider and requestor agreed upon a priori. Thus, in

SPOA the protocol is always a generic one, reduced

to a common denominator—one size fits all—that

leads to inefficient network communication in many

cases. In SOOA, each provider can decide on the

most efficient protocol(s) needed for a particular

distributed application.

Service providers in SOOA can be considered as

independent network objects finding each other via a

service registry using object types and

communicating through message passing. A

collection of these object sending and receiving

messages—the only way these objects communicate

with one another—looks very much like a service

object-oriented distributed system.

Do you remember the eight fallacies (“Fallacies”,

n.d.) of network computing? We cannot just take an

object-oriented program developed without

distribution in mind and make it a distributed

system, ignoring the unpredictable network

behavior. Most RPC systems, with notable exception

of Jini (Edwards, 2000) and SORCER, hide the

network behavior and try to transform local

communication into remote communication by

creating distribution transparency based on a local

assumption of what the network might be. However,

every single distributed object cannot do that in a

uniform way as the network is a dynamic distributed

system and cannot be represented completely within

a single entity.

The network is dynamic, cannot be constant, and

introduces latency for remote invocations. Network

latency also depends on potential failure handling

and recovery mechanisms, so we cannot assume that

a local invocation is similar to remote invocation.

Thus, complete distribution transparency—by

making calls on distributed objects as though they

were local—is impossible to achieve in practice. The

distribution is simply not just an object-oriented

implementation of a single distributed object; it is a

metasystemic issue in object-oriented distributed

SORCER: COMPUTING AND METACOMPUTING INTERGRID

programming. In that context, Web/OGSA services

define distributed objects, but do not have anything

common with object-oriented distributed systems

that for example the Jini architecture emphasizes.

Object-oriented programming can be seen as an

attempt to abstract both data and related operations

in an entity called object. Thus, object-oriented

program may be seen as a collection of cooperating

objects communicating via message passing, as

opposed to a traditional view in which a program

may be seen as a list of instructions to the computer.

Instead of objects and messages, in EO

programming service providers and exertions

constitute a program. An exertion is a kind of meta-

request sent onto the network. The exertion can be

considered as the specification of collaboration that

encapsulates data, related operations, and control

strategy. The operations specify implicitly the

required service providers on the network. The

activated exertion creates at runtime a federation of

providers to execute a service collaboration

according to the exertion’s control strategy. Thus,

the exertion is the metaprogram and its metashell

that submits the request onto the network to run the

collaboration in which all providers pass to one

other the component exertions only. This type of

metashell was created for the SORCER

metacompute operating system (see Figure 3)—the

exemplification of SOOA with autonomic

management of system and domain-specific service

providers to run EO programs.

SORCER defines the object-oriented distribution

for EO programming (Sobolewski, 2008). It uses

indirect federated remote method invocation

(Sobolewski, 2007) with no location of service

provider explicitly specified in exertions. A

specialized infrastructure of distributed services

supports discovery/join protocols for providers and

the exertion shell, federated file system, and the

system brokers responsible for coordination of

executing federations. That infrastructure defines

SORCER’s object-oriented distributed modularity,

extensibility, and reuse of providers and exertions—

key features of object-oriented distributed

programming that are usually missing in SPOA

programming environments.

Figure 3: SORCER layered platform, where P1 resources,

P2 resource management, P3 programming environment.

3 METACOMPUTE GRID

SORCER is a federated service-to-service (S2S)

metacomputing environment that treats service

providers as network peers with well-defined

semantics of a federated service object-oriented

architecture (FSOOA). It is based on Jini semantics

of services (“Jini Architecture”, n.d.) in the network

and the Jini programming model (Edwards, 2000)

with explicit leases, distributed events, transactions,

and discovery/join protocols. While Jini focuses on

service management in a networked environment,

SORCER is focused on EO programming and the

execution environment for exertions.

As described in Section 2, SOOA consists of four

major types of network objects: providers,

requestors, registries, and proxies. The provider is

responsible for deploying the service on the

network, publishing its proxy to one or more

registries, and allowing requestors to access its

proxy. Providers advertise their availability on the

network; registries intercept these announcements

and cache proxy objects to the provider services.

The requestor looks up proxies by sending queries to

registries and making selections from the available

service types. Queries generally contain search

criteria related to the type and quality of service.

Registries facilitate searching by storing proxy

objects of services and making them available to

requestors. Providers use discovery/join protocols to

publish services on the network; requestors use

discovery/join protocols to obtain service proxies on

the network. The SORCER metacompute OS uses

Jini discovery/join protocols to implement its

FSOOA.

ICEIS 2008 - International Conference on Enterprise Information Systems

In FSOOA, a service provider is an object that

accepts exertions from service requestors to execute

a collaboration. An exertion encapsulates service

data, operations, and control strategy. A task

exertion is an elementary service request, a kind of

elementary remote instruction (elementary

statement) executed by a single service provider or a

small-scale federation. A composite exertion called a

job exertion is defined hierarchically in terms of

tasks and other jobs, including control flow

exertions. A job exertion is a kind of network

procedure executed by a large-scale federation.

Thus, the executing exertion is a service-oriented

program that is dynamically bound to all required

and currently available service providers on the

network. This collection of providers identified at

runtime is called an exertion federation. While this

sounds similar to the object-oriented paradigm, it

really is not. In the object-oriented paradigm, the

object space is a program itself; here the exertion

federation is the execution environment for the

exertion, and the exertion is the object-oriented

program—specification of service collaboration.

This changes the programming paradigm

completely. In the former case the object space is

hosted by a single computer, but in the latter case the

parent and its component exertions along with

related service providers are hosted by the network

of computers.

The overlay network of all service providers is

called the service grid and an exertion federation is

called a virtual metacomputer. The metainstruction

set of the metacomputer consists of all operations

offered by all providers in the grid. Thus, a service-

oriented program is composed of metainstructions

with its own service-oriented control strategy and

service context representing the metaprogram data.

Service signatures specify metainstructions in

SORCER. Each signature primarily is defined by a

service type (interface name), operation in that

interface, and a set of optional attributes. Four types

of signatures are distinguished:

PROCESS,

PREPROCESS, POSTPROCESS, and APPEND. A

PROCESS signature—of which there is only one

allowed per exertion—defines the dynamic late

binding to a provider that implements the signature’s

interface. The service context (Zhao, 2001;

Sobolewski, 2008) describes the data that tasks and

jobs work on. An

APPEND signature defines the

context received from the provider specified by this

signature. The received context is then appended in

runtime to the service context later processed by

PREPROCESS, PROCESS, and POSTPROCESS

operations of the exertion. Appending a service

context allows a requestor to use actual network data

in runtime not available to the requestor when the

exertion is submitted. An EO program allows for a

dynamic federation to transparently coordinate the

execution of all component exertions within the grid.

Please note that these metacomputing concepts are

defined differently in traditional grid computing

where a job is just an executing process for a

submitted executable code with no federation being

formed for the executable.

An exertion can be activated by calling exertion’s

exert operation:

Exertion.exert(Transaction):Exertion,

where a parameter of the

Transaction type is

required when a transactional semantics is needed

for all participating nested exertions within the

parent one. Thus, EO programming allows us to

submit an exertion onto the network and to perform

executions of exertion’s signatures on various

service providers indirectly, but where does the

service-to-service communication come into play?

How do these services communicate with one

another if they are all different? Top-level

communication between services, or the sending of

service requests, is done through the use of the

generic

Servicer interface and the operation

service that all SORCER services are required to

provide:

Servicer.service(Exertion,

Transaction):Exertion

. This top-level service

operation takes an exertion as an argument and gives

back an exertion as the return value.

So why are exertions used rather than directly

calling on a provider's method and passing service

contexts? There are two basic answers to this. First,

passing exertions helps to aid with the network-

centric messaging. A service requestor can send an

exertion implicitly out onto the network—

Exertion.exert()—and any service provider can

pick it up. The provider can then look at the

interface and operation requested within the

exertion, and if it doesn't implement the desired

interface or provide the desired method, it can

continue forwarding it to another service provider

who can service it. Second, passing exertions helps

with fault detection and recovery. Each exertion has

its own completion state associated with it to specify

if it has yet to run, has already completed, or has

failed. Since full exertions are both passed and

returned, the user can view the failed exertion to see

what method was being called as well as what was

SORCER: COMPUTING AND METACOMPUTING INTERGRID

used in the service context input nodes that may

have caused the problem. Since exertions provide all

the information needed to execute a task including

its control strategy, a user would be able to pause a

job between tasks, analyze it and make needed

updates. To figure out where to resume an exertion,

the executing provider would simply have to look at

the exertion’s completion states and resume the first

one that wasn't completed yet. In other words, EO

programming allows the user, not programmer to

update the metaprogram on-the-fly, what practically

translates into creation new collaborative

applications during the exertion runtime.

Despite the fact that every

Servicer can accept

any exertion,

Servicers have well defined roles in

the S2S platform (see Figure 3):

Taskers – process service tasks

Jobbers – process service jobs

Spacers – process tasks and jobs via exertion

space for space-based computing (Freeman,

1999)

Contexters – provide service contexts for

APPEND Signatures

FileStorers – provide access to federated file

system providers (Sobolewski, 2003, Berger,

2005, Berger 2007)

Catalogers – Servicer registries

Persisters – persist service contexts, tasks,

and jobs to be reused for interactive EO

programming

Relayers – gateway providers; transform

exertions to native representation, for example

integration with Web services and JXTA

(“JXTA”, n.d.)

Autenticators, Authorizers, Policers,

KeyStorers – provide support for service

security

Auditors, Reporters, Loggers – support for

accountability, reporting, and logging

Griders, Callers, Methoders – support

compute grid (see Section 4)

l) Generic

ServiceTasker, ServiceJobber, and

ServiceSpacer

implementations are used to

configure domain-specific providers via

dependency injection—configuration files for

smart proxying and embedding business objects,

called service beans, into service providers.

An exertion can be created interactively

(Sobolewski, 2006) or programmatically (using

SORCER APIs), and its execution can be monitored

and debugged (Soorianarayanan, 2006) in the

overlay service network via service user interfaces

(“The Service UI Project”, n.d.) attached to

providers and installed on-the-fly by generic service

browsers (“Inca X”, n.d). Service providers do not

have mutual associations prior to the execution of an

exertion; they come together dynamically (federate)

for all nested tasks and jobs in the exertion. Domain

specific providers within the federation, or task

peers, execute service tasks. Jobs are coordinated by

rendezvous peers: a Jobber or Spacer, two of the

SORCER platform core services. However, a job

can be sent to any peer. A peer that is not a

rendezvous peer is responsible for forwarding the

job to an available rendezvous peer and returning

results to the requestor. Thus implicitly, any peer

can handle any exertion type. Once the exertion

execution is complete, the federation dissolves and

the providers disperse to seek other exertions to join.

Exertion is activated by calling its exert

method. The SORCER API defines the following

three related operations:

Exertion.exert(Transaction):Exertion

– join the federation; the activated exertion binds

to an available provider specified by the

exertion’s

PROCESS signature;

Servicer.service(Exertion,

Transaction):Exertion

– request a service

in the federation initiated by any bounding

provider; and

Exerter.exert(Exertion,

Transaction):Exertion – execute the

argument exertion by the provider accepting the

service request in 2) above.

This above Triple Command pattern (Sobolewski,

2007) defines various implementations of these

interfaces:

Exertion (metaprogram), Servicer

(generic peer provider), and Exerter (service

provider exerting a particular type of

Exertion).

This approach allows for the P2P environment

(Oram, 2001) via the

Servicer interface, extensive

modularization of

Exertions and Exerters, and

extensibility from the triple design pattern so

requestors can submit onto the network any EO

programs they want with or without transactional

semantics. The Triple Command pattern is used as

follows:

1. An exertion can be activated by calling

Exertion.exert(). The exert operation

implemented in

ServiceExertion uses

ServiceAccessor to locate in runtime the

ICEIS 2008 - International Conference on Enterprise Information Systems

provider matching the exertion’s

PROCESS

signature.

2. If the matching provider is found, then on its

access proxy the

Servicer.service() method

is invoked.

3. When the requestor is authenticated and

authorized by the provider to invoke the method

defined by the exertion’s PROCESS signature,

then the provider calls its own

exert operation:

Exerter.exert().

Exerter.exert() operation is implemented

ServiceTasker, ServiceJobber, or

ServiceSpacer

. The ServiceTasker peer

calls by reflection the application method

specified in the

PROCESS signature of the task

exertion. All application domain methods of any

interface have the same signature: a single

Context type parameter and a Context type

return vale. Thus an application interface looks

like an RMI (Pitt, 2001) interface with the above

simplification on the common signature for all

interface methods.

The exertion activated by a service requestor can be

submitted directly or indirectly to the matching

service provider. In the direct approach, when

signature’s access type is

PUSH, the exertion’s

ServicerAccessor finds the matching service

provider against the service type and attributes of the

PROCESS signature and submits the exertion to the

matching provider. Alternatively, when signature’s

access type is

PULL, a ServiceAccessor can use a

Spacer provider and simply drops the exertion into

the shared exertion space to be pulled by a matching

provider. The execution order of signatures is

defined by signature priorities, if the exertion’s flow

type is

SEQUENTIAL, otherwise they are dispatch in

parallel. In Figure 4 four use cases are presented to

illustrate push vs. pull exertion processing with

either

PUSH or PULL access types. We assume here

that an exertion is a job with two component

exertions executed in parallel (sequence numbers

with a and b), i.e., the job’s signature flow type is

PARALLEL. The job can be submitted directly to

either

Jobber (use cases: 1—access is PUSH, and

2—access is

PULL) or Spacer (use cases: 3 —

access is

PUSH, and 4—access is PULL) depending

on the interface defined in its

PROCES signature.

Figure 4: Push vs. pull exertion processing.

Thus, in cases 1 and 2 the signature’s interface is

Jobber and in cases 3 and 4 the signature’s

interface is

Spacer as shown in Figure 2.

The exertion’s

ServicerAccessor delivers the

right service proxy dynamically, either for a

Jobber

Spacer. If the access type of the parent exertion

PUSH, then all the component exertions are

directly passed to servicers matching their

PROCESS

signatures (case 1 and 3), otherwise they are written

into the exertion space by a

Spacer (case 2 and 4).

In the both cases 2 and 4, the component exertions

are pulled from the exertion space by servicers

matching their signatures as soon as they are

available. Thus,

Spacers provide efficient load

balancing for processing the exertion space. The

fastest available sevicer gets an exertion from the

space before other overloaded or slower servicers

can do so. When an exertion consists of component

jobs with different access and flow types, then we

have a hybrid case when the collaboration

potentially executes concurrently with multiple pull

and push subcollaborations at the same time.

4 COMPUTE GRID

Also, to use legacy applications, SORCER supports

a traditional approach to grid computing similar to

those found in Condor (Thain, 2003) and Globus

(Sotomayor, 2005). Here, instead of exertions being

executed by services providing business logic for

collaborating exertions, the business logic comes

from the service requestor's executable codes that

seek compute resources on the network.

The cGrid services in the SORCER environment

include

Griders accepting exertions and

collaborating with

Jobbers and Spacers in the role

of grid scheduler.

Caller and Methoder services

are used for task execution received from

Jobbers

or picked up from exertion space via

Spacers.

Callers execute provided codes via a system call as

SORCER: COMPUTING AND METACOMPUTING INTERGRID

described by the standardized

Caller’s service

context of the submitted task.

Methoders download

required Java code (task method) from requestors to

process any submitted service context with the

downloaded code accordingly. In either case, the

business logic comes from requestors; it is

executable code specified in the service context

invoked by

Callers, or mobile Java code executed

Methoders that is annotated by the exertion

signature.

The SORCER cGrid with

Methoders was used

to deploy an algorithm called Basic Local Alignment

Search Tool (BLAST) (Alschul, 1990) to compare

newly discovered, unknown DNA and protein

sequences against a large database with more than

three gigabytes of known sequences. BLAST (C++

code) searches the database for sequences that are

identical or similar to the unknown sequence. This

process enables scientists to make inferences about

the function of the unknown sequence based on what

is understood about the similar sequences found in

the database. Many projects at the USDA–ARS

Research Unit, for example, involve as many as

10,000 unknown sequences, each of which must be

analyzed via the BLAST algorithm. A project

involving 10,000 unknown sequences requires about

three weeks to complete on a single desktop

computer. The S-BLAST implemented in SORCER

(Khurana, 2005), a federated form of the BLAST

algorithm, reduces the amount of time required to

perform searches for large sets of unknown

sequences. S-BLAST is comprised of

BlastProvider (with the attached BLAST Service

UI),

Jobbers, Spacers, and Methoders.

Methoders in S-BLAST download Java code (a

service task method) that initializes a required

database before making system call for the BLAST

code. Armed with the S-BLAST’s cGrid and

seventeen commodity computers, projects that

previously took three weeks to complete can now be

finished in less than one day.

The SORCER cGrid with

Griders, Jobbers,

Spacers, and Callers has been successfully

deployed with the Proth program (C code) and easy-

to-use zero-install service UI attached to a

Grider

and the federated file system.

5 FEDERATED FILE SYSTEM

The SILENUS federated file system (Berger, 2005;

Berger, 2007) was designed and developed to

provide data access for metaprograms. It

complements the file store developed for FIPER

(Sobolewski, 2003) with the true P2P services. The

SILENUS system itself is a collection of service

providers that use the SORCER framework for

communication.

In classical client-server file systems, a heavy

load may occur on a single file server. If multiple

service requestors try to access large files at the

same time, the server will be overloaded. In a P2P

architecture, every provider is a client and a server at

the same time. The load can be balanced between all

peers if files are spread across all of them. The

SORCER architecture splits up the functionality of

the metacomputer into smaller service peers

(

Servicers), and this approach was applied to the

distributed file system as well.

The SILENUS federated file system is comprised

of several network services that run within the

SORCER environment. These services include a

byte store service for holding file data, a metadata

service for holding metadata information about the

files, several optional optimizer services, and façade

(Grand, 1999) services to assist in accessing

federating services. SILENUS is designed so that

many instances of these services can run on a

network, and the required services will federate

together to perform the necessary functions of a file

system. In fact the SILENUS system is completely

decentralized, eliminating all potential single point

failures. SILENUS services can be broadly

categorized into gateway components, data services,

and management services.

The SILENUS façade service provides a gateway

service to the SILENUS grid for requestors that

want to use the file system. Since the metadata and

actual file contents are stored by different services,

there is a need to coordinate communication

between these two services. The façade service itself

is a combination of a control component, called the

coordinator, and a smart proxy component that

contains needed inner proxies provided dynamically

by the coordinator. These inner proxies facilitate

direct P2P communications for file upload and

download between the requestor and SILENUS

federating services like metadata and byte stores.

Core SILENUS services have been successfully

deployed as SORCER services along with WebDAV

and NFS adapters. The SILENUS file system scales

well with a virtual disk space adjusted as needed by

the corresponding number of required byte store

providers and the appropriate number of metadata

stores required to satisfy the needs of current users

and service requestors. The system handles several

types of network and computer outages by utilizing

disconnected operation and data synchronization

mechanisms. It provides a number of user agents

ICEIS 2008 - International Conference on Enterprise Information Systems

Figure 5: Integrating and wrapping cGrids with SORCER mcGrids. Two requestors, one in JXTA iGrid, one in

OGSA iGrid submits exertion to a corresponding relayer. Two federations are formed that include providers from

all the two horizontal layers below the iGrid layer (as indicated by continues and dashed links).

including a zero-install file browser attached to the

SILENUS façade. Also a simpler version of

SILENUS file browser is available for smart MIDP

phones.

SILENUS supports storing very large files

(Turner, 2007) by providing two services: a splitter

service and a tracker service. When a file is

uploaded to the file system, the splitter service

determines how that file should be stored. If a file is

sufficiently large enough, the file will be split into

multiple parts, or chunks, and stored across many

byte store services. Once the upload is complete, a

tracker service keeps a record of where each chunk

was stored. When a user requests to download the

full file later on, the tracker service can be queried to

determine the location of each chunk and the file can

be reassembled to the original form.

6 SORCER IGRID

Relayers are SORCER gateway providers that

transform exertions to native representations and

vice versa. The following

Exertion gateways have

been developed:

JxtaRelayer for JXTA (“JXTA”,

n.d.), and

WsRpcRelayer and WsDocRelayer for

for RPC and document style Web services,

respectively. Relayers exhibit native and mcGrid

behavior. Some native cGrid providers play

SORCER role (SORCER wrappers), thus are

available in the iGrid along with mcGrid providers.

Also, native cGrid providers via corresponding

relayers can access iGrid services (bottom-up in

Figure 5).

The iGrid-integrating model is depicted in Fig 5,

where horizontal native technology grids (bottom)

are seamlessly integrated with horizontal SORCER

mcGrids via the SORCER operating system

services. Through the use of open standards-based

communication—Jini, Web Services,

Globus/OGSA, and Java interoperability—iGrid

leverages mcGrid’s FSOOA with its inherent

provider protocol, location, and implementation

neutrality along with the flexibility of EO

programming for iGrid computing.

7 CONCLUSIONS

An object-oriented grid is not just a collection of

distributed objects; it is the network of unreliable

objects that come and go. From an object-oriented

point of view, the network of objects is the problem

domain of object-oriented distributed programming

that requires relevant abstractions in the solution

space—a metacompute OS. The SORCER

architecture shares the features of grid systems, P2P

systems, and provides a platform for procedural

programming and service-oriented meta-

programming as well. EO programming introduces

new network abstractions with federated method

invocation in FSOOA. It allows for creation

adaptive collaborative applications at the exertion

runtime.

SORCER: COMPUTING AND METACOMPUTING INTERGRID

Executing a top-level exertion means federating

currently available providers in the network that

collaboratively process service contexts of all nested

exertions. Services are invoked by passing exertions

on to one another indirectly via object proxies that

act as access proxies allowing for service providers

to enforce security policies on access to services.

When permission is granted, then the operation

defined by a signature is invoked by reflection.

SORCER allows for P2P computing via the common

Servicer interface, extensive modularization of

Exertions and Exerters, and extensibility from

the Triple Command design pattern. The SORCER

federated file system is modularized into a collection

of distributed providers with multiple remote

façades. Façades supply uniform access points via

their smart proxies available dynamically to file

requestors. A façade’s smart proxy encapsulates

inner proxies to federating file system providers that

are accessed directly (P2P) by file requestors.

The SORCER iGrid has been successfully tested

in multiple concurrent engineering and large-scale

distributed applications (Burton, 2002; Kolonay,

2002; Sampath, 2002; Kao, 2003; Lapinski, 2003;

Khurana, 2005; Sobolewski, 2006; Berger, 2007;

Turner, 2007; Goel, 2005; Goel, 2007; Kolonay,

2007; “SORCER Research”, 2008). Due to the

large-scale complexity of the evolving iGrid

environment, it is still a work in progress and

continues to be refined and extended by the

SORCER Research Group at Texas Tech University

(“SORCER Lab”, n.d.) in collaboration with Air

Force Research Lab, WPAFB. The SORCER

approach is consistent with the object-oriented

distributed granularity of many service provider and

exertion types, and provider configuration-based

dependency injection.

REFERENCES

Altschul, S.F., Gish, W., Miller, W., Myers, E. W. &

Lipman, D. J. (1990). Basic Local Alignment Search

Tool. J. Mol. Biol. 215:403-410.

Berger, M., Sobolewski, M. (2005). SILENUS—A Federated

Service-oriented Approach to Distributed File

Systems, Next Generation Concurrent Engineering.

ISPE/Omnipress, ISBN 0-9768246-0-4, pp. 89-96.

Berger, M., Sobolewski, M. (2007) Lessons Learned from

the SILENUS Federated File System, Complex

Systems Concurrent Engineering, Loureiro, G. and

L.Curran, R. (Eds.). Springer Verlag, ISBN: 978-1-

84628-975-0, pp. 431-440.

Burton, S. A., Tappeta, R., Kolonay, R. M., Padmanabhan, D.

(2002). Turbine Blade Reliability-based Optimization

Using Variable-Complexity Method, 43

AIAA/ASME/ASCE/AHS/ASC Structures, Structural

Dynamics, and Materials Conference, Denver, Colorado.

AIAA 2002-1710.

Edwards, W. K. (2000). Core Jini, 2nd ed., Prentice Hall,

ISBN: 0-13-089408.

Fallacies of Distributed Computing. Retrieved March 5,

2008, from:http://en.wikipedia.org/wiki/Fallacies_of

_Distributed_Computing.

FIPER: Federated Intelligent Product EnviRonmet.

Retrieved March 5, 2008, from: http://sorcer.cs.ttu.

edu/fiper/fiper.html.

Foster, I., Kesselman, C., Nick, J., S. Tuecke, S. (2002).

The Physiology of the Grid: An Open Grid Services

Architecture for Distributed Systems Integration.,

Open Grid Service Infrastructure WG, Global Grid

Forum, June 22, 2002. Retrieved March 5, 2008, from:

http://www.globus.org/alliance/publications/papers/og

sa.pdf.

Freeman, E., Hupfer, S., & Arnold, K. (1999).

JavaSpaces™ Principles, Patterns, and Practice.

Addison-Wesley, ISBN: 0-201-30955-6.

Goel, S, Talya, S., and Sobolewski, M. (2005).

Preliminary Design Using Distributed Service-based

Computing, Next Generation Concurrent Engineering.

ISPE/Omnipress, ISBN 0-9768246-0-4, pp. 113-120.

Goel, S., Talya, S., Sobolewski, M. (2007). Service-based

P2P overlay network for collaborative problem

solving, Decision Support Systems, Volume 43, Issue

2: pp. 547-568, 2007.

Grand, M. (1999). Patterns in Java. Volume 1, Wiley,

ISBN: 0-471-25841-5.

Inca X™ Service Browser for Jini Technology. Retrieved

March 5, 2008, from: http://www.incax.com/

index.htm?http://www.incax.com/service-

browser.htm.

JXTA (n.d). Retrieved March 5, 2008, from:

https://jxta.dev.java.net/

Jini architecture specification, Version 1.2., 2001.

Retrieved March 5, 2008, from: http://www.sun.com/

software/jini/specs/jini1.2html/jini-title.html.

Jini.org. Retrieved March 5, 2008, from:

http://www.jini.org/.

Kao, K. J., Seeley, C.E., Yin, S., Kolonay, R.M., Rus, T.,

Paradis, M.J. (2003). Business-to-Business Virtual

Collaboartion of Aircraft Engine Combustor Design,

Proceedings of DETC’03 ASME 2003 Design

Engineering Technical Conferences and Computers

and Information in Engineering Conference, Chicago,

Illinois.

Khurana, V., Berger, M., Sobolewski, M. (2005). A

Federated Grid Environment with Replication

Services. Next Generation Concurrent Engineering.

ISPE/Omnipress, ISBN 0-9768246-0-4, pp. 97-103.

Kolonay, R. M., Sobolewski, M., Tappeta, R., Paradis, M.,

Burton, S. (2002). Network-Centric MAO Environment.

The Society for Modeling and Simulation

International, Westrn Multiconference, San Antonio,

TX.

ICEIS 2008 - International Conference on Enterprise Information Systems

Kolonay, R. M., Thompson, E.D., Camberos, J.A.,

Franklin Eastep, F. (2007). Active Control of

Transpiration Boundary Conditions for Drag

Minimization with an Euler CFD Solver, AIAA-2007-

1891, 48th AIAA/ASME/ASCE/AHS/ASC Structures,

Structural Dynamics, and Materials Conference,

Honolulu, Hawaii.

Lapinski, M., Sobolewski, M. (2003). Managing

Notifications in a Federated S2S Environment,

International Journal of Concurrent Engineering:

Research & Applications, Vol. 11: pp. 17-25.

McGovern, J., Tyagi, S., Stevens, M. E., Mathew, S.

(2003). Java Web Services Architecture, Morgan

Kaufmann.

Nimrod: Tools for Distributed Parametric Modelling. Retrieved

March5,2008,from:http://www.csse.monash.edu.au/

~davida/nimrod/nimrodg.htm.

Oram, A. (Editor) (2001). Peer-to-Peer: Harnessing the

Benefits of Disruptive Technology. O'Reilly.

Package net.jini.jeri. Retrieved March 5, 2008, from:

http://java.sun.com/products/jini/2.1/doc/api/net/jini/je

ri/package-summary.html

Pitt, E. (2001) java™.rmi: The Remote Method Invocation

Guide. Addison-Wesley

Project Rio. A Dynamic Service Architecture for

Distributed Applications. Retrieved March 5, 2008,

from: https://rio.dev.java.net/.

Röhl, P. J., Kolonay, R. M., Irani, R. K., Sobolewski, M., Kao, K.

(2000). A Federated Intelligent Product Environment.AIAA-

2000 - 4902, 8thAIAA/USAF/NASA/ISSMO Symposium on

Multidisciplinary Analysis and Optimization, Long Beach,

CA.

Ruh, W. A., Herron, T., Klinker, P. (1999). IIOP

Complete: Understanding CORBA and Middleware

Interoperability. Addison-Wesley.

Sampath, R., Kolonay, R. M, Kuhne, C. M. (2002). 2D/3D

CFD Design Optimization Using the Federated

Intelligent Product Environment (FIPER) Technology.

AIAA-2002-5479, 9th AIAA/ISSMO Symposium on

Multidisciplinary Analysis and Optimization, Atlanta,

GA.

Sobolewski, M. (2002a). Federated P2P services in CE

Environments. Advances in Concurrent Engineering.

A.A. Balkema Publishers, 2002, pp. 13-22, 2002.

Sobolewski, M. (2002b). FIPER: The Federated S2S

Environment. JavaOne, Sun's 2002 Worldwide Java

Developer Conference. Retrieved March 5, 2008, from:

http://sorcer.cs.ttu.edu/publications/papers/2420.pdf.

Sobolewski, M., Soorianarayanan, S., Malladi-Venkata, R-

K. (2003). Service-Oriented File Sharing, Proceedings

of the IASTED Intl., Conference on Communications,

Internet, and Information technology, pp. 633-639,

Scottsdale, AZ. ACTA Press.

Sobolewski, M., Kolonay R. (2006) Federated Grid Computing

with Interactive Service-oriented Programming,

International Journal of Concurrent Engineering:

Research & Applications. Vol. 14: pp. 55-66.

Sobolewski, M. (2007). Federated Method Invocation with

Exertions, Proceedings of the International

Multiconference on Computer Science and Information

Technology, Springer Verlag, ISSN 1896-7094, Vol. 2: pp.

765 – 778. Retrieved March 5, 2008, from:

http://www.proceedings2007.imcsit.org/pliks/96.pdf.

Sobolewski, M. (2008). Service-oriented Programming,

SORCER Technical Report SL-TR-13. Retrieved March 5,

2008,from:http://sorcer.cs.ttu.edu/publications/papers/2008/

SL-TR-13.pdf.

Soorianarayanan, S., Sobolewski, M. (2004). Monitoring

Federated Services in CE, Concurrent Engineering:

The Worldwide Engineering Grid, Tsinghua Press and

Springer Verlag, ISBN 7-302-08802-0, pp. 89-95.

SORCER Lab. RetrievedMarch5, 2008, from:

http://sorcer.cs.ttu.edu/.

SORCER Research Topics. Retrieved March 5, 2008,

from: http://sorcer.cs.ttu.edu/theses/.

Sotomayor, B., Childers, L. (2005). Globus® Toolkit 4:

Programming Java Services. Morgan Kaufmann.

Thain, D., Tannenbaum, T., Livny, M. (2003). Condor and

the Grid. In Fran Berman, Anthony J.G. Hey, and

Geoffrey Fox, editors, Grid Computing: Making The

Global Infrastructure a Reality. John Wiley.

Turner, A., Sobolewski, M. (2007). FICUS—A Federated

Service-Oriented File Transfer Framework, Complex

Systems Concurrent Engineering, Loureiro, G. and

L.Curran, R. (Eds.). Springer Verlag, ISBN: 978-1-

84628-975-0, pp. 421-430.

The Service UI Project. Retrieved March 5, 2008, from:

http://www.artima.com/jini/serviceui/index.html.

Waldo, J. (n.d.). The End of Protocols. Retrieved March 5,

2008,from: http://java.sun.com/developer/technicalArticles/

jini/protocols.html.

Zhao, S., and Sobolewski, M. (2001). Context Model

Sharing in the FIPER Environment, Proc. of the 8th

Int. Conference on Concurrent Engineering: Research

and Applications, Anaheim, CA.

SORCER: COMPUTING AND METACOMPUTING INTERGRID
