WEB 2.0 MASHUPS FOR CONTEXTUALIZATION, FLEXIBILITY,

PRAGMATISM AND ROBUSTNESS

Thorsten Hampel

Department of Knowledge and Business Engineering, University of Vienna, Rathausstr. 19/9, A-1010 Vienna, Austria

Tom

s Pitner

Masaryk University, Faculty of Informatics, Botanick

a 68a, 602 00 Brno, Czech Republic

Jonas Schulte

Heinz Nixdorf Institute, University of Paderborn, Fuerstenallee 11, 33102 Paderborn, Germany

Keywords:

Mashup, Mistel, Web 2.0, Web Service, Flexible Integration.

Abstract:

In current Web 2.0 developments the word “mashups” stands for a totally new way of ﬂexible application

bringing together several Web 2.0 services. Mashups form a serious new trend in web development by con-

textualizing existing services and bringing customizable applications to the user. Out of this, a new style

of web-based applications arises. To get a better understanding of the phenomena of mashups, this paper

observes and interprets the way the development of web based applications and appropriate background sys-

tems changed. It presents several state of the art Web 2.0 technologies and points out why the evaluation of

Web 2.0 applications currently moves from web-based APIs to web services. We will present a short taxon-

omy of mashups as ﬂexible, pragmatic, and robust web applications. Further, their new form of ﬂexibility and

customization will be illustrated with the help of our mistel Framework.

1 INTRODUCTION

A ﬁrst look at the so-called Web 2.0 movements un-

veils a large number of different understandings and

deﬁnitions. People often think of social software and

community developments such as “power to the peo-

ple”. Others mainly confer informal semantics such

as tags or folksonomies. An extensive overview of

folksonomies, their characteristics, and semantics in

communities is given in (Michlmayr, 2005).

“Mashups” a new buzzword within the Web 2.0

context originally is used in the scope of music and

means remix; in the context of Web 2.0 mashup

means reusing and conﬂating existing technologies

to develop a new style of applications. Anymore

mashup also stands for the requirement changes of

the Web 2.0, which needs faster reusability and in-

tegrability than ever before.

As far as a new understanding for the new web

and therefore for the next generation of the Internet

can be, so important (we think) it is to be aware of the

new web not to be a collection of single services, but

a network (mashup) of highly interoperable services.

No longer users are served only by a single service,

they can proﬁt from a network of services. Shaped

transparently for the user, the application consists of

different network services, which are contextualized

and integrated dynamically to the users needs.

Therefore our understanding for the next genera-

tion web (we still call that for a better understanding

Web 2.0) is about:

• contextualization of services along the users

needs,

• ﬂexible interoperability of services, and

• robust and secure service integration.

Most of the above-mentioned issues are attributed

to Service Oriented Architectures (SOA) (Bih, 2006).

There is a plethora of deﬁnitions of the service con-

cept in IT, ranging from very abstract ones, such

as “a functional unit” (IBM), to more concrete ones

“self-contained stateless business function that ac-

107

Hampel T., Pitner T. and Schulte J. (2008).

WEB 2.0 MASHUPS FOR CONTEXTUALIZATION, FLEXIBILITY, PRAGMATISM AND ROBUSTNESS.

In Proceedings of the Tenth International Conference on Enterprise Information Systems - SAIC, pages 107-112

DOI: 10.5220/0001693201070112

 SciTePress

cepts one or more requests and returns one or more

responses through a well deﬁned standard interface”

(Wikipedia).

The discussion of web services (Gurguis and Zeid,

2005; Schranz, 1998) stands now for more than ﬁve

years for the same idea: offering ﬂexible and self-

describable web based services. Since then is the con-

cept of services applied in many areas including ba-

sic system infrastructure, such as storage service, net-

work monitoring, user identity management and au-

thentication, and geoinformation services.

Popular Web 2.0 services grow very quickly,

therefore a robust, scalable architecture, and, at the

same time, a simple, easy-to-use user interface is

needed. Thus, architectural styles and patterns sup-

porting non-functional requirements, such as the Rep-

resentational State Transfer (REST) are highly wel-

come.

In this paper we explore the leading Web 2.0 tech-

nologies to point out why the evolution moves from

web-based APIs to web services and why mashups

offer a new technology for developing ﬂexible, prag-

matic, and robust web applications. We compare

different models of integration to emphasize func-

tionalities and technologies that reﬁne the concept of

mashups. We will concentrate primarily on the tech-

nological aspects while business and legal issues are

discussed in (Dr

sil et al., 2008).

The paper is structured as follows: Primarily, we

identify why are the Web 2.0 services different from

the traditional view of Web services in the Section 2.

The technological foundation of service and system

integration is outlined in the Section 3 providing a

comparison between static web-based APIs, SOAP-

and REST-based web services by in addition pointing

out the beneﬁts of using web services. The next Sec-

tion 4 focuses on development of services and inte-

grated systems including mashups. After presenting

the state-of-the-art in open system integration (4.1),

the shortcomings of current solutions and techniques

are highlighted in 4.2. Since Web 2.0 mashups are an

enhancement of traditional web services, 4.3 presents

the requirements and visions for creating mashups.

As the ultimate goal, self-descriptive services are de-

scribed and accompanied by a proposed implementa-

tion in 4.4. The paper is concluded in Section 5.

2 WHAT IS NEW TO WEB 2.0

SERVICES?

Once might ask what is really new to the Web 2.0

movements regarding the well-known web service

idea? New is not the basic idea nor the used tech-

nology (e.g. SOAP and XML); new are its attributes

of:

• a broad and successful usage of different web ser-

vices as part of any class of Web 2.0 applications

(e.g. Google maps is widely used and therefore

generates complete new classes of applications),

• a pragmatic integration of web services on differ-

ent levels of semantics and complexity (e.g. web

services can be on a high semantic level, such as

semantic web services (Narayanan and Mcilraith,

2002; Patil et al., 2004) or on a very low semantic

level, such as screen scraping), and

• a new quality in the integration of web services.

Services are integrated in a way that they offer a

new quality of interoperability and interactivity to

the users.

Results of these new attributes is real system conver-

gence. Different parts of applications serve as a ﬂex-

ible, highly customizable, and contextualizable appli-

cations to the users. As a result the Web 2.0 move-

ments signiﬁcantly increase the stability and usabil-

ity for many well-known technologies. This leads to

a larger number of successful new applications and

robust technologies. The following contribution will

discuss the above-mentioned criteria for web services

in the focus of contextualization and system conver-

gence. Different stages of service integration will be

presented and analyzed, from the high-level web ser-

vice integration up to simple forms of application in-

tegration. As part of different levels of service com-

plexity, also different ways of using web services will

be discussed in detail. As a special focus of the pa-

per various security aspects of web services will be

presented. Our goal is to shape a new understanding

of mashups as the accelerators for the Web 2.0 move-

ment.

3 FROM APIs TO WEB SERVICES

- THE TECHNOLOGY BEHIND

Web-based systems are in general characterized by

orientation to network. However, the architectural

and interaction models, protocols, and data exchange

formats vary signiﬁcantly among different types of

web-based systems.

3.1 Web-based API

Networks of web-based systems can be build upon a

tight coupling via a Web-based API, enabling to in-

tegrate the functionality of a remote service or sys-

ICEIS 2008 - International Conference on Enterprise Information Systems

108

tem providing an interface speciﬁc for the given pro-

gramming language and the service integrated. For a

typical contemporary programming language, such an

API has a form of object-oriented library encapsula-

tion the remote service functionality. An integration is

thus technically easy but inﬂexible, being closely tight

to the respective programming environment; actually

not gaining any advantage of the service-orientation.

Despite of these disadvantages, many successful Web

2.0 services (like Delicious, Flickr, and others) offer

such an API.

3.2 SOAP-based Web Services

To provide a more ﬂexible, platform and language

neutral interfacing, current Web Services provide a

description of the service using the Web Services De-

scription Language (WSDL) that can be used to au-

tomatically generate clients interacting with the web

service. This allows an easy modiﬁcation of existing

applications if the interface of a web service changes.

In Web services, SOAP (Consortium, 2008)

serves as a protocol for messaging between a Web

service and its clients. Being based on XML, it rep-

resents a platform neutral foundation for wide sys-

tem interoperability with looser coupling than a web-

based API. Nowadays, SOAP-based Web services

are, despite of their complexity, the industry standard

for implementing a service-oriented architecture in an

enterprise environment. They also quickly replaced

older interoperability efforts like CORBA, based on

distributed objects rather than on services.

However, for integration services on Web 2.0, they

might not always be the right option, as they do not

warranty scalability in a whole web dimension. An

alternative usable for web scale services requires even

simpler use, less overhead, and better scalability than

SOAP-based Web Services. REST architectural style

may be the right concept for such Web Services.

3.3 REST Web Services

REST (REpresentational State Transfer) was coined

by R. T. Fielding (Fielding, 2000). Fielding’s goal

was to specify a set of architectural constraints

(also called architectural style) ensuring better perfor-

mance and scalability within distributed hypermedia

systems fully based on successful HTTP protocol.

1. It uses the concept of resource instead of service.

A user, group, calendar item, map, or a document

are examples of a resource in the REST sense.

2. Resource are identiﬁed by unique URIs (typi-

cally URLs), and may have one or more Rep-

resentations that can be textual (like plaintext),

(semi)structured data (XML), or multimedia (like

images), among others.

3. HTTP protocol methods (like POST, GET, PUT,

and DELETE) correspond to basic operations on

resources.

Notably, the state of the processing ﬂow (“session”)

between the service provider and consumer is not kept

at the server – the communication is stateless. There-

fore, it supports robustness and scalability because

the communication between server and client consists

only of exchanging representations of resources and

thus may be proxied and/or cached.

Vinoski (Vinoski, 2007) notes namely that REST

architectural style with its uniform HTTP interface as

an important constraint signiﬁcantly simpliﬁes devel-

opment of large service distributed applications and

leads to more scalable and robust ones. While SOAP

service deﬁnition language (WSDL) inherently binds

data formats together with interface constraints, in

REST the data formats are necessarily orthogonal

to interfaces. REST thus introduces self-describing

messages based on standard formats (typically but

not limited to open web formats) negotiated between

client and server.

The REST architectural style simplicity and ease-

of-use led to large popularity of REST among

Web 2.0 service developers. Many of the present

Web 2.0 services (ProgrammableWeb.com, 2008)

prefer a REST-based API instead of a SOAP-based

one. Some services employing both SOAP- and

REST-based interface (like Amazon(Goth, 2004))

show that simpler REST-based service gaining about

80 % of the total trafﬁc clearly outperform their SOAP

counterparts.

4 DEVELOPING WEB SERVICES

AND MASHUPS

This section focusses on generating networks of web

services, so called mashup applications. After ex-

plaining the shortcomings of today’s web services

in Section 4.2, Section 4.3 presents the deﬁnition

of a mashup and the key advantages. In order to

automatically build networks of services, the self-

descriptiveness of web services is required as de-

scribed in Section 4.4.

4.1 Web Service Integration

In the past four years several frameworks and con-

cepts for an “Open Service Integration” for Computer

Supported Cooperative Work (CSCW) applications

WEB 2.0 MASHUPS FOR CONTEXTUALIZATION, FLEXIBILITY, PRAGMATISM, AND ROBUSTNESS

109

appeared. The range of these concepts and frame-

works spreads from simple ones, requiring manual

user interaction to select services from an UDDI in-

ventory to those, that try to ﬁnd and dock with newly

available services fully automatically.

The authors of (Lima-Gomes et al., 2005a; Lima-

Gomes et al., 2005b) offer a Loosely-coupled Envi-

ronment for Integrating Collaborative Applications

called LEICA. This framework consists of three

different components: session management, event-

notiﬁcation service, and adapter for each used col-

laborative application. The session management ex-

changes information with the adapters to conﬁgure

each session. After exchanging all necessary data,

the systems communicate using events, which are dis-

tributed through the event notiﬁcation service. As a

result, in LEICA each application is still independent

and no data is exchanged directly between systems.

In (Anzures-Garc

ıa et al., 2006) the authors pro-

pose a SOA-based architecture for collaborative ap-

plications. Their architecture includes a component

for managing sessions and for group awareness. Due

to its service-oriented structure, it is possible to in-

clude new services as web services. The disadvantage

of this architecture is that existing applications can-

not be used offhand as part of this service oriented ar-

chitecture. Instead, Computer Supported Cooperative

Work (CSCW)-Services need to be explicitly devel-

oped for this architecture in order to use the provided

services.

When applications and services rely on services

that are subscribed dynamically and on-demand many

other aspects, e.g. monitoring of Service Level

Agreements (SLA) for web services have to be con-

sidered. In (Keller and Ludwig, 2003) the authors

present the Web Service Level Agreement (WSLA)

framework, which is targeted at deﬁning and moni-

toring SLAs for web services. The WSLA framework

is part of IBM’s web service toolkit. Obviously such

developments are so successful, since the number of

available web services is increasing rapidly and thus

automatic ﬁnding, monitoring and coupling of web

services becomes essential.

4.2 Current Shortcomings and

Limitations

The searchability of web services is a signiﬁcant ben-

eﬁt in comparison to web-based APIs since potential

consumers can ﬁnd unknown services and providers.

However, the concept of the UDDI (Clement et al.,

2002) directory is not completely practicable, because

the supported search bases on WSDL ﬁles which in-

cludes plain text comparison and lacks of semantics.

A search returns all web services whose description

contains the searched keywords. Obviously, a de-

scription can be on the one hand extensive and not

only point out the key functionality of the associated

web service and on the other hand same terms can be

used in different contexts. As an example, searching

for the keyword “weather” ﬁnds 3% of all registered

web services at a popular web service repository like

Salcentral.com (Patil et al., 2004). Since the search

has to build on WSDL ﬁles and thereby to base on

text-search, the used terms have to be set in relation

to the semantic context.

METEOR's Annotation Framework

Consumer

Provider

WSDL files

annotated with Ontologies

Figure 1: WSDL Files Annotated with Ontologies.

Patil et al. have extended WSDL with semantic

annotations (Patil et al., 2004) in the METEOR-S

Framework to handle the missed out descriptiveness

of web services (see Figure 1). Setting the description

in a semantic context by using ontologies improves

the search quality and reduces the number of not

suitable search hits. The description of a web

service applies to its input / output (data semantics)

as well as its functionality or business workﬂow

processed by the web service (functional semantics).

A search which can differ between data semantics

and functional semantics is desirable to improve

the search quality by a more precise selection of

eligible services. Furthermore, in the context of the

METEOR-S Framework the execution semantics

as well as the QoS semantics have been identiﬁed

which describe the correctness and veriﬁcation

of the execution as well as the performance and

cost parameters associated with the service. Since

ontologies will increase over time, it was necessary

to develop a semi-automated process of annotating

web services with ontologies. The METEOR-S

Framework addresses the requested semi-automatism

and scalability by implementing adequate algorithms

for semantic annotation and categorization of web

services.

ICEIS 2008 - International Conference on Enterprise Information Systems

110

Web 2.0 application as a

mashup of services

robust

contexulizable

pragmatic

ﬂexible

service A

service B

service C

Figure 2: Web 2.0 Application as a Mashup of Services.

4.3 Integration in Web 2.0

A Web 2.0 application being a mashup unions differ-

ent web services in order to provide more functional-

ity for a client interacting with this Web 2.0 applica-

tion. As an example, the mashup application capsu-

lates the interaction with a service A for searching in

a digital library with a service B for storing or linking

documents in a CSCW system. Hence, the mashup

application offers to clients the whole functionality to

search for digital literature as well as storing docu-

ments in a CSCW system by interacting only with one

application. The interaction with one single applica-

tion has a big beneﬁt for the service consumer, since

searching for literature and making these documents

available for e.g. other students should be one step

without a media breach.

Figure 2 depicts our deﬁnition of mashups. The key

idea of developing Web 2.0 applications as mashups

of services is that they are pragmatic and contextuliz-

able by combining different web services in order to

higher the value of using the services. In particular,

often the value of using the combined services is sig-

niﬁcantly higher than using services separately. Since

the Web 2.0 application can add, remove, or exchange

arbitrary services of their mashup, they provide high-

est ﬂexibility for services. Web 2.0 applications can

hold themselves a set of useable web services provid-

ing the same functionality. If integrated services are

not running or not available, the Web 2.0 application

can use other services proceeding the same business

workﬂow. This interchangeability of web services in-

creases the robustness of services being mashups.

Note that the semantic annotation of web services

presented in Section 4.2 enables the contextualization

and generation of meaningful and pragmatic compo-

sition of several web services. However, to com-

pletely implement the composition, more information

(for example security aspects) than provided by the

WSDL ﬁle is required. Section 4.4 addresses this is-

sue.

service

consumer

service

provider

authentication

negotiation

service usage

Figure 3: Negotiation Process Between Service Provider

and Service Consumer.

4.4 The Ultimate Ambition:

Self-descriptive Web Services

As mentioned above, our understanding of mashups

does not only means to reuse existing web services but

also remixing services of different applications. The

following steps describe a communication cycle be-

tween service provider and service consumer in mis-

tel:

1. The ﬁrst step contains security aspects like au-

thentication and authorization, since not every ser-

vice consumer is allowed to use all available ser-

vices of any service provider.

2. In the second step both actors, the service provider

and the service consumer, negotiate about the ser-

vice usage. This means, that the service provider

describes the web service functionalities.

3. After successful service negotiation the consumer

uses the service by invoking its methods.

Figure 3 depicts the communication process in three

phases. The difference between a normal web ser-

vice invocation and the mistel web services is the ne-

gotiation process in step two with its enhanced self-

explanation capabilities. In fact a service provider

may also act as a service consumer and vice versa.

We have chosen a similar approach with deﬁning

a common API for collaborative systems called the

CowAPI. The goal is a to allow a loose coupling of

collaborative systems into an application. Because of

the varying functionality of different groupware sys-

tems we deﬁned some functional areas:

• Users: Create, Query, and Manipulate Users

• Groups: Create, Query, and Manipulate Groups,

Group Membership Files: Create Files and Con-

tainers, get inventory of containers

WEB 2.0 MASHUPS FOR CONTEXTUALIZATION, FLEXIBILITY, PRAGMATISM, AND ROBUSTNESS

111

• Calendars: Create and manage appointments

A system implementing the CowAPI could imple-

ment all functional areas or a subset. The explain

functionality allows to return the supported function-

ality. Because of the standardized API it is now pos-

sible to exchange systems without needing to rewrite

any code. The CowAPI could be used as a media-

tor service to connect different backend groupware

servers or could be made directly available within any

groupware system.

5 CONCLUSIONS

The usage of web services providing access to al-

ready developed applications had increased the num-

ber of application ﬁelds in comparison to static web-

based APIs. However, a single web service often does

not offer the complete functionality requested by con-

sumers. As a consequence, networks of services of-

fer a higher value for consumers since they gain more

functionality or can use more complex business work-

ﬂows by interacting with one single Web 2.0 appli-

cation being a mashup of various services. Mashups

feature pragmatism, robustness, and contextualization

since they can add, remove, or exchange speciﬁc web

services of their network.

To enable an automatic generation of mashups, on

the one hand semantic annotations are desirable in or-

der to identify those services whose composition of-

fers a higher value for consumers. On the other hand

web services must be able to describe themselves in

detail. Hence, a negotiation phase will be performed

before a service can be added to the mashup.

ACKNOWLEDGEMENTS

The research has been supported by the German

Research Foundation (DFG), project MISTEL. For

further information please refer to www.dfg.de and

www.systemkonvergenz.de. Moreover the research

has been partially supported by the Czech National

Program Information Society, project E-learning in

the Semantic Web Context, No. 1ET208050401.

REFERENCES

Anzures-Garc

ıa, M., Paderewski-Rodr

ıguezguez, P., and

Hornos, M. J. (2006). Soa-based generic architecture

for cscw systems. In Proceedings of First Interna-

tional Conference on Ubiquitous Computing (ICUC),

Alcal

a de Henares, Spain.

Bih, J. (2006). Service oriented architecture (soa) a new

paradigm to implement dynamic e-business solutions.

Ubiquity, 7(30):1–1.

Clement, L., Hately, A., von Riegen, C., and Rogers, T.

(2002). Uddi version 3.0 published speciﬁcation.

Consortium, W. (2008). Soap version 1.2 – w3c recommen-

dation 27 april 2007.

sil, P., Hampel, T., Pitner, T., and Steinbring, M.

(2008). Get ready for mashability! concepts for web

2.0 service integration. In ICEIS 2008 Proceedings,

Barcelona, Spain. INSTICC.

Fielding, R. T. (2000). Architectural styles and the design

of network-based software architectures. PhD the-

sis, University of California, Irvine. Chair-Richard N.

Taylor.

Goth, G. (2004). Critics say web services need a rest. IEEE

Distributed Systems Online, 5(12).

Gurguis, S. A. and Zeid, A. (2005). Towards autonomic web

services: achieving self-healing using web services.

SIGSOFT Softw. Eng. Notes, 30(4):1–5.

Keller, A. and Ludwig, H. (2003). The wsla framework:

Specifying and monitoring service level agreements

for web services. J. Netw. Syst. Manage., 11(1):57–

81.

Lima-Gomes, R., de Jes

us Hoyos-Rivera, G., and Courtiat,

J.-P. (2005a). Leica: Loosely-coupled environment

for integrating collaborative applications. In DEXA

Workshops, pages 635–639. IEEE Computer Society.

Lima-Gomes, R., de Jes

us Hoyos-Rivera, G., and Courtiat,

J.-P. (2005b). Loosely-coupled integration of cscw

systems. In Kutvonen, L. and Alonistioti, N., editors,

DAIS, volume 3543 of Lecture Notes in Computer Sci-

ence, pages 38–49. Springer.

Michlmayr, E. (2005). A case study on emergent semantics

in communities. In Proceedings of the Workshop on

Social Network Analysis, International Semantic Web

Conference (ISWC).

Narayanan, S. and Mcilraith, S. (2002). Simulation, veriﬁ-

cation and automated composition of web services. In

Proceedings of the 11th International Conference on

World Wide Web, pages 77–88, New York, NY, USA.

ACM Press.

Patil, A., Oundhakar, S., Sheth, A., and Verma, K. (2004).

Meteor-s web service annotation framework. In Pro-

ceedings of the Thirteenth International World Wide

Web Conference (WWW2004), New York, USA. LS-

DIS Lab, University of Georgia.

ProgrammableWeb.com (2008). Programmableweb –

mashups, apis, and the web as platform.

Schranz, M. W. (1998). Engineering ﬂexible world wide

web services. In SAC ’98: Proceedings of the 1998

ACM symposium on Applied Computing, pages 712–

718, New York, NY, USA. ACM.

Vinoski, S. (2007). Rest eye for the soa guy. IEEE Internet

Computing, 11(1):82–84.

ICEIS 2008 - International Conference on Enterprise Information Systems

112
