MODELING HUMAN INTERACTION

TO DESIGN A HUMAN-COMPUTER DIALOG SYSTEM

A. Loisel, N. Chaignaud and J-Ph. Kotowicz

LITIS Laboratory - EA 4108 - Place Emile Blondel - BP 08 - 76131 Mont-Saint-Aignan Cedex, France

Keywords: Human-computer dialog, human factors, intelligent user interface, intelligent agent, corpus analysis.

Abstract: This article presents the Cogni-CISMeF project, which aims at improving the health information search

engine CISMeF, by including a conversational agent that interacts with the user in natural language. To

study the cognitive processes involved during information search, a bottom-up methodology was adopted.

An experiment has been set up to obtain human dialogs related to such searches. The analysis of these

dialogs underlines the establishment of a common ground and accommodation effects to the user. A model

of artificial agent is proposed, that guides the user by proposing examples, assistance and choices.

1 INTRODUCTION

CISMeF (French acronym for “Catalog and Index of

French-language health resources” www.cismef.org)

aims at describing and indexing the main French-

language health resources in order to assist health

professionals and consumers in their search for

electronic information available on the Internet. To

index resources, CISMeF uses four different

concepts: meta-term, keyword, subheading and

resource type. It contains a thematic index, including

medical specialties, and an alphabetic index.

Nowadays, the system includes a graphic user-

interface, a query language and uses index and

thesaurus to find information. However, the

“extended” and the “boolean” search options

increase the complexity of the interface and users

are not comfortable with it.

The aim of the Cogni-CISMeF project is to

improve search in CISMeF by including a

conversational agent that interacts with the user in

natural language. This agent leads the user in his

information search by analyzing his aims and by

proposing, assistance and choices. Once recognized,

the user’s intention is translated into queries.

In order to adapt the system to the user, we

believe that the human-computer interactions shall

be designed to mimic human interactions. To this

end, an experiment has been set up to obtain human

dialogs between a CISMeF expert and users looking

for health information. These dialogs (constituting a

corpus) have been analyzed to extract their

discursive structure and their linguistic features in

order to build a cognitive model of a conversational

agent.

In this article, Section 2 describes related work

on dialog systems. Section 3 details the

psychological experiment we have set up and the

corpus collection. The analysis of the corpus is

presented in Section 4 and Section 5 describes the

cognitive model that we propose, according to these

results. In Section 6, conclusion and perspectives

close this paper.

2 DIALOG SYSTEMS

Theories used by human-computer dialog systems

can be classified into several categories. One

possibility is to assess whether they are based on the

agent intention or on social conventions.

2.1 Intention based Approaches

Intention based approaches use a representation of

the mental states of the artificial agent. The most

famous model is BDI (Belief, Desire and Intention).

which has been used both in logic (Cohen and

Levesque, 1990) and planning (Allen and Perrault,

1980) settings. Its implementation is complex and its

reuse is domain restricted.

227

Loisel A., Chaignaud N. and Kotowicz J. (2008).

MODELING HUMAN INTERACTION TO DESIGN A HUMAN-COMPUTER DIALOG SYSTEM.

In Proceedings of the Tenth International Conference on Enterprise Information Systems - HCI, pages 227-232

DOI: 10.5220/0001698402270232

 SciTePress

2.2 Convention based Approaches

To simplify, a dialog can be considered as a protocol

represented by finite state automata in which

transitions are the possible speech acts of the dialog.

The agent has no internal representation. These

approaches are rather rigid even if some of them

(Sitter and Stein, 1992) use recursive automata.

Another conventional model (Lewis, 1979)

consists in representing information shared during

the dialog (called “common ground”) in a

conversational board. This theory is more

descriptive than predictive and thus is difficult to

integrate into a dialog system.

2.3 Mixed Approaches

Dialog games (Levin and Moore, 1980) are

interested in social conventions between utterances.

They use structures, games for which interactions

are precisely described. Games are stereotypes that

model a communicational situation.

The QUD (Questions Under Discussion) model,

proposed by (Ginzburg, 1996) and totally

implemented in the GoDiS system (Larsson, 2002),

takes into account mainly the transmission of

missing information. The dialog uses both a

conversational board and internal representation of

the agent. This approach is mainly based on the

questions and their responses. Each speech act

(enunciated by the user or the system) modifies the

“information state” (IS), comprising a private part

and a public part.

With the “grounding” theory, (Traum, 1994)

proposes 5 modalities according to which an

utterance is grounded: perception, contact, semantic

understanding, pragmatic understanding, integration.

For each modality, there are speech acts of positive

(resp. negative) grounding if this modality is (resp.

is not) grounded. For example, if the perception is

grounded but not the semantic understanding, the

system can produce a repeating of the utterance to

show that it has been heard and then it can say a

speech act like “not understood”.

This approach is highly capable when it is added

with accommodation effects (Lewis, 1979) like in

GoDiS. When user utterances do not match with the

current plans, the system loads a new relevant plan

to this utterance. Plans can be performed in parallel.

3 CORPUS COLLECTION

At first, we wanted to model the reasoning of the

CISMeF chief librarian, when he was searching in

the CISMeF system. He was asked five questions

from health professionals and his answers have been

recorded. These records showed that the CISMeF

chief librarian has a complete understanding of the

user’s intention and suggests optimal queries.

However, he does not need to converse with the user

to understand his inquiry. We had thus to set up a

new experimentation dealing with the recording of

dialogue between a CISMeF expert and a user.

The users were voluntary members of the LITIS

laboratory (secretary, PhD students, researchers and

teachers) who wanted to obtain responses about

medical inquiries. The experts were two members of

our project, trained to the CISMeF system and

terminology. The experimentation took place as

follows: one expert and one user were facing a

computer using the advanced search interface of the

system and recording all the queries with their

answers in a log. The expert was in charge of

conducting the search by conversing with the user

and verbalizing each action, inquiry and answer. The

experimentation ended when relevant documents

were given to the user or when it seemed that no

answer existed in the system. A textual corpus was

constituted from the transcription of the twenty-one

dialogues recorded.

Moreover, following this experimentation, we

asked the CISMeF chief librarian to answer the

users’ inquiries and to verbalize his search process.

The verbal occurrences were also recorded. Our aim

was to obtain optimal queries to these questions

using the CISMeF terminology. They provide

explanations about the strategies adopted by the

chief librarian.

4 ANALYSIS OF THE CORPUS

We have hand-analyzed the textual corpus. During

the conversations, experts tried to keep control of the

dialog by making the user repeat and confirm his

utterances to avoid ambiguity or contestation. Many

discursive tags (agreement, question, suggestion,

refusal…) lead to interaction. Several iterative loops

ensure the continuity of the dialog.

This analysis brings out a global structure of

dialogs broken down into sub-dialogs and it allows

to build a list of speech acts observed in the corpus.

4.1 Global Structure of Dialogs

In the dialogs, there are a lot of comings and goings

between the initial query of the user and the answers

of the system depending on the results. Moreover,

dialogs can be divided into sub-dialogs. Figure 1

ICEIS 2008 - International Conference on Enterprise Information Systems

228

describes the possible links between sub-dialogs. A

dialog always begins with an opening sub-dialog,

which can indifferently be short or long. It consists

in identifying the user, presenting the CISMeF

system and negotiating the task. Then, the user can

ask the expert his medical inquiry in a querying sub-

dialog. The expert reformulates the question to be

sure of the tackled themes and the meaning of the

words used. The inquiry can be broken down into

several other inquiries that can be a question about a

definition or about explanation on the system itself.

In the case of an information inquiry, the expert

builds the query with the help of the user. Each term

constituting the query is discussed according to the

CISMeF terminology. Queries are performed and the

list of documents is presented to the user. One

particular document can be described. At any time,

these sub-dialogs can be interrupted by precision

inquiries. The dialog finishes with an ending sub-

dialog on the initiative of the user either with a

success (the documents are relevant) or with a

failure.

Figure 1: Links between sub-dialogs.

4.2 Taxonomy of Speech Acts

A list of speech acts has been built according to

linguistic features found into the corpus.

This taxonomy comes from (Weisser, 2003) and

has been adapted to our corpus. It follows the

illocutionary force of the speech acts.

Initiative assertives

• Inform: to bring information without

expecting any response

(e.g. expert: “I think that the keyword

“parasomny” also exists”)

Initiative directives

• RequestInfo: information query

(e.g. expert: “Do you think that we can find a

medical specialty?”)

•

Offer: to propose something that the

interlocutor can accept or refuse

(e.g. expert: “Do you want to try with the

keyword “general medicine”?”)

•

RequestDirective: the speaker expects

guidelines from the interlocutor

(e.g. expert: “What is your question?”)

Reactive assertives

• Answer: response to a question

(e.g. expert: “There are to many

documents!”)

•

Accept: to agree with a previous utterance

that is both achieved and satisfied

(e.g. user: “Yes, exactly!”)

•

Refuse: to refuse a previous utterance that

is achieved but not satisfied

(e.g. user: “No, I am not interested”)

•

Acknowledge: to tell the interlocutor that

his utterance is achieved

(e.g. expert: “Ok! I understood the

question!”)

•

WantsNothing: to answer negatively to a

RequestDirective

(e.g. user: “No, I do not want anything else”)

Reactive directives

• Confirm: request of utterance confirmation

(e.g. expert: “You want to know the process

to follow to donate an organ, don’t you?”)

Declaratives

• Bye: to conclude the conversation and to

close the communication channel

(e.g. expert: “Bye, have a nice day!”)

•

Greet: to initiate a conversation or to

pursue it after a break

(e.g. expert: “Hello, what is your question?”)

Promissives

• InformIntent: to specify to the

interlocutor what we are about to do

(e.g. expert: “Well, let’s see if we can find

something about it”)

Some of these acts are explicit « grounding »

acts:

Accept, Acknowledge, WantsNothing,

Confirm, Refuse.

The analysis of these dialogs highlighted:

• the breaking down of the dialogs into sub-

dialogs represented by plans;

• the establishment of a common ground,

thanks to rewordings, agreements, questions;

• a list of speech acts, classified according to

their illocutionary force and their content;

• a classification of some of these acts as

positive or negative « grounding » acts;

• accommodation effects on the user.

MODELING HUMAN INTERACTION TO DESIGN A HUMAN-COMPUTER DIALOG SYSTEM

229

5 MODELING A

CONVERSATIONAL AGENT

From the corpus analysis, our aim is to design a

software agent able to converse with a user and help

him to find information.

5.1 Agent Architecture

Our agent (Figure 2) is composed of 3 main

modules:

• The language model, which receives the

user’s inquiry in natural language. It

performs a lexical and syntactical analysis

(using TreeTagger (Schmid, 1994) from

Stuttgart University), a pragmatic analysis

(from our speech act analyzer, which uses

linguistic tags — like tense, modality and

context — to assign speech acts to

utterances, thanks to a set of rules) and a

semantic analysis (identification of terms

from the CISMeF terminology).

• The dialog model, which comprises the

dialog manager and the sentence generator

based on incomplete sentences.

• The task model, which encapsulates the

CISMeF interface to access the medical

document base. It includes also a query

builder from the recognized terms and a

result interpreter.

Figure 2: Conversational agent architecture.

This agent is under development in Java. Our

dialog uses the implementation of GoDiS (Larsson,

2002) written in Prolog. We only describe here the

dialog manager.

5.2 Dialog Manager

The GoDiS system (Larsson, 2002) is well adapted

to our needs, since it is based on an explicit task and

requires no reasoning on users intention. However, it

uses a list of speech acts, which is less extensive

than ours: it misses acts like

Inform, Offer and

Suggest. These acts allow the system to propose

relevant information in an opportunistic way

according to the search.

5.2.1 Overview

Our dialog manager performs a set of plans to

produce speech acts. There exist two types of plans:

• question plans (planQ), in the sense of QUD,

which aim at answering inquiries by

returning data;

• action plans (

planA), which run a sequence

of actions.

The formalism uses the predicate logic with the

operator “?” to represent questions. There are three

types of questions:

• the total inquiries: ?P,

• the partial inquiries: ?P(x),

• the inquiries with a list of choices:

?set(P1(x), P2(y), P3(z)).

Moreover, our dialog manager controls an

information state (IS) composed of a private part and

a public part.

The private part contains:

•

Agenda, actions of the current plan,

•

Bel, the knowledge of the system,

•

Plan, the current plan,

•

Nextmove, the next speech act to be

produced.

• The public part is the conversational board:

• Com, shared knowledge,

• Issue, planQ in progress or idle,

•

Qud, focus on Issue,

•

Action, planA in progress or idle.

Plans use a list of actions that can produce

speech acts. This list comes partly from GoDiS:

•

findout(Q) to question with the speech act

Ask. The system repeats the question Q until

it is answered or aborted.

•

raise(Q) to question (only one time)

optionally.

•

bind(Q) to answer the question Q without

posing the query.

•

assume(B) to add a predicate B to the

knowledge

Bel.

ICEIS 2008 - International Conference on Enterprise Information Systems

230

•

assumeAction(A) to add a predicate A to

Agenda.

•

assumeIssue(I) to add a predicate I to

Issue.

• consultDB(Q) to interrogate the data base

and to add relevant information to

Bel to

make suggestions.

• cooperativeSearch(p,l,r) to suggest

to the user information having a property

among a list

l in com. r is the result of the

search (

failure or success).

•

report(I) to say the speech act inform.

•

say(l) to say a speech act l,

•

loadPlan(p) to load a plan p to be

performed.

• The predicate

PostCond(P,A) allows to

give the value

A to the predicate P.

Suggestions can interrupt these plans in an

opportunistic way. A rule base generates them

according to the IS. There exist three types of rules:

• rules to update private or shared beliefs in

the IS,

• rules to choose a speech act according to the

utterance just pronounced by the user,

• strategies or meta-rules to choose the update

rules to be used during interactions: to

update the IS with the contents of the speech

act, to load plans from the plan library to

Plan, to use accomodation rules when a non

expected speech act is found, to move the

current action from

Plan to Agenda, to

clean the IS, to perform the action in

Agenda.

Each sub-dialog (Figure 1) is represented by a

dialog plan (

PlanQ or PlanA). We describe below

three of them: the opening plan, the queryAnalysis

plan and the

DocumentSearch plan.

5.2.2 Opening Plan

The Opening plan allows the system to initiate the

dialog with a prompt. Then the

QueryAnalysis

plan is loaded.

PlanA

(Opening,

(say(Greet),

loadPlan(QueryAnalysis)))

5.2.3 QueryAnalysis Plan

The QueryAnalysis plan aims at gathering the

query of the user. If the user does not ask quickly his

question, the action

Findout allows the system to

ask for his goal (definitions, documents or

explanations about the system).

PlanA

(QueryAnalysis,

(raise(?question(q)),

ifThen(not q)

findout(?set(question(Definition)),

(question(Document)),

(question(Explanation)))

ifThen(question(Definition))

loadPlan(DefinitionSearch),

ifThen(question(Document))

loadPlan(DocumentSearch),

ifThen(question(Explanation))

loadPlan(ExplanationSearch)))

When the user opens a dialog with the system

and submits directly his query (e.g. “Hello, I would

like to know if …”) in one sentence, an

accommodation rule allows the system to load two

plans successively (

Opening and QueryAnalysis

plans) to adapt itself to this single sentence.

5.2.4 DocumentSearch Plan

The DocumentSearch plan performs several steps

of the sub-dialog: it builds the query and submits it

to the database. Then, it evaluates the resulting

documents if any. It comprises several plans

described below.

This plan is special since it remains active in the

IS. The search can be refined to increase the number

of results or expanded to decrease the number of

results. This plan ends only with an agreement of the

user (with or without success).

PlanA

(DocumentSearch,

(findout(?term(t)),

ifThen(t)

loadPlan(QueryBuilding(t)),

ifThen(∃ d ∈ Bel)

loadPlan(ListEvaluation(d))))

Post-condition: this plan remains active.

QueryBuilding plan

The

QueryBuilding plan includes four different

steps:

1. At the beginning of the search, from the initial

query, the system suggests keywords of the

CISMeF taxonomy thanks to the action

CooperativeAction.

2. If the keywords found in the previous step are

not sufficient to find documents, the system

tries to refine the query by suggesting meta-

terms and subheadings. If it does not find any

term, it can ask to the user.

3. If not enough documents are found, the

system expands the query.

4. If too many documents are found, the system

refines the query.

The action

CooperativeAction determines

how to specify the inquiry to obtain relevant

documents: add or delete terms, use synonyms,

hyponyms, hyperonyms, etc.

MODELING HUMAN INTERACTION TO DESIGN A HUMAN-COMPUTER DIALOG SYSTEM

231

PlanQ

(QueryBuilding(d),

(ifThen(not ∃ keyword(k) ∈ Com)

(cooperativeSearch(keyword(k),term(t),r)

report(submitQuery),consultDB(d)),

ifThen(∃ keyword(k) ∈ Com

and NotEnoughDocument ∉ Com)

(report(refine),

cooperativeSearch(metaTerm(m),

term(t),r),

ifThen(not ∃ metaTerm(m) ∈ Com)

raise(?metaTerm(m)),

ifThen(not ∃ subheading(q) ∈ Com)

raise(?subheading(q))

report(submitQuery),consultDB(d)),

ifThen(NotEnoughDocument ∈ Com)

(cooperativeSearch(SpecificTerm(s),

term(t),r)

ifThen(r=failure)

(findout(?term(t)),consultDB(d)))

ifThen(NotEnoughDocument ∉ Com)

(report(refine),

cooperativeSearch(SpecificTerm(s),

term(t),r)

raise(?term(m)),

ifThenElse(∃ term(t) ∈ Com)

(consultDB(d),

findout(?term(t)),consultDB(d)))))

ListEvaluation plan

The

ListEvaluation plan takes as input a set of

documents

d and informs (as output) the user

whether the documents are numerous enough or not

according to the limit δ (min and max). If they are

sufficient, the plan loads the plan

DocumentDescription.

PlanQ

(ListEvaluation(d)

(getNbDocuments(d,nb),

report(nbdocuments(nb)),

ifThen(nb<δ

min

,(assume(notEnoughDocument),

report(notEnoughDocument)))

else(ifThen(nb>δ

max

(assume(tooMuchDocuments),

report(tooMuchDocuments)))

else(assume_issue

(DocumentDescription(d))))))

DocumentDescription plan

The

DocumentDescription plan takes as input a

set of documents d, analyses their headers to decide

whether they are relevant to the user’s question. If

necessary, the user is also given a chance to assess

the relevance of the documents.

Suggestions can interrupt these plans in an

opportunistic way and trigger for example a plan

that explains the system. These suggestions are

generated by a set of rules according to the IS.

PlanQ

(DocumentDescription(d),

While(not interesting(x))

(member(d,x),

Report(description(x)),

cooperativeAction(interesting(x))

bind(?interesting(x))

ifThen(interesting(x))

raise(?EndOfSearch)))

6 CONCLUSIONS

We adopted an interdisciplinary approach to design

a human-computer dialog system for health

information search. We collected and analyzed a

rich textual corpus on which the building of a

common ground and accommodation effects on the

user have been observed. Dialogs can be divided

into sub-dialogs, directly linked to the task. This

analysis allowed us to propose a cognitive model

based on the theories of “grounding” and

“accommodation”.

This model is under development. Once

implemented, our system will be tested with users on

the web to obtain human-computer dialogs, in order

to identify and fix its shortcomings.

The validation of our system consists in

evaluating the added value brought to CISMeF. The

idea is to compare the queries made by the user,

those proposed by the chief librarian and those built

using our dialog system. This comparison will be

made by calculating queries precision and recall.

REFERENCES

Allen J, Perrault C, 1980. Analysing intention utterances,

Artificial Intelligence, 15, 143-178.

Cohen P, Levesque H, 1990. Rational interaction as the

basis for communication, in Intentions in

communication, Cohen & Pollack, 221-255.

Ginzburg J, 1996. Interrogatives: Questions, facts, and

dialogue. In Shalom Lappin, editor, Handbook of

Contemporary Semantic Theory. Blackwell, Oxford.

Larsson S, 2002. Issue-Based Dialogue Management, PhD

thesis, Goteborg University.

Levin J, Moore J, 1980. Dialogue-games: meta-

communication structure for natural language

interaction. Cognitive Science, 1(4), 395-420.

Lewis D, 1979. Scorekeeping in a language game, in

Pragmatics : a reader, Davis S, 416-427.

Schmid H, 1994. Probabilistic part-of-speech tagging

using decision trees. International Conference on New

Methods in Language Processing, 44-49.

Sitter S, Stein A, 1992. Modeling the Illocutionary

Aspects of Information-Seeking Dialogues.

Information Processing and Management, Vol. 28 (2),

165-180.

Traum D, 1994. A computationnal model of grounding in

Natural Language Conversation, Phd thesis,

University of Rochester.

Weisser M, 2003. SPAACy: A tool for Annotating

Dialogue, International Journal of Corpus Linguistics,

Vol. 8.1.

ICEIS 2008 - International Conference on Enterprise Information Systems

232
