BUSINESS DRIVEN RISK ASSESSMENT
A Methodical Approach to Risk Assessment and Business Investment
David W. Enström
1246857 Ontario Ltd., 14 Honey Gables Dr., Ottawa, K1V 1H5, Canada
Siavosh Hossendoust
Enterprise Security Architect, IBM, 2220 Walkely Road, Ottawa, Canada
Keywords: High Assurance Enterprise Security Architecture Risk Assessment Planning.
Abstract: Dynamic business environments require concurrent, distributed, and flexible architectures that must provide
an agreeable level of reliability and acceptable level of trust. A three level undisruptive business driven
planning process has been formulated using a risk analysis model that provides a justifiable direction for
implementing a low risk solution and selecting appropriate products. The methodology includes
identification of “Risk Priority” through assessment of risks for: business effectiveness, logical IT solution
architecture (PIM) aspects, and physical IT solution architecture (PSM) aspects. It also introduces a risk
dependency analysis process as an aid in understanding relationships between architectural layers. This
proposed methodology aids in understanding and prioritizing risks within the context of the organization; it
has broadened the concept of a TRA into a risk controlled solution architecture domain.
1 INTRODUCTION
This paper articulates a modern IT capability
planning and acquisition process that fuses business
and technology experts with best practices and
lessons learned to increase synergy between
capability acquisition and its support of business
objectives. This is done through the assessment of
risks in the context of business priorities, solution
architecture options and technical solution options.
A conceptual model for risk is developed along with
characterization and analysis of business impact and
architectural impact.
Traditionally, technology experts and project
managers rely on their technology and domain
knowledge, plus best practices, to compare solution
options and plan investment. Undoubtedly, this kind
of approach has produced many high–value lessons
learned for solution architecture improvements, risk
mitigation and planning that have not been exploited
effectively. These lessons learned have evolved to
the point where today there are widespread
enterprise planning and architecture processes
beneficial for large IT projects. These processes
strive, through the application of proven
methodologies and enforcing best practices, to
provide quality product delivery that meets the
business requirements. The use of these processes is
proven to eliminate and mitigate investment and
development risks, and also result in solutions that
better meet the business need.
This paper describes a methodical approach for
the assessment of risk based upon business priorities
and goals, logical architecture aspects and physical
architecture aspects with an aim to improve the
cost–effectiveness and business benefits of corporate
IT security investments.
2 RISK MODEL
The proposed process is dependent upon a thorough
analysis of risk. Risk can be decomposed into three
disjoint sets or categories, namely risk associated
with business operations, risk associated with the
chosen logical solution and risk associated with the
physical solution implemented:
High priority risks are usually the ones of interest
to the business and IT since they will have the
271
W. Enström D. and Hossendoust S. (2008).
BUSINESS DRIVEN RISK ASSESSMENT - A Methodical Approach to Risk Assessment and Business Investment.
In Proceedings of the Tenth International Conference on Enterprise Information Systems - ISAS, pages 271-278
DOI: 10.5220/0001701602710278
Copyright
c
 SciTePress

largest impact. It is therefore important to
understand the relationship between risks at each of
these architectural layers, at both initial capability
design and implementation time and later in the
system life–cycle.
Dependencies exist between business
components (i.e. functions and processes), between
logical architecture (Processing Independent Model
(PIM)) components and between Physical level
solution (Processing Specific Model (PSM))
components. Dependencies also exist between
components at one layer (e.g. business) and other
layers (e.g. PIM). For example, an important
business process may rely on a server, and the
server’s life expectancy and availability are
dependent on the reliability of its weakest
component (e.g. hard drive or power supply). These
dependencies need to be systematically analyzed in
such a way that high priority (and some medium
priority) risks can be identified and mitigated.
Systematic prioritization (based upon business
drivers) of these risks is done, which provides many
benefits.
This Risk Dependency Analysis can be directly
equated to Social Network Analysis, where in the
risk context the nodes are business, PIM or PSM
components and the relationships or ties between
nodes are the risk dependencies as shown in Figure
1.
B
B
B
B
B
B
B
L
L
L
L
L
L
L
P
P
P
P
P
P
P
- Business Component
5 - High Risk Priority
1 - Low Risk Priority
2 - Dependency Priority
5
5
5
5
5
5
3
3
3
3
3
3
3
3
3
3
2 2
2
2
2
2
2
2
2
2
2
2
1
1
1
1
1
1
1
- Logical Component
- Physical Component
- Dependency
...
Figure 1: Risk Dependency Analysis Model.
3 RISK ASSESSMENT PROCESS
The process aims to define strategic IT plans in line
with the business priorities through the definition of
a more formal approach to the assessment of risks.
This assessment process, summarized in Figure 2, is
driven by business priorities along with an
assessment of logical and physical component
solutions. Therefore, each organization’s specific
situation and characteristics will be used to
determine the most significant sources of business
productivity, the business areas affected along with
the risks that pose the highest impact and chance of
happening.
The model in Figure 2 is used to define the
relative risk priority based upon risks that have the
highest business impact, which in turn drives the
selection of technologies and solutions that are most
useful for business. In other words, the impacts of
risks plus constraints derived from the business is
used to develop a comprehensive and low risk plan,
which in turn leads to product selection choices that
mitigate a given level of risks. This has the
following benefits:
¾ Understanding the risk impact and risk priority allows
selection of solutions appropriate and cost–effective
for a given risk
¾ Risk impact analysis permit a more logical and
appropriate phasing of implementation
¾ Design and technology choices, including costs, are
easily justified based upon this type of risk analysis
Prioritized Risks
Solution Architecture
(PIM and PSM)
Risk Categories
Risk Rating Criteria
- Business Effectiveness Risks
- Logical Architecture Risks
- Physical Architecture Risks
- Risk Importance
- Probability of Occurrence
- Asset Value
Risk Prioritization
Drives
RDA
RDA = Risk Dependency Analysis
Key Constraints
Key Dependencies
-Laws
- Business Rules
- Partnership Obligations
- Cost
- Skill Types
- Skill Levels
- Service Provider
Constraints
Feedback
Feedback
Figure 2: Business Driven Risk Analysis.
The Risk Prioritization portion of the model
shown in Figure 2 is the key aspect of this business–
driven approach. It will be described in more detail
below. The Risk Dependency Analysis (RDA) is a
refinement of available solution options (also see
Figure 3), whereas constraints are conditions to
which all solutions must comply.
4 RISK PRIORITIZATION
The prioritization of risks, based upon several
methodical criteria, is the key to this process. The
process for determining risk priority is applied to all
identifiable risks. This process is used to assess all
ICEIS 2008 - International Conference on Enterprise Information Systems
272

types of risks. Risks are identified and evaluated
based upon three categories:
¾ Business Effectiveness Risks – Risks that, if they
were to occur, would harm the effectiveness of the
business to accomplish it goals.
¾ Logical Architecture (PIM) Risks – Risks in this
category are associated with the logical definition of
the solution architecture, the lack of proper Identity
Management for example.
¾ Physical Architecture (PSM) Risks – Risks in this
category are associated with the physical definition of
the solution architecture, the specific attributes of a
technology in use for example.
These categories are defined further below.
4.1 Business Effectiveness Risks
Timely, accurate, and appropriately information
gathering, flow, processing, analysis and secure
distribution are needed to maintain business
effectiveness. Consequently, for the organization to
stay in business, it is necessary that it satisfy client,
partner and vendor obligations. The following
business capabilities are examined, among many
others, to determine the level of risk involved for the
various business areas
¾ Well defined and fully enforced business processes
¾ Undisrupted and high quality business services
¾ High quality services management:
¾ Timely access to valuable information
¾ Suitable communication channels at all levels
¾ Uninterrupted legitimate user access
4.2 Logical Architecture Risks
The logical architecture includes an end–to–end IT
systems strategy for various aspects of the IT
infrastructure and environment in accordance with
the organizational (and partner) policies and
business rules. Risks have significant importance in
this context and must be rated appropriately by the
IT and security subject matter experts.
The logical level architecture defines the
approach for developers, which is evaluated to
determine the level of risk involved for its various
aspects. Some of the aspects of the logical
architecture to be examined to identify risks are:
¾ User requirements
¾ Business use cases
¾ System use cases
¾ Architectural decisions
¾ Architectural models
¾ System requirements / specifications
¾ Policies and business rules
¾ Service / component aspects and structure
¾ Resource / content management
¾ Integration and interoperability
4.3 Physical Architecture Risks
The physical architecture must include an end–to–
end IT product strategy for the IT environment, and
in accordance with organizational (and perhaps
partner) policies and business rules. Risks have
significant importance in this context and must be
rated appropriately by the IT and security subject
matter experts.
The physical level (operational) risks such as
“inadequate admin tools” and common risks such as
“lack of timely product vendor information” are two
major areas that must be dealt with. Aspects of the
physical solution architecture to be examined,
among many others, to identify risks are:
¾ System testing
¾ System deployment
¾ System configuration
¾ System connectivity
¾ System protection
¾ System life–cycle management
¾ Administration
¾ Product type, setup and configuration
¾ Product service and support
¾ Product maintenance
¾ Product assurance level
4.4 Risk Rating Criteria
In–order to understand and prioritize risk within
these three contexts, it has been necessary to
broaden the concepts of the formal Threat Risk
Assessment (TRA). This has been achieved by
introducing a risk rating technique known as the
“Risk Priority”. Risk Priority is derived from three
conditions, namely Risk Importance, Risk
Probability and Asset Value. Each of these three
conditions is described below, followed by an
explanation of how they are used to calculate Risk
Priority. The referenced tables are in the Appendix
Having a Risk Priority provides many benefits,
including:
¾ The ability to make intelligent cost–benefit decisions
¾ The ability to choose protections appropriate for each
risk within a specific business context
¾ The ability to prepare intelligent implementation
planning and phasing decisions
4.4.1 Risk Importance
The risk importance rating defines the relative
importance of the risk to the organization; based
upon the threat and the organizational and business
context. For example, a business that only sells
online would place a very high risk importance on
business, solution and physical components
BUSINESS DRIVEN RISK ASSESSMENT - A Methodical Approach to Risk Assessment and Business Investment
273

supporting this portion of the business. Appendix
Table 1 defines the ratings used for risk importance,
along with specific criteria for determining the
correct importance value. Ratings defined are from 1
(very low Risk Importance) to 5 (very high Risk
Importance).
4.4.2 Risk Probability
The risk probability ratings, as described in Table 2,
define the likelihood of a risk (threat) occurring.
They are based upon the level of confidence of the
organization in the capability of its users, the
deployed environment, and organizational plans and
processes; plus the vulnerability of the component
that are characterized by the evaluator knowledge,
assurance level and environmental protection. These
two factors are what determine the likelihood of a
risk (threat) actually occurring. Ratings defined are
from 1 (very low Risk Probability) to 5 (very high
Risk Probability).
4.4.3 Asset Value
The Asset Value rating is purely a business valued
based assessment. The value of assets to the business
(not necessarily their monetary value), involved or
implicated in a specific risk/threat, define this rating.
The Risk Importance is based upon the impact to the
business of the risk occurring, the Asset Value
amplifies this by defining the relative value of assets
involved. For example, a business that only sells
online would place a very high Asset Value on
business, solution and physical components
supporting this portion of the business. Table 2
defines the generic ratings for Asset Value. The
ratings defined are from 1 (very low Asset Value) to
5 (very high Asset Value).
4.4.4 Risk Prioritization Calculation
Risk priority is a combination of the importance of
the risk, and the probability of the risk occurring,
and the value of the business assets involved.
The calculation of risk priority is quite simple:
Risk Priority = Risk Importance x Risk
Probability x Asset Value
The risk priority is calculated by multiplying
together the three rating criterion. If the risk
importance or risk probability are zero (the asset
value should never be zero), then the priority is zero,
meaning that no investment should take place to
mitigate the associated risk. Similarly, if the risk
importance is high and the risk probability is high,
then a level of investment commensurate with the
value of the business assets involved should be
made. Thus, once the Risk Priority is determined, it
is used to decide on the level of effort and expense
that should be applied in mitigating the risk, and in
the priority for implementation of safeguards.
All Possible
Products &
Solutions
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
M
M
M
M
M
L
L
H
L
L
L
L
C
= Product Choice
C
Legend
H
M
L
= High Priority Risks
= Medium Priority Risks
= Low Priority Risks
PSM
Risk
F
ac
t
o
r
s
PIM
Risk
Factors
Business
Level
Risk Factors
H
H
MM
LL
H
Risk Dependency Analysis
Figure 3: Solution Analysis: RDA vs. Solutions.
4.5 Solution Analysis
Figure 3 illustrates how analysis is used to finalize
capability planning and to select best products. The
potential candidate products from each optional
solution for physical architecture are examined to
determine what risks they mitigate at the business
level. This reduces further the possible set of
candidate products. Likewise, candidate solutions
are then examined to determine what risks they also
address at the PIM level. As shown in the diagram, a
solution to a business level risk will ideally address
multiple risks at the PIM level, and even more at the
PSM level. The solution is chosen that addresses the
most risks at all levels, all other factors (e.g. cost and
life–cycle cost) being equal. Some, hopefully low
level, risks may not be addressed by any solutions,
in which case the risk must be accepted by business
management, or changes will need to be made to the
architecture to reduce or eliminate these risks.
5 EXAMPLE
5.1 Simple Scenario
A modern datacenter for a global business is located
in a city that is known for ice storms. Ice storms
seriously affect the A/C power supply, among other
infrastructure services. The loss of power is a serious
business risk that impacts business obligations (e.g.
services uptime for customers must be equal or
ICEIS 2008 - International Conference on Enterprise Information Systems
274

better than 99.5 %). This situation is analysed below
following the described approach.
The Risk Importance rating is three (3) since it
will have an “important impact (denial of service
beyond agreeable delays, partners affected)” from
Table 1.
The Risk Probably rating is four (4) since there is
“Inadequate ability within the organization, or with
current technology, to reduce or manage the risk
impact” from Table 2.
The Asset Value rating is five (5) since the
“affected asset(s) is extremely important to day–to–
day business activity” from the Table 3.
Following the formula described above, the Risk
Priority for this particular risk is:
Risk Priority = 3 x 4 x 5 = 60
The real advantage to the business comes when
multiple risks are prioritised and Risk Dependency
Analysis is done, allowing informed investment
decisions to be made.
6 SUMMARY AND
CONCLUSIONS
6.1 Summary
The purpose of the process is to acquire IT security
solutions that mitigate risks at the appropriate level
and in line with business priorities. The logical
architecture and technical solution are also included
in the analysis. Life cycle costs and skills demand
should also be factored in to provide a complete
view of the solution. The significant stakeholders for
this approach are following groups:
1. Business mission management groups
2. IT planning & strategy groups
3. IT support & operations groups
Advantages of the proposed approach are:
1. Business evolution aided by methodical
threat risk assessment processes
2. Systematic prioritization resulting in cost
effective and appropriate investment
3. Repeatable analyses that are important for
evaluating architecture and solution options
4. Ability to validate the solution is in support
of the right business needs / priorities
5. Validation of the technical priorities in
relation to business priorities
6. Ability to compare alternative solution
options from multiple project aspects
Disadvantages of the proposed approach are:
1. Lack of standards for business prioritization
process
2. Dependent upon domain expert knowledge
3. Dependent upon the accuracy of the business
priorities
4. Dependent upon the quality of the logical
and physical architectures
6.2 Related Work
There is little work closely related to this analysis
approach. The (McGraw, 2006a and 2006b) article
and book summarize well the current activity, and
references some similar concepts; however this
paper broadens the definition of risk analysis so that
it includes multiple architectural layers, including
the business layer. It also shows how these
architectural layers may be related and understood
through Risk Dependency Analysis.
Similarly, (Kotonya) explores the usage of risk
analysis during development, but leaves out the
critical link to business requirements and business
plans.
Another similar approach by Robert Benedict
(NASA, 2003) shows risk analysis as part of a sound
business plan and its benefit to the Agency in
developing (and will be fully coordinated with the
ongoing effort to define) the NASA Enterprise
Architecture. Again, Michael G. Stamatelatos
(NASA, 2004) leaves out logical level and physical
level risks.
6.3 Future Work
Historically, the most common projects are those
that do not transform the business completely, do not
conflict with the enterprise architecture and do not
require noticeable changes to the infrastructure.
Recently, the evolution of new architectural
frameworks such as Service Oriented Architecture
(SOA) and Model Driven Architecture (MDA) are
providing the ability to make rapid changes at
business, architecture and infrastructure levels.
As always, practitioners who are specialist in
their domain and very likely familiar with theses
frameworks still need a systematic and repeatable
process that helps them to make timely, effective
and low risk capability planning decisions.
Generally, the current common concerns are “How
do we get there?” and “How do we do that?” We
have explained within this document, through a
systematic and repeatable process, “How we get
BUSINESS DRIVEN RISK ASSESSMENT - A Methodical Approach to Risk Assessment and Business Investment
275

there”. We will discuss a systematic process “how
we do that” in future work.
6.4 Conclusions
The systematic and repeatable process allows
capability planners to develop and prioritize
capabilities and assess the gain/ impact before
making project proposals or even making serious
investments.
The feedback from program managers that have
used this process for large project capability
planning (projects that continue for several years)
have been very positive and they have confirmed
that application and demonstration of this process as
part of their capability planning has increased the
creditability of their plans.
ACKNOWLEDGEMENTS
Authors would like to express sincere gratitude to
Dr. D. Walsh for his innovative leadership.
REFERENCES
CSE, (2005). Threat and Risk Assessment Working Guide,
viewed January 2007, <http://www.cse-
cst.gc.ca/publications/gov-pubs/itsg/itsg04-e.html>.
McGraw, Gary (2006a). Software Security: Building
Security In, Addison–Wesley, New York.
McGraw, Gary (2006b). Architectural Risk Analysis,
Viewed November 2007, <http://www.devsource.com/
article2/0,1895,1928687,00.asp>.
IBM (2003). Risk reduction with the RUP phase plan,
Viewed November 2007, <http://www.ibm.com/
developerworks/rational/library/1826.html>.
HP (2007). Planning for Disaster: Assessing Risks to Your
Business Data, Viewed November 2007,
<http://www.score.org/pdf/HP_Download_Planningfo
rDisaster.pdf>.
Kotonya, Gerald, & Rashid, Awais (2001). A Strategy for
Managing Risk in Component–based Software
Development. Proceedings of the 27th EUROMICRO
Conference 2001: A Net Odyssey (EUROMICRO’01),
pp. 12-22.
NASA (2003). XML Business Case, Robert Benedict,
NASA, Washington.
NASA (2004). NASA Activities in Risk Assessment,
Project Management Conference 2004, Michael G.
Stamatelatos, NASA, Washington.
Houmb, S.H., Georg, G., France, R., Bieman, J., Jurjens, J.
(2005). Cost-benefit trade-off analysis using BBN for
aspect-oriented risk-driven development. Proceedings
of the 10th IEEE International Conference on
Engineering of Complex Computer Systems, pp. 195-
204.
Williams, Ray, Ambrose, Kate, Bentrem, Laura,
Merendino, Tom (2004). Risk Based Diagnostics,
Carnegie Mellon Software Engineering Institute for
the Department of Defense, Pittsburgh.
Choudhary, A. Rahim, (2005). A Policy Based
Architecture for NSA RAdAC Model. Proceedings of
the 6
th
IEEE IA Workshop, pp. 10.
Wikipedia (2007). Social Network, Viewed November 2007,
http://en.wikipedia.org/wiki/Social_network_analysis.
The Bumble Bee (2006). Social Network Analysis: An
Introduction, Viewed November 2007,
<http://www.bioteams.com/2006/03/28/social_networ
k_analysis.html>.
Liemur (2005). Risk Based Software Development:
Reducing Risk and Increasing the Probability of
Project Success, Viewed November 2007,
<http://www.liemur.com/Articles/Risk_Based_Softwa
re_Development.html>.
Custers, B. H. M. (2007). Risk Profiling of Money
Laundering and Terrorism Funding - Practical
Problems of Current Information Strategies. ICEIS
2007 Conference Proceedings, pp. 90-94.
Gulías, Víctor M., Abalde, Carlos, Castro, Laura M.,
Varela, Carlos (2006). Formalisation of a Functional
Risk Management System. ICEIS 2006 Conference
Proceedings, pp. 516-519.
Misra, Subhas C., Kumar, Vinod, Kumar, Uma (2005).
Modeling Strategic Actor Relationships to Support
Risk Analysis and Control in Software Projects.
ICEIS 2005 Conference Proceedings, pp. 288-293.
Enström, David W., Walsh, D'Arcy, Hossendoust, Siavosh
(2007). A Reference Model for Enterprise Security -
High Assurance Enterprise Security. ICEIS 2007
Conference Proceedings, pp. 355-364
ICEIS 2008 - International Conference on Enterprise Information Systems
276

APPENDIX
Table 1: Risk Importance Ratings.
Business Effectiveness Effected Users Rating
Minor impact (e.g. short interruption)
Minor impact (less than 1% of users)
and
Minor exposure: Effects of vulnerability tightly contained. Does not increase the probability
of additional vulnerabilities being exploited.
1
Moderate impact (e.g. management
agreeable delays / interruption in services)
Moderate impact (deemed essential employees and management can continue their work)
and
Moderate exposure: Vulnerability can be expected to affect more then one system element
or component. Exploitation increases the probability of additional vulnerabilities being
exploited.
2
Important impact (denial of service beyond
agreeable delays, partners affected)
Important impact (essential employees and management are effected, plus partners)
and
Vulnerability affects a majority of system components. Exploitation significantly increases
the probability of additional vulnerabilities being exploited.
3
High impact (denial of service beyond
agreeable delays, clients affected)
High impact (essential employees and management are effected, plus clients)
and
Vulnerability affects a majority of client facing system components. Exploitation
significantly increases the probability of additional vulnerabilities being exploited.
4
Extreme impact (the future of the business
is at stake)
Extreme impact (all employees, clients and partners affected)
and
Vulnerability affects the viability of continued operations.
Exploitation significantly increases the probability of additional vulnerabilities being
exploited.
5
Table 2: Risk Probability Ratings.
Confidence in Users, Systems & Organizational Processes Vulnerability Level Rating
Confidence: High
High Confidence Indicators
User: Has extensive knowledge, skills and knowledge of the organization’s
processes, roles and responsibilities and infrastructure to use authorized
services, without causing damage to reputation or effectiveness of the business.
And
Capability: Build to specification and composed of matured components.
And
Organization: Both tested recovery and business continuity plans exist in the
organization to manage the risk impact and maintain business continuity.
Vulnerability: Low
Low Vulnerability Indicators
Evaluator: Has extensive domain knowledge and
expertise to perform accurate evaluation and provide
mitigation plan.
And
Capability: Evaluated to an appropriate level of
assurance, certified and deployed following industry
recommendations.
And
Environment: has suitable level of protection.
1
Confidence: High
High Confidence Indicators
User: Has extensive knowledge, skills and knowledge of the organization’s
processes, roles and responsibilities and infrastructure to use authorized
services, without causing damage to reputation or effectiveness of the business.
And
Capability: Build to specification and composed of matured components.
And
Organization: Both tested recovery and business continuity plans exist in the
organization to manage the risk impact and maintain business continuity.
Vulnerability: Medium
Medium Vulnerability Indicators
Evaluator: Has domain knowledge and expertise to
perform accurate evaluation and provide mitigation plan.
And
Capability: Evaluated to an appropriate level of
assurance, vulnerabilities mitigated and deployed
following industry recommendations.
And
Environment: has acceptable level of protection.
2
Confidence: High
High Confidence Indicators
User: Has extensive knowledge, skills and knowledge of the organization’s
processes, roles and responsibilities and infrastructure to use authorized
services, without causing damage to reputation or effectiveness of the business.
And
Capability: Build to specification and composed of matured components.
And
Organization: Both tested recovery and business continuity plans exist in the
organization to manage the risk impact and maintain business continuity.
Vulnerability: High
Medium Vulnerability Indicators
Evaluator: Has limited domain knowledge and expertise
to perform accurate evaluation and provide mitigation
plan.
And
Capability: Limited testing only, identified vulnerabilities
mitigated and deployed following industry
recommendations.
And
Environment: has low level of protection.
3
Confidence: Medium
Medium Confidence Indicators
User: Has adequate knowledge, skills and knowledge of the organization’s
processes, roles and responsibilities and infrastructure to use authorized
services, without causing damage to reputation or effectiveness of the business.
And
Capability: Build to specification and composed of tested components.
And
Organization: Recovery and business continuity plans to manage the risk
impact and maintain business continuity exist in the organization but not
tested.
Vulnerability: Low
Low Vulnerability Indicators
Evaluator: Has extensive domain knowledge and
expertise to perform accurate evaluation and provide
mitigation plan.
And
System: Evaluated to an appropriate level of assurance,
certified and deployed following industry
recommendations.
And
Environment: has suitable level of protection.
2
BUSINESS DRIVEN RISK ASSESSMENT - A Methodical Approach to Risk Assessment and Business Investment
277

Table 2: Risk Probability Ratings (cont.).
Table 3: Asset Value Ratings.
Business Impact Asset Context Rating
Affected asset not important to day–to–day activity No dependency between the affected asset(s) and other assets 1
Affected asset moderately important to business activity. Moderate dependency between the affected and other asset(s) 2
Affected asset important to day–to–day activity Important dependency between the affected and other asset(s) 3
Affected asset highly important to day–to–day activity High dependency between the affected asset(s) and other assets 4
Affected asset extremely important to business activity Extreme dependency between the affected and other asset(s) 5
Confidence in Users, Systems & Organizational Processes Vulnerability Level Rating
Confidence: Medium
Medium Confidence Indicators
User: Has adequate knowledge, skills and knowledge of the organization’s
processes, roles and responsibilities and infrastructure to use authorized
services, without causing damage to reputation or effectiveness of the business.
And
Capability: Build to specification and composed of tested components.
And
Organization: Recovery and business continuity plans to manage the risk
impact and maintain business continuity exist in the organization but not
tested.
Vulnerability: Medium
Medium Vulnerability Indicators
Evaluator: Has domain knowledge and expertise to
perform relatively accurate evaluation and provide
mitigation plan.
And
System: Evaluated to an appropriate level of assurance,
vulnerabilities mitigated and deployed following industry
recommendations.
And
Environment: has acceptable level of protection.
3
Confidence: Medium
Medium Confidence Indicators
User: Has adequate knowledge, skills and knowledge of the organization’s
processes, roles and responsibilities and infrastructure to use authorized
services, without causing damage to reputation or effectiveness of the business.
And
Capability: Build to specification and composed of tested components.
Organization: Both recovery and business continuity plans to manage the risk
impact and maintain business continuity exist in the organization but not
tested.
Vulnerability: High
Medium Vulnerability Indicators
Evaluator: Has limited domain knowledge and expertise
to perform accurate evaluation and provide mitigation
plan.
And
System: Limited testing only, identified vulnerabilities
mitigated and deployed following industry
recommendations.
And
Environment: has low level of protection.
4
Confidence: Low
Low Confidence Indicators
User: Has limited knowledge, skills and knowledge of the organization’s
processes, roles and responsibilities and infrastructure to use authorized
services, and may cause damage to reputation or effectiveness of the business.
And
Capability: Build as you go with limited testing.
And
Organization: Both recovery and business continuity plans to manage the risk
impact and maintain business continuity do not exist in the organization.
Vulnerability: Low
Low Vulnerability Indicators
Evaluator: Has extensive domain knowledge and
expertise to perform accurate evaluation and provide
mitigation plan.
And
System: Evaluated to an appropriate level of assurance,
certified and deployed following industry
recommendations.
And
Environment: has suitable level of protection.
3
Confidence: Low
Low Confidence Indicators
User: Has limited knowledge, skills and knowledge of the organization’s
processes, roles and responsibilities and infrastructure to use authorized
services, and may cause damage to reputation or effectiveness of the business.
And
Capability: Build as you go with limited testing.
And
Organization: Both recovery and business continuity plans to manage the risk
impact and maintain business continuity do not exist in the organization.
Vulnerability: Medium
Medium Vulnerability Indicators
Evaluator: Has domain knowledge and expertise to
perform relatively accurate evaluation and provide
mitigation plan.
And
System: Evaluated to an appropriate level of assurance,
vulnerabilities mitigated and deployed following industry
recommendations.
And
Environment: has acceptable level of protection.
4
Confidence: Low
Low Confidence Indicators
User: Has limited knowledge, skills and knowledge of the organization’s
processes, roles and responsibilities and infrastructure to use authorized
services, and may cause damage to reputation or effectiveness of the business.
And
Capability: Build as you go with limited testing.
And
Organization: Both recovery and business continuity plans to manage the risk
impact and maintain business continuity do not exist in the organization.
Vulnerability: High
Medium Vulnerability Indicators
Evaluator: Has limited domain knowledge and expertise
to perform accurate evaluation and provide mitigation
plan.
And
System: Limited testing only, identified vulnerabilities
mitigated and deployed following industry
recommendations.
And
Environment: has low level of protection.
5
ICEIS 2008 - International Conference on Enterprise Information Systems
278
