B2B AUTOMATIC TAXONOMY CONSTRUCTION

Ivan Bedini

Orang Labs, Caen, France

Benjamin Nguyen, Georges Gardarin

PRiSM Laboratory, University of Versailles, Versailles, France

Keywords: Semantic Web, Ontology Learning, B2B, XML Mining.

Abstract: The B2B domain has already been subject to several research experiences, but we believe that the real

advantage of introducing semantic technologies within enterprise application integration has not yet been

investigated fully. In this paper we provide a new use case for the next generation Semantic Web

applications with regards to enterprise application integration. We also present the results of our experience

in automatically generating a taxonomy from numerous B2B standards, constructed using Janus, a software

tool we have developed in order to extract semantic information from XML Schema corpora. The main

contribution of this paper is the presentation of the results of our tool.

1 INTRODUCTION

One of the most frequently asked questions during

exchanges with other colleagues is surely: “Why

introduce ontologies in the area of enterprise

applications integration and interoperability? What is

their contribution and what are the new benefits

compared to existing technologies?”

While current solutions work and enterprises are

able to exchange electronic information between

each other, several experiences show it is practically

impossible to connect two or more enterprise

applications on the fly. Even when two businesses

use standards claiming conformance to the same

base and same type of messages, business

integration remains difficult.

An example of this is shown by (Anicic, 2005),

where authors argue that the integration of two

applications, one based on the Standards in

Automotive Retail (STAR) and the second on the

Automotive Industry Action Group (AIAG), where

both of their native interfaces are based on the Open

Application Group (OAG) standard, requires the

construction of a supplementary external module to

connect them. Many other similar examples exist,

and form the motivation of this work.

The predominant view of application integration

is that it should be completely performed at design

time, i.e. when deciding on integration rules between

applications, rather than being performed at run

time, i.e. during the business exchange execution.

In this context, advantages of a Semantic Web

(SW) based approach for enterprise applications

integration has been widely recognised (Perez 1999),

(Fensel, 2001a), (Zhao, 2003a). But as clearly

presented by (Sabou, 2006) and (Motta, 2006), the

problem of the definition of a reference knowledge

as base to improve the ontology mapping still

remains.

In this context we consider this problem as

equivalent to enterprise applications integration.

The aim of this paper is not to resolve the whole

problem of business application integration, but to

analyse the problem and to present a solution to the

reference knowledge generation, starting from

existing XML B2B documents.

In Section 2 we present an analysis of the B2B

use case in the context of the Semantic Web and

show current approaches to business exchanges.

Section 3 presents Janus, the tool that we have

developed in order to retrieve semantic information

from existing XML Schema files and some results

obtained by the application of Janus on a collection

of 23 B2B XML based standards freely available on

the Web. In Section 4, we discuss related works and

Section 5 is a conclusion

325

Bedini I., Nguyen B. and Gardarin G. (2008).

B2B AUTOMATIC TAXONOMY CONSTRUCTION.

In Proceedings of the Tenth International Conference on Enterprise Information Systems - ISAS, pages 325-330

DOI: 10.5220/0001702903250330

 SciTePress

2 THE B2B USE CASE

In this section, we present a generic B2B use-case,

and advocate the use of ontologies to solve

integration problems.

2.1 Why we need Semantics?

The book by Gregor Hohpe (Hohpe, 2003) clearly

shows that there are many problems with application

integration. He provides an exhaustive list composed

of 65 patterns to be considered when building a

system able to manage the whole process of

application integration. In this paper we do not

address the whole process of integration, but we

focus on the content of messages exchanged

between enterprises in B2B applications.

B2B provides an interesting use case for

semantic applications because, by its nature, it

focuses on the problem of different designs and

ways of structuring the same set of concepts. Yet no

existing approach implements techniques based on

semantics. Currently, applications exchange

information on the basis of passing parameters or

data, formatted in XML according to strict, pre-

defined syntaxes and semantics. We define this

approach as the exactness method. This method has

the advantage of allowing good error management,

but leaves no space for data interpretation. In

consequence, reasoning on data of this type for

integration is virtually impossible, because of the

rigidity of data definitions.

2.2 Business Exchange Approaches

As far as we know, current approaches to message

content definition for electronic business exchanges

are mainly based on three types of solutions, which

are: Ad-hoc solution, where the format is defined

multilaterally during the design time phase of the

application; Proprietary solution where the format

is decided unilaterally (e.g., by a main contractor in

cooperation with small businesses, such as a big

retail group and its suppliers) and; Adoption of

standards where the format is defined by a

consortium in some standardization body.

As shown in the European e-business report (E-

Business W@tch, 2007), at least three enterprises

out of four that realize business exchanges with

partners, declare implementing applications based

on B2B standards solutions (at least in Europe).

Moreover, the authors of this report also state that

the broad adoption of XML based standards in

combination with web services, could become the

key to shape electronic business transactions

between enterprises in the future.

2.3 The Canonical Data Model

Gregor Hohpe (Hohpe, 2003) suggests building a

Canonical data model in order to minimize

dependencies from different data formats, but he

does not explain how to build it. We suggest

adopting an ontology based approach when building

the canonical data model and using semantic web

technologies to improve application integration. This

approach is quite different from other experiences in

the e-business domain, such as (Corcho, 2001),

because it targets global message definition rather

than a thesaurus like eCl@ss or UNSPSC. A

message is not a well defined hierarchical set of

items, but meets a specific request. This practice

makes complex the matching of two messages, and

therefore application integration, because standards

can model them with different pieces of information.

Figure 1: Messages translation procedure.

In other words, we are not able to say

beforehand if the sending application ship messages

that correspond exactly to the receiver application

messages, in a one-to-one association. However, we

make the hypothesis that the sender application

manages some “concepts” that are similar to those of

the receiver application. We propose a procedure to

correlate these messages (see Figure 1), based on the

following steps: 1) detect what concepts the message

conveys; 2) match them with the canonical model;

3) find corresponding concepts in the target

application model; 4) chose the message mappings

that best fit the requirement and finally; 5) translate

the message. As we can see, the main problem is

building the canonical model. The difficulty is that

the classical development of a domain ontology,

typically entirely based on strong human

participation, does not adequately fit this use case,

because it needs a more dynamic and automatic

ontology building system, in order to be able to

ICEIS 2008 - International Conference on Enterprise Information Systems

326

integrate new business partners on the fly.

3 AUTOMATIC CONSTRUCTION

OF THE TAXONOMY

In this section we present Janus, a tool we have

developed that manages information extraction from

XML schema files. We also present the firsts results

obtained from the automatic construction of a B2B

taxonomy.

3.1 B2B Corpus Source

For this experience we have investigated more than

30 B2B standards, but not all are freely available

and require membership fees (these have not been

studied during the tests presented here).

Only cXML does not provide an XML Schema

(XSD) for messaging content definition, but instead

provides a DTD based standard. Moreover no

RDF/OWL format is officially provided by any

consortium. For this reason we decided to initially

consider only standards offering XSD files and to

focus our efforts on developing a tool of information

retrieval specifically for this format. XML Schema

simplifies the defininition of a structure for elements

(candidate concepts for the ontology) notably

limiting the difficulties of natural language

interpretation. However as we show below, these

documents introduce some noise at semantic level

that needs special attention in order to provide good

quality results. Almost all organizations provide a

package containing several XSD files, one for each

specific message, one for grouping common data,

others for grouping common data type definitions

and code lists. In the end we get a corpus source

composed of a collection of 23 standards (listed in

Table 1), with more than 2000 XSD files that has

been considered enough in order to have significant

information about B2B business message definition

practices and semantics. Others standards can be

added in future in an incremental way.

3.2 Janus: Taxonomy Builder Tool

Our tool implements an adaptation of several

techniques originating from the text mining and

information retrieval/extraction fields, applied to

XML files (that we call XML Mining), in order to

pre-process simple and compound terms from XML

tags. In reality our tool goes further in trying to build

a reference ontology, making the hypothesis that

each standard’s set of files provides enough

information to be considered an ontology itself.

Figure 2 shows the overall architecture of Janus.

Figure 2: Janus overall architecture.

Let us now detail the algorithm for term

extraction and automatic taxonomy construction

from XML tags:

Acquisition Step. The aim of this step is to organize

the corpus source and to select useful terms for the

taxonomy. The extraction tasks are: XSD Parsing

and extraction of XML tag values; composite words

detection (e.g.: on-line); detection of "useless" terms

previously identified, like systematic addition of

unrelated semantic sense to the tag (e.g.:

CommonData for UnitOfMeasureCommonData);

Splitting compound terms forming the tag, (e.g.:

PersonIDCode = person + id + code) and;

abbreviation transformation (e.g.: Addr = Address,

PO = Purchase Order).

As output to this step we produce a set of extracted

tags for each family in the form:

Term

_..._Term

(ex.:

ABIEPostalAddressType that becomes

ABIE_Postal_Address)

Normalisation Step. This step detects those terms

that are not useful for the taxonomy and provides the

lemmatization of accepted terms. Tasks for this step

are: Case normalisation, all terms are converted to

lower case; Stop-word normalisation, removes

words like “of”, “a”, “for”,…; Bad words detection,

terms unknown by the dictionary are cast aside and;

Morphological and semantic normalisation, which

consists in finding the stem and lemma form.

Build Taxonomy Step. The aim of this step is to

create a first level of semantic relationships and

hierarchy between words of the taxonomy.

For this tags are recomposed using their lemma in

order to be able to detect similarities between tags

(thus between concepts of the ontology that we are

building). In second stage, seeing that tags are

usually composed by more than one word, a graph

B2B AUTOMATIC TAXONOMY CONSTRUCTION

327

based on Galois lattice is built to relate those tags

having the same words (ex. address and

postal_address); we calculate the Term Frequency

of graph nodes and; we remove the nodes that are

insignificant (values below a threshold). As last

synonyms are checked and added to the lattice (just

applied to words belonging to the taxonomy itself).

Filtering Step. In this step we analyse the words

rejected by a first pass and we try to detect false

semantics present within a tag. The first task is the

Bad words “reconciliation”, where we try to detect

as many abbreviations as possible applying a

modified version of the N-Gram algorithm and

Levenstain distance. We look for abbreviations of

terms already present within the taxonomy and not

in a dictionary, because we would detect too many

similar terms, most of them out of context. A second

task tries to detect "useless words". Using the lattice

we automatically detect those words that present

disproportionate relationships between graph nodes

(like Type or CommonData), and therefore do not

convey any semantics in reality. Finally new terms

are integrated.

Build Views Step. At this point, we have

implemented some visualization methods to view

our taxonomy. We have implemented the following

views: as list, as tags lattice (with synonyms

relationships) and as tag cloud. Others, like “Social

Network of Word”, are under development.

3.3 Results

Table 1 resumes the collection of B2B standards and

some information about their declared relationships

with other organizations. This table also resumes for

each standard body the following information:

number of XSD files that they provide (or in some

cases, just the files that we have considered), the

total number of complex type and element tags, the

resulting number of “semantically” different words

and; since XML tags can be composed of real

dictionary words, mere abbreviations, or simply any

sequence of characters, the last column provides the

number of words unrecognised by the system.

This table shows several aspects regarding

current B2B business standards. On one hand they

highlight some XML schema definition practices by

standardization bodies, such as the use of

anonymous types for elements, rather than declared

types; the adoption of Upper Camel Case or hyphen

for tags to separate compound words (which is what

we implement); the trend that financial and related

bodies often use abbreviations rather than real terms

for tags whereas standardization bodies mainly use

common words for tags. Therefore it is possible to

define a common taxonomy for the B2B domain. In

fact, as shown in Figure 3, by adding one standard at

a time, even in a random order, we have observed

that after half a dozen of additions, less than 20% of

words are really new, and reach only 9% of new

words in the last standard added. We have noted that

these words usually represent terms characterizing

the standard, but that the other, more general terms

are already present in the global dictionary. Also we

have observed that 60% of the words are shared

between standards, 11% of the words are used by

more than 10 of them and that this trend increases if

measured over tags. So it shows that a dynamic

taxonomy like this evolves easily and that a shared

vocabulary emerges naturally.

We obtain 70976 tags, of which after

normalization about 20000 are distinct. The total

number of different words composing them is only

2887. On average, standards share three words over

four. For example, PostalAddress is a tag, composed

of 2 words. PostalAddressTown is a tag composed of

3 words. A standard composed of these two tags

(normalized elements) would have 5 words, of

which 3 are different (Postal, Address and Town). A

tag called PostAddrTwn would be the same

normalized element as PostalAddressTown.

3.4 Special Concern for “Bad Words”

A considerable number of unrecognised words still

remain (see Table 1), at least at first sight.

The analysis shows that these bad words are of

the following type: mostly abbreviations (about

50%); about 30% are compound words not split by

the system (for example compound words not

written in UCC form like worktime); about 10% are

words not included in the dictionary; and another

10% are acronyms.

Several techniques can be implemented in order

to improve the detection of hidden words. Our

implementation of abbreviation discovery is able to

detect more than 70% of them automatically, which

in reality corresponds to 80% of total occurrences

(for example amt => amount has 958 occurrences

thus more important than wvg=> waiving with just

one occurrence). Improving these results means (a)

adopting a more complex management of

abbreviations in order to detect different words

having the same abbreviation, (b) implementing

NLP techniques in order to mine text documents that

often come with XML files and; (c) improving the

external dictionary’s capabilities.

ICEIS 2008 - International Conference on Enterprise Information Systems

328

Terms Addition Percentage

,22

,21

11,57

35,90

0,2

8,3

3,13

3,5

,83

21,08

5,6

7,1

8,3

12,65

9,26

100,00

Figure 3: Graph of sequential of terms addition (measures

are in percentage).

Therefore solutions that provide good precision

and recall exist, but in order to fully exploit the

potential of semantic technologies, source document

should be somehow semantically well formed. No

semantic application will be able to understand the

sense behind tags such as AmortMktValDiffPct or

setr.100.101.

Another improvement in this direction should be

to exploit the structural content of XML files. Rather

than using tag name with abbreviations for

indicating structural relations like PostAddrTwn (11

chars) using simply Town (4 chars) as sub-element

of PostalAddress should be enough for a machine to

understand that town is a propriety of the address

concept. A positive side effect is the economy of

physical space.

4 RELATED WORK

Our work is related to several research domains. For

work closer to B2B we can cite an interesting

experience by Zaho and Lövdahl (Zaho 2003b), that

provides an approach to develop ontology for

Internet commerce by reusing XML-based

standards. They also define layers and relationships

of the common vocabulary as shared in the

following parts: Core, General, Reusable and

Special. But they do not go any further and do not

provide concretely a taxonomy. Gloria Giraldo and

Chantal Reynaud (Giraldo, 2002) have developed a

semi-automatic ontology generation software for the

tourism industry domain extracting information

contained in DTD files. This experiment is really

close to our use case but is limited to the sole

domain of tourism, which is defined in advance with

great precision, and therefore the detection of

relevant concepts does not produce conflicts

between different representations.

Other experiences that try to mix semantic

integration and B2B thesaurus were developed by

(Fensel, 2001b) and (Corcho, 2001), but their work

was limited to catalogues of products like UNSPSC

and eCl@ss, which have hierarchy and semantics

well defined. In practice, the goal is the mapping of

two thesaurus rather than the construction of an

ontology. For more related semantic integration the

document by Noy (Noy, 2004) provides an

exhaustive list of experiences where our tool should

be effective similar in terms of construction

techniques, but they mainly target the merging of

two input sources at a time. Concerning the

automation process of taxonomy and ontology

generation in (Bedini, 2007) is shown that solutions

implementing an automatic method for such a task

are rare. We do not have the room to detail this here.

Finally, for the construction of reference

ontologies, the experience of D’Aquin et al.

(D’Aquin, 2007) is significant for our work, but they

do not consider XML Schema sources.

5 CONCLUSIONS AND FUTURE

WORK

In this paper we have presented our starting point for

building B2B applications in agreement with the

“Next Generation Semantic Web Applications" as

described in (Motta, 2006).

Despite the great amount of XML files available,

current tools and software are only able to extract

semantics from text corpora, or ontologies: tools

providing the analysis of a consistent group of XML

files are rare, and none really exist in the B2B

domain. We have therefore developed Janus, a tool

capable of extracting valuable semantic information

from such corpora and have demonstrated its results

with the automatic construction of a B2B taxonomy.

Although these results are encouraging, it is clear

that our system does not yet offer enough to build a

canonical data model for the B2B use case, nor does

it reduce application integration to an automatic

task. We plan on continuing this work with the

development of a more complete tool, capable to

associate semantic concepts to discovered

taxonomy's terms in order to build as automatically

as possible a reference ontology for the B2B

domain.

B2B AUTOMATIC TAXONOMY CONSTRUCTION

329

REFERENCES

Anicic, N., Ivezic, N., Jones A., 2005. An Architecture for

Semantic Enterprise Application Integration

Standards. In proceedings of INTEROP-ESA 05,

Geneva, Switzerland.

Bedini, I., Nguyen, B., 2007. Automatic Ontology

Generation: State of the Art. Technical report,

University of Versailles. (http://bivan.pagespro-

orange.fr/Janus/index.html)

Charlet, J., Bachimont, B., Troncy, R., 2004. Ontologies

pour le Web sémantique. In Revue I3, numéro Hors

Série «Web sémantique», 2004.

Corcho, O., Gomez-Perez, A., 2001. Solving integration

problems of e-commerce standards and initiatives

through ontological mappings. In Proceedings of the

Workshop on e-business and Intelligent Web, 2001.

D'Aquin, M., Baldassarre, C., Gridinoc, L., Angeletou, S.,

Sabou, M., Motta, E., 2007. Watson: A Gateway for

Next Generation Semantic Web Applications.

International Semantic Web Conference, ISWC 2007.

E-Business W@tch observatory, 2007. The European e-

Business Report, 2006/07 edition. 5th Synthesis

Report of the e-Business W@tch, on behalf of the

European Commission's January 2007.

(http://www.ebusiness-watch.org)

Fensel, D., 2001a. Ontologies: Silver bullet for knowledge

management and electronic commerce. Springer-

Verlag, Berlin.

Fensel, D., Ding, Y., Omelayenko, B., Schulten, E.,

Botquin, G., Brown, M., Flett, A., 2001b. Product

Data Integration in B2B E-Commerce. IEEE

Intelligent Systems, vol. 16, 2001, pp. 54-59.

Giraldo, G., Reynaud, C., 2002. Construction semi-

automatique d'ontologies à partir de DTDs relatives à

un même domaine. 13èmes journées francophones

d'Ingénierie des Connaissances, Rouen.

Gomez-Perez, A., Benjamins, V., 1999. Overview of

Knowledge Sharing and Reuse Components:

Ontologies and Problem-Solving Methods. IJCAI-

1999, Workshop on Ontologies and Problem-Solving

Methods.

Hohpe, G., Woolf, B., 2003. Enterprise Integration

Patterns: Designing, Building, and Deploying

Messaging Solutions. Addison-Wesley, October 2003

Motta, E., Sabou, M., 2006. Next Generation Semantic

Web Applications. In Proc. of the 1st Asian Semantic

Web Conference (ASWC), Beijing, China 2006.

Noy, N., 2004. Semantic integration: a survey of ontology-

based approaches. SIGMOD Record, Vol. 33, No. 4,

December 2004.

Sabou, M., D’Aquin, M., Motta E. (2006) Using the

Semantic Web as Background Knowledge for

Ontology Mapping. In Proc. of the International

Workshop on Ontology Matching, collocated with

ISWC'06.

Welty, C., 2003. Ontology Research. AI Magazine, 24(3).

Zhao, Y., Sandahl, K., 2003a. Potential Advantages of

Semantic Web for Internet Commerce. Proceedings of

International Conference on Enterprise Information

Systems (ICEIS), .Angers, France, April 2003.

Zhao, Y., Lövdahl, J., 2003b. A Reuse-Based Method of

Developing the Ontology for E-Procurement. Proc

Second Nordic Conference on Web Services, 2003.

Table 1: Presentation of involved B2B standard and of the correspondent extraction of XML semantics.

Standard

Body

Business Area Alliances Files Tags

Dictionary

words

Unknown

words

ACORD

Insurance, reinsurance and related financial service X12, XBRL, HR-XML 8 5263 1162 657

AdsML

graphics communication 14 737 301 10

AgXML

Agriculture supply chain ebXML, CIDX, RAPID 11 808 216 4

ARTS

Retail 44 5853 734 44

CIDX

Chemical ebXML, RAPID 61 1881 437 20

ebXML

Cross industry 74 1401 408 10

ebInterface

Invoice 1 105 66 6

ETSO

Specific electric transaction ebXML 1 27 32 0

FIX

Banks, broker-dealers, exchanges and institutional investors SWIFT (ISO 20022), FpML 18 552 117 93

FpML

Financial FIX, FIXML 21 2124 544 34

GS1

Supply chain for Healthcare, Defence, Transport & Logistics ebXML 289 2360 216 8

HR-XML

Human Resource ACORD 166 12717 949 71

IFX

Financial 310 4256 446 249

ISO20022

Financial IFX, OAGIS, TWIST 74 11082 256 384

MISMO

Residential, commercial, eMortgage IFX, ACORD, ASC X12 14 1432 252 26

OAGIS

Cross industry ebXML 515 4584 704 170

OTA

Tourist 233 3649 552 67

PapiNet

Paper 42 1394 530 18

PIDX

Petroleum ebXML, CIDX 26 745 341 9

STAR

Automotive retail OAGIS, ebXML 181 5518 1130 88

TWIST

Supply chain, payment FpML, FIX, SWIFT 18 2489 457 184

UBL

Invoicing, ordering ebXML 11 650 274 10

X12

Cross industry 9 1349 271 23

Sum*: 2141 70976 10395 2185

* This sum value does not consider eventual correspondence of common tags or words between different bodies

ICEIS 2008 - International Conference on Enterprise Information Systems

330
