A FRAMEWORK FOR DATA CLEANING IN DATA

WAREHOUSES

Taoxin Peng

School of Computing, Napier University, 10 Colinton Road, Edinburgh, EH10 5DT, U.K.

Keywords: Data Cleaning, Data Quality, Data Integration, Data Warehousing.

Abstract: It is a persistent challenge to achieve a high quality of data in data warehouses. Data cleaning is a crucial

task for such a challenge. To deal with this challenge, a set of methods and tools has been developed.

However, there are still at least two questions needed to be answered: How to improve the efficiency while

performing data cleaning? How to improve the degree of automation when performing data cleaning? This

paper challenges these two questions by presenting a novel framework, which provides an approach to

managing data cleaning in data warehouses by focusing on the use of data quality dimensions, and

decoupling a cleaning process into several sub-processes. Initial test run of the processes in the framework

demonstrates that the approach presented is efficient and scalable for data cleaning in data warehouses.

1 INTRODUCTION

The popularity of data warehouses (DWs) in recent

years confirms the importance of data quality in

today’s business success. There are many reasons

for a data warehouse project to fail. One of them is

the poor data quality. It is estimated that as high as

75% of the effort spent on building a data warehouse

can be attributed to back-end issues, such as

readying the data and transporting it into the data

warehouse. Data cleansing will absorb nearly half of

that time (Atre, 1998). To overcome this problem,

there are at least two questions needed to be

answered: How to improve the efficiency when

performing data cleaning? How to improve the

degree of automation when performing data

cleaning?

In past decade, many researchers have

challenged the problems raised regarding the quality

of data since data warehousing techniques became

important in decision support information systems.

Topics range from data cleaning methods and

approaches (Galhardas et al, 2001, Hipp, Guntzer

and Grimmer, 2001, Liu, Shah and Jiang, 2004,

Raman and Hellerstein, 2001, Sung, Li and Sun,

2002, Winkler, 2003) to quality-oriented data

warehouse design (Jarke et al, 1999, Mecella et al,

2003). Generally speaking, data cleaning deals with

detecting and correcting errors and inconsistencies

from data. There are several reasons for databases to

have data quality problems, which include typos

during data entry, missing values, uncertainty,

inconsistency etc., especially when multiple data

sources need to be integrated, e.g., in data

warehouses. Halevy et al recently outlined some

future challenges to data integration research in

(Halevy, Rajaraman and Ordille, 2006), where they

claimed that “data integration has been referred to as

a problem as hard as Artificial Intelligence, maybe

even harder!”. To overcome data quality problems, a

variety of methods has been developed. However,

few efforts have been dedicated to frameworks for

making data cleaning more efficient, leaving the

above two questions still open.

This paper investigates current data cleaning

methods, approaches, and data quality oriented data

warehousing design mechanisms, and then challenge

above two questions by presenting a novel

framework, which provides an approach to

managing data cleaning in data warehouses by

focusing on integrating data quality factors into

mechanisms of processing data cleaning, and

decoupling the cleaning process into several sub-

processes. The rest of this paper is structured as

follows. Basic concepts of data quality, methods of

data cleaning and special data quality issues in data

warehouses are introduced in next section. The main

contribution of this paper is presented in section 3

that describes a novel framework for dealing with

data quality in data warehouses. An example for

illustrating the proposed framework is shown in

473

Peng T. (2008).

A FRAMEWORK FOR DATA CLEANING IN DATA WAREHOUSES.

In Proceedings of the Tenth International Conference on Enterprise Information Systems - DISI, pages 473-478

DOI: 10.5220/0001706004730478

 SciTePress

section 4. Finally, this paper is concluded and future

work pointed out in section 5.

2 DATA QUALITY AND DATA

CLEANING

2.1 Data Quality

There is a variety of definitions for data quality.

From literature, data quality can be defined as

“fitness for use”, i.e., the ability of data to meet

user’s requirement. The nature of this definition

directly implies that the concept of data quality is

relative.

Data quality is a multi-dimensional concept and

each of its dimensions is specifically related to a

particular aspect of data such as data views, data

values, and data representation. It is often

represented as a set of quality dimensions (Wang,

Storey and Firth, 1995), which can be refined as:

 Accuracy – conformity of the recorded value

with the actual value;

 Timeliness – the recorded value is not out of

date;

 Completeness – all values for a certain variable

are recorded;

 Consistency – the representation of data is

uniform in all cases.

Recall the second question raised in

Introduction: How to improve the automation when

perform data cleaning? Two of the dimensions

discussed above will be concerned: timeliness and

consistency. Temporal information represents

change. Data in a database is static, but the real

world keeps changing. In general, the temporal

dimension plays an important role in ensuring high

quality of data. Whether the representation of data is

consistent or not is another concern. For instant, to

represent a property’s (flat) address, there are three

options: 10/3, 2F1 10 or Flat 3 10. All these three

representations share the same address: the third flat

at property number 10. If a customer uses version

2F1 10 to register in a bank, it is very likely that this

customer will be treated as two different customers

when the customer uses 10/3 to check his/her credit.

This is a popular example for inconsistency. In

section 4, an example is used to show a way of using

such data quality dimensions in the proposed

framework.

2.2 Data Cleaning

Data cleaning is required whenever there is any level

of doubt existing. The aim of data cleaning is to

detect, correct errors and inconsistencies from data.

It is proved to be a difficult but unavoidable task for

any information system. Several researches have

been done to investigate, examine problems,

methods, and approaches to data cleaning (Muller

and Freytag, 2003, Rahm and Do, 2000).

Ideally, the processes of detecting, correcting

should be performed automatically. However, it is

known that fully automatically performing data

cleaning is nearly impossible in most of cases.

Therefore, declarative, semi-automatic approaches

are feasible and acceptable for developing data

cleaning tools. To actually perform data cleaning,

for each type of data errors, an appropriate data

cleaning method (approach) need to be selected and

then applied. Choosing such a method is proved to

be a difficult task (Luebbers, Grimmer and Jarke,

2003). It depends on several factors, such as the

problem domain, the nature of errors, etc. If there is

more than one method involved, how to apply them,

i.e., in which order makes difference. To develop an

effective data cleaning tool, it is therefore necessary

to allow users to select appropriate methods for

specified domains. It should also provide a

mechanism to allow users to decide an appropriate

order in which the selected methods are performed.

These tasks need experienced technical and business

experts.

2.3 Special Issues

A DW is a repository storing integrated data for

efficient querying and analysis. It needs a set of

tools for extracting data from multiple operational

data sources, for cleaning, transforming and

integrating the data; for loading data into the data

warehouse; and for regularly updating the

warehouse. This is called ETL process (Extraction,

Transformation, Loading). During this process, data

cleaning is typically performed in a separate data

area, called Cleaning Staging Area (CSA). The

resulting cleaned, standardised and integrated data

are loaded as materialised views into the data

warehouse.

Considering that the purpose of data

warehousing is supporting decision making, the

quality of data in a data warehouse is vital. Since the

volume of data from multi sources is huge, and the

data format might be different from one source to

another, there is a high probability of errors

ICEIS 2008 - International Conference on Enterprise Information Systems

474

presenting in data while doing the unavoidable data

integration.

In recent years, several research contributions

have tackled the Data Warehouse Quality (DWQ)

problem (Jarke et al, 1999, Mecella et al, 2003).

Data quality issues discussed in these contributions

are mainly focused on data warehouse quality

design. However, issues on managing data cleaning,

integrating data efficiently are not addressed.

Since performing data cleaning in very large

databases, especially in data warehouses is costly

and time consuming, it is necessary to employ

techniques or approaches to, on one hand, reduce

cleaning time, and on the other hand, maximise the

degree of automation. The experiment done by

Galhards et al (2001) shows that the time used for

executing algorithms on a relatively large set of data

is significantly long. This case will be normal if the

data cleaning is for a data warehouse.

3 A FRAMEWORK

3.1 Some Definitions

Data errors are usually classified into several types.

Muller and Freytag (2003) classify errors into three

groups: syntactical, semantic and coverage. Each

group includes a set of error types which have

similar characteristics. In order to illustrate the

proposed framework and the following examples

explicitly, only two error types are discussed here:

outliers and duplicates:

 Outliers – are observations that are

unexpectedly different from the majority in

the sample;

 Duplicates – are two or more tuples

representing the same entity.

To separate errors particularly relevant to single-

source and multi-source databases respectively, the

following definitions are needed:

 Single-source Errors. An error of this type is

present in single source databases, such as

misspelling, invalid, out of dated, outliers,

etc.;

 Multi-source Errors. An error of this type is

present when data from more than one data

source is integrated, such as inconsistent data,

duplicates, etc.

Also from the computational point of view, the

following two definitions are made:

 Computational-costly Errors. an error of this

type costs time significantly when detecting it,

such as duplicates. Computational-costly is a

relative measure. In practice, this

measurement should be determined by the

user;

 Non-computational-Costly Errors. An error

of this type is an opposite of the

computational-costly errors, such as out of

date data, outliers.

Furthermore, from the execution point of view,

the following two definitions can be defined:

 Automatic-removable Errors. An error of this

type can be detected, then removed/corrected

without any human interruption;

 Non-automatic-Removable Errors. an error

of this type can’t be detected then

removed/corrected without any human

interruption.

3.2 The Framework

Briefly, the strategy is to break the whole data

cleaning process into two stages. At the first stage,

single-source errors are dealt with. At the second

stage, multi-source errors are treated. At each stage,

the process is further divided into two sub-processes.

One deals with Automatic-removable errors, while

the other deals with Non-automatic-removable

errors. This strategy is more important at the second

stage because it is believed that more complicated

errors that are difficult to deal with in a fully

automatic way present at this stage, such as

inconsistencies, duplicates, etc. The proposed

framework includes the following components:

1) Auto-dealing Process for Single-source

Errors. For each data source, tasks include:

a) Identify (not detect) all Single-source

and Automatic-removable errors by the

user;

b) Select appropriate algorithms, which

can be used for detecting, then

removing/correcting errors identified in

a) automatically;

c) Decide an order in which the

algorithms are applied, based on error

types involved;

d) Execute the algorithms in the order

decided in c);

2) Semi-auto-dealing Process for Single-source

Errors. For each data source, tasks include:

a) Identify (not detect) all Single-source

and Non-automatic-removable errors

by the user;

A FRAMEWORK FOR DATA CLEANING IN DATA WAREHOUSES

475

b) Select appropriate algorithms, which

can be used for detecting errors

identified in a);

c) Decide an order in which the

algorithms are applied, based on error

types involved;

d) Execute the algorithms in the order

decided in c);

e) Correct/remove detected errors;

3) Auto-dealing Process for Multi-source

Errors. Tasks include

a) identify (not detect) all multi-source

and Automatic-removable errors by the

user;

b) Select appropriate algorithms, which

can be used for detecting, then

removing/correcting errors identified in

a) automatically;

c) Decide an order in which the

algorithms are applied, based on error

types involved;

d) Execute the algorithms in the order

decided in c);

4) Semi-auto-dealing Process for Multi-source

Errors. Tasks include

a) Identify (not detect) all Multi-source

and Non-automatic-removable errors

by the user;

b) Select appropriate algorithms, which

can be used for detecting errors

identified in a);

c) Decide an order in which the

algorithms are applied, based on error

types involved;

d) Execute the algorithms in the order

decided in c);

e) Correct/remove detected errors;

5) Transformation Process. Tasks include

a) Format data/schema;

b) Integrate data;

c) Aggregate data.

This framework can be further outlined as

follows (see Figure 1): There are two main stages:

one deals with single-source errors; the other deals

with multi-source errors. At each stage, there are

two sub-processes, auto-dealing process and semi-

auto-dealing process. First data is dealt with

individually, cleaning data in source databases one

by one. At this stage, domain knowledge is used to

help to identify possible single-source data errors

presenting in each database. These errors are further

classified into two groups, automatic removable

errors and non-automatic-removable errors.

Automatic-removable errors are considered first in

the auto dealing process. These errors are detected

and removed/corrected by use of appropriate

algorithms, which are performed sequentially in a

specified order. Basically, algorithms dealing with

non-computational-costly errors are put at the front

in the order. This strategy aims to minimise the

processing time. It also ensures that when it’s time

to perform computational-costly errors, such as

duplicates, the data volume should be significantly

reduced. Hence, the processing time needed is

reduced. In auto-dealing process, errors should be

detected and removed/corrected automatically,

without any interruption. Several factors may play a

role in identifying such errors. Temporal factor is

one of them.

After the auto-dealing process, a semi-auto-

dealing process is performed. Again, possible errors

need to be identified, then appropriate algorithms are

selected together with a decision of an order in

which the selected algorithms are performed.

Similarly, the strategy of dealing with non-

computational errors first applies.

As a result of this stage, the data volume is

supposed to be reduced significantly.

At the second state, dealing with multi-source

errors, again, auto-dealing process is performed first.

Both domain and technical knowledge are needed

for identifying multi-source errors. The rest is

similar to the processes at stage one. Rules,

strategies for selecting algorithms, deciding orders

are needed. After the above two stages, the data left

in the CSA should be cleaned and ready for

transformation. The transformation process deals

with data/schema format, data integration and data

aggregation. At this stage, if it is necessary, the

Semi-Auto-Dealing process or Auto-Dealing process

will be triggered again. At the end, the data should

be ready for loading to the DW.

There are three core characteristics in this

framework. The first is the identification of data

error types based on different purposes, such as

time saving, automatic processing etc. There is no

generic approach to do this at present. Developing

such approaches remains our future work. The

ICEIS 2008 - International Conference on Enterprise Information Systems

476

Source DB

……

Single-Source Process

Auto

Dealing

Process

Multi-Source Process

Trans-

forma-

tion

Data

Warehouse

Semi-

auto

Dealing

Process

Auto

Dealing

Process

Semi-

Auto

Dealing

Process

Source DB

Figure 1: The cleaning process.

second core characteristic is the decision of an order

for executing a set of selected algorithms. The third

one is the decoupling of the data cleaning process

into two processes, based on the ability of

performing automatic process. These two processes

will be performed at two different stages, based on

single or multi data sources. The objective of this

approach is to answer the two questions raised in

Introduction: How to improve the efficiency when

performing data cleaning? How to improve the level

of automation when performing data cleaning?

4 AN EXAMPLE

To illustrate the basic idea, the framework has been

prototyped and applied to some artificially designed

databases, which have some of the data quality

dimensions embedded. This section presents a

simple example to show the efficiency of the

proposed framework.

In UK, National Health Services (NHS) is a

nation wide organisation, which provides health

services to all residents. To simplify the description,

suppose every city has a single database. The DW

needs information from all cities. The scenario for

this example is as follows. University students may

move to other cities after they graduate. They

universities are located. After they graduate and find

a job or a further study position in another city

(CityB), it is likely that they register a doctor again

in CityB, without informing their doctors in CityA.

Table 1 (CityA_Patient) and Table 2 (CityB_Patient)

show the samples of data in each of the two cities,

where VST stands for valid start time, and VET for

valid end time.

These two tables include some duplicates. As

described in the proposed framework, some

particular data quality factors are needed for this

purpose. In this example, the temporal factor is

identified as a data quality factor, which can be used

to make the decision whether a possible duplicate is

genuine or not. Therefore, an automatic process can

be formed. By using values of attributes VST and

VET, we are able to make such decisions.

It is important to notice that the use of data

quality factors plays a crucial role in this framework.

It helps to set rules for removals. Such factors can

only be identified by business domain experts. In

this example, the rule for the confirmation of

duplicates is described as follows. For each pair (two

tuples) of a possible duplicate, if the value of

attribute Post in one of the tables is Student, suppose

in table 1, and value of attribute VST in table 2 is

about 4 years later than the VST value in table 1, a

duplicate is confirmed.

Given the data quality factor, time, the rules, and

the two tables, as the result of running the Auto-

Dealing process, tuples 1, 2 and 4 are removed from

table 1 because of duplication.

Although this is a simple example, the result

shows that with the use of proper quality factors

some of the detecting and removing tasks can be

done as one unified process.

5 CONCLUSIONS AND FUTURE

WORK

This paper has investigated current data cleaning

methods, approaches and data quality oriented data

warehousing design and implementation

mechanisms. Based on this investigation, a novel

framework has been proposed, which aims to

challenge two issues: minimising the data cleaning

time and improving the degree of automation in data

cleaning. These two issues are closely relevant to the

two questions raised in the introduction. The

minimisation and improvement are achieved by

introducing a mechanism of using

A FRAMEWORK FOR DATA CLEANING IN DATA WAREHOUSES

477

Table 1: CityA_Patient.

No. L. Name F. Name Age Address Post VST VET

1 Cole Liam 23 City A Student 28-09-2003 Now

2 Gerrard John 25 City A Student 02-10-2001 Now

3 Small Helen 23 City A Student 26-09-2002 Now

4 Smith William 24 City A Student 01-10-2001 Now

5 Smith Mary 28 City A Student 12-10-2001 10-09-2005

Table 2: CityB_Patient.

No. L. Name F. Name Age Address Post VST VET

1 Cole Liam 23 City B Engineer 20-08-2007 Now

2 Gerrard John 25 City B Engineer 18-09-2005 Now

3 Small Helen 23 City B Student 28-09-2003 Now

4 Smith William 24 City B Student 08-10-2005 Now

5 Smith Kirsty 30 City B Engineer 10-10-2005 Now

data quality dimensions and decoupling the data

cleaning process into two sub-processes, base d on

different purposes. This framework retains the most

appealing characteristics of existing data cleaning

approaches, and enjoys being able to improve the

efficiency of data cleaning in data warehouse

applications.

The work introduces a number of further

investigations, including: a) to examine further

characteristics of data quality dimensions, in order to

develop a detailed guidance for determining the

choice of a particular strategy for data cleaning in

data warehouses; b) to develop a comprehensive

data cleaning tool for data warehouses based on the

framework proposed in this paper; and c) to test the

framework by applying it onto bigger multi data

sources. The successful outcome of such future work

would certainly enhance the performance of data

cleaning systems in data warehouses.

REFERENCES

Atre, S., 1998. Rules for data cleansing. Computerworld.

Galhardas, H., Florescu, D., Shasha, D., 2001.

Declaratively Data Cleaning: Language, Model, and

Algorithms. In Proceedings of the 27

International

Conference on Very Large Databases (VLDB), Roma,

Italy.

Halevy, A., Rajaraman, A., Ordille, J., 2006. Data

Integration: The Teenage Years. In the 32

International Conference on Very Large Databases.

Seoul, Korea.

Hipp, J., Guntzer, U., Grimmer, U., 2001. Data Quality

Mining. In the 6

ACM SIGMOD Workshop on

Research Issues in Data Mining and Knowledge

Discovery.

Jarke, M. M., Jeusfeld, A., Quix, C., Vassiladis, P., 1999.

Architecture and Quality in Data Warehouses: An

Extended Repository Approach. Information Systems,

24(3).

Luebbers, D., Grimmer, U., Jarke, M., 2003. Systematic

Development of Data Mining-Based Data Quality

Tools. In the 29

International Conference on Very

Large Databases, Berlin, Germany.

Liu, H., Shah, S., Jiang, W., 2004. On-line Outlier

Detection and Data Cleaning. Computers and

Chemical Engineering 28.

Mecella, M., Scannapieco, M., Virgillito, A., Baldoni, R.,

Catarci, T., Batini, C., 2003. The DAQUINCIS

Broker: Querying Data and Their Quality in

Cooperative Information Systems. Journal of Data

Semantics, Vol. 1, LNCS 2800.

Muller, H., Freytag, J. C., 2003. Problems, Methods, and

Challenges in Comprehensive Data Cleansing.

Technical. Report, HUB-1B-164.

Rahm, E., Do, H., 2000. Data Cleaning: Problems and

Current Approaches. IEEE Bulletin of the Technical

Committee on Data Engineering, Vol 23, No. 4.

Raman, V., Hellerstein, J., 2001. Potter’s Wheel: An

Interactive Data Cleaning System. In the 27

International Conference on Very Large Databases.

Roma, Italy.

Sung, S., Li, Z., Sun, P., 2002. A fast Filtering Scheme for

Large Database Cleaning. In the 11

International

Conference on Information and Knowledge

Management, Virginia, USA.

Winkler, W., 2003. Data Cleaning Methods, In the

Conference SIGKDD, Washington DC, USA.

Wang, Y., Storey, V., Firth, C., 1995. A Framework for

Analysis of Data Quality Research, IEEE Transactions

on Knowledge and Data Engineering, Vol. 7, No. 4.

ICEIS 2008 - International Conference on Enterprise Information Systems

478
