AN APPROACH FOR SCHEMA VERSIONING IN

MULTI-TEMPORAL XML DATABASES

Zouhaier Brahmia and Rafik Bouaziz

Faculty of Economic Sciences and Management, University of Sfax, Road of the Aerodrome, Sfax, Tunisia

Keywords: Temporal databases, XML databases, Schema versioning, XML Schema.

Abstract: Schema evolution keeps only the current data and the schema version after applying schema changes. On

the contrary, schema versioning creates new schema versions and preserves old schema versions and their

corresponding data. These two techniques have been investigated widely, both in the context of static and

temporal databases. With the growing interest in XML and temporal XML data as well as the mechanisms

for holding such data, the XML context within which data items are formatted also becomes an issue.

Whereas much research work has recently focused on the problem of schema evolution in XML databases,

less attention has been devoted to schema versioning in such databases. In this paper, we propose an

approach for schema versioning in multi-temporal XML databases. This approach is based on the XML

Schema language for describing XML schema, and is database consistency-preserving.

1 INTRODUCTION

XML (W3C, 2006a) is an emergent standard for web

documents. It is being used in a wide range of

applications and among a wide array of

communities. In database context, XML is also a

new database model for semi-structured data.

XML provides an excellent support for

temporally grouped data models, which have long

been advocated as the most natural and effective

representations of temporal information (Clifford et

al, 1995).

Since change is a fundamental aspect of

persistent information and data-centric systems, both

the data and the structure (schema) of XML

documents tend to change over time for a multitude

of reasons, including to reflect a change in the real

world, a change in the user’s requirements, mistakes

in the initial design or to allow the expansion of the

application scope over time. While XML schema

changes are inevitable during the life of an XML

database, most of the current XML DBMS

unfortunately do not provide enough support for

these changes and do not support schema evolution

or schema versioning. So, XML database developers

try to solve the problem of schema evolution in an

ad hoc manner. Note that schema evolution is

partially supported by some relational database

systems, such as Oracle and Microsoft SQL Server,

and also by some object-oriented database systems,

such as Orion and TIGUKAT (Ozsu et al, 1995).

Schema versioning has been previously studied

in the context of temporal databases (Roddick,

1995). But an XML schema is a grammar

specification, unlike a relational database schema, so

new techniques are required. Though various XML

schema languages have been proposed in the

literature and in the commercial area (Lee & Chu,

2000), there are neither model schema changes nor

provision for versioning.

Schema versioning and its consequences on

instances have also been thoroughly investigated in

object-oriented databases (e.g. (Galante et al, 2005)).

Though object-oriented schema bring some

similarities with XML Schema, there are

fundamental differences that prevent to smoothly

adapt techniques developed in that context to XML

Schema.

Moreover, whereas several previous works have

dealt with schema evolution in XML databases

(Coox, 2003; Guerrini et al, 2005; Wang & Zaniolo,

2005), few works were done on schema versioning

in such environment (Costello & Utzinger, 2006;

W3C, 2006b). Besides, whereas most previous

works about XML schema versioning use the DTD

schema language (W3C, 2006a) which has limited

capabilities compared to other schema languages

(Lee & Chu, 2000), few works have used the XML

290

Brahmia Z. and Bouaziz R. (2008).

AN APPROACH FOR SCHEMA VERSIONING IN MULTI-TEMPORAL XML DATABASES.

In Proceedings of the Tenth International Conference on Enterprise Information Systems - DISI, pages 290-297

DOI: 10.5220/0001707702900297

 SciTePress

Schema language (W3C, 2001) which is a powerful

schema language backed by the W3C and supports

the major features available in other XML schema

languages. For these reasons, we propose in this

paper an approach for schema versioning in multi-

temporal XML databases, using the XML Schema

language.

The rest of the paper is organized as follows.

Section 2 presents our approach for schema

versioning in multi-temporal XML databases

(chosen XML schema language; schema change

operations; schema change propagation; XML data

management and querying; implementation). Section

3 is devoted to a brief review of related works.

Conclusions can finally be found in Section 4.

2 PRESENTATION OF THE

PROPOSED APPROACH

A general description of our approach is depicted in

figure 1.

The designer defines, modifies and deletes XML

Schema of objects of the real world. These XML

schema can evolve over time through many

versions. Figure 1 shows the translation from the

XML Schema version number i of an object o to the

XML Schema version number i+1 of the same

object o. After this translation, the version number i

becomes a past version and the version number i+1

becomes the current XML Schema version of the

object o.

Users must define documents which are valid to

a specified XML Schema version (a past version or

the current version). By default, users must use the

current XML Schema version of an object to define

and to modify documents which are valid to this

XML Schema version. But a user can specify that

he/she wants to define an XML document of an

object according to a past XML Schema version of

this object. The changes of an XML document must

be done within the same XML Schema version of

this document, i.e. this document must be valid to its

schema even after modification.

2.1 Chosen XML Schema Formalism:

XML Schema

Although there are many schema languages (DTD,

XML Schema, XDR, DSD, SOX, Schematron,

DCD, DDML, RELAX, Assertion Grammars, etc.)

(Lee & Chu, 2000), the two mostly widely-used

schema languages are currently DTD and XML

Schema.

We choose XML Schema (and not DTD) for the

following reasons:

 it includes more powerful features for defining

the structure and content of an XML

document than DTD (it has more than 44

built-in data types available, over only 10 data

types for DTD language; it supports different

keys like primary key and referenced key as

opposed to only ID and IDREF support in

DTD, etc.);

 it supports the major features available in

other XML schema languages;

 it is backed by the W3C.

The XML Schema language is also referred to as

XML Schema Definition (XSD).

2.2 Basic Principles

Our research is based on the following basic

principles:

 The considered XML environment is multi-

version and temporal: each object of the real

world (e.g. Student, Course, Teacher and

Degree, in an academic system) can have

many XML Schema versions since an XML

Figure 1: General description of our approach.

XML

document

XML

Schema version

n° i of object o

XML

document’

XML Schema

version n° i+1 of

object o

Data

change

Schema change

XML Schema

designer

XML

document

Creation, Modification

and Deletion

valid to

XML

document’’

valid to

User

Data

change

Creation, Modification

and Deletion

AN APPROACH FOR SCHEMA VERSIONING IN MULTI-TEMPORAL XML DATABASES

291

Schema of an object is considered as a logical

entity that evolves over time through various

versions; and each XML Schema version has a

temporal format (snapshot, transaction-time,

valid-time or bitemporal). An XML document

which is valid to an XML Schema version

must have the same temporal format of its

schema.

 Extensional XML data (or XML documents)

are multi-temporal (De Castro et al, 1997): we

consider an XML database in which

documents of different temporal formats

coexist. A temporal XML document records

the entire history of an object rather than just

its current state.

 XML schema versioning is temporal: any

XML schema version has a temporal interval

[version start time – version end time]. The

version end time remains unknown until the

definition of a new XML Schema version;

during this period, it is set to the special

symbol ‘UC’ that means ‘until changed’.

 XML schema versioning is individual: each

object has its own XML Schema versions

which are managed independently from XML

Schema versions of any other object.

 For each object of the real world, we have

always one current XML schema version and

zero, one or several past XML schema

version(s). When a new XML schema version

is defined for an object, this version becomes

the only current version for this object and the

previous XML Schema version becomes a

past version.

 XML Schema versions of an object are

numbered in an increasing order (e.g.,

Employee_V1.xsd, Employee_V2.xsd,

Employee_V3.xsd, etc.). The current XML

schema version has always the biggest

number.

 An XML Schema version can be derived from

a previous one: XML database administrator

can use old schema versions to define new

ones.

 The new XML Schema version must be

different from the last one (difference in

structure and/or difference in format);

otherwise it cannot be accepted. We must not

have two successive schema versions which

are identical. If we suppose that a schema

version V2 is identical to V1, what is the

utility of V2 in that case? V2 is not necessary;

the DBMS must refuse it and continue

considering V1 as the current XML schema

version until having a new schema version

which modifies V1.

2.3 Schema Change Operations for

XML Schema

In this section, we propose a set of basic schema

change operations that can be applied to any XML

schema expressed by XML Schema language. We

also provide examples of their use. These operations

provide schema versioning facilities and are

consistency-preserving: they ensure that all existing

XML Schemas and their underlying XML

documents are kept without any modification.

An XML Schema of an object is simply an XML

document which is a set of XML elements. Each

element can be composed of several sub-elements

and each element or sub-element is characterized by

a set of attributes. Thus, schema change operations

can deal with XML Schema elements (or XML

Schema sub-elements) and/or attributes of XML

Schema elements (or XML Schema sub-elements).

Translation from the current XML Schema

version of an object to a new XML Schema version

of this object is achieved by applying a set of

schema change operations.

Below, we present an example to illustrate

changes in XML Schema. Figure 2 depicts the first

version of an XML Schema for the object Hotel (in a

system of hotel management), called Guide_V1.xsd,

and Figure 3 shows a sample XML document valid

to this XML Schema version. The first sample

document is used for running examples hence forth.

<?xml version=”1.0” encoding=”UTF-8”?>

<xsd:schema xmlns:xsd=http://www.w3.org/2000/10/XMLSchema>

<xsd:element name="Guide">

<xsd:complexTtype>

<xsd:sequence>

<xsd:element name="Hotel" maxOccurs="unbounded">

<xsd:complexType>

<xsd:sequence>

<xsd:element name="Name" type="xsd:string"/>

<xsd:element name="Address">

<xsd:complexType>

<xsd:sequence>

<xsd:element name="Number" type="xsd:short"/>

<xsd:element name="Street" type=”xsd:string”/>

<xsd:element name="Town" type=”xsd:string”/>

<xsd:element name="Postcode" type=”xsd:string”/>

</xsd:sequence>

</xsd:complexType>

</xsd:element>

<xsd:element name="Room" type="xsd:short"/>

<xsd:element name="Phone" type="xsd:string"/>

<xsd:element name="Fax" type="xsd:string" minOccurs=”0”/>

</xsd:sequence>

<xsd:attribute name=”Category” type="xsd:string" use=”required”/>

</xsd:complexType>

</xsd:element>

</xsd:sequence>

<xsd:attribute name=”Country” type="xsd:string" use=”required”/>

<xsd:attribute name=”Continent” type="xsd:string" use=”required”/>

<xsd:attribute name=”Version” type="xsd:short" use=”required”/>

ICEIS 2008 - International Conference on Enterprise Information Systems

292

<xsd:attribute name=”Version_Start_Time” type="xsd:date"

use=”required”/>

<xsd:attribute name=”Version_End_Time” type="xsd:date"

use=”required”/>

<xsd:attribute name=”Format” type="xsd:string" use=”required”

fixed=”Snapshot”/>

</xsd:complexType>

</xsd:element>

</xsd:schema>

Figure 2: Guide_V1.xsd.

<?xml version=”1.0” encoding=”UTF-8”?>

<Guide Country=”Tunisia” Continent=” Africa” Version=”1”

Version_Start_Time=”2007-01-31” Version_Start_Time=”2007-01-31”

Format=”Snapshot”>

<Name>Kantawi Club</Name>

< Number>12</Number>

<Street>Flowers</Street>

<Town>Sousse</Town>

</Address>

</Hotel>

</Guide>

Figure 3: An XML document valid to Guide_V1.xsd.

2.3.1 Notations

When dealing with the schema change operations,

we will use the notation presented in Table 1.

Table 1: Notation of the schema change operations.

Expression Description

i,o

The XML Schema version number i of

the object o

i,o

The element e of SV

i,o

The set of elements of SV

i,o

;

i,o

= {e

i,o

}

i,o

The attribute a of e

i,o

Att(e

i,o

) The set of attributes of the element e

i,o

;

Att(e

i,o

) = {a

i,o

}

2.3.2 Schema Change Operation

Specification

We distinguish six main schema change operations:

 Addition, Deletion and Modification of an

XML Schema element;

 Addition, Deletion and Modification of an

attribute of an XML Schema element.

We assume that the following schema change

operations are applied to SV

i,o

and produce SV

i+1,o

output.

For the illustrative examples, suppose that we

translate from Guide_V1.xsd to Guide_V2.xsd by

applying a set of schema change operations.

Addition of a new XML Schema Element “e”.

This operation cannot be performed if there is an

existing element with the same name of e in the

current XML Schema version. Such an operation

can be formalized as follows:

AddElem(SV

i,o

,e) Æ SV

i+1,o

such that

i+1,o

= E

i,o

∪ {e}

Example 1: Result of the operation “Addition of the

element homepage”.

Before addition:

Guide_V1.xsd

After addition:

Guide_V2.xsd

……

<xsd:element name="Fax"

type="xsd:string"

minOccurs=”0”/>

</xsd:sequence>

……

<xsd:element

name="Fax"

type="xsd:string"

minOccurs=”0”/>

<xsd:element

name="homepage"

type="xsd:string"

minOccurrs="0"

maxOccurrs="1"/>

</xsd:sequence>

……

Deletion of an XML Schema Element “e”. The

element e must already exist in the current XML

Schema version, otherwise this operation fails. Such

an operation can be formalized as follows:

DelElem(SV

i,o

,e) Æ SV

i+1,o

such that

i+1,o

= E

i,o

/ {e}

Example 2: Result of the operation “Deletion of the

element Fax”.

Before deletion:

Guide_V1.xsd

After deletion:

Guide_V2.xsd

……

<xsd:element name="Phone"

type="xsd:string"/>

<xsd:element name="Fax"

type="xsd:string"

minOccurs=”0”/>

</xsd:sequence>

……

<xsd:element

name="Phone"

type="xsd:string"/>

</xsd:sequence>

……

Modification of an XML Schema Element “e”.

The element e must exist in the current XML

schema version, otherwise this operation cannot be

realized. This operation can be one of the following

operations: Addition of a new sub-element s to e,

Deletion of a sub-element s of e, Renaming e,

Modification of type of element e, etc. It can be

formalized as follows:

AN APPROACH FOR SCHEMA VERSIONING IN MULTI-TEMPORAL XML DATABASES

293

ModifElem(SV

i,o

,e) Æ SV

i+1,o

such that

i+1,o

= E

i,o

/ {e

i,o

} ∪ {e

i+1,o

}

Example 3: Result of the operation “Modification of the

element Postcode”.

Before modification:

Guide_V1.xsd

After modification:

Guide_V2.xsd

……

<xsd:element

name="Town"

type=”xsd:string”/>

<xsd:element

name="Postcode"

type=”xsd:string”/>

</xsd:sequence>

……

<xsd:element

name="Town"

type=”xsd:string”/>

<xsd:element

name="Zip code"

type=”xsd:string”/>

</xsd:sequence>

……

Addition of an Attribute “a” to an XML Schema

Element “e”. This operation cannot be achieved if

there is an existing attribute of e with the same name

of a, in the current XML Schema version. It can be

formalized as follows:

AddAtt(SV

i,o

,e,a) Æ SV

i+1,o

such that E

i+1,o

= E

i,o

} ∪ {e

i+1,o

} ∧ [Att(e

i+1,o

)=Att(e

i,o

) ∪ {a

i+1,o

}]

Example 4: Result of the operation “Addition of the

attribute Id to the element Hotel”.

Before addition:

Guide_V1.xsd

After addition:

Guide_V2.xsd

……

</xsd:sequence>

<xsd:attribute

name=”Category”

type="xsd:string"

use=”required”/>

</xsd:complexType>

……

</xsd:sequence>

<xsd:attribute

name=”Id”

type="xsd:byte"

use=”required”/>

<xsd:attribute

name=”Category”

type="xsd:string"

use=”required”/>

</xsd:complexType>

……

Deletion of an Attribute “a” of an XML Schema

Element “e”. This operation cannot be performed if

there is no existing attribute of e with the same name

of a, in the current XML Schema version. Its

formalization is as follows:

DelAtt(SV

i,o

,e,a) Æ SV

i+1,o

such that E

i+1,o

= E

i,o

} ∪ {e

i+1,o

} ∧ [Att(e

i+1,o

)=Att(e

i,o

) / {a

i,o

}]

Example 5: Result of the operation “Deletion of the

attribute Continent of the element Guide”.

Before deletion:

Guide_V1.xsd

After deletion:

Guide_V2.xsd

……

<xsd:attribute

……

<xsd:attribute

name=”Country”

type="xsd:string"

use=”required”/>

<xsd:attribute

name=”Continent”

type="xsd:string"

use=”required”/>

<xsd:attribute

name=”Version”

type="xsd:short"

use=”required”/>

……

name=”Country”

type="xsd:string"

use=”required”/>

<xsd:attribute

name=”Version”

type="xsd:short"

use=”required”/>

……

Modification of an Attribute “a” of an XML

Schema Element “e”. This operation cannot be

performed if there is no existing attribute of e with

the same name of a, in the current XML Schema

version. This operation can modify any attribute a of

e (like its name or its type). It can be formalized as

follows:

ModifAtt(SV

i,o

,e,a) Æ SV

i+1,o

such that E

i+1,o

= E

i,o

} ∪ {e

i+1,o

} ∧ [Att(e

i+1,o

)=Att(e

i,o

) / {a

i,o

} ∪

i+1,o

}]

Example 6: Result of the operation “Modification of the

attributes Version_Start_Time and Version_End_Time of

the element Guide”.

Before modification:

Guide_V1.xsd

After modification:

Guide_V2.xsd

……

<xsd:attribute

name=”Version_Start_Ti

me” type="xsd:date"

use=”required”/>

<xsd:attribute

name=”Version_End_Ti

me”

type="xsd:date"

use=”required”/>

……

<xsd:attribute

name=”Version_Start_

Time”

type="xsd:dateTime"

use=”required”/>

<xsd:attribute

name=”Version_End_

Time”

type="xsd:dateTime"

use=”required”/>

……

2.4 Schema Change Propagation

In order to avoid problems, like data loss,

modification of semantics and essentially document

revalidation (Raghavachari & Shmueli, 2004;

Guerrini et al, 2005), and to preserve the complete

history of XML Schema and data changes, creation

of a new XML schema version must not affect old

XML schema versions and their underlying XML

documents. Old XML documents continue to be

considered as valid for their XML Schema and must

not be revalidated. But new XML documents should

be valid for the new schema version. In our

approach, when a new XML Schema version is

ICEIS 2008 - International Conference on Enterprise Information Systems

294

created, there is neither conversion of previous XML

schema nor revalidation of previous XML

documents. Only the version end time attribute of

the previous XML Schema version, which is set to

‘UC’, will be changed to the instant that precedes

the start time of the new version.

Thus, schema changes do not affect the

underlying data.

Example: Suppose we have an XML Schema

version V

(i > 0) used during its temporal interval [t

– UC[. When we apply to V

, at an instant t

(j > i),

one or more schema change operations (addition of

an element, for example), a new XML schema

version V

i+1

will be created by the XML DBMS with

a temporal interval equal to [t

– UC[. The old XML

schema version V

will be kept with a temporal

interval equal to [t

– (t

-1)]. All documents which

are valid relatively to V

will also be kept without

any modification.

2.5 XML Data Management

In our context, XML documents are multi-version

and temporal. XML data management includes

XML document creation, modification and deletion.

XML document modification includes XML element

addition, modification and deletion. In an XML

document of snapshot or valid-time format, XML

element modification and deletion operations are

destructive. However, these operations are not

destructive in an XML document of transaction-time

or bitemporal format. The definition of each

operation is presented below.

Addition of an Element. This operation inserts a

new element into the corresponding position in the

XML document. If this XML document is of

transaction-time or a bitemporal format, then the

system sets the transaction start time attribute of this

new element to the current time and the transaction

end time attribute to the special symbol ‘UC’. In the

case of a valid-time or a bitemporal document, the

validity start time and validity end time attributes of

the new element are defined by the user. The

validity end time attribute can be set by the user to

the special symbol ‘now’ that represents the ever-

increasing current element.

Modification of an Element. This operation

appends a new element with the same name

immediately after the original element. If the

corresponding XML document is of transaction-time

or a bitemporal format, then the system sets the

transaction start time attribute of this new element to

the current time and the transaction end time

attribute to ‘UC’; it also sets the transaction end time

attribute of the original element to the current time.

Each previous XML document, which is valid to

a previous XML schema version, must be modified

according to its schema version.

After modification of an XML document, this

latter must be valid to its original XML Schema, else

the modification is canceled and the document is

kept in its initial state (i.e. before modification).

Deletion of an Element. This operation changes the

state attribute of this element to ‘d’ that means

‘deleted’. This attribute can be set to ‘v’ (default

value) for ‘valid’ or ‘e’ for ‘erroneous’.

For each object of the real world, new XML

documents are created and modified according to the

current XML schema version of this object; they

must be valid to this version.

Thus, XML data (or document) change

operations (element addition, modification or

deletion) have no effect on the corresponding XML

Schema. Modification of an XML document cannot

lead to a new XML Schema; it has to leave the

modified document valid with regard to its XML

Schema.

2.6 XML Data Querying

In a multi-version environment, we can have multi-

schema queries (i.e., queries in which several

schema versions qualify for the temporal selection

conditions). To answer these queries, the XML

DBMS will use all selected schema versions (multi-

schema answer).

XQuery (W3C, 2007) is a powerful query

language which provides an effective support for

(complex) temporal queries (e.g. slicing queries,

historical queries and temporal join queries) at the

logical level (Wang & Zaniolo, 2005).

In order to support temporal multi-schema

queries, XQuery will need new operators like the

Allen operators (Allen, 1983) (i.e. before, after,

meets, overlaps, etc.) and new functions in order to

specify schema versions in XML queries (e.g.

first_verion(), last_version(), version_applied_at(a

particular time t), versions_applied_during(a

particular time interval), etc.).

XQuery is Turing-complete and natively

extensible (Kepser, 2004). Thus, additional

constructs needed for temporal multi-schema queries

can be defined in XQuery itself, without having to

depend on difficult-to-obtain extensions by standard

committees.

AN APPROACH FOR SCHEMA VERSIONING IN MULTI-TEMPORAL XML DATABASES

295

Figure 4: The overall system architecture.

2.7 Implementation

To verify the feasibility of our approach, we

implement the ideas presented in this paper in a

functioning prototype system for schema versioning

in multi-temporal XML databases, called

Sysvermutex. This system is developed on top of an

open source native XML DBMS, eXist (http://exist-

db.org/), by using Java, within a stratum approach.

The overall architecture is depicted in figure 4. The

dashed rectangle indicates the boundary of the

stratum. This stratum consists of the three

components shown as Schema Change Processor,

XML Data Management Processor and Multi-

Schema Temporal Query Processor modules.

3 RELATED WORK

Schema evolution had been previously investigated

for schemas expressed by DTDs in (Su et al, 2001),

where a set of evolution operators is proposed and

discussed in detail. DTD evolution has also been

investigated in (Bertino et al, 2002): the focus was

on dynamically adapting the schema to the structure

of most documents stored in an XML data source.

An axiomatic model of an XML database schema is

suggested in (Coox, 2003) that automatically

maintains the integrity of the XML database when

basic changes are made to its schema. A framework

for schema evolution of relational database-based

systems with XML “interface” is presented in

(Simanovsky, 2004).

Schema evolution and schema versioning had

also been studied for schema expressed by XML

Schema in (Guerrini et al, 2005), (Dyreson et al,

2006) and (Joshi, 2007). In (Guerrini et al, 2005),

the authors have proposed a set of evolution

primitives and analyzed the impact of such

primitives on the validity of XML documents known

to be valid for the original schema. In (Dyreson et al,

2006), the authors show how schema versioning can

be integrated with support for time-varying

documents in a fashion consistent and upwardly-

compatible with XML, XML Schema, and

conventional XML validators. In (Joshi, 2007), the

authors show that by utilizing schema-constant

periods and cross-wall validation, it is possible to

realize a comprehensive system for representing and

validating data- and schema-versioned XML

documents, while remaining fully compatible with

the XML standards.

Moreover, in order to minimize impact to

existing instance documents and applications as new

versions of XML Schema are created and to

facilitate system evolution, the authors of (Costello

& Utzinger, 2006) made eight recommendations

concerning design of XML Schema, instance

documents and applications. A description of use

cases where XML Schema are being versioned is

presented in (W3C, 2006b). These use cases

describe the desired behaviour from XML Schema

processors when they encounter the different

versions of schema and the instances defined by

them.

Finally, it is shown in (Wang & Zaniolo, 2005)

that XML views combined with XML query

languages (like XQuery) can provide surprisingly

effective solutions to the problem of representing

and querying both the evolution of database contents

and the evolution of database schema.

XML DBMS eXist

Schema Change

Processor

Multi-Schema

Temporal Query

Processor

Temporal

XML Query

XQuery

Query

Schema change

operation(s)

New XML

Schema

version

XML database (XML Document versions, Index,

XML Schema versions, etc.)

XML Data

Management Processor

XML Data

management

operation(s)

New XML document

or u

dated documen

ICEIS 2008 - International Conference on Enterprise Information Systems

296

4 CONCLUSIONS

This paper presents a new approach for schema

versioning in multi-temporal XML databases.

This approach is based on XML Schema which

is a powerful XML schema language that overcomes

the limitations of DTDs (used in most works

concerning schema evolution or versioning).

Moreover, our approach treats XML Schema

changes as a versioning process instead of a simple

evolution. It also ensures the consistency of the

XML database since:

 when a new XML Schema version is defined,

it does not convert previous XML Schema

versions and does not revalidate previous

XML documents which are valid to their

XML Schema versions;

 XML document change operations do not

affect the corresponding XML Schema;

 after modification of an XML document, this

latter is still valid to its XML Schema.

The prototype implementation of the proposed

approach will serve as a testbed for experimental

evaluation.

Currently, we are working on XML data change

operations in a temporal multi-version environment

and on extensions needed by XQuery to support

temporal multi-schema queries.

REFERENCES

Allen, J.F., 1983. Maintaining knowledge about temporal

intervals. Communications of the ACM, 26(11), p.832-

843.

Bertino, E., Guerrini, G., Mesiti, M. & Tosetto, L., 2002.

Evolving a Set of DTDs according to a Dynamic Set

of XML Documents. In EDBT Workshops 2002, 8

International Conference on Extending Database

Technology 2002 Workshops. Springer.

Clifford, J., Croker, A., Grandi, F. & Tuzhilin, A., 1995.

On Temporal Grouping. In Temporal Databases 1995,

International Workshop on Temporal Databases 1995.

Springer.

Coox, S.V., 2003. Axiomatization of the Evolution of

XML Database Schema. Programming and Computer

Software, 29(3), p.1-7.

Costello, R. L. & Utzinger, M., 2006. Impact of XML

Schema Versioning on System Design.

www.xfront.com/SchemaVersioning.html

De Castro, C., Grandi, F. & Scalas, M.R., 1997. Schema

versioning for multitemporal relational databases.

Information Systems, 22(5), p.249-290.

Dyreson, C., Snodgrass, R. T., Currim, F., Currim, S. &

Joshi, S., 2006. Validating Quicksand: Schema

Versioning in τXSchema. In ICDE Workshops 2006,

International Conference on Data Engineering

Workshops. IEEE Computer Society.

Galante, R.M., Dos Santos, C.S., Edelweiss, N. &

Moreira, A.F., 2005. Temporal and versioning model

for schema evolution in object-oriented databases.

Data and Knowledge Engineering, 53(2), p.99-128.

Guerrini, G., Mesiti, M. & Rossi, D., 2005. Impact of

XML Schema Evolution on Valid Documents. In

WIDM’05, 7

ACM International Workshop on Web

Information and Data Management. ACM.

Joshi, S., 2007. τXSchema - Support for Data- and

Schema-Versioned XML Documents. Technical

Report TR-89, TimeCenter. http://www.cs.auc.dk/

TimeCenter/

Kepser, S., 2004. A Simple Proof for the Turing-

Completeness of XSLT and XQuery. In EML2004,

Extreme Markup Languages 2004 Conference.

IDEAlliance.

Lee, D. & Chu, W.W., 2000. Comparative Analysis of Six

XML Schema Languages. ACM SIGMOD Record,

29(3), p.76-87.

Ozsu, M.T., Peters, R.J., Szafron, D., Irani, B., Lipka, A.

& Munõz, A., 1995. TIGUKAT: a uniform behavioral

objectbase management system. The VLDB Journal,

4(3), p.445-492.

Raghavachari, M. & Shmueli, O., 2004. Efficient

Schema-Based Revalidation of XML. In EDBT 2004,

International Conference on Extending Database

Technology. Springer.

Roddick, J., 1995. A survey of schema versioning issues

for database systems. Information and Software

Technology, 37(7), p.383-393.

Simanovsky, A., 2004. Evolution of Schema of XML-

documents Stored in a Relational Database. In

DB&IS’2004, 6

International Baltic Conference on

Database and Information Systems. Springer-Verlag.

Su, H., Kramer, D., Chen, L., Claypool, K. T. &

Rundensteiner, E. A., 2001. XEM: Managing the

evolution of XML documents. In RIDE-DM’01, 11

International Workshop on Research Issues in Data

Engineering: Document Management for Data

Intensive Business and Scientific Applications. IEEE

Computer Society.

Wang, F. & Zaniolo, C., 2005. An XML-Based Approach

to Publishing and Querying the History of Databases.

World Wide Web, 8(3), p.233-259.

W3C, 2001. XML Schema Part 0: Primer. W3C

Recommendation. http://www.w3.org/TR/2001/REC-

xmlschema-0-20010502/

W3C, 2006a. Extensible Markup Language (XML) 1.0

(4th edition). W3C Recommendation.

http://www.w3.org/TR/2006/REC-xml-20060816.

W3C, 2006b. XML Schema Versioning Use Cases. W3C

Working Draft. http://www.w3.org/XML/2005/xsd-

versioning-use-cases/2006-01-31.html.

W3C, 2007. XQuery 1.0: An XML Query Language. W3C

Recommendation. http://www.w3.org/TR/2007/REC-

xquery-20070123/

AN APPROACH FOR SCHEMA VERSIONING IN MULTI-TEMPORAL XML DATABASES

297
