A SIMILARITY MEASURE FOR MUSIC SIGNALS

Gonc¸alo Marques

Instituto Superior de Engenharia de Lisboa, Portugal

Thibault Langlois

Universidade de Lisboa, Faculdade de Ciˆencias, Departamento de Informatica, Portugal

Keywords:

Music Information Retrieval, Music Similarity Measure, Audio Signal Processing, Feature Extraction.

Abstract:

One of the goals in the ﬁeld of Music Information Retrieval is to obtain a measure of similarity between two

musical recordings. Such a measure is at the core of automatic classiﬁcation, query, and retrieval systems,

which have become a necessity due to the ever increasing availability and size of musical databases. This

paper proposes a method for calculating a similarity distance between two music signals. The method extracts

a set of features from the audio recordings, models the features, and determines the distance between models.

While further work is needed, preliminary results show that the proposed method has the potential to be used

as a similarity measure for musical signals.

1 INTRODUCTION

Nowadays there is an enormous amount of digital mu-

sic available on-line, and users can search through

vast databases to select their favorite albums, artists,

songs, and create their own databases or playlists.

Even at a personal level, one can create fairly large

music collections by transferring ones CDs to a com-

puter or an iPod. Nevertheless, with the rapidly in-

creasing amount of digital data it is necessary to have

some means of indexing,searching and retrieving mu-

sic contents. Theses tasks are aided by including

some information along with a song (metadata), typ-

ically annotated manually by an expert or by the user.

Nevertheless, metadata is not always provided or in

some cases is erroneous, and with the every increas-

ing number of new songs, the required manual work

becomes prohibitive.

Similarity is the core of classiﬁcation and ranking

algorithms, thus, having an automatic way of mea-

suring similarities between two songs would be a

valuable tool in the ﬁeld of Music Information Re-

trieval. Such a tool would have many applications

such as making database queries by user-provided ex-

amples (Spevak and Favreau, 2002; Heln and Virta-

nen, 2007), automatically organizing and classifying

digital audio collections (Neumayer et al., 2005), au-

tomatic playlist generation (Aucouturier and Pachet,

2002b; Logan and Salomon, 2001), providing per-

sonal musical recommendations, etc.

In order to measure the similarity between songs

it is necessary to characterize each song with a set

of features and to determine a distance between sets.

There is an extensive number of features that can be

used for this purpose, since the question of similarity

can be answered from multiple perspectives. For in-

stance, one could include features that are not directly

related to the audio signals, such as lyrical contents,

geographical origins, historical periods, artists infor-

mation, reviews, etc. This type of information is well

suited for Web-based methods, and a various works

exist on this subject - for example (Whitman and Ellis,

2004; Baumann et al., 2004; Pampalk et al., 2005a).

In this paper we are interested in deriving a mea-

sure of similarity solely based on the music signal,

without any additional information. There are several

features that can be extracted directly from the audio

signal, and there are many ways of using them to ob-

tain a similarity measure between songs. The most

common approach for obtaining the features is to di-

vide the signal into short overlapping frames (typi-

cally 10ms to 40ms long) and use each frame to ex-

tract time domain information such as the zero cross-

ing rate, or some spectral domain information such

as the fast Fourier transform (FFT), or the Mel fre-

quency cepstrum coefﬁcients (MFCCs). These can be

directly used as features vectors, or one can be incor-

porated some additional statistics of each audio seg-

ment such as the spectral centroid, spectral ﬂux, his-

tograms, etc. Once the features are extracted, there

308

Marques G. and Langlois T. (2008).

A SIMILARITY MEASURE FOR MUSIC SIGNALS.

In Proceedings of the Tenth International Conference on Enterprise Information Systems - AIDSS, pages 308-312

DOI: 10.5220/0001707903080312

 SciTePress

are a few ways of obtaining a similarity measure.

A model can be constructed for the feature vectors,

and then, the distances between models from different

musics can be determined. For instance (Tzanetakis

and Cook, 2002; Pampalk et al., 2005b; Aucouturier

and Pachet, 2002a; Heln and Virtanen, 2007) use a

Gaussian mixture model, and (Logan and Salomon,

2001; Berenzweig et al., 2004) apply a k-means algo-

rithm to model the features. Then the modelsare com-

pared using different techniques such as Monte Carlo

sampling (Aucouturier and Pachet, 2002a), Kullback-

Leibler divergence (Virtanen and Heln, 2007), likeli-

hood approximation (Berenzweig et al., 2004), ... (for

a review of the main methods see (Aucouturier and

Pachet, 2004) and references therein).

In this paper, we present a method for construct-

ing a distance measure between musics based on their

audio contents. The organization of this paper is as

follows. In section 2 we describe the process of ob-

taining the features and we present the method for de-

termining the similarity measure. Experimental re-

sults are presented and analyzed in section 3. Finally,

some conclusions are drawn and possible directions

for future work are presented.

2 OVERVIEW OF THE METHOD

Our goal is to estimate a similarity measure between

different pieces of music. The ﬁrst step consist in

computing the spectrogram of the music and ﬁnding

the most representative frames. This set of frames is

then used to compute a “distance” between this music

and other signals. This is done by calculating the av-

erage minimum distance between the FFT vectors of

the audio signal and the representative frames found

in the ﬁrst music.

2.1 Representative Frames

The ﬁrst step consist in ﬁnding representative frames

for each music. First, from the audio signal sam-

pled at 44.1KHz, the spectrogram is computed using

a 1024 samples windows with 50% overlap. Let F

be the set of FFT vectors of every frame of music A.

Let F

′A

be the subset of F

that corresponds to a

30 seconds excerpt of the middle of music A. Then,

the k-means algorithm is used on this subset to ﬁnd

k centroids (c

i=1..k

) that will represent the music. Ac-

cording to the parameter used to compute the FFT, the

FFT vectors are in a 512-dimensional space.

In our experiment, we used k = 6. The ﬁgure 1

shows the different clusters obtained on a spectrogram

Figure 1: An example of spectrogram. The color indicates,

for each frame, the corresponding cluster.

(each frame is colored according to the nearest cen-

troid).

2.2 Similarity

In order to compute the similarity between a music A

and a music B, we consider a set F

(n = 1..N) of 30

seconds-sequences of music B

. For each portion of

music F

, the euclidean distance between each vec-

tor f

in F

and each centroid of A (c

i=1..k

) is com-

puted. The time indice t corresponds to the indice of

the FFT frames. For each frame the distance to the

nearest centroid is recorded:

D (A, f

) = argmin

(dist( f

)) ∀t ∈ j = 1..k

This set of distances is then averaged to give the the

similarity between music A and the portionF

of mu-

sic B:

S (A,F

) =

∑

D (A, f

) (1)

Because we are interested in a similarity measure

between music A and the whole B music, we deﬁne

the similarity measure as the average similarity over

all portions F

S (A,B) =

∑

n=1

S (A,F

) (2)

The following section shows some results obtained

when comparing various kinds of musical pieces us-

ing this similarity measure.

The signal is cut in 30 second sequences in order to

save computing resources.

A SIMILARITY MEASURE FOR MUSIC SIGNALS

309

3 EXPERIMENTS AND RESULTS

In order to evaluate the proposed similarity measure,

we extracted three musics from three albums from

very different artists: Sade, The Clash and Frederic

Chopin. The goal of this ﬁrst test is to verify ex-

perimentally that the similarity measure makes sense

when very different kinds of sounds are compared.

The tracks chosen for this experiment are:

Artist - Album - Title

A Sade - Love Deluxe - No Ordinary Love

B Sade - Love Deluxe - Feel No Pain

C Sade - Love Deluxe - I Couldn’t Love you more

D The Clash - London Calling - London Calling

E The Clash - London Calling - Hateful

F The Clash - London Calling - Brand new Cadillac

G Frederic Chopin - Nr. 11 g-moll op. 37/1: Andante

sostenuto

H Frederic Chopin - Nr. 14 ﬁs-moll op. 48/2: An-

dantino

I Frederic Chopin - Nr. 20 cis-moll op. posth.: Lento

con gran espressione

The capital letters will be used for shorter reference.

3.1 Similarity between Different Kinds

of Music

The similarity matrix, computed for the musics A - I

is represented in this table:

A B C D E F G H I

A 323 315 368 412 431 475 626 570 630

B 337 293 361 391 396 471 554 500 560

C 357 352 324 500 534 547 395 423 417

D 491 453 579 324 363 417 1043 967 1034

E 482 430 559 360 297 455 1054 984 1044

F 498 460 556 352 364 351 892 816 889

G 863 864 700 1014 1051 902 300 288 314

H 799 798 651 929 968 825 318 280 315

I 819 809 666 939 972 827 301 280 299

As seen above, the similarity measure is not symmet-

ric. It is interesting to note that in most cases the

shortest distance is between a music and itself (i.e.

the smallest values are on the diagonal). The only ex-

ception occurs for music I.

The measure of similarity can be easily be adapted

to yield a symmetric distance:

d(A,B) = (S (A,B) + S (B, A))/2

where d(A,B) represents the distance between musics

A and B. The image in ﬁgure 2 represent the distance

Figure 2: Picture of the matrix of distances between music

pieces A – I.

matrix. Tracks are ordered from A to I starting at the

upper left corner. Dark squares correspond to small

distances. One can see clearly three clusters that cor-

respond to the pieces from the same author. Accord-

ing to the distance measure, The Clash is closer to

Sade than it is to Frederic Chopin, which corresponds

to our expectations.

3.2 Similarity between Portions of

Tracks

In this experiment we use the same set of tracks as be-

fore but we consider each 30 seconds-long sequences

extracted from each track as a different music. The

distance matrix is computedas before and represented

as an image (see ﬁgure 3) but this time a logarithmic

scale is used to represent the gray levels.

At this scale, one can see three clusters that cor-

Figure 3: Picture of the matrix distance between all 30 sec-

onds portions of music A – I.

ICEIS 2008 - International Conference on Enterprise Information Systems

310

respond to the three artists. Within each cluster, the

lighter pixels indicate that certain segments of a given

music are not that close to the centroids of another

portion of the same music. This is not surprising,

since different instruments may be used on different

segments.

3.3 Similarity between Musics with

Different Instruments

The objective of this experiment is to evaluate the

ability of the proposed similarity measure to capture

timbral characteristics of differentinstruments. In this

experiment we use three kinds of classical music fea-

turing a piano solo, a piano and cello, and a cello solo:

Artist - Album - Title

H Frederic Chopin - Nr. 14 ﬁs-moll op. 48/2: An-

dantino

I Frederic Chopin - Nr. 20 cis-moll op. posth.: Lento

con gran espressione

J Rostropovitch, Britten - Frank Bridge - Sonata for

viloncello and piano part 1

K Rostropovitch, Britten - Frank Bridge - Sonata for

viloncello and piano part 2

L Janos Straker - Bach Suite for Solo Cello - Suite

No. 1 in G Major

M Janos Straker - Bach Suite for Solo Cello - Suite

No. 3 in C Major

The matrix distance is represented as before by a

gray-scale image (ﬁgure 4) with tracks in the follow-

ing order: H, I, J, K, L, and M starting at the upper

right corner. Again, darker squares represent shorter

distances.

Figure 4: Picture of the matrix distance calculated between

music pieces H, I, J, K, L and M.

The gray cross visible on the image indicates

that musics J and K that feature cello and piano are

roughly equidistant from musics H and I and from

musics L and M. Our interpretation of these results

is that in the ﬁrst two pieces (H and I), clusters will

represent various instances of piano sounds and clus-

ters of musics (L and M) will represent cello. Then,

as Frank Bridge sonatas feature piano and cello, the

corresponding FFT vectors are likely to be close to a

piano cluster or to a cello cluster.

4 CONCLUSIONS AND FUTURE

WORK

A new distance measure for estimating similarity be-

tween audio signals was presented. Preliminary re-

sults on a set of musics show that the distance measure

meet our expectations in terms of perceptual similar-

ities. The proposed distance does not capture high

level features of the music like beat or melody but

musics with similar sounds are indeed recognized as

similar. This characteristic is an interesting feature

that indicates that our distance may be used for clus-

tering audio signals based on timbre.

Ongoing work focus two main directions: on one

hand these preliminary results have to be conﬁrmed

on a larger database, and several parameters like

the number of centroids used in the clustering phase

should be better understood and optimized. On the

other hand, following the last experiment described

in this paper, we are working on methods that use

this approach in order to cluster a set of music tracks

according to the instruments used or to the timbre

present in the signal.

ACKNOWLEDGEMENTS

This work was supported by EU and FCT, through

LaSIGE Multiannual Funding Programme, and by the

Department EETC of ISEL.

REFERENCES

Aucouturier, J.-J. and Pachet, F. (2002a). Music similarity

measures: What’s the use? In ISMIR, Paris, France.

Aucouturier, J.-J. and Pachet, F. (2002b). Scaling up music

playlist generation. In ICME, Lausanne, Switzerland.

Aucouturier, J.-J. and Pachet, F. (2004). Improving timbre

similarity: How high is the sky? Journal of Negative

Results in Speech and Audio Sciences, 1(1).

A SIMILARITY MEASURE FOR MUSIC SIGNALS

311

Baumann, S., Pohle, T., and Shankar, V. (2004). Towards

a socio-cultural compatibility or MIR systems. In IS-

MIR, Barcelona, Spain.

Berenzweig, A., Logan, B., Ellis, D., and Whitman, B.

(2004). A large-scale evaluation of acoustic and sub-

jective music similarity measures. Computer Music

Journal, 28(2):63–76.

Heln, M. and Virtanen, T. (2007). Query by example of au-

dio signals using euclidean distance between gaussian

mixture models. In ICASSP, Honolulu, USA.

Logan, B. and Salomon, A. (2001). A music similarity func-

tion based on signal analysis. In ICME, Tokyo, Japan.

Neumayer, R., Lidy, T., and Rauber, A. (2005). Content-

based organization of digital audio collections. In Pro-

ceedings of the 5th Open Workshop of MUSICNET-

WORK, Vienna, Austria.

Pampalk, E., Flexer, A., and Widmer, G. (2005a). Hier-

archical organization and description of music collec-

tions at the artist level. In ECDL, Vienna, Austria.

Pampalk, E., Pohle, T., and Widmer, G. (2005b). Improve-

ments of audio-based music similarity and genre clas-

siﬁcation. In ISMIR, London, UK.

Spevak, C. and Favreau, E. (2002). Soundspotter - pro-

totype system for content-based audio retrieval. In

DAFX, Hamburg, Germany.

Tzanetakis, G. and Cook, P. (2002). Musical genre classi-

ﬁcation of audio singals. IEEE Trans. on Speech and

Audio Processing, 10(5):293–302.

Virtanen, T. and Heln, M. (2007). Probabilistic model based

similarity measures for audio query-by-example. In

WASPAA, NY.

Whitman, B. and Ellis, D. (2004). Automatic record re-

views. In ISMIR, Barcelona, Spain.

ICEIS 2008 - International Conference on Enterprise Information Systems

312
