AUTOMATIC CLASSIFICATION OF MIDI TRACKS

Alexandre Bernardo and Thibault Langlois

Universidade de Lisboa, Faculdade de Ciˆencias, Departamento de Inform´atica, Portugal

Keywords:

MIDI Track Classiﬁcation, Music Information Retrieval, Neural Networks, k-Nearest Neighbors.

Abstract:

This paper presents a system for classifying MIDI tracks according to six predeﬁned classes: Solo, Melody,

Melody+Solo, Drums, Bass and Harmony. No metadata present in the MIDI ﬁle is used. The MIDI data (pitch

of notes, onset time and note durations) are preprocessed in order to extract a set of features. These data sets

are then used with several classiﬁers (Neural Networks, k-NN).

1 INTRODUCTION

Music Information Retrieval is, nowadays, a highly

active branch of research and development in the

computer science ﬁeld, and focuses on several top-

ics such as beat tracking, music genre classiﬁcation,

melody extraction, score-following, to name a few.

There are a lot of known applications that use

this technology for some extent: the new generation

media players, which organizes music in an intelli-

gent way, based in the music itself, and generates,

for example, dynamic playlists; Internet radio sta-

tions, which builds a playlist based on the user’s taste;

score following; ﬁnding similarities between songs in

a large database.

The work, presented in this paper, focuses on

music stored using MIDI format. Electronic instru-

ments use this format to communicate and synchro-

nize themselves. The format consists in a number

of tracks where each track represents the sequence of

notes (pitch level and duration) played by one instru-

ment. MIDI ﬁles also contain some metadata, such

as the instrumentation or key. One of the advantages

of the MIDI format is its compactness. Many musical

resources using this format are freely available on the

Internet.

Previous work in Music Information Retrieval

using MIDI format includes music genre detection

where several approaches have been proposed. Some

researchers use similarity measures based on Kol-

mogorov complexity estimates in conjunction with a

classical Machine Learning technique like k-Nearest

Neighbors (Ruppin and Yeshurun, 2006), Support

Vector Machines (Li and Sleep, 2004b) or clustering

(Cilbrasi et al., 2004). Cataltepe (Cataltepe et al.,

2007) compares the performance of obtained with

the Normalized Compression Distance approach on

MIDI and audio ﬁles with the ad-hoc features ex-

traction and Machine Learning approach proposed by

McKay (McKay and Fujinaga, 2004).

Other researchers proposed to extract a set of fea-

tures from MIDI ﬁles and perform a genre classiﬁ-

cation using Neural Networks (McKay and Fujinaga,

2004) (Huang et al., 2004) or Support Vector Ma-

chines in conjunction with dimensionality reduction

techniques (Li and Sleep, 2004a). Basili (Basili et al.,

2004) made a comparison of various Machine Learn-

ing techniques on a musical genre classiﬁcation task.

Another approach is to perform automatic melody

detection. Rizo et al. (D. et al., 2006a) (D. et al.,

2006b) has proposed a set of features to characterize

each MIDI track and used a Random Forest classiﬁer

to identify tracks which contain melody. In (Madsen

and Widmer, 2007), an information-theoretic com-

plexity measure and an estimate of the local entropy

are used to recognize melody tracks.

In this paper we address the problem of MIDI

track classiﬁcation. Based on the pitch levels and du-

rations which describe each track, we extract a set of

features that are used to train a classiﬁer. It is im-

portant to note that, in contrast to many other previ-

ously published studies, our approach does not use

any metadata present in the MIDI ﬁle (such as in-

strumentation). Tracks are classiﬁed into six classes:

Solo, Melody, Melody+Solo, Drums, Bass and Har-

mony. Two Machine Learning approaches are com-

pared. The rest of the paper is organized in the follow-

ing way: section 2 describes the data and the different

sets of descriptors and the classiﬁers that were used.

Section 3 reports the experiments and the results ob-

tained. Finally, section 4 concludes and discusses fu-

ture directions of research.

539

Bernardo A. and Langlois T. (2008).

AUTOMATIC CLASSIFICATION OF MIDI TRACKS.

In Proceedings of the Tenth International Conference on Enterprise Information Systems - AIDSS, pages 539-543

DOI: 10.5220/0001708705390543

 SciTePress

2 METHODOLOGY

In order to characterize the musical content from

each track, a vector of numeric descriptors, normally

known as shallow structure description, is extracted.

Then theyare used as inputs for the classiﬁers — Neu-

ral Network and k-Nearest Neighbors — which were

implemented in the Matlab environment. Also, the

MidiToolbox Matlab toolbox was used for handling

the MIDI ﬁles.

2.1 MIDI Track Description

Each MIDI track is characterized by a vector of nu-

meric descriptors, such as pitch, note and silences in-

formation, which summarizes the track musical con-

tent and provides a statistical overview of the track.

Based on other similar works in this area, twenty ﬁve

descriptors, plus twelve more that represent the pitch

intervals histogram, have been deﬁned, and are pre-

sented in Table 1. There are ﬁve descriptors for track

information, used to represent the track as a whole,

and thirty two other descriptors for speciﬁc charac-

teristics, which are subdivided into seven categories.

Normalized values are computed for all descriptors,

except the Intervals Histogram, so there’s a propor-

tional relation between all tracks from the same MIDI

ﬁle.

The ﬁrst category, Track Information, has ﬁve de-

scriptors: duration, the track duration in beats; num-

ber of notes; number of signiﬁcant silences, which

are silences greater than a tick (1/16 beat) - smaller

silences are not considered silences, as they ac-

knowledgments are almost imperceptible and non-

signiﬁcant; occupation rate, which is the proportion

of the track occupied by notes; polyphony rate, a pro-

portion of the track occupied by two or more simul-

taneous notes. Pitch descriptors refer to the actual

MIDI note value, ranging from 0 (C-2) to 127 (G8).

Pitch interval is the difference between two consec-

utive notes, and gives important feedback about the

track melody/harmony progression, namely, in re-

spect to the number of different two-note intervals.

n-grams descriptor also reﬂects the number of differ-

ent pitch intervals, but on a three or four (depending

on the track meter) consecutive notes basis. Note du-

rations descriptors are self explanatory, as Silences

durations, and are computed in beats. Syncopation

is a rhythmic descriptor which reﬂects the number of

notes whose onset is after the beat, normally in be-

tween beats. Syncopation is very frequent in jazz, and

is also an important aspect to consider. Pitch intervals

histograms show the frequency of the intervals semi-

tones, giving valuable information about the musical

scale and the kind of melody, or harmony, of the track.

2.2 Classiﬁers

Two different classiﬁers have been used to train and

test the system, a Neural Network (NN), which is the

main classiﬁer, and k-Nearest Neighbors (kNN) for

comparison purposes and for validating some deci-

sion choices on which descriptors should be used for

best results.

2.2.1 Neural Network

Several Neural Networks (Multi-layer Perceptrons)

were created for these experiments with a number of

hidden units ranging from 40 to 100, in the search

for the best balance between hidden units/computing

time/results. Multi-Layer Perceptrons were trained

using the scaled conjugate gradient algorithm.

2.2.2 K Nearest-Neighbors

k-Nearest Neighbors approach provides very fast re-

sults, given limited data ﬁles, and gives us the capac-

ity to steer the experiments in the right direction.

Table 1: Descriptors.

Category Descriptors

Track Information 1 Duration

(TI) 2 # Notes

3 # Signiﬁcant silences

4 Occupation rate

5 Polyphony rate

Pitch 6 Highest

(P) 7 Lowest

8 Mean

9 Standard Deviation

Pitch Intervals 10 # Different intervals

(PI) 11 Largest

12 Smallest

13 Mean

14 Mode

15 Standard Deviation

Note Durations 16 Longest

(ND) 17 Shortest

18 Mean

19 Standard Deviation

Silences Durations 20 Longest

(SD) 21 Shortest

22 Mean

23 Standard Deviation

Syncopation (S) 24 # Syncopated notes

Repetitions (R) 25 # Different n-grams

Intervals Histogram 26 (0)Perfect Unison

(semitones) 27 (1)Minor Second

(IH) 28 (2)Major Second

29 (3)Minor Third

30 (4)Major Third

31 (5)Perfect Fourth

32 (6)Augmented Fourth,

Diminished Fifth

33 (7)Perfect Fifth

34 (8)Minor Sixth

35 (9)Major Sixth

36 (10)Minor Seventh

37 (11)Major Seventh

ICEIS 2008 - International Conference on Enterprise Information Systems

540

2.3 MIDI File Format

The MIDI format has several ways to organize each

track, and unfortunately, there is no real standard, be-

cause there are numerous ways, MIDI sequencers, to

create a MIDI song, and each MIDI sequencer may

create the MIDI ﬁle in a different way. This can lead

to several problems when interpreting the MIDI (i.e.

all the instruments on the same MIDI track but on dif-

ferent MIDI channels). Rosegarden, an open-source

MIDI sequencer, was used to normalize all the MIDI

ﬁles used in the experiments, so that all share the same

structure.

2.4 Track Selection

A melody track can be interpreted as the leading

voice, an instrument solo or simply a monophonic in-

strument playing its part throughout the song. The

melody which we are interested in, is the leading

voice. In a Jazz song there isn’t always an obvious

melody, but instead, several solos, or a melody and a

solo on the same track. Harmony is, normally, pro-

vided by instruments such as piano, organ, guitar, or

a suite of strings, and are polyphonic, which con-

trasts with melody or solo tracks, which are mostly

monophonic. Harmony tracks may also contain solos,

but these are mostly played in accompaniment with

chords - a pianist soloing with the right hand, accom-

panies himself with the left hand - so it’s harmony

nevertheless. Also, bass and drums are categorized,

mostly because they are evidently different from the

other instruments, and are, individually and together,

very important components in genre deﬁnition. We

present six classes of tracks: Melody; Melody+Solo;

Solo; Harmony; Bass; Drums. Tracks which don’t ﬁt

in these classes are discarded.

2.5 Music Corpora

Two MIDI Music Corpora were assembled for the

experiments, as depicted in Table 2, from only one

genre, Jazz, as it incorporates the most common prob-

lems in identifying the different components of a

song: jazz hasn’t obvious singing voice melodies, has

various solos on several tracks and most songs have

enough instruments to populate our six classes with

different data. This gives us enough different issues

to solve in the descriptor extraction and classiﬁcation

methods. As the name implies, the neural networks

were trained using the “training” set, and tests using

the “test” set.

This music corpora is available for download at

http://www.di.fc.ul.pt/

tl/ICEIS2008/

Table 2: Music Corpora.

Corpus Jazz (training) Jazz (test)

# Files 40 43

# Tracks 239 252

Melody 37 41

Melody + Solo 23 18

Solo 23 22

Harmony 62 71

Bass 39 43

Drums 39 43

3 EXPERIMENTS

Early experiments showed that using all descriptors

gives poor results, leading us to experiment with one

descriptor category at a time, such as Pitch or Notes,

or a combination of two categories. This approach

led us to another problem. Which category combina-

tion was better? And which single descriptor combi-

nation? Testing every possible combination couldn’t

even be an hypothesis, for a very large number of

combinations can be made out of all the thirty seven

single descriptors.

A very simple algorithm solved the problem. The

set of descriptors is built by testing each descriptor

individually and joining iteratively more descriptors

to the set while the performance increases. Section

3.3 shows some results obtained with different sets of

descriptors.

The Matlab environment was used to implement

the system and to perform the experiments. An addi-

tional toolbox was used, the MidiToolbox for helping

with the handling of MIDI ﬁles in the Matlab environ-

ment. Matlab was chosen because it already sports a

vast array of functions, classiﬁers, graphics, plots, etc,

which help in analyzing the MIDI ﬁles.

3.1 Track Selection: All Descriptors

In the ﬁrst set of experiments, all thirty seven de-

scriptors were used, which proved to be a naive ap-

proach. Several NN were used, with hidden units

ranging from 40 to 80, and they all presented basi-

cally the same results, varying only in 3%, so the best

network was used, with 80 hidden units. kNN best k

value was 7. The confusion matrices obtained with

both methods are shown in tables 3 and 4.

Table 3: Confusion Matrix. NN: all descriptors. Classiﬁca-

tion Rate: 67,8%.

Melody 9 2 6 17 7 0

Melody+Solo 0 3 6 8 1 0

Solo 0 3 15 4 0 0

Harmony 0 0 5 61 3 2

Bass 0 0 0 1 42 0

Drums 0 0 0 1 1 41

AUTOMATIC CLASSIFICATION OF MIDI TRACKS

541

Table 4: Confusion Matrix. k-NN: all descriptors. Classiﬁ-

cation Rate: 71,8%.

Melody 23 5 3 8 2 0

Melody+Solo 2 6 5 5 0 0

Solo 2 5 15 0 0 0

Harmony 5 3 1 57 3 2

Bass 1 1 0 2 39 0

Drums 0 0 1 1 0 41

k-NN gave slightly better results than NN, but not

a signiﬁcant beneﬁt. Using all descriptors, is a naive

approach, because some descriptors may successfully

distinguish between two different classes, but another

descriptor may distinguish the same classes in an op-

posite way, and confuse the ﬁnal classiﬁcation.

Notice the high score in Harmony, Bass and

Drums, this is mostly because these tracks are quite

different from each other, and specially from the other

three classes. Harmony is polyphonic, as are mostly

Drum tracks, in contrast to melody or solo tracks

which are monophonic. Bass is also monophonic

but usually has a lower pitch than melodies or solos,

which makes it easy, for the classiﬁer, to distinguish.

It seems that the real problem is classifying Melody

and Solo, as these are quite similar, and may be con-

fused with Melody+Solo class.

3.2 Track Selection: Single Descriptor

Category

A different approach was used in the following ex-

periments. Instead of using the full set of descriptors,

six sets of descriptors were used, corresponding to the

descriptor categories, and also some combinations of

the best scoring sets. Both networks used, with hid-

den units set to 80 for NN, and k values ranging from

1 to 29 for kNN, using the best value achieved. The

results are shown in table 5.

With NN, surprisingly, the TI set alone provided

better results than the whole set of descriptors. Also,

the TI+P set provided the best results so far! All the

other sets yielded worse results and are clearly con-

fusing the classiﬁer, and should not be used, at least

not in this naive way. The kNN results, using set TI,

Table 5: Single Categories Classiﬁcation Rates.

Set NN Rate(%) k-NN Rate(%)

TI 71,8 63,8

P 56,7 53,9

PI 50,4 44,4

ND 50,4 42

SD 31,3 30,9

S 38,8 37,6

R 42 40,5

IH 47,2 36,9

TI+P 75,4 71,8

P+PI 63 48,8

were worse than those achieved when using the full

set of descriptors, but using TI and P combined gave

similar results. As in NN, all the other categories gave

worse results. These results proved that the descrip-

tors have to be carefully selected, not only by com-

bining categories, but combining single descriptors,

in order to achieve the best results.

3.3 Track Selection: Best Descriptors

Using the algorithm described previously a possible

best descriptor set was found. The best set is com-

posed of descriptors [1 2 4 5 7 8 9 15 18 24 31 34]

(numbers are correspondent to table 1) for NN using

60 hidden units, and [3 4 5 6 7 8 9 11 13 18 19 24 25

31 33] for kNN with k = 5. It’s clearly obvious that

using a whole category is not the best option. Instead,

using only the descriptors that work better together.

For NN, which is the main classiﬁer, a signiﬁcant 16%

gain was achieved comparing with the full descriptor

set.

As we can see, only the descriptor #3 was not cho-

sen from the TI set, which makes sense, as it was the

set that provided the best results alone. From the P

set, Highest Pitch was not chosen, but Lowest Pitch

was, as it’s used for classifying the bass tracks. From

the PI set, only the Standard Deviation was used and

from the ND set, only Mean was chosen. The SD set

was ignored by the algorithm, which means that the

silences are not signiﬁcant and could be discarded. S

was also chosen, meaning that the rhythm is also an

important feature in distinguishing between classes.

The descriptors chosen from the IH set, were “Per-

fect Fourth” and “Minor Sixth”. According to music

theory, there intervals are one of the most consonant,

because they have simple pitch relationships resulting

in a high degree of consonance, which is perfect for

distinguishing between, for example, a simple slow

Melody or a fast complicated Solo.

In respect to the confusion matrix, all the misclas-

siﬁed tracks make sense. A melody track is similar to

a bass track, although it has higher pitches. In fact,

that one misclassiﬁed bass track has higher pitches

as well. The Melody+Solo class is the worst per-

forming, mainly because a solo can be made of sev-

eral melodies, or even harmony at some point, and

be misclassiﬁed. More training data would deﬁnitely

improve the performance on this class.

ICEIS 2008 - International Conference on Enterprise Information Systems

542

Table 6: Confusion Matrix. NN: best descriptors. Classiﬁ-

cation Rate: 83,7%.

Melody 31 4 2 4 0 0

Melody+Solo 2 13 1 1 1 0

Solo 0 4 17 1 0 0

Harmony 2 0 0 69 0 0

Bass 0 1 0 0 42 0

Drums 0 0 2 1 1 39

Table 7: Confusion Matrix. KNN: best descriptors. Classi-

ﬁcation Rate: 77,3%.

Melody 28 4 3 4 2 0

Melody+Solo 2 10 5 1 0 0

Solo 4 2 14 1 1 0

Harmony 5 1 3 60 1 1

Bass 0 0 0 0 43 0

Drums 0 0 1 1 1 40

4 CONCLUSIONS AND FUTURE

WORK

An Automatic Classiﬁcation of Midi Tracks system

has been implemented and presented. It uses MIDI

ﬁles from a single genre, Jazz, and classiﬁes the tracks

in six classes, Melody, Melody+Solo, Solo, Harmony,

Bass and Drums. A neural network is used to process

thirty seven descriptors extracted from each MIDI

track, which has been previously tagged in the six

classes. The experiments showed that using all de-

scriptors is a wrong approach, as there are descriptors

which confuse the classiﬁer. Using carefully selected

descriptors proved to be the best way to classify these

MIDI tracks. Future work, under research now, in-

cludes using a larger MIDI database, testing new gen-

res, such as Rock, Pop or Classical, to prove the sys-

tems reliability between all genres, so that it can be

used as a crucial part of a larger musical genre clas-

siﬁcation system. Having the tracks identiﬁed, as we

have presented here, allows different processing spe-

cialized to each class.

ACKNOWLEDGEMENTS

This work was supported by EU and FCT, through

LaSIGE Multiannual Funding Programme.

REFERENCES

Basili, R., Seraﬁni, A., and Stellato, A. (2004). Classiﬁca-

tion of musical genre: a machine learning approach.

In ISMIR.

Cataltepe, Z., Yaslan, Y., and Sonmez, A. (2007). Music

genre classifcation using midi and audio featres. Jour-

nal on Advances in Signal Processing, 2007.

Cilbrasi, R., Vit´anyi, P., and de Wolf, R. (2004). Algorit-

mic clustering of music based on string compression.

Computer Music Journal, 29(4):49–67.

D., R., de Le´on P. J., P., C., P.-S., and Pertusa A., I. J. M.

(2006a). A pattern recognition approach for melody

track selection in midi ﬁles. In Dannenberg R., Lem-

str¨om K., T. A., editor, Proc. of the 7th Int. Symp. on

Music Information Retrieval ISMIR 2006, pages 61–

66, Victoria, Canada. ISBN: 1-55058-349-2.

D., R., de Le´on P.J., P., and Pertusa A., I. J. (2006b).

Melodic track identiﬁcation in midi ﬁles. In Proc. of

the 19th Int. FLAIRS Conference. AAAI Press. ISBN:

978-1-57735-261-7.

Huang, Y.-P., Guo, G.-L., and Lu, C.-T. (2004). Using back

propagation model to design a midi music classiﬁca-

tion system. In International Computer Symposium,

pages 253–258, Taipei, Taiwan.

Li, M. and Sleep, R. (2004a). Improving melody classiﬁ-

cation by discriminant feature extraction and fusion.

In Proc. of the 5th Int. Symp. on Music Information

Retrieval ISMIR 2004.

Li, M. and Sleep, R. (2004b). Melody classiﬁcation using a

similarity metric based on kolmogorov complexity. In

Sound and Music Computing, Paris, France.

Madsen, S. T. and Widmer, G. (2007). A complexity-based

approach to melody track identiﬁcation in midi ﬁles.

In International Workshop on Artiﬁcial Intelligence

and Music (MUSIC-AI 2007), Hyderabad, India.

McKay, C. and Fujinaga, I. (2004). Automatic genre classi-

ﬁcation using large high-level musical feature sets. In

ISMIR.

Ruppin, A. and Yeshurun, H. (2006). Midi music genre

classiﬁcation by invariant features. In ISMIR, pages

397–399.

AUTOMATIC CLASSIFICATION OF MIDI TRACKS

543
