A QVT-BASED APPROACH FOR MODEL COMPOSITION

Application to the VUML Profile

Adil Anwar

1,3

, Sophie Ebersold

, Mahmoud Nassar

, Bernard Coulette

and Abdelaziz Kriouile

University of Toulouse, IRIT ;UT2 ; 5 allées A. Machado, F-31058 Toulouse, France

SI2M laboratory, ENSIAS, BP 713 Agdal, Rabat, Maroc

LRIMIARF laboratory, Université Mohammed V-Agdal, Faculté des sciences, Rabat, Maroc

Keywords: Model composition, VUML Profile, Viewpoints, Transformations, Correspondences, translation and

composition rules, QVT-Core standard.

Abstract: With the increasing importance of models in software development, many activities such as transformation,

verification and composition are becoming crucial in the field of Model Driven Engineering (MDE). Our

main objective is to propose a model-driven approach to compose design models. This approach is applied

to the VUML profile that allows to analyse/design a system on the basis of functional points of view. In this

paper we first describe a transformation-based composition process and then we specify transformations as

a collection of QVT-Core rules implemented in ATL. The proposal is illustrated by a simple example.

1 INTRODUCTION

In the context of increasing complexity of

Information Systems, the composition of models is a

challenging and recurring activity. To cope with

composition of UML models developed separately,

we have been using the VUML (View Based UML)

profile which allows to put into action a view-based

analysis/design. Our global objective is to formalise

and implement the model composition activity

(called “model merging” in VUML) by means of the

Model Driven Architecture (MDA) (Soley et al.,

2000) features, and to apply it to VUML.

Model driven approaches have been focusing

mainly on the definition of languages and tools

allowing the implementation of operations on

models, such as transformations (Jouault et al.,

2005) (OMG, 2007) or verification (Nébut et al.,

2006), etc. Several research works deal more

specifically with model composition in such

domains as Aspect Oriented Modelling (Reddy el

al., 2006) (Baniassad et al., 2004) or Requirements

Engineering (Sabetzadeh et al., 2005) (Chitchyan et

al., 2007). An emerging approach has proposed

generic operators and mechanisms to reuse design

knowledge of composition operators (Fleurey et al.,

2007). These approaches do not consider

composition as a MDA transformation.

However, composition should concern MDA

approach since it is addressed in the context of

Domain Specific Languages (DSL) and

implemented in programming languages such as

Java, or with transformation languages such as ATL

(Jouault et al., 2005). We think that a more abstract

and generic approach for specifying models

composition (and specially merging) as a MDA

activity is needed. Such models composition should

be independent of any specific DSL. Therefore, we

strongly believe that it lacks a shared definition of

composition as a MDA operation for combining

models.

In the present paper, we show how a composition

operation can be specified using the transformation

technology based on the QVT (Queries, Views,

Transformations) standard (OMG, 2007). More

precisely, we define the composition transformation

as a set of declarative rules described with the QVT-

Core language, which is the basic infrastructure of

the declarative part of QVT. There are significant

benefits to use QVT-Core for this purpose: (i) the

QVT-core language allows the rules developer to

declaratively specify transformation rules (which,

also, can be bidirectional), and to check the structure

of the involved models. Thus, the developer can put

the emphasis on rules specification, rather than on

rules execution and sequencing ; (ii) model patterns

360

Anwar A., Ebersold S., Nassar M., Coulette B. and Kriouile A. (2008).

A QVT-BASED APPROACH FOR MODEL COMPOSITION - Application to the VUML Proﬁle.

In Proceedings of the Tenth International Conference on Enterprise Information Systems - ISAS, pages 360-367

DOI: 10.5220/0001710203600367

 SciTePress

can be described in a graphical way similarly to

UML object diagrams; this kind of representation

makes the transformation rules quite easy to

understand and to edit (Lohmann et al., 2007).

This paper addresses the following contributions:

 a generic composition process for merging

UML design models. This process is applied

to VUML profile;

 a models composition activity described in

QVT-Core to graphically specify model

transformations based on declarative rules.

The paper is organised as follows: section 2

introduces the VUML methodology to analyse and

design model software systems with a user centred

approach. Section 3 describes main steps of a

composition process. Section 4 illustrates our

approach with a simple example. In section 5, we

specify the transformation rules in QVT-Core thanks

to a graphical notation. Section 6 considers related

works, and the last section discusses the

contributions of this paper and some perspectives.

2 ANALYSIS/DESIGN

APPROACH IN VUML

2.1 Principles of VUML Profile

The VUML profile (View based Unified Modelling

Language) was developed to meet the needs of

modelling complex information systems with UML

according to various points of view. A point of view

(called viewpoint in VUML) on the system

represents an actor’s requirements and rights. Such

viewpoints may be considered as functional aspects.

The main concept of VUML language is the

multiview class, which is composed of a base class

(shared by all viewpoints), and a set of view classes

(extensions of the base class), each view class being

specific of a given viewpoint. VUML’s semantics is

described by a metamodel, a set of well-formed rules

expressed in OCL (OMG, 2003b), and a set of

textual descriptions in natural language. On the

methodological level, a process allows us to analyse

and design software systems with respect to

viewpoints. A code generator was developed to

derive Java code from VUML class diagrams.

2.2 Analysis and Design Process

Associated to VUML

The VUML analysis/design process is led by a set of

designers who have specific viewpoints. The process

is decomposed into five phases (figure 1):

 Analyse Actor’s Requirements. During this

phase, actors are identified and their

requirements are described in terms of

activities and use cases. Each actor is

associated with a viewpoint.

 Define a Common Domain Glossary.

This phase is a general and preliminary

analysis aiming at defining the basic concepts

which represent the business domain of the

application. At the end of this phase, a

common glossary of the system is established

and shared by all the designers.

 Design Viewpoint Models. The aim of this

phase is to produce a set of design models

according to specific viewpoints. Each

viewpoint model may be designed in parallel

with the others.

 Analyse Conflicts. During this phase,

representation conflicts, such as naming

conflicts and structural conflicts are detected

and resolved. While naming conflicts are

solved through renamings into the design

models, structural conflicts are solved by

applying heuristics allowing a semi-automatic

resolution method.

 Compose Viewpoint Models. The last phase is

a composition operation; it consists in

merging design models developed separately

in order to obtain a global VUML design

model. In the following sections, we will

focus on this phase.

Figure 1: VUML Analysis and Design Process.

A QVT-BASED APPROACH FOR MODEL COMPOSITION - Application to the VUML Profile

361

3 COMPOSITION PROCESS

3.1 Composition Steps

In order to provide a complete automatic solution for

model composition, we reuse existing researches

(Kolovos et al., 2006) (Fleurey et al., 2007) which

have demonstrated that designing a model

composition operator can be done through two

separate operators: a correspondence operator and a

merging operator. Thus, our composition process is

composed of three main steps called

correspondence, merging and analysis.

Correspondence. It consists in identifying the

set of correspondences between models to be

composed. This activity is governed by

correspondence rules which specify the strategy of

comparison between model elements. The

comparison of elements is based on syntactic

properties defined at the metamodel level. For

example, the syntactic properties of a UML class are

represented by the set {name, isAbstract,

ownedAttribute,ownedOperation} that are properties

of the metaclass Class in the UML metamodel

(OMG, 2003a). A correspondence rule, applied to

two elements describing the same concept, creates a

link between those elements called correspondence

relationship. Correspondence relationships are

stored into a separate model called correspondence

model. The correspondence step is summarized in

Figure 2.

Figure 2: Step 1 of Composition: Elaboration of the

correspondence model.

Merging. The merging step of the process

depends on the target metamodel. In our application

context, this step produces a VUML model. It

creates VUML elements from source elements of the

correspondence model according to the type of

correspondence relationships which relate them. The

strategy for merging two model elements is specified

by a merging rule. Elements which have no

correspondent in the opposite model are simply

translated into the VUML model with respect to

translation rules. The merging step is summarized in

Figure 3.

Figure 3: Step 2 of Composition: Creation of the resulting

VUML Model.

Analysis. The last step of the composition process is

an analysis activity that aims to supress composition

errors, Thus the produced VUML model can be

analyzed according to well-formedness rules defined

in the VUML profile. The analysis strategy is similar

to the one defined in (Bézivin et al., 2005); it allows

to generate a diagnosis model which conforms to a

diagnosis metamodel.

3.2 MDA-based Models Architecture

MDA proposal is a conceptual framework for

system modelling organized in four levels of

abstraction. We use this framework to describe the

interactions among models and metamodels

involved in our composition process. In Figure 4

below, we show only the three higher levels. The

M1 level is dedicated to models that are conceptual

abstractions of real word objects (M0). QVT

transformations and VUML class diagrams are, thus,

considered as models. At the M2 level, we find the

concept of metamodel. Metamodels are models of

languages which allow us to describe the models

involved in M1 level. Four metamodels are to be

considered in our approach: UML2 metamodel,

Correspondence metamodel, VUML metamodel,

and QVT metamodel. We proposed in a precedent

work (Anwar et al., 2007b) a kernel of a

Correspondence metamodel. It contains an abstract

metaclass called CorrespondenceRelationship which

is specialized according to the semantics of bindings

between elements. Due to space limitation, we do

not describe here this correspondence metamodel.

The M3 level of this framework is composed of

the metametamodel MOF2.0 which is able to

describe itself (meta-circularity).

ICEIS 2008 - International Conference on Enterprise Information Systems

362

Figure 4: MDA-based models architecture.

4 EXAMPLE

To illustrate how the transformation rules are

applied on models, we consider a simple example

which particularly describes a weighted point

through the WPoint class designed according to two

viewpoints. The first viewpoint represents a

weighted point with respect to its Cartesian

coordinates. We consider also the class Segment

which is composed of two weighted points and a

length method to calculate the Euclidian distance

between the two points. Figure 5 shows the resulting

design model elaborated with the Cartesian

viewpoint.

Figure 5: The Cartesian Viewpoint design model.

Let us consider now another viewpoint that

identifies a weighted point object by its polar

coordinates. A set of points forms a Disk which is

represented by a radius and a method to calculate for

example the perimeter of the Disk. Figure 6 shows

the resulting design model elaborated with the Polar

viewpoint.

Figure 6: The Polar Viewpoint design model.

The design models described above have to be

composed to build the global view of the system.

This operation is necessary for checking the global

consistency of the system’s model, or for analyzing

interactions across the composed views (Fleurey et

al., 2007).

The VUML merging scenario, illustrated in

Figure 7, can be achieved as follows: the class

Segment is the same in both design models.

Therefore, it is merged as one class Segment in the

VUML model. The class Disk exists in the Polar

viewpoint model only; so it is translated as the

multiview class Disk which has a base and one Polar

view. The class WPoint appears in both design

models with distinct descriptions; thus it is translated

as the multiview class WPoint: the shared elements

like weight and distance are placed into the base,

whereas specific coordinates are put into Cartesian

and Polar views.

Figure 7: The VUML Design model.

In the following section, we will use those two

viewpoint design models and the VUML resulting

model to illustrate the application of transformation

rules in the composition process.

A QVT-BASED APPROACH FOR MODEL COMPOSITION - Application to the VUML Profile

363

5 QVT TRANSFORMATION

RULES

Our model composition strategy is governed by

three categories of transformation rules:

correspondence, composition and translation rules.

This enables us: first to establish correspondences

between input models, second to merge these

models in order to produce the global model.

As justified in the introduction (Section 1) of this

paper, we have adopted the QVT standard to

describe the transformation rules that govern our

composition process. More precisely, we specify

rules in the QVT-Core language (OMG. 2007) with

a graphical representation defined in (Greenyer et

al., 2007). This notation is similar to that of UML

object diagrams, that is convenient to identify both

source and target patterns of transformation rules.

This section presents these three kinds of rules.

To illustrate them, we consider the two design

viewpoint models of the example described in

Section 3 above.

5.1 Correspondence Rules

This category of rule focuses on identifying all

possible relationships between source model

elements. In this aim, the compares the meta-

properties values defined in metamodel constructs.

This operation is showned in the guard condition of

the rule. That means that the relationship between

source elements holds (creating a correspondence

relationship which relates the two source model

elements) only when the guard condition is

evaluated to true.

According to the semantics of correspondence

which exists between two model elements, there are

different types of relationships. For example, for

class elements, we have identified two

correspondence relationships: similarity and

conformity. Conformity holds when two classes

appear with the same name and are semantically

equivalent (represents two views of the same

concept), and when they have the same properties

(attributes, operations, associations, etc.).

The transformation rules in QVT-Core language

are called mappings; a single mapping is composed

of several types of patterns. For example, the

mapping AttributesToE

quality (Figure 8) is

structured in four columns. The first three columns

contain the patterns of the involved models, and the

last one contains the mapping nodes, called also

trace objects that reference nodes of the domain

patterns.

Figure 8: The AttributesToEquality mapping.

This rule shows the case where two attribute

elements of source models having two

corresponding types and defined in two distinct

classes sharing the same name are related by an

EqualityRelationship.

The mappings ClassesToConformity and

DataTypesToEquivalence are called top mappings

because they specify the context of the mapping

AttributesToEquality. Hence, they are placed in the

guard pattern of this mapping. They are considered

as preconditions of the rule.

To start the transformation, the guard patterns are

matched in the source models, and then the target

model elements are created. In this case, a

ConformityRelationship element and an

EquivalenceRelationship element are created in the

target model. Later, the pattern in the bottom area of

the mapping AttributesToEquality is searched in the

source models when the required precondition

pattern is true, the context of the mapping can be

applied. Finally, the EqualityRelationship element is

created in the target model.

Given our example about weighted points, an

EqualityRelationship is created in the

Correspondence model to link both weight attributes

of viewpoint models (Figures 5 and 6).

5.2 Composition Rules

The second category of transformation rules

regroups the composition rules; it consists in

building new model elements from elements related

by correspondence relationships.

To start this composition activity, the

composition operator looks for the set of elements

that match in the correspondence model and creates

a new model element in the target model with

respect to the semantics of the correspondence

relationship. Indeed, the composition strategy

depends on the nature of relationships. For example,

if two class elements are related by a

ConformityRelationship, the composition strategy

consists of merging these classes that is to create in

ICEIS 2008 - International Conference on Enterprise Information Systems

364

the target model a class that represents a deep copy

of the sources classes.

Figure 9 shows a QVT-Core rule that describes

how two classes related by a similarity relationship

are composed to build a multiview class in the

VUML model.

Figure 9: The QVT-Core SimilarityComposition rule.

To apply this rule, the top mapping described in

the guard pattern must hold first so that a VUML

model could exist. When the guard is true, the

context of the rule SimilarityToMultiviewClass is

available and so, the bottom pattern is searched in

the source model and matched. Then, a multiview

class is created in the target model for each

similarity relationship found in the correspondence

model.

Let us consider our example about weighted

points. A SimilarityRelationship was created about

WPoint during the Correspondence step.

Henceforth, a multiview class is created with a base

and two views in the VUML target model (figure 7).

5.3 Translation Rules

As composition rules, translation rules produce also

elements in the target model. The main difference

between them is that translation rules consider only

elements for which no correspondent has been found

in the opposite model. In case where the default

translating strategy is applied, the source elements

are deeply copied into the target model.

Alternate translation strategies must be used in

some situations depending on the target metamodel.

For example, if we apply the default translation

strategy to the Disk class (Figure 6), this class will

appear in the VUML model as a normal UML class

which may be lead to an inconsistency because this

class should be accessible only from the polar

viewpoint. To resolve this problem, the translation

rule has to create a multiview class as target element

with a base and one Polar view (Figure 7). In this

way, it is possible to access to the WPoint class only

through the PolarDisk view, that consistent with the

Polar viewpoint model (Figure 6). The rule

described below expresses this translation strategy.

Figure 10: The QVT-Core Class2MultiviewClass

Translation rule.

Let us consider again our example about

weighted points. Class Disk appears only in the

Polar viewpoint model, thus, it is translated into the

VUML model as a multiview class of same name

with one Polar view (figure 7).

6 RELATED WORKS

A number of researchers have developed model

composition known also as model merging

approaches in different application domains:

requirements engineering (Sabetzadeh et al., 2005),

Aspect Oriented Modelling (Baniassad et al., 2004)

(Reddy et al., 2006), Schema integration (Eder et al.,

1994), Ontology merging (Noy et al., 2000). We will

focus in the rest of this section on works that are

close to our approach.

Reddy et al (Reddy et al., 2006) propose

directives for model composition in aspect oriented

design. The objective is to compose a set of aspect

models which encapsulate crosscutting concerns

(persistence, security, etc) with a primary model

which represent the functionalities of a software

system. This approach can be classified as

imperative because it describes the operation of

composition in an algorithmic way. Therefore, it is

not easily compatible with our approach based on

declarative rules which rather specify what should

be transformed instead of how it should be done.

The EML language (Epsilon Merging Language)

proposed by (Kolovos et al., 2006) is a rule based

language for merging models. The tool support of

EML was developed as an Eclipse plugging. EML

belongs to the Epsilon platform (Epsilon, 2006),

which is a model driven framework for developing

integrated languages for model management tasks

such as model comparison, model transformation,

model validation, etc. The comparison strategy in

EML is similar to ours. But contrary to EML, our

approach considers the result of the correspondence

step as a model that is the input of the merging step.

A QVT-BASED APPROACH FOR MODEL COMPOSITION - Application to the VUML Profile

365

The Atlas Model Weaver (AMW) (Del Fabro et

al., 2005) is a model composition framework that

uses model weaving and model transformation to

define and execute composition operation. The tool

support is available as an open source deliverable of

Eclipse GMT (EclipseGMT. 2005). This technique

has the advantage of being generic and flexible

thanks to the extension mechanism of the weaving

metamodel; however, the manual definition of the

links between model elements is a tedious work.

Other works such as (Yahyaoui et al., 2005)

(Romero et al., 2006) focus on the definition of

viewpoints correspondences in the context of the

RM-ODP standard (ISO, 2005). These authors relate

viewpoints through explicit links for change

management and propagation. But contrary to them,

we also use such links to merge viewpoint models as

shown above in this paper.

7 DISCUSSION AND

CONCLUSIONS

In this paper, we have presented a QVT-based

approach to specify rules to compose models

developed separately. We adopted QVT because it is

the OMG standard recommended for specifying

MDE transformations. We used the QVT-Core

language which represents the basic infrastructure of

the declarative part of QVT. In addition, we adopted

the graphical notation proposed by (Greenyer et al.,

2007).

Compared to our previous works (Anwar et al.,

2007b) the main benefit of this study is to use a

standardized language to express composition as

declarative transformation rules at a high level of

abstraction. Thus, the rules designer may

concentrate himself on the definition of rules rather

than on their sequencing.

Our approach has been applied to the VUML

profile which allows to produce view-based models

separately and merge them into a unique multiview

model. We experimented it on a significant case

study describing the view-based design of a Shared

Medical File Sytem (Anwar et al., 2007a).

To validate our work, we have implemented the

operations (QVT transformations) in ATL (Jouault

et al., 2005) which is considered here as an

implementation of the QVT standard. It is also a

standard component in Eclipse, now integrated into

the M2M project (Eclipse, 2007).

In the near future, we intend to extend our

approach in several ways:

• Enrich our composition rules metamodel

(Anwar et al., 2007a) so as to separate target

model-independent rules from target model-

dependent rules. Concretely, we have already

identified generic composition rules which are

reusable in any model composition strategy

and specific rules for the VUML DSL. We

intend to integrate this hierarchy into a well-

defined metamodel.

• Enlarge the kinds of source models: we

should compose not only UML models

resulting from decentralized modelling with

UML, but also VUML models previously

composed through the VUML process.

• Integrate behavioural diagrams of UML

(mainly state charts or activity diagrams) into

the VUML profile so as to cover dynamic

aspects of system design.

• Cope with compositional conflicts as follows:

(i) semantics conflicts due to homonymy and

synonymy at the analysis level. To solve them

in automatic ways, one can reuse dedicated

techniques coming from database community

(Geller et al., 1992) or ontology-based works

(Noy et al., 2000); (ii) structural conflicts at

the design level. These types of conflicts may

be solved through refactoring techniques but

so far they are difficult to automate.

ACKNOWLEDGEMENTS

This work was partially supported by the COMPUS

Project MA/06/151, PAI VOLUBILIS 2006.

REFERENCES

Anwar, A., Ebersold, S., Coulette, B., Nassar, M.,

Kriouile, A., 2007a. Une approche MDA pour

produire un modèle VUML par intégration de modèles

par points de vue. In Proceedings of (IDM’2007),

Toulouse France, Hermès Science, pp 41-58.

Anwar, A., Ebersold, S., Coulette, B., Nassar, M.,

Kriouile, A., 2007b. Vers une approche à base de

règles pour la composition de modèles : application au

profil VUML. Revue RSTI-L’Objet. vol.13- n°4/2007,

pp 73-103.

Baniassad, E., Clarke, S., 2004. Theme: An Approach for

Aspect-Oriented Analysis and Design. In Proceedings

of ICSE'04 (Int. Conference in Software Engineering),

p. 158-167. Edinburgh, Scotland.

Bézivin J., Jouault F., 2005. Using ATL for Checking

Models. In proc. of the International Workshop on

ICEIS 2008 - International Conference on Enterprise Information Systems

366

Graph and Model Transformation (GraMoT), Tallinn,

Estonia. 2005.

Del Fabro, MD., Bézivin, J., Jouault, F., Breton, E.,

Gueltas, G., 2005. AMW: a generic model weaver.

Dans 1ère Journée IDM’05. Paris, France, p. 105-114.

Eclipse GMT Project Web Page.

http://www.eclipse.org/gmt/amw/, 2005.

Eclipse/M2M Project Web Page .

http://www.eclipse.org/m2m/, 2007.

Eder, J., Frank, H., 1994. Schema Integration for Object

Oriented Database Systems. Published in: Tanik M.,

Rossak W., Cooke D. (eds.): Software Systems in

Engineering, ASME, PD-Vol. 59, pp. 275-284.

EpsilonSubProject2006.

http://www.eclipse.org/gmt/epsilon/.

Fleurey, F., Baudrey, B., France, R., Ghosh, S., 2007. A

Generic Approach For Model Composition. In

Proceedings of the Aspect Oriented Modeling.

Workshop at Models 2007. Nashville USA.

Geller, J., Perl, Y., Neuhold, E., Sheth, A., 1992.

Structural Schema Integration with full and partial

correspondence using the Dual Model, Information

Systems, Vol. 17, No. 6, 1992, pp. 443-464.

Greenyer, J., 2006. A Study of Model Transformation

Technologies - Reconciling TGGs with QVT.

University of Paderborn, Department of Computer

Science, Master/Diploma thesis.

Greenyer, J., Kindler, E., 2007. Reconciling TGGs with

QVT. G. Engels et al. (Eds.): MoDELS, LNCS 4735,

pp. 16-30.

ISO/IEC CD 19793, ITU-T Rec. X.906 (2005).

Information technology – Open distributed processing

– Use of UML for ODP system specifications. ISO &

ITU-T.

Jouault, F., Kurtev, I., 2005. Transforming Models with

ATL. In Proceedings of the Model Transformations in

Practice, Workshop at Models. Montego Bay, Jamaica

2005.

Kolovos, DS., Paige, RF., Polack, FAC., 2006. Merging

Models with the Epsilon Merging Language (EML).

In Proc. ACM/IEEE 9th International Conference on

Models/UML), Genova, Italy, October.

Lohmann, C., Greenyer, J., Jiang, J., Systâ, T., 2007.

Applying Triple Graph Grammars For Pattern-Based

Workflow Model Transformations. In Journal of

Object Technology, Special Issue: Tools EUROPE,

October 2007. pp 253-273.

http://www.jot.fm/issues/issue_2007_10/paper13/.

Nassar M., Coulette B., Crégut X., Ebsersold S.., Kriouile

A., 2003. Towards a View based Unified Modeling

Language. Proc. of 5th International Conference on

Enterprise Information Systems (ICEIS’2003), Angers,

France.

Nébut C., Fleurey, F., Le Traon, Y., Jézéquel, JM., 2006.

Automatic test generation: A use case driven

approach. IEEE Transactions on Software

Engineering, 32(3):140--155, March.

Noy, N., Musen, M., 2000. PROMPT: Algorithm and Tool

for Automated Ontology Merging and Alignment. In

proc. Of AAAI/IAAI, pp 450–455.

OMG 2003a, UML 2.0 Superstructure Final Adopted

specification,Document-ptc/03-08-02,

http://www.omg.org/docs/ptc/03-08-02.pdf.

OMG 2003b, UML 2 OCL Final Adopted Specification,

2003. http://www.omg.org/docs/ptc/03-10-14.pdf.

OMG 2007. OMG: (MOF2).0 QVT Final Adopted

Specification.http://www.omg.org/docs/ptc/07-07-

07.pdf.

Reddy, Y. R., Ghosh, S., France, R. B., Straw, G.,

Bieman, J. M., McEachen, N., Song, E., Georg, G.,

2006. Directives for Composing Aspect-Oriented

Design Class Models. Transactions of Aspect-

Oriented Software Development, Vol.1, No. 1, LNCS

3880, p75-105, Springer.

Romero, R., Moreno, N., Vallecillo, A., 2006. Modeling

ODP Correspondences using QVT. In MDEIS 2006,

Paphos, Cyprus, pp. 15-26.

Sabetzadeh, M., Easterbrook, S., 2005. An Algebraic

Framework for Merging Incomplete and Inconsistent

Views. In 13th IEEE International Requirements

Engineering Conference, September 2005.

Soley et al., 2000. MDA Model Driven Architecture,

Object Management Group White Paper, Draft 3.2 -

November 27.

Yahiaoui, N., Traverson, B., and Levy, N. 2005.

Adaptation management in multi-view systems. In

Proc. of the 2nd International Workshop on

Coordination and Adaptation Techniques for Software

Entities (WCAT’05), pages 99–105, Glasgow,

Scotland, UK.

A QVT-BASED APPROACH FOR MODEL COMPOSITION - Application to the VUML Profile

367
