AN EVALUATION INSTRUMENT FOR LEARNING OBJECT
QUALITY AND MANAGEMENT
Erla M. Morales Morgado
1
, Francisco J. García Peñalvo
2
and Ángela Barrón Ruiz
1
1
Department of Theory and History of Education
University of Salamanca, Pº de Canalejas, 169, 37008, Salamanca, Spain
2
Department of Computing Science, University of Salamanca, Plaza de los Caídos, S/N, 37008, Salamanca, Spain
Keywords: Metadata, learning objects, knowledge management.
Abstract: Being able to evaluate the quality of LOs is crucial for reliable LO management. LO quality evaluation must
take into account both their pedagogical and the technical characteristics. It also needs to consider them as
units of learning and to determine their level of granularity (size). This paper describes a proposal for a
specific LO quality evaluation instrument and presents the results of its assessment by a panel of experts.
1 INTRODUCTION
Information represents one of the world’s most
important sources of power today, and Internet
growth is geared to promoting better services that
will enable users to find and retrieve the information
they really need.
The concept of learning objects (LOs) was
devised in order to manage and reutilize existing e-
learning resources without interoperability problems.
However, the capacity of LOs to achieve that goal
will be diminished if their quality is poor. With that
in mind, we designed a quality evaluation instrument
and had it assessed by a panel of pedagogical and
technical experts.
This paper presents the background to our work,
describing the quality evaluation instrument we
developed and summarizing the experts’ comments,
before culminating in a round-up of our conclusions
and future work plans.
2 THE LO QUALITY
EVALUATION INSTRUMENT
Given that LO quality is crucial to LO management,
surprisingly little work has been done in this area,
resulting in just a handful of proposals for
developing and enhancing LO design and evaluation
tools and processes. Williams (2000), for example,
proposes a process to desegregate and rebuild LOs
using instructional design; and, as far as we are
aware, the only evaluation instruments currently in
use consider highly imprecise, general criteria such
as motivation, interaction, feedback and so on: the
Learning Object Review Instrument (LORI), for
example, considers a basic set of nine such criteria,
yet is used to evaluate LOs by major repositories
such as the Co-operative Learning Object Exchange
(CLOE) (http://cloe.on.ca/), the Digital Library
Network for Engineering and Technology (DLNET)
(http://www.dlnet.vt.edu/), and Multimedia
Educational Resource for Learning and Online
Teaching (MERLOT) (www.merlot.org).
The imprecision of those instruments is all the
more serious in the light of the huge number of
definitions of LOs. This makes it hard, in any
endeavour to develop a means of enhancing LO
quality and, hence, effective LO management for e-
learning systems, to have a clear idea of what
actually constitutes an LO.
As LOs come in many different sizes (levels of
granularity), we decided to produce a precise
definition of LO granularity based on IEEE LOM
(2002) and featuring the following additional details
(Morales, García and Barrón, 2007c):
• Level 1: the lowest level of granularity, e.g. an
image used in a lesson (photo, video, etc).
• Level 2: a lesson – possibly a group of level 1 LOs
– focusing on a specific learning objective with a
specific kind of content (data and concepts, process
and procedure, principles, etc.), with optional
exercises (for practice and/or examination).
327
M. Morales Morgado E., J. García Peñalvo F. and Barrón Ruiz Á. (2008).
AN EVALUATION INSTRUMENT FOR LEARNING OBJECT QUALITY AND MANAGEMENT.
In Proceedings of the Tenth International Conference on Enterprise Information Systems - AIDSS, pages 327-332
DOI: 10.5220/0001712303270332
Copyright
c
 SciTePress

D/N= Don't know,
1=Very Disagree,
PEDAGOGICAL CRITERIA FOR LEARNING OBJECTS EVALUATION 2=Disagree,
3=Agree
4=Very Agree
PSYCHOPEDAGOGICAL
Motivation and Attention 3,7
Presentation: Capture learners attention mantaning their motivation
3,6
Add important information: Information need to be relevant according to the LO subject
3,7
Learners participation: LO explains very clear how learners can to participate in the lesson
3,8
Professional competence 3,9
Learning objectives help users to achieve their professional competences
3,9
Difficulty level
3,6
Contents difficulty level: It needs to be suitable for user cognitive domain
3,6
Language: It needs to be suitable for previous users knowledge
3,5
Interactivity
3,5
Interactivit
y
Level: It
p
romotes o
pp
ortunities to interact with LO in different wa
y
s
3,6
Interactivity type: LO interaction aims to achieve learning objectives
3,4
Creativity 3,8
It promotes self-learning
3,8
It promotes cognitive domain development
3,7
GENERAL COMMENTS
(Describe some examples where this LO can be reused)
3,7
Figure 1: Psychopedagogical item into Pedagogical criteria for LO evaluation.
• Level 3: a learning module made up of a set of
level 2 LOs (lessons) plus at least two or three
kinds of content (data and concepts, process and
procedure, principles, etc.), with optional
exercises (for practice and/or examination).
• Level 4: a learning course made up of a set of
level 3 LOs (modules) plus at least two or three
kinds of content (data and concepts, process and
procedure, principles, etc.), and optional
exercises (for practice and/or examination).
LOs must be clearly defined in order to be able to
establish specific quality evaluation criteria. We
must know exactly what we are evaluating. To
define a quality evaluation instrument, we decided to
consider LOs as basic units of learning – as in the
case of the prototype LOs in our Salamanca
University pilot project (Morales, García and
Barrón, 2008) – because we believed them to be
consistent with the core idea of the LO concept. We
used this as a basis upon which to determine the
kind of criteria that would serve to evaluate the
pedagogical and technical aspects of LO quality, i.e.
whether or not, and to what degree, the learning
resources in question displayed characteristics
suggesting that they could effectively achieve the
specified educational goals.
To achieve those goals, LOs must embrace a
specific range of curricular and psycho-pedagogical
issues. Curricular issues concern the subject matter,
the goals and so on, while psycho-pedagogical
issues concern the user’s characteristics (age,
learning ability, motivation, etc.).
We established a set of quality criteria for
evaluating pedagogical aspects of LOs (figure 1),
and then divided those criteria into categories and
sub-categories containing more detailed criteria.
Each of these was assessed by a panel of ten
educational and technical experts who rated each
item according to the following scale: D/N=don’t
know; 1=very disagree; 2=disagree; 3=agree; 4=very
agree.
Once the experts had rated the criteria, they each
had the chance to comment on them and suggest
ways to improve them in a face-to-face interview.
The overall rating (3.7) reflects their unanimous
agreement that the proposed criteria were sound.
The highest scoring criterion was ‘professional
skills’ (3.9), meaning that the LOs were considered
very well suited to helping students achieve their
objectives and enhance their professional skills.
The next highest scoring items were ‘creativity’
(3.8), which the experts said would be useful if the
LO promoted meta-cognitive skills and self-
learning; ‘motivation’ (3.7), which was considered
crucial for any kind of learning material; and
‘interactivity level’ (3.5), which was regarded as
critical for promoting active student participation,
but whose evaluation depended on the learning
objectives because the LOs could include lectures or
other ‘passive’ activities.
ICEIS 2008 - International Conference on Enterprise Information Systems
328

D/N= Don't know,
1=Very Disagree,
PEDAGOGICAL CRITERIA FOR LEARNING OBJECTS EVALUATION
2=Disagree,
3=Agree
4=Very Agree
DIDACTIC-CURRICULAR
Context
3,8
Formative level 3,5
Subject description 4
Objectives
3,7
Formulation 3,6
Factibility 3,7
Describe the materia that need to be learned 3,8
Coherent with general objectives 3,7
Learning Time
3,5
Time destined for learning activities may be congruent with the time disponible 3,5
Contents 3,7
Present enou
g
h information and suitable for the educational level
3,7
Contents are suitable for the proposed objective 3,7
LO
p
resent information considerin
g
different kind of formats
(
text, audio, etc.
)
3,6
LO provide contents interacion by some links 3,6
LO
p
resent com
p
lementar
y
information
(g
lsosar
y
, aids, etc.
)
3,8
The information is reliable 3,9
The information presentation aims to obtain a better contents comprehension 3,7
Language is suitable respect on learning objectives 3,5
Activities 3,8
They help to reinforce the concepts 3,9
Promotes an active participation 3,7
Presents different kind of learning strategies 3,9
Presents evaluation and practice activities 4
They proposes work modality (if if is the needed) 3,7
Feedback
3,9
Knowledge is reinforced by exercises and activities, self-evaluation, etc.
3,9
GENERAL COMMENTS
(Describe some examples where this LO can be reused)
3,7
Figure 2: Didactic-curricular section of pedagogical criteria for LO evaluation.
The next section of the LO quality evaluation
instrument focuses on didactic-curricular items, a
sub-category of pedagogical criteria (figure 2).
Once again the overall rating was very high
(3.7). The highest scoring item was ‘feedback’ (3.9),
which the experts said was especially important for
LOs because it provided pointers for reinforcing
them and their capacity to serve as basic units of
learning and knowledge containers, thereby helping
prepare students for other, more advanced and
complex, LOs.
A similarly high score was given to ‘context’
and ‘activities’ (3.8), with the experts saying that
context was crucial to an LO’s value and reusability.
The LO quality evaluation instrument must therefore
assess whether an LO is suitable for the formative
level and provides a clear enough description of its
subject.
Next came ‘objectives’ and ‘content’ (3.7). The
experts approved of the fact that these criteria sought
to assess formulation, feasibility and other such
fundamental issues. It is interesting to consider the
evaluation of specific objectives and how they relate
to general objectives because the aim is to rate the
consistency and sequence of a group of LOs (a
module, didactic unit, course, etc.)
Finally, the lowest scoring didactic-curricular
item was ‘learning time’ (3.5). The experts described
this as crucial to learning activities but said that in
some cases learning time needed to be modified
during the activities according to the objectives, the
students’ characteristics and so on. They approved
of this criterion because it was designed to assess
whether enough time was devoted to learning to
complete the allotted tasks.
As mentioned earlier, an LO quality evaluation
instrument must also cover technical criteria. In
order to identify these we analysed a number of
proposals for rating such items as multimedia
sources (Marques, 2000), educational web pages
(Marques, 2003; Torres, 2003) and usability
(Nielsen, 2000). On this basis, and with the LO as
we define it serving as a digital basic unit of
learning, we decided to sort technical issues into two
categories: interface design (figure 3) and navigation
design (figure 4) (Morales. García and Barrón,
2007a).
The highest scoring items into interface design
were ‘images’ and ‘animations’ (3.7), and the
AN EVALUATION INSTRUMENT FOR LEARNING OBJECT QUALITY AND MANAGEMENT
329

D/N= Don't know,
USABILITY CRITERIA FOR LEARNING OBJECTS EVALUATION
1=Very Disagree,
2=Disagree,
INTERFAZ DESIGN
3=Agree
4=Very Agree
Text 3,5
Text need to
b
eorganizedi
n
short paragraphs. I
t
is importan
t
to don't rompe
r
the patagraphs
continuity and the ideas which they contain. 3,4
It is recomendable that LOs consider at leas
t
the half part of a text which could
b
eusedfor
printed publication. 3,4
It is advisable to use hipertext to divide large ionformation in multiples pages. 3,6
Marc contents using titles, epighaphs, etc. 3,5
Different pages need to have different titles. 3,5
The use of capital letter need to be used only for titles, headlines or for points out specific text. 3,4
It is advisable to avoid underline text when there are not text links. 3,3
Text need to have legible kind of letter and suitable size. 3,5
The colours and kind of letters provide information by itself. 3,6
Text don't have to present any ortographic mistake. 3,9
Imagen 3,7
Images complement and support the information. 3,6
Images don't are superflues, they need to be present only if it is necessary. 3,7
Animations 3,7
The animations used need to be justified. 3,7
They need to atract the users attention to point out important information. 3,6
Animations don't have to take a long upload time. 3,7
It is advisable to avoid animations which are repeiting all the time (loop). 3,7
Multimedia
3,5
Multimedia use need to aport and be justified. 3,6
The format and file size need to mention if its download time take more than 10 seconds. 3,4
Sound 3,5
Sound need to
b
eusedonl
y
if it is necessary. Users need to have the opportunit
y
to listen the
sound in an optional way. 3,5
Users need to
b
e informed if the sound file characterisctics
b
efore to dowlown it (size, kind o
f
conection, etc. 3,4
Vídeo
3,6
Need to serve as a complement of vídeo and images. 3,6
They use need to be justified. 3,6
The images and audio need to be as clear as possible.
3,5
GENERAL COMMENTS
(Describe some examples where this LO can be reused)
3,6
Figure 3: Interfaz design item into Usability criteria for LOs evaluation.
D/N= Don't know,
USABILITY CRITERIA FOR LEARNING OBJECTS EVALUATION 1=Very Disagree,
2=Disagree,
3=Agree
4=Very Agree
NAVIGATION DESIGN
HOME PAGE
3,7
Users need to be clear what places are visiting and the what are the LO objectives 3,9
Page need to presen
t
a director
y
considering the main contents are
a
and links to complemen
t
the
information 3,6
The welcome pages do'nt have to slow down the users interaction 3,8
NAVIGABILITY
3,7
The structure need to be flexible in order to aim users to control their navigation. 3,8
Titles need to be present and be clear into ecah one of LOs pages 3,7
La intefaz de navegación muestra todas las alternativas posibles al mismo tiempo, para que los
usarios puedan escoger su opción 3,7
Users need to be clear where are the
y
in each
p
a
g
e
3,7
Users need to be clear where are the
y
into site structure
3,8
The
p
a
g
e desi
g
n is directed in
g
rant
p
art to the sub
j
ect contents.
3,7
Pa
g
es need to be sim
p
le no rechar
g
ed
4
The page design need to be strong into each one of the pages (size, colours, iconos, kind of
letter, etc.
)
.
3,7
GENERAL COMMENTS (Describe some examples where this LO can be reused)
3,7
Figure 4: Navigation design item into Usability criteria for LOs evaluation.
ICEIS 2008 - International Conference on Enterprise Information Systems
330

experts approved of the proposed criteria because
such resources could help boost the learner’s
motivation and provide useful information to
complement the text. Similar comments were made
in regard to the next highest scoring item: ‘vídeo’
(3.6).
Then came ‘text’, ‘sound’ and ‘multimedia’
(3.5), whose slightly lower score reflected the fact
that these are highly specialized domains with which
some of the experts were unfamiliar.
The experts deemed it important, therefore, that
those using the evaluation instrument either be
acquainted with the subjects covered by the various
criteria, or to omit those criteria from their
evaluation.
The experts approved or fully approved of all of
the items in the final section of the instrument,
covering usability criteria with a specific focus on
navigational aspects (figure 4).
The highest scoring item was ‘are web pages simple
and devoid of heavy graphics’ (4.0). Next came
‘does the user know the places they are visiting and
the objectives of the LO’ (3.9). This was followed
by three separate items: ‘do home pages slow down
the user’s interaction with those pages’ (potentially
demotivating); ‘is the page structure flexible enough
to allow the user to play an active role during
navigation’; and ‘is the user aware of where they are
within the site architecture’ (3.8).
The remaining five navigation-relation items all
achieved a score of 3.7.
The post-evaluation face-to-face interviews with
the experts enabled us to gather qualitative
information on the instrument itself together with a
number of suggestions for their improvement. All of
the experts agreed with the criteria proposed and the
items considered.
They also suggested editorial changes in the
wording of the items. Some said that it was
advisable to avoid the use of expressions such as
“must have” because they were too imposing and
could complicate matters for the evaluators.
On the other hand, the items should be worded
briefly and should avoid using examples likely to
influence the evaluation. All figures in this paper
have been corrected according to the experts’
qualitative evaluation.
In the final comments, some of the experts
suggested other kinds of scales aimed at rating
specific aspects of LO quality. Based on their
suggestions we have decided to introduce the
following version into our instrument as shows the
Table 1.
Table 1: LOs evaluation rating scale.
Scale
Range
Value
1,0 – 1,5 Very Low: LO quality is too bad, it
need to be eliminated
1,6 – 2,5 Low: LO quality is bad, it requires a
big improvement
2,6 – 3,5 Acceptable: LO quality is not bad,
however it needs to be improved
3,6 – 4,5 High: LO quality is good but can be
improved
4,6 – 5,0 Very High: LO quality is quite
good, it does not need to be
improved
For a balanced LO quality evaluation we
suggest calculating an average final score for each of
the four sections of the instrument so as to be able to
extract a specific value to add to our LO metadata
typology based on the LOM 9. Classification
metadata category (Morales, García and Barrón,
2007b). The aim here is to introduce numeric values
that will help the user find and retrieve LOs
according to quality-related criteria, and enable us to
develop more sophisticated LO management
capabilities, e.g. automated means using intelligent
agents that will pave the way for new quality-based
LO management tasks (Gil, García and Morales,
2007), (Morales, Gil and García, 2007).
3 CONCLUSIONS
Our model LO quality evaluation instrument
contains a wide variety of criteria aimed at
enhancing the core pedagogical quality of LOs:
meaningful logical and psychological criteria. The
first set of criteria concerns curricular issues, i.e.
whether the LO is consistent with the study
programme objectives, content, activities and so on.
The second centres on the learners’ characteristics:
learning ability, motivation, interactivity, and so on.
In order to produce a holistic evaluation of an
LO’s quality as a pedagogical digital resource (in
line with our definition of what constitutes an LO),
the instrument also focuses on assessing technical
criteria. As these types of resources can consist of
different kinds of media, our model therefore takes
into consideration the most commonly used
multimedia resources: images, video, etc.
Finally, since LOs are composed of different
kinds of media, it is important to ensure that each is
rendered accessible: e.g. an Internet site or web page
designed to enable all kinds of users to access them,
AN EVALUATION INSTRUMENT FOR LEARNING OBJECT QUALITY AND MANAGEMENT
331

taking into account personal characteristics,
navigation context, etc.
If we want to promote holistic LO quality, we
must seek to evaluate their accessibility, bearing in
mind the basic technical rules for accessible web
development: e.g. the Web Content Accessibility
Guidelines
(WCAG), which promote the Web
Accessibility Initiative (WAI)
(http://www.w3.org/WAI/). In so doing, we can help
enhance LO quality not only for existing resources,
but also for those under development.
ACKNOWLEDGEMENTS
This work was partly financed by Ministry of
Education and Science as well as FEDER KEOPS
project (TSI2005-00960) and the the Junta de
Castilla y León Project (SA056A07).
REFERENCES
Gil, A. B., Morales, E., García, F.J. 2007. E-Learning
Multi-agent Recommender for Learning Objects. En
SIIE’07. Actas del IX Simposio Internacional de
Informática Educativa, ISBN:978-972-8969-04-2, pp.
163-169.
IEEE LOM. 2002. IEEE 1484.12.1-2002 Standard for
Learning Object Metadata. Retrieved June, 2007, from
http://ltsc.ieee.org/wg12.
Marquèz, P. 2000. Elaboración de materiales formativos
multimedia. Criterios de calidad. Disponible en
http://dewey.uab.es/pmarques.
Marquèz, P. 2003. Criterios de calidad para los espacios
Web de interés educativo. Disponible en
http://dewey.uab.es/pmarques/caliWeb.htm
Morales, E. M., García, F. J., Barrón, Á. 2007a. Key
Issues for Learning Objects Evaluation. ICEIS'07, 9th
International Conference on Enterprise Information
Systems. Vol 4. pp. 149-154. INSTICC Press.
Morales, E. M., García, F. J., Barrón, Á. 2008. Research
on Learning Object Management. ICEIS'08, 10th
International Conference on Enterprise Information
Systems. (unpublished).
Morales, E. M., García, F. J. & Barrón, Á. 2006. Quality
Learning Objects Management: A proposal for e-
learning Systems. In ICEIS’06. 8th International
Conference on Enterprise Information Systems
Artificial Intelligence and Decision Support Systems
Volume Pages 312-315. INSTICC Press. ISBN 972-
8865-42-2. 2006. (B3).
Morales, E. M., García, F. J., Barrón, A. 2007b. Improving
LO Quality through Instructional Design Based on an
Ontological Model and Metadata J.UCS. Journal of
Universal Computer Science, vol 13. nº 7. pp. 970-
979. ISSN 0948-695X
Morales, E. M., García, F. J. & Barrón, A. (2007c).
Definición pedagógica del nivel de granularidad de
Objetos de Aprendizaje. EuniverSALearning’07. Actas
del I Congreso Internacional de Tecnología,
Formación y Comunicación. En Prensa.
Nielsen, J. 2000. Usabilidad Diseño de Sitios Web.
Prentice Hall PTR.
Torres, L. 2005. Elementos que deben contener las
paginas web educativas. Pixel-Bit: Revista de medios
y educación, Nº. 25, 2005, pags. 75-83.
Williams D. D. 2000 Evaluation of learning objects and
instruction using learning objects. In D. A. Wiley (Ed.),
The instructional use of LOs,
http://reusability.org/read/chapters/williams.doc
ICEIS 2008 - International Conference on Enterprise Information Systems
332
